AUTHORIZATION AND ACCESS CONTROL TO SECURE WEB

SERVICES IN A GRID INFRASTRUCTURE

Serena Pastore

National Institute of Astrophysics, Astronomical Observatory of Padova, vicolo Osservatorio 5, 35122, Padova, Italy

Keywords: Grid Security Infrastructure, Authentication and Authorization.

Abstract: Security in a grid infrastructure is implemented by adopting standard protocols that realize authentication,

authorization and access control to shared distributed network nodes, resources and services. Despite of

middleware used to built a grid, security components provide mutual authentication, delegation and single

sign-on features while every virtual organization joining the grid sets own authorization policies. Access

control and secure communication are the most important aspect of security that need to be addressed if the

shared resources are web services. This paper reports about the strategy required for securing web services

as means of an application packaged as a Web ARchive (WAR) file deployed in a grid node that has to be

shared for grid users. Software implementation uses packages coming from different past and present grid

projects that secure both web container and the application. Security chain is basically implemented by

means of java libraries to provide a message handler technique for digital signing and validating SOAP

message and an authorization engine compatible with methods adopted in grid.

1 GRID SECURITY

Grid security refers to the need for any Virtual

Organization (VO) which composes the grid

infrastructure, to share information, resources and

even applications across organizational boundaries

in a secure and highly efficient manner (Foster, I. et

al., 2001). The globally distributed feature of a grid

system should allow for all grid entities (users

belonging to a VO, nodes and services)

authentication to be identified in the infrastructure,

secure communication over the network and

authorization to make use of shared objects

according to both local (site level) and distributed

policies (VO level). Enabling remote access to

different network systems and sharing resources

require many other services like mutual

authentication among each parties forming the grid

to prove who they are, single sign-on for user and

delegation to have the necessary permissions to act

on behalf of a grid entity. Access control and secure

communication are the most important aspect of

security that needs to be addressed for sharing web

service application: access control in specific

encompasses a number of concepts that includes

knowing who users are (identity) and what they can

do in the applications (authorization) and keeping

record of what they have done (auditing). Despite

middleware used to built a grid, components which

address security requirements adopt standard

technologies. According the Globus Security

Infrastructure (GSI) (http://www.globus.org) that is

the reference architecture developed by the Globus

Alliance, the SSL(Secure Sockets Layer) protocol

provides secure communication, authentication is

realized by using digital certificate of the Public Key

Infrastructure(PKI) (http//www.ietf.org/), while

various authorization models are implemented. GSI

creates a basic security mechanism that does not

require a centralized management authority. Public

key cryptography is used for digitally signing any

piece of information. Each grid entity has an unique

identity composed by a signed certificate following

the X.509 format and a private key (credentials)

which authenticate it in grid. A Certification

Authority (CA) guarantees identities by issuing

signed certificates that validate individuals and

organizations: in a global grid environment with

many parties involved, each CA is structured to form

a hierarchy of trusted entities. Delegation and

mutual authentication services are provided to grid

by a proxy method. This introduces new temporary

credentials (a certificate signed by the owner from

the original one and a private key with a limited

lifetimes) that can be passed to any grid resource.

Authorization indeed outlines the core problem in

264

Pastore S. (2006).

AUTHORIZATION AND ACCESS CONTROL TO SECURE WEB SERVICES IN A GRID INFRASTRUCTURE.

In Proceedings of WEBIST 2006 - Second International Conference on Web Information Systems and Technologies - Internet Technology / Web

Interface and Applications, pages 264-267

DOI: 10.5220/0001252802640267

 SciTePress

grid setting that is how to handle and combine the

overlay of polices imposed by different

organizations. A first method uses a global-to-local

identity mapping by a special authorization file

called

grid-mapfile. A LDAP directory stores the

list of certificates corresponding to users affiliated to

VOs and this information is used to create a file that

contains mappings from the user identity to a local

user account (real or pool). The file, distributed in all

grid nodes and frequently updated, is checked

whenever a host receives a request addressing a

service or resource that needs authorization. Other

solutions leave access control decisions to each

organization composing the system. An example is

the Virtual Organization Membership Service

(VOMS) method (Alfieri R. et al., 2005) for central

users management at VO level. The approach allows

to catalogue each users on adhering on groups, roles

and capabilities mapping identities with roles.

Sharing web services application for a VO in a grid

site offers many integration advantages, but presents

security challenges: it should be only accessed by

identified users according security policies locally

implemented. The paper looks at the strategy of

securing web services application to be shared in a

specific grid environment like the Italian INFN

production grid (http://grid-it.cnaf.infn.it). The case

study refers to apply control access rules to java web

services deployed as Web ARchive (WAR) file

whose security process makes use of software

developed in grid projects.

2 GRID TESTBED DESCRIPTION

AND WEB SERVICES

SECURITY CONCERNS

The reference grid infrastructure (http://grid-

it.cnaf.infn.it) consists of several VOs representing

different institutes: each one contributes with

distributed grid nodes to provide resources and

services. The testbed is built on a specific grid

middleware (INFN-GRID) that gathers many

software developed in past and present grid projects

running on Linux platforms. Among these, Globus

Toolkit (GT) developed by Globus Alliance

(http://www.globus.org), EDG software of DataGrid

project (http://lcg.web.cern.ch/LCG/), LCG

middleware provided by CERN (http://eu-

datagrid.web.cern.ch/eu-datagrid/) and gLite toolkit

of EGEE project (http://glite.web.cern.ch) are the

mainly used. They implement many grid features by

means of modules installed on grid nodes. The

resulting architecture

(https://edms.cern.ch/document/439938/1) outlines

logical machine types specifically named to

represent single functionalities that VOs share in

grid. Each site contributes with at least Computing

Element (CE) that is a frontend node defined as a

batch queue system built on a homogenous a farm of

computing nodes (Worker Nodes) behind it and

Storage Element (SE) that provides uniform access

to storage spaces. Grid gateway allowing for

command line interface to grid operations is usually

the User Interface (UI) machine even if grid portal

are also available. Specialized sites provide

management features like the information service

that keeps updated information about distributed

resources and the workload management system that

is responsible of match-making between best

resources and job requirements and the scheduling

and processing of the job itself. In this testbed both

users, hosts and services must possess valid

identities released by a trusted CA: the INFN

institute manages a CA organized in a set

Registration Authorities (RAs) to locally delegate

the identification.

The trusted CAs root certificates as well as the

certificate revocation lists (CRLs) are available in

rpm formats and installed in grid machines (in the

/etc/grid-security directory),where credentials

of grid entities that share servers or services are also

stored with the proper permissions. Grid credentials

are kept in a specific UI directory (the

.globus

directory) or in the browser. On demand services use

delegated credentials from either the system or user.

Identities are centrally managed by LDAP directory

or relational database: the VO structure (each user

registers to at least one VO) has brought to the

VOMS client-server system for users certificates

management and attributes-based authorization.

Digital certificates are used for authentication, but

also for single sign-on and delegation services: the

proxy mechanism enable the creation, on behalf of

the client, of a short term proxy certificate that will

be used during a session for all subsequent

Figure 1: Distribution of grid entities certificates: creation

of a VOMS proxy certificate and information attached to

it.

AUTHORIZATION AND ACCESS CONTROL TO SECURE WEB SERVICES IN A GRID INFRASTRUCTURE

265

interactions with the grid. A specific proxy

certificate that includes VOMS extensions is created

with the command

voms-proxy-init (figure 1).

Globus proxy certificates differ from standard

proposed simply adding the prefix “

CN=proxy” to

the subject DN: VOMS extensions that contain user

authorization information extracted by the VOMS

server are simply included in it and may be passed

directly or delegated remotely to grid services which

extract it for checking. Securing web services in this

infrastructure is a system-wide concern: transport

security (SSL) or message security (SOAP security)

together with secure single sign-on play a part in

providing protection against unauthorized access.

Transport security realizes privacy and data integrity

as well authentication of the communication end

points (HTTPS), message security focuses on

confidentiality (content protection) and integrity

(avoiding modification). Moreover web services are

deployed in specific SOAP engine that supports the

idea of message handler means SOAP messages pass

through a series of processing steps prior to actually

delivering the message to the service

implementation code. Security constraints applicable

to secure web services could be addressed in grid by

using the Trust Manager and Authorization

Framework implemented by middleware packages

named respectively

glite-security-

trustmanager

and edg-java-security.

3 SECURING WEB SERVICES IN

GRID

The approach described to provide secure web

services in grid is applied to a case study of a grid

application that offers facilities over distributed

astronomical databases (Pastore et al., 2004) even if

the security process could be generally applied.

From a technical perspective a web service is a

collection of related operations described by service

description (XML) and network accessible through

XML messaging (SOAP protocol). The application

is structured as a set of java web services processed

by the Axis SOAP engine and deployed in Tomcat 5

web application container running on a digitally

certified CE element: access to services is enabled

for authenticated grid users with specific

authorization rules both by submitting a job from a

UI and using graphical mode (i.e. web pages

developed in JSP technology). The overall security

process (figure 2) which every incoming request to

web services is subjected to, can be divided into

authentication and authorization steps. The client

SOAP request containing the certificate is send to

the HTTP listener. The authentication phase deals

with the verification of the client identity through

validation of X.509 certificate paths, and is

performed by a gLite module known as Trust

Manager.

Figure 2: Modules schema for processing secure web

services and description of a policy applied.

The authorization step should check the mapping

between user credentials and access role and is done

by an EDG module called Authorization

Framework. This includes the insertion of an handler

in front of the web service to be protected and the

instantiation of an authorization engine

(Authorization Manager) that along with an optional

user management interface, it allows or denies

access following the policy specified. The engine is

in fact organized as a collection of Policies, one for

each service that needs protection.

3.1 Trust Manager and

Authorization Framework

The Trust Manager, overriding the standard Tomcat

implementation, provides a java implementation of

SSL protocol to support Globus proxy certificates

format and CRLs of CAs. Enabling server-side-only

SSL on the Web service platform, ensures messages

protection in the interaction but with the limitation

of securing a single communication channel. After

that the client request is verified for authorization

step, before passing on to the actual service

implementation. The signed SOAP request is

intercepted and submitted through an Axis handler

implemented as a java class that protects the web

service implementation. The handler examines the

request, extracts the client certificate and all

information embedded (i.e. subject DN and

attributes), communicates with one instance of the

Authorization Manager to whom delegates any

decision and gets back the result of the step to access

or deny the service. The policy (figure 2) applied to

web service is defined in a XML configuration file

(

AuthzManager.xml) to perform a two-step

mapping between the client (its DN) and a given role

WEBIST 2006 - INTERNET TECHNOLOGY

266

and (optionally) between such attribute and a local-

ID value usable by an application. These phases are

specified into distinct sections: AttributeRepository

and TranslationMap. Both define attribute types

where to find the information needed to the

authorization process. For example in the VOMS

management, the

voms type defines the use of

VOMS extensions for checking rules. Otherwise the

second mapping always gets the information from

pluggable storage module (

AttributeMap) that

stores associations in a memory map and in turn

specifies their behaviour (i.e.

regex value allows

for keys specification as regular expressions).

3.2 Practical Steps for Access Secure

Web Services Implementation

The full process requires the installation and

configuration of the java environment, related

libraries (i.e. cryptographic libraries) and other tools

(i.e. logging services) together with digital

certificates for CAs and hosts involved. Client

interaction with web service requires the installation

of users digital credentials. Both

glite-

security-trustmanager and edg-java-

security provide client and server java libraries to

be used in applications. Trust Manager software

gives configuration files and scripts to modify

standard Tomcat 5 configuration and interact with it

through the secure connection (8443 port) validated

by host credentials. Web services deployment

usually means the availability of the application as a

single Web ARchive (WAR) file: the security

process setup requires the settings of the modules

and libraries and files inclusions before the

automatic packaging made with Ant tools. Java

libraries for server authentication and authorization

should be available in the specific library application

directory as well as the Axis ones. The configuration

of the Authorization Framework requires the setup

of the manager file to specify authorization policy

applied, the registration of the Axis Handler with the

service itself in the service deployment descriptor

(

server-config.wsdd) and the definition of

handler parameters (i.e. log4j configuration file,

location of the manager file, default policy, etc.) in a

text file (called

AuthzHandlerConfig.txt)

whose location is specified in the web application

descriptor (

web.xml). Once deployed in the

container, every client java application accesses the

secure web service by using authentication and

authorization libraries.

4 CONCLUSIONS

Strategy for securing web service application to be

shared in grid environment as WAR file, addresses

secure communication and access control.

Implementation of security constraints are realized

by using specific grid software. Trust Manager (by

gLite) provides digital authentication supporting

proxy methods. Authorization Framework (by EDG)

realizes the authorization process required to access

control to web services by means of a message

handler technique to validating messages and an

authorization engine that describing policy in XML

format is compatible with the VOMS system used

for VO level managing. This allows for setting

specific access role for such shared resources based

on VOMS attributes. Despite of software

implementation, the security design is applicable for

every java web services. Moreover the use of XML

technologies allows to increase security by applying

in future development web services security-focused

specifications introduced by WS-Security, XML

signatures or XML encryption standards.

REFERENCES

Foster, I. et al 2001. The Anatomy of the Grid: Enabling

Scalable Virtual Organizations. In Journal

Supercomputer Applications, 15(3).

The Globus Security Infrastructure (GSI) of the Globus

Toolkit. At URL: http://www.globus.org

Public-Key Infrastructure (X.509). At url:

http//www.ietf.org/.

Alfieri, R. et. al, 2005. From gridmap-file to VOMS:

managing authorization in a Grid environment. In

Future Generation Computer System 21 549-558.

Italian National Institute of Nuclear Physics (INFN) grid

infrastructure. At url: http://grid-it.cnaf.infn.it).

LCG middleware (at url: http://lcg.web.cern.ch/LCG/) for

the LHC (Large Hadron Collider) projects

European DataGrid (EDG) project (at url: http://eu-

datagrid.web.cern.ch/eu-datagrid/)

gLite (at url: http://glite.web.cern.ch) software for the

Enabling Grids for E-sciencE (EGEE) project (at url:

URL: http://egee-intranet.web.cern.ch).

DataGrid Software Architecture Models, 2004. At URL:

https://edms.cern.ch/document/439938/1

Pastore, et al., 2004. Enabling Access to astronomical

databases through the grid: a case study. In Proc. of

Astronomical Data Analysis III Conference.

AUTHORIZATION AND ACCESS CONTROL TO SECURE WEB SERVICES IN A GRID INFRASTRUCTURE

267
