TRANSFORM:

A TRANSACTION SAFE WEB APPLICATION MODEL

Matthias Ihle and Georg Lausen

Institut f

ur Informatik

Universit

at Freiburg

Georges-K

ohler-Allee, 79110 Freiburg i. Brsg.

Germany

Keywords:

Web applications, web forms, transactions, concurrency control.

Abstract:

Classical models of database-driven web applications follow thin-client architectures, i.e., all data processing

and business logic resides on the server while the client’s role is to arrange and display the user interface.

When transactions come into play, which may naturally span several consecutive interactions between client

pages and server actions, problems arise since transactions cannot exceed the boundaries of server actions.

We address this issue by proposing a novel architecture for web applications, where a webservice-based data

access component is integrated directly in the markup of a client page. Our approach guarantees ACID trans-

action properties and generates serializable histories in the sense of conﬂict serializability. In contrast to past

efforts to transaction management in web applications, our architecture does not necessitate the existence of

an additional, external transaction server.

1 INTRODUCTION

Enterprise applications which are generally data-

centric and transaction-based are often form-based

systems with a submit/response style interface (Dra-

heim and Weber, 2004). A proven architecture for

such interfaces are thin client web applications, where

the browser forms the interface tier and the applica-

tion logic is implemented in different actions on the

web server. These server actions deliver pages to the

client and, eventually handle a database connection.

The human-computer-interaction works via the ex-

change of messages between client pages and server

actions. In a typical scenario, some initial values are

read from a database during a server action and dis-

played in web forms of a corresponding client page.

Now a user can edit the data in the forms and send it

to another server action that writes the changed values

back to the database and displays the result in another

client page.

Such a web form lifecycle, intended to happen in

a single transaction, spans several transitions between

client pages and server actions. Unfortunately it is not

possible to embed the whole form processing into one

single transaction of the underlying database system,

since such transactions cannot exceed the boundaries

of a server action.

The reason for this is that each server action needs

a new database connection, since it is unpredictable in

which process, respectively thread on the web server

it is executed. Even persistent connections that pro-

vide a pool of open database connections cannot grant

the assignment of the same connection in two consec-

utive server actions.

Usually, the problem is resolved by adoption of ex-

ternal transaction servers or an application speciﬁc so-

lution.

The contribution of this paper is a novel model for

web applications that provides a web service based

database interface. Thereby we utilize the AJAX

(Garrett, 2005) technologies of current browsers and

access this interface via HTTP (Fielding et al., 1998)

requests from within javascript. The access to this

interface is deﬁned directly in the markup of a web

page.

The beneﬁt of our model is that we can bundle

all data access operations within a client page into

a transaction satisfying the ACID properties (H

arder

and Reuter, 1983). For that, we do not even need ad-

ditional components beside the web server.

In our model a transactional web page is created by

a server action independently of the database state.

Hence, a transaction in a client page is completely

self-contained and there is no need to consider the

164

Ihle M. and LausenLausen G. (2006).

TRANSFORM: A TRANSACTION SAFE WEB APPLICATION MODEL.

In Proceedings of WEBIST 2006 - Second International Conference on Web Information Systems and Technologies - Internet Technology / Web

Interface and Applications, pages 164-171

DOI: 10.5220/0001253101640171

 SciTePress

Figure 1: The classical form processing mechanism.

preceding server action.

As it is typical, we assume that all data access hap-

pens via our interface. Otherwise the transaction man-

ager of the database system interferes with that of our

web service.

The remainder of this paper is organized as follows:

section 2 presents the different parts of the TransForm

model in detail, while section 3 describes the sched-

uler we have implemented in our prototype. Section

4 summarizes the ﬁeld of research and ﬁnally, section

5 concludes the paper.

2 TRANSFORM

In TransForm, the data access during the lifecycle of

a web page is enclosed in a transaction with the well

known ACID properties. Actions of such a transac-

tion, for instance, read initial values of form ﬁelds or

write them back to the database, when edited. Addi-

tionally, there are actions that begin, abort or commit

a transaction.

Therefore we do not use the standard form process-

ing mechanism, depicted in ﬁgure 1. Here, several

server actions and client pages are needed to process

a form. A ﬁrst server action creates a client page con-

taining form values read from the database. Then, af-

ter changing the values, a user submits the form to

a second server action which writes the new values

back to the database and displays the result in another

client page.

On the other hand, the TransForm procedure is

shown in ﬁgure 2. The complete processing of the

form is done within a single client page. The corre-

sponding transaction is not inﬂuenced by the server

action delivering the page, since the page generation

happens independently of the database state. There-

fore, in the ﬁgure this server action is depicted in grey.

Figure 2: The processing of forms in TransForm.

We can simply assume a static web page with

empty form ﬁelds containing deﬁnitions of the

database objects that the form ﬁelds are associated

with. After the page is loaded in the browser, a

javascript program starts the transaction and reads the

initial form values from the speciﬁed database ob-

jects. With the help of javascript event handlers this

program now propagates user actions to the database,

whenever a form ﬁeld changes or the commit, respec-

tively abort of the transaction is requested.

All these transaction operations happen via a state-

less web service that constitutes the interface to the

database in our TransForm model. Beside the re-

quested operation a transaction identiﬁer must be

speciﬁed in every service invocation. This identiﬁer

is generated by the operation starting the transaction

and hold by the javascript program in the client page.

The web service now wraps all operations with the

same identiﬁer into a single transaction for which the

ACID properties are guaranteed. Now, if the access to

the database happens exclusively with this web ser-

vice interface, TransForm produces conﬂict serializ-

able schedules only. If other database interfaces are

used simultaneously, the transaction manager of the

database interferes with that of the web service. This

way non serializable schedules may occur.

Behind the web service interface different sched-

uler strategies can be deployed. In our implementa-

tion we have opted for an optimistic strategy that is

considered in detail in section 3.

All the information to access the web service, e.g.

the connection of a form element to a database ﬁeld

or the URL of the service, in our model needs to

be deﬁned within a client page. Therefore, Trans-

Form deﬁnes custom tags that are interleaved with the

HTML tags in the markup of the web page. Every

tag contains the database object it is connected with

and stands for a particular HTML representation in

the web page.

TRANSFORM: A TRANSACTION SAFE WEB APPLICATION MODEL

165

The beneﬁt of this tag based data access facility is

that it can be easily embedded into web application

modelling frameworks, like (Ceri et al., 2000), that

generate HTML pages in their output, since a Trans-

Form page basically is an ordinary web page con-

nected with an additional javascript program.

We will see in the remainder of this section how

this works in detail. Therefore, we ﬁrst present the

data and transaction model before we describe the

web service and the client interface in the following

subsections.

2.1 Data Access Model

TransForm establishes an additional layer on top of

the database system implementing its own data man-

ager and transaction manager. The data manager ad-

dresses objects in the database and identiﬁes conﬂicts

among them.

Therefore it represents the actual database in XML.

Now, objects in the database are addressed by XPath

expressions (W3C, 1999). Although this additional

layer certainly has its impact on performance, there

are some incitements to do so:

• If we connect a web form element with a relational

database ﬁeld with the help of an XPath expression,

the respective SQL statement can be automatically

generated for read and write operations. Otherwise,

we would have to state separate select and update

statements for every form element.

• With this abstraction layer we can support not only

relational backends but also native XML or docu-

ment databases. We can even use storage facilities

that come without native transaction support like

regular ﬁle systems.

• Performance is in the majority of cases not a big

issue because the system is mainly idle waiting for

user inputs.

With the help of XPath expressions we now de-

tect conﬂicts among the database objects, even when

they occur because referential integrity constraints are

deﬁned among the tables in an underlying relational

database. However, it would go beyond the scope of

this paper to describe this functionality in detail.

Hence, for the remainder of this paper we sim-

ply assume a page model for the transactions where

database object, speciﬁed by XPath expressions, are

read and written.

Here, a data access operation simply is of the form

r(x) or w(x, v). Thereby x is an XPath expression on

the XML representation of the database specifying a

database object. Furthermore, v is a value of the type

of x. So, r(x) reads and returns the value of x while

w(x, v) writes v to x.

The write operation covers insert, delete and update

in the following way: an empty v means a delete of x

while a non empty v is an update and an x that is not

in the instance graph is interpreted as an insert.

2.2 Transaction Model

Besides the data manager, TransForm provides its

own transaction manager that wraps single opera-

tions, called actions, into transactions.

In this model, an action is a pair (t, a). Thereby, t is

a transaction identiﬁer and a is either r(x) or w(x, v),

the data access operations of the previous subsection,

or one of the following transaction control operations:

• begin: starts a new transaction.

• abort: aborts the transaction.

• commit: tries to commit the transaction.

Now, a transaction t is an ordered sequence of ac-

tions that all share the same transaction identiﬁer. Ev-

ery transaction has exactly one begin action as its ﬁrst

step and either abort or commit as its last step.

2.3 Web Service Architecture

As we have deﬁned transactions and their enclosed

actions in the previous subsection we now need to

adapt them in the web service. In essence, an action

corresponds to an invocation of the web service.

The transaction identiﬁer is thereby not an inherent

part of the service, it is rather speciﬁed as argument

by the service caller. So, a transaction is basically

a subsumption of service invocations with the same

transaction identiﬁer.

With every service invocation, operations on the

underlying database system are carried out. These

operations depend on the actual protocol used by the

scheduler. Thereby, it is important that the operations

of a service invocation occur in a serial, non inter-

leaved order with respect to the underlying database

system. Additionally, the service call should happen

in an atomic fashion. The simplest way to achieve this

is to embed all steps performed during a service call

in a native transaction of the database system. This is

possible, because all the steps are executed during a

single server action. If the database system does not

have its own transaction facilities, some kind of lock-

ing mechanism needs to be provided.

Because we utilize the AJAX technology of cur-

rent browsers to invoke the web service via HTTP

requests in javascript, the use of the SOAP protocol

(W3C, 2000) is inappropriate. We rather follow the

REST (Fielding, 2000) web service design which has

the following characteristics:

• The service is comprised of a resource which is

named using a URL.

• The resource is accessed through a generic inter-

face, in this case HTTP via the GET method.

WEBIST 2006 - INTERNET TECHNOLOGY

166

• It is stateless, i.e. each request from the browser

to service must contain all the information neces-

sary to understand the request, and cannot take ad-

vantage of any stored context on the server. For

instance, the identiﬁer of the transaction a service

invocation belongs to must be contained in a call

argument.

• The response is an XML document. In our case, it

contains information about success of operations,

requested values or detected conﬂicts that lead to

transaction aborts.

So the service is basically a HTTP call to the ser-

vice URI where the requested action is speciﬁed in

the GET variable action. Depending on the con-

crete action, further arguments are required. For the

allowed actions this is as follows:

• begin: No further argument is needed. This action

returns the transaction id.

• abort: The transaction id must be speciﬁed in the

additional argument tid.

• commit: Here also the tid must be speciﬁed. The

return value is either success or failure.

• read: In addition to the tid the object to be

read needs to be given. The value of this object is

returned.

• write: It takes the same arguments as read plus the

value of the object via the value argument.

Example The following service invocation requests

the commit of the transaction with the id 3. The

service is located at the host serviceurl under

the path servicepath.

http://serviceurl/servicepath

?action=commit&tid=3

The respective response to the above request could

be the following XML document:

failed

</response>

The response signals that the commit has failed due

to a conﬂict with another transaction.

2.4 Browser Tags

Having the web service available, we need to embed

it in web sites. Therefore, we introduce special tags

in the page markup that encode all the necessary in-

formation like the database objects they are connected

with in their attributes. These tags are converted into

suitable HTML elements by a javascript program that

is invoked when the browser has loaded the page. To-

gether with normal HTML these tags build the skele-

tal structure of TransForm web pages.

The javascript program is additionally responsible

for the following tasks:

• It ﬁrst parses the document to identify all Trans-

Form tags. Therefore it uses the DOM representa-

tion of the web page, an interface with whom the

various page components can be accessed and ma-

nipulated.

• It starts a transaction for every tf:form element that

it ﬁnds during the initial parse with a begin request.

In the response to this request it gets an identiﬁer

for every transaction. Because this id is needed in

all further service requests it is stored during the

lifetime of the transaction.

• It takes care of the complete processing of the ser-

vice requests. Therefore, event handlers are set ac-

cordingly and AJAX objects are created when such

an event triggers. Furthermore, it handles the ser-

vice response messages. Retrieved values are writ-

ten to form elements and, in case of conﬂicts, trans-

action aborts are triggered.

In the following we present some selected tags that

are used in the example in ﬁgure 3:

<tf:form serv="url"> This tag forms the

boundaries of a transaction. All further TransForm

tags inside it belong to the same transaction. Addi-

tionally, it speciﬁes the URL of the web service in

the serv argument. With this mechanism we can

deﬁne access to several databases in a single web

page. This leads to distributed transactions that are

explained in section 3.2.

This is similar to the ordinary HTML form element

that speciﬁes a server action and contains all the

elements of the form.

<tf:input xpath="x"> This tag is converted

into an ordinary HTML input form element. It re-

trieves its initial value by a read request for object x.

Additionally, an event handler is set that requests a

write operation whenever a user changes the value

in the form.

<tf:abort> Here, the javascript program creates

a button with whom the user can explicitly request

the abort of the current transaction. In such a case, a

new transaction is started and the values of the form

ﬁelds are retrieved once again from the database.

<tf:commit> This tag is also converted into a

HTML button with whom the user can request the

commit of the current transaction. Every tf:form

tag must contain a commit button, otherwise the

user can never request the commit of the transac-

tion.

Figure 3 shows an example of a TransForm page. It is

an ordinary HTML page with some custom tags that

a browser does not display when rendering the page.

In the page header a javascript ﬁle is included that

TRANSFORM: A TRANSACTION SAFE WEB APPLICATION MODEL

167

<html>

<head>

</head>

<div>

<tf:form service="url" protocol="opt">

<tf:input xpath="a[b=2]/a">

<tf:input xpath="a[b=2]/c">

<tf:commit/>

</tf:form>

</div>

</body>

</html>

Figure 3: An example of an HTML document interleaved with TransForm tags.

contains the aforementioned program. The body el-

ement deﬁnes an onload event handler that invokes

the transform() function. This function now converts

the TransForm tags according to the above description

and starts a transaction for the contained tf:form ele-

ment. It sets the event handler for the tf:input and the

tf:commit tags accordingly, for instance, an onclick

event for the submit button.

For every event an appropriate handler is deﬁned

in the script. This handler creates an AJAX object

for every request that asynchronously invokes the web

service. Therefore, a callback function is deﬁned that

handles the response of the request.

Example scenario Suppose two users, X and Y ,

each load the above example page and edit the form

ﬁelds depicted by the tf:input tags. In each browser

a transaction is started and the initial values are re-

trieved via respective begin and read service calls.

Let user X change the values of both input forms

while user Y simply changes the value of the object

a[b =2]/a.

A scheduler would now detect a conﬂict because

both transactions write the same object (a[b =

2]/a). Depending on the order of the commits

requested by pressing the commit button and the

particular scheduler strategy one transaction is ac-

cepted and committed into the underlying database

while the other one is rejected and all its write op-

erations are discarded.

At the end of this section it is clear that a TransForm

page only makes use of standard web technology and

therefore still is an ordinary HTML page with some

non-standard tags and a dedicated javascript program.

This has the beneﬁt that it integrates well into web

application frameworks that normally produce web

pages in their output. Thereby, it provides them with a

transaction safe data access component. It must solely

be taken care that the generation of the web pages

still is independent of the database that is used within

the page. Otherwise the transaction safety cannot be

guaranteed anymore.

3 SCHEDULER

Behind the interface presented in the previous section

different scheduler strategies are possible.

Thereby, it is not necessarily clear that the same

strategies proven for classical databases are also well

suited in the context of the web environment.

Here we deal with online transactions where it is

not possible to simply rerun a failed transaction. In

such a case, the user needs to specify the values to be

written in the database again depending on different

read values.

Hence, we ﬁrst gather the requirements of sched-

ulers in the context of web applications and dis-

cuss the pros and cons of several classical schedulers

strategies found in (Weikum and Vossen, 2001):

• The scheduler protocol must not constrict the form

editing when several users work with the same

database objects. It should only interfere when the

current transaction cannot be committed anymore.

• If transactions are in conﬂict with each other the

accepted transaction should be chosen after a ’ﬁrst

come ﬁrst serve’ principle.

• On the other side, if a page processing cannot be

commit ed because unresolvable conﬂicts have oc-

curred, the scheduler should not defer a conﬂict no-

tiﬁcation until a user requests the commit opera-

tion.

• Read-only transactions must not affect transaction

aborts for writing transactions.

Locking schedulers require the explicit locking of

database objects for both reading and writing. Be-

cause we do not know when a user has ﬁnished the

WEBIST 2006 - INTERNET TECHNOLOGY

168

work on a form ﬁeld we would have to hold the locks

from the begin of the transaction when the initial val-

ues are read until the commit. This could lead to a se-

rial transaction execution and reduce parallelism dras-

tically.

The timestamp ordering protocol evades locks by

use of totally ordered, unique timestamps that are

assigned to each transaction. This protocol has the

drawback that among several conﬂicting transactions

only the one with the highest timestamp successfully

commits. This is not compatible with requirements

two and four.

In our implementation, we have opted for an opti-

mistic protocol (H

arder, 1984; Kung and Robinson,

1981) where newly arriving operations simply pass

and the burden of concurrency control is deferred un-

til the end of the transaction. Thereby, detected con-

ﬂicts are resolved by aborting transactions.

The execution of a transaction is divided into two

phases, the read phase and the valwrite phase. During

the read phase all read operations are logged in the

readset RS and all write operations are performed in

a private workspace, the writeset WS. So the writ-

ten values are not visible to other transaction before a

transaction successfully commits.

The valwrite phase is initiated with the commit op-

eration. It tests whether the transaction execution has

been correct in the sense of conﬂict serializability. If

so, the writeset of the transaction is transferred to the

database, otherwise the transaction is aborted.

This protocol meets best the previously formulated

requirements. It is only perceivable in the case of con-

ﬂicts and favours the transaction which initiates the

commit ﬁrst.

3.1 The FOCC Scheduler

Our scheduler protocol follows the forward oriented

optimistic concurrency control presented in (Weikum

and Vossen, 2001), where a transaction is validated

against all concurrent transactions.

Here, a transaction t

is validated at the time n if

the following holds for all concurrent transactions t

WS(t

) ∩ RS

)=∅

Thereby, RS(t) and WS(t) are the readset and write-

set of transaction t.

Hence, the scheduler makes sure that no values

other concurrent transactions have read are overwrit-

ten, and thereby outdated, by the validating transac-

tion. This is immediately satisﬁed if the validating

transaction is read-only.

Since these transactions are not yet committed we

gain some ﬂexibility in handling a detected conﬂict.

In order to satisfy the second requirement we follow

the ’kill and commit’ scheme presented in (H

arder,

1984), where a non validating transaction neverthe-

less commits and the conﬂicting transactions abort.

To sketch the proof that our scheduler produces

conﬂict serializable schedules only we show that the

produced conﬂict graph is acyclic.

With the commit of transaction t

we insert the new

node t

into the so far acyclic conﬂict graph. If the

graph became thereby cyclic the node t

had to be

involved in the cycle. Therefore, the node t

had in-

coming and outgoing edges. For an incoming edge

would have read values that were written by an al-

ready committed transaction. That would have lead to

an abort of t

. So, only outgoing edges are possible

and the conﬂict graph remains acyclic.

Beside the readset and the writeset our scheduler

has to hold the status of all running transactions in an

internal table. Thereby, the status of a transaction is

either running, committed, aborted or in conﬂict.

In the following we resume the actions taken by our

scheduler for each possible request:

• begin: The scheduler generates a new unique trans-

action id and inserts it in the status table as running.

• abort: The readset and writeset of the transaction

is deleted and the status of the transaction is set to

aborted.

• commit: The transaction is validated and the write-

set is transferred to the database. If the valida-

tion was not successful the status of the conﬂicting

transactions is set to in conﬂict.

• read: First, it is checked whether the transac-

tion status is set to in conﬂict. In this case the

browser is signaled to abort the transaction, other-

wise the value of the requested object is read from

the database and the readset is updated.

• write: Similar to the read request either the writeset

is updated or a conﬂict is signaled.

Example An example for the execution of a schedule

under this protocol is shown in ﬁgure 4.

At time of the commit of transaction 1 its writeset

and the readset of the only concurrent transaction

2 are disjoint, so the validation is successful and

transaction 1 is written to the database.

The next transaction to commit is the second. Its

writeset is only disjoint with the readset of concur-

rent transactions 4 and 5 while it overlaps with the

readset of transaction 3 (RS(3) = z, WS(2) = z).

So, the status of transaction 3 is set to in conﬂict

and with its next operation, here r(x), a conﬂict is

signaled and consequently the transaction aborts.

The next committing transaction is the read-only

transaction 5. It has an empty writeset and thus suc-

cessfully validates. The validation of transaction 4

now trivially succeeds, since there are no more con-

current transactions.

TRANSFORM: A TRANSACTION SAFE WEB APPLICATION MODEL

169

Figure 4: An Example schedule.

3.2 Distributed Transactions

As we have already seen in section 2.4, TransForm

even supports distributed transactions (Bernstein and

Goodman, 1981). There, several services working on

different databases were addressed in one web page.

Of course, global serializability must be guaranteed.

Therefore, the subtransactions at each site, respec-

tively service, either commit or abort altogether.

Fortunately, the following holds for distributed

transaction over several sites (Lewis et al., 2002): If

the concurrency control at each site uses an optimistic

algorithm and the system uses a two-phase commit

protocol, every global schedule is serializable.

The two-phase commit protocol (Lampson and

Sturgis, 1979) is easily adapted in our system. We

therefore just need the additional transaction control

operations prepare, ready and done. The javascript

program naturally takes the role of the coordinator.

4 RELATED WORK

Concurrency control is a well known problem in the

domain of web applications.

A typical approach to solve this problem is the one

taken in JPernLite (Yang and Kaiser, 1999) that sup-

ports advanced transactional features for web applica-

tions. Unlike TransForm, JPernLite is a middleware

approach where an external transaction server that op-

erates independently of web servers provides the con-

currency control capabilities to client applications.

Cheetah (Pardon and Alonso, 2000) is a java-based

set of tools for building composite components that

interact transactionally. Its main contribution is the

composite system architecture and the support for

nested transactions that are not addressed in our ap-

proach.

Besides the use of external components there have

been attempts to build transactional capabilities into

the existing WWW infrastructure. In contrast to

TransForm, in (Lyon et al., 1998) web servers must

be extended to be compliant to the protocol that pro-

vides the concurrency control functionality. Then, a

client can explicitly submit operations as part of trans-

actions.

WebDav (E. James Whitehead and Goland, 1999)

is an HTTP extension for web servers that intend to

support locking of their web pages. In (Shadgar and

Holyer, 2004) the authors make use of WebDAV to

provide a methodology for accessing and authoring

databases.

Though this last approach comes close to our sys-

tem in addressing a database object via an URL,

TransForm is to the best of our knowledge unique in

that it provides transaction safe data access for web

application without the need for additional compo-

nents besides the web server.

5 CONCLUSION

In this paper we have presented TransForm, a novel

model for web applications that speciﬁes the access

to data sources directly in the markup of a web page

and executes it with the help of a javascript program in

WEBIST 2006 - INTERNET TECHNOLOGY

170

the browser and a web service that forms the interface

to the data sources.

We have shown that this data access happens in a

transaction safe way. Thereby transactions span the

whole lifecycle of a web page and are independent of

the preceding server action if this server action gener-

ates the page without dependency on the database.

Hence, TransForm integrates well into other web

application frameworks providing them with a con-

currency control component.

We have presented the scheduler of our implemen-

tation, following an optimistic approach, as one of

several possible scheduler strategies. Optimistic con-

currency control schemes were designed under the

explicit assumption that conﬂicts among transactions

are rare events. This does not hold generally in the

context of web applications. So, our scheduler may

not be the best in all circumstances and therefore we

plan to examine other strategies and test them under

different server workloads.

Another ﬁeld we are working on is the resource op-

timization. Currently only the transaction id is stored

in the browser while the service manages the bulk of

context information for all running transactions. In

order to increase the server performance we try to

shift parts of this context information to the browser,

which in turn submits it back to the service when re-

questing a transaction commit.

In this paper we have mainly presented the parts

of TransForm that deal with form processing. Albeit

an important part, it is only one aspect of the com-

plete framework. TransForm provides support for ar-

bitrary services that can be included into a web page

in a transaction safe way. They range from the inte-

gration of dynamically created parts of the application

to the embedding of commercial off-the-shelf compo-

nents (COTS).

REFERENCES

Bernstein, P. A. and Goodman, N. (1981). Concurrency

control in distributed database systems. ACM Comput.

Surv., 13(2):185–221.

Ceri, S., Fraternali, P., and Bongio, A. (2000). Web mod-

eling language (webml): a modeling language for de-

signing web sites. In Proceedings of the 9th interna-

tional World Wide Web conference on Computer net-

works : the international journal of computer and

telecommunications netowrking, pages 137–157, Am-

sterdam, The Netherlands, The Netherlands. North-

Holland Publishing Co.

Draheim, D. and Weber, G. (2004). Form-Oriented Analy-

sis: A New Methodology to Model Form-Based Appli-

cations. Springer Verlag.

E. James Whitehead, J. and Goland, Y. (1999). Webdav:

a network protocol for remote collaborative author-

ing on the web. In Proceedings of the Sixth Euro-

pean conference on Computer supported cooperative

work, pages 291–310, Norwell, MA, USA. Kluwer

Academic Publishers.

Fielding, R., Gettys, J., Mogul, J. C., Frystyk, H., Masin-

ter, L., Leach, P., and Berners-Lee, T. (1998). Hyper-

text Transfer Protocol – HTTP/1.1. Technical Report

Internet RFC 2616, IETF. http://www.ietf.

org/rfc/rfc2616.txt.

Fielding, R. T. (2000). Architectural styles and the design

of network-based software architectures.

Garrett, J. J. (2005). Ajax: A new approach to web

applications. http://www.adaptivepath.

com/publications/essays/archives/

000385.php.

arder, T. (1984). Observations on optimistic concurrency

control schemes. Inf. Syst., 9(2):111–120.

arder, T. and Reuter, A. (1983). Principles of transaction-

oriented database recovery. ACM Comput. Surv.,

15(4):287–317.

Kung, H. T. and Robinson, J. T. (1981). On optimistic meth-

ods for concurrency control. ACM Trans. Database

Syst., 6(2):213–226.

Lampson, B. W. and Sturgis, H. E. (1979). Crash recovery

in a distributed data storage system. Technical report.

Lewis, P. M., Bernstein, A., and Kifer, M. (2002).

Databases and Transaction Processing. Addison-

Wesley.

Lyon, J., Evans, K., and Klein, J. (1998). Trans-

action Internet Protocol. Technical Report Inter-

net RFC 2371. http://www.ietf.org/rfc/

rfc2372.txt?number=2372.

Pardon, G. and Alonso, G. (2000). Cheetah: a lightweight

transaction server for plug-and-play internet data

management. In VLDB ’00: Proceedings of the 26th

International Conference on Very Large Data Bases,

pages 210–219, San Francisco, CA, USA. Morgan

Kaufmann Publishers Inc.

Shadgar, B. and Holyer, I. (2004). Adapting databases

and webdav protocol. In WWW ’04: Proceedings of

the 13th international conference on World Wide Web,

pages 612–620, New York, NY, USA. ACM Press.

W3C (1999). XML Path Language (XPath) Version 1.0.

Technical report.

W3C (2000). Simple Object Access Protocol (SOAP) 1.1.

Technical report.

Weikum, G. and Vossen, G. (2001). Transactional infor-

mation systems: theory, algorithms, and the practice

of concurrency control and recovery. Morgan Kauf-

mann Publishers Inc., San Francisco, CA, USA.

Yang, J. and Kaiser, G. E. (1999). Jpernlite: Extensible

transaction services for the www. IEEE Transactions

on Knowledge and Data Engineering, 11(4):639–657.

TRANSFORM: A TRANSACTION SAFE WEB APPLICATION MODEL

171
