EFFICIENT POLICY-BASED ACCESS CONTROL IN

WEB-BASED PERSONALIZATION MANAGEMENT

For Use in Convergent Applications

Heinz-Josef Eikerling

Siemens SBS, C-LAB, Fürstenallee 11, D-33 102 Paderborn, Germany

Keywords: Personalization, Distributed Data Management, Profiles, Security.

Abstract: Personalisation of web-centric user environments and applications to contextual information, as well as to

the needs and preferences of the user is a contemporary concern. The involved personalisation data is

usually captured by profiles and is sensitive to security concerns. Therefore mechanisms need to be devised

to maintain privacy and data integrity, and to ensure proper access control. Within this paper we describe a

system which handles access control by the definition of policies. The access control engine is a key

component within the set of interacting services making up the profile access manager. Through this

approach the according profiles can be potentially dispersed over different types of physical storage devices

and access control can be featured quite independently of the actual storage type. Particularly, the

integration of the different storage devices is facilitated which permits to bind locally stored profile data to

data stored elsewhere (due to space or constraints with respect to accounting of profile information). We

thus believe that the system is particularly applicable for convergent personalisation scenarios in which

web-based personalisation data has to be combined with local information stored on mobile devices for

nomadic use.

1 INTRODUCTION

With the tremendous increase of devices of different

type being dynamically associated with a user, there

is an increasing demand for advanced semi-

automatic configuration functionalities to be applied

to the user’s environment. This is especially

important with respect to convergent scenarios in

which a nomadic user roams between located

services delivered through mobile or stationary

terminals. If the configuration process mainly targets

the user (i.e., the physical person accessing a

service), the configuration process is frequently

referred to as personalization.

In order to facilitate this, some configuration data

(configuration rules, attributes, etc.) has to be

created, accessed and persistently maintained. In

most practical cases, this profile data can be

dispersed over different physical storages, like for

instance databases, configuration files or more

advanced and proprietary types of storages (like for

instance tamper-resistant Smart Cards). The major

reasons for the dissemination of this information

over such storages are:

• Different levels of security with respect to

accessing and modifying profiled information

(e.g., identity related information) have to be

supported.

• Different types of profile information have to be

maintained and managed by different principals

depending on what is inevitably required to be

locally available, especially in case of temporary

off-line situations.

• The storage capabilities for a specific device

might be too limited to host the entire relevant set

of profile information.

Within this paper, we describe a system

permitting to handle the above aspects through the

use of profiles which can be physically dispersed

over networked storage resources. Basically, in our

approach a profile is regarded as a repository of

structured data that has an influence on sets of

configurable entities. We propose a light-weight,

platform- and site-spanning service infrastructure

called Customization Management System (CMS) to

handle the distribution of profile data as well as the

369

Eikerling H. (2006).

EFFICIENT POLICY-BASED ACCESS CONTROL IN WEB-BASED PERSONALIZATION MANAGEMENT - For Use in Convergent Applications.

In Proceedings of WEBIST 2006 - Second International Conference on Web Information Systems and Technologies - Internet Technology / Web

Interface and Applications, pages 369-374

DOI: 10.5220/0001257003690374

 SciTePress

implications of applying that data to the configurable

entities.

2 BACKGROUND

There are several formats available for the

description and exchange of profiles like CC/PP,

Dublin Core, PIDF, GUP, etc. However, they are all

not widely employed yet. Moreover, when applied to

mobile environments comprising devices like PDAs

and mobile phones (or Smart Cards) offering limited

processing power and low bandwidth

communication capability, they seem to be not well

suited as a complete profiling standard. Therefore

we have defined a suitable set of different XML-

based profile formats (Eikerling, 2005) taking into

account the above constraints.

In general profiles can be regarded as a special

type of distributed data which needs to be put under

the regime of a decentralized data management

(Perich, 2004). Currently, the data dissemination

aspects are mostly considered in terms of persistent

data being hosted by databases (Bukhres, 1997).

Under these circumstances, a profile can be viewed

as a collection of continuous location dependent data

queries (Cherniak, 2003). In order to handle the case

of information dispersal, this rather centralized

model needs to be further extended.

3 REQUIREMENTS

Due to space constraints, we can only give a

summary of the key requirements for the

customization management system and refer to the

major CMS service ingredients. The design of those

takes into account the following requirements:

• Decentralization. As mentioned earlier, profile

data might be distributed over different physical

storages. Hence it should be possible to link

profiles, to migrate and replicate profiled data

when and where needed. This has a major impact

on the data formats and the protocols to be used

which both have to support extensibility and broad

platform coverage.

• Diversification. Different storages (also referred to

as profile bearers) can hold the profile

information. The data management has to be able

to (preferably dynamically) integrate these bearers

and make them accessible through the service

interface. Ideally, the profile storage devices can

Figure 1: Service access manager and access control engine.

Profile Access Manager

SPAI

DPAI

Security Layer

Dispatcher

Credentials

NPAI

SPAI

NPAI

DPAI

Credential

Management

Access Control Engine (ACE)

Policy

Enforcer

Policy

Evaluator

Policies

Policy

Manager

Request

Transformer

Service

Access

Manager

(SAM)

local CMS

request

13a

local CMS

response

local CMS

request

13b

local CMS

response

2 transform to

XACML request

12 generate CMS

response

11b provide access

query result

45910

Profile Access Manager

SPAI

DPAI

Security Layer

Dispatcher

Credentials

NPAI

SPAI

NPAI

DPAI

Credential

Management

Access Control Engine (ACE)

Policy

Enforcer

Policy

Evaluator

Policies

Policy

Manager

Request

Transformer

Service

Access

Manager

(SAM)

local CMS

request

13a

local CMS

response

local CMS

request

13b

local CMS

response

2 transform to

XACML request

12 generate CMS

response

11b provide access

query result

45910

WEBIST 2006 - WEB INTERFACES AND APPLICATIONS

370

be federated through the CMS service.

• Connectivity. With respect to nomadic scenarios,

temporal disconnection from central

communication services offering access to certain

profile information may occur. This requires to

support nomadic user mobility which has specific

consequences for the enforcement of security

mechanisms, i.e., access to locally available

profile information should still be possible.

• Low complexity. This mainly addresses the service

interface which should insulate from the com-

plexity of data distribution, heterogeneity of

communication and data management

mechanisms.

4 CMS PROFILE FORMAT

In our approach, a profile is considered to be a data

container which can be split into two main parts:

• Data payload: this is the data uniquely

characterizing the configurable entity (e.g., name,

first name etc. of a user). Properties, as the most

basic profile data elements, are vectors of property

name and value with an associated type pairs. It

has to be ensured that the name of a property is

unique within a profile. The value part of a

property can be anything ranging from simple data

types to complex data structures.

• Meta-data: this is information describing the

format of the data, for instance whether it can be

linked to other data (e.g., profiles) or information

concerning its origin, location, history etc. The

meta-data is used for the processing of the profile

information within the customization management

system.

A configurable entity can be a user, hardware

(i.e., a device or device configuration) or a software

component (e.g., application or service), an

organisation (e.g., a company), a network, or the

environment in which such user is acting (context

data). Thus, we consider different profile domains

like user, device, service, application, network and

context profiles.

Each type of domain profile has to support a

certain set of generic operations: lifecycle operations

(create, delete, replicate), editing operations

(composing, linking, modifying, and moving),

retrieval (lookup) and advanced operations

(versioning, synching, inheritance, evolution).

Additionally, there are domain-specific operations.

The profiles may reside on different types of

storages reflecting the different levels of security.

For example, device characteristics might be stored

on a networked resource, whereas identity

information as part of the user profile has to be

retrieved from tamper-resistant smart cards.

A key feature of the CMS is the ability to

logically link sets of profile instances to each other

in order to reflect coherent relations between them.

The respective information model supporting this

has to be mapped to the according bearers (database

schema, standard or proprietary file system on a

storage device etc.) in the PAIs (Profile Access

Interfaces). For the bearer-independent handling of

profile information inside the CMS and in the

applications accessing the CMS we have foreseen a

set of XML schema definitions specifying the

domain profiles. This format is also used as a bearer

independent representation of results returned as a

response to access queries requesting profile sets or

profile fragments. Moreover, the network profile

access interface (NPAI) employs this format for

persistently storing profile information.

5 CMS ARCHITECTURE

The CMS constitutes a light-weight service

infrastructure supporting advanced personalization

through the use of distributed profiled information.

The approach is based on a simple layered protocol

featuring a request / response mechanism. For

integrating different CMS instances, the service

dispatches profile access requests either to local

resources or to distant resources; this is achieved

through a portable URI-based addressing scheme

which is handled through the core CMS component

(see Fig. 1), the Profile Access Manager (PAM).

Quite naturally, the PAM is required to feature

widely accepted communication mechanisms and

formats; it can be either integrated as a library or by

utilizing the provided CMS port together with a

secured transport protocol. For the latter, an

accessing entity has to know the CMS address made

up of the host name and the CMS port, i.e. one host

can run multiple CMS instances. The SSL/TLS-

based server could be addressed by

https://www.ubisec.org/cms?message=[b64c]

where [b64c] constitutes a base64 encoded CMS

request.

The developed request format features a query

part that is used to specify access commands. These

are coded by means of a access and manipulation

language. For routing requests to the according PAI,

a resource part (containing schema definition,

addressed authority, and path information) is

foreseen. Both, resource and query part together

form an access query:

EFFICIENT POLICY-BASED ACCESS CONTROL IN WEB-BASED PERSONALIZATION MANAGEMENT - For

Use in Convergent Applications

371

"?" <query>

A sample access query to obtain certain user

preferences would look as follows:

file:///C:/CMS/CMSProfiles/

container/ContextProfile/sampleCo

ntext.pc.xml?path=Lw==&action=cmV

hZA==&relativePath=L0NvbnRleHRQcm

9maWxlL3NhbXBsZUNvbnRleHQucGMueG1

s&subject=cm9vdA==

To avoid problems with masking parameters,

values following the “=” symbol are in fact base64

encoded to form valid queries.

Concerning the Security Layer of the PAM, the

service access manager (SAM) is responsible to

ensure message integrity checking, decryption,

encryption, decoding, encoding, authentication, and

handling of client or server side certificates. For

establishing trust relationships between CMS

instances and applications accessing them, it can be

bundled with an enhanced PKI (ePKI) solution

which targets trust management in decentralized

environments (Almenárez, 2004).

The other part of the Security Layer is

constituted by the Access Control Engine (ACE).

Here we refer to XACML policies (Moses, 2005)

and an according implementation. The Transformer

in the Security Layer parses incoming access

requests and generates a common request format,

i.e., a transformation from the UBISEC native CMS

request format into an XACML compliant request

(Step 2). This supplies the Access Controller with an

access request that comes in a common,

semantically well-defined format, regardless of

profile type, requesting subject and accessed

resource. The steps 3 – 5 and 8 – 11a are in

accordance with XACML access control by means

of policy evaluation.

In Step 7, the CMS Dispatcher sends a request to

one of the PAIs in order to acquire profile data that

are necessary for policy evaluation. The Dispatcher

takes care about routing of requests to the correct

PAI. The different kinds of PAIs are SPAIs for

Smart Cards, DPAIs for data bases, and NPAIs for

networks. Note here that a single PAM can manage

a number of PAIs of the same kind. Each PAI then

transforms the request into the (native) format that is

understood by the resource storing the profile data

(e.g., a query in case of a database or an APDU

command in case of a Smart Card).

Assume now that the policy evaluation

terminated with a result, such that we have an access

response generated by the Access Controller (Step

11b). If the XACML evaluation result (Step 10)

concludes that access is denied, the Access

Controller returns an according 'deny' response. If

access is permitted, this in turn may require the

Smart Phone

PDA

Control Application

CMS

User Profile “peter”

user=“hans”

context=“token1”

…

User Profile “hans”

context=(URI)

player=(URI)

Context Server

Location

Tracking

CMS

Context Profile

asset=“token1”

location=“den”

…

Context Profile

asset=“token1”

location=“den”

…

Context P. “token1”

location=“den”

…

Display

CMS

Application Profile

session= =“s1013”

file=“clip56.mp2”

position=“3473”

Player

Application

Application Profile

session= =“s1013”

file=“clip56.mp2”

position=“3473”

Application P. “mp2p”

session= =“s1013”

file=“clip56.mp2”

position=“3473”

Smart Phone

PDA

Control Application

CMS

User Profile “peter”

user=“hans”

context=“token1”

…

User Profile “hans”

context=(URI)

player=(URI)

Context Server

Location

Tracking

CMS

Context Profile

asset=“token1”

location=“den”

…

Context Profile

asset=“token1”

location=“den”

…

Context P. “token1”

location=“den”

…

Display

CMS

Application Profile

session= =“s1013”

file=“clip56.mp2”

position=“3473”

Player

Application

Application Profile

session= =“s1013”

file=“clip56.mp2”

position=“3473”

Application P. “mp2p”

session= =“s1013”

file=“clip56.mp2”

position=“3473”

Figure 2: Mobile display scenario.

WEBIST 2006 - WEB INTERFACES AND APPLICATIONS

372

execution of obligations that have to be fulfilled

before access is granted. A possible obligation could

be that an additional notification has to be sent to

some other entity (e.g., a profile administrator) or

that some security obligations have to be enforced.

The Policy Enforcer takes care for these obligations.

Moreover, the access response may include a data

payload, in particular when a 'read' action was

specified in the CMS request.

6 APPLICATION SAMPLE

The CMS is a basic means for profile management

and various actual application scenarios can be

thought of. A specific class of scenarios that is

frequently examined is the context-aware (location-

dependent) delivery of digital content to nomadic

users. Within our setup, we have focused on users

roaming between different discrete, distinct sites /

locations while accessing streamed media. In the

particular prototype system, the transmission of

MPEG-2 streams is examined. Depending on the

context of the users, the media is delivered to them.

For accessing the media and for controlling the

environment, either a mobile or a stationary access

device can be used. During a session, the handoff /

handover among the access devices can be featured.

Pertaining to the personalisation of the

environment of a nomadic user and according to the

scenario described above, the following functions

and data sets (see Fig. 2) have to be supported:

• User management: profile data concerning the

user (e.g., identity related information like user

name “hans”) and references to other types of

profiled information (e.g., to some context

“token1” and application data “player”) relevant

to the user have to be maintained.

• Context management: the location contexts have

to be managed, i.e., the user has to be tracked. The

tracking system managing the symbolic user

locations (e.g., “den”) is physically detached from

the mobile access device.

• Application / service management: the replay of

media streams via the delivery service might be

interrupted (for instance, if the user’s context

changes). For this, the status of the playing session

(i.e., file name and current positioning within file)

should be maintained, so that the settings can be

restored once the user roams into the range of the

service again.

The above functional needs clearly motivate a

demand for distributing the customization data as

shown in Fig. 2. The advantages of this approach

over more traditional (e.g., centralized) ones are:

1. Autonomous acting: by partitioning and

distributing the functionalities and the required

customization data, the interference and

dependability between the involved peers is

minimized.

2. Privacy / anonymity: the location tracking only

deals with abstract position names. The mapping

of the symbolic names to the identities of the

users being mapped to these names can be only

done via the user profile mastered by the user.

3. Linking: linking to profile data from within a

profile is essential to enable such features as

anonymity. Through a URI-based request format,

different domain profiles can be easily linked

which facilitates complex personalization tasks.

Figure 3: CMS ACE performance.

CMS Startup Time

(number of policies varying)

CMS Startup Time

(number of policies varying)

Accumulated CMS Response Time

(number of requests varying)

Accumulated CMS Response Time

(number of requests varying)

EFFICIENT POLICY-BASED ACCESS CONTROL IN WEB-BASED PERSONALIZATION MANAGEMENT - For

Use in Convergent Applications

373

7 RESULTS

With respect to the above scenario, the efficient

handling of context information is paramount to the

overall performance of the system. We particularly

examined the dependency of the request processing

time on the authorization (which is handled by the

ACE) and authentication (handled by the SAM)

mechanisms. We found that:

• There is virtually no dependency on the

authentication handled by the SAM.

• When considering profiles delivered as complete

XML files through the NPAI, with respect to

security a certain tribute has to be paid to

authorization through the ACE.

• The accumulated response time is pretty

independent of the number of policies and the

number of requests issued over a certain time

period as can be seen from Fig. 3. The overhead of

ACE request validation amounts to approx. 7% of

the overall request processing time.

• When having different runs of the same access

pattern (forming an iteration) we found that just

after one iteration the ACE gets ‘used’ to this

pattern, i.e., within forthcoming repetitions the of

the particular pattern, the accumulated response is

constant (within certain limits).

Through its ease of use, the CMS features some

interesting characteristics. For instance, aside from

user mobility as described in the application scenario

described above, it is also possible to realise

terminal mobility (or access device mobility) as

shown in Fig. 2. The playing of a clip can be stopped

on one device and can be resumed on another device

with virtually no user intervention through the use of

personalisation features offered by the CMS.

8 CONCLUSION

We have presented an approach to the secured data

management and dissemination of profile data over

different types of physical storages. This particularly

includes the transparent maintenance of a user’s

context depending on device, application and

environmental settings as well as user preferences

and capabilities. The described concepts are

especially applicable to decentralised environments

as opposed to pure centralised environments with

unlimited connectivity to a profile server (e.g., data

base) in which authorization decisions can be

handled more efficiently though by the penalty of

centralisation.

We believe that the distribution of profile data is

an inevitable requirement for convergent scenarios

which has to be adequately dealt with. So far, rather

centralized approaches and proprietary solutions

only targeting specific aspects of personalization /

customization (i.e., tied to a specific operating

system) exist. The design of the CMS is a step to

approach the distribution of profile data from the

perspective of nomadic users. For a wider

dissemination and proliferation of the proposed

mechanisms, a standardization of the concepts,

protocols and formats is quite essential and efforts to

promote this have been launched.

ACKNOWLEDGEMENTS

The work described herein is funded by the FP6-

2002-IST-1 project UBISEC (Ubiquitous Networks

with a Secure Provision of Services, Access, and

Content Delivery), contract number 506926.

REFERENCES

Eikerling, H-J. et al. (2005, June). Customization of

Secured Ubiquitous Environments via Advanced

Profile Management, IST Mobile & Wireless

Communications Summit, Dresden.

Perich, F. et al. (2004, May). On Data Management in

Pervasive Computing Environments. IEEE

Transactions on Knowledge and Data Engineering,

16(5):621-634.

Bukhres, O. et al. (1997). A Proposed Mobile Architecture

for Distributed Database Environment. Technical

report, Indiana University, Purdue University.

Q. Ren and M. Dunham (2000, August). Using Semantic

Caching to Manage Location Dependent Data in

Mobile Computing. 6th Annual International

Conference on Mobile Computing and Networking

(MobiCom’00), Boston, MA, USA, pp. 210-221.

M. Cherniack, E. Galvez, D. Brooks, M. Franklin, and S.

Zdonik (2003, March). Profile-Driven Cache

Management. Proceedings of the 19th International

Conference on Data Engineering (ICDE), Bangalore,

India.

F. Almenárez, A. Marín, C. Campo, C. García-Rubio.

PTM (2004). A Pervasive Trust Management Model

for Dynamic Open Environments. Workshop on

Pervasive Security, Privacy and Trust (PSPT 2004),

Boston, USA.

T. Moses (ed.) (2005). OASIS eXtensible Access Control

Markup Language (XACML) Version 2.0, OA-SIS

Standard.

WEBIST 2006 - WEB INTERFACES AND APPLICATIONS

374
