ASSOCIATIVE PROGRAMMING AND MODELING:

ABSTRACTIONS OVER COLLABORATION

Bent Bruun Kristensen

Maersk Mc-Kinney Moller Institute, University of Southern Denmark, Denmark

Keywords: Collaboration, abstraction, modeling and progr

amming, association, concurrent and interleaved execution,

activity, role.

Abstract: Associations as abstractions over collaborations are motivated and explored. Associations are seen as first

class concepts at both modeling and programming levels. Associations are seen as concepts/phenomena and

possess properties. Various notations for collaboration in object-oriented programming and modeling are

discussed and compared to associations. Concurrent and interleaved execution of objects is described in

relation to associations.

1 INTRODUCTION

Description of collaboration between some

participants is less supported by existing notations

and diagrams. In collaboration the participants

engage in the collaboration through specific roles

and the actual interaction sequence between the

participants follow some rules. Existing notation and

diagrams are mainly based on object-centric

modeling and programming exemplified by objects,

object references and remote method invocation.

Examples of non object-centric notations and

diagrams include the relation (May et al, 2001). This

relation is an example of an abstraction over

structural aspects only—interaction aspects are not

covered by relations. Associations are seen as an

abstraction over both structural and interaction

aspects of collaboration. The association supports

description at both abstract modeling and concrete

programming levels. At the abstract level

associations are seen as concepts and phenomena

characterized by their properties. At the

programming level properties of associations are

expressed through language mechanisms.

Associations are inspired from a conceptual

odel for understanding ambient systems (May et

al, 2001). Such systems have a more dynamic

situation with respect to collaboration among the

entities in the system. In this model we imagine

tangible objects existing in habitats and

collaborating with other tangible objects—and

tangible objects enter and leave habitats. As part of

this dynamic picture tangible objects engage in

collaboration with other tangible objects—simple or

complex collaborations. The notion of associations

is a means of capturing planned or spontaneous

collaborations between tangible objects—to

conceptually understand and prescribe collaboration

as abstractions over collaboration. The illustration of

an ambient system included as example in this

article—“the conference organizing problem”—only

includes aspects of collaboration but excludes

aspects of user awareness and support through

knowledge of time and place, augmentation of

reality by additional views, and availability and

interaction with software agents and physical robots

(Kristensen, 2003).

Our approach is inspired by the evolution from

trad

itional systems (often information systems)

towards ambient systems including pervasive

(Burkhardt et al, 2001) and ubiquitous (Weiser,

1991) systems. Ambient systems illustrate the

change from development of systems towards an

understanding where systems are grown through

evolution. Associations are a move from object-

centric technology towards non-centric technology.

For associations we distinguish between an abstract,

informal and conceptual modeling level and a

concrete, formal and executable programming level.

Bruun Kristensen B. (2006).

ASSOCIATIVE PROGRAMMING AND MODELING: ABSTRACTIONS OVER COLLABORATION.

In Proceedings of the First International Conference on Software and Data Technologies, pages 54-62

DOI: 10.5220/0001308600540062

 SciTePress

2 OBJECT-ORIENTATION

References support the relations between objects in

object-oriented programming languages. In Figure 1

we illustrate the usual notions of class, object,

reference and method invocation. Class

C has

method

mc. Object Oc is an object of C. Class D has

method

md and a reference Rc qualified by C. Object

Od is an object of D and reference Rc has the value

Oc. Method md of Od can invoke method mc of Oc by

Rc.mc(…).

Rc.mc

()

Figure 1: Class, object, reference and method invocation.

Oc1

Oc2

Oc3

Figure 2: Illustration of object-oriented collaboration.

In a typical object-oriented collaboration as

illustrated in Figure 2, method

m1 of class C1

contains the following example—(this collaboration

example is also used in subsections 2.2 (Figure 3)

and 2.3 (Figure 4)):

x1 = r2.k2(…);

x2 = r2.k2(…);

y = n1(x1, x2);

r3.k3(y);

We observe the following characteristics of this

schematic example from object-oriented

programming:

• The reference is statically bound to the class

(and any object of the class) whereas the value

of the reference varies dynamically

• The reference is qualified by a class, which

determines which types of objects may be

referenced by the reference

• The reference is used for different purposes

(invocations of different methods from different

methods)

• The use of a reference for a given purpose is

separated from the reference and distributed

over several method bodies

2.1 Object-Oriented Delegation

The characteristics of collaboration through object-

oriented delegation include that collaboration is

explicitly described and implemented in a method in

Figure 3 as

a1 of A1. Collaboration is initiated by

Oc1.m1(…) by invoking a1 of object oA1. This

approach includes some typical problems:

•

Oc1 and n1 are not necessarily known to oA1 for

the invocation

n1(x1, x2) (“self” problem)

•

A1 may be parameterized by references r2 and

r3 and with some reverse reference for r

oA1

Oc2

Oc3

Oc1

Figure 3: Illustration of object-oriented delegation.

2.2 Control Object/Method

The characteristics of collaboration through a

control method/object include that collaboration is

explicitly described and implemented in a

method/object (objectification of collaboration but

here only exemplified by methodification as

a1 of A1

in Figure 4). Collaboration is initiated by Oc1.m1(…)

by invoking

a1 of object oA1. This solution includes

the following problems:

ASSOCIATIVE PROGRAMMING AND MODELING: ABSTRACTIONS OVER COLLABORATION

• The effect through

y on Oc1 must be a side-

effect through invocation of

r1.n1

•

A1 may be parameterized by references r1, r2

and

Oa1

Oc2

Oc3

Oc1

Figure 4: Illustration of object-oriented control method.

3 ASSOCIATIONS

Associations represent an alternative to object-

centric modeling and programming. Our

associations support not only structural relationship,

but also collaboration between objects. An

association is described as an abstraction, it may be

instantiated, and it has identity. Dynamic changing

associations are supported—descriptions may be

added to executing systems and objects of these may

associate participating objects of the executing

system.

Oc2

Oc1

Oc2

’

C1’

’

Oc1’

Oc2

Figure 5: Snapshots of associations.

Figure 5 illustrates dynamic creation and

deletion of objects of associations through four

snapshots. In (2) an object

Ax with roles with

properties

n1 and n2 is created. Object Oc2 of class

C2 function as one participant in the association. In

snapshot (1) no associations exist for

Oc2. In (2) Oc2

is associated by means of

Ax with object Oc1 of class

C1. In (3) the association Ax no longer exists. In (4)

Oc2 is associated by means of an object Ay with roles

with properties

l1 and l2 with object Oc1’ of class

C1’.

In UML models the main concepts are captured

through class diagrams supplied with

relation/association classes as fundamental model

structures. In addition these models include

sequence and collaboration diagrams, where the

interaction of objects is modeled in terms of method

invocations. This description is separated from

classes and associations, and neither sequence nor

collaboration diagrams are conceptualized as

abstractions over collaboration. Our notion of

association is an abstraction over interaction and

collaboration and the actual method invocations

between objects are modeled as integrated elements

of the association. In addition roles played by

participating objects in an association are also

modeled as extensions of the objects to participate in

the association. Traditionally abstractions over

certain aspects of an object—as for example the

collaboration of the object with other objects or the

objects’ role towards other objects—are

objectifications of such aspects. In this sense our

notion of association is an integrated objectification

of collaboration aspects and role aspects.

The association is seen as an abstraction during

conceptual modelling (Madsen et al, 1993). In

conceptual modeling different forms of abstraction

in terms of concepts and phenomena are illustrated

in (Kristensen, 2003): Classification (and

exemplification) where a concept classifies a

number of phenomena (which themselves exemplify

the concept). Specialization (and generalization)

where a more general concept generalizes a more

specific concept (which itself specializes the general

concept). Aggregation (and decomposition) where a

whole concept describes the aggregated

phenomenon of several part concepts (which

themselves can be decomposed from the whole

concept).

3.1 Example: paper_review

As an illustrating example, we examine the

association of reviewing papers a conference—

referred to as a

paper_review. This association

requires a certain degree of collaboration between

those who are involved in it. For instance, an

author will submit a paper for review, while the

chairman will submit papers to reviewers who must

report back. A directive describes how the

association should be carried out. With the

ICSOFT 2006 - INTERNATIONAL CONFERENCE ON SOFTWARE AND DATA TECHNOLOGIES

paper_review, the directive might be carried out in

distinct portions:

1. prepare_paper_review

author_submits_paper_to_chairman

chairman_submits_papers_to_reviewers

reviewers_submit_reports_to_chairman

2. paper_selection

3. chairman_informs_authors

The association paper_review is only one type

of review that can take place. For example, a

periodical_review is the review of a submitted

article that takes place for a periodical; it is

somewhat similar but involves an

editor rather than

chairman and its selection process is different.

Both

paper_review and periodical_review are

specialized types of review. The directive that

specifies how

paper_review should be carried out

may also be seen as a specialization of a more

general review directive:

1. prepare_review

2. carry_out_review

3. complete_review

These portions correspond to (1), (2) and (3)

above (which are more specialized). The

participants of these associations may also be

similarly classified. For instance, all review

associations involve a

coordinator and an author.

Thus, in a

paper_review, we can refine a

coordinator to be a

chairman—in a

periodical_review, we can refine a coordinator

to become an

editor.

These different types of review associations may

have similar methods. For example, producing a

status_report (produce a listing of the current

status of the ongoing reviewing process) is

something that each

review association must do—a

paper_review will produce a specialized type of

status_report, as will a periodical_review.

Finally, such associations are constituted from

smaller sets of associations. For example, within the

paper_review association, there is a

paper_selection association to choose acceptable

papers.

3.2 Execution

In addition to action directives, associations include

roles to be played by participants in the

collaboration. Roles are abstractions in associations.

Roles may specify additional methods or may extend

existing methods of an object (Kristensen, 2003). In

Figure 6

R1, R2 and R3 are roles of association class

X. Ax illustrates an object of class X. Ax associates

objects

Oc1, Oc2 and Oc3 (each playing a role R1, R2

and

R3) of classes C1, C2 and C3 respectively. The

method k1 of

R1 illustrates an additional method—

alternatively k1 may be described as an extension of

the existing method

n1 of C1 (similar for methods k2

and

k3).

Oc2

Oc1

Oc3

Figure 6: Illustration of association.

The directive of association X is executed by the

respective owners of the actions among the

participants of

X. The notation R::k(…) means that

the object playing role

R executes its method k(…).

Hence the collaboration is explicitly described

through the directive of

X e.g.:

x1 = R2::k2(…);

x2 = R2::k2(…);

y = R1::n1(x1, x2);

R3::k3(y);

An association is a description of a central

abstract unit. The notation

R::… is different from

remote denotation, because “

…” is situated in the

context of

R and interpreted in this context. The

execution of its contribution from a directive is done

by the participating object. In sequential execution,

description and execution of sequencing are in terms

of one execution thread only—a method in one

object invokes a method of another object and one

thread executes the entire invocation sequence. In

multi-sequential execution, sequencing is described

as several execution threads (one for each object)

but is executed by one thread only. The thread

switches (at language defined points) between the

executions of the objects—this interleaved execution

of the sequencing of objects means that only one

object is executed at a given time.

ASSOCIATIVE PROGRAMMING AND MODELING: ABSTRACTIONS OVER COLLABORATION

4 CONCURRENCY

In general objects execute concurrently.

Communication and synchronization constructs

describe the interplay between such active objects.

Objects have an individual action part—on

instantiation, an object will immediately execute its

action part and is inherently active. The description

of the action part may involve the activation of

methods in the object itself and (activation requests

of) methods for other objects. Because the objects

are active, the interaction between objects is usually

coordinated by means of various forms of ego-

centric language mechanisms for synchronization of

the execution of the life cycle of the object and

method requests of/from other objects. As an

example, when one object attempts a method request

of another object, then the first objects must wait

until the other object explicitly accepts this

invocation. When the invocation is accepted the

objects are synchronized and the invocation can take

place.

4.1 Interleaved Execution

In associations the collaboration (including

communication and synchronization between the

participating objects) is described in directives of

associations only. Active objects are executed in

parallel (and shared data resources are typically

active objects to ensure exclusive access). The

association directive itself supports various ways of

describing the sequencing of the collaboration

including sequential, repeated, parallel, interleaved,

any order executions etc. The individual action part

of an object only describes its individual life cycle,

i.e. no form for interaction with other objects is

included. The execution of the total life cycle of an

object described through several contributions in

directives (of current collaborations) is an

interleaved execution of its contributing parts and

also interleaved execution with its individual action

part. Interleaved execution for one such object of

several different parts means that (at language

defined points in the parts) execution will switch

between the parts.

Figure 7 illustrates the mechanisms introduced.

Object

Ax is of association class X. Object Oc1 is a

participant of class

C1 and R1 denotes the role played

Oc1. The construct R1::k1(…) denotes a

contribution to the directive of

Ax from role R1. The

object

Oc1 executes its individual action part

(exemplified by “

… n1(…) …”) interleaved with the

various contributions from role

R1 of directive Ax

(and contributions from similar directives of

associations in which

Oc1 currently plays roles).

Oc1

…

n1(…)

…

R1::k1(…)

…

Figure 7: Interleaved execution of active objects.

4.2 Example: paper_review

In the paper_review example, a reviewer may be

actively performing other actions than those in

connection with the

paper_review such as

researching and teaching. A teaching association

between

teacher, student and administration is

specialized into

course_teaching and supervision.

Association

course_teaching includes an iterative

sequence of

remind_students actions from teacher

students. Figure 8 illustrates how a person (with

own individual action part illustrated by “

…

exercise(…) …

”) participates in both

a_paper_review and a_course_teaching

associations. The contribution to the person in

a_paper_review includes submit_report. The

contribution from

a_course_teaching includes

remind_student. An active person object executes

exercise, submit_report and remind_student

interleaved.

submit_report

exercise

…

exercise(…)

…

reviewer::submit_report(…)

…

reviewer

a_course_teachin

teacher

remind_student

…

teacher::remind_student(…)

…

a_paper_review

Figure 8: Illustration of reviewer and teacher roles.

4.3 Specialization of Directive

Collaborations may have general directives prepared

for further specialization in directives of sub-

collaborations —for example the directive of the

ICSOFT 2006 - INTERNATIONAL CONFERENCE ON SOFTWARE AND DATA TECHNOLOGIES

more general association

teaching may include

possibilities for both

course_teaching and

supervision. The general directive of teaching has

the form:

1. planning

2. …

3. inner: content

4. …

5. examination

This directive illustrates two types of

specialization of collaborations: In each of 1) and 5)

we illustrate virtual (part) collaborations. This means

that for example

planning is a virtual abstraction

with some preliminary description (a directive

similar to the

teaching directive) and may be

extended in specializations of

teaching cf. virtual

classes (Madsen et al, 1993). In

course_teaching

(as a specialization of

teaching) planning may be

specialized to

course_session_planning. In 3) we

illustrate an explicit

inner construct (named as

inner: content). Several such inner constructions

may be specified in the directive (Kristensen, 1993),

(Kristensen et al, 1996). In

course_teaching the

inner:content construct is specialized into a

sequence of

lecturing activities (for concrete

courses

lecturing is specified further with respect

to number and content). The specialized directive is

the original general directive with these two types of

specializations included. The execution of a

participating active object is still an interleaved

execution of its individual action part and its

contributions from all such specialized directives.

The directive of

course_teaching, specialized from

the directive of

teaching, includes of the sequence

course_session_planning, a sequence of

lecturing, and curriculum_examination of the

form:

1. course_session_planning

2. …

3. … lecturing …

4. …

5. curriculum_examination

5 PROGRAMMING

We introduce association classes and objects with

roles and directives in schematic programming

language form. We include the

paper_review

example as an illustration. Finally we conclude by

defining interleaved execution schematically. In

general the notation

… indicates various less

important or repeated parts left out of the

descriptions.

5.1 Association Classes

Association classes Xj include roles Rj (with method

nj) and local associations Yj and a directive (with

various characteristic ingredients to be explained

later). Association object

Axj is instantiated:

association Xj {

role virtual Rj for Ci {

method nj (…) …

}

…

association virtual Yj {…}

…

directive {

… Yj … inner:Ij … Rj::nj(…) …

}

object Axj of Xj

Object

Oci of class Ci enters role Rj of Axj. A

role is qualified by a class,

Ci, meaning that only

objects of this class or its subclasses,

CCi, may enter

that role. Also role

Rj may invoke methods of Ci

and

CCi. The action part of Ci illustrates various

characteristic ingredients: mi(…) is an invocation of

a Ci method, whereas the description

inner:Ii is

replaced by its refined description denoted by

{…} in

CCj:

class Ci {

method mi {…}

…

action_part {… mi(…) … inner:Ii …}

}

object Oci of Ci

Oci enters Axj as Rj

class CCi extends Ci {… Ii:{…} …}

Associations Yj and roles Rj may be specified as

virtual in order to be specialized further in

specializations like

XXj of the enclosing association

Xj (for roles also the classifying class Ci may be

specialized as e.g.

CCi). The directive of XXj is the

directive of

Xj where for each Ij the description

inner:Ij is replaced by its refined description

denoted by

{…} in XXj:

association XXj {

role Rjk for CCi {…} …

association Yj {…} …

directive {

… Ij:{…} …

ASSOCIATIVE PROGRAMMING AND MODELING: ABSTRACTIONS OVER COLLABORATION

}

5.2 Example: paper_review

The paper_review is presented in the language style

below. The ordinary concurrent object

person

executes method

exercise repeatedly in its action

part:

class person {

method exercise {…} …

action_part {… exercise(…) …}

}

Association paper_review is a sub-association

review and specializes the directive by

prepare_review, carry_out_review and

complete_review. Also roles reviewer and

coordinator are specialized:

association review {

role virtual reviewer for person {…}

role virtual coordinator for person {

method submit (…) …

}

role author {…}

association virtual prepare_review {…}

association virtual carry_out_review {…}

association virtual complete_review {…}

…

directive {

prepare_review

carry_out_review

complete_review

}

association paper_review extends review {

role reviewer {

method submit_report {…} …

}

role chairman extends coordinator {…}

association prepare_review {

author::submit (paper, chairman)

… chairman::submit (paper, reviewer) …

reviewer::submit_report(…)

}

association paper_selection

extends carry_out_review {…}

association extends complete_review {

… chairman::inform_author …

}

directive {…}

}

Association course_teaching is a specialized

association of

teaching—and refines the directive

teaching. Also the roles teacher, student and

administration may be specialized—for example

for

teacher by adding method remind_student:

association teaching {

association virtual planning {…}

association virtual examination {…}

role teacher for person {…}

role student for person {…}

role administration for organization {…}

directive {

planning

…

inner: content

…

examination

}

association course_teaching extends teaching

{

association course_session_planning

extends planning {…}

association curriculum_examination

extends examination {…}

association lecturing {

… teacher::remind_student(…) …

}

role teacher {

method remind_student {…}

…

}

directive {

content: {… lecturing …}

}

Objects of

course_review and paper_review

are instantiated. Object

John then enters the

association objects

a_course_teaching and

a_paper_review:

object a_course_teaching of course_teaching

object a_ paper_review of paper_review

object John of person

John enters a_course_teaching as teacher

John enters a_paper_review as reviewer

5.3 Interleaved Execution

Action parts of active objects are executed

concurrently with directives of associations, but each

action part and directive is executed sequentially:

ICSOFT 2006 - INTERNATIONAL CONFERENCE ON SOFTWARE AND DATA TECHNOLOGIES

class Ci {

…

action_part {… mi(…) …}

}

association Xj {

role virtual Rj for Ci {…}

…

directive {… Rj::nj(…) …}

}

A given Oci of Ci is engaged as role Rj of Xj in

a collection of association objects

Axj of Ax, where

1) the next individual action for

Oci is mi(…)

2) for the collection of

Ax’s the next action to be

executed for

Axj with Oci in role Rj is

Rj::nj(…)

Interleaved execution of

Oci means, that exactly

one out of

mi and the collection of nj’s is selected

randomly and executed. For an object of a

specialized class engaging in specialized

associations the specialized action part and

specialized directives are used.

6 RELATED APPROACHES

Notions similar to associations are available in

object-oriented modeling whereas in object-oriented

programming associations are implemented by

means of references. Our associations support both

modeling and programming (Kristensen, 2003). We

include the association as a first class concept in our

modeling and programming notation. In classical

object-centric modeling and programming the

fundamental problem is that “no object is an island”

(Beck et al, 1989). In object-oriented systems an

object supports encapsulation; the object is self-

contained; focus is on structure instead of function

and focus is on methods instead of processes. These

characteristics are seen as appreciated properties of

object-oriented systems, but are also essential

problems because they emphasize an object-centric

point of view.

Relations from (Rumbaugh, 1987) are

introduced as non object-centric abstractions. In an

illustrative example a relation

Employment with

property

Salary is defined between classes Person

and

Company. Objects of class Person play the role

Employee and objects of class Company play the

role of

Employer. The relation Employment captures

an abstraction, the properties of which we do not

place at neither

Person nor Company—the relation is

between these and therefore in conflict with the

intentions of the object-centric approach.

6.1 Language/Notation

Various approaches to notation for non object-

centric modeling and programming include:

Relations (Rumbaugh, 1987) and the corresponding

associations in OMT (Rumbaugh et al, 1991) and

UML (Booch et al, 1998) are object-external

abstractions but these relations/associations only

cover structural aspects, not collaboration. Sequence

and collaboration diagrams in UML support the

description of object interaction by means of method

invocation, but not as abstractions and not integrated

with relations/associations of objects. Complex

associations (Kristensen, 1994) are object-external

abstractions and support only complex structural

relationships between complex, structured objects.

Subject-oriented programming (Harrison et al, 1993)

and subjective behavior (Kristensen 2001) support

different views on objects respectively from an

external and internal perspective, but not

relationships between objects. Activities (Kristensen

et al, 1996), (Kristensen, 1993) are abstractions over

collaborations of objects, but include no support of

roleification of objects participating in the

collaboration. Roles (Kristensen et al, 1996),

(Kristensen 1995) are abstractions over roleification

of objects for various relationships of objects, but no

explicit collaboration is included.

6.2 Collaboration Approaches

Design patterns (Gamma et al, 1994) capture

experience of object oriented design and

programming. In this approach language constructs

for collaborating objects are typically simulated by

patterns of objects including for example

DECORATOR,

OBSERVER, and MEDIATOR. Activity-based computing

(ABC) (Bardram, 2005) supports mobility and

cooperation in human work activities. ABC is a

framework supporting a computing infrastructure to

describe how to keep track of collaborative

activities. The system offers a distributed, real time

joint repository for activities including states,

participants, communication and information. Model

Driven Architecture (Zhao, 2005) is supported by

the notion of roles (as a modeling paradigm) by

viewing object interactions from the dimensions

roles, responsibilities and collaborators. The

approach yields a semantically rich model, and also

a simple, elegant design that is flexible and

adaptable.

ASSOCIATIVE PROGRAMMING AND MODELING: ABSTRACTIONS OVER COLLABORATION

7 CONCLUSION

Associative programming and modeling is

characterized by:

• Object-oriented programming contains object-

centric descriptions, and collaboration is

implicitly described only and distributed among

methods of participating objects. In object-

oriented methodologies alternatives exist

typically only for analysis and design, but not

for implementation

• Associations support associative modeling and

programming through abstractions over

collaboration. Associations support

objectification of integrated collaboration

aspects and role aspects. Classification,

specialization and aggregation are available

• In associations directives (sequencing rules for

interactions among the participating objects) are

central, partial descriptions related to the

participating objects. The objects execute their

own contributions to the collaboration in their

context. An active object participating in

various associations execute contributions from

the directives interleaved

Challenges include:

• Notation at the modeling and programming

levels for creation and deletion of associations

• Entry and exit of objects in associations

• Similarities between inheritance of directives

and inheritance anomaly (Matsuoka et al, 1993)

ACKNOWLEDGEMENTS

This research was supported in part by the A. P.

Møller and Chastine Mc-Kinney Møller Foundation.

We thank Palle Nowack, Steffen Jensen and Beata

Hargesheimer for collaboration and contributions.

REFERENCES

Bardram. J.E., 2005. Activity-Based Computing: Support

for Mobility and Collaboration in Ubiquitous

Computing. Personal and Ubiquitous Computing, 9(5).

Beck, K., Cunningham, W., 1989. A Laboratory For

Teaching Object-Oriented Thinking. Proceedings of

the Object-Oriented Systems, Languages and

Applications Conference.

Booch, G., Rumbaugh, J., Jacobson, I., 1998. The Unified

Modeling Language User Guide. Addison Wesley.

Burkhardt, J., Henn, H., Hepper, S., Schaeck, T.,

Rindtorff, K., 2001. Pervasive Computing:

Technology and Architecture of Mobile Internet

Applications. Addison Wesley.

Gamma, E., Helm, R., Johnson, R., Vlissides, J., 1994.

Design Patterns: Elements of Reusable Object-

Oriented Software. Addison Wesley.

Harrison, W., Ossher, H., 1993. Subject-Oriented

Programming (A Critique of Pure Objects).

Proceedings of the Object-Oriented Programming

Systems, Languages and Applications Conference.

Kristensen, B.B., 1993. Transverse Activities:

Abstractions in Object-Oriented Programming.

Proceedings of International Symposium on Object

Technologies for Advanced Software.

Kristensen, B.B., 1994. Complex Associations:

Abstractions in Object-Oriented Modeling.

Proceedings of Conference on Object-Oriented

Programming Systems, Languages, and Applications.

Kristensen, B.B., 1995. Object-Oriented Modeling with

Roles. Proceedings of the 2nd International

Conference on Object-Oriented Information Systems.

Kristensen, B.B., May, D.C-M., 1996. Activities:

Abstractions for Collective Behavior. Proceedings of

the European Conference on Object-Oriented

Programming.

Kristensen, B.B., Østerbye, K., 1996. Roles: Conceptual

Abstraction Theory & Practical Language Issues.

Special Issue of Theory and Practice of Object

Systems on Subjectivity in Object-Oriented Systems.

Kristensen, B.B., 2001. Subjective Behavior. International

Journal of Computer Systems Science and

Engineering, Volume 16, Number 1.

Kristensen, B.B., 2003. Associations: Abstractions over

Collaboration. Proceedings of the 2003 IEEE

International Conference on Systems, Man &

Cybernetics.

Madsen, O.L., Møller-Pedersen, B., Nygaard, K., 1993.

Object Oriented Programming in the Beta

Programming Language. Addison Wesley.

Matsuoka, S., Yonezawa, A., 1993. Analysis of

Inheritance Anomaly in Object-Oriented Concurrent

Languages. In G. Agha, P. Wegner, and A. Yonezawa,

editors, Research Directions in Object-Based

Concurrency. MIT Press.

May, D.C-M., B.B.Kristensen, B.B., P.Nowack, P., 2001.

TangO: Modeling In Style. Proceedings of the Second

International Conference on Generative Systems in the

Electronic Arts.

Rumbaugh, J., 1987. Relations as Semantic Constructs in

an Object-Oriented Language. Proceedings of the

Object-Oriented Systems, Languages and Applications

Conference.

Rumbaugh, J., Blaha, J.M., Premerlani, W., Eddy, F.,

Lorensen, 1991. Object-Oriented Modeling and

Design. Prentice Hall.

Weiser, M., 1991. The Computer for the 21st Century.

www.ubiq.com/hypertext/weiser/SciAmDraft3.html.

Zhao, L., 2005. Designing Application Domain Models

with Roles. Lecture Notes in Computer Science,

Volume 3599.

ICSOFT 2006 - INTERNATIONAL CONFERENCE ON SOFTWARE AND DATA TECHNOLOGIES
