A SCENARIO GENERATION METHOD USING A

DIFFERENTIAL SCENARIO

Masayuki Makino, Atsushi Ohnishi

Department of Computer Science, Ristumeikan University, Kusatsu, Shiga 525-8577, Japan

Keywords: Scenario analysis, Scenario generation, Requ

irements elicitation, Requirements definition.

Abstract: A generation method of scenarios using differ

ential information between normal scenarios is presented.

Behaviours of normal scenarios belonging to the same problem domain are quite similar. We derive the

differential information between them and apply the information to generate new scenarios. Our method

will be illustrated with an example.

1 INTRODUCTION

Scenarios are important in software development,

particularly in requirements engineering, by

providing concrete system description

(Weidenhaupt et al., 1998). Especially, scenarios are

useful in defining system behaviors by system

developers and validating the requirements by

customers. In scenario-based software development,

incorrect scenarios will have a negative impact on

the overall system development process. However

scenarios are usually informal and it is difficult to

verify the correctness of scenarios.

The authors have developed a scenario language

for

describing scenarios in which simple action

traces are embellished to include typed frames

based on a simple case grammar of actions and for

describing the sequence among events (Zhang et al.,

2004). Since this language is a controlled language,

the vagueness of the scenario written with this

language can be reduced. Furthermore, the scenario

with this language can be transformed into internal

representation. In the transformation, both the lack

of cases and the illegal usage of noun types can be

detected (Ohnishi, 1996).

Scenarios can be classified into 1) normal

scenari

o, 2) alternative scenario, and 3) exceptional

scenario. A normal scenario represents the normal

and typical behavior of the target system, while an

alternative scenario represents normal but untypical

behavior of the system and an exceptional scenario

represents abnormal behavior of the system. In

order to grasp whole behaviors of the system, not

only normal scenarios, but also alternative/

exceptional scenarios should be specified. However

it is difficult to hit upon most of alternative

scenarios and exceptional scenarios, whereas it is

easy to think of normal scenarios.

2 SCENARIO LANGUAGE

2.1 Outline

The scenario language named SLAF has already

been introduced (Zhang, 2004, Toyama 2005). In

this paper, a brief description of this language will

be given for convenience.

A scenario can be regarded as a sequence of

event

s. Events are behaviors employed by users or

the system for accomplishing their goals. We

assume that each event has just one verb, and that

each verb has its own case structure (Fillmore,

1968). The scenario language has been developed

based on this concept. Verbs and their own case

structures depend on problem domains, but the roles

of cases are independent of problem domains. The

roles include agent, object, recipient, instrument,

source, etc.

We provide requirements frames (Ohnishi, 1996)

n which verbs and their own case structures are

specified. The requirements frame depends on

problem domains. Each action has its case structure,

and each event can be automatically transformed

into internal representation based on the frame. In

the transformation, concrete words will be assigned

to pronouns and omitted indispensable cases. With

Requirements Frame, we can detect both the lack of

cases and the illegal usage of noun types.

We assume four kinds of time sequences among

279

Makino M. and Ohnishi A. (2006).

A SCENARIO GENERATION METHOD USING A DIFFERENTIAL SCENARIO.

In Proceedings of the First International Conference on Software and Data Technologies, pages 279-282

 SciTePress

events: 1) sequential, 2) selective, 3) iterative, and

4) parallel. Actually most events are sequential

events.

2.2 Scenario Example

We consider a scenario of train ticket reservation of

a railway company. Figure 1 shows a scenario of

customer’s purchasing a ticket of express train at a

service center of a railway company. This scenario

is written with our scenario language based on

videoized behaviors of both a user and a staff at a

service center of a railway company (Railway

Information System, 2001).

[Title: A customer purchases a train ticket of reservation seat]

[Viewpoints: Staff, customer]

1. A staff asks a customer about leaving station, destination and

traveling date as customer’s request.

2. The staff sends the customer’s request to reservation center via

private line.

3. He retrieves available trains with the request.

4. He informs the customer of a list of available trains.

5. The customer selects a train that he/she will get.

6. The staff retrieves available seats of the train.

7. He shows a list of available seats of the train.

8. The customer selects a seat of the train.

9. If (there exists a seat selected by the customer) then the staff

reserves the seat with the terminal.

10. The staff gets a permission to issue a ticket of the seat from the

center.

11. The customer pays for the ticket by cash.

12. The staff gives the ticket to the customer.

13. If (changes exist) then the staff gives changes.

Figure 1: Scenario example.

A title of the scenario is given at the first line of

the scenario in Fig.1. Viewpoints of the scenario are

specified at the third line. In this paper, viewpoints

mean active objects such as human and system

appearing in the scenario. There exist two

viewpoints, namely staff and customer. The order of

the specified viewpoints means the priority.

In this scenario, almost all events are sequential,

except for just two selective events (the 9

event

and the 13

event). Selection can be expressed with

if-then syntax like program languages. Actually,

event number is for reader’s convenience and not

necessary.

2.3 Analysis of Events

Each of events is automatically transformed into

internal representation. For example, the 2

event

“The staff sends the customer’s request to

reservation center via private line” can be

transformed into internal representation shown in

Table 1.

In this event, the verb “send” corresponds to the

concept “data flow.” The data flow concept has its

own case structure with four cases, namely to say,

source case, goal case, object case and instrument

case. Sender corresponds to the source case and

receiver corresponds to the goal case. Data

transferred from source case to goal case

corresponds to the object case. Device for sending

data corresponds to the instrument case. In this

event, “customer’s request” corresponds to the

object case and “the staff” corresponds to the source

case.

Table 1: Internal representation of the 2nd event.

Concept: Data Flow

source goal object instrument

Staff Reservation

center

Customer’s

request

Private line

The internal representation is independent of

surface representation of the event. Suppose other

representations of event, “Customer’s request is

sent from staff to reservation center via private line”

and “reservation center receives customer’s request

from staff via private line.” These events are

syntactically different but semantically same as the

event. These two events can be automatically

transformed into the same internal representations.

3 DIFFERENTIAL SCENARIO

Systems belonging to the same domain similarly

behave each other. In other words, normal scenarios

belonging to the same domain resemble each other.

Since our scenario language provides limited

vocabulary and limited grammar, the abstraction

level of any scenarios becomes almost same.

For one system, there exist several normal

scenarios. In case of ticket reservation, reservation

can be written as a normal scenario and cancellation

can be written as another normal scenario. To make

a differential scenario, we select two normal

scenarios of two different systems. Each of the two

scenarios represents almost same behavior, such as

reservation of a ticket.

The differential scenario consists of 1) a list of

corresponding words, 2) deleted events which

appear in one scenario (say, scenario A) and do not

appear in the other (say, scenario B), and 3) added

events which do not appear in scenario A and

appear in scenario B.

Fig. 2 shows a scenario of flight ticket

reservation using credit card. By comparing two

scenarios, we can get the differential scenario. The

first four events of the scenario in Fig. 1 can be

transformed as shown in Table 2. In fact, data flow

ICSOFT 2006 - INTERNATIONAL CONFERENCE ON SOFTWARE AND DATA TECHNOLOGIES

280

concept has four cases, that is, source, goal, object,

and instrument cases as shown in Table 1, but the

instrument cases are omitted in Table 2 and 3 for the

space limitation.

Since the sequence of the concepts of the first

four events of the scenario in Fig. 1 is same as that

of the scenario in Fig. 2, we can regard these events

are corresponding each other. Then, the difference

between cases of the corresponding events will be

checked. In the case of the first event of the two

scenarios, object cases of the events are different

each other.

[Title: A customer purchases a flight ticket]

[Viewpoints: Staff, customer]

1. A staff asks a customer about leaving airport, destination, and

departure date as customer’s request.

2. The staff sends the customer’s request to reservation center via

private line.

3. He retrieves available flights with the request.

4. He informs the customer of a list of available flights.

5. The customer selects a flight that he/she will get.

6. The staff retrieves available seats of the flight.

7. He shows a list of available seats of the flight.

8. The customer selects a seat of the flight.

9. If (there exists a seat selected by the customer) then the staff

reserves the seat with the terminal.

10. The staff gets a permission to issue a ticket of the seat from the

center.

11. The customer pays for the ticket by credit card.

12. The staff checks the credit card.

13. The staff charges the ticket fee to the card.

14. The staff gives the ticket to the customer.

Figure 2: Normal scenario of flight reservation.

Table 2: The internal representation of the first four events

of the scenario in Fig.1.

concept agent/

source

goal objects

query staff customer leaving station,

destination,

traveling date

data flow staff reservation

center

customer’s

request

retrieve staff available

trains

request

data flow staff customer list of available

trains

Table 3: The internal representation of the first four events

of the scenario in Fig.2.

concept agent/

source

goal objects

query staff customer leaving airport,

destination,

departure date

data

flow

staff reservation

center

customer’s

request

retrieve staff available

flights

request

data

flow

staff customer list of available

flights

The difference between corresponding events will

be stored as corresponding words in Table 4. The

12th and the 13th events of Fig. 2 are not-

corresponding events and will be stored as added

events, while the 12th event of Fig. 1 and the 14th

event of Fig. 2 are corresponding events. The 13th

event of Fig. 1 is a not-corresponding event and will

be stored as a deleted event.

Finally, we can get the differential scenario

between train ticket reservation and flight ticket

reservation shown in Table 4, 5, and 6.

Table 4: A list of corresponding words between scenarios

of Figure 1 and 2.

Fig.1 Fig.2 Fig.1 Fig.2

station airport trains flights

traveling departure cash credit card

train flight

Table 5: Added events.

The staff checks the credit card.

The staff charges the ticket fee to the card

Table 6: Deleted events.

If (changes exist) then the staff gives changes.

4 SCENARIO GENERATION

Once differential scenario between system A and B

given, we can apply it to another scenario of system

A and get a new scenario of system B by changing

corresponding words and by deleting or adding not-

corresponding events.

Fig. 3 shows an exceptional scenario of ticket

reservation. In this scenario, the customer cannot

get any available trains with respect to the first

request. So, the customer changes the traveling date

and then gets available trains.

By applying the differential scenario in Table 4,

5, and 6, we can get a new exceptional scenario of

flight ticket reservation as shown in Fig. 4.

[Title: A customer purchases a train ticket of reservation seat, but

cannot find available train, so he gives the second choice.]

[Viewpoints: Staff, customer]

1. A staff asks a customer about leaving station, destination and

traveling date as customer’s request.

2. The staff sends the customer’s request to reservation center via

private line.

3. He cannot find available trains with the request.

4. He informs the customer of no available trains and asks the customer

about another traveling date.

5. The customer gives another traveling date.

6. The staff sends the customer’s request to reservation center via

private line.

7. He retrieves available trains with the new request.

8. He informs the customer of a list of available trains.

9. The customer selects a train that he/she will get.

10. The staff retrieves available seats of the train.

11. He shows a list of available seats of the train.

12. The customer selects a seat of the train.

13. …

Figure 3: An exceptional scenario.

A SCENARIO GENERATION METHOD USING A DIFFERENTIAL SCENARIO

281

[Title: A customer purchases a flight ticket of reservation seat,

but cannot find available flight, so he gives the second choice.]

[Viewpoints: Staff, customer]

1. A staff asks a customer about leaving airport, destination and

departure date as customer’s request.

2. The staff sends the customer’s request to reservation center

via private line.

3. He cannot find available flights with the request.

4. He informs the customer of no available flights and asks the

customer about another departure date.

5. The customer gives another departure date.

6. The staff sends the customer’s request to reservation center

via private line.

7. He retrieves available flights with the new request.

8. He informs the customer of a list of available flights.

9. The customer selects a flight that he/she will get.

10. The staff retrieves available seats of the flight.

11. He shows a list of available seats of the flight.

12. The customer selects a seat of the flight.

13. …

Figure 4: Generated a new exceptional scenario.

5 RELATED WORKS

Ben Achour proposed guidance for correcting

scenarios, based on a set of rules (Achour, 1998).

These rules aim at the clarification, completion and

conceptualization of scenarios, and help the

scenario author to improve the scenarios until an

acceptable level in terms of the scenario models.

Ben Achour's rules can only check whether the

scenarios are well written according to the scenario

models. We propose generation methods of

exceptional scenarios and alternative scenarios from

a normal scenario.

Derek Cramp claimed the importance of

alternative scenarios. He proposed a model to create

alternative scenarios (Cramp et al., 1995). However,

his model strongly depends on a specific domain.

Ian Alexander proposed a scenario-driven search

method to find more exceptions (Alexander, 2000).

In his approach, a model answer was prepared with

knowledge of all exception cases identified by

stakeholders. For each event, related exceptions are

listed as a model answer. His model answer,

however, strongly depends on a specific domain.

Neil Maiden et al. proposed classes of exceptions

for use cases (Maiden et al, 1998). These classes are

generic exceptions, permutations exceptions,

permutation options, and problem exceptions. With

these classes, alternative courses are generated.

They proposed a generation method of alternative

paths for each normal sequence from exception

types for events and generic requirements with

abnormal patterns (Sutcliff et al., 1998).

Our approach for generating scenarios with a

differential scenario is independent of problem

domains.

6 CONCLUSION

We have developed a generation method of

scenarios using a differential scenario. Because of

the space limitation, we showed just one example,

but we confirmed that alternative scenarios and

different normal scenarios can be generated with

our method.

We have to validate the ideas more thoroughly

by applying to several different problem domains.

We have been developing a prototype system based

on the method. The evaluation of our method

through the use of the prototype system is another

future work.

REFERENCES

Achour, C. B., 1998: Guiding Scenario Authoring, Proc. of

the Eight European-Japanese Conference on

Information Modeling and Knowledge Bases, pp.181-

200.

Alexander, I., 2000: Scenario-Driven Search Finds More

Exceptions, Proc. 11

International Workshop on

Database and Expert Systems Applications, pp.991-

994.

Cramp, D.G., Carson E.R., 1995: Assessing Health Policy

Strategies: A Model-Based Approach to Decision

Support, Proc. International Conference on System,

Man and Cybernetics, Vol.3, pp.69-73.

Fillmore, C.J., 1968: The Case for Case, in Universals in

Linguistic Theory, Holt, Rinehart and Winston.

Maiden, N.A.M., Manning’ M.K., Ryan M., 1998:

CREWS-SAVRE: Systematic Scenarios Generation

and Use, Proc. IEEE 3

ICRE’98, pp.148-155.

Ohnishi, A., 1996: Software Requirements Specification

Database on Requirements Frame Model, Proc. IEEE

ICRE’96, pp.221-228.

Railway Information System Co., Ltd., 2001: JR System,

http://www.jrs.co.jp/keiki/en/index_main.html.

Sutcliffe, A. G., Maiden, N. A. M., Minocha S., Manuel D.,

1998: Supporting Scenario-Based Requirements

Engineering, IEEE Trans. Software Engineering,

Vol.24, No.12, pp.1072-1088.

Toyama, T., Ohnishi, A., 2005: Rule-based Verification of

Scenarios with Pre-conditions and Post-conditions,

Proc. 13

IEEE RE2005, pp. 319-328.

Weidenhaupt, K., Pohl, K., Jarke, M., Haumer, P., 1998:

Scenarios in System Development: Current Practice,

IEEE Software, March, pp.34-45.

Zhang H., Ohnishi, A., 2004: Transformation between

Scenarios from Different Viewpoints, IEICE Trans.

Information and Systems, Vol.E87-D, No.4, pp.801-

810.

ICSOFT 2006 - INTERNATIONAL CONFERENCE ON SOFTWARE AND DATA TECHNOLOGIES

282
