IMPACT OF WRAPPED SYSTEM CALL MECHANISM ON

COMMODITY PROCESSORS

Satoshi Yamada and Shigeru Kusakabe

Grad. School of Information Sci. & Electrical Eng., Kyushu University

6-10-1 Hakozaki, Higashi-ku, Fukuoka, 812-8581 Japan

Hideo Taniguchi

Faculty of Engineering, Okayama University

3-1-1 Tsushima-naka, Okayama, 700-8530 Japan

Keywords:

System call, mode change, locality of reference.

Abstract:

Split-phase style transactions separate issuing a request and receiving the result of an operation in different

threads. We apply this style to system call mechanism so that a system call is split into several threads in

order to cut off the mode changes from system call execution inside the kernel. This style of system call

mechanism improves throughput, and is also useful in enhancing locality of reference. In this paper, we call

this mechanism as Wrapped System Call (WSC) mechanism, and we evaluate the effectiveness of WSC on

commodity processors. WSC mechanism can be effective even on commodity platforms which do not have

explicit multithread support. We evaluate WSC mechanism based on a performance evaluation model by using

a simpliﬁed benchmark. We also apply WSC mechanism to variants of cp program to observe the effect on

the enhancement of locality of reference. When we apply WSC mechanism to cp program, the combination

of our split-phase style system calls and our scheduling mechanism is effective in improving throughput by

reducing mode changes and exploiting locality of reference.

1 INTRODUCTION

Although recent commodity processors are built

based on a procedural sequential computation model,

we believe some dataﬂow-like multithreading mod-

els are effective not only in supporting non-sequential

programming models but also in achieving high

throughput even on commodity processors. Based

on this assumption, we are developing a program-

ming environment, which is based on a dataﬂow-

like ﬁne-grain multithreading model(Culler et al.,

1993). Our work also includes a dataﬂow-like mul-

tithread programming language and an operating sys-

tem, CEFOS(Communication and Execution Fusion

OS)(Kusakabe and et al, 1999).

In our dataﬂow-like multithreading model, we use

a split-phase style system call mechanism in which a

request of a system call and the receipt of the system

call result are separated in different threads. Split-

phase style transactions are useful in hiding laten-

cies of unpredictably long operations in several sit-

uations. We apply this style to system calls and

call as Wrapped System Call (WSC) mechanism.

WSC mechanism is useful both in reducing overhead

caused by system call mechanisms on commodity

processors and in enhancing locality of reference.

In this paper, we evaluate the effectiveness of WSC

mechanism on commodity processors. Section 2 in-

troduces our operating system, CEFOS, and some of

its features including WSC mechanism. Section 3 dis-

cusses the performance estimation and experimental

benchmark results of WSC mechanism from the view

point of system call overhead. Section 4 evaluates

WSC mechanism for variants of cp program from the

view point of locality of reference. We conclude WSC

mechanism can reduce system call overhead and en-

hance locality of reference even on commodity plat-

forms, which have no explicit support to dataﬂow-like

multithreading.

2 SCHEDULING MECHANISMS

IN CEFOS

2.1 CEFOS for Fine-Grained

Multithreading

While running user programs under the control of an

operating system like Unix, frequent context switches

308

Yamada S., Kusakabe S. and Taniguchi H. (2006).

IMPACT OF WRAPPED SYSTEM CALL MECHANISM ON COMMODITY PROCESSORS.

In Proceedings of the First International Conference on Software and Data Technologies, pages 308-315

DOI: 10.5220/0001321003080315

 SciTePress

Table 1: Results of LMbench (Clock Cycles).

processor null call 2p/0K 2p/16K L1$ L2$ MainMem

Celeron 500MHz 315 675 3235 3 11 93

Pentium4 2.53 GHz 1090 3298 5798 2 18 261

Intel Core Duo 1.6GHz 464 1327 2820 3 14 152

PowerPC G4 1GHz 200 788 2167 4 10 127

and communications between user processes and the

kernel are performed behind the scenes. A system call

requests a service of the kernel, and then voluntarily

causes mode change. Activities involving operating

system level operations are rather expensive on com-

modity platforms.

Table 1 shows the result of a micro-benchmark

LMbench (McVoy and Staelin, 1996) on platforms

with commodity processors and Linux. The row “null

call” shows the overhead of a system call and the row

“2p/0K” shows that of a process switch when we have

two processes of zero KB context. Thus, the row “x

p/y K” shows the overhead of a process switch for

the pair of x and y which represent the number and

the size of processes, respectively. The rows “L1$”,

“L2$” and “MainMem” show the access latency for

L1 cache, L2 cache and main memory, respectively.

As seen from Table 1, activities involving operating

system level operations such as system calls and con-

text switches are rather expensive on commodity plat-

forms.

Therefore, one of the key issues to improve sys-

tem throughput is to reduce the frequency of context

switches and communications between user processes

and the kernel. In order to address this issue, we em-

ploy mechanisms for efﬁcient cooperation between

the operating system kernel and user processes based

on a dataﬂow-like multithreading model in CEFOS.

Figure 1 shows the outline of the architecture of

CEFOS consisting of two layers: the external ker-

nel in user mode and the internal kernel in supervi-

sor mode. Internal kernel corresponds to the kernel of

conventional operating systems. A process in CEFOS

has a thread scheduler to schedule its ready threads.

A program in CEFOS consists of one or more par-

tially ordered threads which may be ﬁne-grained com-

pared to conventional threads such as Pthreads. A

thread in our system does not have a sleep state and

we separate threads in a split-phase style at the points

where we anticipate long latencies. Each thread is

non-preemptive and runs to its completion without

going through sleep states like Pthreads. While op-

erations within a thread are executed based on a se-

quential model, threads can be ﬂexibly scheduled as

long as dependencies among threads are not violated.

A process in CEFOS has a thread scheduler and

schedules its ready threads basically in the user-

space. Since threads in CEFOS are a kind of user-

level thread, we can control threads with small over-

head. The external-kernel mechanism in CEFOS in-

termediates interaction between the kernel and thread

schedulers in user processes. Although there ex-

ist some works on user level thread scheduling such

as Capriccio (Behren and et al, 2003), our research

differs in that we use ﬁne-grain thread scheduling.

In order to simplify control structures, process con-

trol is only allowed at the points of thread switch-

ing. Threads in a process are not totally-ordered

but partially-ordered, and we can introduce various

scheduling mechanisms as long as the partial order

relations among threads are not violated. Thus, CE-

FOS has scheduling mechanisms such as WSC mech-

anisms and Semi-Preemption mechanism.

2.2 Display Requests and Data

(DRD) Mechanism

Operating systems use system calls or upcalls

(E.A.Thomas and et al, 1991) for interactions be-

tween user programs and operating system kernel.

System calls issue the demands of user processes

through SVC and Trap instructions, and upcalls in-

voke speciﬁc functions of processes. The problem in

these methods is overhead of context switches (Puro-

hit and et al, 2003). We employ Display Requests

and Data (DRD) mechanisms (Taniguchi, 2002) for

cooperation between user processes and the kernel in

CEFOS as we show below:

1. Each process and the kernel share a common mem-

ory area (CA).

2. Each process and the kernel display requests and

necessary information on CA.

3. At some appropriate occasions, each process and

the kernel check the requests and information dis-

played on CA, and change the control of its execu-

tion if necessary.

This DRD mechanism assists cooperation between

processes and the kernel with small overhead. A

sender or receiver of the request does not directly trig-

ger the execution of request at the instance the request

is generated. If the sender triggers directly the exe-

cution of receiver’s side, the system may suffer from

IMPACT OF WRAPPED SYSTEM CALL MECHANISM ON COMMODITY PROCESSORS

309

thread

external kernel

process

.....

thread

external kernel

process

.....

thread

external kernel

process

.....

internal kernel

user

mode

supervisor

mode

Figure 1: Overview of CEFOS.

large overhead to switch. On the other hand, the sys-

tem handles the request at its convenience with small

overhead if we use DRD mechanism. For an extreme

example, all requests from a process to the kernel are

buffered and the kernel is called only when the pro-

cess exhausted its ready threads.

The external kernel mechanism in CEFOS inter-

mediates interaction between the internal kernel and

thread schedulers in user processes by using this

DRD mechanism. Thus, CEFOS realizes schedul-

ing mechanisms such as WSC mechanism and Semi-

Preemption mechanism by using DRD mechanism.

2.3 WSC Mechanism

WSC mechanism buffers system call requests from

user programs until the number of the requests satis-

ﬁes some threshold and then transfers the control to

the internal kernel with a bucket of the buffered sys-

tem call requests. Each system call request consists

of four kinds of elements listed below.

• type of the system call

• arguments of the system call

• the address where the system call stores its result

• ID of the thread which the system call syncs after

the execution

The buffered system calls are executed like a single

large system call and each result of the original sys-

tem calls is returned to the appropriate thread in the

user process. Figure 2 illustrates the control ﬂow in

WSC mechanism, and each number in Figure 2 cor-

responds to the explanation below.

1. A thread requests a system call to External Kernel.

2. External Kernel buffers the request of system call

to CA.

3. External Kernel checks whether the number of re-

quests has reached the threshold. If the number of

requests is less than the threshold, the thread sched-

uler is invoked to select the next thread from the

ready threads in the process. If the number of re-

quest has reached the threshold, WSC mechanism

sends the requests of system calls to the internal

kernel to actually perform the system calls.

4. Internal Kernel accepts the requests of system calls

and executes them one by one.

5. Internal Kernel stores the result of the system call

to the address which Internal Kernel accepts as the

third arguments of the system call. Also, Internal

Kernel tells the thread, whose ID is accepted as the

fourth argument, that it stores the result.

6. When Internal Kernel terminates executing all re-

quests of system calls, External Kernel executes

other threads. In other cases, WSC mechanism

goes back to 3 and repeats this transaction.

WSC mechanism reduces overhead of system calls

by decreasing the number of mode changes from user

process to the kernel. Parameters and returned re-

sults of the buffered system calls under WSC mecha-

nism are passed through CA of DRD to avoid frequent

switches between the execution of user programs and

that of the kernel.

3 EVALUATION: SYSTEM CALL

OVERHEAD

We evaluate the effectiveness of WSC mechanism on

commodity processors. The test platform is built by

extending Linux 2.6.14 on commodity PCs.

ICSOFT 2006 - INTERNATIONAL CONFERENCE ON SOFTWARE AND DATA TECHNOLOGIES

310

Table 2: The values to calculate M (in clocks), and the estimated value of M.

processor (Hz) T

gen

sched

sync

req

Celeron 500M 63 31 21 31 3.4

Pentium4 2.53G 110 43 27 31 1.24

Intel Core Duo 1.62G 61 30 19 29 1.42

process

thread threadsplit-phase

system call

request of

system call

buffer system call

requests

# requests >= threshold ?

thread scheduler

external kernel

internal kernel

execute system calls

User

mode

Supervisor

mode

return results &

activate waiting

threads

thread

YES

5,6

Figure 2: Control ﬂow in WSC mechanism.

3.1 Estimation of the Effectiveness of

WSC

First, we estimate the effectiveness of WSC mecha-

nism by focusing on system call overhead. We com-

pare the execution time of a program with normal sys-

tem calls under the normal mechanism and that with

split-phase system calls under WSC mechanism.

The total execution time of a program with N nor-

mal system calls under the normal mechanism, T

nor

is estimated as:

nor

= T

onor

+ N × (T

sys

+ T

body

) + P

nor

(1)

where T

onor

is the execution time of the program por-

tion excluding system calls under the execution of the

normal system call mechanism, T

sys

is the setup and

return cost of a single system call, and T

body

is the

execution time of the actual body of the system call.

In this estimation, we assume that we use the same

system call and that there exist no penalties concern-

ing memory hierarchies such as cache miss penalties

and TLB miss penalties in T

onor

and T

body

. P

nor

the total penalties including cache miss penalties and

TLB miss penalties during the execution of the nor-

mal system call mechanism.

Programs to which we can apply WSC mechanism

are multithreaded and use split-phase style system

calls. Additional thread management should be per-

formed in this multithreaded program and we describe

the overhead of this additional part as T

. T

is es-

timated as:

= X × T

gen

+ Y × T

sche

+ Z × T

sync

(2)

where X is the number of threads, T

gen

is the over-

head to generate a single thread, Y is the number of

times threads are scheduled, T

sche

is the overhead to

schedule a thread, Z is the number of times synchro-

nizations are tried and T

sync

is the overhead of a syn-

chronization.

Although the execution of system call bodies will

be aggregated, buffering system call request must be

performed for each system call. We represent the

overhead of buffering a single system call request

as T

req

. Thus, T

wsc

, the total execution time of a

program with N split-phase system calls under WSC

mechanism, is estimated as:

wsc

owsc

+ T

+ N × T

req

[N/M] × T

sys

+ N × T

body

+ P

wsc

(3)

where T

owsc

is the execution time of the program por-

tion excluding system calls, M is the number of sys-

tem calls to be buffered for a single WSC (i.e. WSC

threshold) and P

wsc

is the total penalties concern-

ing memory hierarchies including cache miss penal-

ties and TLB miss penalties during the execution un-

der WSC. We assume none of such penalties exists in

owsc

as in the estimation for T

onor

and T

body

∆T , the difference between the execution time un-

der the normal mechanism and that of under CEFOS

with WSC is estimated as:

∆T =T

wsc

− T

nor

=(T

owsc

− T

onor

+ N × T

req

− (N − [N/M]) × T

sys

wsc

− P

nor

)

(4)

IMPACT OF WRAPPED SYSTEM CALL MECHANISM ON COMMODITY PROCESSORS

311

0.2

0.4

0.6

0.8

1.2

1.4

1.6

1.8

1 2 4 8 16 32

# of threshold

Celeron 500MHz

Pentium4 2.53GHz

Intel Core Duo 1.66GHz

normal

Figure 3: Comparison of clock cycles (getpid).

We can say the performance is improved by WSC

mechanism when ∆T < 0. We estimate the value

of M, the number of system calls to be buffered, to

satisfy this condition. We assume the following con-

ditions for the sake of simplicity: each program por-

tion excluding system calls is the same, and each sys-

tem call body is the same both in the normal ver-

sion and in CEFOS version. Under these assump-

tions, we will only observe the difference of system

call cost between the normal version and the CEFOS

version. This assumption makes T

owsc

− T

onor

and

wsc

− P

nor

amount to zero. We also assume X, Y

and Z are equal to N. Thus, we can estimate the con-

dition for M to satisfy ∆T < 0 as:

M >

sys

− (T

gen

+ T

sche

+ T

sync

+ T

req

)

(5)

We measured each value in (5) in order to calculate

the value of M that satisﬁes the above condition as

shown in Table 2 (we used the values of null call in

Table 1 for T

sys

)

The performance on Pentium4 2.53GHz and In-

tel Core Duo 1.62GHz will be improved when M is

larger 1. The performance on Celeron 500MHz will

be improved when M is larger than 4. (Please note M

is a natural number)

3.2 Performance Evaluation Using

getpid()

The above estimation assumed each system call body

is the same both in the normal version and in CEFOS

version for the sake of simplicity. In this subsection,

we examine our estimation by using getpid() as a

system call to meet such an assumption. We measured

We omit the values of PowerPC G4 because of the

problem of accuracy. However, the observed M for Pow-

erPC G4 is 4 according to the experiment explained in the

next subsection.

open() open()

read()

write()

close() close()

buffer

descriptor descriptor

file1 file2

A A

Figure 4: Control ﬂow in cp program.

the number of clocks for a number of getpid()sys-

tem calls using the hardware counter. We executed

128 getpid() system calls in our experiments. We

changed the threshold of WSC as 1, 2, 4, 8, 16 and

32 for the WSC version. We also measured the total

time of successive getpid() system calls under the

normal system call convention in unchanged Linux.

Figure 3 shows the comparison results of clock cy-

cles for getpid() system calls. The x-axis indi-

cates the threshold of WSC and y-axis the ratio of

clock cycles of WSC versions compared with clock

cycles under the normal system call convention in un-

changed Linux. The lower y value indicates the better

result of WSC.

As seen from Figure 3, we have extra overhead

when WSC threshold is 1, because of newly added

load of T

gen

, T

sche

, T

sync

and T

req

. However, we

observe the effect of WSC when the threshold be-

comes 2 for Pentium4 2.53GHz and Intel Core Duo

1.66GHz and 4 for Celeron 500 MHz as we estimated

in the previous estimation. The clock cycles in WSC

versions are decreased as the threshold gets larger re-

gardless of the processor type.

4 EVALUATION: LOCALITY OF

REFERENCE

In the previous section, we evaluate the effectiveness

of WSC mechanism in reducing overhead caused by

system calls. In this section, we examine the effec-

tiveness in exploiting locality of reference. We can

expect high throughput when we can aggregate sys-

tem calls which refer to the same code or data. The

test platform is also built by extending Linux 2.6.14

on Pentium4 2.53 GHz.

4.1 cp Program

We use modiﬁed cp programs to evaluate the

effectiveness of WSC mechanism in exploit-

ICSOFT 2006 - INTERNATIONAL CONFERENCE ON SOFTWARE AND DATA TECHNOLOGIES

312

ing locality of reference. Figure 4 shows an

overview of the control ﬂow in cp program,

and the symbols A, B and C in Figure 4 cor-

respond to the ones in the explanation below.

A. one open() system call opens a ﬁle to read and

the other open() system call opens another ﬁle

to write, preparing a ﬁle descriptor for each ﬁle

respectively.

B. read()system call reads up to designated bytes

from the ﬁle descriptor into buffer, and then

write() system call writes up to designated

bytes to the ﬁle referenced by the ﬁle descriptor

from buffer.

C. close() system calls close these ﬁles.

Thus, a cp program uses six system calls per trans-

action. We use a cp program called NORMAL

version, which executes these six system calls in

the order we show above, like open(), open(),

read(), write(), close() and close(). We

have to open() a ﬁle before executing read() or

write(), and we have to specify the ﬁle descriptor,

which is the result of open()system call, to execute

read(), write() and close(). Therefore, we

cannot simply wrap these six system calls. We have

to wrap two open() system calls and other four sys-

tem calls respectively. Because of the additional over-

head of using WSC mechanism that we mentioned in

Figure 3, we cannot expect the effect when applying

WSC mechanism to just one cp transaction. In fact,

doing one cp in WSC version of one cp took about

two times clock cycles compared to NORMAL ver-

sion. Therefore, we consider doing multiple cps in a

program.

We use other four versions of cp program, and

measure 11 portions of these 5 programs to observe:

I. whether WSC mechanism is effective or not in

cp programs in total,

II. the difference between the effect of wrapping

single type of system calls and that of wrapping

various types of system calls, and

III. the effect of wrapping system calls which have

the same code but refer to different data.

Figure 5 shows these 5 programs and 11 portions.

“N” in Figure 5 is the number of cp transactions.

Now, we explain each program and portion below.

Then we explain why we choose these portions to ex-

amine the points of our interests above.

In Program 2 in Figure 5, we wrap every one of six

kinds of system calls. We call this WSC+COLLECT

version.

As a counterpart of this WSC+COLLECT, we also

collect system calls of the same type in a block but ex-

ecute the block with normal system call convention.

We call this program as NORMAL+COLLECT ver-

sion (Program 3 in Figure 5).

In addition, we implement WSC+RW and NOR-

MAL+RW version (Program 4 and 5 in Figure 5),

which change the order of read() and write()

in WSC+COLLECT and NORMAL+COLLECT ver-

sion.

Then, we show the explana-

tion of 11 portions we measure.

1. from open() to close() of NORMAL.

2. from open() to close() of NOR-

MAL+COLLECT.

3. from open() to close() of

WSC+COLLECT.

4. from open() to close() of NORMAL+RW.

5. from open() to close() of WSC+RW.

6. read() and write() part of NOR-

MAL+COLLECT.

7. read() and write() part of

WSC+COLLECT.

8. read() and write() part of NORMAL+RW.

9. read() and write() part of WSC+RW.

10. only write() of NORMAL+COLLECT.

11. only write() of WSC+COLLECT

We measured only write() in portion 10 and

11 to observe the effect of wrapping system calls

which refer to different data. While read() sys-

tem call contains disk access time, write() system

call buffers access to the disk and enables us to ob-

serve the effect of WSC mechanism excluding disk

access time. Also, we implemented NORMAL+RW

and WSC+RW and measured portion 6, 7, 8 and 9 to

observe the effect of wrapping two types of system

calls together. Then, we measured the whole cp in

portion 1, 2 and 3 to examine if WSC mechanism is

effective or not in total. Also, we measured portion 4

and 5 to examine the inﬂuence of wrapping read()

and write() system calls on cp total.

We measure clock cycles and the number of events

such as L1 cache misses in every portion. From these

results, we investigate how WSC mechanism effects

locality of reference from the view point of I, II and

III above.

4.2 Performance Evaluation

Table 3 shows the result of cpprograms. In this case,

WSC threshold is 8 and we do cp transactions 100

times, which means N in Figure 5 is 100. The num-

bers in the row “portion” correspond to the numbers

of the explanation we show in subsection 4.1. The

row “#clocks” shows clock cycles, the row “L2$”

shows L2 cache miss counts and rows “ITLB”, and

“DTLB” show the walk counts for ITLB and DTLB,

respectively. We measured these events with a perfor-

mance monitoring tool perfctr (Petterson, n.d.).

IMPACT OF WRAPPED SYSTEM CALL MECHANISM ON COMMODITY PROCESSORS

313

open()

read()

write()

close()

open() N

read() N

write() N

close() N

open() N

read()

write()

close() N

open() N

close() N

Program 1.

NORMAL

Program 3.

NORMAL+COLLECT

Program 5.

NORMAL+RW

Program 4.

WSC+RW

open() N

read() N

write() N

close() N

Program 2.

WSC+COLLECT

read()

write()

portion 1

portion 2

portion 4

portion 8portion 6

portion 10

portion 3

portion 5

portion 9

represents the execution of normal system calls

represents the execution of system calls to which we applied Wrapped System Call mechanism

Figure 5: Program and Portion we measure in cp program.

0.84

0.86

0.88

0.9

0.92

0.94

0.96

0.98

1.02

1 2 4 8

ratio of WSC/NORMAL

# of threshold

WSC

NORMAL

Figure 6: Comparison of clock cycles (write()).

In write() sections (portion 10 and 11), the

clock cycles for WSC+COLLECT write() are less

than NORMAL+COLLECT write() in about 0.12

million cycles, which is reduction to 83 % in clock

cycles. The reduction of this 0.12 million cycles

by WSC mechanism is larger than the reduction es-

timated by using formula in section 3, which is

about 0.072 million cycles for 100 write() sys-

tem calls. We consider this improvement is achieved

by enhanced locality of reference, therefore we mea-

sure the number of events concerning memory hier-

archies. As we expected, we can see the reduction

of L2 cache misses, ITLB walks and DTLB walks

in WSC+COLLECT write() compared to NOR-

MAL+COLLECT write(). Thus, we can say WSC

mechanism is effective even when each system call

refer to different data. We changed the threshold and

measured portion 10 and 11 to compare the results

with those of getpid(). Figure 6 shows the result,

and we can see the same tendency as we see in Figure

3 that wrapping more than 2 system calls is effective

in clock cycles in Pentium 4.

In read/write section (portion 6, 7, 8 and 9), we can

see the effect of wrapping different system calls by

comparing portion 6 with 7 and 8 with 9. Both clock

cycles and number of events decrease in WSC version

in both cases.

Finally, from portion 1, 2 and 3, we can say ap-

plying WSC mechanism to cp program is effective

in total. When we compare portion 2 with 3 to ig-

nore the difference of disk access pattern, the reduc-

tion in clock cycles is about 0.32 million cycles. As

we see in write() system call, we can see the re-

duction of L2 cache misses, ITLB walks and DTLB

walks. Therefore, we conclude that WSC mechanism

for split-phase style system calls is effective in ex-

ploiting locality of reference. We can see the simi-

lar result from portion 4 with 5 and reach to the same

conclusion.

ICSOFT 2006 - INTERNATIONAL CONFERENCE ON SOFTWARE AND DATA TECHNOLOGIES

314

Table 3: Results of cp program.

portion #clocks L2$ ITLB DTLB

1. NOR 2,884,325 7378 511 136

2. NOR+COLLECT 2,588,200 8800 187 207

3. WSC+COLLECT 2,262,523 7740 81 120

4. NOR+RW 2,625,804 8264 227 200

5. WSC+RW 2,431,758 8118 128 197

6. NOR+COLLECT read/write 1,090,608 4385 112 69

7. WSC+COLLECT read/write 876,703 3503 37 42

8. NOR+RW read/write 1,096,045 3875 130 72

9. WSC+RW read/write 985,227 3647 70 62

10. NOR+COLLECT write 686,883 1779 93 28

11. WSC+COLLECT write 569,206 1363 41 13

5 CONCLUSION

In this paper, we discussed our WSC mechanism in

CEFOS. While CEFOS is based on a dataﬂow-like

ﬁne-grain multithreading model, WSC mechanism is

effective in improving throughput even on commodity

platforms which have no explicit support to dataﬂow-

like ﬁne-grain multithreading.

Today, many investigation have been made about

utilizing multithreading processor, such as SMT.

Many of them tackle with memory hierarchy problem

because cache conﬂict often occurs under the con-

dition where several threads run concurrently. One

effective solution to this problem is improving the

scheduling of thread, which is conventional Pthread,

to utilize CPU resources more effectively(Snavely

and Tullsen, 2000). On the other hand, our work split

conventional thread and control the thread in user pro-

cess. Thus, we have more chances to schedule ﬁne-

grained threads more ﬂexibly with smaller overhead.

In cp program, the combination of our split-phase

style system calls and WSC mechanism is effective in

improving throughput by reducing mode changes and

penalties concerning memory hierarchies such as L2

cache misses and TLB walks.

Recently, the overhead of system call and context

switch is increasing on commodity processors. Be-

sides, we think the tendency continues that latency of

memory access becomes bottleneck, which is coming

from the gap between processor speed and memory

speed. Therefore, we think WSC will be more effec-

tive in the future, which can reduce the overhead of

system call and context switch and enhance the lo-

cality of reference. We believe this will contribute to

higher throughput of internet server and large-scale

computation in the future. Our future work includes

collecting more data from other processors and ex-

ploiting the effect of SYSENTER/SYSEXIT com-

mand in x86 architecture.

REFERENCES

Behren, R. and et al (2003). Revising old friends: Capric-

cio: scalable threads for internet services. In Proc. of

the 19th ACM symposium on Operating systems prin-

ciples, pages 268–281.

Culler, D. E., Goldstein, S. C., Schauser, K. E., and von

Eicken, T. (1993). Tam – a compiler controlled

threaded abstract machine. In Journal of Parallel and

Distributed Computing Vol.18, pages 347–370.

E.A.Thomas and et al (1991). Scheduler activation: Effec-

tive kernel support for the user-level management of

parallelism. In Proc. of the 13th ACM Symp. on OS

Principles, pages 95–109.

Kusakabe, S. and et al (1999). Parallel and distributed op-

erating system cefos. In IPSJ ISG Tech. Notes, Vol.99,

No.251, pages 25–32.

McVoy, L. and Staelin, C. (1996). lmbench:

Portable tools for performance analysis,

http://www.bitmover.com/lm/lm-bench.

Petterson, M. (n.d.). Perfctr,

http://user.it.uu.se/ mikpe/linux/perfctr/.

Purohit, A. and et al (2003). Cosy: Develop in user-land,

run in kernel-mode. In Proc. of HotOS IX: The 9th

Workshop on Hot Topics in Operating Systems, pages

109–114.

Snavely, A. and Tullsen, D. (2000). Symbiotic jobschedul-

ing for a simultaneous multithreading processor. In

9th International Conference on Architectural Sup-

port for Programming Languages and Operating Sys-

tems, pages 234–244.

Taniguchi, H. (2002). Drd: New connection mechanism

between internal kernel and external kernel. In Tran.

of IEICE, Vol.J85-D-1, No2.

IMPACT OF WRAPPED SYSTEM CALL MECHANISM ON COMMODITY PROCESSORS

315
