A SERVICE DISCOVERY THREAT MODEL FOR AD HOC

NETWORKS

Adrian Leung and Chris Mitchell

Information Security Group

Royal Holloway, University of London

Egham, Surrey, TW20 0EX, UK

Keywords:

Security, Secure Service Discovery, Threat Model, Mobile Ad Hoc Networks, MANETs.

Abstract:

The dynamic yet vulnerable nature of an hoc network presents many new security and privacy challenges.

Securing the process of service discovery is one of them. Novel solutions are therefore required. However, in

order for appropriate security measures to be devised, all possible security threats must ﬁrst be identiﬁed and

thoroughly analysed. In this paper, we present a threat model for service discovery in ad hoc networks. Based

on these threats, we proceed to derive the security services required to achieve secure service discovery.

1 INTRODUCTION

An ad hoc network is formed spontaneously by a col-

lection of two or more mobile devices. These devices,

also referred to as Nodes, may communicate directly

if they are within radio range of each other, or rely on

intermediate nodes to route their messages if they are

not. Nodes may join, leave or change their existing lo-

cations, and this results in a constantly changing net-

work topology. The dynamic and infrastructureless

nature of the ad hoc network poses many interesting

problems and challenges. Service Discovery is one of

them.

One of the primary objectives of forming an ad hoc

network is for nodes to share and utilise each others’

resources. Before a resource can be used, it needs to

be located. The process of ﬁnding available resources

in an ad hoc network is known as service discovery

and research in this important area is slowly gather-

ing momentum. A variety of ad hoc network ser-

vice discovery schemes (Garcia-Macias and Torres,

2005; Mohan et al., 2004) have recently been pro-

posed, with each scheme focusing on different aspects

of service discovery, such as architectural choice (Lim

et al., 2005), service description syntax (Tyan and

Mahmoud, 2005) and other performance metrics (Gao

et al., 2006). However, none addresses the issue of

security from the outset, despite its fundamental im-

portance.

Before any novel security solutions are devised to

secure service discovery, a thorough analysis of all

possible security threats that could arise must be con-

ducted. Effective solutions can then be developed

with these threats in mind. In this paper, we focus

on the threats that arise during service discovery, and

we also analyse the threats according to the type of

misbehaviour that the nodes exhibit.

The remainder of this paper is organised as follows.

In section 2, we deﬁne the terminology used, and sec-

tion 3 describes the different service discovery archi-

tectures. In section 4, we present the threat model. In

the penultimate section, the security requirements are

identiﬁed, and conclusions are drawn in section 6.

2 TERMINOLOGY

We begin with the deﬁnition of a service. O’Sullivan

(O’Sullivan et al., 2002) has deﬁned a Service as: “An

action performed by an entity on behalf of another and

this action involves the transfer of value”. In the con-

text of an ad hoc network, examples of service may

include printing of documents, performing computa-

tions, data storage, image capture, etc. Against this

backdrop, Service Discovery can thus be deﬁned as:

“The act or process of ﬁnding and locating a service

on a network”. The overall performance of a ser-

vice discovery scheme can be measured with a metric

known as Service Availability. This metric is the ra-

tio of the number of service requests made against the

number of requests that were actually fulﬁlled.

The entities participating in the service discovery

process are now introduced: A Service User (SU)

node is a node that seeks a particular service offered

by other nodes in the network. A Service Provider

167

Leung A. and Mitchell C. (2006).

A SERVICE DISCOVERY THREAT MODEL FOR AD HOC NETWORKS.

In Proceedings of the International Conference on Security and Cryptography, pages 167-174

DOI: 10.5220/0002097301670174

 SciTePress

(SP) node has one or more services to offer other

nodes. Depending on the service discovery architec-

ture employed, a Directory (SD) node may also be in-

volved in the service discovery process. An SD node

acts as a broker between the SU and SP nodes. It

maintains a list of the available services in the net-

work. Some nodes may not participate directly in

the service discovery process, but may be called upon

to forward or route the service messages between the

principal participants. We call these nodes Forward-

ing (FW) nodes. It is also possible for a node to take

on more than one role. For instance, a node may offer

a particular service (SP node) and also be a consumer

of another service (SU node).

A variety of different service messages are ex-

changed and sent between the entities during service

discovery. A Service Request (SrvReq) is a message

sent by an SU node to search for a particular service.

A Service Reply (SrvRep) is a message sent to an SU

node if the requested service is available. It can be

sent by either an SP or an SD node. A Service Adver-

tisement (SrvAdv) is a message sent (via broadcast)

by an SP node to announce its service offering. An SU

node sends an Acknowledgement (SrvAck) message

to the SP node if it is interested in the advertised ser-

vice. Service Register/Deregister (SrvReg/SrvDReg)

messages are sent by an SP node to an SD node to

knowledgement (SrvAck) message is sent back to the

SP node. An SD node will broadcast a Directory Ad-

vertisement (DirAdv) message to announce its pres-

ence to other nodes. A Service List (SrvList) is a ﬁle

maintained by an SD node that contains a listing of

the available services.

Two other important terms, used to denote the dis-

tance (in terms of radio ranges) between two nodes,

are hop and hop count. Nodes within radio range of

each other are said to be one hop apart. Two nodes are

X hops away from each other if a minimum of X − 1

intermediate nodes are required to route a message

between them. Hop count is deﬁned as the maximum

number of times that a particular message will be for-

warded by an intermediate node. The set of nodes

which are at most X hops away from a node is also

referred to as the scope of a node.

3 AD HOC NETWORK SERVICE

DISCOVERY ARCHITECTURES

In an ad hoc network, services may be discovered in a

number of different ways. This has an effect on how

the entities interact with each other, which in turn af-

fects the type of threats that arise during service dis-

covery. Hence, it is imperative to have a good under-

standing of the various discovery methods in order to

produce an accurate threat model.

As depicted in Figure 1, techniques for service dis-

covery in ad hoc networks can generally be classiﬁed

into three main types (Rao, 2004). They are the medi-

ated, immediate and hybrid architectures.

Mediated Immediate

Service

Discovery

Architectures

Hybrid

Active Passive

Active

+ Passive

Transparent Non-Transparent

Figure 1: Classiﬁcation of Service Discovery Architectures.

We now examine the workings of the three archi-

tectures, based on the assumption that all the nodes

are non-malicious, co-operative and trustworthy.

3.1 Mediated Architecture

This architecture is also known as the Service Co-

Ordinator Based architecture (Toh, 2002). In this

architecture, SU and SP nodes rely on a service co-

ordinator or an SD node to facilitate service discov-

ery. As an ad hoc network is usually composed of het-

erogenous devices, the role of an SD node is usually

taken on by the more powerful devices (the method

used to select an SD node is beyond the scope of this

paper).

Assuming that an SU and an SP node are both

within the scope of an SD node, service discovery

takes place as follows:

1. The SD node periodically announces its presence

by broadcasting a DirAdv message through the net-

work (with an initial hop count of X).

2. An SP node will register its service offerings with

the SD node by sending a unicast SrvReg message

to the SD node.

3. The SD node will acknowledge receipt of an

SrvReg message by sending a SrvAck message

back to the SP node. The SD node also updates

its list (SrvList) of all registered services.

4. An SU node seeking a service will query an SD

node by sending a unicast SrvReq message to the

SD node.

5. Upon receiving a SrvReq message, an SD node

searches its SrvList for the requested service. If

the sought service is found, the SD node sends a

SrvRep message back to the SU node. The SrvRep

message will contain details of the service provider

(e.g. the URL or IP address of the service provider).

SECRYPT 2006 - INTERNATIONAL CONFERENCE ON SECURITY AND CRYPTOGRAPHY

168

6. A registered service may be removed from the

SrvList when it expires or when an SP node sends

a SrvDrg message to the SD node.

In the event that an SD node is more than one ra-

dio hop away from SU and SP nodes, intermediate

nodes will forward the SrvReq, SrvRep, SrvReg, Sr-

vAck and SrvDrg messages to and from the SD nodes,

provided the message does not traverse more than X

hops. It should be noted that the mediated architec-

ture can be further divided into two sub-categories:

transparent and non-transparent. Transparent means

that SU and SP nodes are fully aware of the existence

of one or more SD node(s) in the network, while non-

transparent means SU and SP nodes are not aware that

an SD node is present, thinking they are interacting

directly with each other.

The mediated approach is extremely scalable but

is unsuitable for highly mobile environments, as the

SrvLists have to be constantly updated and modiﬁed.

Another shortcoming of this approach is the service

non-discoverability problem between an SU node that

is interested in the service offering of an SP node. The

two nodes may be in close proximity, but service dis-

covery simply cannot take place. This is because ei-

ther one or both of the nodes are lying outside the

scope (beyond X hops) of the SD node. In such a

case, there is no way for either node to be aware of

the presence of the other, no matter how near they are

to each other.

3.2 Immediate Architecture

The immediate architecture is also referred to as the

Distributed Query-Based Architecture (Toh, 2002). In

this architecture, there are no SD nodes. SU and SP

nodes seek and advertise their own services directly,

without relying on SD nodes.

An SU node seeks a service by broadcasting a

SrvReq message through the network (with an initial

hop count of X ). Upon receiving this SrvReq mes-

sage, a node may:

• send a unicast SrvRep message to the SU node

if it offers the requested service, and forward the

SrvReq message to its neighboring nodes.

• decrement the hop count and rebroadcast the

SrvReq message if it does not offer the speciﬁed

service.

• do nothing and drop the packet if the hop count

reaches zero.

This method of discovery is sometimes known as ac-

tive or pull-based discovery. Alternatively, an SP

node may advertise its service by broadcasting a Sr-

vAdv message through the network (with an initial

hop count of X). Upon receiving a SrvAdv message,

a node may:

• send a SrvAck message to the SP node if it is in-

terested in the service offered, and rebroadcast the

SrvAdv message.

• decrement the hop count and rebroadcast the Sr-

vAdv message.

• do nothing and drop the packet if the hop count

reaches zero.

Nodes receiving a SrvAdv message may cache the

service information for future use and compile a

SrvList of their own. This method of discovery is also

referred to as passive or push-based discovery.

Finally, as shown in Figure 1, active and passive

discovery may also take place concurrently. This ar-

chitecture is suitable for highly mobile networks, but

it does not scale well.

3.3 Hybrid Architecture

The mediated and immediate architectures may co-

exist at the same time to yield the hybrid approach.

The hybrid approach offers several advantages over

a pure mediated or a pure immediate architecture.

Firstly, simulation results in (Guichal and Toh, 2001)

have shown that service availability is signiﬁcantly

better with the hybrid approach. Secondly, the pres-

ence of SD nodes in the network also improves scal-

ability. Finally, the service non-discoverability prob-

lem can also be easily overcome. Service discovery

is now possible between two nodes that are in close

proximity even when one or both of the nodes are

not within the scope of the SD node. Because of

the added ﬂexibility of the immediate approach, either

node is now capable of broadcasting a service request

or service advertisement on their own.

In summary, the hybrid approach is more ﬂexible

and enhances service availability.

4 A SERVICE DISCOVERY

THREAT MODEL

There exist a variety of security issues and threats in

ad hoc networks (Mishra and Nadkarni, 2003; Pa-

padimitratos and Hass, 2003; Zhou, 2003). However,

in our threat model we focus solely on the threats that

arise during service discovery.

4.1 Objective of Service Discovery

Different entities have different aims for, and expecta-

tions of, a service discovery protocol. We brieﬂy dis-

cuss this from the perspectives of the three main types

of entity involved, namely: Service Users, Service

Providers and Directory nodes. From a service user’s

A SERVICE DISCOVERY THREAT MODEL FOR AD HOC NETWORKS

169

perspective, the primary aim is to ﬁnd a provider of

the desired service within its scope. It may also want

to know what other services are available in the net-

work. A service provider’s main aim is to inform all

service users of its service offerings. Finally, a direc-

tory simply wants all users and providers to be aware

of its presence so that it can perform its task.

Therefore, any action that can be performed by an

entity that prevents any of the above can be consid-

ered as a security threat, or a form of attack.

4.2 Threat Targets

Threat targets are the assets of the system. They

are the prime motivation for a potential adversary to

launch an attack. Threat targets can be broadly cate-

gorised into two types: Tangible and Intangible.

If an attack is aimed at a tangible threat target, then

the effects would be more immediately observable.

Examples of tangible threat targets include: the in-

tegrity and availability of the entities, the conﬁdential-

ity, integrity and availability of the service messages

and SrvList, the integrity and legitimacy of the service

discovery process, and the resources or energy of the

nodes.

An attack aimed at intangible threat targets may not

have an immediately observable effect. Examples of

intangible threat targets include: network connectiv-

ity and availability, and the reputations of the entities.

4.3 The Threat Model

In an ad hoc network, where all communications take

place over the wireless medium, any device with an

appropriate network interface is capable of gaining

access to the network and participating in the network

functions it offers. Further, devices or nodes are free

to join or leave the network or even change their lo-

cations at any time. This results in an dynamic net-

work topology. Consequently, the concept of a phys-

ical perimeter does not really apply in an ad hoc net-

work.

Without a clear boundary, it is difﬁcult to make a

distinction between internal and external nodes and

to classify the corresponding threats into internal or

external threats.

In our threat model, we therefore do not attempt to

distinguish between internal and external threats. In-

stead, we focus on the types of threat that could arise

from the various types of node misbehaviour.

A classiﬁcation of service discovery security

threats is shown in Figure 2. The threats are divided

into three main categories, according to the type of

misbehaviour (Yau and Mitchell, 2003) that the nodes

exhibit. They are: Failed nodes, Selﬁsh nodes and

Malicious nodes. Malicious nodes can be further sub-

divided into Active and Passive threats. It is helpful

to examine the threats arising from these three differ-

ent types of misbehaviour, for they have very different

characteristics.

Service

Discovery

Threats

Failed Node

Threats

Selfish Node

Threats

Malicious Node

Threats

Active

Threats

Passive

Threats

Figure 2: Classiﬁcation of Service Discovery Threats.

We now examine the different types of threats in

greater detail and discuss their implications and con-

sequences.

4.3.1 Failed Nodes

Involuntarily, a node may be prevented from partak-

ing in the service discovery process in the normal co-

operative manner that is demanded of all nodes in an

ad hoc network. Such nodes are termed Failed Nodes

and do not harbour any malicious intent. This type of

misbehaviour is usually a consequence of either:

• A node having its resources (power) completely de-

pleted. Such a node may have been the target of

a concerted Denial of Service (DOS) attack by an

adversary. As a result of the attack, the node’s bat-

tery or power might have been completely drained,

rendering it unable to perform any task or network

function. A node’s resources could also have nat-

urally run out without being subjected to any prior

attacks. This type of failure is also known as grace-

ful failure.

• A node may also be deemed a failed node if it is

incapable of communicating with the other nodes

(within its radio range) in the network. This may

be due to a faulty network interface or the result of

an adversary jamming or interfering with the wire-

less channel. Normal operation may resume once

the adversary stops the interference. As such, node

failure could be temporary or permanent.

Even though failed nodes do not misbehave inten-

tionally, the threats they posed to the service discov-

ery process are just as devastating. Threats pose by

failed nodes vary signiﬁcantly, depending on the type

of node that fails. If the failed node is:

• an FW node, it will not be able to forward any ser-

vice messages to and from any service entities (SU,

SP and SD). Service discovery will not be possible

if the particular failed FW node serves as the only

SECRYPT 2006 - INTERNATIONAL CONFERENCE ON SECURITY AND CRYPTOGRAPHY

170

link or path between two service entities. Also,

an FW node may fail while forwarding a service

message. It will thus be unable to complete its ac-

tion and will be deemed a failed node. The conse-

quences of a failed FW node can therefore be rather

signiﬁcant even though it is not a principal partici-

pant in the service discovery process.

• an SU node, it is incapable of sending and receiv-

ing any service messages to or from any other en-

tities. In other words, it is unable to take any part

in the service discovery process. However, service

discovery between other service entities is not af-

fected.

• an SP node, it will no longer be able to service

its existing service users and to solicit new ser-

vice users as it is incapable of sending any service

advertisement or registration messages to service

users or directories. Service discovery between

other service entities remains unaffected.

• an SD node, the entire service discovery system in

the network may be crippled. In a mediated only

architecture, SU and SP nodes rely on SD nodes to

facilitate service discovery. If it is the only SD node

in the network, the effects are dire. Otherwise, ser-

vice discovery may still take place normally in the

absence of an SD node, as seen in the hybrid or

immediate architectures. The effects that a failed

SD node has on the service discovery process de-

pend very much on the service discovery architec-

ture that is employed.

4.3.2 Selﬁsh Nodes

In an ad hoc network, the success of the service dis-

covery process depends greatly on the co-operation

of all the nodes. Unfortunately, with the aim of con-

serving their scarce resources, some nodes may sim-

ply refuse to co-operate even though they are fully

capable of doing so. These nodes co-operate only

when there are incentives for them to do so. Nodes

that exhibit this type of behaviour are known as self-

ish nodes. These nodes are not malicious in nature

even though they misbehave intentionally. If a selﬁsh

node is:

• an FW node, it selectively forwards service mes-

sages. As a result, SU, SP and SD nodes may

not receive the service messages intended for them.

Also, in order to conserve some of its processing

power, a selﬁsh FW node may forward service mes-

sages without decrementing the hop count. Nodes

may receive an out of scope service message and

may have trouble contacting the sending node later

on. Service discovery may be severely disrupted as

a result of either action.

• an SU node, it selectively broadcasts service re-

quests. The service discovery process is not really

affected in any way. It should be noted that it is

highly unlikely that an SU node behaves in a self-

ish manner, as there is very little motivation for the

SU node to do so, and it stands to gain very little.

• an SP node, it does not broadcast its service adver-

tisements as often as it should. SU and SD nodes

will not be aware of the services offered by the SP

node. Again, there is very little incentive for an SP

node to behave in a selﬁsh manner, as it does not

stand to gain anything.

• an SD node, it may not inform the network of its

existence. As such, SU and SP nodes will not be

able to request and register services respectively.

Hence, in a pure mediated architecture, service dis-

covery will simply be impossible. Also (regard-

less of the type of architecture employed), it may

not accept SrvReq messages from SU nodes or

SrvReg/SrvDReg messages from SP nodes. As a

result, when it does decide to be contacted by the

other nodes, it will not be in possession of an up-

dated Srvlist.

4.3.3 Malicious Nodes

Malicious nodes have no intention of participating in

the service discovery process. Their primary aim is

to disrupt the “proper” operation of the service dis-

covery process. A wide range of threats are posed by

the malicious nodes to the service discovery process.

Associated with every threat are one or more threat

targets. Using the STRIDE method (Swiderski and

Snyder, 2004), we can classify malicious node threats

into six categories, namely: Spooﬁng, Tampering, Re-

pudiation, Information disclosure, Denial of service,

and Elevation of privilege. Threats may also be clas-

siﬁed as Active or Passive.

The STRIDE method (Swiderski and Snyder,

2004) is now be used to identify and analyse the ser-

vice discovery threats caused by malicious nodes.

1. Spooﬁng. A malicious node may masquerade as

another entity during service discovery. It may

pose as:

• an FW node. Upon receiving a legitimate ser-

vice message, it may not forward the message

to other nodes. Service discovery cannot take

place if this FW node is the only link between

two nodes. The threat target would be the in-

tended recipients of the service messages.

• an SU node and broadcast a SrvReq message

through the network. An SP or SD node receiv-

ing the message may think that they are interact-

ing with a legitimate SU node. The threat target

here is the SP, SD or even an FW node.

• another legitimate SP node and offer “services”

to an unknowing SU node.

A SERVICE DISCOVERY THREAT MODEL FOR AD HOC NETWORKS

171

• an SD node and announce its presence to the net-

work. This malicious SD node may be nearer

(less hops away) to some of the SU or SP nodes.

They may then choose to interact with this mali-

cious SD node instead of a legitimate one that is

further away.

The threat targets are the entities to whom the ma-

licious node will be masquerading. Spooﬁng is an

active threat.

2. Tampering. A malicious node may capture and

then modify legitimate service messages traversing

the network in one of the following ways:

• Alteration of legitimate service messages by

changing their contents. As a result, the in-

tended recipients of the service messages will

not be presented with accurate service informa-

tion. This greatly compromises the service dis-

covery process. The direct threat targets are the

service messages, while the indirect threat tar-

gets are the intended recipients of the altered

messages.

• Deletion of legitimate service messages. The in-

tended recipients of the service messages will

not be able to receive the messages. Service

discovery will then not take place as it should.

This threat has the same effect as a selﬁsh node

not wanting to forward SrvReq and SrvAdv mes-

sages to other nodes. In this case, the di-

rect threat target is the deleted service message,

while the indirect threat target is the intended re-

cipient of the original service message.

• Insertion of bogus service messages. A ma-

licious node may broadcast fraudulent service

messages (e.g, SrvReq, SrvAdv, or DirAdv) into

the network. Recipients of such fraudulent mas-

sages may think that they are actually interacting

with legitimate SU, SP or SD nodes. This threat

is similar to the spooﬁng threat discussed above.

The threat targets here are the intended recipients

of the fraudulent messages.

It is obvious that tampering is an active threat.

The worse case scenario for a tampering threat is

when an SD node is malicious. It will then be

able to modify — i.e. alter, delete, or insert — ser-

vice information pertaining to legitimate SU and

SP nodes, since it has direct access to the SrvList.

The consequence of an inaccurate SrvList is dev-

astating for the integrity of the entire service dis-

covery process. The threat target here is clearly the

SrvList, and the indirect threat targets are the ser-

vice entities that it will be interacting with.

3. Repudiation. A malicious node may later deny

having performed a certain action. For example,

a malicious SU, SP or SD node may deny having

sent a SrvReq, SrvAdv, or DirAdv message, re-

spectively. Similarly, they may also deny having

receive a speciﬁc service message. The threat tar-

get would be the entity that the malicious node was

interacting with. Repudiation is an active threat.

4. Information Disclosure. Eavesdropping is partic-

ularly simple in a setting such as an ad hoc network,

since the primary mode of communication amongst

the nodes is a wireless channel.

During the service discovery process, a mali-

cious node is capable of eavesdropping on the ser-

vice messages that are exchanged between the ser-

vice entities, or broadcast through the network by

SU or SP nodes. An inventory of services requested

and advertised can thus easily be compiled, and this

constitutes an enumeration attack. From the gath-

ered information, a malicious node may learn the

following: the type of services being requested by

SU nodes, the type of services offered by SP nodes,

which and where the SD nodes are, and the net-

work topology. Such information can be extremely

useful for the malicious node and may be used sub-

sequently: to infer or predict future service discov-

ery patterns, or as intelligence for launching sub-

sequent attacks (e.g. replaying certain messages).

The disclosure of service information may be con-

sidered a breach of the individual entities’ privacy.

The direct threat targets are therefore the ser-

vice messages, and the indirect threat targets in-

clude the privacy or even availability of the SU,

SP and SD nodes. An information disclosure threat

does not disrupt the service discovery process in

any noticeable way. Very often, the legitimate ser-

vice entities may not even be aware that such an at-

tack is taking place. That is why this type of threat

is also commonly known as a passive threat.

5. Denial of Service (DOS). This occurs when a le-

gitimate service entity is prevented from participat-

ing in the normal service discovery process because

of the actions of a malicious node. For instance,

a malicious node may mount a DOS attack on an

SP node by ﬂooding the node with SrvReq mes-

sages. The SP node may be overwhelmed by these

messages and hence be unable to accept legitimate

SrvReq messages from other nodes. A competitor

SP node may have strong motivation to launch such

an attack. An SU node may also be the target of a

DOS attack, even though the effects it has on the

service discovery process are not as signiﬁcant.

A DOS attack could also be launched by ﬂood-

ing an SD node with illegitimate SrvReg and

SrvReq messages. The effects of this attack could

be deadly, as the entire service discovery process of

the network could be crippled.

Nodes may fail as a consequence of a DOS at-

tack. The direct threat target would be the avail-

SECRYPT 2006 - INTERNATIONAL CONFERENCE ON SECURITY AND CRYPTOGRAPHY

172

ability of the service entities that were subjected to

the DOS attacks, while the indirect threat targets

would be their respective reputations. DOS is an

active threat.

6. Elevation of Privileges. This happens when a ma-

licious node, by some illegitimate means, is able

to gain more privileges than it currently has (Goll-

mann, 2005). This threat normally takes place in

conjunction with the spooﬁng threat. When a mali-

cious node is able to masquerade as another entity

(e.g. an SU, SP, SD or FW node), it assumes the

privileges and capabilities of that entity.

It should be noted that the aforementioned threats

rarely occur in isolation. More often than not, one

threat may lead to another, as they are inter-related.

5 SECURITY REQUIREMENTS

If the threats are not properly mitigated, they could

be exploited by malicious nodes to launch a variety

of attacks. Countermeasures are therefore essential to

prevent the threats from being realised. The security

services required to mitigate the threats are identiﬁed

and presented below.

Authentication. One of the most important require-

ments is the mutual authentication of SU and SP

nodes (in the immediate architecture) or SD and

SU/SP nodes (in the mediated architecture). Mutual

authentication will provide two interacting service en-

tities with the assurance that they are indeed inter-

acting with the intended parties. A rogue node may

fraudulently request for/advertise a service. It may be

difﬁcult or impossible to prevent a rogue node from so

doing, especially in immediate architectures, but an

SU or SP node may decide not to use/provide the ser-

vice if the authentication outcome is unsatisfactory.

Unilateral authentication will not sufﬁce in this sort

of peer to peer environment, as it is equally likely for

either an SU or SP node to be malicious. This secu-

rity service aims to address the threats of spooﬁng and

elevation of privileges.

Authorisation. An SU node may discover a number

of available services in the network, but may only be

allowed to use some of them, depending on the secu-

rity policy speciﬁed by the SP nodes. Alternatively, a

service may not even be discoverable by an SU node

if it is unauthorised to use it. In other words, SU nodes

may only have a controlled visibility of the available

services, based on their credentials or some security

policy. Similarly, only authorised SP nodes may be

allowed to advertise their service offerings. Options

for achieving authorisation include the use of capabil-

ities, access control list and credentials. This security

service does not directly mitigate any of the afore-

mentioned threats. Nonetheless, it is important in the

context of service discovery.

Conﬁdentiality. A variety of service messages tra-

verse the network during service discovery. A mali-

cious node can easily intercept or eavesdrop on these

messages and obtain the following information: the

identities of the senders and intended recipients, the

speciﬁc services that are being requested or advertised

by an SU or SP node, the physical location of the ser-

vice entities, etc. An SU (or even an SP) node may

not want such information to be disclosed to other en-

tities (malicious or not), apart from a legitimate SD

node. It is therefore necessary to encrypt such mes-

sages to prevent the threat of information disclosure

and to protect the privacy of service entities.

Integrity. Service messages, exchanged during ser-

vice discovery, should not be modiﬁed (i.e. altered,

deleted, inserted, or replayed). A secure service dis-

covery protocol should provide this assurance to all

service entities participating in the service discovery

process. This security service addresses the tamper-

ing threat.

Non-repudiation. Mechanisms (e.g. digital signa-

tures) should be in place to prevent any service en-

tity from later denying that a certain action has taken

place. For example, service entities should not be able

to later deny that a particular service message was

sent or received, if that action had indeed taken place.

This security service addresses the threat of repudia-

tion.

Accountability. A log that records all the events

should be available. In the event of any dispute, a neu-

tral adjudicator is able to refer to the log and make an

impartial and accurate judgement. This requirement

is closely related to the non-repudiation service, in the

sense that it may be used to deter potential repudiation

threats.

Availability. Malicious nodes should be prevented

from ﬂooding (e.g. using broadcast) the network with

bogus service messages. A high volume of such mes-

sages could create a broadcast storm (Tseng et al.,

2002) in the network. The resources of legitimate

nodes may be depleted in an attempt to process such

messages. The entire service discovery process could

be crippled as a result. Instead of targeting the net-

work, malicious nodes may also target individual

nodes and ﬂood them with messages. Appropriate

measures are therefore required to thwart the denial

of service threat.

Privacy. This requirement is closely related to the

conﬁdentiality service. Privacy may mean different

things in different contexts; in the context of service

discovery for ad hoc networks, protecting the privacy

of the service entities means the following. Firstly,

A SERVICE DISCOVERY THREAT MODEL FOR AD HOC NETWORKS

173

service information should not be divulged to exter-

nal service entities that are not directly participating

in the service discovery process. Secondly, the iden-

tities of service entities should not be disclosed un-

necessarily without the owner’s permission. Thirdly,

the physical location information of the service enti-

ties should not be revealed. Finally, colluding SP or

SD nodes should not be able to correlate a particular

SU node’s actions. Like the conﬁdentiality service,

this service mitigates the effects of the information

disclosure threat.

6 CONCLUSION

In this paper, we have presented a threat model in the

context of which potential service discovery threats

were identiﬁed and analysed according to the differ-

ent types of node misbehaviour. We proceeded to de-

rive the security services that are required to mitigate

the identiﬁed threats. This work will provide a basis

for the design of secure service discovery schemes.

We believe that the two most important security re-

quirements that need to be addressed are mutual au-

thentication followed by authorisation. Existing solu-

tions for mutual authentication are not well suited for

an environment such as an ad hoc network, as there

is no central authority. Supporting mutual authenti-

cation between two interacting service entities is very

challenging in such circumstances. The need to au-

thenticate a speciﬁc identity may not be necessary if

one entity is able to prove to the other that it is a trust-

worthy service provider or user.

Similarly, achieving authorisation in this sort of dy-

namic and peer to peer environment is particularly

challenging for several reasons. Firstly, a central ad-

ministrator does not exist to pre-specify a security

policy. Secondly, service entities may belong to dif-

ferent administrative domains. Finally, authorisation

can only take place after two service entities are mutu-

ally authenticated, which is still an unsolved problem.

Fortunately, research on these authorisation problems

has been conducted under the auspices of Trust Nego-

tiation.

The dynamism of ad hoc networks has introduce

many new and interesting security problems that call

for new solutions.

REFERENCES

Gao, Z., Wang, L., Yang, M., and Yang, X. (2006).

CNPGSDP: An efﬁcient group-based service discov-

ery protocol for MANETs. Computer Networks. (In

Press).

Garcia-Macias, J. A. and Torres, D. A. (2005). Service dis-

covery in mobile ad hoc networks: Better at the net-

work layer? In Proc of 34th International Conference

on Parallel Processing (ICPP 2005), pages 452–457.

IEEE ComSoc.

Gollmann, D. (2005). Computer Security. John Wiley &

Sons, West Sussex, England, 2nd edition.

Guichal, G. and Toh, C. K. (2001). An evaluation of central-

ized and distributed service location protocols for per-

vasive wireless networks. In Proc of 12th IEEE Inter-

national Symposium on Personal, Indoor and Mobile

Radio Communications (PIMRC 2001), pages 55–61.

Lim, B.-I., Choi, K.-H., and Shin, D.-R. (2005). An ar-

chitecture for lightweight service discovery protocol

in Manet. In Proc of 5th International Computa-

tional Science Conference (ICCS 2005), pages 963–

966. Springer-Verlag LNCS 3526, Berlin.

Mishra, A. and Nadkarni, K. M. (2003). Security in Wire-

less Ad Hoc Networks. In Ilyas, M., editor, The Hand-

book of Ad Hoc Wireless Networks, chapter 30, pages

30.1–30.51. CRC Press, Boca Raton, FL, USA.

Mohan, U., Almeroth, K. C., and Belding-Royer, E. M.

(2004). Scalable service discovery in mobile ad hoc

networks. In Proc of 3rd IFIP Networking Confer-

ence, pages 137–149. Springer-Verlag LNCS 3042,

Berlin.

O’Sullivan, J., Edmond, D., and Hofstede, A. (2002).

What’s in a service? Towards accurate description

of non-functional service properties. Distributed and

Parallel Databases Journal, 12(2/3):117–133.

Papadimitratos, P. and Hass, Z. J. (2003). Securing mobile

ad hoc networks. In Ilyas, M., editor, The Handbook

of Ad Hoc Wireless Networks, chapter 31, pages 31.1–

31.17. CRC Press, Boca Raton, FL, USA.

Rao, R. (2004). Integration of on-demand service and route

discovery in mobile ad hoc networks. Master’s the-

sis, Dept of Computer Science, North Carolina State

University.

Swiderski, F. and Snyder, W. (2004). Threat Modeling. Mi-

crosoft Press, Redmond, Washington.

Toh, C. (2002). Ad Hoc Mobile Wireless Networks: Proto-

cols and Systems. Prentice Hall, Upper Saddle River,

NJ, USA.

Tseng, Y.-C., Ni, S.-Y., Chen, Y.-S., and Sheu, J.-P. (2002).

The broadcast storm problem in a Mobile Ad Hoc Net-

work. Wireless Networks, 8(2-3):153–167.

Tyan, J. and Mahmoud, Q. H. (2005). A comprehensive ser-

vice discovery solution for Mobile Ad Hoc Networks.

Mobile Networks and Applications, 10(4):423–434.

Yau, P. W. and Mitchell, C. J. (2003). Security vulnerabili-

ties in ad hoc networks. In Proc of the 7th Int Sympo-

sium on Comms Theory and Applications (ISCTA’03),

pages 99–104. HW Communications Ltd.

Zhou, D. (2003). Security issues in ad hoc networks. In

Ilyas, M., editor, The Handbook of Ad Hoc Wireless

Networks, chapter 32, pages 32.1–32.14. CRC Press,

Boca Raton, FL, USA.

SECRYPT 2006 - INTERNATIONAL CONFERENCE ON SECURITY AND CRYPTOGRAPHY

174
