INTERNET ROUTING SECURITY: AN APPROACH TO DETECT

AND TO REACT TO INCORRECT ADVERTISEMENTS

Ines Feki, Xiaoli Zheng, Mohammed Achemlal

France Telecom R&D, 42 rue des coutures, Caen, France

Ahmed Serhrouchni

Telecom Paris, 46 rue Barrault 75013 Paris, France

Keywords: Internet routing, Security, BGP.

Abstract: Internet is composed of thousands of autonomous systems (AS). The Border Gateway Protocol (BGP) is the

exterior routing protocol used to exchange network reachability information between border routers of each

AS. The correctness of the exchanged information in BGP messages is crucial to the Internet routing

system. Unfortunately, BGP is vulnerable to different attacks that have considerable impacts on routing

system. Network prefix hijacking, where an AS illegitimately originates a prefix is one of the most

important attacks. It allows the attacker to receive traffic in destination to the prefix owner. The attacker is

then able to blackhole the traffic or to force it to take another path. Proposed solutions rely on public key

infrastructures and cryptographic mechanisms to prevent incorrect routing information propagation. In

practice these approaches involve many parties (Internet Service Providers, Operators, Vendors, and

Regional Internet Registries) and are difficult to deploy. In this paper we formally define routing

information correctness, especially the legitimacy of an AS to originate a prefix. We also propose a method

to associate with an AS a legitimacy level to originate a prefix. We use Regional Internet Registry databases

to initialize the legitimacy level. We also use received announcements and public routing data to update this

legitimacy level. We finally describe all conceivable reactions facing origin AS changes.

1 INTRODUCTION

Internet is composed of a set of interconnected

autonomous systems (AS). Each autonomous system

is a collection of IP networks administrated by a

single authority. An ISP may have several

autonomous systems. An interior gateway protocol

is used to route IP packets locally and to apply one

local routing policy. When exterior network prefixes

should be reached, border routers use routing

information received from a neighboring AS's

border router. The Border Gateway Protocol (BGP)

(Rekhter, Y, 2006) is used to exchange this dynamic

reachability information between ASes's border

routers which will be used to forward IP packets.

When a BGP session is initiated between two

neighboring routers, they exchange the content of

their routing table. Then, when events happen

leading to a change in reachability information

(session shutdown, restart, routing policy change,

etc...) BGP Updates are sent between routers to keep

each neighbor informed about the new reachability

information. BGP is a path vector routing protocol;

updates contain a path composed of a sequence or a

set of ASes. This AS path should be used to reach

the announced network prefixes. A BGP router does

not have a global view of the topology; it only

knows the neighbor capable of reaching a

destination. When the reachability changes it just

sends updates to its neighbors which forward them

to their neighbors and so on.

BGP allows the application of policies used for

different reasons (traffic engineering, load

balancing, etc...). Business relationships play an

important role in defining these policies. It is

possible, for example, for an organization to deny its

traffic to traverse a competitor and to prefer another

path, even longer. The agreements between ASes

dictate routing policies. Moreover, providers often

compete with one another for customers but must

110

Feki I., Zheng X., Achemlal M. and Serhrouchni A. (2006).

INTERNET ROUTING SECURITY: AN APPROACH TO DETECT AND TO REACT TO INCORRECT ADVERTISEMENTS.

In Proceedings of the International Conference on Security and Cryptography, pages 110-117

DOI: 10.5220/0002104201100117

 SciTePress

nonetheless cooperate to offer global connectivity to

hundreds of millions of hosts. Routing policies are

used to select which routes are advertised to which

neighbors and which paths are used to send packets

to any given destination.

The way routing information is exchanged and the

content of routing information are crucial for

Internet connectivity, reliability, and robustness. If

this network prefix reachability information is

incorrect, traffic may not reach its destination,

networks may be isolated, and traffic may be

subverted to unintended networks. There are many

reasons why this information may be incorrect. First,

BGP has vulnerabilities; its messages are subject to

modification, deletion, forgery, and replay. At the

beginning of Internet, there were few interconnected

ASes and there was an implicit trust relationship,

nowadays their number is increasing considerably

(approximately 30 per week (Huston, 2006)). Even

if the peering agreements between two ASes helps to

build a trust relationship, the hop by hop routing

paradigm and the ability of each hop to modify BGP

messages decreases the trust relationship.

Information traverses unknown ASes and is subject

to modification or deletion maliciously or due to

misconfigurations.

The remainder of this paper is structured as follows.

Section 2 reviews the related work. Section 3

formally defines identified requirements. In section

4 we introduce the background materials and we

describe the methodology that we used to identify

incorrect announcements, we discuss this proposal.

We conclude in section 5.

2 RELATED WORK

Several efforts have been made to solve internet

routing security problems. They vary from the

utilization of cryptographic methods, the utilization

of the forwarding plane to validate announcements,

to anomaly detection based on routes monitoring.

Different solutions are based on cryptographic

methods aiming to avoid and to prevent incorrect

information propagation. One of these approaches is

Secure BGP (Kent, 2000). Its goal is to assure the

integrity of BGP messages, the authorization of a

router to originate and to announce a route. IPSec is

used to provide messages integrity and peer

authentication. A public key infrastructure is used to

support the authentication of the ownership of

address blocks and autonomous system identities,

the given BGP router's identity and its right to

represent the AS it claims. Certificates are issued as

address blocks and autonomous systems numbers

are allocated by Regional Internet Registries (RIR).

Another public key infrastructure is used to express

the authorization of a router to send an

announcement to another router. The main

disadvantage of SBGP is to add complexity and

increase the convergence time. In addition, the strict

hierarchal public key infrastructures (PKIs) make it

difficult to deploy over Internet (Atkinson, 2004).

Zhao et al (Zhao, 2004)(Zhao, 2005) addressed these

drawbacks and proposed some enhancements. They

used different cryptographic methods in order to

make it less complex and to minimize the added

convergence time. In addition, SBGP does not

address issues such as detecting policy violations or

incorrect propagation of route announcements or

withdrawals. Secure Origin BGP (White, 2003) is a

second solution using cryptographic methods. It uses

a PKI to authenticate the AS; RIRs are not involved

as Certificate Authorities (CA) for their

authentication. ASes issue certificates to authorize

other ASes to announce their prefixes. So, SoBGP is

based on the idea that ASes publish their policies

which may be considered as a drawback since some

ASes consider them confidential. Pretty Secure BGP

(Wan, 2005) uses both centralized and distributed

trust models used in SBGP and SoBGP. The first

model is used for AS number authentication and the

latter is used for IP prefix ownership and origination

verification. The three solutions described above

were presented in IETF Routing Protocols Security

Working Group but there was no consensus on those

solutions (RPSEC). A new IETF working group that

will focus on Interdomain routing security (SIDR) is

currently under proposal.

Besides cryptographic solutions, other works

focused on the MOAS conflicts. Wu et al worked on

BGP anomalies and MOAS visualization tools

(Teoh, 2003)(Teoh, 2004). Anomaly visualization is

not efficient enough againt anomalies, it would be

more efficient to have a mechanism that detects and

reacts to anomalies as the routing system is running

or even a mechanism that prevent those attacks.

Zhao et al proposed to create a list of multiple ASes

who are entitled to originate a prefix and attach it to

BGP community attribute in announcements (Zhao,

2002). In order to validate received paths, Kim et al

proposed to use forwarding plane information and

used ICMP traceback messages (Kim, 2005). The

disadvantage of this approach is related to ICMP

filtering practices currently used. Moreover there

can be legitimate differences between BGP AS paths

and paths derived from forwarding plane (Huyn,

2003).

INTERNET ROUTING SECURITY: AN APPROACH TO DETECT AND TO REACT TO INCORRECT

ADVERTISEMENTS

111

Another solution that validates announcements is

Interdomain Route Validation (IRV) (Goodell,

2003). It introduces a new protocol and a framework

to validate routing information announced between

ASes. IRV allows ASes to acquire and validate static

(policies) and dynamic (advertisements) interdomain

routing. The approach is based on an interdomain

routing validator which resides in each participant

AS. This validator receives requests from the other

elements placed in the other ASes. These latter

elements send a request in order to validate the

routes they have just received or consider them as

malicious or abnormal. The reasons that trigger the

requests are not mentioned. It is left to the AS to

choose its algorithm. This can be considered as an

advantage and a drawback also since it gives

flexibility to the AS but if the validation process is

not frequent benefits will be reduced.

3 REQUIREMENTS DEFINITION

In this paragraph, we address all the requirements

for a resilient and robust interdomain routing

system. Internet resources can be seen in global

routing system only if they have been delegated by

IANA to RIRs then allocated to ISPs by RIRs and

assigned to end users. So, one of the global

requirements is that private and non delegated

resources should not be present in global routing. It

is possible to ensure this if all ASes filter received

and sent announcements using prefix lists that filters

private and unallocated prefixes, and filter lists that

filter AS numbers. The challenge consists in

updating filters as ASNs and prefixes are allocated.

This type of information is distributed via emails

and there is no automatic and "on line" way that

permit all ISPs to update their filters.

If we take a look at the requirements of an AS, the

basic need is to be sure that its inbound and

outbound connectivity is assured. That means that a

stub AS needs to be sure that its prefixes are

announced correctly by their providers and that they

will let it reach all networks sought. Furthermore, if

this AS is multihomed and uses BGP to apply some

traffic engineering rules and policies, it needs to be

sure that its policies are applied. In the same way, a

transit AS needs to be sure that not only its prefixes

but also those of its customers are correctly

announced and that the traffic in their destination

won't be subverted, redirected or blackholed. They

also need to be sure that their sent traffic reaches its

intended destination. So, if an AS needs to verify all

these requirements before accepting any

announcement, its border routers need to check its

content and verify:

- Internet resources validity (public and allocated

ASN and prefixes)

- Origin AS legitimacy to originate the prefix

- Policy conformance of the path

We address every requirement and some operational

requirements below. First, let us define all the

elements involved in the routing system. Paths and

routes are defined in a graph where nodes

correspond to ASes and links correspond to their

interconnections. Nodes are directly connected and

exchange reachability information using BGP. A

path is a sequence or a set of interconnected nodes.

A route is a unit of information that pairs a set of

destinations with attributes (local preference, path

length, etc...) of a path to those destinations. It is

used by ASes on the graph to select paths to

destinations. The destination refers to a single node

or a group of nodes identified by an IP prefix.

Let AASN the allocated set of AS numbers. Let O

be the set of all organizations that use BGP. Let RIR

be the set of Regional Internet Registries. For each

organization C ∈ O let ASN(C) be the set of ASN

that have been assigned to it from IANA or any

registry. Note that ∀C ∈ O, ASN(C) ∈ AASN.

IANA delegates IP prefixes to RIRs. We note this

relation

RIANA

⎯→⎯ where R∈ RIR. At the

beginning of the Internet deployment, a classful

address architecture was used. The address

architecture has evolved and changes to a classless

architecture. During the first period resources were

allocated using classes and were provided to

organizations with minimum requirements. Some

organizations have maintained these allocations. Let

OIP(IANA) be the set of these early allocations.

RIRs allocate prefixes to Internet Service Providers

(ISP) or Local Internet Registries (LIR). We note

this relation:

⎯→⎯ .

The latter sub-allocates them to other ISPs or assigns

them to end users. We note this relation:

'/ CC

⎯→⎯ . Let IP(IANA) be the set of IP

addresses that IANA already delegated to RIRs or

assigned to ISPs. Let IP(R) be the set of IP addresses

that a Registry R ∈ RIR allocated. Note that IP(R) ⊂

IP(IANA). Let us note the providers of an

organization C as Providers(C). RIRs allocate also

IP prefixes to exchange points. Let IP(IX) be the set

of prefixes allocated to an exchange point IX. Let

ASN(IX) be the set of ASes that participate in this

exchange points.

SECRYPT 2006 - INTERNATIONAL CONFERENCE ON SECURITY AND CRYPTOGRAPHY

112

3.1 Resources Validity

A prefix or an ASN is considered valid if it has been

delegated by IANA to a RIR and allocated by the

RIR to an organization. This defines the following

rule:

P is valid if

∪

RIRR

RIPP

∈

∈ )(

ASN is valid if ASN ∈ AASN.

3.2 Origin AS Legitimacy

Origin legitimacy is the ability of an AS to originate

a prefix. This ability is deduced from prefix

delegation and allocation hierarchy, and ASes

relationships. RIRs allocate prefixes to organizations

and AS numbers independently. Any AS number

that an organization handles can be a legitimate

origin AS of the prefixes that have been allocated to

the organization. An AS originates legitimately a

prefix if:

- IANA has directly allocated the prefix to the AS

(early allocations)

- The prefix was delegated to a RIR. The RIR

allocated it to the AS. The prefix may be

assigned to this AS or sub allocated to another

organization.

- The prefix is allocated by a provider to a

multihomed AS that announces it to all its

providers.

- The prefix is allocated to an exchange point and

the AS is one of the autonomous systems in this

exchange point.

Formally this legitimacy may be defined as follows:

∀ASN ∈ AASN ∀C, C' ∈ O ; ASN∈ ASN(C)

ASN originates legitimately P if:

- P∈ OIP(IANA) and

CIANA

⎯→⎯ (early

allocations)

- or P

∈

IP(R) and CR

⎯→⎯

- or P

∈

IP(R) and 'CR

⎯→⎯ and

⎯→⎯/'

- or P ∈ IP(R) and

'CR

⎯→⎯ , and C ∈

Providers(C).

- or P ∈ IP(IX) and ASN ∈ ASN(IX)

3.3 Path Validity and Policy

Conformance

Path validity may be defined by its existence

physically and logically. A path exists physically if a

BGP session exists between routers of ASes in the

path. It exists logically if routing policies of each AS

in the path authorizes its creation and advertisement.

Let import(AS) and export(AS) be AS's import and

export policies where AS ∈ AASN. Here are

examples of policies:

- import: from AS2 action pref = 1; accept

{128.9.0.0/16} : this example states that the prefix

129.9.0.0/16 is accepted from AS2 with preference

- export: to AS2 announce AS4 : in this example,

AS4's routes are announced to AS2

Policy conformance: A path containing a

sequence of ASn ASn-1 ….. AS2 AS1 to a

destination d is valid and policy conformant if:

export(AS1) contains announce d to AS2 or any

and import (AS2) contains accept d from AS1

and export(AS2) contains announce d to AS3

……..

and import(ASn-1) contains accept d from ASn-2

export(ASn-1) contains announce d to ASn or any

import(ASn) contains accept d from ASn-1

3.4 Operational Requirements

One of the operational requirements is a low cost of

the solution to be deployed. When deploying a

secure routing protocol using cryptographic features

to attest address ownership, expenses of issuing

credentials is an ISP and RIR responsibility. It is a

costly solution since it requires RIRs and ISPs

involvement while their benefits from this

investment are limited. A second requirement is

related to BGP convergence time which should not

be heavily increased. Finally, the solution that will

be adopted should be incrementally deployable.

4 BACKGROUND,

METHODOLOGY AND

DISCUSSION

It is likely to be some time before a cryptographic

mechanism for routing information authentication is

deployed and have a significant security benefit. Our

viewpoint is that in the meantime we need an

intermediate solution that detects incorrect routing

information. Routing system needs an "online" -

runs while the routing is running- verification

system which instantaneously distinguishes between

suspicious and legitimate routes.

We describe in this paragraph a system able to detect

and to react to anomalous announcements. It is

based on available information retrieved from

INTERNET ROUTING SECURITY: AN APPROACH TO DETECT AND TO REACT TO INCORRECT

ADVERTISEMENTS

113

Internet Routing Registry databases, received routes,

and archived public routing data. The first goal is to

facilitate the decision process when a change of a

prefix's origin AS is received. We present in this

paragraph the sources of data that we use and the

methodology we followed.

4.1 Internet Routing Registry

Database

The Internet Routing Registry (IRR) represents a

framework for ASes cooperation. The IRR is a

distributed set of routing databases that are

individually operated by organizations such as

Verio, Merit and by RIRs like APNIC, ARIN, and

RIPE. RIRs databases contain data related to IP

prefix and ASN allocation. Some ASes publish their

routing policies and the policies of their customers.

Routing Policy Specification Language (RPSL)

(Alaettinoglu, 1999) is used to specify ASes policies

that are stored in these object oriented databases.

RPSL can also be used to produce router

configuration files (IRR).Unfortunately, all the ASes

are not members of this IRR community and do not

not be available. Siganos et al (Siganos, 2004)

designed a tool that analyzes IRR databases. This

tool tests policies consistency and compares the

registered data to real routing data. The analysis

showed that RIPE database is the most consistent

database and that RIRs databases generally provide

useful information. RIPE has also a project aiming at

checking their database consistency (RIPE RRCC).

RPSL is object oriented; different classes are defined

in this language. The route class is one of the

classes used in RPSL to define policies and

administrative objects. This class is used to register

prefixes and their origin AS.

4.2 Public Routing Data

Routeviews (Routeviews) and RIPE RIS (RIPE RIS)

are two major measurement projects that deploy

route collectors and provide publicly available BGP

data. A route collector is a measurement box that

peers with commercial ISP networks via BGP

sessions. It receives BGP messages from its peers,

but it does not advertise any prefixes back to them.

Periodically, the collector dumps its full routing

tables and routing updates received from its peers.

4.3 Methodology

The aim of our system is to enable origin ASes

changes detection and to decide which action to

carry out after this detection among predefined

actions. The idea is to associate with an AS a

legitimacy level to originate a prefix P based on

regional internet registries databases, received

announcements and an analysis of public routing

announcements.

4.3.1 System Architecture

The conceptual model architecture of our system is

composed of the following components:

- Origination legitimacy database: we store in this

database a legitimacy level to originate a prefix

associated with an ASN.

- Data collection module: this module collects data

from RIR databases. This data is used to initialize

the values of the legitimacy level of an AS to

originate a prefix. This legitimacy level is updated

as received announcements are processed. This

module collects also announcements from public

routing data.

- Data processing module: collected data from the

previous module is processed in this module. One

of the functions of this module is to detect origin

AS changes. A second function is to process

received announcements and public routing data

to infer legitimacy level from received

announcements.

- Decision module: This module is able to decide

which action to carry out from the predefined set

of possibilities. When an origin AS is detected the

received announcement may be filtered,

dampened. The router may also de-aggregate its

prefixes if it detects that its prefixes were

originated by another AS.

Figure 1 : System architecture.

SECRYPT 2006 - INTERNATIONAL CONFERENCE ON SECURITY AND CRYPTOGRAPHY

114

4.3.2 Components Functions

Data collection: This module collects the required

data from RIR databases. Registry databases do not

contain all the required data and legitimacy cannot

be validated to every tuple (prefix, AS). We applied

our model to validate the tuples (prefix, origin AS)

of the routing information in a routing table of one

router of a provider. 20% of the prefixes present in

its routing table were allocated to RIPE. In the RIPE

database, available tuples represents 96% of these

prefixes. This module collects also public routing

data and received routing data in the AS in order to

infer a legitimacy level to missed data. Since, there

is no explicit data about multihomed ASes and their

providers. This means that we cannot collect this

information and have the set of providers of an AS.

We assume that an AS is a potential originator of a

prefix if it is one of the ASes to which the owner AS

exports this prefix and if it imports this prefix from

the owner AS. This module collects also export and

import policies of ASes and the correspondent

prefixes.

Data processing: Collected data from registry

databases is processed in this module in order to

infer the legitimacy level of an AS to originate a

prefix. This level is a real number between 0 and 1.

It is considered as the probability of announcement

correctness. The highest level is associated with

route records (origin, prefix) that are registered in

RIR databases. A threshold is associated with tuples

(AS, prefix) if the AS is a potential originator as the

definition we have defined above. If a part of these

conditions is satisfied then the legitimacy value

associated with the tuple is the half of the threshold.

If the conditions are not satisfied then the value is

null. If we consider the hypothesis that RIR

databases are not complete and not updated

frequently, this value changes in time. This change

depends on the received advertisements and the

public routing data. These data are also used in a

heuristic way to infer legitimacy level of a tuple

when there is no information about the export

policies of the owner AS of this prefix.

Collected export and import policies are stored in a

database where the relation between prefixes, their

origin ASes, ASes to which they are exported and

ASes from which they are imported is more explicit.

This data is then used to associate the legitimacy

level with tuples. If the origin AS of a prefix exports

the prefix to an AS (or a set of ASes) and

symmetrically the AS (set of ASes) imports the

prefix then the threshold of legitimacy is associated

with the tuple (AS, prefix). If the AS does not

import the prefix then the half of the threshold value

is associated. Finally, ASes that are not in the export

list of the origin AS are considered illegitimate, and

the value associated is null. This value changes in

time according to the received advertisements and

the public routing data.

Public routing data is used to observe multiple origin

announcements for prefixes for an observation

period. A report is carried out containing prefixes

originated by multiple ASes and their origin ASes.

We focus on origin ASes that do not satisfy the

conditions above (ASes that are not registered in

RIR databases as origin of the prefixes and ASes

that are not potential originators of the prefixes). We

observe the time period where the prefix is

originated by those ASes. A threshold is set to the

period. If this period is shorter than the threshold the

advertisement is considered as a misconfiguration or

a hijacking. The AS is considered suspicious. The

threshold is an important parameter in our system. It

should be well tuned in order to let the heuristic be

efficient and to avoid false positives.

We used RIS collected data for the month of

October 2005, we observed daily MOAS reports.

We focused on prefixes that are present more than

25 days in these reports. 65 % of these prefixes do

not have a registered origin AS, although 70% of

these prefixes are delegated to RIPE and this

database is considered the most complete one. The

remainders 35% have a registered origin AS, but all

the origin ASes observed are not mentioned in the

export policy of the registered origin ASes. So,

according to our model all these announcements are

considered suspicious. But the number of times

these ASes originate these prefixes is considered

high and the period is long, so the legitimacy may be

estimated once again. At this step, we need a neural

network which considers all the new announcements

and evaluates the legitimacy level as announcements

are monitored. The consideration of some other

RPSL attributes like the description of network

(inetnum, maintainer, email addresses)(IRR) may be

used as a heuristic to readjust the model we

specified. In this module, public routing data is also

used to help a provider detecting if another AS is

originating its prefixes or the prefixes of its

customers.

Received announcements are monitored in order to

avoid incorrect ones. They are stored and analyzed

to infer the legitimacy level of tuples (AS, prefix). A

route will not be selected before the ending of the

data processing and decision process execution.

When a new advertisement is received, the origin

AS is compared to the one in the routing table. If an

INTERNET ROUTING SECURITY: AN APPROACH TO DETECT AND TO REACT TO INCORRECT

ADVERTISEMENTS

115

origin AS change is detected then the legitimacy

database is checked. The action which will be

performed by the decision process depends on this

value. The decision process is explained in the next

paragraph. All the parameters of the announcement

are stored in order to infer the legitimacy level of the

correspondent tuple. The model used in the analysis

is similar to the one used in the analysis of public

routing data. It is based on the number of times the

tuple is received. The difference resides in the ability

of the AS that monitors the routes that its routers

receive to use other parameters. The parameters are

the trust level it associates with its peers that send

the announcement containing the tuple and its routes

preference generally based on business relationships.

Moreover, when an origin AS change is detected for

the first time, another parameter can also be

considered. If we assume that the incorrect route was

sent for the first time due to a misconfiguration or a

short lived hijacking attack, then the route may be

ignored for a brief period of time. During this period

of time, the router waits for another announcement

with the same attributes that withdraws the previous

or for a different route. This period should be well

tuned in order to let the router enough time to

receive the second announcement. In summary, the

legitimacy level inferred depends on the number of

times the tuple is received, the peer that sends the

tuple, and the announcements that follows.

Decision Module: There are different actions that

can be performed when an origin AS change is

detected in received announcements and public

routing data. The action depends on the source of the

data. First, when an origin AS change is detected in

received announcements, the legitimacy database is

checked in order to find a value for the received

tuple (Prefix, Origin AS). If the value is higher than

the threshold then the announcement may be

selected. Note that this verification should be

applied before the execution of the BGP best route

selection process. We mean that the preference for

non suspicious routes should be the first step in the

route selection process before the local preference

and the AS path length. However, this may

introduce an economic trade off for the AS.

Generally the preference of a route is business

relationship-driven. Customers' routes are preferred

to provider routes. The AS gains revenue by

directing as much traffic as possible through

downstream customers. The reception of non

suspicious routes from the provider would constrain

the AS to choose a route that goes against its

business model.

In the other case, if the legitimacy value is lower

than the threshold, then the announcement is

discarded. If the received prefix is less specific than

the one in the routing table and was aggregated then

this aggregation is considered in the legitimacy level

evaluation. If the legitimacy level of the received

tuple has not been yet evaluated, due to a lack of

information in RIR databases or because the

announcement was sent for the first time, then the

announcement will not be discarded but the selection

will be delayed. The decision process will wait for

more information to evaluate the legitimacy level.

Next, when the analysis of public routing data

reveals to the AS that one of its prefixes or its

customers' prefixes is originated by an unauthorized

AS, then the AS may de-aggregate the affected

prefix. This will guarantee that no traffic will be lost.

Then, the AS may use filters based on prefixes to

block the announcement. When the unauthorized

announcements disappear the AS disable those

filters. The length of the prefix, that was announced

by an unauthorized AS, may raise a problem. In fact,

if the prefix is a /16 then, announcing /17 may solve

the problem. But if the prefix is a /24, announcing

/25 will not solve the problem since most of the

ASes filter prefixes more specific than /24.

4.4 Discussion and Future Work

We defined in this paper a system able to detect

incorrect Internet routing announcements. This

approach is simple and may be deployed

immediately since no protocol changes are required.

We believe that it is an efficient approach that can

be used today until rigorous solutions based on

public key infrastructure will be deployed. Our

approach is based on available data from registry

databases. The registered data may be updated by

their owners. The legitimacy level that we infer from

this data should also be updated. An automatic

update feature of the database should be added and

scheduled.

We use a statistics-based approach to identify

incorrectness related to unavailable data. Like all the

statistics-based approaches, our approach is faced to

the "magic number" problem. In fact, the legitimacy

level that we evaluate depends on the number of

times the tuple (prefix, origin AS) is announced

during a period of observation. This period is also a

key parameter which must be well tuned in order to

avoid false positives. In the legitimacy level

inference, we assumed that when an AS aggregates a

prefix it can be considered as legitimate originator.

SECRYPT 2006 - INTERNATIONAL CONFERENCE ON SECURITY AND CRYPTOGRAPHY

116

Further verifications should be applied to

aggregators. We are working on the definition of

conditions for these verifications. Moreover, the

evaluated legitimacy level may be exchanged

between ASes that trust each other. It can be

considered in the decision process of each AS

participating to a collaborative architecture. Finally,

the system we have defined may be extended to

support the policy conformance verification of a

route.

5 CONCLUSION

In this paper we defined formal correctness rules

that BGP advertisements should satisfy. We

designed a system able to detect incorrect

announcements and to classify them in order to be

considered in the decision process. We used

available data in regional Internet registries to verify

the legitimacy of an AS to originate a prefix. We

also defined a methodology to infer this legitimacy

level to the missed data. We believe that registry

databases contain useful information that can be

used for route announcements verification.

We also believe that some enhancements to these

databases can have a significant impact on routing

security. The problem that we tried to settle is the

distinction between invalid multiple origin AS

announcements for prefixes and valid ones.

Multihoming is one the cases where prefixes may be

originated by multiple ASes. Unfortunately data

related to multihomed ASes, their providers and

their prefixes is not available. The availability of this

data would ease this distinction between

multihoming BGP advertisements and wrong

multiple BGP advertisement. We think that this data

should be added to registry databases.

In the future, we expect to further enhance our

approach and to define methods to verify the policy

conformance rules we have defined in this paper.

Further work will be to make routers ore intelligent

and to automatically react to anomalous

announcements.

REFERENCES

Rekhter, Y, 2006. The Border Gateway Protocol. RFC

4271

Huston, G. 2006. www.potaroo.net

Kent, S., 2000. Secure Border Gateway Protocol. In IEEE

Journal on Selected Areas in Communications, Vol.

18, No. 4, pp. 582-592

Atkinson, R., 2004. IAB Concerns and Recommendations

Regarding Internet Research and Evolution. RFC

3869.

Zhao, M., 2004 Evaluation of Efficient Security for BGP

Route Announcements using Parallel Simulation. In

Journal on Simulation Modeling Practice and Theory

Zhao, M., 2005. Aggregated Path Authentication for

Efficient BGP Security. In proceedings of ACM

Conference on Computer and Communications

Security.

White, R., 2003. Securing BGP through Secure Origin

BGP. In Internet Protocol Journal, Cisco, Vol. 6 Num

3, p15-22.

Wan, T. 2005. Pretty Secure BGP. In proceedings of

Network and Distributed System Security Symposium

Conference.

RPSec WG, www.ietf.org/html.charters/rpsec-charter.html

SIDR WG,

www.ietf.org/proceedings/06mar/minutes/sidr.txt

Teoh, S.T., 2003. Visual-based Anomaly Detection for

BGP Origin AS Change (OASC) Events. In

DSOM2003, 14th IFIP/IEEE International Workshop

on Distributed Systems: Operations and Management.

Teoh, S. T., 2004. Combining visual and automated data

mining for near-real-time anomaly detection and

analysis in BGP, CCS Workshop on Visualization and

Data Mining for Computer Security.

Zhao, X., 2002. Detection of Invalid Routing

Announcement in the Internet. In Proceedings of

International Conference on Dependable Systems and

Networks.

Kim, E., 2005. Global Internet Routing Forensics:

Validation of BGP Paths using ICMP Traceback. In

Proceedings of the First annual IFIP WG 11.9

International Conference on Digital Forensics.

Hyun, Y., 2003. Traceroute and BGP AS Path

Incongruities. In the proceedings of the International

Working Conference on Performance Modeling and

Evaluation of Heterogeneous Networks.

Goodell, G., 2003. Working Around BGP: An Incremental

Approach to Improving Security and Accuracy of

Interdomain Routing. In proceedings of Network and

Distributed Systems Security.

IRR. www.irr.net

Alaettinoglu, C., 1999. Routing Policy Specification

Language. RFC2622

Meyer, D., 1999. Using RPSL in Practice, RFC2650.

Siganos, G., 2004. Analyzing BGP Policies: Methodology

and Tool., in Proceedings of IEEE INFOCOM.

RIPE RRCC Project,

www.ripe.net/projects/rrcc/index.html

Routeviews, www.routeviews.org

RIPE RIS Project, www.ripe.net/projects/ris/index.html

INTERNET ROUTING SECURITY: AN APPROACH TO DETECT AND TO REACT TO INCORRECT

ADVERTISEMENTS

117
