SECURITY RISK ANALYSIS IN WEB SERVICES SYSTEMS

Carlos Gutiérrez, Eduardo Fernández-Medina, Mario Piattini

ALARCOS Research Group. Information Systems and Technologies Department UCLM-Soluziona Research and

Development Institute. University of Castilla-La Mancha Paseo de la Universidad, 4 – 13071 Ciudad Real, Spain

Keywords: Security Risk Analysis and Management, Security Engineering, Software Security Development Process,

Web Services Security.

Abstract: Nowadays, best practices dictate that security requirements of distributed software-intensive systems should

be based on security risk assessments. Web services-based systems supporting network alliances among

organizations through Internet are such type of systems. In this article we present how we’ve adopted the

risk analysis and management methodology of the Spanish Public Administration, which conforms to ISO

15408 Common Criteria Framework (CCF), to the Process for Web Services Security (PWSSec) developed

by the authors. In addition, a real case study where this adaptation was applied is shown.

1 INTRODUCTION

Nowadays, best practices dictate that security

requirements of software-intensive systems should

be based on risk assessments (Butler and Fischbeck

2005). Software systems based on Web services

(WS) technologies have achieved a great popularity

recently in both industry and academic world. Web

services are a natural consequence of the evolution

of the Web and distributed systems. Since its

beginnings as a way to share and distribute

information on a global scale, effectively becoming

a giant distributed content library, the Web has been

progressively widening its reach to enable more

sophisticated forms of interaction between browser

clients and servers: single form-based interactions,

retail ecommerce applications, and more complex

business-to-business interactions. IDC estimates that

$2.3 billion was spent worldwide on total WS

software in 2004, more than double the amount from

the previous year. IDC expects spending to continue

to increase dramatically over the next 5 years,

reaching approximately $14.9 billion by 2009. In

consequence, security in WS development processes

should include a risk analysis so that security

requirements can be elicited and prioritized. In this

paper, we present a risk analysis process on a WS-

based system that is part of the tasks to be developed

during the WSSecReq (Web Services Security

Requirements) subprocess of the PWSSec (Process

for Web Services Security) process created by the

authors (Gutiérrez, Fernández-Medina et al. 2005).

Although WSSecReq subprocess does not demand a

specific risk analysis method we show how the risk

analysis and management method of the Spanish

Public Administration, Magerit2 (Crespo, Gómez et

al. 2005), is applied to a real case study. MAGERIT

2 is the Spanish Public Administration's adaptation

of ISO 15408, Common Criteria Framework.

The rest of the article is organized as follows: i) in

section 2, a little background on those terms the rest

of the article is based on is presented. That is, a brief

explanation about the PWSSec process, a short

introduction on its WSSecReq subprocess, and,

finally, a short presentation of the case study that

section 3 is based on (see (Gutiérrez, Fernández-

Medina et al. 2005)) for more details on the case

study’s context); ii) in section 3, we will explain

how we have adopted Magerit2 methodology when

performing the tasks related to risk analysis defined

by the WSSecReq subprocess; iii) in section 4, final

conclusions are stated.

425

Gutiérrez C., Fernández-Medina E. and Piattini M. (2006).

SECURITY RISK ANALYSIS IN WEB SERVICES SYSTEMS.

In Proceedings of the International Conference on Security and Cryptography, pages 425-430

DOI: 10.5220/0002105004250430

 SciTePress

Figure 1: Activities and taks of the WSSecReq subprocess.

2 BACKGROUND

2.1 PWSSec Overview

The PWSSec process specifies how to define

security requirements for WS-based systems,

describes a security services-based reference

security architecture and explains how to instantiate

it to obtain concrete security architecture based on

the current WS security standards (Gutiérrez,

Fernández-Medina et al. 2005). PWSSec process

is structured in three sub-processes which describe

their inputs, outputs, activities, actors and

sometimes, guides, best practices, tools and

techniques that complement, improve and facilitate

the set of activities and tasks developed within these

stages. WSSecReq sub-process’s main purpose is to

produce, by means of a systematic approach, a

specification (or a part of it) of the security

requirements of the WS-based system. WSSecArch

sub-process is aimed at allocating the security

requirements specified in the previous section to a

WS-based security architecture. This security

architecture will be equipped with the necessary

security policies and architectural mechanisms to

achieve the considered security requirements.

WSSecTech subprocess’s main objective is to

identify the set of WS-based security standards that

will implement the architectural security

mechanisms identified in the previous stage.

2.2 WSSecReq Overview

The main purpose of this subprocess is to produce a

specification (or a part of it) of the security

requirements of the target WS-based system. Its

input is composed by a specification of the scope

that we want to comprise during the current

iteration, the business and security goals defined for

the system as well as the part of the organizational

security policy that we estimate that may impact on

the system design. The output is basically formed

by: i) A threat attack tree (Schneier 1999) associated

with the WS business and application pattern

(Endrei, Ang et al. 2004) identified within the

analyzed functionality; ii) Every built attack tree’s

leaf will show a threat (WS-I 2005) that can refined

by a set of attack scenarios, defined as misuse cases

according to (Alexander 2003; Sindre and Opdahl

2005), organized into attack profiles (Moore, Ellison

et al. 2001), and represented according to the

Quality of Service UML profile (OMG 2004); ii)

every misuse case must have related a set of security

use cases, according to Donald G. Firesmith

(Firesmith 2003), that state how the system should

respond to the associated misuse case; iii) A formal

specification of the security requirements for the

scope of the system based on SIREN (Toval, Nicolás

et al. 2001) (Gutiérrez, Fernández-Medina et al.

2005). These requirements will have been derived

after instantiating the WS security requirements

templates associated with every security use case.

This subprocess defines 4 main activities:

Elicitiation, Analysis, Specification and

PWSSec Process

Sub-process P1 – WSSecReq

Activity A1.1: Elicitation

Task T1.1.1: Decide granularity level and identify the fragment of functional software whose security will be

analyzed

Task T1.1.2: Identify the IBM WS-based business pattern.

Task T1.1.3: Identify the IBM WS-based application pattern.

Task T1.1.4: Identify possible business threats.

Task T1.1.5: Identify possible application threats.

Task T1.1.6: Relate business and application threats.

Task T1.1.7: Identify and assess threats.

Task T1.1.8: Identify type of attackers and their possible types of attack.

Task T1.1.9: Assess impact of attacks.

Task T1.1.10: Estimate and prioritize security risks.

Task T1.1.11: Determine the behaviour the system should have for each attack.

Task T1.1.12: Identify security sub-factors.

Task T1.1.13: Specify security requirements.

Activity A1.2: Analysis

…

Activity A1.3: Specification

…

Activity A1.4: Verification and Validation

SECRYPT 2006 - INTERNATIONAL CONFERENCE ON SECURITY AND CRYPTOGRAPHY

426

Validation and Verification. Here, we will focus

on the Elicitation activity (see (Gutiérrez,

Fernández-Medina et al. 2005) for more details on

the others). The Elicitation activity will be

supported by a detailed study of security for each

WS business service identified and considered in the

current iteration. This activity is inspired in the risk

analysis and management process known as

Operationally Critical Attack, Asset, and

Vulnerability Evaluation

(OCTAVE) (Firesmith

2003). This activity defines a set of tasks that

support security risk analysis during elicitation of

security requirements. In this article we will show

how we have adopted Magerit2, a Common Criteria

Framework-compliant security risk analysis and

management methodology, developed by the

Spanish Public Administration.

2.3 Case Study

In this article we present an actual case study that

was applied to a web services-based system known

as WS-BTS (Web Services-based Bank Transfer

System). This system’s objective was the sale of

certain products chosen by purchasers through a

Web application. Payments are made from

purchaser’s bank account which is associated with

the bank account of the sales organization (hereafter

SalesOrg). This use case was developed as a WS-

based system and consists of two types of WS-based

agents: (1) a WS consumer agent, belonging to

SalesOrg, who will be referred to as WS-

BTSConsumer (Web services-based Bank Transfer

System Consumer) and (2) the WS provider agent of

the bank service (hereafter BankOrg) that will be

referred to as WS-BTSProvider (Web services-based

Bank Transfer System Provider). These agents

interact in order to fulfil a business workflow called

BTS (Bank Transfer System), whose objective is to

assist the final customer during its payment so

purchase is facilitated. This use case is achieved by a

three-step protocol carried out by the WS-

BTSConsumer and WS-BTSProvider web services

agents as described in (Gutiérrez, Fernández-Medina

et al. 2005). In this article we illustrate how risk

analysis was made as part of applying the

WSSecReq subprocess on this case study.

3 RISK ANALYSIS IN WS-BASED

SYSTEMS

In this section, we’ll show how WSSecReq’s tasks

were carried out during the aforementioned case

study. Concretely, we’ll focus on risk analysis-

related tasks. That is, tasks from T1.1.4 to T1.1.10

(see high-lighted tasks in Figure 1). In tasks T1.1.1-

Threat Tree derived of the IBM WS Application Pattern Exposed Direct Connection

ID: A3Ap-CED-1

Goal: 1. Cause damage on the elements defined in the IBM WS Application Pattern named Exposed Direct

Connection when applied to the WS-BTS system.

1.1. Threat WS-BTS Agents

1.1.1 Threat WS-BTSConsumer/WS-BTSProvider

1.1.1.1 Intentional Threats

1.1.1.1.1 Principal Spoofing of WS-BTSConsumer/WS-BTSProvider

1.1.1.1.1.1 Integrity

1.1.1.1.1.2 Confidentiality

1.1.1.1.1.3 Service’s User Authentication

1.1.1.1.1.4 Message Origin Authentication

1.1.1.1.2 Manipulation of Configuration of WS-BTSConsumer/WS-BTSProvider

1.1.1.1.2.1 Integrity

1.1.1.1.2.2 Confidentiality

1.1.1.1.2.3 Service’s User Authentication

1.1.1.1.2.4 Message Origin Authentication

1.1.1.1.2.5 Service Traceability

1.1.1.1.2.6 Message Traceability

1.1.1.1.3 Denial-of-Service to WS-BTSConsumer/WS-BTSProvider

1.1.1.1.3.1 Availability

1.1.1.1.4 Privilege Abuse by WS-BTSConsumer/WS-BTSProvider

1.1.1.1.4.1 Integrity

1.1.1.1.4.2 Confidentiality

1.1.1.1.5 Unforeseen use of WS-BTSConsumer/WS-BTSProvider

1.1.1.1.5.1 Availability

1.1.1.1.6 Re-routing of messages to WS-BTSConsumer/WS-BTSProvider

1.1.1.1.6.1 Integrity

1.1.1.1.6.2 Confidentiality

1.1.1.1.6.3 Service’s User Authentication

1.1.1.1.6.4 Message Origin Authentication

1.1.1.1.7 Non-authorized Access

1.1.1.1.7.1 Integrity

1.1.1.1.7.2 Confidentiality

1.1.1.1.7.3 Message Origin Authentication

1.2. Threat Network Zone

1.3. Threat Connection Rules

…

Figure 2: Threat Tree derived from the IBM WS Application Pattern Exposed Direct Connection– View of threats on the

existing run-time software systems.

SECURITY RISK ANALYSIS IN WEB SERVICES SYSTEMS

427

T1.1.3, business and application IBM WS-based

architectural patterns were identified (Endrei, Ang et

al. 2004). The novelty of our approach resides in

showing how a risk analysis method conformed to

the Common Criteria Framework was integrated into

PWSSec in such a way that security requirements

and security engineering disciplines for Web

services-based system were successfully aligned,

integrated and developed. Few previous approaches

have been proposed on the subject of applying

security risk analysis in WS-based development

processes up until now. The problem with them is

that they explain how this subject from a very

abstract level of detail (Christopher Steel 2005). In

this paper, we provide a reusable, real and practical

solution on this area showing how we adjusted

Magerit2 to security analysis-related tasks of

PWSSec.

3.1 A1.1. Elicitation - T1.1.4:

Identify Possible Business

Threats

Rigorous risk analysis relies on an understanding of

business impacts, which requires an understanding

of laws and regulations as well as the business

model supported by the software (Verdon and

McGraw 2004). The main purpose of this task is,

from the business-level description elaborated

during task T1.1.2, to define the set of potential

business-level threats that applies to the system

under development. We’ve associated an abstract

business threat tree to every IBM WS business

(Endrei, Ang et al. 2004; Gutiérrez, Fernández-

Medina et al. 2005). This way, once the WS

business pattern has been identified its potential

threats are systematically discovered. These threats

are organized in a tree-like form (Moore, Ellison et

al. 2001). This task’s output is a Business Threat

Model containing the description of the identified

threats organized in the business threat tree. The

chosen notational language representation is based

on the Quality-of-Service UML Profile (OMG

2004).

3.2 A1.1. Elicitation - T1.1.5:

Identify Possible Application

Threats

Risk analysis on modern distributed paradigms such

as WS, requires a functional decomposition of the

application into major components, processes, data

stores, and data communication flows, mapped

against the environment across which the software

will be deployed (Verdon and McGraw 2004). In

this task, the application-level threat tree, which

provides such a functional decomposition, will be

created based on the IBM WS-based application

pattern identified during task T1.1.3 (see Figure 2).

The set of IBM WS application patterns and their

associated abstract threat trees are part of the WS

Security E&A (Elicitation and Analysis) Resources

Repository of WSSecReq subprocess (Gutiérrez,

Fernández-Medina et al. 2005). In Figure 2, the

fragment of the application threat tree that unfolds

branch 1.1 is presented. Under this branch, the set of

threats to be considered on WS agents that

participate in the WS-BTS system: Agent WS-

BTSConsumer (WS-BTSC) and agent WS-

BTSProvider (WS-BTSP) are organized according

to their types. The set of threats on the network

organized under branch 1.2 and 1.3 are omitted due

to space-limits. These threats have been extracted

from the catalogue of threats defined in Magerit2.

Under branch 1.4 the set of threats to be considered

on the WS-based interactions is presented. Here, the

division proposed by the abstract threat tree is based

on the set of threats on the messages of each one of

the interactions that support the functionality whose

security is under analysis (threats have been

extracted from (WS-I 2005) and (Crespo, Gómez et

al. 2005)). This task’s output is an Application

Threat Model. The description of these threats will

give place to a threat model at the application level

that will mainly contain: i) An application threat tree

specific for the system under analysis; ii) UML QoS

model of threats and assets (OMG 2004).

3.3 A1.1. Elicitation - T1.1.7: Threat

Assessment

Task T1.1.7 of WSSecReq is completed by applying

the following Magerit2’s steps: i) Identification of

Assets: According to the application threat tree, and

just focusing on threats on the interactions, the

lowest level assets (those whose risk depends on

higher-level assets) are TNT message (for the

developed branch), TTR Message, TTR Response

Message, RNP Message and RNP Response

Message as well as WS-BTSP and WS-BTSC

agents; ii) Definition of the Dependency Matrix of

Assets: Every (business/application) abstract threat

tree has predefined its own template for its

corresponding asset dependency matrix within the

WS Security E&A Resources WSSecReq’s

repository. The asset dependency matrix allows the

establishment of dependencies between branches

representing assets of the threat tree. The types of

assets considered in a WS context are: a) Web

SECRYPT 2006 - INTERNATIONAL CONFERENCE ON SECURITY AND CRYPTOGRAPHY

428

Services: The purpose of the WS-BTS system is to

offer a service; b) WS agent: From

Magerit2’s viewpoint, we consider it as software

applications; c) Messages: access to data (messages)

is made through WS agents; d) Volatile/Persistent

Structured Storage Services (Databases, directory

services, etc.): It is the base from which certain

messages are created (outgoing messages) and

where the results of processing other messages are

stored (incoming messages); iii) Threat

Characterization: Threat characterization consists

of determining the likelier threats for each one of the

assets and represents them in a System’s Risk Map.

In our case, this step was straightforward since we

just needed to add two new metrics to the

application threat tree: Frequency of Threat

Occurrence and Asset Degradation Ratio. The

Frequency of Occurrence Threat’s value will be

valued during task T1.1.8, when all types of attacks

for each threat are identified and when the highest

frequency of occurrence due to those attacks is

obtained. The asset degradation’s value will be

determined during task T1.1.9 as part of the

calculation of the threat impact. In Table 1, the final

Risk Map (resulting of task T1.1.10) which includes

the set of identified assets is presented. As output

product of this task the Threat Assessment, an

Assessed Global Threat Model consisting of the

aggregation of the security analysis made to the

Global Threat Model is obtained.

3.4 A1.1. Elicitation - T1.1.8:

Identify the Type of Attackers

and their Possible Types of

Attacks

The next step will consist of refining the leaf-nodes

of the threat tree, i.e. further specification of the

threats by means of concrete attacks. Towards this

ends, use will be made of the concept of attack

profile described in (Moore, Ellison et al. 2001). We

use misuse cases in (Sindre and Opdahl 2005) to

defining the sequences of steps which state the

achievement of successful attacks on the system. An

attack profile contains a set of abstract misuse cases

that apply to a reference model defined within the

profile (in our case the IBM WS-based Application

Pattern). Therefore, interactions in every WS-based

application pattern have one attack profile related.

Every WS-based application pattern has one or more

attack profiles related to it which state the potential

attacks that could be targeted at them.

We complete the Assessed Global Model of

Threats with the characterization and frequency of

the attacks that materialize every threat thereby

obtaining the Global Model of Threats and Attacks.

3.5 A1.1. Elicitation - T1.1.9: Assess

Impact of Attacks

In Magerit2 terms, this task will consist of

completing the Risk Map by assigning the value of

degradation on assets as a consequence of threats’

materialization. In addition, the Risk Map is

completed by incorporating an additional value that

represents the accumulated impact on every high-

level asset (WS-BTSProvider/WS-BTSConsumer)

and the repercussed impact on every low-level asset

(WS messages). As output of this task we obtain the

Assessed Global Model of Threats and Attacks

completed with the Risk Map.

Table 1: View of the Risk Map showing degradation ratio, accumulated impact and risk of the WS-BTSC asset. Column F

represents Frequency of the threat.

Security Dimensions

(I=Integrity, C=Confidentiality, A=Availability, S_A=Service’s User Authentication,

M_A=Message Origin Authentication, S_T=Service Traceability, M_T=Message Traceability)

Asset Threat F I C D A_S A_M T_S T_D

1.1.1.1.1.1 5 50% [3] {3} 50% [4] {4} 100%[4] {4} 100% [6] {6}

1.1.1.1.1.2 5 60 % [4] {4} 5% [0] {0} 10% [0] {0} 10% [0] {0} 0% [0] {0} 0% [0] {0}

1.1.1.1.1.3 5 10%[0] {0}

1.1.1.1.1.4 5 0 [0] {0} 0% [0] {0}

1.1.1.1.1.5 5 0%[0] {0}

1.1.1.1.1.6 5 10% [0] {0} 5% [0] {0} 5% [0] {0} 5% [0] {0}

1.1.1.1.1.7 5 0

WS-

BTSC

1.1.1.1.1.8 5 100

%[7] {7} 10% [0] {0} 60% [3] {3}

SECURITY RISK ANALYSIS IN WEB SERVICES SYSTEMS

429

3.6 A1.1. Elicitation - T1.1.10:

Assess and Prioritize Security

Risks

Finally, we estimate and prioritize the risk

completing the Assessed Global Model of Threats

and Attacks. In the case of Magerit2, risk is

computed as a function of the impact and frequency

of the threats. Table 1 shows the computed risks for

every threat and asset and its security dimension.

These risks will guide and provide a basis for the

development of the following tasks defined within

the WSSecReq sub-process. These tasks basically

consist of identifying the expected behaviour of the

system for every attack (task T1.1.11) and eliciting

the security requirement (task T1.1.12). Risks on

every asset will guide what and how resources

should be planned during security architecture

development (in WSSecArch sub-process).

4 CONCLUSIONS

In this paper, we have presented how Magerit2 can

be adapted in the context of the PWSSec process

during elicitation of security requirements within

WS-based systems. This presentation has been

complemented with a demonstration of the

application of the WSSecReq subprocess, one of the

sub-processess defined by the PWSSec process to a

real case study.

ACKNOWLEDGMENTS

This research is part of the following projects

RETISTIC network (TIC2002-12487-E), of

Dirección General de Investigación del Ministerio

de Ciencia y Tecnología, DIMENSIONS (PBC-05-

012-1), financed by the FEDER and the “Consejería

de Ciencia y Tecnología de la Junta de Comunidades

de Castilla-La Mancha” (Spain) and CALIPO

(TIC2003-07804-C05-03) granted by the “Dirección

General de nvestigación del Ministerio de Ciencia y

Tecnología” (Spain).

REFERENCES

Alexander, I. (2003). "Misuse Cases: Use Cases with

Hostile Intent." IEEE Computer Software 20(1): 58-

66.

Butler, S. A. and P. Fischbeck (2005). Multi-Attribute

Risk Assessment. SREIS'05 in conjuntction with

RE'05, Paris, France.

Christopher Steel, R. N., Ray Lai (2005). Core Security

Patterns: Best Practices and Strategies for J2EE™,

Web Services, and Identity Management, Prentice Hall

PTR / Sun Microsystems.

Crespo, F. L., M. Á. A. Gómez, et al. (2005). MAGERIT -

Versión 2. Metodologías de Análisis y Gestión de

Riesgos de los Sistemas de Información. III - Guía de

Técnicas. Madrid, Ministerio de Administraciones

Públicas: 154.

Endrei, M., J. Ang, et al. (2004). Patterns: Service-

Oriented Architecture and Web Services: 345.

Firesmith, D. G. (2003). "Engineering Security

Requirements." Journal of Object Technology 2(1):

53-68.

Firesmith, D. G. (2003). "Security Use Cases." Journal of

Object Technology 2(3): 53-64.

Gutiérrez, C., E. Fernández-Medina, et al. (2005).

PWSSec: Process for Web Services Security. IEEE

International Conference on Web Services 2005,

Orlando, Florida, USA.

Gutiérrez, C., E. Fernández-Medina, et al. (2005). Security

Requirements for Web Services based on SIREN.

Symposium on Requirements Engineering for

Information Security, Paris, France.

Gutiérrez, C., E. Fernández-Medina, et al. (2005). Web

Services Enterprise Security Architecture: a Case

Study. ACM Workshop on Security on Web Services,

Fairfax, Virginia, USA, ACM Press.

Gutiérrez, C., E. Fernández-Medina, et al. (2005). Web

Services-based Security Requirement Elicitation. 1st

International Workshop on Service-Oriented

Computing: Consequences for Engineering

Requirements (SOCCER'05) in conjunction with

IEEE RE'05, Paris, France.

Moore, A. P., R. J. Ellison, et al. (2001). Attack Modelling

for Information Security and Survivability. Survivable

Systems, Software Engineering Institute.

OMG (2004). UML Profile for Modeling Quality of

Service and Fault Tolerance Characteristics and

Mechanisms.

Schneier, B. (1999). "Attack Trees: Modeling Security

Threats." Dr. Dobb's Journal.

Sindre, G. and A. L. Opdahl (2005). "Eliciting Security

Requirements with Misuse Cases." Requirements

Engineering Journal 10(1): 34-44.

Toval, A., J. Nicolás, et al. (2001). "Requirements Reuse

for Improving Information Systems Security: A

Practitioner's Approach." Requirements Engineering

Journal 6(4): 205-219.

Verdon, D. and G. McGraw (2004). Risk Analysis in

Software Design. IEEE Security & Privacy. 2: 79-84.

WS-I (2005). Security Challenges, Threats and

Countermeasures Versión 1.0, WS-I. 2005.

SECRYPT 2006 - INTERNATIONAL CONFERENCE ON SECURITY AND CRYPTOGRAPHY

430
