SEMI INTERACTIVE METHOD FOR DATA MINING

Lydia Boudjeloud-Assala, François Poulet

ESIEA Pôle ECD

38, rue des docteurs Calmette et Guérin

Parc Universitaire de Laval-Changé, 53000 Laval, France

Keywords: Data Mining, interactive genetic algorithm, high dimensional data, data visualization.

Abstract: Usual visualization techniques for multidimensional data sets, such as parallel coordinates and scatter-plot

matrices, do not scale well to high numbers of dimensions. A common approach to solve this problem is

dimensionality selection. We present new semi-interactive method for dimensionality selection to select

pertinent dimension subsets without losing information. Our cooperative approach uses automatic

algorithms, interactive algorithms and visualization methods: an evolutionary algorithm is used to obtain

optimal dimension subsets which represent the original data set without losing information for unsupervised

tasks (clustering or outlier detection) using a new validity criterion. A visualization method is used to

present the user interactive evolutionary algorithm results and let him actively participate in evolutionary

algorithm search with more efficiency resulting in a faster evolutionary algorithm convergence. We have

implemented our approach and applied it to real data set to confirm it is effective for supporting the user in

the exploration of high dimensional data sets and evaluate the visual data representation.

1 INTRODUCTION

The data stored in the world are rapidly growing.

This growth of databases has far outpaced the

human ability to interpret these data creating a need

for automated analysis of databases. Knowledge

Discovery in Databases (KDD) is the non-trivial

process of identifying valid, novel, potentially

useful, and ultimately understandable patterns in

data (Fayyad & al., 1996). The KDD process is

interactive and iterative, involving numerous steps.

Data mining is one step of the KDD process. In most

existing approaches, visualization is only used

during two particular steps of the data mining

process: in the first step to view the original data or

data distribution and in the last step to view the final

results. Usual visualization techniques for

multidimensional data sets, such as parallel

coordinates (Inselberg, 1985) and scatter-plot

matrices (Carr & al., 1987) do not scale well to high

dimensional data sets. With large number of axes

representing dimensions, the user cannot detect any

pertinent information about items or cluster details.

Even with low numbers of items, high

dimensionality is a serious challenge for current

display techniques. To overcome this problem, one

promising approach is dimensionality selection (Liu

and Motoda, 1998). The first idea is to select some

pertinent dimensions without losing information in

the original data set and then visualize the data set in

this subspace. Most of these methods focus on

supervised classification and evaluate potential

solutions in terms of predictive accuracy. Few works

(Dash and Liu 2000) deal with unsupervised

classification where we do not have prior

information to evaluate potential solution. Another

promising approach focusing on unsupervised

classification is subspace clustering. Subspace

clustering methods must evaluate features in only a

subset of the data and dimensions, representing a

cluster. A survey of subspace clustering algorithms

can be found in (Parsons & al., 2004). The main idea

presented in this paper is inspired by the feature

selection, we use a filter method for clustering and

outlier detection with a new validity index combined

with a visual interactive validation. Furthermore,

some new methods called Visual data mining have

recently appeared (Poulet, 2004), trying to involve

more significantly the user in the data mining

process and using more intensively the visualization

(Aggarwal, 2002). We think it is important to

consider user perception in the dimension selection

process, according to his choice for unsupervised

learning problem. We propose semi-interactive

algorithm combining automatic algorithm,

interactive evolutionary algorithm and visualization

Boudjeloud-Assala L. and Poulet F. (2006).

SEMI INTERACTIVE METHOD FOR DATA MINING.

In Proceedings of the Eighth International Conference on Enterprise Information Systems - AIDSS, pages 3-10

DOI: 10.5220/0002454600030010

 SciTePress

methods. First evolutionary algorithm generates

pertinent dimension subsets, using a new validity

index for the two problems (clustering or outlier

detection) without losing information. Some of these

dimension subsets are then visualized using parallel

coordinates for example. The user can interactively

choose the data representation that seems significant

according to his problem and the selected dimension

subsets are then in input of the next evolutionary

algorithm generation and so on until having optimal

data representation. We have applied our method to

several high dimensional data sets and found this

approach is helpful in exploring high dimensional

data sets. This paper is organized as follows. The

next section describes related works in interactive

evolutionary algorithm, methods using visualization

in the data mining process and dimensionality

selection methods. Then we present our semi-

interactive Genetic Algorithm and details about our

evaluation function for outlier detection and

clustering. In section 4 we present the current

prototype of Viz-IGA (Visual Interactive Genetic

Algorithm) before the conclusion and future work.

2 RELATED WORKS

2.1 Interactive Evolutionary

Algorithm

There are two types of target systems for

optimization system: system whose optimization

performances are numerically defined as evaluation

functions and systems whose optimization indexes

are difficult to specify. Most engineering research

uses several optimization methods based on

minimizing error criteria and focus on the former,

including auto-control, pattern recognition,

engineering design and so on. However, to obtain

the most favourable outputs from interactive systems

that create or retrieve graphics or music, such

outputs must be subjectively evaluated. It is difficult,

or even impossible, to design human evaluation

explicit functions. Generally, the best system outputs

such as images, acoustic sound, and virtual realities

can be detected by the human senses and be

evaluated by the user impressions, preferences,

emotions and understanding. There are many

systems, not only in the artistic or aesthetic fields,

but also in the engineering, education fields and

recently in data mining field where we have

difficulties to model and evaluate problem solution.

Their system parameters or structures must be

optimized based on the user's subjective evaluation.

Since we cannot use the gradient information of our

mental psychological space, we need another

approach different from conventional optimization

methods. (Takagi, 2001) defines Interactive

Evolutionary Algorithm (IEA) as an optimization

method that adopts evolutionary algorithm (EA)

among optimization system based on subjective

human evaluation. It is simply an EA technique

whose fitness function is replaced by human user.

IEAs have been successfully applied to several

domains like for instance image synthesis where the

user evaluates images, face recognition and

knowledge discovery in databases. (Venturini& al.,

1997) present GIDE (Genetic Interactive Data

Explorer) where the main idea is to provide the user

new variables (attributes) and the corresponding 2D

graphical representations. An individual of GIDE

represents a couple of function of the initial

variables combined with different mathematical

operators which can also be viewed as a couple of

axes of the 2D graphical representation. The user is

involved to select which operators or mathematical

functions may appear in the individual. For the

evaluation, the user has an interactive process where

the individual is presented in 2D graphical form

where the two functions correspond to the two axes.

2.2 Visual Data Mining

For data mining to be effective, it is important to

include the human in the data exploration process

and combine the flexibility, creativity and general

knowledge of the human with the enormous storage

capacity and the computational power of today’s

computers. The basic idea of visual data exploration

is to present the data in some visual form, allowing

the human to get insight into the data, draw

conclusions and directly interact with the data.

Visual data mining techniques have proven to be of

high value in exploratory data analysis and they also

have a high potential for exploring large databases.

Visual data exploration is especially useful when

little is known about the data and the exploration

goals are vague. Since the user is directly involved

in the exploration process, shifting and adjusting the

exploration goals is automatically done if necessary

(Keim, 2002). The visual data exploration process

can be seen as hypothesis generation process: the

visualizations of the data allow the user to gain

insight into the data and come up with new

hypotheses. The verification of the hypotheses can

also be done via visual data exploration but it may

also be accomplished by automatic techniques from

statistics or machine learning. In addition to the

direct involvement of the user, the main advantages

of visual data exploration over automatic data

mining techniques are:

ICEIS 2006 - ARTIFICIAL INTELLIGENCE AND DECISION SUPPORT SYSTEMS

- visual data exploration can easily deal with

highly heterogeneous and noisy data,

- visual data exploration is intuitive and requires

no understanding of complex mathematical or

statistical algorithms or parameters.

As a result, visual data exploration usually

allows a faster data exploration and often provides

better results, especially in cases where automatic

algorithms fail. This fact leads to a high demand for

visual exploration techniques and makes them

indispensable in conjunction with automatic

exploration techniques. In data mining, some new

methods have recently appeared (Poulet, 2004),

trying to involve more significantly the user in the

process and using more intensively the visualization

(Aggarwal, 2002). We think it is important to

consider user perception to overcome the drawbacks

of dimension selection process and propose new

approach where the user choice is combined with

automatic fitness function. These automatic fitness

functions are applied to eliminate a great part of

redundant and noisy solutions and the interactive

fitness is applied to evaluate the visual interpretation

as understandable or not.

2.3 Dimensionality Selection

Dimension selection attempts to discover the

attributes of a dataset that are the most relevant to

the data-mining task. It is a commonly used and

powerful technique for reducing the dimensionality

of a problem to more manageable levels. Feature

selection involves searching through various feature

subsets and evaluating each of these subsets using

some criterion (Liu and Motoda, 1998). The

evaluation criteria follow one of the two basic

models, the wrapper model and the filter model. The

wrapper model techniques evaluate the dataset using

the data-mining algorithm that will ultimately be

used. Algorithms based on the filter model examine

intrinsic properties of the data to evaluate the feature

subset prior to data mining. Much of the work in

feature selection has been directed at supervised

learning. The main difference between feature

selection in supervised and unsupervised learning is

the evaluation criterion. Supervised wrapper models

use classification accuracy as a measure of

goodness. The filter-based approaches almost

always rely on the class labels, most commonly

assessing correlations between features and the class

labels. In the unsupervised clustering problem, there

are no universally accepted measures of accuracy

and no class labels. However, there are a number of

methods that adapt feature selection to clustering.

The wrapper method proposed in (Kim & al., 2000)

forms a new feature subset and evaluates the

resulting set by applying a standard k-means

algorithm. The EM clustering algorithm can also be

used in the wrapper framework (Dy and Brodley,

2000). Hybrid methods have also been developed

that use a filter approach as a heuristic and refine the

results with a clustering algorithm. In addition to

using different evaluation criteria, unsupervised

feature selection methods have employed various

search methods in attempts to scale to large, high

dimensional datasets. With such datasets, genetic

searching becomes a viable heuristic method and has

been used with many of the aforementioned criteria

(Boudjeloud and Poulet, 2005a). Another promising

approach focusing on unsupervised classification is

subspace clustering. A survey of subspace clustering

algorithms can be found in (Parsons & al., 2004).

The two main types of subspace clustering

algorithms can be distinguished by the way they

search for subspaces. A naive approach might be to

search through all possible subspaces and use cluster

validation techniques to determine the subspaces

with the best clusters. This is not feasible because

the subset generation problem is intractable. More

sophisticated heuristic search methods are required

and the choice of a search technique determines

many other characteristics of an algorithm. (Parsons

& al., 2004) divide subspace clustering algorithms

into two categories based on how they determine a

measure of locality used to evaluate subspaces. The

bottom-up search method takes advantage of the

downward closure property of density to reduce the

search space, using an APRIORI style approach. The

top-down subspace clustering approach starts by

finding an initial approximation of the clusters in the

full feature space with equally weighted dimensions.

For the subspace clustering methods many

parameters tuning are necessary in order to get

meaningful results. The most critical parameters for

top-down algorithms are the number of clusters and

the size of the subspaces, which are often very

difficult to determine a priori. Since subspace size is

a parameter, top-down algorithms tend to find

clusters in the same or similarly sized subspaces. For

techniques that use sampling, the size of the sample

is another critical parameter and can play a large role

in the quality of the final results.

3 SEMI INTERACTIVE GENETIC

ALGORITHM

The large number of dimensions of the data set is

one of the major difficulties encountered in data

mining. We use genetic algorithm (Boudjeloud and

Poulet, 2004), (Boudjeloud and Poulet, 2005a) for

dimension selection with the individual represented

SEMI INTERACTIVE METHOD FOR DATA MINING

by a small subset of dimensions. The different

parameters used in the genetic algorithm are

described in (Boudjeloud and Poulet, 2004).

(Boudjeloud and Poulet, 2005b) report in their paper

that to obtain ideally an understandable data

visualization, we have to visualise data with about

some tens dimensions using standard visualization

methods (the value is user-defined). We choose to

represent a small subset of dimensions to obtain an

understandable data representation. The population

of the genetic algorithm is first evaluated by new

index validity for the two problems (outlier detection

or clustering) and then some data visualizations are

proposed for user validation. The originality of our

approach is to combine both user interactive

validation and automatic validation to increase

algorithm convergence. The advantage is the

proposed solutions are not biased by the user choice

or automatic fitness function, but both are

considered to generate next evolutionary algorithm

generation.

3.1 Attribute Subset Evaluation

The main idea of our method is to measure the

adequacy of the attribute subset with the original

dataset in terms of cluster structure without losing

information. Let T be a set of N feature vectors with

dimensionality D, T (N*D). Let A = {a

, a

, …, a

}

be the set of all attributes a

of T. Any subset S ⊂ A,

is a subspace or attribute (dimension) subset. The

goal of clustering is to partition datasets into

subgroups such that objects in each particular group

are similar and objects in different groups are

dissimilar. Our objective is to select an attribute

subset with few or no loss of information for high

dimensional data clustering and to obtain the same

distribution in the subspace as the one obtained in

the whole dataset.

Clustering quality. (Milligan and Cooper, 1985)

compared thirty methods for estimating the number

of clusters using four hierarchical clustering

methods. The criteria that performed the best in

these simulation studies with a low level of error in

the data was (CH) a pseudo F-statistic developed by

(Calinski and Harabasz, 1974). This index is based

on clusters’ compactness in term of intra-cluster

variance and separation between clusters in term of

inter-cluster variance.

CH = (SSB/(k-1))/(SSW/(N-k)),

()

mmcSSB −=

∑

∑∑

∈

−=

kCx

mxSSW ,)(

where k represents the cluster number, N the

whole dataset cardinality, |C

| cardinality of the

cluster k, m

the centre of the cluster k and m the

centre of the dataset. SSW refers then to the within

group sum of squares and SSB refers to the between

group sum of squares. The Calinski and Harabasz

index is generally used to set the number of clusters

(k), the highest CH value corresponds to the optimal

cluster number. We use this measure to first

determine the optimal cluster number without

requiring the user to specify parameter and then as

clustering quality criterion (in term of compactness

and separation) for data subspace. When we

maximize the CH value, we obtain the optimal

compactness and separation between clusters in the

dataset or subspace. However, if we use only this

measure to evaluate attribute subsets, we must verify

the point distribution in the clusters, for this purpose

we introduce a measure for the distribution quality.

Distribution quality. We introduce a distribution

quality measure to evaluate the adequacy between

the whole dataset (T) and the subspace (S) according

to the data distribution in the different clusters. Let

and R

measures represent the inverse of the

harmonic mean of the data point distribution in

different clusters (

) in the subspace S and (

)

in the whole dataset T. R

has a fixed value and we

search the subspace S that obtains the best R

value

according to the user task (clustering or outlier

detection).

As shown in left part of the figure 1, if R

=1,

we obtain the same data distribution in the clusters

in T and S, when R

is around 1, only some

elements (they are near the frontiers) swap between

clusters. In this case, S is the optimal attribute subset

that represents (T) the whole dataset in term of

clustering. This subspace represents more clearly the

data distribution. As shown in the right part of the

figure 1, when we search the maximal value of

we obtain clusters that can contain outliers.

Four outliers are detected and we visualize the

corresponding data projection.

⎩

⎨

⎧

≈

===

∑∑

OutliersMax

cluster

Same

)1(1

ICEIS 2006 - ARTIFICIAL INTELLIGENCE AND DECISION SUPPORT SYSTEMS

Figure 1: Distribution quality evolution.

Combination. Our problem is to maximize the

clustering quality and according to the user choice

maximize R

to detect outliers or find R

=1 to

respect the original distribution of the dataset. We

have two quality criteria to simultaneously optimize.

(Freitas, 2004) presents a review of three different

approaches where two or more quality criteria must

be simultaneously optimized. The first approach is

to transform the original multi-objective problem

into a single-objective problem by using a weighted

formula. The second solution is a lexicographical

approach, where the objectives are ranked in order

of priority. The last solution is the Pareto approach,

which consists in finding as many non-dominated

solutions as possible and returns the set of non-

dominated solutions to the user. The conclusion is

the weighted formula is far the most used in data

mining. We choose to combine our two measures

through the F-measure defined by (Van Rijsbergen,

1979) and classically used in the information

retrieval field to combine recall and precision. The

F-measure is considered as a weighted formula, we

apply it to CH and R

which have both to be

maximized (according to the user problem choice).

We define the global criterion SE to maximize.

where b is a weighting parameter controlling the

relative importance of the two aims in the

evaluation. If b=1 for instance, SE gives same

weight for a good clustering and distribution data.

3.2 Attribute Subset Search

When we are searching for the best attribute subset,

we must choose the same number of clusters as the

one used when we run clustering in the whole

dataset, because we want to obtain a subset of

attributes having the same information (ideally) as

the one obtained in the whole dataset. We first use

the described measure (CH) to find the best number

of clusters for the whole dataset. The method is to

find the maximum value max

of CH

(where k is the

number of clusters and CH

the Calinski index value

for k clusters) (Boudjeloud and Poulet, 2004). For

this purpose, we use the k-means algorithm. Our

algorithm computes all CH index values where k

takes values in the set (2, 3, …, a maximum value)

and selects the maximum value max

of the CH

measure and the corresponding value of k. Then we

try to find an optimal combination of attribute

subsets with a genetic algorithm having SE value as

fitness function. Our objective is to find a subset of

attributes that best represents the configuration of

the dataset and discover the same configuration of

the clustering (number, contained data, …) for each

cluster. The number of clusters is the value obtained

for the whole dataset and we search the attribute

subset that has the optimal SE value according to the

user choice: clustering or outlier detection. Using

this approach of cluster validity our goal is to

evaluate the clustering results or outlier detection in

the attribute subset selected by the genetic

algorithm.

3.3 Some Results

We applied our method on several datasets: Colon

tumor (62 elements, 2000 attributes), Lung cancer

(32 elements, 12533 attributes) and Ovarian tumor

(253 elements, 15154 attributes) from the Kent

Ridge Biomedical dataset repository (Jinyan and

Huiqing, 2002) and Vehicule (946 elements, 18

attributes) from the UCI Machine Learning dataset

repository (Blake and Merz, 1998). The results are

presented as follows: k Opt (optimal number of

clusters) and Rp opt (optimal cluster data

distribution) are obtained in the whole dataset with

an optimization search. We have applied a genetic

algorithm to obtain an attribute subset that best

represents the whole dataset in clustering and the

attribute subset where we can clearly detect outliers.

In table 1 we present corresponding results obtained

in different subspaces: Rp sub (subspace data

distribution), R

and SE corresponding values of

the attribute subset. We present the optimal results

for clustering (where R

=1), and results obtained

for outlier detection (where we maximize R

We run our genetic algorithm with SE values as

fitness function. For outlier detection we search for

the maximal SE value. For clustering we add the

constraint R

=1 and we search the optimal

subspace (S). We obtain with R

=1, the same

clustering schema as obtained in the whole dataset

(figure 2a Ovarian dataset with scatter-plot matrices

visualization) and outlier detection when we

)(

)1(

CHb

+⋅

⋅⋅+

SEMI INTERACTIVE METHOD FOR DATA MINING

maximize SE as shown in the figure 2b (Lung

dataset).

Table 1: Dataset results.

Dataset R

Opt R

Sub R

11-21 11-21 1 1.94 Lung

32*12533

k Opt = 2

outlier 1-31 7.45 13.8

18-44 18-44 1 1.95 Colon

62*2000

k Opt = 2

outlier 5-57 2.77 5.06

117-

136

117-136 1 1.98 Ovarian

253*1515

k Opt = 2

outlier - - -

3-13-

16-23-

3-13-16-

23-39

1 1.95 Vehicule

946*18

k Opt = 5

outlier 1-1-22-

27-43

3.87 7.31

Table 2: Lung cancer dataset results.

Dataset k

Opt

Sub

5-27 1.71 3.35

11-21 1 1.94

2-30 3.85 7.22

Lung

32*12533

2 11-21

1-31 7.45 13.82

We also present different results obtained

according to SE values in table 2 for the Lung

cancer dataset. When we apply our method to obtain

optimal cluster number with the k-means algorithm

in the whole dataset we obtain the optimal cluster

number equal to 2 and the optimal data distribution

is 11 elements in the first cluster and 21 elements in

the second cluster. In one hand, when we search the

optimal value of SE adding the constraint of

=1, we find the same data distribution with 11

elements in the first cluster and 21 elements in the

second cluster and when we visualize the data in the

subspace, we note that we obtain exactly the same

clusters ( figure 2a for the Ovarian dataset). In other

hand, when we search the optimal value of SE

without any constraint, we find one cluster with only

one element: it is the outlier and when we visualize

the data (figure 2b) we see clearly it is different from

other elements. We can also obtain clusters

(according to SE value - in table 2) having 2 or 5

elements that can be considered as outliers. For all

datasets we obtain the same results (clusters and

outlier element) in the different subsets selected by

our method as in the whole dataset. For Ovarian

dataset we don’t obtain cluster having only few

elements for this reason we do not describe outlier

results in the table 1.

Figure 2a: Subset clustering for the Ovarian dataset.

Figure 2b: Outlier detection in the Lung dataset.

4 VIZ-IGA SYSTEM

In this section, we describe Viz-IGA, a system

which explores different attribute combinations in

interaction with the domain expert. The algorithm

chooses randomly 9 individuals that are proposed to

the user as we can see in the figure 3 and the user

can choose the data visualizations that seem

significant for his problem. In our example the

problem is outlier detection, we want to find data

visualization where we can see element that is

different from the whole data set.

Before this, the first initialisation of evolutionary

population is the following: we represent the

individual by a combination of different dimensions

that are picked in the whole set of dimensions. At

this step, the first population is ready; it is evaluated

by the validity measure described in section 3.1.

Once the population is evaluated and sorted we

propose them for the user appreciation. Figure 3

shows data representation of some evolutionary

individuals proposed for outlier detection problem

(our example).

ICEIS 2006 - ARTIFICIAL INTELLIGENCE AND DECISION SUPPORT SYSTEMS

Figure 3: Visualized generations and selected individuals.

Once the initial population has been seen, we

observe different data visualizations and we note the

third and fourth ones contain element that has

extreme values and can be outlier. We select these

data visualizations with a mouse click or by

selecting them in the right part of the screen near

their identifications and they appeared different from

others (as shown in the figure 3). Genetic algorithm

considers the dimension subsets that correspond to

these selected visualizations and are then in input of

the next genetic algorithm generation. The user can

choose the size of the attribute subset and the

different visualization display: scatter-plot matrices,

parallel coordinates or star plot. He can also choose

the order of the attributes in the visualization. We

evaluate how human involvement speeds up the

convergence of the EA search. Since our approach

deals with subjective fitness value combined with

black box fitness depending on the application task

(clustering or outlier detection), we compare

convergence of the evolutionary algorithm described

in (Boudjeloud and Poulet, 2004) and Viz-IGA. The

role of human in Viz-IGA is to select the best

candidates in the d-D visualization (d is user-

defined), while in the GA, the user only validates the

final result. We obtain the same outlier in the

attribute subset as in the whole data set and we

obtain the same selected attributes subset with less

generation with Viz-IGA than the standard GA.

5 CONCLUSION AND FUTURE

WORK

We propose in this paper to use user perception to

overcome drawbacks of dimension selection process

for two unsupervised learning problems. We have

developed a semi-interactive algorithm, integrating

automatic algorithm, interactive evolutionary

algorithm and visualization methods. First

evolutionary algorithm generates pertinent

dimension subsets using our new criterion,

according to user choice (clustering or outlier

detection) without losing information. Some of these

dimension subsets are then visualized using parallel

coordinates or scatter-plot matrices. The user can

interactively choose the representation that seems

the most significant and select dimensions in input

of the next evolutionary algorithm generation and so

on until having optimal data visualization. We

introduce a new criterion flexibly combining in an

F-measure a clustering quality index with

distribution quality for subspace clustering and

outlier detection. The numerical experiments and

visualizations show it is an efficient tool to evaluate

subspace clustering and outlier detection. Its main

advantage lies in its flexibility which makes it

possible for the user to find in a subset of

dimensions same clusters or to detect same outliers

as in the whole dataset. Furthermore the number of

dimensions used being low enough this allows the

user to explicitly understand clustering or outlier

detection results with the final visualization. We

must keep in mind that we work with high

dimensional datasets. This step is only possible

because we use a subset of dimensions of the

original data as we can see in the figure 4.

Figure 4: 100 dimensions of the Lung cancer data set

displayed with parallel coordinates

We have tested our methods on different high

dimensional biomedical datasets where our criterion

selects the best subspace of dimensions. We have

used the k-means clustering algorithm, the new

validity criterion SE and a genetic algorithm (for the

attribute selection) having the value of the SE

validity criterion as fitness function. Our first

objective is to obtain subsets of attributes that best

represent the dataset distribution (number, contained

data). This kind of approach is only suitable for

numerical datasets (if some attributes are categorical

they must be transformed into numerical values).

Our criterion needs the computation of R

(mean of

the dataset point) we intend to overcome this

problem by another criterion requiring no

computation on the whole dataset. We also obtain

some local optima, we think to improve this part by

tuning some parameters of the genetic algorithm.

SEMI INTERACTIVE METHOD FOR DATA MINING

REFERENCES

Blake C.L., Merz C.J. 1998, UCI Repository of Machine

Learning Databases Irvine, CA: University of

California, Department of Information and Computer

Science. [http://www.ics.uci.edu /~mlearn/MLR

epository.html] .

Boudjeloud L., Poulet F. 2004, A Genetic Approach for

Outlier Detection in High Dimensional Data Sets, in

Modelling, Computation and Optimization in

Information Systems and Management Science, Le

Thi H.A., Pham D.T. Eds, Hermes Sciences

Publishing, pp 543-550.

Boudjeloud L., Poulet F. 2005a, Attributes selection for

high dimensional data clustering, in proc. of XI

International Symposium on Applied Stochastic

Models and Data Analysis, ASMDA'05, pp 387-395.

Boudjeloud L., Poulet F. 2005b, Visual Interactive

Evolutionary Algorithm for High Dimensional Data

Clustering and Outlier Detection, in Advances in

Knowledge Discovery and Data Mining, T.B. Ho, D.

Cheung, and H. Liu (Eds.), LNAI 3518, Springer-

Verlag, PAKDD 2005, pp 426 – 431.

Calinski R.B. and Harabasz J., 1974. A dendrite method

for cluster analysis. In Communication in statistics,

volume 3, pages 1–27.

Carr D. B., Littlefield R. J., Nicholson W. L. 1987,

Scatter-plot matrix techniques for large N, Journal of

the American Statistical Association, 82(398), pp 424-

436, Littlefield.

Dash M., Liu H. 2000, Feature selection for clustering. In

Proc. Pacific-Asia Conf. on Knowledge Discovery and

Data Mining, pp 110-121.

Dy J. G., Brodley C. E. 2000, Feature subset selection and

order identification for unsupervised learning. In

Proceedings of the Seventeenth International

Conference on Machine Learning, pp 247-254.

Fayyad U., Piatetsky-Shapiro G., Smyth P. 1996, The

KDD process for extracting useful knowledge from

volumes of data, Communications of the ACM, 39(11),

pp 27-34.

Freitas A. A. 2004, A Critical Review of Multi-Objective

Optimization in Data Mining: A Position Paper, ACM-

SIGMOD’04, pp 77-87, vol. 6, n° 2.

Inselberg A. 1985, The Plane with Parallel Coordinates,

Special Issue on computational Geometry, vol 1, pp

69-97.

Jinyan L., Huiqing L. 2004, Kent ridge bio-medical data

set repository, http://sdmc.-lit.org.sg/GEDatasets.

accede in December 2004.

Keim D.A. 2002, Information visualization and visual data

mining, IEEE transaction on visualization and

computer graphics, 7(1), pp 100-107.

Kim Y., Street W., Menczer F. 2000, Feature selection for

unsupervised learning via evolutionary search. In

Proceedings of the Sixth ACM SIGKDD International

Conference on Knowledge Discovery and Data

Mining, pp 365-369.

Liu H., Motoda H. 1998, Feature detection for knowledge

discovery and data mining, Kluwer Academic

Publishers.

Milligan G., Cooper M. 1985, An examination of

procedures for determining the number of classes in a

data set, Psychometrika, vol.52, n°2, pp 159-179.

Parsons L., Haque E., Liu H. 2004, Subspace clustering

for high dimensional data: a review, Special issue on

learning from imbalanced datasets, ACM SIGKDD

Explorations Newsletter, vol 6, n° 1, pp 90-105, 2004.

Poulet F. 2004, SVM and Graphical Algorithms: a

Cooperative Approach, in proc. of IEEE ICDM, the

4th International Conference on Data Mining, pp 499-

502.

Takagi H. 2001, Interactive Evolutionary Computation:

Fusion of the Capacities of EC Optimization and

Human Evaluation, Proceedings of the IEEE, Vol.89,

No.9, pp1275-1296.

Van Rijsbergen C.J. 1979, Information retrivial,

Butterworth, London.

Venturini G., Slimane M., Morin F., Asselin de Beauville

J.P. 1997, On Using Interactive Genetic Algorithms

for Knowledge Discovery in Databases, in 7th

International Conference on Genetic Algorithms, pp

696-703.

ICEIS 2006 - ARTIFICIAL INTELLIGENCE AND DECISION SUPPORT SYSTEMS
