SECTET – An Extensible Framework for the Realization

of Secure Inter-Organizational Workflows

Michael Hafner

, Ruth Breu

, Berthold Agreiter

, Andrea Nowak

Universität Innsbruck, Institut für Informatik, Innsbruck, 6020, Österreich

Austrian Research Center Seibersdorf Research GmbH, Seibersdorf, 2444, Österreich

Abstract. S

ECTET is an extensible framework for the model-driven realization

of security-critical, inter-organizational workflows. The framework is based on

a methodology that focuses on the correct implementation of security-

requirements and consists of a suite of tools that facilitates the cost-efficient

realization and management of decentralized, security-critical workflows. After

giving a description of the framework, we show how it can be adapted to

incorporate advanced security patterns like the Qualified Signature, which

implements a legal requirement specific to e-government. It extends the concept

of digital signature by requiring that the signatory be a natural person.

1 Introduction

SECTET is a framework for the high-level development and management of security-

critical, inter-organizational workflows based on Web services. The framework

supports business partners during the design, the realization and the management of a

common Global Workflow - a decentralized collaboration between actors across

domain boundaries [1]. Realizing the paradigm of Model Driven Security [2], the

framework targets the correct technical implementation of business-level security-

patterns which are integrated at the abstract level into the specification of the Global

Workflow.

A Global Workflow specifies the message flow between partners in a distributed

environment with no central control, by means of UML 2.0 diagrams. The models of

this virtual process are translated into executable configuration files for Workflow

Management Systems (WFMS) and security components of target architectures

located at every partner’s node based on XML and Web services standards and

technologies [3]. A target architecture encapsulates a set of core Web services, which

may access back-end services, orchestrates them through a WFMS, and guards them

by imposing specified security policies to inbound and outbound service calls.

In this paper we present the core components of our framework and illustrate the

main concepts of our methodology for the systematic design and realization of

security-critical inter-organizational workflows with a portion of a workflow-scenario

drawn from e-government. We additionally show how the framework can be adapted

to incorporate advanced security patterns like the Qualified Signature, which extends

the concept of digital signature by requiring a natural person to sign [4].

Section 2 sketches the technical background of our framework and refers to related

Hafner M., Breu R., Agreiter B. and Nowak A. (2006).

SECTET – An Extensible Framework for the Realization of Secure Inter-Organizational Workﬂows.

In Proceedings of the 4th International Workshop on Security in Information Systems, pages 47-57

 SciTePress

work. Section 3 introduces a motivating scenario and shows how to realize a secure

inter-organizational workflow by applying the concepts of our framework to a

specific case. Section 4 shows how the framework can be extended according to

specific business requirements. For a comprehensive introduction to the S

ECTET

framework or a detailed presentation of single aspects, please refer to a series of

accompanying papers (e.g., [5], [6] and [7]).

2 Background

Workflow Standards. The Business Process Execution Language for Web Services

(WS-BPEL [8]) is an XML-based language to compose workflows on top of atomic

Web services. It provides mechanisms to define executable business processes and,

with limitations, abstract business protocols. Collaboration protocols like BPSS [9]

and WS-CDL [10] provide the means to formally specify collaborations in distributed

environments by offering a global view on collaborating services. BPML [11] and

ebXML [10] are alternative languages to specify executable processes. BPML is quite

similar to WS-BPEL as it supports Web services standards, but it is considered as

semantically weaker. ebXML comprises a powerful set of standards for the

specification of B2B protocols but it is not compatible to the Web services concept.

Since we strongly focus on Web services technologies, which is the most widespread

technology with strong vendor support, we consider WS-BPEL as the appropriate top-

layer standard to model local workflow processes in our context.

Web Services Security. Currently a comprehensive set of Web services security

standards is emerging. OASIS has proposed a security extension built on top of the

SOAP Protocol [12]. The extension uses the XML encryption and signature

mechanism to add security features to SOAP messages ([13], [14]). This way, security

mechanisms can be integrated into the header and the body of a SOAP message, and

be sent via any transport channel without compromising security. Beside transport

level security extensions, a variety of standards provides means to manage and

exchange security policies. XACML [15] is a standard to define access control for

resources in a system. Sun has proposed a specific profile for XACML – called Web

Services Policy Language - to define the reconcilement of access rights between

partners. SAML [16] is a standard for the exchange of security tokens. WS-Policy

[17] allows for the definition of protocol level security requirements.

Related Work. Many approaches deal with secure document exchange and

workflow management in centrally organized environments, e.g., the Author-X

system [18], Akenti [19] and the EU-financed project TrustCom [20]. A big

community is working on issues related to inter-organizational workflow management

systems [1], [21], [22], and [23]. We do not aim to contribute a novel approach to this

field. Instead, we rely on UML models for modeling workflow and security into

workflow management systems based on Web services technology. Security

extensions for workflow management systems are treated in [24], [25] and [26]

although at a quite technical level. A model driven approach that is close to the idea

of our framework is [2]. It introduces the concept of Model Driven Security for a

software development process that allows for the integration of security requirements

through system models and supports the generation of security infrastructures. But

this approach focuses exclusively on business logic, whereas we concentrate on inter-

organizational workflow management.

3 The SECTET - Framework

In this section we introduce the conceptual foundation (3.1), we then present the

components of the SECTET Framework (3.2) and finally show how the framework is

applied to a real-life case study, by modeling a Global Workflow that complies to

three basic security requirements of the concept Secure Document Flow (3.3).

3.1 Conceptual Framework

3.1.1 Global and Local Workflows

We define a Global Workflow as a network of partners cooperating in a controlled

way by calling services and exchanging documents. In order to guarantee loose

coupling and design autonomy at the local level without compromising

interoperability, we make the assumption that there is no central control of the inter-

organizational workflow. This means that there is no central Workflow Management

System (WfMS) or document repository.

The Global Workflow can be thought of as virtual process that emerges through

peer-to-peer interaction of executable Local Workflows, which traditionally are

located in different domains. Through their collaboration they exactly realize the

behavior as specified in the Global Workflow. This kind of decentralized application

is especially suited to scenarios where central management is not desirable, may it be

for social, political or competitive reasons (e.g., public procurement, e-government).

In contrast to the Global Workflow, a Local Workflow is executed on a WfMS.

This kind of process accesses back-end functionality by calling local services and

orchestrates these services according to some workflow logic. In our approach we

focus on the Global Workflow and assume that partners already have implemented

the application functionality they agreed to contribute to the Global Workflow.

3.1.2 Model Views

Our approach is based on two orthogonal views: the Interface View and the Workflow

View. The latter is further divided into the Global Workflow Model (GWfM)

specifying the message exchange between cooperating partners, and the Local

Workflow Model (LWfM) that describes the application and the workflow logic which

is local to each partner. The Interface View describes the interface of every partner

independently of the components’ usage scenario. The application of orthogonal

perspectives allows us to combine the components that provide the services, into

various global Workflows, each one realizing a particular usage scenario.

3.1.3 Interface View

The Interface View represents the contractual agreement between the parties to

provide a set of services. It specifies the minimum set of technical and domain level

constraints and thereby links the GWfM to the LWfM. It describes the interface of

every partner’s services independently of their usage scenario and consists of four

sub-models:

The Document Model is a UML class diagram that describes the data type view of

the partner. We talk of documents because we do not interpret this class diagram in

the usual object oriented setting but in the context of XML schema. The Interface

Model contains a set of abstract (UML-) operations representing services the

component offers to its clients. The types of the parameters are either basic types or

classes in the Document Model. Additionally, pre- and post-conditions (in OCL style)

may specify the behaviour of the abstract services. The Role Model describes the roles

having access to the services and finally the Access Model describes the conditions

under which a certain role has the permission to call a service. The permissions are

written in S

ECTET-PL [27] in a predicative style over the structures of the Document

Model. We provide an in-depth view on model dependencies in [5].

In most cases, when parties agree to realize a Global Workflow, the Interface View

or some of its sub-models already exist as parties may already make some of there

services accessible to the outside world. Very often the Document Model, which

corresponds to the information model and the Interface Model, consisting of method

signatures already exist.

3.1.4 Security in Global Workflows

The security requirements are modeled at the design level and integrated as security

patterns into the models of the Workflow and the Interface View. They are then

translated into executable security components or configuration artifacts for target

architectures. Our framework currently supports the following security patterns:

A. Secure Document Flow (Module S

ECTINO). This pattern allows the

specification of a secure document exchange satisfying “End-to-End Security”, which

means that the requirements are satisfied even in case of being routed via

intermediaries. Documents or parts can be qualified with the requirement of

confidentiality, which is implemented with the help of public key encryption,

Integrity, which means a kind of system signature or non-repudiation of sender or

receiver, which triggers signaling at the protocol layer through the exchange of signed

timestamps.

B. Context Dependent Access Constraints (Module S

ECTET-PL). We specify

conditions under which a specific role has the right to access services in the Access

Model with the help of an extended OCL-style predicate logic [27]. The right to call

an operation of a specific Web service may depend either on the caller’s role or on

parameters that may depend on the system’s environment (e.g., time, IP-Address etc.)

or that are sent together with the service call.

C. Application Domain Specific Security (Module S

ECTET-Extensions). Many

scenarios have to integrate complex security patterns that satisfy complex legal or

business-driven requirements. In most cases they are based on the basic requirements

of confidentiality, integrity or non-repudiation. The Qualified Signature is an e-

government specific requirement that extends the concept of the system signature,

which is used to guarantee integrity to a legal entity (e.g., a citizen). In public

procurement anonymity of bidders is guaranteed by a specific security protocol and in

most cases requires a trusted third party.

3.2 SECTET-Framework Components

3.2.1 Modelling Component

The modeling component comprises a set of tools that supports the collaborative

modeling of the Global Workflow and its security-requirements at the application

domain level in a platform independent context. According to OMG’s paradigm of

Model Driven Architectures (MDA) we specify three levels of abstraction (Fig. 1a):

The Platform Independent Model (PIM) captures the domain level knowledge

and abstracts from implementation details of the target architecture in two respects.

The global process is defined independently of platform technology at partner nodes

(J2EE, DotNet, Corba etc.) and independently of workflow standards like BPEL or

BPSS that may be used to implement local workflow logic. We model the Global

Workflow using UML 2.0 activity diagrams. Security requirements are integrated as

constraints associated to object nodes, which act as a logical container for documents

flowing from partner to partner. Documents and interface signatures are modeled as

class diagrams in the Document and the Interface Model respectively.

The Platform Specific Model (PSM) describes the system on its intended platform

(e.g. BPEL4WS) by integrating platform specific syntax and semantics. Parts of the

global workflow logic are translated into executable stubs in a specific workflow

standard for WfMS at partner nodes. The translation component (Sect. 4.2) generates

the interfaces of the Local Workflows that are accessed by the Global Workflow.

The Implementation Specific Model (ISM) represents the reference architecture

that acts as the runtime environment at local partner nodes. Currently our framework

targets a Web services based reference architecture.

Applying the MDA approach means the transformation of a PIM into a PSM and /

or an ISM. We extend the MDA approach towards Model Driven Security in the

sense that we integrate security requirements at the abstract level into the PIM. The

PIM and the PSM are mapped onto each other and finally translated into

configuration artefacts for the runtime environment.

(a) (b)

Fig. 1. Model Dependencies (a) and Reference Architecture (b).

2´

3. Optional: Conformance Validation through Standard

2´´

Global Workflow Model

UML 2.0

Interface Model

(UML 2.0)

Local Workflow Model

UML4BPEL UML 1.5 Profile

Orchestration Language

(BPEL)

Security Configurations

(XACML, WSPL, WS-Security, …)

Model Level

Runtime Level

PSM

PIM

ISM

Choreography Language

(WS-CDL, BPSS, …)

Security Domain Boundaries

External

Policy

Enforcement

Point

(Security

Gateway)

Token

Processing,

Decryption and

Signature

Validation

Message

Encryption and

Signature

Workflow

Engine

Web Service

Internal

policy

Enforcement

point

Elemental Services

Policy Decision Point

Policy Configuration

Engine

Authentication &

Role Mapping

Authentication Request

Security Compliance

Check

Authorization

Request

Policy

Repository

Internal

PDP

PKI Interface

to Security Token Service

Logging Unit Session Engine

8 9 10

Signature Component

3.2.2 Reference Architecture

The target architecture as depicted in Figure 1 represents the runtime environment for

the Local Workflow and its back-end services at the partner node. The architecture is

based on the data-flow model of XACML [15]. The components implement a set of

XML- and Web services Technologies and standards.

Workflow Component. A workflow engine (1), based on an XML-based

Workflow Language like BPEL orchestrates the sequence of local Web services (2)

calls as specified in the LWfM. The engine bundles the services to a composition that

may be offered to a service of its own. As described above, Global and Local

Workflows are modeled in the PIM and PSM as UML 2.0 diagrams and translated

into runtime artifacts (BPEL files for the Workflow Engine, WSDL-Files for Web

services description) for the target architectures.

Workflow Security. The workflow engine and the Web services in the back-end

are wrapped by security components. So-called Policy Enforcement Points (PEP) act

as security gateways. We differentiate between the external (3) and the internal PEP

(11). The external PEP is the single point of entry into the domain. He is in charge of

implementing requirements related to message integrity, confidentiality and non-

repudiation for all external communication. To this end, it checks the correct

signatures and decrypts incoming requests or response. Correspondingly, the gateway

signs outgoing requests or responses and encrypts them as specified in the global

workflow model. Both, the security gateway and the workflow engine implement the

requirements by configuration. The configuration data is generated from the

respective models views. After receiving a service request the PEP authenticates the

caller with support of the Authentication and Role Mapping Unit (6), checks the

compliance of the incoming message according to signed and encrypted elements (5)

and finally queries the Policy Decision Point (PDP) (4) for access rights. After

successful completion of these three steps, the PEP forwards the request to the

workflow engine (1) which then performs the service orchestration. Optionally, an

internal PEP, that merely acts as a role mapping unit may map the caller’s global role

to some internal role representation required by the back-end applications.

3.2.3 Model Transformation and Code Generation Component

This component has three tasks:

A. Mapping Global to Local Workflows. Those parts of the GWfM that

correspond to interfaces that local process nodes should implement are translated into

stubs of executable process code. In our case study the partners imported the stubs

into Oracle’s Process Manager [28] and added service calls to back end functionality.

B. Generation of Security Artefacts. The security requirements in the PIM are

translated into configuration artefacts for the target architectures. We made the

assumption that every partner wrapped his local node with the security components

specified in the reference architecture.

C. Import and Export of Global Workflows. A choreography which was

specified in a wide-spread standard like WS-CDL or BPSS can be imported into the

framework [29]. The intention is the representation of a global workflow with a

standard that is completely independent of the technical platform. WS-CDL is only

suited to representation of choreographies, that were designed to run on a Web

services based platform. The same can be said about BPSS and ebXML.

3.3 Scenario

The example captures an inter-organizational process in e-government. It is drawn

from a case that was elaborated within the project SECTINO [5]. The project's vision

was defined as the development of a framework supporting the systematic realization

of e-government related workflows.

The workflow “Municipal Tax Collection" describes a Web services based

interaction between three participants: a tax-payer (the Client), a business agent (the

Tax Advisor) and a public service provider (the Municipality). In Austria, wages paid

to employees of an enterprise are subject to the municipal tax. According to the

traditional process, corporations have to send an annual statement via their tax advisor

to the municipality. The latter is responsible for collecting the tax. It checks the

declaration of the annual statement calculates the tax duties and returns a tax

assessment notice to the tax advisor. In our case the stakeholders in this public

administration process agreed to implement a new online service, which enables

citizens and companies to submit their annual tax statements via internet. Due to legal

considerations, the process had to be realized in a peer-to-peer fashion and should

integrate security requirements like integrity, confidentiality and non-repudiation and

ultimately advanced security patterns like the Qualified Signature.

3.3.1 Modelling the Global Process

Table 1. Informal Description of Global Workflow and Security Requirements.

1. Client sends annual statement to Tax Advisor

2. Tax Advisor does internal processing on the document

3. The Tax Advisor forwards the processed annual

statement

4. Municipality calculates tax duties and

5. Municipality returns a notification to Tax Advisor

6. Tax Advisor processes notification

7. Tax Advisor sends tax information to Client

Internal Processing Steps Document flow Interaction Activity

A. Integrity: All exchanged documents have to be signed by

the sending party with a “System Signature” when leaving the

domain boundaries in order to guarantee message integrity.

B. Confidentiality: The annual income and the clientId of

the annual statement and the tax notification are

confidential, and should only be readable to the Municipality

C. Non-repudiation: Receipt of the annual statement and

the notification must not be deniable.

Modeling the global process requires two steps. In a first step the partners had to

agree on a global process scenario they wanted to implement. Table 1 informally

summarizes the Global Workflow. The partners identified three roles (Client, Tax

Advisor and Municipality), four interactions (steps 1, 3, 5 and 7) and four documents

flowing between the partners (annual statement, processed annual statement,

notification and information).

TaxAdvisor

receiveAnnualStatement

sen d P r oce sse d A S

sen d C on firma tion

Munici

alit

receiveProcessedAS

sen d N o ti fica ti o n

«sec urityR equirements»

context processedA S : ProcessedAS :

self.Confidentiality ={

(self.annualIncome ),

(self.clientID)

}

self.Integrity = { (s elf) }

self.NonR epudiation ={ (self) }

processedA S

notification

«se c urityR equ irem ents »

context notification : Notification:

self.Confidentiality ={

(self.annualIncome ),

(self.clientID )

}

self.Integrity = { (self) }

Client

Annual

Statem ent

Inform ation

Fig. 2. Global Workflow Model as UML 2.0 Activity Diagram.

Figure 2 shows the result of step 2: the Global Workflow is specified as a UML 2.0

activity diagram. It describes the collaboration of the three roles in terms of the

interactions in which the participating parties engage. Model information is confined

to "observable behaviour", corresponding to the message flow between the

participants, the interaction logic and the control flow between the elementary actions.

The graphical representation of the Global Workflow as a UML 2.0 activity diagram

allows formalizing the process description in a very intuitive way.

3.3.2 The Transformation Process

The first part of the translation process generates those parts of the Local Workflow

Model which represent the interfaces to the GWfM (e.g., the Interaction-Activities

receiveAnnualStatement and SendProcessedAS) for every partner-role (Fig. 3a).

Those partners who are assigned a specific role in the GWfM take the BPEL code

stubs, import them in the BPEL design tool of their choice (e.g., [28]) and

complement service calls to back-end application. The models can then be translated

into BPEL and WSDL files for the workflow engine with existing tools (e.g., [30]).

<partnerLink name="MS_Provider" partnerLinkType="Municipality_LWfM"

partnerRole="Municipality_LWfM"/>

<partnerLink name="TS_Provider" partnerLinkType="TaxAdvisor_LWfM"

partnerRole="TaxAdvisor_LWfMRequester"

myRole="TaxAdvisor_LWfMProvider"/>

</partnerLinks>

</variables>

<receive name="receiveInput" partnerLink="TS_Provider"

portType="TaxAdvisor_LWfM"

operation="sendAnnualStatement" variable="input" createInstance="yes"/>

<invoke partnerLink="MS_Provider" portType="Municipality_LWfM"

operation="sendProcessedAS" inputVariable="input_MU"

outputVariable="output_MU" name="sendProcessedAS"/>

<invoke name="callbackClient" partnerLink="TS_Provider"

portType="TaxAdvisor_LWfMCallback"

operation="onResult" inputVariable="output"/>

</sequence>

</process>

PolicySet {(target=<AnnualStatement>)

PolicySet { target=<outbound>

PolicySet {(target=<processedAS>)

Policy (Aspect = “Confidentiality”) {

Rule {

Signature-Algorithm = “RSA-SHA1”,

Node1 = “/self/annualIncome”,

Node2 = “/self/clientID”,

Recipient = “Municipality”} }

Policy (Aspect = “Integrity”) {

Rule {

Signature-Algorithm = “RSA-SHA1”,

Node1 = “/self/”,

Recipient = “Municipality”}

}

PolicySet { target=<inbound>

PolicySet {(target=<processedAS>)

Policy (Aspect = “Qualified Sign”) {

Rule {

Signature-Algorithm = “RSA-SHA1”,

Node1 = “/self/”,

Source = “Municipality”

Signatories = 2}

}}}}

(a) (b)

Fig. 3. BPEL File (a) and Security File (b) for Role TaxAdvisor.

Security Components. The second part generates the configuration files for the

security components in the architecture (Fig. 3b). The security requirements in the

constraint box in GWfM (Fig. 2) are translated into an XACML file stored in the

Policy-Repository (7) and loaded into the PCE (5) at runtime in order to determine the

compliance of inbound messages and to identify security mechanisms to be applied to

outbound messages. Figure 4b) shows how the security requirements are translated

into a configuration file for the role

TaxAdvisor. Figure 4 shows the dependency

between the security requirements in the GWfM and the Document-Model of the

Interface View.

4.2 Platform Independent Model and Reference Architecture

Figure 6 shows how the security requirement – namely that the

Notification has to

be signed twice - is represented at PIM-level (once by the

LocalRole SeniorClerk

and once by a

ClericalAssistant). The requirement Qualified Signature in the

Document Model is translated into a corresponding entry into the XACML policy file

(Figure 3b) and is implemented through an additional component in the Reference

Architecture. In case of an appropriate requirement for an outbound message, the PEP

buffers the message, identifies, notifies authenticates the signatory and lets him sign

the message via an applet popping up in his work-place.

<<SecurityRequirement>>

context notification : Notification:

QualifiedSignature =

{

signatory.size() = 2,

Municipality.SeniorClerk,

Municipality.ClericalAssistant

}

«soapBody»

Notification

«dataType»

ResponseComment

«dataType»

ClerkID

«dataType»

ClientID

«documentType»

Notification

Fig. 6. Document Model “Notification” with Security Requirement.

4.3 Conclusion

ECTET implements a comprehensive approach for the model-driven realization and

management of inter-organizational workflows. Future work has to be done in several

directions. The set of supported security requirements has to be extended (e.g., rights

delegation). Additionally, we are currently implementing a testing environment and

working out requirements for efficient change management of inter-organizational

workflows. Positive results in pilot applications with industrial partners encourage us

to further steps.

References

1. W.M.P. van der Aalst.: Loosely Coupled Inter-organizational Workflows. In: Information

and Management 37 (2000) 2, pp. 67-75.

2. D. Basin, J. Doser, T. Lodderstedt: Model Driven Security for Process-Oriented Systems.

In 8th ACM Symposium on Access Control Models and Technologies. ACM Press, 2003.

3. IBM and Microsoft. 2002: Security in a Web Services World. A joint security whitepaper

from IBM Corporation and Microsoft Corporation. April 2002, Version 1.0.

4. Austrian Signature Act (Signaturgesetz - SigG), Art. 1 of the Act published in the Austrian

Federal Law Gazette, part I, Nr. 190/1999.

5. M. Hafner et al.: Model Driven Security for Inter-Org. Workflows in E-Gov. To Appear in:

A. Mitrakas et al. (Eds.) : Secure E-Government Web Services. Idea Group, Inc, 2006.

6. R. Breu et al. : Web Service Engineering - Advancing a New Software Engineering

Discipline. In: D. Lowe, M. Gaedke (Eds.): Web Engineering, ICWE 2005, Sydney,

Australia, July 2005, Proc. LNCS 3579 Springer 2005, ISBN 3-540-27996-2.

7. M. Hafner et al.: Modeling Inter-org. Workflow Security in a Peer-to-Peer Environment. In:

R. Bilof (Ed.): Proc. of the 2005 IEEE International Conference on Web Services, ICWS

2005, Orlando, USA, 2005, IEEE Conference Publishing Services, ISBN 0-7695-2409-5.

8. T. Andrews et al.: Business Process Execution Language for Web Services, Version 1.1. ,

BEA, IBM, Microsoft, SAP, Siebel (2003).

9. OASIS: ebXML Business Process Specification Schema Version 1.01. OASIS, 2001.

10. M. Bernauer et al., “Comparing WSDL-based and ebXML-based Approaches for B2B

Protocol Specification”. In: Proc. of the 1st Int. Conf. on Service-Oriented Computing

(ICSOC), Trento, 2003.

11. A. Arkin: Business Process Modeling Language - BPML1.0, Working Draft, 2002.

12. N. Mitra, N.: SOAP Version 1.2 Part 1: Messaging Framework. W3C Rec. 24/06/2003.

13. Eastlake, D. et al., (eds.): XML-Signature Syntax and Processing. W3C Rec. 14/02/2002

14. Eastlake, D. et al. (eds.): XML Encryption Syntax and Processing. W3C Rec. 10/12/2002.

15. T. Moses et al. (eds.): XACML Profile for Web-Services. XACML Working draft, v.

4/09/2003.

16. P. Mishra et al. (eds.): Conformance Requirements for the OASIS Security Assertion

Markup Language (SAML) V2.0. Committee Draft 02, 24/09/2004.

17. S. Bajaj, et al., :Web Services Policy Framework (WS-Policy). 09/2004.

18. E. Bertino, S. Castano, E. Ferrari: Securing XML Documents with Author X. In: IEEE

Internet Computing 5 (2001) 3, pp. 21-31.

19. D. W. Chadwick: RBAC Policies in XML for X.509 Based Privilege Management. In:

Proc. of the 17th Int. Conf. on Information Security: Visions and Perspectives 2002

20. http://www.eu-trustcom.com/

21. P. Grefen et al.: CrossFlow: Cross-org. Workflow Man. in Dynamic Virtual Enterprises. In:

Int. Journal of Computer Systems Science & Engineering 15 (2000) 5, pp. 277-290.

22. F. Casati and M. Shan: Event-based Interaction Management for Composite E-Services in

eFlow. In: Information Systems Frontiers 4 (2002) 1, pp. 19-31.

23. M. Dijkman, M. Dumas: Service-Oriented Design: A Multi-Viewpoint Approach. Int.

Journal of Cooperative Information Systems 13(4): 337-368 (2004).

24. E. Gudes, M. Olivier, R. van de Riet.: Modelling, Specifying and Implementing Workflow

Security in Cyberspace. In: Journal of Computer Security 7 (1999) 4, pp. 287-315.

25. W.K. Huang, V. Atluri: SecureFlow: A secure Web-enabled Workflow Management

System. In: ACM Workshop on Role-Based Access Control 1999, p. 83-94.

26. J. Wainer et al.: W-RBAC – A Workflow Security Model Incorporating Controlled

Overriding of Constraints. In: International Journal of Cooperative Information Systems. 12

(2003) 4, pp. 455-485.

27. M. Alam et al.: Model Driven Security for Web Services. In: Proc. of the 8th International

Multi-topic Conference (INMIC 2004), IEEE, Lahore, 2004.

28. http://www.oracle.com/technology/products/ias/bpel/index.html

29. J. Mendling, M. Hafner: From Inter-Organizational Workflows to Process Execution:

Generating BPEL from WS-CDL. In conf. and workshop proc. MIOS 2005 . R. Meersmann

et al. (Eds.): LNCS 3762, pp. 305-315, 2005.

30. K. Mantell: From UML to BPEL. IBM-developerWorks, 2003.
