Testing of Semantic Properties in XML Documents

Dominik Jungo, David Buchmann and Ulrich Ultes-Nitsche

telecommunications, networks & security Research Group

Department of Computer Science, University of Fribourg

Boulevard de P

erolles 90, 1700 Fribourg, Switzerland

Abstract. XML is a markup language with a clear hierarchical structure. Vali-

dating an XML document against a schema document is an important part in the

work ﬂow incorporating XML documents. Most approaches use grammar based

schema languages. Grammar based schemas are well suited for the syntax deﬁ-

nition of an XML document, but come to their limits when semantic properties

are to be deﬁned. This paper presents a rule based, ﬁrst order schema language,

complementary to grammar based schema languages, demonstrating its strength

in deﬁning semantic properties for an XML document.

1 Introduction

XML [9] [4] is an easily extensible markup language with a hierarchical structure, read-

able by computers as well as by humans. Own sub languages, can be deﬁned with a so

called schema. A schema deﬁnes the languages syntax and semantics. Syntax means

the hierarchy of the XML elements. The term semantics depends on the expressiveness

of the chosen schema language.

Own sub languages with syntax and semantics deﬁned in a schema can be used as

an exchange or serialisation format for data used in an application. In many cases, XML

data gets from a producer to a consumer, which treats the received XML documents. It is

important to deﬁne clearly the languages syntax and semantics, similar to the deﬁnition

of public methods or functions in libraries, so that the producer and consumer of XML

documents have the same understanding of the document. Different grammar based

languages exist to create these deﬁnitions. DTD (Document Type deﬁntion) [2] was a

ﬁrst attempt for a grammar based schema language. DTD is itself not written in XML,

name spaces are not supported and certain syntactical aspects cannot be expressed.

These points turned out to be a too big disadvantage. W3C designed XML schema [12]

[14] as alternative to DTD and is now widely used to deﬁne the syntax of XML sub

languages. W3C XML schema as well as Relax NG [15] are grammar based schema

languages written in XML itself. The purpose of grammar based schema languages is

mainly to deﬁne a document’s syntax.

The paper is organised as follows. Section 2 shows the limits of grammar based

schema languages justifying why it is necessary to introduce a new kind of schema lan-

guages. One of these new kind and more powerful languages, CLiXML, is introduced

and explained more detailed in Section 3 using an example. Section 4 shows some al-

ternatives to CLiXML and ﬁnally Section 5 concludes this paper.

Jungo D., Buchmann D. and Ultes-Nitsche U. (2006).

Testing of Semantic Properties in XML Documents.

In Proceedings of the 4th International Workshop on Modelling, Simulation, Veriﬁcation and Validation of Enterprise Information Systems, pages 38-46

DOI: 10.5220/0002484500380046

 SciTePress

2 Limits of Grammar Based Schema Languages

Grammar based languages are well suited for a languages syntax deﬁnition, but reach

quickly their limits when they are used to deﬁne semantic properties of an XML doc-

ument. In the case of grammar based schema languages, semantics means specifying

data types of attribute values. W3C XML schema knows simple and complex data types.

Elements, Comments and Text belong to complex data type. Attribute values, compa-

rable to simple data types, such as integers or strings, in programming languages, are

simple data types. Complex data types can be extended using choices and sequences.

Simple types can be adapted using restrictions, enumerations and regular expressions.

This approach lets one deﬁne only a very limited set of semantics properties.

Let us illustrate the restricted schema capabilities with an example. Listing 1 shows

an XML representation of an oriented labeled loop free graph respecting referential

integrity. Referential integrity means that each edge is connected to an existing vertex.

The graph consists of a list of vertices. Each vertex has a label (identiﬁer, attribute id)

and a list of edges from the vertex to other vertices, deﬁned by the to attribute in the

edge element. These syntactical properties can be easily deﬁned by a grammar based

schema.

<graph>

</vertex>

...

</graph>

Listing1. An XML representation of an oriented labeled loop free graph.

Consider the case of writing an application which expects as input an oriented loop

free connex graph respecting referential integrity, in XML format, from an external

source. We cannot trust this external source to deliver graphs as expected. Our applica-

tion that treats these documents only works ﬁne if the input document meets the given

requirements. Hence we have to test the XML documents if they represent a graph that

is oriented, loop free, connex and respecting referential integrity prior to the treatment

within the application. This can happen using either the host language, the language

in which the XML treating application is written, or using a schema document and a

schema validator which checks whether the document meets all requisites speciﬁed in

the schema document. Using a schema has the advantage that it can be negotiated be-

tween the document provider and the user before writing any applications. The schema

document acts as an interface descriptor or contract between provider and consumer.

Both parties, the provider and the consumer, can check the XML documents against the

same schema.

Properties being well formed and having a valid semantics can be tested using gram-

mar based schema. The documents correct structure, i.e. whether the labels are integer

and unique values, whether the graph element contains only vertex elements, the vertex

elements contain only edges an so on, can be veriﬁed with an XML schema. Semantic

properties, like testing whether the graph is connex, loop free and is respecting refer-

ential integrity cannot be tested using W3C XML schemas. W3C XML schemas are

missing powerful constructs letting deﬁne required relationships between any compo-

nents within the XML document. Roberts [10] describes it as missing cross-ﬁeld checks

such as ”if element x contains value y then element z should be mandatory”. W3C

schema grammars allows only to deﬁne which element x can appear as child of element

z, but any other conditions than parent-child relationship cannot be expressed. Hence a

new kind of not grammar based schema has to be introduced. The solution therefore are

rule based schemas. Section 3 gives a short introduction to the most outstanding rule

based schema language: Constraint Language in XML (CLiXML). Unlike grammar

based schema languages, rule based schema languages have a much simpler structure.

A rule based schema consists of a list of rules. Each rule has an output part which will

be outputted by the schema validator when the rule succeeds, respectively fails and the

rule itself, which contains constraints and restrictions of the XML document, and its

content, i.e. required relationships between its content.

3 Testing of Semantical Properties in XML Documents

W3C XML schema cover basically syntactical properties. So only semantical proper-

ties have to be tested by the newly introduced language, since it does not assert it’s

claim to be an all-in-one language suitable for every purpose, doing work already done

by W3C XML schema. All grammar based rules show that their template-like structure

is cumbersome and hindering to describe semantical properties. They let only deﬁne a

parent child relationship. In the language described here, CLiXML, another approach is

used. Nodes (elements, attributes, text, comments) are selected by an XPath [3] expres-

sion and constraints are set up on, respectively between the selected nodes. XPath is the

language deﬁned by W3C to select nodes of an XML document. Selections are made

using a regular expression inspired language, adopted for XML’s tree structure. XPath

requests result in lists. Hence using ﬁrst order logic expressions seems to be quite a

natural approach.

Quantiﬁers forall and exists contain a predicate variable (variable name and an

XPath expression to select a list of nodes). The quantiﬁer contains a further quantiﬁer, a

logical predicator (equal, less, bigger...) or a logical operator (and, or, not, ...). Predica-

tors are binary. This means that predicator elements contain two attributes op1 and op2,

which are both related together by the predicator. Logical operators are elements that

group operators, predicators or quantiﬁers. Nested quantiﬁers and predicators can use

the preliminarily deﬁned variable to specify the needed relationships between the se-

lected nodes; i.e. inner quantiﬁers can deﬁne XPath expressions relative to the selected

node or comparators can use the selected node and compare it with another one. The

quantiﬁers act like iterators when being evaluated. In each iteration step, the predicate

variable takes one value from the list. A forall test succeeds only if the nested test suc-

ceeds for all iteration steps. Exists succeeds if the nested test succeeds for at least one

iteration step.

CLiXML was speciﬁed by Systemwire [1]. Systemwire integrated their implemen-

tation of CLiXML into a commercial product but published the languages XML schema

on their website. An open source version [7] of CLiXML, corresponding to the XML

schema, is being implemented by one of the authors of this paper. The open source

implementation is also used in the VeriNeC project [13] [8] [6].

Let us illustrate the language’s power using our example from Listing 1. Among

others, we required that the graph fulﬁlls referential integrity. I.e. each edge leads to an

existing vertex. In other words, for all edge destination id’s there must exist a vertex

such that the edge destination id is the same as the vertex id. Or mathematically:

∀e ∈

′

/graph/vertex/edge

′

, ∃v ∈

′

/graph/vertex

′

: $e/@to = $v/@id.

This can be translated into the CLiXML rule illustrated in Listing 2.

<report>edge leads to non existing vertex</report>

</exists>

</forall>

</rule>

Listing2. An referential integrity CLiXML rule.

One could argue that the id and idref types from XML schema are able to describe

exactly this scenario. But when using different elements with id attributes, XML schema

can only test if the referenced ids exist, but not if they exist where they are expected.

Listing 3 shows a graph with labeled edges, where the edge labels are also id attributes.

In this case schema is not able to make a difference between ids of a vertex and ids of an

edge. So it would be possible to deﬁne an edge connected to another edge if we would

just rely on W3C schema.

<graph>

</vertex>

...

</graph>

Listing3. An XML representation of an oriented labeled loop free graph with labeled edges.

Testing whether the graph is loop free can be done using the label property in an

oriented graph. For all vertices srcV and for all edges within the vertex srcV, named

dst, it must hold that the id of the source Vertex srcV is strictly smaller than the “to”

attribute of the destination vertex dst.

Or mathematically:

∀srcV ∈

′

/graph/vertex

′

, ∀dst ∈

′

$srcV/edge

′

: $srcV/@id < dst/@to

Listing 4 shows the CliXML rule which tests whether the graph is loop free or not.

<report>graph is cyclic</report>

</forall>

</rule>

Listing4. An CLiXML rule that checks for loop freeness.

Finally, checking whether the graph is connex can be done checking whether all vertices

are reachable, except the vertex with the smallest id. In words, for all vertices, there exist

an edge leading to it, or the vertice is the ﬁrst.

∀v ∈

′

/graph/vertex

′

, ∃e ∈

′

/vertex/edge

′

: $v/@id = min(/vertex/@id) ∨

$v/@id = $e/@to

<report>graph is not connex</report>

<or>

</or>

</exists>

</forall>

</rule>

Listing5. Listing: An CLiXML rule that checks whether the graph is connex.

Listing 5 shows the rule that checks whether the graph is connex.

3.1 Macros

CLiXML offers the possibility to write own macros. A macro is a template like struc-

ture. A macro is deﬁned by a name, contains a list of parameters and a macro body. A

macro can be called with a macro call element, containing a list of parameters. When

a macro is called, the caller element is replaced by the deﬁnition body, with the vari-

ables replaced by it’s parameters within the macro body. Macros can contain calls to

other macros or to themselves. On a macro call, macro’s are always evaluated by one

level. Only when coming to the evaluation of a macro call in the body of the previously

replaced macro, the macro is replaced by the next level. This level by level evaluation

allows to write recursive macros.

3.2 User Deﬁned Functions

Where CLiXML predicates, quantiﬁers and macros are not enough, one can introduce

own validator functions. Therefore the validator has to be extended and these functions

are only usable in the validator they were written for. Open CLiXML offers an interface

which functions must implement. But these functions cannot be used on other imple-

mentations using another mechanism for user deﬁned functions.

A function contains a name which is passed by an attribute and function parameters

by a list of elements. Implementing own functions should be avoided, wherever pos-

sible, since own function implementations depend on validators implementation and

cannot be passed as easily as the schema document. Using the example graphs, lets

choose colored graphs and decide whether the number of used colors equals the graphs

chromatic number. This would be a candidate to be expressed in a user deﬁned func-

tion since macros are not adapted to do things that are that complex as determining the

chromatic number.

4 Alternatives to CliXML

This section gives a short overview of alternatives for CLiXML allowing to deﬁne se-

mantic properties.

4.1 Using a Host Language

One alternative to check the XML Document’s semantical validity is surely doing this

by own written functions in the host language of the application, using or building up

the XML document. By doing so, one loses the independence of host systems. XML’s

strength is its independence from programming languages and systems, and it is not in

XML’s sense to hard code a semantics validator. Creator and consumer have to agree

on the same validating function. When one side uses another host language, they have

to write their own validator and it is not guaranteed that it behaves as the other side’s

validator. Another consequence using the host language instead of a schema document

is, that one is losing the schema as contract document. One should be discouraged from

hard coding the document’s semantics in a host language language.

4.2 Schematron

As alternative to CLiXML, there exists Schematron [5]. Schematron is a rule based

schema language also using XPath expressions, very similar to CLiXML. Reference

implementation is written in XSLT. This is a very interesting concept, since it can be

employed wherever an XSLT processor exists. Schematron’s drawback is that it is not

very strongly structured. Instead of splitting up rules into hierarchically nested ele-

ments, it uses a ﬂat structure. The whole complexity of a rule lies within a single at-

tribute containing an own language paired with XPath. Hence recursive deﬁnitions are

not possible. It is proposed to use javascript or any other wrapper language

to elim-

inate this drawback. Schematron’s drawbacks rise from a too simple and ﬂat language

structure, but allow an XSLT implementation.

language which calls the validator

4.3 OASIS Content Assembly Mechanism

Content Assembly Mechanism (CAM) [11] was speciﬁed by the OASIS group. It aims

to be a system to deﬁne, validate and compose XML documents. Unlike CLiXML, it

is quite complex since it was designed for more tasks than CLiXML. CAM contains a

part with rule based schemas. In CAM they are called business rules. The business rules

are similar ﬂat structured as rules in schematron with the same drawbacks. Recursive

structures are missing. This makes CAM less powerful in expressing semantic rules than

CLiXML. Constraint actions (see Listing 6) catches the readers eyes, when browsing

the CAM tutorials.

Listing6. A CAM constraint action.

The action attribute contains a java or c like function call with an XPath parame-

ter. Such structured, nested content within one attribute is an indicator for improper

language design. Having a closer look at the schema deﬁnition of CAM makes our

skepticism stronger. The action attribute is declared as an unstructured string, but in the

tutorials described as a c-like function call. Listing 7 shows a proper suggestion split-

ting up function name and XPath parameter into own attributes for improvement. The

function like structure from Listing 6 has been apparently chosen, to keep the deﬁni-

tion part simple and the language easily readable by humans. But this introduction of

unstructured data makes it more difﬁcult to be treated by an application. CAM offers a

much longer list of useful predicates than CLiXML or Schematron do. CAM is used by

a community, including people from industry.

Listing7. A proposal for a proper CAM constraint action.

5 Conclusion

CLiXML has been used by the autor of this paper to deﬁne acceptable event series in

simulation log ﬁles [8]. By using CLiXML we experienced that CLiXML is working

ﬁne for strongly nested documents, but is rather clumsy for ﬂat structure XML ﬁles.

Coming back to our graph example, using a structure as in Listing 8 complicates

things a lot. We have to use recursive macros and things gets unnecessarily compli-

cated, when a ﬂat structure is chosen. Taking a well adapted XML structure reduces

complexity for the schema as well as for the application treating the data.

<graph>

...

...

</graph>

Listing8. An alternative XML representation of a graph.

CLiXML speciﬁcations are not everywhere as precise as they should. This impre-

cise speciﬁcation let the risk of not being compatible with the original CLiXML im-

plementation. Details about how a macro is called are missing and the report output

is completely open too. The macro calls are made from the Macro namespace. But a

schema belonging to this namespace is missing. An own schema has been introduced

there. The CLiXML schema itself was in some minor points not W3C schema compli-

ant and needed adjustment. As a help to understand why a test failed, the open source

implementation of CLiXML offers the possibility to add a stack trace to the report,

showing which part of the rules failed and which succeeded. Quantiﬁers show in the

stack trace which values a variable has taken during testing a document. Stack traces

including variables has turned out to be useful.

This paper presented the relevance of schema documents in the work ﬂow process

where XML data is used. The limited capabilities for describing semantics using a

schema document were explained using the graph example. Finally the rule based

schema language, CLiXML was explained and compared to other rule based languages.

References

1. Clixml speciﬁcation. Technical report, Systemwire.com, http://www.clixml.org/spec.html,

2003.

2. Jon Bosak, Tim Bray, Dan Connolly, Eve Maler, Gavin Nicol, C. Michael Sperberg-

McQueen, Lauren Wood, and James Clark. Guide to the w3c xml speciﬁcation (xmlspec)

dtd, version 2.1. Technical report, W3C, http://www.w3.org/XML/1998/06/xmlspec-report.

3. James Clark and Steve DeRose. Xml path language (xpath). Technical report, W3C,

http://www.w3.org/TR/xpath, 1999.

4. Elliotte Rusty Harold and W. Scott Means. XML in a Nutshell. O’Reilly, Sebastopol, 3rd

edition, 2004.

5. Rick Jelliffe. An xml structure validation language using patterns in trees. Technical report,

Academia Sinica Computing Centre, http://xml.ascc.net/resource/schematron, 2005.

6. Dominik Jungo. The role of simulation in a network conﬁguration engineering approach.

In ICICT 2004, Multimedia Services and Underlying Network Infrastructure, Cairo, Egypt,

2004. Information Technology Institute.

7. Dominik Jungo. Open clixml. Technical report, University of Fribourg,

http://clixml.sourceforge.net/, 2005.

8. Dominik Jungo, David Buchmann, and Ulrich Ultes-Nitsche. A unit testing framework for

network conﬁgurations. In Proceedings of the 3rd International Workshop on Modelling,

Simulation, Veriﬁcation, and Validation of Enterprise Information Systems (MSVVEIS 2005),

Miami, Florida, USA, 2005. INSTICC Press.

9. Liam Quin et al. Extensible markup language (xml). Technical report, W3C,

http://www.w3.org/XML/, 1996-2003.

10. Martin Roberts. jcam. Technical report, CAM, http://jcam.org.uk/, 2006.

11. OASIS CAM TC. Oasis content assembly mechanism (cam) tc. Technical report, OASIS,

http://www.oasis-open.org/committees/tc home.php?wg abbrev=cam, 2004.

12. Henry S. Thompson, David Beech, Murray Maloney, and Noah Mendelsohn. Xml schema.

Technical report, W3C, http://www.w3.org/TR/xmlschema-1/, 2004.

13. Ulrich Ultes-Nitsche, Dominik Jungo, and David Buchmann. Veriﬁed network conﬁgu-

ration. Technical report, University of Fribourg, http://diuf.unifr.ch/tns/projects/verinec/,

2004–2005.

14. Eric van der Vlist. XML Schema. O’Reilly Media, Inc., 2002.

15. Eric van der Vlist. RELAX NG. O’Reilly Media, Inc., 2003.
