Semantic Web Services Composition for the Mass

Customization Paradigm

Yacine Sam

, Omar Boucelma

and Mohand-Sa

ıd Hacid

LSIS–CNRS, Universit

e Aix-Marseille 3, Domaine Universitaire de Saint-J

ome.

Avenue Escadrille Normandie-Niemen, 13397 Marseille Cedex 20, France

Universit

e Claude Bernard Lyon 1.

43, boulevard du 11 Novembre 1918, 69622 Villeurbanne cedex, France

Abstract. In order to fulﬁll current customers requirements, companies and ser-

vice providers need to supply a large panel of their products and services. Re-

cently, this situation has led to the Mass Customizing Paradigm, meaning that

products and services should be designed in such a way that makes it possi-

ble to deliver and adapt different conﬁgurations. The increasing number of ser-

vices available on the Web, together with the heterogeneity of Web audiences,

are among the main reasons that motivate the adoption of this paradigm to Web

services technology.

In this paper we describe an approach that allows automatic customization of

Web services: a supplier conﬁguration, published in a services repository, is auto-

matically translated into another conﬁguration that is better suitable for fulﬁlling

customers’ needs.

1 Introduction

The Web is not only an enormous warehouse of text and images, its evolution made

it also a services provider [14]. The Web service concept refers to an application ad-

vertised over the Internet and made accessible to services requesters through standard

Internet protocols. Currently available examples of Web services are weather forecast-

ing, online tickets reservation, banking services, etc. Roughly speaking, Web services

are deﬁned as well deﬁned, loosely coupled software components and constitute there-

fore a new paradigm for applications integration [5].

Web services are currently implemented through three standard technologies: WSDL

[21], UDDI [19] and SOAP [17]. These standards provide only syntactical interop-

erability that prevents agents for automating services discovery, selection and com-

position tasks. The semantic Web provides standards for representing and processing

computer-interpretable information [1, 6]. Semantic Web services are then a synthesis

of these two standards and constitute therefore a good proposal for the automation of

the various tasks of Web services life cycle.

Semantic Web services descriptions relay on Web services annotations with terms

having a formal description in structured dictionaries called ontologies. DAML+OIL [7]

is a logic-based language intended to the description of Web services. It is used directly

Sam Y., Boucelma O. and Hacid M. (2006).

Semantic Web Services Composition for the Mass Customization Paradigm.

In Proceedings of the 1st International Workshop on Technologies for Collaborative Business Process Management, pages 52-61

 SciTePress

or through DAML-S [2]. DAML-S is a DAML+OIL concepts ontology describing the

technical aspects of a Web service (Inputs/Outputs parameters, data types, etc). OWL

[15], an evolution of DAML+OIL, was recently standardized by the W3C [20]. OWL

is now the main standard language for Web ontologies description and OWL-S is the

corresponding evolution of DAML-S.

Other languages represent interesting solutions for automatic Web services discov-

ery, selection and composition. One can quote GOLOG [10] and LARKS (Language for

Advertising and Requesting for Knowledge Sharing) [18]. The latter is a frame based

language for semantic Web services discovery and selection. The former is a Situation

Calculus Language and was adapted in [13] for Web services composition.

In this paper, we build on LARKS to elaborate a Web services customization frame-

work. Mass Customization Paradigm [9] is a principle which considers that products

must be conceived in such a way that makes it possible to satisfy various needs. Expo-

nential proliferation of services provided through the Web and the cosmopolitan aspect

of Web users justify the Mass Customization Paradigm for Web services.

We propose a framework that allows the automatic customization of Web services.

The basic idea is to automatically transform services published in the services directo-

ries in order to generate suitable conﬁgurations for answering client needs. The goal of

the automatic transformation, based mainly on the dynamic composition of Web ser-

vices, is twofold. On one hand, the construction task of a given service becomes easier

for the providers. On the other hand, the requesters will be able to obtain services in the

alternatives that can satisfy their preferences, even if they are not explicitly present in

the services directory. Thus, service providers publish only one explicit conﬁguration of

a given service, the others are dynamically and automatically infered from the services

directory.

The rest of this paper is organized as follows: we provide, in Section 2, a motivating

example that illustrates customer requirements for customizable Web services. Section

3 presents LARKS and its use for advertising and requesting for Web services. In Section

4, we develop our approach to Web Services customization. We ﬁrst propose a new

structure for semantic Web services that allows, in contrast to LARKS, customization

of services customization. We then describe the matchmaking process, and ﬁnally the

automatic Web services customization algorithm. We conclude in Section 5.

2 Motivating Example

Each year, ”La F

ete de la lumi

ere” (Light Celebrates) is the most important traditional

popular celebration in Lyon (a French city). Before traveling to Lyon, a Japanese tourist

wants to obtain information about the available Hotels in Lyon and their fees. Thus, he

sends his request to a Web directory which stores this information in the form of Web

services, expecting to ﬁnd a Web service execution that can satisfy the request.

After the request processing, the services directory seems to be unable to satisfy

the information required by the japanese customer. Indeed, the services turned over

describe Hotels in French with their fees in Euro. This makes them useless for the

customer, which understands only the Japanese language and uses the local currency :

Yen. This scenario shows that the request cannot be satisﬁed, though the Web service

exists in the directory, but in an incompatible conﬁguration.

The framework we propose allows transformation of Web services. The basic princi-

ple of the Web service transformation consists in dynamically calling two intermediate

Web services. The ﬁrst will translate the Hotels descriptions from French to Japanese

and the second will transform the fees from Euro to Yen. The answer to the request

will then be built by the coordination of these two intermediate services and the service

initially available in the directory.

3 Larks Language

LARKS is an advertising and requesting language for Web services [18]. In LARKS,

services and requests are both speciﬁed in the form of a frame. The frame’s attributes

are described hereafter:

– Context : it represents a keyword describing what the service does.

– Types : deﬁnition of the abstract data types used in the speciﬁcation.

– Input/Output : declaration of the Input/Output variables of the service.

Context and Input/Output attributes can be annotated by machine-interpretable con-

cepts stored in the attribute ConcDescription.

– InConstraints/OutConstraints : logical constraints on the Inputs/Outputs. These

constraints can be restrictions on the Inputs/Outputs values or logical constraints

between the service Inputs/Outputs.

– ConcDescripton : formal description of the concepts being used for the semantic

annotation of the context and the Inputs/Outputs of the services. The association of

a concept C to a word (Context or Input/Output) w is noted w*C, which means that

the concept C is the formal description of the word w. The use of formal ontologies

in LARKS makes it possible to semantically describe Web services. Ontologies can

be described formally with concept languages like ITL [4], LOOM [12] or KIF [3].

– TextDescription : textual description of the service requester needs or what a ser-

vice provider can offer.

In LARKS, the constraints are used to restrict the values of an Input/Output. How-

ever, the assignment of a measuring unit to an Input/Output can only be speciﬁed by

semantic annotations using extensional formal concepts. Extensional concepts are sets

of instances (objects) used, in this case, to capture the set of Input/Output’s measuring

units. During the Web Services matchmaking process in LARKS, the comparison of the

two different concepts EURO and YEN (See Figure 2) will fail. Indeed, no knowledge

is available to capture the fact that these two concepts can be made comparable (pro-

viding a conversion). Consequently, no Web services transformation is possible in this

language.

In the following we propose a new Web services structure which constitutes the

foundation for the customization process. It allows a service directory to detect, during

the matchmaking process, that two concepts (measuring units) can be convertible by

another service. Doing so, we avoid immediate failure of the matchmaking process.

From now, the term service is used to refer to a service offered by a service provider,

and the term request refers to a service requested by a client.

4 Web Services Customization

This section introduces a new semantic Web services speciﬁcation structure, the match-

making process associated to it and the Web services customization.

4.1 A New Structure for Web Services

The structure we propose in this paper is used to specify both the services and the

requests. It is made up of two subsystems : the Structural System, and the Constraints

System.

The Structural System (SS). The SS is deﬁned by the triple (C, I, O). C is the context

of the speciﬁcation, it is deﬁned by a keyword related to the speciﬁed service. I and

O are respectively the description of the Input/Output variables and their abstract data

types in a service or in a request. In Figure 1, the abstract data type of the attribute price,

that represents the price of a book, is Real in the Output of the service speciﬁcation.

The keywords of the triple (C, I, O) can be annotated by formal concepts deﬁned in an

ontology, which we consider to be shared between all the users of a speciﬁc domain.

Example 1 Figure 1 illustrates the SS of a books-sale service. It is described by its

context ”Book” and its Inputs/Outputs ”your-book”/(”Price”, ”presentation”). The

Output parameters ”Price” and ”Presentation” are annotated by the concepts Price

and Description respectively.

C Book

I Your-Book:String

O Price*Price:Real, Presentation*Description:String

Fig.1. A Structural System Example.

The formal concepts Price and Description – see Figure 2 – are used to assign

types to the Web service Inputs/Outputs Price and Presentation respectively. By the

Inputs/Outputs’ types we do not mean the abstract data types (Integer, Real, etc), but the

measuring units used to express the values of the Inputs/Outputs in the domain ontology.

In Figure 1, the measuring unit of the Output Price is deﬁned by the concept Price

which corresponds to a set of currencies : Dollar(USD), Euro(EUR) and Yen(YEN) in

the ontology.

Note that the fact that the concept Price contains several measuring units can seem

inconsistent since an attribute value can only have one measuring unit at time. However,

the annotation with this kind of concepts (sets of measuring units) is used only for one

partial service matchmaking that determinates the services likely able to satisfy the

request. There is a second service matchmaking stage where only the services being,

effectively, able to satisfy it will be selected.

Price = Money

Money = (and Real (all in-currency aset(USD, EUR, YEN)))

Euro = (and Real (all in-currency aset(EUR)))

Yen = (and Real (all in-currency aset(YEN)))

Dollar = (and Real (all in-currency aset(USD)))

Description = Language

Language = (and String (all in-currency aset(English, French, Japanese)))

Japanese = (and String (all in-currency aset(japanese)

French = (and String (all in-currency aset(French)

Fig.2. Examples of formal concepts deﬁned in ITL language.

The Constraints System (CS). The CS allows the speciﬁcation of two kinds of con-

straints : constraints on the values of the Inputs/Outputs and constraints on their type-

sin the domain ontology (typing constraints). The CS is deﬁned by the quadruplet

, O

, I

, O

) where the elements are sets of constraints on the Input types, Output

types, Input values and Output values respectively.

In this paper, we focus on typing constraints that allow to specify the measuring

units of Input/Output values in the the speciﬁcations of services. The typing constraints

can be regarded as the specialization of the concepts used at the time of semantic an-

notation level of the SS. The role of the typing constraints is to specify by exactly one

type (measuring unit) each Input/Output. The following example illustrates this issue.

According to Figure 2, the concept Price is equivalent to the concept Money which

is an extensional concept containing sets of currencies. If the user (service provider)

wants her/his service fees in a particular currency unit, an additional knowledge must

be added to the service speciﬁcation. Thus, she/he must annotate the service in the CS

with a more specialized concept than Price. It can be, for example, the concept Yen if

the user wants the fees in Yen (or the concept Euro if the provider can offer the service

in Euro).

price = EURO

Description = French

Fig.3. Typing Constraints.

Context H

otel

I Location : String

O Price∗Price : Real,

Presentation∗Description : String

Price=Euro

Description=French

Fig.4. A motivating example in our new

structure for Web services.

Figure 3 shows two typing constraints corresponding to the SS in Figure 1 that a

requester/provider can specify in the CS. With such constraints, the requester/provider

can offer the necessary details on the values of the service Inputs/Outputs, i.e., in only

one measuring unit. Figure 4 shows a fragment of a service description corresponding to

our motivating example. It is speciﬁed using our structure for Web services description.

4.2 Web Services Matchmaking Process

In our service structure, the Web services matchmaking process involves two steps and

consists in determining if the customer’s request can be satisﬁed by the services ad-

vertised in a services directory. During the ﬁrst step, the component of the directory in

charge of the matchmaking process performs a syntactic comparison of the keywords

describing the request triplet (C, I, O) with the triplets (C

′

, I

′

, O

′

)

of each available

service in the directory, and performs semantic comparison of the associated concepts.

A service is considered as an answer to a request if its context and Inputs/Outputs

are similar to those of the request with a similarity threshold that can be deﬁned within

the directory. At the end of this step, a set of services likely to be able to satisfy the

customer request is selected.

The second step dependents on the success of the matchmaking process during the

ﬁrst step, i.e., the ﬁrst step must return at least one service in order to pass to the sec-

ond step of the matchmaking process. This second step consists in the comparison of

the CS of the request and the CS of the selected services in the ﬁrst step. This step

also comprises two stages : (1) the comparison of the Input/Output typing constraints,

and (2) the comparison of their (value) constraints. We will illustrate in what follows

the matchmaking process of Inputs/Outputs typing constraints. The matchmaking of

Inputs/Outputs value constraints can be performed by constraint satisfaction algorithms

[11].

If all the Inputs/Outputs types of the request and those of a service have similar

measuring units, then there is no conﬂict and the matchmaking process continuous with

their Input/Output values constraints. If at least an Input/Output has two different mea-

suring units in the request and in a service, then a typing conﬂict appears. The typing

conﬂict between a request’s Input/Output and a service’s Input/Output means that the

service cannot (a priori) satisfy the request. However, this does not draw aside this ser-

vice deﬁnitively since it may happen that the conﬂict can be solved.

Deﬁnition 1 (Cover axiom) Let A

, A

, ..., A

be a set of formal concepts. A cover

axiom is an assertion of the form A := A

∨ A

∨ ... ∨ A

, which means that the

concepts A

, A

, . . . , A

are all sub-concepts of the concept A.

The cover axiom represents knowledge allowing the distinction between the con-

cepts being able to lead to typing conﬂicts and the other ones. An axiom is associ-

ated with each extensional concept being able to cause a conﬂict in the domain ontol-

ogy. In the example of Figure 1, the concept Price (equivalent to the concept Money)

can constitute the head of one cover axiom, because the price of a product can be

speciﬁed in several different currencies. Thus, we will have the axiom Money :=

EURO ∨ Y EN ∨ . . . ∨ DOLLAR.

Deﬁnition 2 (Typing conﬂict) Let C be a set of concepts described in an ontology,

x, y, z three extensional concepts deﬁned in C, and the two constraints:

x = y (Request typing constraint)

x = z (Service typing constraint)

If y 6= z ∧ (∃ c ∈ C | y ⊑ c ∧ z ⊑ c), and if there is a cover axiom c := y ∨ . . . ∨ z

then there is a conﬂict due to the difference between the measuring units of the

Input/Output x in the request and in the service.

When conﬂicts between a request and a service are revealed, the process of retriev-

ing some services able to solve them starts. The semantics of a conﬂict resolution is

the transformation of the Web service conﬁguration available in the directory into the

conﬁguration required by the service requester.

4.3 Web Services Customization Process

The matchmaking process between a request and a service can reveal several typing

conﬂicts between their Inputs/Outputs. We use the Web services composition as a

mean for conﬂict resolution. In other words, we propose a mechanism that allows to

transform advertised services in order to be compatible with the requirements of the

service requester.

Our approach exploits services able to solve only one conﬂict. In order to obtain

the context (keyword) for the conﬂict resolution service, we deﬁne a set of rules called

Context Association Rules. Thus, for each domain ontology, a set of rules is deﬁned and

stored in the services directory – one rule for each concept that can generate a typing

conﬂict.

Deﬁnition 3 (Context Association Rule) A Context Association Rule is a binary pred-

icate ConﬂictResolution(Concept, Context). ”Concept” is a variable representing ex-

tensional concepts deﬁned in a domain ontology and belong to the head of one cover

axiom. ”Context” is a variable intended to receive the context (keyword) of the conﬂict

resolution service.

A typing conﬂict is induced by the difference between two concepts, both subsumed

by the same concept appearing in the ﬁrst argument of one ConﬂictResolution predi-

cate. The two conﬂicting concepts are recovered from the annotation concepts of the

same Input/Output in a request and in a service.

Example 2 Figure 5 shows two context association rules in relation to the ontology

of Figure 2. The ﬁrst rule associates the concept Money to the keyword (context) of

the currency conﬂict resolution service : ConversionMoney. The second associates the

concept Language to the keyword of presentation language conﬂict resolution service:

Translation.

The context of the service to call in order to solve an Input/Output typing conﬂict

is extracted by exploring the context association rules. Indeed, the predicate ”Conﬂic-

tResolution” having as ﬁrst argument the concept causing the conﬂict and as second

argument a variable indicating the name of the conﬂict resolution service, will be sent

to the set of context association rules. The context of the conﬂict resolution service is

ConﬂictResolution(Money, ConversionMoney)

ConﬂictResolution(Language, Translation)

Fig.5. Context Association rules.

determined by the substitution of the variable Context by a keyword (context) appearing

in one of the context association rules (see Figure 5). This is done through the terms

uniﬁcation algorithm [16].

The Inputs/Outputs of the conﬂict resolution services are obtained following two

cases, whether the conﬂict relates to an Input or to an Output. When a conﬂict occurs

between the Input of a request and the Input of a service s, the Input of the conﬂict

resolution service is the Inputs of the service s, and its Output is the Inputs of the

request. If the conﬂict is caused by the Output of a request and the Output of a service

s, the Input of the service to be called takes the Outputs of the service s, and its Output

takes the Outputs of the request.

The service to be called will convert the values of the Inputs/Outputs of the orig-

inal service in order to make them comparable with those of the request. The values

of the Inputs/Outputs to convert will be passed to the conﬂicts resolution services in

the service invocation phase. Then, the values of the Inputs/Outputs of the request and

those of the service are made comparable (based on a same measuring unit). This al-

lows to pursue the matchmaking process with the veriﬁcation of the non-contradiction

of the Input/Output value constraints of the request and the service causing the conﬂict.

The Input/Output value constraints matchmaking makes it possible to select the ser-

vices able to answer the request. All these matchmaking steps that allow Web services

customization by dynamic composition of other services are illustrated in Algorithm 1.

5 Conclusion

In order to be able to provide products in a more and more global market, companies

must vary their products according to the customers requirements. To achieve this, they

must change their paradigm from products intended to a large audience of customers to

customizable products. This new paradigm is called Mass Customizing Paradigm [8].

We adapted this paradigm to Web services in order to provide a framework allowing to

automatically satisfy the customer requirements in terms of customizable Web services,

while avoiding to the service providers the heavy task of building speciﬁc conﬁguration

for each customer.

References

1. T. Berners-Lee, J. Hendler, and O. Lassila, editors. The Semantic Web. May, 2001.

Concept for the semantic annotation of request Input

Concept for the semantic annotation of service Input

Concept for the semantic annotation of request Output

Concept for the semantic annotation of service Output

2. M. H. Burstein, J. R. Hobbs, O. Lassila, D. L. Martin, D. V. McDermott, S. A. McIlraith,

S. Narayanan, M. Paolucci, T. R. Payne, and K. P. Sycara. Daml-s: Web service description

for the semantic web. In Horrocks and Hendler [6], pages 348–363.

3. M. R. Genesereth. Knowledge interchange format. In KR, pages 599–600, 1991.

4. N. Guarino. A concise presentation of itl. In PDK, pages 141–160, 1991.

5. G. Hohpe. Web services: Pathway to a Service Oriented Architecture. Thought Works, Inc.,

2002.

6. I. Horrocks and J. A. Hendler, editors. The Semantic Web - ISWC 2002, First International

Semantic Web Conference, Sardinia, Italy, June 9-12, 2002, Proceedings, volume 2342 of

Lecture Notes in Computer Science. Springer, 2002.

7. I. Horrocks, P. F. Patel-Schneider, and F. van Harmelen. Reviewing the design of daml+oil:

An ontology language for the semantic web. In AAAI/IAAI, pages 792–797, 2002.

8. B. J. P. II and S. Davis. Mass Customization: The New Frontier in Business Competition.

Harvard Business School Press.

9. J. Kovse, T. Harder, and N. Ritter. Supporting mass customomization by generating adjusted

repositories for product conﬁguration. In CAD, pages 17–26, 2002.

10. H. J. Levesque, R. Reiter, Y. Lesp

erance, F. Lin, and R. B. Scherl. Golog: A logic program-

ming language for dynamic domains. J. Log. Program., 31(1-3):59–83, 1997.

11. C. Liu and I. T. Foster. A constraint language approach to matchmaking. In RIDE, pages

7–14, 2004.

12. R. M. MacGregor. Inside the loom description classiﬁer. SIGART Bulletin, 2(3):88–92, 1991.

13. S. A. McIlraith and T. C. Son. Adapting golog for composition of semantic web services. In

KR, pages 482–496, 2002.

14. S. A. McIlraith, T. C. Son, and H. Zeng. Semantic web services. IEEE Intelligent Systems,

16(2):46–53, 2001.

15. OWL. http://www.w3.org/TR/owl-features/.

16. J. A. Robinson. A machine oriented logic based on the resolution principle. J.ACM,

12(1):23-41, 1965.

17. SOAP. http://www.w3.org/TR/soap/.

18. K. P. Sycara, S. Widoff, M. Klusch, and J. Lu. Larks: Dynamic matchmaking among het-

erogeneous software agents in cyberspace. Autonomous Agents and Multi-Agent Systems,

5(2):173–203, 2002.

19. UDDI. http://uddi.org/pubs/uddi

v3.htm.

20. W3C. http://www.w3.org/.

21. WSDL. http://www.w3.org/TR/wsdl/.

Algorithm 1 Web Services Customization.

Step 1 : Structural Systems matchmaking

1. Seek a set S of services whose context and Inputs/Outputs are similar to those of the request Q.

2. If the set S is empty then the matchmaking process fails, and no result can be turned over for the request. Else

pass to step 2.

Step 2 : Constraints Systems matchmaking

For each service s in the set S do:

A. Detect the Inputs/Outputs whose types are in conﬂict with the Inputs/Outputs of the request. If no conﬂict is

detected then pass to step C, else pass to step B.

B. Seek a conﬂict resolution service for each typing conﬂict of an Input/Output in a request and a service speciﬁca-

tions. Two cases are to be distinguished, according to whether the conﬂict relates to an Input or to an Output.

a. If(ConceptAnnotate(I

)

=C1

∧ ConceptAnnotate(I

)

= C2 // C1 6= C2

∧ (∃C | C1 ⊑ C ∧ C2 ⊑ C )// C: immediate subsumer of C1 and C2

∧ C := C

∨ C

∨ ...) // Cover Axiom

then Find the service whose structure is :

Context ConﬂictResolution(C, context)

I I

O I

ct(s)

ct(Q)

b. If(ConceptAnnotate(O

)

= C1

∧ ConceptAnnotate(O

)

= C2 // C1 6= C2

∧ (∃ C | C1 ⊑ C ∧ C2 ⊑ C )// C: immediate subsumer of C1 and C2

∧ C := C

∨ C

∨ ...) // Cover Axiom

Then Find the service whose structure is :

Context ConﬂictResolution(C, context)

I O

O O

ct(s)

ct(Q)

C. Evaluate the Inputs/Outputs values constraints. If they are not in contradiction then the service can answer the

request, else the service is not suitable like response to the request.
