Semantic-based Similiarity of Music

Michael Rentzsch and Frank Seifert

Chemnitz University of Technology, Dept. of Computer Science

09107 Chemnitz, Germany

Abstract. Existing approaches to music identiﬁcation such as audio ﬁngerprint-

ing are generally data-driven and based on statistical information. They require

a particular pattern for each individual instance of the same song. Hence, these

approaches are not capable of dealing with the vast amount of music that is com-

posed via methods of improvisation and variation. Futhermore, they are unable

to measure the similarity of two pieces of music. This paper presents a differ-

ent, semantic-based view on the identiﬁcation and structuring of symbolic music

patterns. This new method will allow us to detect different instances of the same

song and acquire their degree of similarity.

1 Introduction

“A new system combining a mobile phone and a cryptographic technique will soon

allow you to get the name of any music track you hear on the radio [. . . ]”

This idea, developed by researchers of consumer electronics giant Philips in 2001,

is reality today and a service offered by many mobile phone companies. But audio

identiﬁcation is more than discovering the name and interpreter of a song you heard.

Music (Information) Retrieval is a young and active research topic which deals with

many ways to analyse and process music—symbolic or sub-symbolic—automatically.

A lot of efforts have been put in the development and improvement of Query-by-

humming ([5], [10]) and audio ﬁngerprinting systems ([1], [3]). As a consequence, they

work very well for identifying music from a limited repository already. Unfortunately,

they require an individual pattern for each piece that shall be identiﬁable. Hence, it is

not possible, to use them for analysing the countless number of audio ﬁles containing

live performed, covered and improvised music. Furthermore, they lack the ability to

determine a ﬁne-grained metric for the similarity of two audio documents. This insuf-

ﬁciency is caused by the lack of knowledge about the semantics of music that these

systems show.

To develop an audio identiﬁcation system that is capable of processing the vast

amount of music which is created through the process of improvising and copying

existing pieces, one has to give concern to human music perception: Listening to a

melody, we create inner hypotheses according to our experiences related to this music

theme. Our intention is to develop a system based on a semantic-based model of music

identiﬁcation. This model—the lead sheet model—includes the required information to

simulate the process of creating and validating hypotheses.

NewScientist.com, 2001-11-28

Rentzsch M. and Seifer t F. (2006).

Semantic-based Similiarity of Music.

In 6th International Workshop on Patter n Recognition in Information Systems, pages 175-180

DOI: 10.5220/0002485101750180

 SciTePress

2 The Lead Sheet Model

The lead sheet model (LSM) has been introduced in [7]. It is designed to be a generic

conceptual model for semantic-based identiﬁcation and comparison of music. The name

originates from a simpliﬁed form of sheet music. A lead sheet contains elementary

parameters of music, i.e. melody, rhythm, chords and tempo. It is widely used for jazz

and songbooks.

= 90

F C7

Fig. 1. Characteristic motif of the Scottish folk song “Auld Lang Syne”.

Figure 1 shows the basic element of the lead sheet model: a characteristic mo-

tif (CM). Analysing an audio document, such motifs are the fundamental components

that have to be identiﬁed. A similar approach has been published in [4]. A combina-

tion of two or more motifs that have a strong semantic connection is called a lead

sheet (LS). Lead sheets add a structural aspect—which [4] does not consider—to the

LSM. They cannot consist of characteristic motifs only but also of other (sub) lead

sheets (see Figure 2). Each link from a parent LS to its sub elements is attributed with

a pair of information: a number marking the temporal order of the child elements and a

bit string specifying the relations between the two nodes. Among others, valid relations

are: motif, theme, verse, refrain, intro, and many more.

1, Verse

2, Refrain

1, Motif

1, Motif2, Motif

2, Motif

Fig. 2. Simple lead sheet graph.

The process of identifying music using the LSM can be split: Firstly, the musical

parameters have to be mapped to characteristic motifs. This results in a set of tempo-

rally ordered motif instances. Secondly, each detected instance has to be correlated with

a parent lead sheet, if possible. The second step might be repeated until there are no ab-

stractions left. Using the lead sheet model, it is possible to compare and identify music

in whatever instantiation it is played. Furthermore, it is not only possible to recognise

simple patterns of music but also combinations of motifs and complex structures. While

[7] showed that it is possible to use the LSM on symbolic documents, [8] successfully

applied the above mentioned mapping process to audio data.

176

3 Inexact Matching of Motifs

Section 2 introduced characteristic motifs as the lead sheet model’s basic elements.

Thus, it is essential to develop functions that identify such motifs in audio documents.

Considering music performed live and improvised, these functions have to be robust

against small modiﬁcations—intended as well as unintended—of a motif. This paper

presents a method for inexact matching of motifs in symbolic representation of music.

Existing approaches to identiﬁcation of symbolic music are predominantly based on

a representation and comparison of the shape or contour of a melody. Basically, there

are three different methods for coding the shape of a melody ([2], [11]):

1. a sequence of exact intervals (semitones), e.g. +7, +3, -2, 0, -12,

2. 3-level representation, e.g. up, up, down, equal, down or

3. higher-level representation, e.g. Up, up, down, equal, Down.

Identiﬁcation methods for such representations of music, e.g. calculcating the string

edit distance, are mainly statistics-based and lack any musical background. They can-

not determine, how similar two motifs are concerning the listener’s overall impression.

Thus, Rentzsch ([6]) introduces a different operation to compare a characteristic motif

and a sequence of tones (melody) and to calculate a concrete degree of equality. This

operation is based on the examination of ﬁve different features—parameters—of mu-

sic: melody, rhythm, tempo, harmony and voice. Each of these features is processed

separately. Thus, ﬁve individual equality values E

are calculated.

The equality values for melody and rhythm E

and E

are determined using a

string representation of both features. Between these representations of the motifs, the

Levenshtein distance is calculated and considered in relation to the number of tones.

The bigger the Levenshtein distance is, the smaller is E

and E

respectively. The

equality value for tempo E

is determined regarding the lengths of the ﬁrst tones in the

motifs that have be compared. The bigger the relation of the longer one to the shorter

one of these tones is, the smaller is E

To compute E

, harmonies are compared for each tone in the considered motifs.

Each comparison returns h

∈ {0, 0.5, 1.0}, depending on whether the harmonies are

unequal, similar

or equal. Then, the overall equality value for harmony E

is the av-

erage of all h

. The last parameter—the value for voice—E

is determined considering

the voice that the motif appears in. If the motif is settled in the main voice, E

is set to

1. In all other cases, E

is 0.

Melody

Rhythm

Tempo

Harmony

Fig. 3. Weighting of E

e.g. C and C7

177

Each comparison of the musical features resulted in an equality value E

with

= 1 if motif and melody are completely equal. Yet, it is useful to develop a pro-

cedure to combine those values to one ﬁnal degree of equality E. As some of the indi-

vidual values are more important for the identiﬁcation of music than others, not all E

should have the same impact. Thus, Rentzsch deﬁned a set of weighting values W

shown in Figure 3. The equality value for voice E

is supposed to have a special impact

on the ﬁnal value. Thus, it affects the resulting formula as a “global” factor. Given the

ﬁve equality values E

and a set of weightings W

, the overall degree of equality E can

be calculated E = E

width p ∈ {M, R, T, H}.

4 Comparing Template Structures

In this part of the paper, we will introduce an approach to comparing entire pieces

of music based on the set of characteristic motifs they contain. Having identiﬁed all

motifs—that are known to the system—in a symbolic document and considering the

structure deﬁned in the lead sheet model, every piece of music can be represented as

a graph as shown in Figure 4. This graph is called document template. All edges are

attributed with the relation—speciﬁed in the lead sheet graph—and the equality value

by which this CM had been identiﬁed.

Verse

Refrain

(Motif, 0.95)(Motif, 0.85)

Fig. 4. Document template.

Now, the attempt to compare two pieces can be reduced to comparing these tem-

plates. Thus, it is possible to take advantage of existing approaches to graph matching.

However, using one of these mainly syntax-based matching methods does not incor-

porate the semantic functions the modiﬁcations hold. Futhermore, the time frame cov-

ered by the template—thus, by the identiﬁed motifs—has no inﬂuence on the resulting

distance. Hence, a different approach—a semantic-based metric—has been developed

([6]). This metric compares document templates in four levels: time level, structural

level, semantic level, and motif level. Each comparison delivers a distance value D

The resulting overall distance is a tuple D = (D

Time

, D

Struct

, D

Semant

, D

Motif

As a ﬁrst step, the common sub-template (CST), i.e. all lead sheets and motifs oc-

curring in both pieces, is determined. On the time level, the time frame that this sub-

template covers in both documents is taken into account. The distance on time level

Time

is deﬁned as the average value of the two time frames. The distance on structural

level D

Struct

is used to consider small modiﬁcations, e.g. the repetition of a motif. Each

modiﬁcation is rated depending on type and relation to the parent lead sheet. Then,

178

Struct

is the average value of all such ratings. The semantic level determines and eval-

uates the relations between the elements in the common sub-template. Result is a set of

values between 0 (motifs from different lead sheets) to 5 (same song/piece). In many

cases, quite a number of different relations is detected. Thus, the distance value D

Semant

is the average value of all relations weighted by the time frame they cover. The last

level analyses the average degree of equality by which all motifs in the CST have been

found. Therefore, D

Motif

is bigger, if many motifs appear unmodiﬁed.

As mentioned before, the ﬁnal distance is a tuple of the four single distance values

Time

, D

Struct

, D

Semant

, and D

Motif

. It depends on a concrete application how these values

are treated. Hence, it is possible to combine these values to one overall value as it is

used for the equality value. However, this would shorten the number of (semantically)

different queries that this metric can process.

5 Results and Future Work

In this paper, we have presented a semantic-based approach to comparing symbolic rep-

resentations of music. This approach uses the lead sheet model as a conceptual model

for music identiﬁcation. Applying this method to two documents determines a tuple of

distance values marking the four levels of comparison. Considering this partitioning, it

is possible to respond to quite a number of different types of queries: “ﬁnd pieces con-

taining song s unmodiﬁed”, “ﬁnd pieces using different motifs from s

and s

”, “ﬁnd

pieces containing the refrain of song s”, and many more. To put the methods described

in Sections 3 and 4 in practice, we have implemented the prototype application CoSMIc

(Comparing symbolic musical instances). This application determines the document

templates of two MIDI documents and returns the resulting distance values to its user.

To show the applicability of our approaches, we want to brieﬂy describe a small exper-

iment and its results.

Table 1. Distances to “Auld Lang Syne”.

Levels

Piece Time Structural Semantic Motif

Original 0.91 0 5 0.95

Motif changes 0.91 0 5 0.91

Medley 0.35 0 3.1 0.95

Different song 0 0 0 0

We have compiled a set of four songs: “Auld Lang Syne” (original), “Auld Lang

Syne” with modiﬁed motifs, “Oh, when the saints”, and a medley of “Auld Lang Syne”

and “Oh, when the saints”. Each of these songs has been processed by CoSMIc and

compared to the original “Auld Lang Syne”. The results of this experiment—thus, the

four distance values of each comparison—are presented in table 1. To make understand-

ing these results easier, we have illustrated them as a 3D chart in Figure 5. Thus, we

have omitted the values on the structural level, as they are all 0.

Apparently, it is possible to classify the ﬁrst two songs as instances of “Auld Lang

Syne”. They are situated in one region of the chart. “Oh, when the saints” reveals no

179

0.2

0.4

0.6

0.8

0.2

0.4

0.6

0.8

Time Level

Motif Level

Semantic Level

Time Level

Fig. 5. Distance diagram.

similarities. The medley of different motifs from “Auld Lang Syne”, and “Oh, when the

saints” is situated in between these key points. Running a number of experiments using

different songs from diverse genres proved the general applicability of the techniques

we have introduced. Thus, our semantic-based approach to comparing and clustering

different pieces of music which can be variations of the same composition succeeds.

Future work should focus on adopting the methods presented in this paper to sub-

symbolic audio data using hypotheses-based recognition ([8]). Being able to detect dif-

ferent instances of the same song in whatever representation shall ﬁnally provide us with

the required techniques to develop a music retrieval system that implements a cluster

index-based access to its document repository. Hence, these techniques will assure that

diverse queries considering the semantics of music will be processable efﬁciently.

References

1. Cano, P., Batlle, E., Kalker T., Haitsma J.: A Review of Algorithms for Audio Fingerprinting.

In: International Workshop on Multimedia Signal Processing, US Virgin Islands (2002)

2. Dowling, W. J.: Scale and contour: Two components of a theory of memory for melodies. In:

Psychological Review, p. 341 - 354 (1978)

3. Haitsma, J., Kalker, T.: A Highly Robust Audio Fingerprinting System. ISMIR, Paris, France

(2002)

4. Neve, G., Orio, N.: Indexing and Retrieval of Music Documents trought Pattern Analysis and

Data Fusion Techniques. ISMIR, Barcelona, Spain (2004)

5. Nishimura, T. et al.: Music Signal Spotting Retrieval by a Humming Query Using Start

Frame Feature Dependent Continuous Dynamic Programming. In: Music Information Re-

trieval, p. 211 - 218, Bloomington, Indiana (2001)

6. Rentzsch, M.: Entwicklung und Implementierung von Vergleichsoperationen f

ur symboli-

sche Tondokumente, Diploma Thesis. Chemnitz University of Technology, Germany (2005)

7. Seifert, F.: Musikalische Datenbanken, Dissertation. Chemnitz University of Technology,

Germany (2004)

8. Seifert, F.: Prediction-Driven Correlation of Audio with Generic Music Templates.

EuroIMSA, Grindelwald, Switzerland (2005)

9. Shapiro, L. G., Haralick, R. M.: A metric for comparing relational descriptions. In: IEEE

Trans PAMI, p. 90 - 94 (1985)

10. Song, J., Bae, S. Y., Yoon, K.: Mid-Level Music Melody Representation of Polyphonic Audio

for Query-by-Humming System. ISMIR, Paris, France (2002)

11. Youngmoo, K., Wei C., Ricardo, G., Barry, V.: Analysis of a contour-based representation for

melody. Int. Symposium on Music Information Retrieval, Plymouth, Massachusetts (2000)

180
