BRIDGING THE LANGUAGE-ACTION PERSPECTIVE AND

ORGANIZATIONAL SEMIOTICS IN SDBC

Boris Shishkov

Department of Computer Science, University of Twente, 5 Drienerlolaan, Enschede, The Netherlands

Jan L. G. Dietz

Department of Software Technology, Delft University of Technology, 4 Mekelweg, Delft, The Netherlands

Kecheng Liu

Informatics Research Centre, The University of Reading, Whiteknights, Reading, UK

Keywords: Business process modelling, Language-Action Perspective (LAP), Organizational Semiotics (OS), SDBC.

Abstract: Achieving an adequate business-software alignment should include capturing essential aspects that concern

the studied business reality as well as reflecting them in the software specification. This concerns semantic

and pragmatic aspects, such as meanings, intentions, negotiations, commitments, and obligations, whose

appropriate consideration is beyond the capabilities of current software design methods which focus just on

formal language structures and data records. Organizational Semiotics allows for an adequate consideration

of essential semantic aspects in conducting a business process modeling. The Language-Action Perspective

is capable of grasping pragmatics on top of that. Some examples of combining LAP and OS have

demonstrated benefits when conducting business process modeling, for the purpose of further specification

of software. To further this work, it is necessary that LAP and OS are incorporated in a modeling

framework which integrates business process modeling and software specification. The SDBC approach

applies the LAP and OS theories, in order to address the business-software alignment challenge. They

support the business process modeling in SDBC, which results in the identification of re-usable business

process models and their mapping to software specification, in consistency with the current software design

standards. Thus, it is feasible to expect that a LAP-OS combination could bring value to the current

application development, in the context of the approach SDBC. In this paper, we further elaborate our

SDBC-driven views on how LAP and OS can be combined for a sound business process modeling which

builds a foundation for software specification.

1 INTRODUCTION

eBusiness, Tele-Work, telecenters, and other

examples of utilizing the latest information

technology, alongside the current development of

global telecommunications and digital multimedia,

are considered to indicate for a just partial success in

Society’s making use of this emerging technology

(Shishkov, 2005). We argue that one of the reasons

for this is the limited capability of (software)

applications in addressing the role they are to play:

to serve as an environment through which users

benefit from particular technical possibilities. This

limited capability represents an actual challenge

which can be seen from numerous examples of

mismatch between the requirements and the actual

functionality of the delivered application (Shishkov

& Dietz, 2004-1). Such examples are evidence that

current application development fails in providing

users with adequate technical support in their

business activities. Not surprisingly, an increasing

number of software projects fail (Liu, 2000).

An essential issue in developing applications, as

studied by Shishkov and Dietz (2005), is that the

modeling of the business processes (to be supported

by applications) and the specification of those

Shishkov B., L. G. Dietz J. and Liu K. (2006).

BRIDGING THE LANGUAGE-ACTION PERSPECTIVE AND ORGANIZATIONAL SEMIOTICS IN SDBC.

In Proceedings of the Eighth International Conference on Enterprise Information Systems - ISAS, pages 52-60

DOI: 10.5220/0002487700520060

 SciTePress

applications need to be considered as one integrated

task. Such an approach assist us in avoiding

common problems of designing software without

prior adequate consideration of the business

processes to be supported by it, or providing a

business process modeling output which is

inadequately transformable into the specification of

software.

Nevertheless, achieving an adequate business-

software alignment would mean that all essential

aspects concerning the studied business reality are

captured and reflected in the software specification.

This should include semantic and pragmatic aspects,

such as meanings, intentions, negotiations,

commitments, and obligations (Stamper, 2000).

Current software design methods often focus on

formal language structures and data records, which

makes them incapable of adequately handling

semantics and pragmatics. The limitations of such

methods have become more apparent with the

increasing penetration of technology and software

into social and economic activities.

rganizational Semiotics (OS) allows for an

adequate consideration of essential semantic aspects,

in conducting a business process modeling (Stamper,

2000; Liu, 2000). The L

anguage-Action Perspective

(LAP) is capable of grasping pragmatics on top of

that (Dietz, 2004). Some examples of combining

LAP and OS have demonstrated benefits when

conducting business process modeling, prior to a

specification of software. To further this work, it is

necessary that LAP and OS are incorporated in a

modeling framework which integrates business

process modeling and software specification.

The SDBC (‘SDBC’ stands for S

oftware Derived

from B

usiness Components) approach (Shishkov,

2005; Shishkov & Dietz, 2005) addresses the

challenge of business-software alignment, relying on

the LAP and OS theories. They support the business

process modeling in SDBC, which results in the

identification of re-usable business process models

and their mapping to software specification, in

consistency with the current software design

standards, such as the Unified Modeling Language

(Shishkov, 2005; Shishkov & Dietz, 2004-2;

OMG, 2003). Thus, it is feasible to expect that a

LAP-OS combination could bring value to the

current application development, in the context of

the SDBC approach.

In this paper, we further elaborate our SDBC-

driven views on how LAP and OS can be combined

for a sound business process modeling which builds

a foundation for software specification.

The outline of the paper is as follows: Section 2

briefly introduces LAP and OS, and analyzes in

general the value of and potentials for their joint

application. Section 3 presents the SDBC approach

and also elaborates on related aspects that concern

the issue on bridging LAP and OS. This is illustrated

in Section 4, by means of an example. Section 5

supports analytically the current study, by discussing

relevant related work, with Section 6 to present

conclusions.

2 LAP AND OS

As stated already, this section will briefly introduce

LAP and OS, and then present some general

considerations regarding their possible combination.

2.1 Language-Action Perspective

We observe that people demand currently more and

more from business processes. For example, it is

often required that such processes are modified

and/or connected to other business processes

(Shishkov, 2005). These increasing demands

towards business processes cannot be met

adequately anymore by relying only on best

practices (Dietz, 2003). A promising perspective,

convincingly claiming to soundly approach the

modeling of business processes is the L

anguage-

Action Perspective (LAP). LAP is a theoretically

based approach towards modeling and developing

business processes and information systems, that has

its roots in language philosophy. The approach

recognizes that language is not only used for

exchanging information, as in reports, for example,

but also to perform actions, as in promises or orders.

Such actions are claimed to represent the foundation

of communities and organizations, and must be

understood to create effective information systems.

The seminal contributions to the development of

LAP are one European (Goldkuhl & Lyytinen, 1982)

and one American (Winograd & Flores, 1986)

publication. In LAP, an organization is considered as

a social system. This means that the inter subject

relationships among people, brought about and

maintained in communication, constitute the real

basis of an organization’s existence. Business

processes then become structures of commitments

and the real important activity of the actors in these

processes is that they enter into and comply with

commitments.

BRIDGING THE LANGUAGE-ACTION PERSPECTIVE AND ORGANIZATIONAL SEMIOTICS IN SDBC

Among other things, LAP has given rise to the

notion of Enterprise Ontology, as proposed in

(Dietz, 2006). This notion has appeared on top of

some LAP-driven considerations which concern the

methodology DEMO (Dietz, 2003; Shishkov &

Dietz, 2004-3).

2.2 Organizational Semiotics

Considering solely the concept of information would

not allow for grasping completely all social

relationships attached to a business concept (Liu,

2000). In O

rganizational Semiotics (OS), it is argued

that signs (standing to someone for something else,

in some respect or capacity) offer a rigorous

foundation to understand a business reality

(Stamper 2000). For example, a bank note is more

than just a piece of paper with digits on it. It stands

for its holder’s wealth, the issuing bank’s authority,

and so on. This enables for a balanced business

study reflecting both technological and social

aspects. Further, by adopting a subjectivist

philosophical stance, OS acknowledges that nothing

exists without a perceiving agent and the agent

engaging in actions.

Based on this foundation, Stamper has

contributed to the OS development, by adopting

from Gibson (1979) the notion of affordance – the

action possibilities in the environment in relation to

the action capabilities of an agent. Illustrating this:

in the context of a library, a book affords to be

borrowed – this is a potential pattern of behavior. It

may or may not be realized in reality. However,

once it is realized, new possibilities may emerge.

For example, a borrowed book may be returned.

Hence, affordances have dependency relationships

among them, called Ontological Dependency. It

could be schematically shown with the antecedents

on the left side and the dependencies on the right,

and the solid line denotes the ontological

dependency:

book – borrow - return

This shows not only the logical inter-concept

relationship but also the dependencies getting their

meaning from the existence of the antecedents.

Since the dependencies result from antecedents’

existence, the dependencies’ lifecycle is included by

that of the antecedents. Their existence thus forms a

context for the dependencies. For example, returning

a book refers to the fact that it has previously been

borrowed.

2.3 The LAP-OS Combination

We argue that LAP and OS are necessarily

complementing each other, in allowing for an

adequate business process modeling foundation

which concerns a realistic reflection of the original

business reality. We claim as well that this

distinguishes these theories from the ones currently

used within the Software Community. The crucial

advantage is that a LAP/OS foundation grasps

essential semantic and communication issues and

allows for their reflection in the specification of an

application. We see this as a decisive factor in

making the application-to-be adequately operational

in the context of the business environment in which

it would have to function.

In our discussion on the general foundations of a

LAP-OS combination, we refer to the widely

considered ‘Semiotic Ladder’ (Stamper, 2000):

Real-life aspects (****, *****, ******)

****** S O C I A L W O R L D:

beliefs, expectations, commitments,

contracts, culture, …

***** P R A G M A T I C S:

intentions, communication, conversations,

negotiations, …

**** S E M A N T I C S:

meanings, propositions, validity, truth,

signification, …

IT-platform-related aspects (*, **, ***)

*** S Y N T A C T I C S:

formal structure, language, logic, data,

software, files, …

** E M P I R I C S:

pattern, variety, noise, channel

capacity, codes …

* P H Y S I C A L W O R L D:

signals, traces, physical distinctions,

hardware, laws of nature, …

As it is seen above, in a business-process-

modeling-driven software specification, we should

consider issues that concern the technical aspects of

an application (such as empirics and syntactics, for

example) as well as issues that concern the real-life

aspects (such as semantics and pragmatics, for

instance). We argue that, because of the increasing

scope of applications in the context of a business

system, the real-life aspects must receive greater

attention, as a way to overcome the (frequently

observed) mismatch between the functionality of an

application and the original business requirements.

Therefore, we claim that considering semantics,

pragmatics, and other real-life aspects is of essential

importance. This means that it is necessary to

adequately grasp such aspects and also map them

ICEIS 2006 - INFORMATION SYSTEMS ANALYSIS AND SPECIFICATION

properly to the specification and realization of

software, where empirics and syntactics do play a

role.

Hence, we envision a significant value in OS and

LAP because, as it has been discussed in the current

section, these theories are powerful with regard to

semantics and pragmatics, respectively. Thus, the

potentials for combining LAP and OS do concern

these real-life aspects. Such a combination would

lead, therefore, to a business process modeling

output which is adequate in the context of the

(considered) business-software-alignment task.

However, a challenge is how LAP and OS could

be applied in an integrated way, in tune with the

above-presented views.

The following section is going to answer this

question, by discussing the approach SDBC in

which LAP and OS aspects are integrated, in the

course of delivering an adequate business process

modeling output to be used as a foundation for

specifying software.

3 BRIDGING LAP AND OS IN

SDBC

In this section, we will present, on the basis of the

general LAP-OS discussion conducted in Section 2,

our views on how LAP and OS aspects could be

helpfully combined in SDBC. That is why we will

first briefly present the SDBC approach in Sub-

section 3.1.

3.1 The SDBC Approach

As already mentioned, before discussing the way in

which SDBC bridges LAP and OS aspects, we will

briefly summarize the outline of the approach; we

will realize this using Figure 1. We have used the

following abbreviations there: bc – Business

Component (a business sub-system that comprises

exactly one business process); bk – Business

CoMponent (a model of a Business Component,

which is elaborated in terms of structure, dynamics,

communication, and data); glbk – general Business

CoMponent (which is re-usable by extension); gcbk

– generic Business CoMponent (which is re-usable

by parameterization); ssm – software specification

model; sc – Software Component (an implemented

piece of software representing a part of an

application); sk – Software CoMponent (a

conceptual specification model of a Software

Component). For more information on the above

concepts, interested readers are referred to

(Shishkov, 2005; Shishkov & Dietz, 2005).

Figure 1: Outline of the SDBC approach.

The figure shows that SDBC is about a business-

process-modeling-driven specification of software.

The starting point is a consideration of a business

system. Business Components are identified from it.

This is done by applying an OS-driven analysis

leading to the derivation of the so called ‘SCI

modeling output’ (Shishkov, 2005). The Business

Components should be then reflected in

corresponding Business CoMponents, in supplying

an adequate modeling foundation for the further

software specification activities. Another way of

arriving at a Business CoMponent is by applying re-

use: either extending a general Business CoMponent

or parameterizing a generic Business CoMponent.

DEMO (Shishkov & Dietz, 2004-3) and other LAP-

driven modeling tools are relevant as far as Business

CoMponents are concerned. Each Business

CoMponent should be then elaborated with the

domain-imposed requirements, for the purpose of

adding elicitation on the particular context in which

its corresponding Business Component exists within

the business system (from which it has been

identified). Then, a mapping towards a software

specification model should take place, driven by a

DEMO-UML transformation mechanism (Shishkov,

2005) and supported by OS. The mentioned

requirements as well as the user-defined

requirements are to be considered here, since the

derived software model should reflect not only the

original business features but also the particular user

demands towards the software system-to-be. The

(UML-based) software specification model would

need then a precise elaboration so that it provides

BRIDGING THE LANGUAGE-ACTION PERSPECTIVE AND ORGANIZATIONAL SEMIOTICS IN SDBC

sufficient elicitation in terms of structure, dynamics,

data, and coordination (Shishkov, 2005; Shishkov &

Dietz, 2004-2). The model needs also to be

decomposed into a number of Software CoMponents

reflecting functionality pieces. Then these Software

CoMponents are to undergo realization and

implementation, being reflected (in this way) in

Software Components. This final set of components

might consist of such components which are

implemented (using software component

technologies, such as .NET or EJB, for instance)

based on corresponding Software CoMponents and

such components which are purchased. Finally, the

(resulting) component-based application would

support informationally the target business system,

by automating anything that concerns the initially

considered Business Component(s) identified from

the mentioned system.

3.2 Bridging LAP and OS Aspects

The SDBC approach has been briefly presented

above. However, for more information on the

approach, readers are referred to (Shishkov, 2005).

Due to the limited scope of this paper and also

because of the availability of information on SDBC

as well in other sources (Shishkov & Dietz, 2005;

Shishkov & Dietz 2004-1), we will not introduce in

detail features of SDBC which we will discuss

below in addressing the values of the approach with

regard to the challenge of bridging LAP and OS

aspects. Figure 2 illustrates these values.

behavior

LAP/DEMO transaction

action

entity

LAP/DEMO actor role

business process

business system

business component

business coMponent

identification steps

OS-driven steps

LAP-driven steps

Figure 2: LAP and OS aspects concerning SDBC.

As seen from the figure, LAP/DEMO

transactions do represent the elementary business

process modeling building blocks in SDBC –

actually, we define a Business Process as ‘a structure

of connected transactions…’ (Shishkov & Dietz,

2005). In addition to this, taking into account that

‘nothing exists without a perceiving agent engaging

in actions’ (Section 2), we do consider in SDBC the

LAP/DEMO actor role concept (Shishkov, 2005).

Therefore, a crucial issue about SDBC is the

identification of transactions and actor-roles.

The identification mechanisms on which SDBC

relies regarding this, are based on LAP and OS.

Thus, this is a good starting point for a deeper

discussion on the potentials of combining LAP and

OS, for the purpose of creating a sound business

process modeling foundation in the context of a

software specification.

Hence, we will briefly outline the influence of

LAP and OS in the mentioned identification

mechanisms and then partially illustrate this in the

following section.

For this purpose, we use Table 1 where we

consider not only business process modeling

activities (Figure 2) but also such activities that

concern the reflection of a business process model

towards software specification. However, the latter

are considered to be beyond the scope of this paper

because they have been addressed in another one

(Shishkov & Dietz, 2004-3).

Table 1: LAP and OS influencing steps in SDBC.

SDBC-Task Influence

A. Tasks that concern the

identification of actor-roles

- Building a generalization hierarchy

for the explored domain

Semantic

Analysis

(OS)

- Analysis of responsibilities LAP

B. Tasks that concern the

identification of transactions

- Identification of inter-role relations LAP

- Elaboration of relations Norm

Analysis

(OS)

- Mapping to transactions LAP

C. Tasks that concern the derivation

of a software specification model

- DEMO – use case mapping LAP (and

also OS)

- use case specification OS, LAP

- use case elaboration LAP, OS

ICEIS 2006 - INFORMATION SYSTEMS ANALYSIS AND SPECIFICATION

As seen from the table, the identification of

actor-roles in SDBC comes through building of a

generalization hierarchy for the explored domain

(which is influenced by OS in general and Semantic

Analysis (Stamper, 2000), in particular) and

analyzing the responsibilities connected with each of

the elements of the hierarchy (which is influenced

by LAP). The identification of transactions in SDBC

comes through the LAP-driven identification of

inter-role relations and also through their normative

elaboration (which is OS-driven). Further, the actual

modeling of transactions is based on the SDBC

(LAP-driven) transaction pattern (Figure 5). And

finally, the reflection of the SDBC business process

modeling output in the specification of software

goes through the identification of use cases. The

SDBC use case derivation mechanism (Shishkov &

Dietz, 2004-3) is driven by LAP in general and

DEMO in particular, and supported by OS. As for

the further specification and elaboration of the

derived use cases, both LAP and OS add value – OS

adds value mainly from the perspective of semantic

and normative elaboration while LAP adds value

from the perspective of communicative and

coordination elaboration.

All this information is available in more detail in

the SDBC sources, mainly in (Shishkov, 2005). The

following section is going to provide however some

relevant illustrative elicitation.

4 CASE EXAMPLE

As stated already, this section will illustrate the

influence of LAP and OS, concerning SDBC, and in

particular – their combined contribution.

The illustration is founded on a case study,

namely the Icomp Case. Since the goal is just

illustrative and because of the limited scope of this

paper, the information to be presented will be

partial; for more information on the mentioned case,

interested readers are referred to (Shishkov, 2005).

The case concerns the insurance company Icomp.

We are particularly interested in a part of Icomp’s

business, namely the distribution of financial products

to end customers through brokers; this means that there

are a number of (insurance) financial companies, a

number of brokers, and a number of customers, which

do concern the mentioned distribution mechanism. A

broker distributes products of a number of companies

(including Icomp) to a number of customers. A

customer might be advised by a number of brokers

about the products of a number of (financial)

companies. Hence, Icomp uses a number of brokers

through which it distributes its products to customers.

With respect to the (financial) products distribution,

Icomp has relations not only with brokers but also with

re-insurance companies (taking over insurance risk

from Icomp), product development companies

(delivering new financial, insurance products),

investigation companies (providing an expert support),

and so on.

In conducting the business process modeling in

SDBC, we start by structuring and positioning

semantically the case information, following

modeling steps which are inspired by OS, an in

particular by the Semantic Analysis Method (Liu,

2000). Because of the limited scope of this section,

we go directly to the output (Figure 3) of such a

study, referring readers to (Shishkov, 2005) for more

information about the particular modeling steps

within SDBC.

O r g a n i z a t i o n

C o m p a n y

…

Financial Company

…

(

)

insurance Company

Intermediary Company Prod. Dev. Company

…

Investig. Company

Consultancy Company

…

al person N a t u r a l p e r s o n

P E R S O N

Figure 3: OS-driven business object model.

As seen from the figure, by applying OS, we

arrive at a generalization hierarchy for the explored

domain, which is easily understandable for both

developers and future users. Therefore, an important

role of OS is to allow for bringing order in the case

information which is usually vague and full of

errors.

Next, we conduct in SDBC a LAP-driven

analysis of the achieved modeling output. We

consider for this purpose the entities in the

generalization hierarchy from the perspective of the

LAP notion of actor-role (Shishkov & Dietz, 2004-

3). This allows for a more powerful and flexible

modeling – imagine, for example a manager sending

a fax, this is not a typical activity for a manager and

would therefore make the modeling of such thing

complex and confusing, however if we look at this

as a role, we could easily model it by introducing the

role ‘Secretary’ (sending a fax is a competence of

this role; decision making is a competence of the

BRIDGING THE LANGUAGE-ACTION PERSPECTIVE AND ORGANIZATIONAL SEMIOTICS IN SDBC

role ‘Manager’). Thus, SDBC bridges OS and LAP,

in allowing to reflect an OS-driven generalization

hierarchy in a LAP-driven role model. Again, due to

the limited scope of this paper, the modeling steps

are not presented in detail; refer to (Shishkov, 2005).

Figure 4 presents our resulting role model:

R o l e

INSURER

sell insurance products

REINSURER

take over insurance risk

BROKER

* give financial consultation

* advise for ins. product

realize expertise

SUPPLIER

deliver financial products

EXPERT

CUSTOME

* purchase insurance products

* provide information

Figure 4: Basic role types within the Icomp Case.

Such (identified) role types represent essential

modeling constructs in SDBC, as seen from Figure

2. We particularly use the DEMO interpretation

(Dietz, 2003) of this LAP-driven concept.

Then we

apply the SDBC requirements

elicitation apparatus (which includes further

information gathering – interviews might be needed,

for example) in order to identify the relationships

concerning the discovered role types. These

modeling steps are inspired by LAP and result not

only in identified pairs of role types which have

relationship but also provide textual statement

describing the relation. For example:

INSURER – sell ins. products – CUSTOMER

Actually, here we need to do partial instantiation

because we are interested particularly in the

insurance company Icomp:

Icomp – sell insurance products – CUSTOMER

We could have others, as well:

. . .

BROKER – advice for fin. products – Icomp

We do need to structure further and elaborate the

information concerning the relations. For this

reason, we apply OS, and in particular – the Norm

Analysis Method (Liu, 2000), reflecting each

relation in a semiotic norm. This might require

additional information gathering and/or clarification.

We take, for example, the first of the above

relations and map it to a norm:

Row 1: Whenever BROKER has advised CUSTOMER in favour of an

Icomp’s product and CUSTOMER fits within Icomp’s policy

Row 2 If CUSTOMER decides to purchase this product

Row 3: Then Icomp

Row 4: Is obliged to insure CUSTOMER according to the concrete

product details and based on a CUSTOMER payment, accordingly made.

This represents already a soundly specified and

elaborated inter-role relation: Row 1 describes the

context, Row 2 – the condition/trigger, Row 3 gives

the responsible party, and Row 4 specifies the action

through which the roles relate to each other.

This output is to be elaborated further, by

relating it to particular units inside Icomp (Financial

Department, Account Manager (am), and so on

(Shishkov, 2005)). In SDBC, we handle this by

conducting a LAP-driven analysis which results in

the construction of the SCI Chart (Shishkov, 2005)

which in turn allows the identification of SDBC

business process patterns, such as:

Icomp (Dept am) start AGREEMENT BROKER

We apply then the transaction concept (Figure 5)

to each pattern.

Production-act

input output

r(I) p(E)

d(E)

compromise

found?

s(E) a(I)

d(I)

compromise

found?

Production-fact

Legend

r: request I: Initiator

p: promise E: executor

s: state

a: accept

d: decline

cancel

Yes Yes

Figure 5: SDBC: LAP-driven transaction concept.

We will not explain this because that concept has

been discussed in (Shishkov & Dietz, 2004-1).

However, applying this concept, we could identify a

number of business process models and present them

in DEMO notations (Shishkov & Dietz, 2004-3). An

example of such a model is shown on Figure 6 (T01,

T02, and T03 are transaction types, while S02 as

well as A01 and A02 are role types):

Figure 6: SDBC: identified business process model.

And finally, we apply to such a model a

modeling procedure in order to reflect it in a use

case software specification model.

How we derive use cases and how then we

specify and elaborate them, is discussed in

(Shishkov & Dietz, 2004-3) and (Shishkov, 2005).

ICEIS 2006 - INFORMATION SYSTEMS ANALYSIS AND SPECIFICATION

5 RELATED WORK

The challenge of capturing the essential aspects

about business processes for the purpose of further

software specification, has been addressed not only

by the SDBC approach but also by methods such as

Catalysis (D’Souza & Willis, 1998) and Tropos

(Tropos Project) as well as by the M

odel Driven

Architecture – MDA (OMG, 2003).

The Catalysis method provides a coherent set of

techniques for business analysis and system

development as well as well-defined consistency

rules across models. However, these techniques

concern the software design perspective and have no

theoretical roots relevant to the modeling of business

processes. Hence, the business process modeling as

conducted in Catalysis would inevitably be

superficial and therefore the method cannot

guarantee an adequate capturing of all related real-

life aspects, including semantic and pragmatic ones.

In addition to this, Catalysis does not have

mechanisms for a mapping between business

process models and software specification models.

Therefore, a definite strength (in this regard) of

SDBC is that, relying on the LAP-OS ‘combination’,

the approach supports adequately the business

process modeling task and the software design

activities in SDBC stem from a pure business

process model, guaranteeing that the application-to-

be would function adequately in the business

environment in which it would have to be integrated.

The strengths of the method Tropos relate to its

capability of conducting a sound requirements

analysis, considering the business processes which

are to be supported by the application-to-be. From

such a business process modeling point of view, the

method addresses the software design. The

mentioned requirements analysis includes elicitation

not only of the ‘early requirements’ that concern the

original business reality but also of the ‘late

requirements’ which are about a corresponding

updated (desired) business reality. The analysis is

driven by a thorough consideration of the intentions

of stakeholders, modeled as goals which are then

reflected in the system’s global architecture. Its

definition is in terms of sub-systems interconnected

through data, control, and other dependencies. Then

a detailed design follows. Therefore, all this features

Tropos as a powerful method for designing software,

which appropriately refers to the task of capturing

essential real-life aspects that concern the modeling

of business processes. However, the method is

incomplete with regard to some of these aspects – it

is not exhaustive in handling semantics and is

insufficiently concerned with essential pragmatic

issues, such as communicative actions, negotiations,

coordination, and so on (Shishkov, 2005). Further,

the method lacks (just like Catalysis) clear and

complete guidelines (and elaboration) on how to

reflect the business process modeling output in the

specification of the application-to-be. Such a

specification would therefore inadequately reflect

the original business model.

MDA prescribes three viewpoints from which

models of the application-to-be (our target software

system) should be defined: Computational

Independent Models (CIMs) should focus on the

environment and requirements of the system,

abstracting from the system’s construction;

Platform-Independent Models (PIMs) should focus

on the functionality of the system without revealing

details on the specific technological platform on

which the system is built, and Platform-Specific

Models (PSMs) should define how a PIM is built

using some specific platform. Therefore, the

Computational Independent Modeling as well as the

CIM-PIM transformation relate to the problem

addressed in the current paper, namely the

achievement of an adequate business-software

alignment which is concerned with all relevant real-

life aspects. However, bridging business process

models and application design by using

Computational Independent Modeling and realizing

a CIM-PIM mapping, are issues not enough

explored, as it is well known. The MDA Community

still misses sound guidelines and procedures on how

to discover Computational Independent Models and

how to reflect them in Platform Independent

Models.

Thus, the LAP-OS-driven solution direction

considered in SDBC, is actual and is expected to be

useful to current application development.

6 CONCLUSIONS

As stated in the Introduction, this paper furthers

LAP and OS –related studies, exploring the added

value of a LAP-OS combination, in the SDBC-

driven modeling of business processes.

Such a combination has been considered from a

general perspective (Section 2) and particularly from

the perspective of the SDBC approach (Section 3).

The justified SDBS-related advantages of combining

LAP and OS were then illustrated in Section 4 and

supported by an analysis of related work, in Section

BRIDGING THE LANGUAGE-ACTION PERSPECTIVE AND ORGANIZATIONAL SEMIOTICS IN SDBC

The conclusion we reach is that LAP and OS are

mutually complementable theories whose combined

application contributes to the derivation of an

adequate business process modeling output, in the

context of a specification of software. Such an

adequacy concerns the business process analysis in

SDBC, which is supported by a LAP-OS

combination, guaranteeing that no essential aspects

(regarding the original business reality) are omitted.

This guarantee is motivated by the capabilities of OS

and LAP to soundly grasp semantics and pragmatics,

respectively. This contributes to the creation of a

foundation for the further software specification

activities.

As it has been studied (and also demonstrated) in

this paper, the SDBC approach not only provides a

modeling framework suitable for such a LAP-OS

incorporation, but it also supports the mapping of a

LAP-OS-driven business process modeling output to

a software specification model. In this way, the

approach guarantees that the software application-to-

be would be adequately operational in the business

environment in which it would have to function.

Hence, these reported developments of SDBS are to

be considered in the context of the efforts (within the

Software Community) to bring together business

process modeling and software specification.

Our agenda for further research includes

extension of SDBC and its LAP-OS foundations to

Agent Technology, which would concern the

modeling of more complex (including autonomous)

behavior (Shishkov, 2005). This is connected with

the challenge of achieving adequate coordination in

Multi-Agent Systems, and should be driven

therefore by a sound capturing of semantic and

pragmatic aspects.

REFERENCES

Dietz, J.L.G, 2006. Enterprise Ontology – Theory and

Methodology. Springer Verlag, Berlin New York,

2006.

Dietz, J.L.G, 2004. Basic notions regarding business

processes and supporting information systems. In

CAiSE’04 Workshops in connection with the 16

International Conference on Advanced Information

Systems Engineering. CAiSE Press.

Dietz, J.L.G, 2003. The atoms, molecules, and fibers of

organizations. Data & Knowledge Engineering, vol.

47.

D’Souza, D.f. and A.C. Willis, 1998. Object, components,

and frameworks with UML, the Catalysis approach.

Addison-Wesley, USA.

Gibson, J.J., 1979. The Ecological Approach to Visual

Perception. Boston, USA: Houghton Mifflin.

Goldkuhl, G. and K. Lyytinen, 1982. A language action

view of information systems. In: Ginzberg, M., Ross,

C.A. (Eds.) Proceedings of the 3

International

Conference on Information Systems Engineering,

TIMS/SMIS/ACM.

Liu, K., 2000. Semiotics in Information Systems

Engineering. Cambridge, UK: Cambridge University

Press.

Object Management Group (OMG), 2003. MDA – Guide,

V1.0.1, omg/03-06-01.

Shishkov, B., 2005. Software Specification Based on Re-

usable Business Components. Delft, The Netherlands:

Sieca Repro.

Shishkov B. and J.L.G. Dietz, 2005. Applying component-

based UML-driven conceptual modeling in SDBC. In

ICEIS’05, 7

Int. Conference on Enterprise Inf.

Systems. ICEIS Press.

Shishkov B. and J.L.G. Dietz, 2004-1. Aligning business

process modeling and software specification in a

component-based way, the advantages of SDBC. In

ICEIS’04, 6

International Conference on Enterprise

Information Systems. ICEIS Press.

Shishkov B. and J.L.G. Dietz, 2004-2. Design of software

applications using generic business components. In

HICSS’04, 37

Hawaii International Conference on

System Sciences. IEEE Computer Society Press.

Shishkov B. and J.L.G. Dietz, 2004-3. Deriving Use Cases

from Business Processes, The Advantages of DEMO.

Enterprise Inf. Systems V, Ed: O. Camp, J.B.L. Filipe,

S. Hammoudi, M. Piattini, Kluwer Academic Publ.,

Dordrecht/Boston/London.

Stamper, R., 2000. Organizational Semiotics –

Information Without the Computer? Information,

Organization, and Technology – Studies in

Organizational Semiotics, K. Liu, R.J. Clarke, P.B.

Andersen, R.K. Stamper, ed., NL: Kluwer.

Tropos Project. http://www.troposproject.com

Winograd, T. and F. Flores, 1986. Understanding

Computers and Cognition: A New Foundation for

Design. Ablex, Norwood, NJ

ICEIS 2006 - INFORMATION SYSTEMS ANALYSIS AND SPECIFICATION
