Design Guidelines for Analysis and Safeguarding of

Privacy Threats in Ubicomp Applications

Elena Vildjiounaite

, Petteri Alahuhta

, Pasi Ahonen

, David Wright

and Michael Friedewald

VTT Technical Research Centre of Finland, Kaytovayla 1, 90580, Oulu, Finland

Trilateral Research and Consulting, 12 Tybenham Road, London SW19 3LA, UK

Fraunhofer Institute Systems and Innovation Research, Breslauer Strasse 48, 76139

Karlsruhe, Germany

Abstract. Realisation of the Ubicomp vision in the real world creates signifi-

cant threats to personal privacy due to constant information collection by nu-

merous tiny sensors, active information exchange over short and long distances,

long-term storage of large quantities of data, and reasoning on collected and

stored data. An analysis of more than 100 Ubicomp scenarios, however, shows

that applications nowadays are often developed without considering privacy is-

sues. This paper suggests guidelines for estimation of threats to privacy, de-

pending on real world application settings and on choice of technology; and

guidelines for developing technological safeguards against privacy threats.

1 Introduction

Development of new applications and enabling technologies in Ambient Intelligence /

Ubiquitous Computing (these terms are equally common) often starts from writing an

application scenario: a script that describes in which settings a new technology will

be used. After having reviewed more than 100 Ubicomp scenarios (e.g., [1-8]), we

found that often proposed applications do not consider privacy issues, even though

many researchers [9-11] have already pointed out privacy threats arising from Ubi-

comp (its continuous attention to human activity and increased autonomy of computer

actions) and from rapid technology development, especially the increase in com-

puters' abilities to acquire, store and process more and more different kinds of infor-

mation from different sources. Detailed analysis of privacy threats in the Ubicomp

world is beyond the scope of this paper; such analysis can be found e.g. in [10-12].

After acknowledgement of privacy threats, work on privacy protection has started

[9, 13, 14]. Such work has mainly considered information privacy, i.e., the personal

right of an individual to control which information about him/ her is collected, stored

and shared, while privacy also has other important aspects [11, 15], e.g., “the right to

be left alone" is very important for personal development because people need rela-

tive insularity for developing goals, values and conceptions of self [15].

Vildjiounaite E., Alahuhta P., Ahonen P., Wright D. and Friedewald M. (2006).

Design Guidelines for Analysis and Safeguarding of Privacy Threats in Ubicomp Applications.

In Proceedings of the 3rd International Workshop on Ubiquitous Computing, pages 49-61

DOI: 10.5220/0002499800490061

 SciTePress

The work [9] suggests how the fair information practices (listed in current data

protection laws) can be applied to Ubicomp applications, and shows how difficult it

might be to apply them. The work of Lahlou et al. [14] focuses "on the specific issues

of the data collection phase", although such generic design guidelines as "think before

doing" and "understand the way in which new technologies change the effects of

classic issues" (i.e., existing solutions in the physical world) can be applied not only

to data collection. Our work makes these generic design guidelines more specific.

The work of Hong et al. [13] proposes privacy risk models based on two aspects:

first, social and organizational context in which an application is embedded (who are

data shares and data observers; what kinds of personal information are shared; what is

the value proposition for information sharing; its symmetry, etc.). The second aspect

is technological (how are collection, storage and retention of personal data organized;

who controls the system; is there any possibility to opt-out). This is close to our un-

derstanding of privacy threats, but we suggest taking into account other aspects also,

especially probability of accidental (not intended by designers) information flow.

Currently most of research on privacy protection is concerned with protection of

information privacy in network applications and with security of personal devices,

and considers privacy protection for current technology settings. The main privacy

protecting principles in network applications are stated to be anonymity (possibility to

use a service without disclosure of user identity); pseudonymity (possibility to use a

service without disclosure of user identity, but still be accountable for that use);

unlinkability (possibility to use multiple services without others being able to dis-

cover that these resources were used by the same user) and unobservability (possibil-

ity to use a service without others being able to observe that it is being used).

Even in current technology settings, however, these principles are not yet fully im-

plemented [16]. Implementation of these principles in future settings (as they are

described in scenarios) would be more challenging and not always possible. In net-

work applications, users have some understanding of which data are collected and

means to restrict data collection (e.g., to use Internet cafe for accessing web sites). In

Ubicomp environment, full of numerous invisible sensors, it is difficult (if not impos-

sible) for users to understand and to control data collection and to achieve unob-

servability, anonymity and pseudonymity, because the user and his/ her data are not

physically separated anymore. Another important difference between network appli-

cations and emerging applications is that neither mobile devices nor web usage pene-

trates through such strong privacy protecting borders as walls and the human body,

while physiological, video and audio sensors, proposed for future settings, have much

stronger capabilities to identify a person and to reveal personal activities and feelings.

In this paper, we present dimensions of privacy threat analysis and suggest guide-

lines for privacy protection for future Ubicomp applications.

2 Traditional Privacy Protecting Borders

In the work of Lahlou et al. [14], it is suggested that privacy protection requires un-

derstanding of how new technologies change the ways developed in physical world.

In the physical world, personal privacy is protected by the following borders [11]:

• Natural Borders: physical borders of observability, such as walls, clothing, dark-

ness, facial expression (a natural border against the true feelings of a person).

• Social Borders: expectations with regard to confidentiality in certain social

groups, such as family members, doctors and lawyers, e.g., the expectation that

your colleagues do not read personal fax messages addressed to you.

• Spatial or Temporal Borders: expectations by people that parts of their lives can

exist in isolation from other parts, both temporally and spatially, e.g., a previous

wild adolescent phase should not have a lasting influence on the current life of a

father of four; a party with friends should not affect relations with colleagues.

• Borders due to Ephemeral or Transitory Effects: expectations that certain action

or spontaneous utterances will be soon forgotten or simply unnoticed because

people’s attention and memory are limited.

Physical borders are perhaps perceived as most reliable, which can be illustrated

by, e.g., how poker players control their faces or by the custom of knocking at a

closed door of somebody's private room or office. People also have a well-developed

mental model of the limits of their own or others' ability to notice and to remember

details of what's going around. For example, people in a conference room usually

expect that others' attention and memory are devoted to contents of a presentation

rather than to the auditory side. Concerning social and spatial borders, people per-

ceive them as not so strong, e.g., the likelihood of encountering the same people in

different circumstances or of broken confidentiality is not negligible. Generally, the

stronger is personal belief that certain border is reliable, the more difficult will be

adaptation to its violation by a new technology. Experiments in the research area of

computer-supported collaborative work suggest one example of the adaptation diffi-

culty. In order to facilitate awareness and communications between colleagues, video

cameras were installed in the offices of participants. Although awareness has proved

to be useful, the experiments have shown that people often act according to an "old"

mental model of being reliably hidden by office walls [17].

3 Dimensions of Privacy Threats Analysis

We think that privacy risks fall into two major groups: first, application domain-

dependent risks, which depend on the supported personal or organizational activity.

For example, health data are considered sensitive, and designers of applications for

hospitals follow corresponding privacy-protecting regulations. Second, privacy risks

are caused by a mismatch between personal expectations about current privacy level

and reality, which do not depend on an application domain. If a person perceives his

current situation as private (e.g., being alone at home), but in fact he is being moni-

tored, the chances that personal secrets will be discovered are higher than if the per-

son perceives the current situation as public (e.g., making a presentation in a large

meeting) and takes care of own privacy himself.

After reviewing Ubicomp application scenarios, we observed that the possibility of

privacy being violated accidentally is not always considered. For example, in [1], it is

suggested to make video recordings of meetings, so that writing "meeting minutes" is

not needed. Such recordings of presenter mistakes, personal conversations, spontane-

ous remarks, laughter or bored faces, however, can affect one’s personal career nega-

tively, because playback of a video recording (with the possibility of watching the

same scene many times) reveals many more details than physical presence at the

meeting when people are concentrated on the main points of working problems.

We suggest the following dimensions for analysis of privacy threats:

• Dimensions of the real world:

o Personalities of humans

o People’s activity

o Environment where activity takes place

• Dimensions of technology functionality

o Information flow

o Computer control level vs. personal control level

o Balance between different aspects of technology (storage and com-

munication vs. reasoning capabilities and control level)

3.1 Dimensions of Real World: Humans, Activities and Environment

The notion of what is considered private and what is not depends on a person and on

a situation (context) [15]. For example, the chances that a wife or children acciden-

tally access personal data of a married person are fairly high; however, secrets from

family members are not unusual. We suggest that application designers should con-

sider, first, how privacy-safe is an application for a user who has secrets from family

members (who are always nearby); from work colleagues and superiors; and from an

insurance company capable of hiring good specialists for acquiring personal data.

Second, it is needed to consider how much time and knowledge are needed for con-

figuring privacy protection in a personal device and whether anyone can do it fast.

Personal activity is an important dimension for privacy risk analysis because an ac-

tivity consumes and produces information flow, e.g., a lot of financial data are in-

volved in paying bills; health and identity data are involved in a call to a doctor. Envi-

ronment is an important dimension because people’s mental models of current pri-

vacy levels are based on traditional perceptions of an environment (e.g., "now I am

alone in my office, thus, nobody can see me") and people behave more or less freely

depending on their estimation of current privacy levels. We suggest that applications

should take into account the following:

• traditional perceptions of the environment (e.g., perception of a home as private

environment; perception of a wall as a non-transparent object)

• common activities in the environment (e.g., in an office people usually work)

• other probable activities in the environment (e.g., calling a doctor or flirting with

a colleague in an office environment).

Privacy threats coming from real world settings can be roughly categorized as

high, medium and low. We suggest that high threats appear in the instance of activi-

ties dealing with health care, finances and communications between family members

and close friends; high threats also appear in the home or office environment (because

people can not avoid dealing with private issues at work and are highly dependent on

their work). Medium threats to privacy appear in shopping, learning and mobility

activities (by mobility, we mean travelling within a city as well as holiday and work

trips); and relatively low threats are associated with entertainment activity.

3.2 Dimensions of Technology Functionality

A typical view of an Ubicomp application is presented in Figure 1. Thin arrows indi-

cate information which is collected (pulled) by the system and exists there for a short

or long time, which carries a potential threat that personal data become available,

against a user's wishes, to others (neighbours, government, insurance companies, etc)

if they get access to them. Thus, threats appear either if access control to information

fails (e.g., communications are intercepted, or stored data are unprotected) or if data

contains accidentally acquired secrets (e.g., something in the image background).

Fig. 1. Generic view of Ubicomp application: thin arrows indicate information which is col-

lected and exists in the system, thick arrows indicate information push.

Thick arrows indicate information push, which implies that message contents will

be certainly delivered to their destination and will be available to receivers (or will

cause an automated action, such as opening a door lock in office access control appli-

cations). Consequently, more threats appear: first, access control to a message can

fail; second, message contents can tell the recipient more than the sender intended;

third, a message can be delivered at a wrong time; and last, harm can be caused by

actuators' actions (e.g., failure to lock a door allows everybody to enter a room).

3.2.1 Information Flow and Application Control Level

Information flow starts from data collection performed by sensors. The most popular

sensors in Ubicomp scenarios are audio, video, positioning, physiological and safety

and comfort sensors, as well as logging of human-computer interaction actions.

From the privacy point of view, physiological sensors are most dangerous because

they detect what is inside a person's body, i.e., they "break" into the most private

sphere. These sensors are the basis for building health care applications, where strict

rules for protection of health data exist. Ubicomp scenarios, however, suggest these

sensors for purposes other than health and wellness. Detection of a person's mood and

emotions is an active research area [18], and suggested applications include detection

of interesting scenes for automatic audio and video capture for lifetime personal store

[8] and estimation of a user's liking of TV programmes [2]. However, if physiological

data are linked to the contents of TV programmes and to the presence of other people,

personal feelings become dangerously "naked" and can, for example, reveal to par-

ents with whom their child is in love; or can be used by government for monitoring

the loyalty of citizens. Physiological sensors can also detect health problems, but this

data will not be properly protected because data protection requirements in the do-

main of TV personalization are not very strict.

Video and audio sensors violate natural privacy-protecting borders such as walls,

and video cameras can reveal a lot more than audio sensors. In Ubicomp scenarios

they are suggested, first, for real-time communications between people, e.g., for help-

ing parents to check what their children are doing [5]. Second, such sensors are sug-

gested for memory augmentation, e.g., recording of work meetings [1] and personal

memory aids [8]. The first type of application "breaks the walls"; the second type of

application violates people’s belief in the limits of others’ attention and memory.

Data from safety and comfort sensors (temperature, light, car acceleration; biomet-

ric sensors for access control) can reveal personal lifestyle either inside or outside

homes. The threat of identity theft may be associated with biometric sensors. Another

important issue is that these sensors often initiate information push, e.g., they may

give reminders to switch off the stove or employ actuators to do it automatically. This

is beneficial for people suffering from dementia or for families with babies. However,

if teenagers are assumed to be as irresponsible in caring about home safety as babies,

there may be little opportunity left for teenagers to develop a sense of responsibility.

Application control level denotes how much technology does on behalf of users.

For example, an application that reminds a user to take pills in case of high blood

pressure has a high control level because it initiates a measuring of blood pressure

and initiates a dialog with a user. Consequently, such dialog can annoy the individual

or reveal personal health details if it happens at a wrong moment or in public. An

application which filters shopping advertisements according to user preferences also

has a high control level, because the user can never know about certain shopping

alternatives if they are filtered out. (For such applications, an important question is

who sets filtering rules and how to prevent the favouring of a particular shop.)

3.3 Summary of Technology Threats

With greater information collection, transmission and storage capabilities and higher

control levels, technology poses more privacy threats. Most Ubicomp scenarios in-

volve application-dependent information storage and a lot of wireless communica-

tions (between objects, people and organizations).

We suggest that significant threats to privacy arise if technology penetrates walls

and the human body, e.g., by using physiological, video and/or audio sensors. Sig-

nificant threats are also caused by high control level of technology (i.e., the capability

of a technology to act on behalf of a person, for example, to call an ambulance in an

emergency); by biometrics sensors (due to the possibility of identity theft); and by

aggregation either of a lot of data about one person, or some data about many people.

Medium threats are associated with positioning sensors (used alone, they provide

location data, but not much activity data) and with medium level of technology con-

trol (the capability to make proactive suggestions, e.g., to give reminders). Fairly low

threats are associated with low control level (e.g., ranking advertisements according

to criteria explicitly set by the user), and with comfort sensors (lighting, heating, etc).

4 Design Guidelines for Privacy Protection

Different application domains and components present different threats to privacy

and require different safeguards. One of the most generic safeguards is to minimize

data collection to what is absolutely needed for application purposes (called "Privacy

Razor" in the work of Lahlou at el. [14]). In practice, however, it is not easy to de-

termine what "minimally required data" is, because the same data can be acquired in

many ways, each of them presenting different threats for privacy. For example, movie

recommendations applications need user feedback data, and ways to obtain it include:

use of physiological sensors; analysis of facial expressions; speech recognition; moni-

toring such user actions as fast forward scrolling (which is safest for privacy).

Another generic safeguard is data encryption during data transmission and storage,

but even 100% reliable encryption is not a magic solution; first, because a lot of in-

formation can be gained by monitoring the traffic of encrypted data. Second, the

crucial problem is proper access control to encrypted data, and this problem is not

solved yet. Encryption of data stored in a personal device does not help as long as the

device considers itself in the hands of an authorised owner, which is usually for a

long time after it has been switched on. Appropriate protection of data stored in per-

sonal devices will not be possible until user-friendly access control methods are de-

veloped (that is, methods for frequent, reliable and unobtrusive user authentication).

We suggest that the most important safeguards are appropriate access control to

data and appropriate intelligence of applications, because only they can help against

the dishonest person accessing the data required by a Ubicomp application and

against accidental acquisition of sensitive data by the Ubicomp application, which can

happen either with a single sensor (e.g., video), or via linkage of several sensors' data.

Consequently, we suggest that if an application poses significant threats to per-

sonal privacy in the real world, and if significant threats are caused by choice of tech-

nology, both lightweight and strong safeguards, listed below in more detail, should be

implemented. In some cases, the required level of privacy protection might be too

expensive for the application purposes; or appropriate safeguards may not be mature

yet (e.g., automatic detection of sensitive video data is still in its infancy). Research

on many strong safeguards has already started, but the results are not yet ready for

real life use. In these cases, privacy risks should be decreased by choosing less threat-

ening technology for implementation of a desired functionality: to use other means of

information acquisition, or to decrease the control level of a particular technology.

Additionally, we suggest that application designers should develop some means to

escape from Ubicomp applications gracefully, so that nobody understands why the

user is inaccessible, similar to the current situation with mobile phones when not

answering a phone call is perceived as not unusual (the battery may be discharged; or

the user may be in an area where connections don't work well; or the user may be in a

shower, etc) and does not give any hint of the user's activities or intentions. In a fu-

ture of small powerful hardware embedded into clothes, watches and walls and with

improved network coverage, however, escape from communications might not be that

easy. For example, if users have switched off a meeting recording, one might assume

that they are either discussing work secrets or personal affairs. Thus, an application

should always stop in exactly the same way, e.g., a stopping should be always abrupt.

4.1 Minimisation of Data Collection, Transmission and Storage

We suggest the following relatively lightweight safeguards:

1. Instead of logging raw data, only data features should be logged by using either

hardware filters or by doing as much real-time pre-processing as possible (e.g., log-

ging only the number of peaks or the time period when heart rate was above a prede-

fined threshold; or detect predefined contexts and user actions in real time);

3. Time-stamping of logged data should be limited by making it relative to other

application-related information (e.g., " in the first hour after taking a pill, the blood

pressure was normal, after that it was elevated") or by averaging and generalising

time stamping (e.g., "heart rate was high for two hours"). This should prevent a dis-

covery that, e.g., the heart rate of a boy becomes high each time he meets certain girl;

4. Hardware used for data collection should not have extra memory and extra data

transmission capabilities, and no easy plug-ins for increasing them (to prevent spy-

ing). This can be achieved, e.g., by giving to each application access rights to a cer-

tain memory block instead of giving to all applications access to the main memory;

5. Data should be deleted after an application-dependent time, e.g., when a user buys

clothes, all information about their textiles, prices, designers, etc should be deleted

from the clothes' RFID tags. If applications require active RFID tags (such as for

finding lost objects [7]), the ID of the RFID tag should be changed, so that no links

between a shop’s database and personal clothes are left;

6. Applications which don't require constant monitoring should switch off automati-

cally after a certain period of user inactivity (for example, video cameras automati-

cally switch off after the end of a game).

Fairly heavy-weight (strong) safeguards (required for applications posing signifi-

cant privacy threats) would be:

1. Authorisation at the stage of upgrading hardware and adding plug-ins

2. Anti-spyware software on each piece of hardware.

4.2 Privacy Protection in Networks (Transferring of Identity and Personal

Data)

Data transfer in Ubicomp applications takes place between remote locations (e.g., in

m-commerce applications or web browsing) as well as between diverse sensors in a

smart space and between devices which belong to a personal area network (PAN),

e.g., several sensors attached to a human body in different placements or several

personal belongings. We suggest the following light-weight safeguards:

1. Data filtering on personal device should be preferred, if possible (e.g., instead of

sending a user's financial preferences to a jewellery shop, the application can query

the shop about all items, and sort them by price and other criteria already on the per-

sonal device. This approach requires more data transmission and does not allow use

of certain recommendation techniques known as collaborative filtering, but it has the

advantage that users don't feel that a piece of metal decides what can they afford).

2. Data transmission and storage, if they take place over long distances, should allow

anonymity or pseudonimity (using different identities with minimally sufficient per-

sonal data in different applications, as suggested in [19]) of a data provider (e.g., if a

user buys something and has paid for it, the user's identity should be hidden). The

ways to do it include, first, methods to prove user authorisation locally and to trans-

mit over a network only a confirmation of authorisation; second, methods to hide user

identity, e.g., by distributing this knowledge over many network nodes. The goal of

pseudonimity is to prevent a discovery, either from personal contact details or from

the ID of a personal device, that the same person has ordered a lot of chocolates and

diabetes-related medicines, which might be of interest to an insurance company and

result in increase of the person’s insurance premium’s due to not following a diet.

3. Wherever possible, to implement unobservability in PANs and smart spaces by

limiting the communication range so that signals stay within desired spatial limits

(inside a room or a car), unlike the current situation when two owners of Bluetooth-

enabled phones are aware of each other’s presence in neighbouring apartments.

Higher-level protection should include the following:

1. Data transmission should not use the ID of a personal device or an object; instead,

IDs should be used only for a current communication session (otherwise it is easy to

associate a device or an object, e.g., eye glasses, with a person).

2. Data protection by security means and access control methods (see Section 4.3)

from malicious actions (eavesdropping, data modifications, denial of service, etc).

4.3 Access Control

The traditional understanding of the term “access control” is in regard to granting a

person the right to log on to a system or to have access to an otherwise restricted

office. Recently, “access control” has also taken on a sense of checking which soft-

ware accesses personal data and how the data will be processed. Implementation of

proper access control methods is one of the most important safeguards. Unfortu-

nately, reliable unobtrusive access control methods for privacy protection do not exist

in yet. This situation is best illustrated by usage of mobile phones (which store a lot

of personal data), which are not protected at all for a long time after being switched

on due to lack of user-friendly authentication methods suitable for frequent user veri-

fication. Consequently, loss or theft of a phone presents threats to its owner's privacy.

Proper access control should be also built in licensing languages (methods to im-

pose correctness of data processing and to do privacy audit afterwards [16]). One of a

few existing methods to specify personal privacy policy regarding web applications,

P3P, neither forces web sites to follow the user’s wishes (the user just gets a notifica-

tion about a mismatch between privacy policies), nor to adhere to their own promises

regarding processing of user data.

Lightweight methods of access control include the following:

1. Frequent tests for compatibility and updates of anti-virus and firewall software;

2. Authorisation for accessing not only personal data, but also device characteristics,

unlike the current situation with Bluetooth device IDs or IDs of RFID tags, which are

easily available [20].

Stronger access control methods include the following:

1. Enforcement of privacy law and policies by expressing legal requirements and

personal user wishes in machine-readable rules and by embedding these rules into

data in such a way that they can not be ignored or bypassed (similar to how digital

rights management methods are aimed at preventing illegal copying of files) [16].

These privacy rules should describe what is allowed to do with data in different con-

texts (e.g., in case of merging databases), and to ensure that the attached rule is ap-

plied. Also needed are methods of facilitating privacy audits (to check correctness of

data processing, which should work even in case when the data are already deleted).

2. Access control to sensitive or aggregated personal data should be continuous, un-

obtrusive and context-dependent (e.g., requiring more reliable authentication if a user

starts a more sensitive application). Continuous unobtrusive access control is gener-

ally more reliable, and it decreases the risk of identity theft. For example, if a car lock

can only be opened by the car owner’s fingerprint, there is a danger that criminals

will either produce a faked fingerprint sample or will cut off the owner's finger. How-

ever, if authentication of the owner were to continue inside the car (e.g., by weight

sensors embedded in the seat, by positions of the seat and mirrors, by driving pat-

terns, by voice or even by face recognition), a thief will eventually be discovered.

3. In order to protect against an authorised but dishonest person, unusual patterns of

copying and processing of personal data should be detected (e.g., if the next back-up

of data takes place soon after a previous back-up, then it may indicate a data theft).

4.4 Artificial Intelligence Methods

All software algorithms are to some extent AI methods. In the context of this paper,

however, we call AI safeguards methods of advanced reasoning capabilities, which

are not mature solutions yet, although research on them is actively going on. Many

privacy threats appear due to the fact that reasoning capabilities of software do not

grow as fast as hardware capabilities (storage and transmission capabilities). Ad-

vanced AI safeguards are the main means of protecting people from accidental, unin-

tentional privacy violation, such as disturbing a person at a wrong moment or re-

cording some private action. They are needed also for advanced access control and

anti-virus protection, by catching unusual patterns of data copying or delays in pro-

gram execution.

Lightweight AI safeguards can be rule-based, with rules derived from human com-

mon sense, e.g., that sensitive data can be more easily acquired when there are only

one or two persons in a room than when there are many people. Common sense sug-

gests also giving more freedom and responsibility to teenagers than to younger kids.

Since many exceptions to common-sense rules exist, however, we suggest that AmI

applications with high control levels should be capable of the following:

1. Detection of sensitive data (e.g., recognition that persons in a photo are naked or

kissing or that a conversation is private, even if it takes place in an office);

2. Adaptation to people's ethics (e.g., not to take photos of naked persons automati-

cally; not to provide reminders about private obligations, e.g., taking medicines, in

public; not to record personal conversations; to respect everybody's dignity);

3. Adaptation to different cultures and etiquettes;

4. Intelligent online summarisation of records, e.g., online conversion of a meeting

audio stream into a text document, which would include only working discussions;

5. Intelligent interpretation of users' commands with natural interfaces: application

should have the means to resolve ambiguities (e.g., to understand when the user ad-

dresses the application, and when he/ she talks to other humans; and to be able to

understand complex language constructions in any context).

4.5 Developing of Transparancy Tools

Unfortunately, implementation of an application that records only working discus-

sions is more difficult than implementation of application that records everything.

One partial solution can be raising user awareness about video cameras and data flow.

Since it is impossible to provide details of every surrounding sensor and application,

especially in public places, a concise and unified form of initial warnings should be

developed about most privacy-violating technologies (such as those that record video

and audio data, log personal identity data, physiological and health data), similar to a

form of road signs. Standardisation of privacy policy has started already for web sites

[21]; however, transparancy tools should be applicable to all Ubicomp components.

User-friendly interfaces are needed for providing awareness and for configuring

privacy policies. Maintaining privacy should not be a burden for a user, but, on the

other hand, if the user is really concerned with privacy protection, he should be able

to configure easily the following important settings:

1. the goal of the application (e.g., to record a meeting);

2. the degree of the application’s autonomy (what can the application do on its own

initiative and in which cases, e.g., will it start recording when all meeting participants

arrive; will it suggest to someone that he take a medicine at certain time of a day or

when his blood pressure rises above a certain rate);

3. the information flow from the user who should be able to understand and to con-

figure the following:

• what data are collected and how (e.g., continuous record of blood pressure vs.

counting the number of high blood pressure peaks);

• what happens to the data after collection (what data are processed locally,

what are transmitted; what are stored, where and for how long);

• what patterns are searched (dependency of high blood pressure on absolute

time vs. dependency on relative time, e.g., from the moment of taking a pill);

4. the flow of information to the user who should be able to configure the following:

• how the information is presented (e.g., is a reminder to take a medicine given

as an audio warning or via SMS);

• how the information is filtered (e.g., an application that filters advertisements

can either completely block information which is considered as uninteresting;

or present a complete list of items ranked by their estimated usefulness).

4.6 Developing Means of Recovery

It seems quite probable that losses of personal data will happen in a future, just as

identity thefts happen now. Consequences of data losses can include problems in

personal relations, work discrimination, financial problems or even death, and recov-

ering from some data losses can be impossible or require other than technological

methods, e.g., legal methods. Nevertheless, some problems can be solved by means of

technology. For example, in case of theft of somebody's biometric data, there should

exist means to replace compromised biometrics with another authentication method

(another biometric, tokens, etc) everywhere (in all credit cards, in all office/ home/

car locks etc), and to do it fast and effortlessly for the person, possibly via networks.

Another problem is recovery from a loss of or damage to a personal device. Pro-

tection of personal data in a lost device can be achieved by strict access control and

encryption. However, it is also important that the user should not need to spend a lot

of time customising and “training” a new device; instead, the new device should itself

load user preferences, contacts, favourite music, etc, from some back-up service,

probably a home server, and do so in an effortless and secure way for the user.

5 Conclusions

Recent news reports suggest that large-scale surveillance by means of ubiquitous

technologies (Internet and phones) has already started [22]. However, analysis of

Ubicomp scenarios shows that privacy protection is not yet considered as a necessary

design requirement despite the appearance of significant threats to personal privacy.

This paper has presented a model for privacy threats analysis for Ubicomp devel-

opers, and suggested guidelines for decreasing privacy threats. A typical approach to

privacy threat analysis is to estimate sensitivity of data, which in turn depends on the

application domain (e.g., health care data are considered sensitive) and on informa-

tion consumers [13]. We suggest that privacy protection should also depend on which

real-life privacy protecting borders are violated by the technology used, because the

likelihood of acquiring sensitive data accidentally is high if technology penetrates

through supposedly reliable physical borders. We suggest that developing strong

access control methods both for humans and for software is crucial for privacy pro-

tection. We also suggest development of a unified, concise way of maintaining user

awareness about application functionality, possibly graphical, and of user-friendly

methods of presenting more detailed information about application functionality and

how such functionality can be configured. Furthermore, we suggest development of

ways to escape from being tracked by Ubicomp applications, so that such escape is

not perceived as offensive or as a sign that someone has something to hide.

Since intelligent reasoning algorithms currently are less advanced than storage and

transmission capabilities, technologies that are highly privacy-threatening should be

limited to domains where they are justified by both domain requirements and existing

personal data protection regulations, as in health care. In other domains, usage of

such technologies should be under strict personal control, and applications should

switch off automatically after a certain period of user inactivity. We also suggest

avoidance of highly privacy-threatening technologies in applications where the goal

should be to increase the user's comfort (such as personalisation of TV), and use of

less dangerous technology instead.

This paper is based on work done in the context of the SWAMI project [23].

References

1. Aschmoneit, P.; Höbig, M.,eds. (2002). Context-Aware Collaborative Environments for

Next Generation Business Networks: Scenario Document, COCONET deliverable D 2.2.

2. Palmas, G.; Tsapatsoulis, N.; Apolloni, B. et al. (2001). Generic Artefacts Specification

and Acceptance Criteria. Oresteia Deliverable D01. Milan: STMicroelectronics s.r.l

3. Savidis, A. et al. (2001). Report on Key Reference Scenarios. 2WEAR Deliverable D1.

4. Åkesson, K.-P.; Humble, J.; Crabtree, A.; Bullock, A. (2001). Usage and Development

Scenarios for the Tangible Toolbox. ACCORD Deliverable D1.3.

5. Amigo scenarios: http://www.ctit.utwente.nl/research/projects/telematics/other/amigo.doc/

6. Kim, S. W.; Kim, M. C.; Park, S. H. et al. (2004): Gate reminder: a design case of a smart

reminder. In: Benyon, D.; Moody, P. et al. (Eds.): Proceedings of the Conference on De-

signing Interactive Systems, Cambridge, MA, USA, August 1-4, 2004. ACM, pp. 81-90

7. Orr, R. J.; Raymond, R.; Berman, J.; Seay, F. (1999). A System for Finding Frequently

Lost Objects in the Home, Technical Report 99-24, Georgia Tech.

8. Gemmel, J., Williams, L., Wood, K., Lueder, R., Bell, G., (2004) Passive Capture and

Ensuing Issues for a Personal Lifetime Store, CAPRE 04

9. Langheinrich, M. (2001): Privacy by Design – Principles of Privacy-Aware Ubiquitous

Systems. In: Abowd, G. D.; Brumitt, B. et al. (Hrsg.): Proceedings of the Third Interna-

tional Conference on Ubiquitous Computing (UbiComp 2001). Berlin und Heidelberg,:

Springer-Verlag (Lecture Notes in Computer Science, 2201), pp. 273-291.

10. Langheinrich, M. (2003): The DC-Privacy Troubadour – Assessing Privacy Implications of

DC-Projects. In: Designing for Privacy Workshop. DC Tales Conference, Santorini,

Greece.

11. Bohn, J., Coroama, V., Langheinrich, M., Mattern, F., Rohs, M., (2005) Social, Economic,

and Ethical Implications of Ambient Intelligence and Ubiquitous Computing, In: W. We-

ber, J. Rabaey, E. Aarts (Eds.): Ambient Intelligence. Springer-Verlag, pp. 5-29.

12. Friedewald, M., Vildjiounaite, E., Punie, Y., Wright, D., Privacy, identity and security in

ambient intelligence: A scenario analysis, Telematics and Informatics, In Press

13. Hong, J., Ng, J, Lederer, S., Landay, J., Privacy Risk Models for Designing Privacy-

Sensitive Ubiquitous Computing Systems, in DIS 2004

14. Lahlou, S.; Jegou, F. (2003). European Disappearing Computer Privacy Design Guideslines

v1. Ambient Agora Deliverable D15.4. Electricité de France.

15. Nissenbaum, H. (2004), Privacy as Contextual Integrity, Washington Law Review 79, No.1

16. Camenisch, J., ed.,. PRIME Deliverable D16.1, 2005.

17. Bellotti, V., Sellen, A., Design for Privacy in Ubiquitous Comp. Environments, ECSCW'93

18. Nasoz, F., Alvarez, K., Lisetti, C., Finkelstein, N., (2003), Emotion Recognition from

Physiological Signals for User Modelling of Affect, In Proceedings of the 3rd Workshop

on Affective and Attitude User Modelling (Pittsburgh, PA, USA, June 2003)

19. Nabeth, T., et al., FIDIS Deliverable 2.2: Set of use cases and scenarios.

20. Knospe, H.; Pohl, H. (2004): RFID Security. In: Information Security Technical Report 9,

No. 4, pp. 30-41

21. Cranor, L., P3P: Making Privacy Policies More Useful, IEEE Security and Privacy, 2003

22. http://www.aclu.org/safefree/nsaspying/23989res20060131.html

23. http://swami.jrc.es/pages/index.htm
