Formalizing Real-world Threat Scenarios

Paul Tavolato

, Robert Luh

1,2

and Sebastian Eresheim

1,2

Research Group Security and Privacy, University of Vienna, Kolingasse 14-16, A-1090 Vienna, Austria

Department of Computer Science, UAS St. Pölten, A-3100 St. Pölten, Austria

Keywords: Threat Analysis, Formal Methods, Stochastic Game Theory, Model Checking.

Abstract: Using formal methods in threat analysis would be of great benefit to securing modern IT systems. To this end

a strictly formal description of attacker-defender scenarios is vital. This paper demonstrates how attacker and

defender behavior and its interrelationship can be defined using Markov decision processes and stochastic

game theory. Based on these definitions, model checking methods can be applied to find quantitative answers

to important questions relevant in threat analysis. A main focus lies on the applicability of the method to real-

world situations. This is accomplished by incorporating information from several proven tactical and technical

knowledge bases. Practicability of the method is shown by using the model checking tool PRISM-games.

1 INTRODUCTION

Fighting cyber security threats has become an

inevitable must for every organization, may it be

small-scale businesses, public service providers, or

multinational corporations. Since 100% security

cannot be achieved in reality, a detailed look at the

effectiveness of counteractive measures is vital in

providing the best possible defense within a given

budget. Alternatively, it might be necessary to

determine the exact budget needed to guarantee a

certain level of security. One of the fundamental

operations in this context is threat analysis.

In the realm of cyber security, threat analysis is

understood as the process of assessing the activities

and capabilities of unknown intelligence entities or

criminals. Cybersecurity threats can be defined as a

malicious act that seeks to disrupt proper operation of

IT systems by violating one or more of the central

cybersecurity properties: Confidentiality (by stealing

data), Integrity (by manipulating data), and

Accessibility (by disrupting or rendering impossible

the normal flow of data processing). These principals

of protection are known as the CIA triad (Keyser,

2018). In a broader understanding threat analysis also

comprises the process used to determine which

components of the system need to be protected, as

well as the types of threats (security risks) they should

be protected from. This information is necessary to

determine strategic locations in the IT architecture

and to design reasonable and effective security

measures to be implemented (McCabe, 2007).

Several methods for threat analysis have been

proposed in the literature, including STRIDE and

Pasta (see for example (Shostack, 2014), (Tarandach

& Coles, 2020), or (Swiderski & Snyder, 2004)).

Though all these methods are very useful, they lack

an essential property: they are mainly of an informal

or semi-formal nature. If they contain some formal

parts, these are not strictly formal in a mathematical

sense. Therefore, they cannot be used in connection

with formal methods. By formal methods we

understand the use of mathematically rigorous

techniques for modeling a system and the formal

definition of properties in some sort of logic, e.g.,

temporal logic. The validity of these properties can

then be proved automatically by the use of software

tools. Such proofs are often carried out by a method

called model checking. For cyber security formal

methods have been used so far almost exclusively in

the realm of software development, especially with

regard to the development of safety-critical systems.

Using formal methods with threat analysis on a higher

system level, however, is still a marginal topic in the

scientific literature. Our main focus lies on the

analysis of existing IT systems at the users’ site. The

user in this scenario has no possibility to change the

software itself. S/he is only able to set and enforce

security measures that will detect, mitigate or – at best

– prevent attacks on her/his system.

Tavolato, P., Luh, R. and Eresheim, S.

Formalizing Real-world Threat Scenarios.

DOI: 10.5220/0010781300003120

In Proceedings of the 8th International Conference on Information Systems Security and Privacy (ICISSP 2022), pages 281-289

ISBN: 978-989-758-553-1; ISSN: 2184-4356

281

This paper revolves around applying formal

methods in threat analysis: The system, consisting of

both the attacker and the defender side is modeled in

a mathematically rigorous way. Due to the evident

antagonism between defender and attacker, concepts

from non-cooperative game theory are used,

assuming the attack on a system is a game between

the system owner, the defender, and a hacker, the

attacker. Such a game contains non-determinism: the

attacker as well as the defender can choose among a

set of available actions (restricted by insight, skill and

budget). They are also of a stochastic nature: the

success or failure of an action is determined by a

success probability. Given such a rigorous formal

definition of the attacker-defender system (the game),

one can formulate properties that represent essential

questions such as:

 What is the maximum probability that an attacker

with a specific goal and profile will ultimately

succeed?

 What is the maximum defender success

probability with a given defender budget in the

given situation?

 How does a significant lower defender budget

influence the defender’s minimum success

probability?

To answer these and similar questions we will use

formal methods of stochastic model checking.

Semantically the model is based on an adversarial

cyber security game for threat assessment called

PenQuest (Luh, Temper, Tjoa, Schrittwieser, &

Janicke, 2019). In this role-playing game (RPG) two

players, the attacker and the defender, fight against

each other in order to achieve their respective goal:

The attacker has a predefined goal (violating one part

of the CIA triangle) and the defender has a given

infrastructure he wants to defend against attacks. The

game is characterized by its high degree of practical

relevance, mimicking real-life situations in cyber

security as close as possible. This is accomplished by

taking information from several proven data sources

such as STIX (Structured Threat Information

eXpression language) (MITRE Corporation, D), the

APT kill chain by Hutchinson (Hutchins, Cloppert, &

Amin, 2011), the CAPEC (Common Attack Pattern

Enumeration and Classification) attack patterns

(MITRE Corporation, A), the MITRE ATT&CK

(Adversarial Tactics, Techniques & Common

Knowledge) attack and mitigation patterns (MITRE

Corporation, B), the NIST SP 800-53

Countermeasures (Joint Task Force Transformation

Initiative, 2015), and MITRE D3FEND (MITRE

Corporation, C).

The main tasks in formalizing realistic threat

scenarios comprise the modeling of attacker behavior

along a kill chain, of defender behavior, and of the

interplay between the two.

2 RELATED WORK

As mentioned above, most of the work on formal

methods and security focuses on the construction

(specification, development, implementation) of

secure and safe software, such as the implementation

of network protocols, the implementation of secure

cryptographic algorithms, or generally the

implementation of software without vulnerabilities.

For an overview see for example (Chong, et al., 2016)

or (Nanda & Jeppu, 2018). This work, however, goes

in a different direction.

Some formal aspects of attack modeling are

described in (Guelzim & Obaidat, 2015). For our

purposes, the concept of attack-defense trees (ADT)

used in threat analysis is of particular importance.

Initially of only semi-formal nature, more formal

treatments of ADTs were developed in recent years.

Wideł et al. (Wideł, Audinot, Fila, & Pinchinat, 2019)

provide an overview of the use of formal models in

security; in (Aslanyan, Nielson, & Parker, 2016) the

authors describe a formal system in order to analyze

quantified properties. Attack trees alone (without

defense actions) are discussed in (Gadyatskaya, et al.,

2016), where Priced Timed Automata are used to

formalize attack trees and model checking is

performed using the tool Uppaal CORA; however, no

stochastic aspects were used in this approach.

Another formal treatment of attack trees is discussed

in (Pekergin, Tan, & Fourneau, 2016), where a

stochastic analysis is described, but no model

checking approaches are used. In (Buldas,

Gadyatskaya, Lenin, Mauw, & Trujillo-Rasua, 2020)

constraint programming is used to evaluate attack

trees with incomplete information.

The idea of using stochastic game theory

(Shapley, 1953) in connection with cyber security

dates back to at least 2002 (Hamilton, Miller, Ott, &

Saydjari, 2002). The equivalence of attack-defense

trees and game theory was formally proved by Kordy

et al. (Kordy, Mauw, Melissen, & Schweitzer, 2010).

There are several papers about the application of

game theory to various aspects of security: a good

overview, though restricted to cyber-physical

systems, is given in (Etesami & Basar, 2019). Other

game-theoretic approaches are discussed in

(Bommannavar, Alpcan, & Bambos, 2011), (He,

Zhuang, & Rao, 2012), (Luo, Szidarovszky, Al-

ICISSP 2022 - 8th International Conference on Information Systems Security and Privacy

282

Nashif, & Hariri, 2010), (Nguyen, Alpcan, & Başar,

2009), (Sallhammar, Helvik, & Knapskog, 2006),

(Sajjan, Sankardas, & Dipankar, 2010), (Tabatabaei,

2016), (Zhang, Wang, & Zhuang, 2021), (Li, Peng,

Zhu, & Basar, 2021), (Jie, Choo, Li, Chen, & Guo,

2019), and (Han, Niyato, Saad, & Başar, 2019).

However, all these works use game-theoretic

concepts only and do not combine them with formal

methods (in the sense as described in the

introduction).

Nevertheless, there are a few papers combining

game theory and model checking, all of them coming

from a group at the University of Oxford:

Kwiatkowska (Kwiatkowska, Model Checking and

Strategy Synthesis for Stochastic Games: From

Theory to Practice, 2016) gives a good summary of

the approach, while (Kwiatkowska, Norman, &

Parker, Verication and Control of Turn-Based

Probabilistic Real-Time Games, 2019), (Svorenova

& Kwiatkowska, 2016), (Chen, Forejt, Kwiatkowska,

Parker, & Simaitis, 2013) and (Simaitis, 2013) cover

various details; Wiltsche (Wiltsche, 2015) uses model

checking in the frame of a game-theoretic model for

strategy synthesis. All the papers give some small

examples to illustrate the viability of the method, but

do not cover threat analysis for real-world situations.

This group of researchers has implemented a

stochastic model checking tool with an extension for

game models: PRISM-games (PRISM-games), which

we will use in our approach.

3 FORMALIZING ATTACKER

AND DEFENDER BEHAVIOR

3.1 Environment Information

In order to formalize the behavior of each party, a

number of facts about the environment must be taken

into consideration:

 The configuration of the system: this information

is initially only available to the defender in its

entirety; the attacker may have a restricted view

of the system’s exposed topology and access

points. During the attack process, the attacker may

gain more and more insight into the victim’s

configuration.

 The goal of the attacker: this information is only

available to the attacker in the beginning; again,

during the course of events the defender may

become more and more aware of the attacker’s

goal and progress achieved so far.

 The possible actions available to the attacker and

the defender, respectively.

 The skill level of the attacker and the defender: the

skill level influences the availability of certain

actions and their success probabilities.

 The budget of the attacker and the defender: the

budget, too, limits the availability of actions.

 The attacker’s initiative determines the number of

actions he can perform. It generally decreases

during the game. If, for example, the initiative

reaches 0, the attack stops (the attacker resigns).

3.2 Formalizing Attacker Behavior

Based on the definition of the environment, the skill

level and the available budget, we describe attacker

behavior as an adapted form of a Markov Decision

Process (MDP). Attacker behavior is formalized as a

4-tuple MDP

att

= (S

att

, A

att

, P, C

) where:

att

= {s

, s

, … s

} is a finite set of states; s

defined as the starting state.

att

= {a

, a

, … a

} is a finite set of attacker

actions.

P: S x A

att

x S  [0..1] P(s, a, s’) is the probability

that action a executed in

state s will lead to state s'.

(s, s’) defines the consequences of

a transition from state s to

state s’ due to action a.

Simply put: Starting from state s

the attacker non-

deterministically chooses an executable action from

att

: an action is executable in state s if a predefined

condition evaluates to true. In other words, an action

is executable if it matches the skill level (for some

more complex actions a higher skill level is required),

if it can be executed within the attacker’s budget

(special tools might be necessary for the action, which

must be purchased), if it fits to the stage of the game

(some actions can only be executed if other preceding

actions were successful), and if it aims at a part of the

configuration already known to the attacker (the

attacker has to gain insight into the configuration

before being capable of attacking internals). After

execution of the chosen action the successor state is

determined based on the probability function P that

defines the success probability of the action. For

reasons of simplicity, there are only two possible

successor states depending on the success or failure

of the action. Finally, the function C

(s,s’) defines the

consequences of the state transition initiated by action

a. Such consequences may be a change in budget or

in initiative, an impact on the attacker’s insight into

the defenders configuration, some damage to the

defender’s configuration, or changes of P for future

Formalizing Real-world Threat Scenarios

283

transitions. A state transition together with its

consequences is referred to as a move.

3.3 Formalizing Defender Behavior

Defender behavior is formalized in the same way as

attacker behavior by means of a Markov Decision

Process. MDP

def

= (S

def

, A

def

, P, C

) where:

def

= {s

, s

, … s

} is a finite set of states; s

defined as the starting state.

def

= {a

, a

, … a

} is a finite set of defender

actions.

P: S x A

def

x S  [0..1] P(s, a, s’) is the probability

that action a executed in

state s will lead to state s'.

(s, s’) defines the consequences of

a transition from state s to

state s’ due to action a.

The definitions correspond intuitively to the

definitions of the attacker MDP, especially

concerning skill level, budget and the like. The

concept of insight plays a somewhat different role in

the defender definition: initially, the defender does

not even know that he is being attacked. In this phase

the defender can only take preventive actions of a

general nature; therefore we call this phase the

prevention phase. However, a possible consequence

of a defender action may be the detection of an

ongoing attack – which moves the situation from the

prevention phase to the response phase and can

trigger a significant change in the availability and the

success probability of further defender actions.

4 FORMALIZING THE

INTERRELATIONSHIPS

BETWEEN ATTACKER AND

DEFENDER

The next step in formalizing a realistic threat scenario

is the combination of MDP

att

and MDP

def

. The

obvious mathematical constructs for this come from

game theory. The following general assumptions

about the characteristics of this game are:

 The game is non-cooperative (quite obvious).

 It is a two-player game with attacker and

defender (obvious, too).

 It is an extended form of a zero-sum game.

There is always a winner and a looser, though the

rewards may not match exactly: either the attacker

achieves his goal and wins, or the defender wins,

if the attacker’s initiative reaches zero (he „gives

up”).

 The game includes non-deterministic elements:

each player can in most situations choose between

a number of possible actions (non-

deterministically) restricted only by some

predefined constraints.

 It is a stochastic game: the success of a player’s

action is defined by a probability distribution.

 It is a game with imperfect information: only a

very restricted set of information (or no

information at all) about the current state of the

play is seen by the players; during the game, parts

of this information may become unveiled.

 It is a game with incomplete information: the

players can only guess about the way the game is

played (which means that not only the state of the

game, but objectives and strategies, too, are

unknown; even the rules of the game are

obscured). In the beginning of the game, for

example, the defender does not even know that the

game has already started, and an attack is well

under-way; we call this the prevention phase of

the game. When information about the attack is at

least partly unveiled to the defender, we say that

the defender moves from the prevention phase to

the response phase.

 For the sake of simplicity we restrict the game to

be turn-based: only one player can make a move

at a time. Furthermore the moves are executed

alternately as defined in PenQuest’s game

mechanics (Luh, Temper, Tjoa, Schrittwieser, &

Janicke, 2019). This property makes the game an

extensive form game: the sequence of moves can

be structured in a tree-like manner. For future

work, this restriction could be loosened: the first

move (or even more moves) could be carried out

in parallel.

Under these assumptions we can formalize attacker-

defender scenarios as stochastic 2-player games. To

improve comprehensibility we will use an extension

described by Marta Kwiatkowska (Kwiatkowska,

Model Checking and Strategy Synthesis for

Stochastic Games: From Theory to Practice, 2016),

called a 2½-player game, where probabilistic states

are introduced between the attacker and defender

states to represent the probabilistic transitions

explicitly. This is without loss of generality as in the

above mentioned paper Kwiatkowska has shown that

for any stochastic 2½-player game there is an

equivalent 2-player game without explicit probability

states. In a 2½-player game the states of the game are

composed of the attacker states (S

att

), and the

defender states (S

def

), each controlled by the

ICISSP 2022 - 8th International Conference on Information Systems Security and Privacy

284

respective players, as well as probabilistic states

prob

). Starting from one of the player states, say the

attacker, the player chooses one of his available

actions and the model moves to a probabilistic state.

From the probabilistic state usually two different

successor states to the set of defender states can

follow depending on the probability of the action’s

success: one following the success of the action (with

probability p) and one when the action failed (with

probability 1-p). The sequence of game states then is

att

– s

prob

– s

def

– s

prob

– s

att

– s

prob

… with s

att

∈ S

att

being an attacker state, s

prob

∈ S

prob

being a

probabilistic state and s

def

∈ S

def

being a defender

state.

We now define the stochastic 2½-player game:

= (Π, S, s

, δ, A, α, C, β)

Π = {att, def} the players: attacker and

defender

S = S

att

∪ S

def

∪ S

prob

a finite non-empty set of

states partitioned in three

subsets:

att

the attacker states

def

the defender states

prob

the probabilistic states.

player

= S

att

∪ S

def

∈ S the initial state

δ: S x S  [0,1] a stochastic transition

function assigning

probability values to state

transitions. Player states

map on probabilistic states:

δ(s, s’) ∈ {0,1}

δ(s, s’) = 1 for at least one

s’ ∈ S

prob

Transitions from

probabilistic states to player

states are assigned a success

probability;

for all s ∈ S

prob

holds

∑

(s, s’)









= 1

A = A

att

∪ A

def

a finite set of actions of the

players

α: S

player

x S

prob

 A a function assigning the

selected action to the

transitions from the players

to the probabilistic states.

C a finite set of consequences

β: S

prob

x S

player

 C a function assigning the

consequences of an action

to the transitions from a

probability state to the

succeeding attacker or

defender state

The transition function δ defines the success/

failure probabilities in case of transitions from a

probabilistic state to a player state; in case of the

transition from a player state to a probabilistic state,

it simply defines which states are possible (1) and

which not (0). In the latter case and if δ(s

, s

prob

) = 1

the function α assigns the action selected by player i

to the transition. The function β defines the

consequences of an action (usually only if the action

is successful). Such consequences may be changes in

insight, damage, or changes in success probabilities

or in availability of future actions.

5 EXAMPLE

5.1 Modeling

Let’s assume the following scenario: an attacker

wants to disrupt the victim’s service operation by

either encrypting some of the victim’s essential data

or by arbitrarily changing or even deleting this data.

We will give here only a high-level overview with a

restricted number of actions. Attacker activities are

structured into phases by kill chains. A simplified kill

chain for this attack would consist of three phases:

1. Reconnaissance

2. Gain Access

3. Destroy Data

For each of these stages the following actions are

available to the attacker:

1. Reconnaissance: use open-sources intelligence,

execute a vulnerability scan, perform an active

scan

2. Gain Access: phishing, remote server

connection, brute force password cracking

3. Destroy Data: data encryption, data

manipulation, wipe disk

For each attacker activity we must define possible

target assets, required skills, the necessary budget, the

effects of a successful action on insight in the

defender’s configuration and on the damage status

with regard to CIA, and the success probability. The

skill requirements are rated at a scale from 1 to 5,

according to the STIX threat actor vocabulary

ThreatActorSophistication. The available budget is

rated on a scale from 0 to 10, insight and damage are

rated on a scale from 1 to 3 Tables 1 to 3 show these

assignments for the attacker actions.

Formalizing Real-world Threat Scenarios

285

Table 1: Attacker Stage 1 – Reconnaissance Actions.

TargetAssets SkillReq Budget Insight Damage CIA SuccessProb

OpenSrcInt WebServer MailServer

ApplicationServer

MobileDevices Database

FileServer ClientPC

CloudApplication DMZ

LAN

1 - +1 0,0,0 0.8

VulnScan Same as above 2 - +1 1,0,1 0.6

ActiveScan Same as above 3 - +1 1,0,1 0.5

Table 2: Attacker Stage 2 – Access Actions.

TargetAssets SkillReq Budget Insight Damage CIA SuccessProb

Phishing MailServer ClientPC 2 2 +1 2,2,1 0.6

Remote Server

Connection

WebServer MailServer

ApplicationServer

Database FileServer

CloudApplication

2 - - 2,2,1 0.5

Brute Force Same as above 1 1 - 2,2,1 0.5

Table 3: Attacker Stage 3 – Destruction Actions.

TargetAssets SkillReq Budget Insight Damage CIA SuccessProb

Encryption WebServer MailServer

ApplicationServer

MobileDevices Database

FileServer ClientPC

CloudApplication DMZ

LAN

3 - - 0,0,3 0.3

Manipulation Same as above 3 - - 0,3,1 0.3

Wipe Disk Same as above 3 - - 0,0,3 0.3

The defender activities are structured into two

phases: the prevention phase and the response phase.

There are the following actions at disposal in the

respective stages:

1. Prevention phase: security awareness training,

security response training, incident monitoring,

mobile code restrictions, two-factor

authentication, logon attempts restrictions,

restrict external connections

2. Response phase: information spillage handling

fail-safe procedures, asset recovery

The definitions of target assets, required skills,

budget, insight into the attacker’s intent, and success

probabilities are shown in Tables 4 and 5. Moreover,

a defense action can change the success probability of

a defender action. A security awareness training, for

example, reduces the success probability of a

phishing attack (table 2, first line) by half.

A formal model as described above can be

formulated in a model checking tool. To this end we

chose PRISM-games (Kwiatkowska, Parker, &

Wiltsche, PRISM-games: Verification and Strategy

Synthesis for Stochastic Multi-player Games with

Multiple Objectives, 2018). This tool allows, among

others, for the definition of different players and

modules. The modules contain the actions and their

consequences and can be written to mimic the non-

determinism as well as the stochastic nature of the

activities derived from the success probabilities.

Equipped with this information, one can define

the game: Foremost, we must decide on the

parameters characterizing the players: their skill

levels, their budgets and the attacker’s initiative. The

attacker and defender states correspond to the phases

of the attack and the defense, the probabilistic states

between an attacker and a defender state decide on the

success or failure of an action. The transition function

δ defines the eligibility of an action in a certain state

(depending on skill, budget and other preconditions)

when going from a player state to a probabilistic state

and the success probability otherwise. The set of

actions is given by the tables and the function α non-

deterministically decides on the choice of an action

by a player. The consequences of a successful action

and the function β are defined in the tables, too.

ICISSP 2022 - 8th International Conference on Information Systems Security and Privacy

286

Table 4: Defender Stage 1 – Prevention Phase.

TargetAssets SkillReq Budget Insight ChangeAttProbs SuccessProb

Security

Awareness

Training

Users 1 1 false St2/1 /2 0.8

Security

Response

Training

Staff 2 1 false 0.8

Incident

Monitoring

System 2 2 true 0.7

Mobile Code

Restrictions

Mobile 2 1 false 0.7

Two-Factor

Authentication

System, Users 2 2 false St2/30.01 0.6

Logon

Attempts

Restrictions

System 1 1 false St2/300.6

Restrict

External

Connections

System 2 1 false St2/20.1 0.6

Table 5: Defender Stage 2 – Response Phase.

TargetAssets SkillReq Budget Insight ChangeAttProbs SuccessProb

Information

Spillage

Handling

System 2 2 true 0.7

Fail-Safe

Procedures

System, Staff 3 2 true 0.4

Asset

Recovery

System, Staff 3 3 true 0.5

The current version of the PenQuest model

contains approximately 250 different attack actions

and 70 defense actions that can be used in modeling

attacker and defender strategies. So far we use a

subset of these actions in our model checking

approach.

5.2 Applying Model Checking

Techniques

Having modeled the example scenario as a game in

the tool PRISM-games, quantitative questions about

the threat situation can be formulated. The answers to

these questions can then be calculated by model

checking. Model checking evaluates all possible

paths the game could take and on the way collects the

necessary information to compute maximum and

minimum success probabilities of the attacker and the

defender. In PRISM-games these questions are

formulated in PRISM’s property specification

language, which subsumes several well-known

probabilistic temporal logics.

The questions from the introduction were

answered like follows:

 What is the maximum probability that an attacker

with a specific goal and profile will ultimately

succeed?

Given an attacker initiative of 4 (on a scale from

1 to 10) and a defender budget of 7 (on a scale

from 1 to 10) model checking yield 0.42 in the

example, meaning that in the given situation the

attacker has a 42%-chance of success at best;

while his minimum success probability is 0.0 (no

success)

 What is the maximum defender success

probability in the given situation with a defender

budget of 7 and an attacker initiative of 4, as

above?

Model checking results yield 0.93 in the example,

meaning that the residual rest of risk against an

attacker with initiative 4 is rather small in the

given situation.

 How does a significant lower defender budget

influence the defender’s minimum success

probability?

Model checking results show that lowering the

defender budget from level 7 to level 5 does not

influence the defender’s success probabilities;

lowering it to level 4, however, significantly

Formalizing Real-world Threat Scenarios

287

reduces the minimum probability of defender

success (0.40 instead of 0.58).

In the example – as implemented in our model – the

most important parameters are the attacker’s initiative

and the defender’s budget. The attacker’s initiative

models his persistence: a lower value lets him give up

earlier and hence lowers his success chances. While

the defender’s budget influences a situation only as

long as it makes sense to invest. Spending money for

security measures that do not have any influence in

the modeled scenario will not change the

probabilities.

6 CONCLUSIONS AND FUTURE

WORK

The formalism for modeling attack-defense scenarios

as described in this paper makes threat analysis

possible in a strictly formal way and thus renders

possible the application of formal methods and tools.

The main innovation here is that the combination of

game theory and model checking is applied to tactical

threat analysis for real-world situations. To keep the

analysis as close to practice as possible we collected

attack and defense actions from accepted data sources

and vocabularies. As mentioned above the model so

far contains approximately 250 different attack

actions and 70 defense actions that can be used in

modeling attack and defender strategies. Subsuming

all these aspects into one single model would clearly

lead to a too large model, and hence render model

checking impossible by leading to state explosions.

To keep the model in a manageable size we break

down the model into scenarios along the lines of kill-

chains (Hutchins, Cloppert, & Amin, 2011). Model

checking these scenarios is possible on standard PCs

with 4.6 GHz and 32GB RAM. For more elaborate

scenarios more computing power will be necessary.

Future work will consider parallel execution of

attacker and defender actions in certain situations,

especially in the beginning. This would mean giving

up the turn-based property of the game partially. So

far, the consequences of this are not yet analyzed

fully. Another idea for future development is strategy

synthesis (for defenders): Given a configuration with

real-world limitations such as a budget, skill as well

as anticipated threats, the optimal defense strategy

could be computed.

REFERENCES

Aslanyan, Z., Nielson, F., & Parker, D. (2016). Quantitative

Verification and Synthesis of Attack-Defence

Scenarios. IEEE 29th Computer Security Foundations

Symposium, CSF 2016, (S. 105-119). doi:

10.1109/CSF.2016.15

Bommannavar, P., Alpcan, T., & Bambos, N. (2011).

Security risk management via dynamic games with

learning. IEEE International Conference on

Communications (ICC), (S. 1-6). doi: 10.1109/

icc.2011.5963330

Buldas, A., Gadyatskaya, O., Lenin, A., Mauw, S., &

Trujillo-Rasua, R. (2020). Attribute Evaluation on

Attack Trees with Incomplete Information. Computers

and Security 88/101630.

Chen, T., Forejt, V., Kwiatkowska, M., Parker, D., &

Simaitis, A. (2013). Automatic Verification of

Competitive Stochastic Systems. Formal Methods in

System Design, 43/1, S. 61-92.

Chong, S., Guttman, J., Datta, A., Myers, A., Pierce, B.,

Schaumont, P., Zeldovich, N. (2016). Report on the

NSF Workshop on Formal Methods for Security.

https://dash.harvard.edu/bitstream/handle/1/34604536/

6897521.pdf

Etesami, S. R., & Basar, T. (2019). Dynamic Games in

Cyber-Physical Security: An Overview. Dynamic

Games and Applications, S. 884–913. doi: doi.org/

10.1007/s13235-018-00291-y

Gadyatskaya, O., Hansen, R. R., Larsen, K. G., Legay, A.,

Olesen, M., & Poulsen, D. B. (2016). Modelling

Attack-defense Trees Using Timed Automata. In M.

Fränzle, & N. Markey (Hrsg.), FORMATS 2016,

LNCS 9884. 9884, S. 35–50. Springer LNCS. doi:

10.1007/978-3-319-44878-7 3

Guelzim, T., & Obaidat, M. S. (2015). Formal methods of

attack modeling and detection. In Modeling and

Simulation of Computer Networks and Systems -

Methodologies and Applications (S. 841-860). Elsivier.

Hamilton, S., Miller, W., Ott, A., & Saydjari, O. (2002).

The role of game theory in information warfare. 4th

Information Survivability Workshop, (S. 1-4).

Han, Z., Niyato, D., Saad, W., & Başar, T. (2019). Game

Theory for Next Generation Wireless and

Communication Networks - Modeling, Analysis, and

Design. Cambridge University Press.

He, F., Zhuang, J., & Rao, N. (2012). Game Theoretic

Analysis of Attack and Defense in Cyber-Physical

Network Infrastructures. Proceedings of the Industrial

and Systems Engineering Research Conference. doi:

10.1.1.719.2652

Hutchins, E., Cloppert, M., & Amin, R. (2011).

Intelligence-driven computer network defense infor-

med by analysis of adversary campaigns and intrusion

kill chains. Lead. Issues Inf. Warf. Secur. Res. 1/80.

Jie, Y., Choo, K.-K. R., Li, M., Chen, L., & Guo, C. (2019).

Tradeoff gain and loss optimization against man-in-the-

middle attacks based on game theoretic model. Future

Generation Computer Systems, Volume 101, S. 169-

179. doi: doi.org/10.1016/j.future.2019.05.078

ICISSP 2022 - 8th International Conference on Information Systems Security and Privacy

288

Joint Task Force Transformation Initiative. (2015). SP 800-

53 rev. 4. Recommended Security Controls for Federal

Information Systems and Organizations. Gaithersburg.

Keyser, T. (2018). Security policy. In The Information

Governance Toolkit (S. 57-62). CRC Press.

Kordy, B., Mauw, S., Melissen, M., & Schweitzer, P.

(2010). Attack–Defense Trees and Two-Player Binary

Zero-Sum Extensive Form Games Are Equivalent. In

T. Alpcan, L. Buttyán, & J. Baras (Hrsg.), Decision and

Game Theory for Security. GameSec 2010. . Lecture

Notes in Computer Science, vol 6442. Springer. doi:

10.1007/978-3-642-17197-0_17

Kordy, B., Mauw, S., Radomorivic, S., & Schweitzer, P.

(2014). Attack–Defense Trees. Journal of Logic and

Computation, Volume 24/1, S. 55–87. Von http://

logcom.oxfordjournals.org/cgi/reprint/exs029?

Kwiatkowska, M. (2016). Model Checking and Strategy

Synthesis for Stochastic Games: From Theory to

Practice. Proceedings of the 43rd International

Colloquium on Automata, Languages, and

Programming (ICALP'16). Schloss Dagstuhl - Leibniz-

Zentrum fuer Informatik.

Kwiatkowska, M., Norman, G., & Parker, D. (2019).

Verication and Control of Turn-Based Probabilistic

Real-Time Games. The Art of Modelling

Computational Systems: A Journey from Logic and

Concurrency to Security and Privacy, volume 11760 of

LNCS, S. 379-396.

Kwiatkowska, M., Parker, D., & Wiltsche, C. (4 2018).

PRISM-games: Verification and Strategy Synthesis for

Stochastic Multi-player Games with Multiple

Objectives. International Journal on Software Tools for

Technology Transfer, 20(2), S. 195–210.

Li, T., Peng, G., Zhu, Q., & Basar, T. (2021). The

Confluence of Networks, Games and Learning - A

game-theoretic framework for multi-agent decision

making over networks. IEEE control system magazine,

special issue on Distributed Nash Equilibrium Seeking

over Networks.

Luh, R., Temper, M., Tjoa, S., Schrittwieser, S., & Janicke,

H. (2019). PenQuest: a gamified attacker/defender

metamodel for cyber security assessment and

education. Journal of Computer Virology and Hacking

Techniques. doi: https://doi.org/10.1007/s11416-019-

00342-x

Luo, Y., Szidarovszky, F., Al-Nashif, Y., & Hariri, S.

(2010). Game Theory Based Network Security. Journal

of Information Security 1/1, S. 41-44. doi:

10.4236/jis.2010.11005

McCabe, J. D. (2007). Network Analysis, Architecture, and

Design. Morgan Kaufmann.

MITRE Corporation. (A). CAPEC—Common Attack

Pattern Enumeration and Classification.

https://capec.mitre.org/

MITRE Corporation. (B). MITRE ATT&CK.

https://attack.mitre.org/

MITRE Corporation. (C). MITRE D3FEND.

https://d3fend.mitre.org/resources/D3FEND.pdf

MITRE Corporation. (D). STIX—Structured Threat

Information Expression | STIX Project Documentation.

https://oasis-open.github.io/cti-documentation/

Nanda, M., & Jeppu, Y. (2018). Formal Methods for Safety

and Security. Springer.

Nguyen, K. C., Alpcan, T., & Başar, T. (2009). Stochastic

games for security in networks with interdependent

nodes. Proceedings of the 2009 International

Conference on Game Theory for Networks, GameNets

’09.

Pekergin, N., Tan, S., & Fourneau, J.-M. (2016).

Quantitative Attack Tree Analysis: Stochastic Bounds

and Numerical Analysis. International Workshop on

Graphical Models for Security, GraMSec 2016. doi:

DOI: 10.1007/978-3-319-46263-9_8

PRISM-games.

https://www.prismmodelchecker.org/games/

Sajjan, S., Sankardas, R., & Dipankar, D. (2010). Game

theory for cyber security. CSIIRW '10: Proceedings of

the Sixth Annual Workshop on Cyber Security and

Information Intelligence Research. doi: doi.org/

10.1145/1852666.1852704

Sallhammar, K., Helvik, B. E., & Knapskog, S. J. (2006).

On stochastic modeling for integrated security and

dependability evaluation. Journal of Networks 1/5, S.

31-42. doi: 10.4304/jnw.1.5.31-42

Shapley, L. S. (1953). Stochastic games. PNAS 39/10, S.

1095-1100.

Shostack, A. (2014). Threat Modeling: Designing for

Security. Wiley.

Simaitis, A. (2013). Automatic Verification of Competitive

Stochastic Systems. Dissertation. University of Oxford.

Svorenova, M., & Kwiatkowska, M. (2016). Quantitative

Verification and Strategy Synthesis for Stochastic

Games. European Journal of Control 30, special issue

15th European Control Conference, ECC16, S. 15-30.

doi: doi.org/10.1016/j.ejcon.2016.04.009

Swiderski, F., & Snyder, W. (2004). Threat Modeling.

Microsoft Press.

Tabatabaei, M. (2016). Games and Strategies in Analysis of

Security Properties. Dissertation. Université du

Luxembourg.

Tarandach, I., & Coles, M. J. (2020). Threat Modeling: A

Practical Guide for Development Teams. O'Reilly.

Wideł, W., Audinot, M., Fila, B., & Pinchinat, S. (2019).

Beyond 2014: Formal Methods for Attack tree-based

Security Modeling. ACM Computing Surveys. 52/4,

Article 75. doi: https://doi.org/10.1145/3331524

Wiltsche, C. (2015). Assume-Guarantee Strategy Synthesis

for Stochastic Games. Dissertation. University of

Oxford.

Zhang, J., Wang, Y., & Zhuang, J. (2021). Modeling multi-

target defender-attacker games with quantal response

attack strategies. Reliability Engineering & System

Safety, Volume 205.

Formalizing Real-world Threat Scenarios

289
