Object-less Vision-language Model on Visual Question Classiﬁcation for

Blind People

Tung Le

, Khoa Pho

, Thong Bui

2,3

, Huy Tien Nguyen

2,3

and Minh Le Nguyen

School of Information Science, Japan Advanced Institute of Science and Technology, Ishikawa, Japan

Faculty of Information Technology, University of Science, Ho Chi Minh city, Vietnam

Vietnam National University, Ho Chi Minh city, Vietnam

ﬁ

Keywords:

Visual Question Classiﬁcation, Object-less Image, Vision-language Model, Vision Transformer,

VizWiz-VQA.

Abstract:

Despite the long-standing appearance of question types in the Visual Question Answering dataset, Visual

Question Classiﬁcation does not received enough public interest in research. Different from general text clas-

siﬁcation, a visual question requires an understanding of visual and textual features simultaneously. Together

with the enthusiasm and novelty of Visual Question Classiﬁcation, the most important and practical goal we

concentrate on is to deal with the weakness of Object Detection on object-less images. We thus propose an

Object-less Visual Question Classiﬁcation model, OL–LXMERT, to generate virtual objects replacing the de-

pendence of Object Detection in previous Vision-Language systems. Our architecture is effective and powerful

enough to digest local and global features of images in understanding the relationship between multiple modal-

ities. Through our experiments in our modiﬁed VizWiz-VQC 2020 dataset of blind people, our Object-less

LXMERT achieves promising results in the brand-new multi-modal task. Furthermore, the detailed ablation

studies show the strength and potential of our model in comparison to competitive approaches.

1 INTRODUCTION

Among multi-modal topics which requires advanced

technologies in many cutting-edge areas, vision-

language tasks are challenging and potential to dig

much deeper due to the associated composition be-

tween images and texts. This reﬂects in many in-

triguing tasks such as Visual Question Answering (Le

et al., 2020), Visual Commonsense Reasoning (Wang

et al., 2020), and so on. Those works focus on ana-

lyzing, understanding, and retrieving the relationship

among various modalities (Le et al., 2021a).

In the ﬂow of vision-language studies, we propose

an interesting and novel task named Visual Question

Classiﬁcation (VQC) to determine the category of vi-

sual questions. With an aid of a Visual Question Clas-

siﬁcation approach, it is useful to determine the an-

swer space for the special kinds of questions such

as Yes/No and Number ones. Although this is the

ﬁrst time this task is introduced, the category of vi-

sual question always exists in most Visual Question

Answering datasets such as VQAv2.0 (Goyal et al.,

2017), VizWiz-VQA (Gurari et al., 2018), etc. This

fact reﬂects the enormous potential of question type

which has not ever been used in the previous ap-

proaches.

unanswerable other yes/no number

Figure 1: The typical examples of low-qualiﬁed images.

Together with the potential of question type, our

concerns also come from low-qualiﬁed images in

practice. Throughout our work, object-less images

are the representative of samples that have few ob-

jects recognized from Object Detection models. Typ-

ical examples of these kinds of images are presented

in Figure 1. In these cases, it is not effective to

utilize Object Detection models such as Faster R-

CNN (Ren et al., 2015) to extract the object-based

features. Therefore, an important and practical re-

search question is how to take advantage of recent

vision-language models to deal with the real-world

images. Obviously, object-based approaches seem

vulnerable due to the resolution of images. To over-

180

Le, T., Pho, K., Bui, T., Nguyen, H. and Nguyen, M.

Object-less Vision-language Model on Visual Question Classiﬁcation for Blind People.

DOI: 10.5220/0010797400003116

In Proceedings of the 14th International Conference on Agents and Artiﬁcial Intelligence (ICAART 2022) - Volume 3, pages 180-187

ISBN: 978-989-758-547-0; ISSN: 2184-433X

come the challenges of practical images, we propose

an object-less generator to make use of Transformer-

based image features in constructing the virtual ob-

jects, which is pragmatic and effective to replace the

role of Object Detection component in recent vision-

language models. Our proposed component is less in-

ﬂuenced by side effects of poor quality images. It is

completely suitable and effective to adapt into prac-

tical environment. However, there is no denying that

object-based features are more complicated and efﬁ-

cient in the high-qualiﬁed images due to informative

representation. Although our proposed architecture is

not limited in poor-qualiﬁed vision, it is meaningful

to emphasize the strength of our proposed architecture

in the speciﬁc domain (i.e in VizWiz-VQA dataset of

blind people).

Our main contributions are as follows:

• We introduce a novel task, Visual Question Clas-

siﬁcation, in the cutting-edge area between vision

and language. It is the ﬁrst time this task is re-

garded as an independent problem despite its im-

portance and concealed long-term viability.

• We propose the Object-less Visual Question Clas-

siﬁcation model which takes advantage of image

features to generate the virtual objects and inte-

grates the vision-language models to predict the

category of visual questions.

• Experimental results and ablation studies on

VizWiz-VQC 2020 dataset prove the effective-

ness and robustness of our virtual objects against

object-based models.

In the remain of this paper, some related works

are shown in Section 2. Then, the detail of compo-

nents and our model is represented in Section 3. Next,

to prove the effectiveness of our model, the result of

our model, as well as the comparison with the state-

of-the-art models, are represented thoroughly in Sec-

tion 4. In addition, we also present some samples and

discussion in Section 5. Finally, the conclusion and

future works are shown in Section 6.

2 RELATED WORKS

2.1 Text Classiﬁcation

In recent years, with the development of Transformer

architecture and transfer-learning, text understanding

achieves signiﬁcant improvements, especially in sen-

tence classiﬁcation. Well-known models in this trend

such as BERT (Devlin et al., 2019), XLNet (Yang

et al., 2019) is one of the competitive approaches in a

lot of text classiﬁcation datasets. Different from pre-

vious autoencoding and autoregressive approaches,

XLNet proposes a new framework to learn the con-

text of a word based on the contribution of all tokens

via the permutation operation. Generally, the strength

of these approaches depends on the self-supervised

learning from huge datasets and the robustness of self-

attention in Transformer architecture.

In contrast to inductive learning in the above

approaches, transductive learning techniques are ef-

fective to model the relationship between texts via

observing all data samples. In the traditional ap-

proaches, the category of text is considered by the

local context the global relationship through textual

graphs. In this kind of approach, BERT-GCN is

the powerful approach that combines a large-scale

pre-training language model and transductive learn-

ing. Through a heterogeneous graph of textual ele-

ments, TextGCN (Yao et al., 2019) is able to learn

the text representation via the relationship matrix of

nodes and weighted edges. To integrate external lan-

guage model, BERT-GCN (Lin et al., 2021) proposes

an ensemble classiﬁer with the contribution of both

BERT (Devlin et al., 2019) and TextGCN (Yao et al.,

2019).

2.2 Vision-language Model

In the rapid growth of multi-modal information,

vision-language models have been receiving interest

from both research and industry. However, the dif-

ference of representation between images and texts

is a huge hurdle in previous works. In recent years,

there is a lot of effort to overcome this challenge in

many vision-language tasks such as Visual Question

Answering (Le et al., 2020), Visual Commonsense

Reasoning (Wang et al., 2020), etc.

In previous approaches, visual and textual features

are independently considered and combined by the

multi-modal fusion function. These systems, how-

ever, accidentally ignore the composition between

textual and visual objects. The typical example of

this type is Vision-Text Transformer (Le et al., 2021b)

which utilizes Vision Transformer (Dosovitskiy et al.,

2021) and BERT (Devlin et al., 2019) to extract vi-

sual and textual features. The success of this model

comes from the robustness of pre-trained vision and

language model instead of the interaction between im-

ages and texts.

Recently, another branch where images and texts

are much more considered simultaneously is pre-

training vision-language models. One of the most

successful vision-language models, LXMERT (Tan

and Bansal, 2019), utilize bi-directional cross-

Object-less Vision-language Model on Visual Question Classiﬁcation for Blind People

181

encoder attention to learn the visual and textual fea-

tures together. In particularly, LXMERT utilizes the

Faster R-CNN to extract the object-based features of

images. After, the textual and visual features are in-

tensiﬁed and combined by Transformer architecture.

Besides, it also proposes some pre-training tasks to

optimize the vision-language model. However, its

bottle-neck comes from the external Object Detection

which is profoundly affected by the images’ quality.

3 METHODOLOGY

The performance of most current vision-language

models depends on the quality of Object Detection

system, which is the bottle-neck in practical domain,

especially in poor-qualiﬁed images. With our obser-

vation and the trend of image processing, we pro-

pose an object-less generator which utilizes the visual

features to eliminate the requirements of the exter-

nal Object Detection models. Instead of starting from

scratch, we take advantage of pre-trained models via

transfer-learning to construct the powerful virtual ob-

jects. To prove the efﬁciency of our proposed compo-

nent, we integrate it into one of the most successful

vision-language models, LXMERT (Tan and Bansal,

2019).

3.1 Object-less Generation

3.1.1 Image Feature Extraction

Together with the success of Transformer architecture

in Natural Language Processing, more and more pow-

erful approaches have appeared in many Computer

Vision tasks such as Image Classiﬁcation (Dosovit-

skiy et al., 2021), Image Super-Resolution (Parmar

et al., 2018), etc. Transformer architecture is more

promising than traditional Convolution Neural Net-

work (CNN) to capture self-attention on pixels. With

the fewest modiﬁcations from Transformer architec-

ture, Vision Transformer model treats an image as a

series of patches instead of pixels. This mechanism is

efﬁcient to maintain the spatial relationship in images

and drop the computational cost.

Speciﬁcally, an image is split into a list of N ﬁxed-

size patches which are ﬂattened and mapped into the

featured space via linear projection. Then, each patch

is injected by its position information via position em-

bedding to keep the spatial relation of patches in the

original image. The detail of the Vision Transformer

in our image feature extraction is presented in Fig-

ure 2. We also notice that Vision Transformer is used

as the external feature extractor instead of an internal

Linear Project + Position Embedding


Transformer

Blocks

class

Norm

Multi-head

Attention

Norm

FFNN

+ +

visual

features

Average Pooling 1D

Figure 2: The detailed architecture of our Image Feature

Extraction.

component in our model, which is similar to most pre-

vious image processing approaches. This mechanism

is ideal enough to increase the speed of our system.

Besides, to reduce the computation cost, we also in-

tegrate the stack of Average Pooling 1D in the visual

features to obtain the generalized representation.

3.1.2 Object-less Generation

In our model, we assume that image features are

sufﬁcient to generalize visual contents such as ob-

jects, colors, backgrounds, and so on. Therefore, the

global representation of images is a great alternative

to output from an external Object Detection model.

Furthermore, annotated data of image classiﬁcation

is easier and more reasonable than object-based re-

sources. Even that, our proposed component is com-

pletely accomplished to integrate the portable image

system into understanding visual content.

In the previous components, an image is repre-

sented into the feature vector f

∈ R

d×k

where d is the

dimension of the output layer in Vision Transformer

and k is the number of patches in images. In most

vision-language approaches, an object consists of two

main characteristics extracted by a speciﬁc region of

interest (RoI). Firstly, with each selected RoI, the RoI

features are derived from the mean-pooled convolu-

tion layer of the Object Detection model. Secondly,

the position of bounding boxes in images is also uti-

lized to represent objects. However, we also consider

some thresholds to eliminate the uncertain objects. In

traditional approaches, object-based features are often

extracted by the process in the Up-Down model (An-

derson et al., 2018). Besides, to maintain consistency

in an input layer, the number of objects is often equal

to 36.

Based on the conﬁguration of previous approaches

in image processing, our virtual objects also includes

two kinds of features. With each patch f

∈ f

, RoI

ICAART 2022 - 14th International Conference on Agents and Artiﬁcial Intelligence

182

features of corresponding virtual object o

are gener-

ated by a Feed-forward Neural Network Equation 1.

= tanh



+ b



(1)

Where W

∈ R

d×2048

, b

∈ R

2048

The dimension of RoI features is similar to the

Up-Down model (Anderson et al., 2018) for the orig-

inal objects. The number of virtual objects is, how-

ever, based on the number of patches in Vision Trans-

former instead of the Up-Down model (Anderson

et al., 2018).

After generating the RoI features of virtual ob-

jects, we also learn the corresponding position via

Feed-forward Neural Network models without an ac-

tivation function in Equation 2.

= W

+ b

(2)

Where W

∈ R

d×4

, b

∈ R

. In most Object Detec-

tion models, we need to determine the speciﬁc for-

mat of bounding boxes such as width-height, point-

length, etc. However, our Position Generator is efﬁ-

cient enough to learn spatial information in all con-

ﬁgurations. Similar to RoI Generation, the number of

position features are based on the number of patches

from Vision Transformer (Dosovitskiy et al., 2021).

At a quick glance, our generation is too easy to

consider as the critical component in the novel vision-

language models. However, we need to notice that

the features of objects depend on the bounding boxes.

Therefore, each object is represented locally in each

speciﬁc region of an image instead of considering the

global features. In object-less images, there are a few

objects with high conﬁdence. It is the reason that

object-based features dwell on redundant regions in

images for low conﬁdent objects. Obviously, localiza-

tion is indeed challenging in CNN-based approaches.

In our generation, object features are created by the

global representation of images, so our virtual objects

are ideal to capture global information and learn local

regions in images. Although our generation is simple

and transparent, its generalization is quite high and

efﬁcient. The performance of our proposed generator

is proved in the detailed results and ablation studies.

3.2 Object-less Visual Question

Classiﬁcation

The key component in previous vision-language ap-

proaches is to expand the input and embedding layer

for processing both image and text simultaneously.

However, most of them often depend on the exter-

nal Object Detection models. With the fewest mod-

iﬁcation of the vision-language model, we propose

a novel Object-less Visual Question Classiﬁcation

model. Our model takes advantage of the pre-trained

LXMERT model with our virtual objects. with our

proposed architecture, it is ideal to evolve gradually

through the development of the Computer Vision and

Vision-Language model.

Firtly, after generating the virtual object o =

}

i=1

from our object-less generator, virtual object

features r

and position p

are normalized by Layer-

Norm function (LN). Then, the position-aware em-

bedding is calculated by adding the information of

normalized r

and p

in Equation 3. From this ag-

gregation, image representation becomes the combi-

nation of virtual object features and position informa-

tion.

(LN(W

+ b

) +LN(W

+ b

))

(3)

Next, the visual features v and textual features q

are intensiﬁed by Multi-head attention in Transformer

architecture. To combine the multi-modal informa-

tion, LXMERT proposes a cross-modality encoder

between images and texts. In particularly, this com-

ponent is the bi-direction multi-head attention from

images to texts and vice versa. It is so similar to

guided-attention (Yu et al., 2019) in previous works.

However, the success of the LXMERT model comes

from the pre-training strategies. This process allows

vision-language models to learn the multi-modal data

instead of single modality in traditional approaches.

In our architecture, we take advantage of the pre-

trained LXMERT model to prove the strength of our

virtual objects. Therefore, LXMERT architecture is

almost maintained. Instead of utilizing the object-

based feature, our OL-LXMERT model obtains the

virtual objects via the internal object-less generator.

It is pragmatic and effective to deploy in both prac-

tice and research. Even that, our proposed generator

may completely replace the role of the Object Detec-

tion module in vision-language models in this task.

4 EXPERIMENTS

4.1 Datasets and Evaluation Metrics

In the consistent motivation of our work, we focus on

the VizWiz-VQA dataset for blind people. All sam-

ples of VizWiz-VQA are collected by blind people.

Therefore, images in the VizWiz-VQA dataset are of-

ten object-less and poor-qualiﬁed. Studying in this

domain is ideal to raise the public interest for the dis-

abled especially for blind people. It is humane and

necessary to help them overcome their difﬁculties in

Object-less Vision-language Model on Visual Question Classiﬁcation for Blind People

183

Object-Relationship

Encoder

Which one is

the blue one?

Language

Encoder

Cross-Modality

Encoder

Feed-forward

Neural Network

other

yes/no

unanswerable

number

LXMERT

Model


Question

RoI

Features

POS

Features

Word

Features

POS

Features

Figure 3: OL-LXMERT: The integration of object-less generator and vision-language model for Visual Question Classiﬁca-

tion.

the real world via deploying advanced technologies,

especially in vision-language’s understanding.

To create the VizWiz-VQC dataset, we derive the

visual question information from VizWiz-VQA 2020

dataset. However, VizWiz-VQA is the concealment

of test set. Therefore, we recommend a modiﬁcation

as follows:

• Consider the validation set in VizWiz-VQA as the

test set of VizWiz-VQC for Visual Question Clas-

siﬁcation task.

• Split the original training set in VizWiz-VQA into

the training and validation set of VizWiz-VQC

dataset with the ratio 80% : 20%

The detail of our extracted VQC dataset from VizWiz-

VQA 2020 is presented in Table 1. We also mention

the question type distribution of our data in Table 2.

Table 1: The analysis of our dataset – VizWiz-VQC.

Train Val Test

No. Samples 16,418 4,105 4,319

No. Question Types 4 4 4

Avg. Words/Question 6.76 6.74 7.26

Avg. Objects/Image

(thresh = 0.4)

2.98 3.07 2.88

Table 2: The distribution of question type in VizWiz-VQC.

Train Val Test

% Other 66.91 66.92 62.31

% Yes/No 4.67 4.65 4.51

% Unanswerable 26.95 26.97 32.07

% Number 1.47 1.46 1.11

Obviously, our choice and recommendation is

suitable for object-less as well as real-world images.

Particularly, in VQAv2.0 (Goyal et al., 2017), anno-

tators are required to give a question of objects in im-

ages. Obviously, object-less images are often elimi-

nated in most previous VQA datasets. Therefore, we

consider VizWiz-VQA 2020 as the best choice for the

challenges of object-less images. The most special

characteristic of VizWiz-VQA is based on its data col-

lection process where all samples are taken by blind

people via their personal phones. It is the reason that

most images in this dataset are poor-qualiﬁed and in

low resolution. Speciﬁcally, the number of objects

is approximately 2.9 per image. This ratio is much

lower than the other datasets in the same conﬁgura-

tion of Faster R-CNN. Together with the difﬁculty in

object-less images, questions recorded by blind peo-

ple are challenging for text understanding.

In evaluation, similar to previous approaches in

Question Classiﬁcation, we also consider F1-score as

the main metric in Visual Question Classiﬁcation. In

addition, we also mention the precision and recall of

our classiﬁer in all comparisons.

4.2 Results

Coming from the brand-new appearance of VQC in

the multi-modal tasks, it is too hard to choose the

competitive baselines in this problem. As a pio-

neer in the task, we suggest comparing VQA task

to two kinds of models including (i) general text

classiﬁcation and (ii) multi-modal VQA. In the ﬁrst

comparison, we mention two SOTA text classiﬁca-

tion models which are based on the latest technolo-

gies of XLNET (Yang et al., 2019) for pre-trained

language understanding and BERT-GCN (Lin et al.,

2021) for Graph Neural Network. These approaches

only receive textual questions (Q) as an input instead

of both images (I) and texts (Q). In the aspect of

multi-modal systems, we compare our model to VT-

ICAART 2022 - 14th International Conference on Agents and Artiﬁcial Intelligence

184

Table 3: The detailed comparison of our Object-less approach against the competitive baselines.

Model Precision Recall F1

BERTGCN (Lin et al., 2021) 0.59 0.61 0.59

XLNet (Yang et al., 2019) 0.57 0.58 0.57

QI VT-Transformer (Le et al., 2021b) 0.59 0.65 0.61

QI LXMERT (Tan and Bansal, 2019) 0.63 0.70 0.66

QI OL–LXMERT (Our model) 0.67 0.69 0.68

Transformer (Le et al., 2021b) which is one of the

most successful models in VizWiz-VQA task. The

reason for this choice comes from the similar image

feature extractor between two models. With a few

modiﬁcations in the last prediction layer, we consider

VT-Transformer as the most related approach in com-

parison to our model. Besides, to prove the strength of

our model in object-less domain, we also present the

performance of the original LXMERT together with

object=based features from Faster R-CNN (Ren et al.,

2015) models.

In Table 3, we show the performance of our

Object-Less models (OL–LXMERT) in comparison

to the existing state-of-the-art in text classiﬁcation

and multi-modal approaches. Our model obtains

promising results against the competitive baselines in

both single and multiple modalities. With the same

architecture of LXMERT, our Object-less model is

more efﬁcient and encouraging to overcome the chal-

lenges in images from blind people. Instead of de-

pending on external Object Detection models, our

OL–LXMERT is ideal enough to take advantage of

visual features to generate the local and global ob-

ject representation. In addition, these results also re-

veal that Visual Question Classiﬁcation is challeng-

ing and distinctive. Without the contribution of image

(I), VQC is indeed arduous in text classiﬁcation. This

task is fully worthy enough to be considered in the

independent problem in the multi-modal area.

4.3 Ablation Studies

In this part, we also conduct some ablation studies

to emphasize the contribution of our proposed com-

ponents. Firstly, we also present the reason that we

consider Visual Question Classiﬁcation as an inde-

pendent task. With a cursory glance, VQC is quite

similar to the text classiﬁcation task in NLP. The re-

sults in Table 4, however, reﬂect this task’s differences

and challenges. In text classiﬁcation, the category is

determined by the context of natural language. How-

ever, the type of visual question is based on the re-

lationship between images and texts. Especially, in

VizWiz-VQC, questions are spoken by the blind in

their daily lives, so it contains a lot of redundant infor-

mation. In Table 4, the single modality model can not

overcome the challenges in the VQC task. With the

combination of images and questions, our approach

and previous multi-modal system have enough fea-

tures to give a correct choice.

Table 4: The contribution of images and texts in multi-

modal VQC task.

Model Precision Recall F1

Q BERT 0.58 0.63 0.59

Vision

Transformer

0.56 0.57 0.55

QI OL–LXMERT 0.67 0.69 0.68

Secondly, we also emphasize the strength of vi-

sual features from Transformer architecture against

traditional Convolution Neural Work models. In this

comparison, we utilize the image features from the

latest improvement of the CNN-based model as Efﬁ-

cientNet (Tan and Le, 2019). Our detailed compari-

son between Transformer-based and CNN-based im-

age feature extraction is presented in Table 5. Ob-

viously, Vision Transformer obtains the best perfor-

mance against the traditional approaches in CNN.

The visible question in this comparison is the

weakness of virtual objects in CNN-based approaches

against the Object-based model of Faster R-CNN.

However, when we consider the architecture of Faster

R-CNN carefully, it is easy to realize that both Ef-

ﬁcientNet and Faster-RCNN are also deployed by the

CNN models. Moreover, the annotated information of

Object Detection is more greatly enriched than image

classiﬁcation. Besides, LXMERT (Tan and Bansal,

2019) architecture is designed and trained to satisfy

the object-based models. Therefore, with the same

fundamental architecture from CNN, the performance

of Faster RCNN is better than EfﬁcientNet in the

LXMERT model.

However, as we mentioned above, the drawback

of Convolution Neural Network models is based on

the mechanism of kernels which only observe limited

regions in images. In Object-less images, there are

a few objects in high conﬁdence, which means the

features of local objects are less meaningful to cover

all content of images. On the contrary, our model

takes advantage of the Transformer-based approach to

extract the global features in the object-less images.

Object-less Vision-language Model on Visual Question Classiﬁcation for Blind People

185

Table 5: The comparison of Transformer-based and CNN-based image feature extraction.

Model Precision Recall F1

Object-based Faster-RCNN (Ren et al., 2015) 0.63 0.70 0.66

Objectless-based

EfﬁcientNet-b7 (Tan and Le, 2019) 0.58 0.63 0.59

EfﬁcientNet-b6 (Tan and Le, 2019) 0.56 0.57 0.55

ViT (B 16) 0.67 0.69 0.68

With the same process of virtual objects, the global

features from Transformer architecture obtain signiﬁ-

cant results against CNN-based representation in both

Image Classiﬁcation and Object Detection models. It

also reﬂects that our virtual images are auspicious

enough to integrate the global and local features in

images.

5 DISCUSSION

As a result, our virtual objects are created to reduce

the dependence on object-based features in vision-

language models. However, there are some special

cases where the content of objects is so important.

Through the detailed confusion matrix in Figure 4,

the strength and weaknesses of our virtual objects are

demonstrated clearly.

(a) LXMERT. (b) OL–LXMERT.

Figure 4: The detailed confusion matrix between LXMERT

and OL–LXMERT.

Firstly, our Object-less LXMERT model outper-

forms the object-based LXMERT in total. Speciﬁ-

cally, our model has signiﬁcant success in the unan-

swerable samples which are the characteristic features

of the VizWiz dataset against the previous works such

as VQAv2.0 (Goyal et al., 2017), CLEVR (Johnson

et al., 2017), etc. The main reason for the appearance

of unanswerable samples in VizWiz comes from col-

lection process from blind people. Obviously, these

samples are too poor-qualiﬁed to detect any objects in

images. Therefore, in these cases, our virtual objects

are indeed efﬁcient to predict the category of visual

questions.

With the other question, both LXMERT and OL-

LXMERT are equivalent in precision, recall and F1-

score. Nevertheless, the recall of OL-LXMERT is

worse than LXMERT model in number and yes/no

question. It means that the object-based model fo-

cuses on the relationship between objects and key-

words in question to predict the type of question. It

also comes from the characteristic of the number and

yes/no visual samples whose content is about the exis-

tence and quantity of objects. However, the precision

of the LXMERT model in these kinds of questions

is worse than OL-LXMERT. Although these samples

tend to relate to the appearance of objects, most im-

ages in the VizWiz dataset are object-less. Therefore,

our object-less model is more powerful to cover the

global and local features through virtual objects.

Obviously, our virtual objects prove their strength

and robustness in four kinds of questions. Especially,

in unanswerable questions, our virtual objects clearly

prove their importance and potential. Even, in the

mainstream of object-based models in number and

yes/no visual question, our object-less also obtains

signiﬁcant precision against LXMERT. However, we

can not deny that the low recall of OL-LXMERT in

the object-based question is also the weakness of our

virtual objects. It encourages us to deploy the deli-

cacy combination between real and virtual objects in

the future works.

6 CONCLUSION

In this paper, we emphasize the importance and ne-

cessity of the Visual Question Classiﬁcation task as

an independent problem in the multi-modal area, es-

pecially in object-less images for blind people. We

also propose the Object-Less LXMERT model to take

advantage of the pre-trained vision-language model

with the fewest modiﬁcation via transfer learning.

Our OL-LXMERT model is efﬁcient to generate the

virtual objects for replacing the role of the external

Object Detection models in previous vision-language

approaches. Through our detailed comparison and

ablation studies, our Object-less LXMERT model

achieves signiﬁcant results against the competitive

baselines in both single and multiple modalities in our

extracted VizWiz-VQC 2020.

ICAART 2022 - 14th International Conference on Agents and Artiﬁcial Intelligence

186

ACKNOWLEDGEMENTS

This work was supported by JSPS Kakenhi Grant

Number 20H04295, 20K20406, and 20K20625. This

research also was funded by the University of Sci-

ence, VNU-HCM, Vietnam under grant number

CNTT 2021-11.

REFERENCES

Anderson, P., He, X., Buehler, C., Teney, D., Johnson, M.,

Gould, S., and Zhang, L. (2018). Bottom-up and top-

down attention for image captioning and visual ques-

tion answering. In Proceedings of the IEEE Con-

ference on Computer Vision and Pattern Recognition

(CVPR).

Devlin, J., Chang, M.-W., Lee, K., and Toutanova, K.

(2019). BERT: Pre-training of deep bidirectional

transformers for language understanding. In Proceed-

ings of the 2019 Conference of the North American

Chapter of the Association for Computational Lin-

guistics: Human Language Technologies, Volume 1

(Long and Short Papers), pages 4171–4186.

Dosovitskiy, A., Beyer, L., Kolesnikov, A., Weissenborn,

D., Zhai, X., Unterthiner, T., Dehghani, M., Minderer,

M., Heigold, G., Gelly, S., Uszkoreit, J., and Houlsby,

N. (2021). An image is worth 16x16 words: Trans-

formers for image recognition at scale. In Interna-

tional Conference on Learning Representations.

Goyal, Y., Khot, T., Summers-Stay, D., Batra, D., and

Parikh, D. (2017). Making the V in VQA matter: Ele-

vating the role of image understanding in Visual Ques-

tion Answering. In Proceedings of the IEEE Con-

ference on Computer Vision and Pattern Recognition

(CVPR).

Gurari, D., Li, Q., Stangl, A. J., Guo, A., Lin, C., Grau-

man, K., Luo, J., and Bigham, J. P. (2018). Vizwiz

grand challenge: Answering visual questions from

blind people. In Proceedings of the IEEE Conference

on Computer Vision and Pattern Recognition (CVPR).

Johnson, J., Hariharan, B., van der Maaten, L., Fei-Fei, L.,

Lawrence Zitnick, C., and Girshick, R. (2017). Clevr:

A diagnostic dataset for compositional language and

elementary visual reasoning. In Proceedings of the

IEEE Conference on Computer Vision and Pattern

Recognition (CVPR).

Le, T., Nguyen, H. T., and Nguyen, M. L. (2020). Integrat-

ing transformer into global and residual image feature

extractor in visual question answering for blind peo-

ple. In 2020 12th International Conference on Knowl-

edge and Systems Engineering (KSE), pages 31–36.

Le, T., Nguyen, H. T., and Nguyen, M. L. (2021a). Multi

visual and textual embedding on visual question an-

swering for blind people. Neurocomputing, 465:451–

464.

Le, T., Nguyen, H. T., and Nguyen, M. L. (2021b). Vi-

sion and text transformer for predicting answerability

on visual question answering. In 2021 IEEE Interna-

tional Conference on Image Processing (ICIP), pages

934–938.

Lin, Y., Meng, Y., Sun, X., Han, Q., Kuang, K., Li, J., and

Wu, F. (2021). Bertgcn: Transductive text classiﬁca-

tion by combining gnn and bert. In Proceedings of the

59th Annual Meeting of the Association for Computa-

tional Linguistics.

Parmar, N., Vaswani, A., Uszkoreit, J., Kaiser, L., Shazeer,

N., Ku, A., and Tran, D. (2018). Image transformer.

In Proceedings of the 35th International Conference

on Machine Learning, volume 80 of Proceedings of

Machine Learning Research, pages 4055–4064.

Ren, S., He, K., Girshick, R., and Sun, J. (2015). Faster

r-cnn: Towards real-time object detection with re-

gion proposal networks. In Cortes, C., Lawrence,

N., Lee, D., Sugiyama, M., and Garnett, R., editors,

Advances in Neural Information Processing Systems,

volume 28, page 91–99. Curran Associates, Inc.

Tan, H. and Bansal, M. (2019). LXMERT: Learning cross-

modality encoder representations from transformers.

In Proceedings of the 2019 Conference on Empirical

Methods in Natural Language Processing and the 9th

International Joint Conference on Natural Language

Processing (EMNLP-IJCNLP), pages 5100–5111.

Tan, M. and Le, Q. (2019). EfﬁcientNet: Rethinking model

scaling for convolutional neural networks. In Chaud-

huri, K. and Salakhutdinov, R., editors, Proceedings of

the 36th International Conference on Machine Learn-

ing, volume 97 of Proceedings of Machine Learning

Research, pages 6105–6114. PMLR.

Wang, T., Huang, J., Zhang, H., and Sun, Q. (2020). Vi-

sual commonsense r-cnn. In IEEE/CVF Conference

on Computer Vision and Pattern Recognition (CVPR).

Yang, Z., Dai, Z., Yang, Y., Carbonell, J., Salakhutdinov,

R. R., and Le, Q. V. (2019). Xlnet: Generalized

autoregressive pretraining for language understand-

ing. In Wallach, H., Larochelle, H., Beygelzimer,

A., d'Alch

e-Buc, F., Fox, E., and Garnett, R., editors,

Advances in Neural Information Processing Systems,

volume 32. Curran Associates, Inc.

Yao, L., Mao, C., and Luo, Y. (2019). Graph con-

volutional networks for text classiﬁcation. In The

Thirty-Third AAAI Conference on Artiﬁcial Intelli-

gence, AAAI 2019, The Thirty-First Innovative Ap-

plications of Artiﬁcial Intelligence Conference, IAAI

2019, The Ninth AAAI Symposium on Educational Ad-

vances in Artiﬁcial Intelligence, EAAI 2019, pages

7370–7377.

Yu, Z., Yu, J., Cui, Y., Tao, D., and Tian, Q. (2019). Deep

modular co-attention networks for visual question an-

swering. In Proceedings of the IEEE Conference on

Computer Vision and Pattern Recognition (CVPR),

pages 6281–6290.

Object-less Vision-language Model on Visual Question Classiﬁcation for Blind People

187
