Continuous Perception for Classifying Shapes and Weights of Garments

for Robotic Vision Applications

Li Duan

and Gerardo Aragon-Camarasa

School of Computing Science, University of Glasgow, Glasgow, U.K.

Keywords:

Continuous Perception, Depth Images, Shapes and Weights Predictions.

Abstract:

We present an approach to continuous perception for robotic laundry tasks. Our assumption is that the visual

prediction of a garment’s shapes and weights is possible via a neural network that learns the dynamic changes

of garments from video sequences. Continuous perception is leveraged during training by inputting consec-

utive frames, of which the network learns how a garment deforms. To evaluate our hypothesis, we captured

a dataset of 40K RGB and depth video sequences while a garment is being manipulated. We also conducted

ablation studies to understand whether the neural network learns the physical properties of garments. Our

ﬁndings suggest that a modiﬁed AlexNet-LSTM architecture has the best classiﬁcation performance for the

garment’s shapes and discretised weights. To further provide evidence for continuous perception, we evaluated

our network on unseen video sequences and computed the ’Moving Average’ over a sequence of predictions.

We found that our network has a classiﬁcation accuracy of 48% and 60% for shapes and weights of garments,

respectively.

1 INTRODUCTION

Perception and manipulation in robotics are an inter-

active process which a robot uses to complete a task

(Bohg et al., 2017). That is, perception informs ma-

nipulation, while manipulation of objects improves

the visual understanding of the object. Interactive per-

ception predicates that a robot understands the con-

tents of a scene visually, then acts upon it, i.e. ma-

nipulation starts after perception is completed. In

this paper, we depart from the idea of interactive

perception and theorise that perception and manip-

ulation run concurrently while executing a task, i.e.

the robot perceives the scene and updates the ma-

nipulation task continuously (i.e. continuous percep-

tion). We demonstrate continuous perception in a de-

formable object visual task where a robot needs to

understand how objects deform over time to learn its

physical properties and predict the garment’s shape

and weight.

Due to their materials’ physical and geometric

properties, garments usually have folds, crumples

and holes, which are irregular shaped and conﬁg-

ured, making garments to have a high-dimensional

state space. Therefore, when a robot manipulates a

https://orcid.org/0000-0002-0388-752X

https://orcid.org/0000-0003-3756-5569

garment, the deformations of the garment is unpre-

dictable and complex. Due to the high dimensionality

of garments and complexity in scenarios while ma-

nipulating garments, previous approaches for predict-

ing categories and physical properties of garments are

not robust to continuous deformations (Tanaka et al.,

2019)(Mart

ınez et al., 2019). Prior research (Bhat

et al., 2003)(Tanaka et al., 2019), (Runia et al., 2020)

has leveraged the use of simulated environments to

predict how a garment deforms, however, real-world

manipulation scenarios such as grasping, folding and

ﬂipping garments are difﬁcult to be simulated because

garments can take an inﬁnite number of possible con-

ﬁgurations in which a simulation engine may fail to

capture. Moreover, simulated environments can not

be fully aligned with the real environment, and a

slight perturbation in the real environment will cause

simulations to fail.

Garment conﬁgurations (garment state space)

have high dimensionality, therefore motion planning

for garments requires a high dimensionality space.

This motion planning space should represent the dy-

namic characteristics of garments and the robot’s dy-

namic capabilities to successfully plan a motion. In

this paper, we argue that it is need to learning physi-

cal properties ﬁrst to enable robotic manipulation of

garments (and other deformable objects). Garment

348

Duan, L. and Aragon-Camarasa, G.

Continuous Perception for Classifying Shapes and Weights of Garments for Robotic Vision Applications.

DOI: 10.5220/0010804300003124

In Proceedings of the 17th International Joint Conference on Computer Vision, Imaging and Computer Graphics Theory and Applications (VISIGRAPP 2022) - Volume 4: VISAPP, pages

348-355

ISBN: 978-989-758-555-5; ISSN: 2184-4321

shapes and weights are two important geometric and

physical properties of garments. In this paper, we

therefore learn the physical and geometric proper-

ties of garments from real-world garment samples.

For this, garments are being grasped from the ground

and then dropped. This simple manipulation scenario

allows us to train a neural network to perceive dy-

namic changes from depth images and learn physical

(weights) and geometric (shapes) properties of gar-

ments while being manipulated, see Fig 1.

To investigate the continuous perception of de-

formable objects, we have captured a dataset contain-

ing video sequences of RGB and depth images. We

aim to predict the physical properties (i.e. weights)

and categories of garment shapes from a video se-

quence. Therefore, we address the state-of-the-art

limitations by learning dynamic changes as opposed

to static representations of garments (Jim

enez and

Torras, 2020; Ganapathi et al., 2020). We use weight

and shape as the experimental variables to support

our continuous perception hypothesis. We must note

that we do not address manipulation in this paper

since we aim to understand how to equip a robot

best to perceive deformable objects visually, as serves

as a prerequisite for accommodating online feedback

corrections for garment robotic manipulation. Our

codes and datasets are available at: https://github.

com/cvas-ug/cp-dynamics

2 BACKGROUND

Bhat (Bhat et al., 2003) proposed an approach to

learn physical properties of clothes from videos by

minimising a squared distance error (SSD) between

the angle maps of folds and silhouettes of the sim-

ulated clothes and the real clothes. However, their

approach observes high variability while predicting

physical properties of clothes such as shear damping,

bend damping and linear drag. Li et al. (Li et al.,

2018; Li et al., 2020) has proposed to integrate par-

ticles to simulate simple fabrics and ﬂuids in order

to learn rigidness and moving trajectories of a de-

formable object using a Visually Grounded Physics

Learner network (VGPL). By leveraging VGPL to-

gether with an LSTM, the authors can predict the

rigidness and future shapes of the object. In their re-

search, they are using particles to learn the dynamic

changes of objects. In contrast, due to the high dimen-

sionality and complexity of garments, particles are an

approximation to the dynamic changes which cannot

be fully described for a robot manipulation task. In

Bhat(Bhat et al., 2003)’s work, they study the phys-

ical properties of garments by comparing differences

between motion video frames of real and simulated

garments, where they only aim to match the shapes

between real and simulated garments. In our work,

we learn the physical properties of garments through

continuously perceiving video frames of grasped gar-

ments, which means we learn deformations of gar-

ments rather than shapes of garments. Deformations

of garments encode dynamics characteristics of gar-

ments, which depend on their physical and geometric

properties. Therefore, our network has higher accu-

racy while predicting physical and geometric proper-

ties of garments (equivalent to shapes and weights of

garments) compared to (Bhat et al., 2003).

To learn elasticity of objects, Senguapa et al.

(Sengupta et al., 2020) has proposed an approach

where a robot presses the surface of objects and ob-

serves the object’s shape changes in a simulated and

a real environment. They aimed to ﬁnd the difference

of the simulated and real objects Young’s modules to

estimate the object’s elasticity and estimate forces ap-

plied on the object without any force sensor. Tanake

et al. (Tanaka et al., 2019) minimised the shape dif-

ference between real and simulated garments to ﬁnd

their stiffness. In these two approaches, if there ex-

ists a small variation between simulation and reality

or if an unseen object is presented, their approaches

require to simulate novel object models again as the

simulation is limited to known object models.

Compared with previous research that has utilised

temporal images to analyse the physical properties

of deformable objects, Davis et al. (Davis et al.,

2015) chose to investigate deformable objects’ phys-

ical properties in terms of their vibration frequen-

cies. That is, they employed a loudspeaker to gen-

erate sonic waves on fabrics to obtain modes of vi-

bration of fabrics and analysed the characteristics of

these modes of vibration to identify the fabrics materi-

als. The main limitation of this approach is in the use

of high-end sensing equipment which would make it

impractical for a robotic application. In this paper, we

employ an off-the-shelf RGBD camera to learn dy-

namic changes of garments.

Yang et al. (Yang et al., 2017) has proposed a

CNN-LSTM architecture. Their method consists of

training a CNN-LSTM model to learn the stretch stiff-

ness and bend stiffness of different materials and then

apply the trained model to classify garment material

types. However, suppose a garment consists of mul-

tiple materials. In that case, the CNN-LSTM model

will not be able to predict its physical properties be-

cause their work focuses on garments with only one

fabric type. Mariolis et al. (Mariolis et al., 2015) de-

vised a hierarchical convolutional neural network to

conduct a similar experiment to predict the categories

Continuous Perception for Classifying Shapes and Weights of Garments for Robotic Vision Applications

349

of garments and estimate their poses with real and

simulated depth images. Their work has pushed the

accuracy of the classiﬁcation from 79.3% to 89.38%

with respect to the state of the art. However, the main

limitations are that their dataset consists of 13 gar-

ments belonging to three categories. In this paper, we

address this limitation by compiling a dataset of 20

garments belonging to ﬁve categories of similar ma-

terial types, and we have evaluated our neural network

to predict unseen garments.

Similar to this work, Martinez et al. (Mart

ınez

et al., 2019) has proposed a continuous perception

approach to predict the categories of garments by ex-

tracting Locality Constrained Group Sparse represen-

tations (LGSR) from depth images of the garments.

However, the authors did not address the need to un-

derstand how garments deform over time continu-

ously as full sequences need to be processed in order

to get a prediction of the garment shape. Continuous

predictions is a prerequisite for accommodating dex-

terous robotic manipulation and online feedback cor-

rections to advanced garment robotic manipulation.

3 MATERIALS AND METHODS

We hypothesise that continuous perception allows a

robot to learn the physical properties of clothing items

implicitly (such as stiffness, bending, etc.) via a Deep

Neural Network (DNN) because a DNN can predict

the dynamic changes of an unseen clothing item above

chance. For this, we implemented an artiﬁcial neu-

ral network that classiﬁes shapes and weights of un-

seen garments (Fig. 1 and Section 3.1). Our network

consists of a feature extraction network, an LSTM

unit and two classiﬁers for classifying the shape and

weight of garments. We input three consecutive frame

images (t, t + 1, t + 2) into our network to predict the

shape and weight of the observed garment from a pre-

dicted feature latent space at t + 3. We propose to use

the garment’s weight as an indicator that the network

has captured and can interpret the physical properties

of garments. Speciﬁcally, the garment’s weight is a

physical property and is directly proportional to the

forces applied to the garment’s fabric over the inﬂu-

ence of gravity.

Garment Dataset. To test our hypothesis, we have

captured 200 videos of a garment being grasped from

the ground to a random point above the ground around

50 cm and then dropped from this point. Each gar-

ment has been grasped and dropped down ten times

in order to capture its intrinsic dynamic properties.

Videos were captured with an ASUS Xtion Pro, and

each video consists of 200 frames (the sampling rate

is 30Hz), resulting in 40K RGB and 40K depth im-

ages at a resolution of 480×680 pixels.

Our dataset features 20 different garments of ﬁve

garment shape categories: pants, shirts, sweaters,

towels and t-shirts. Each shape category contains four

unique garments. Garments are made of cotton ex-

cept for sweaters which are made of acrylic and ny-

lon. To obtain segmentation masks, we use a green

background, and we used a green sweater to remove

the inﬂuence of our arm. We then converted RGB im-

ages to a HSV colour space and identiﬁed an optimal

thresholding value in the V component to segment the

green background and our arm from the garment.

3.1 Network Architecture

Our ultimate objective is to learn the dynamic proper-

ties of garments as they are being manipulated. For

this, we implemented a neural network comprising

a feature extraction network, a recurrent neural net-

work, and a shape and a weight classiﬁer networks.

Fig. 1 depicts the overall neural network architecture.

We split training this architecture into learning the ap-

pearance of the garment in terms of its shape ﬁrst,

then learning the garments dynamic properties from

visual features using a recurrent neural network (i.e.

LSTM).

Feature Extraction. A feature extraction network

is needed to describe the visual properties of gar-

ments (RGB images) or to describe the topology of

garments (depth images). We therefore implemented

3 state of the art network architectures, namely

AlexNet(Krizhevsky et al., 2012),VGG 16(Simonyan

and Zisserman, 2014) and ResNet 18 (He et al., 2016).

In Section 4.2, we evaluate their potential for extrac-

tion features from garments.

Shape and Weight Classiﬁers. The classiﬁer com-

ponents in AlexNet, Resnet and VGG-16 networks

comprise fully connected layers that are used to pre-

dict a class depending on the visual task. In these

layers, one fully connected layer is followed by a

rectiﬁer and a regulariser, i.e. a ReLu and dropout

layers. However, in this paper, we consider whether

the dropout layer will beneﬁt the ability of the neu-

ral network to generalise the classiﬁcation prediction

for garments. The reason is that the image dataset

used to train these networks contain more than 1000

categories and millions of images (Krizhevsky et al.,

2012), while our dataset is considerable smaller (ref.

Section 3). The latter means that the dropout layers

may ﬁlter out useful features while using our dataset.

VISAPP 2022 - 17th International Conference on Computer Vision Theory and Applications

350

t+1

t+n

-1

t+1

t+2

LSTM

Concatenate

t+3

(Shape)

(Weight)

Average

Pooling

Shape class

label

Weight

class label

[3,1,256,256] [3,256,15,15]

[3,256,15,15] [1,256,15,15]

(after reshaping from [1,57600])

See Sec.

III-B.2 for

details

hidden state dimension: (1, 256, 255)

cell state dimension: (1, 256, 255)

Sampling Rate: 30Hz

Figure 1: Our network is divided into feature extraction (F), an LSTM unit and classiﬁer networks. Depth images of a garment

with a resolution of 256 × 256 pixels are passed to the feature extraction network. Three feature latent spaces, i.e. C

, C

+ 1

and C

+ 2 from time-steps t, t + 1 and t + 2, respectively, are concatenated and then passed to the LSTM. Each feature latent

space has a tensor size of 15 × 15 with a channel size of 256. From the LSTM, we obtain a predicted future feature latent

space (C

+ 3) which is reshaped back to the original feature space size (i.e. [1, 256, 15, 15]) and input to an average pooling

layer. The average pool output with size of [1, 256, 6, 6] is ﬂattened to [1, 9216] and passed to the fully connected (FC) shape

and weight classiﬁers.

Dropout layers are useful when training large datasets

to avoid overﬁtting. Therefore, we have experimented

with modifying the fully connected networks by re-

moving the ReLu and dropout layers and observe their

impact on the shape and weight classiﬁcation tasks.

After experimenting with four different network pa-

rameters, we found that the best performing structure

comprises three fully connected layer blocks, each of

which only contains a linear layer. The number of

features stays as 9216 without any reduction, then the

number reduces to 512 in the second layer, and ﬁ-

nally, we reduce to 5 for shape and 3, for weight as

the outputs of the classiﬁcations. We do not include

these experiments in this paper as they do not directly

test the hypothesis of this paper but instead demon-

strates how to optimise the classiﬁcation networks for

the shape and weight classiﬁers in this paper.

LSTM Rationale. The ability to learn dynamic

changes of garments is linked to perceiving the object

continuously and being able to predict future states.

That is, if a robot can predict future changes of gar-

ments, it will be able to update a manipulation task

on-the-ﬂy by perceiving a batch of consecutive im-

ages rather then receiving a single image and act-

ing sequentially. For this, we have adopted a Long

Short-Term Memory (LSTM) network to learn the dy-

namic changes of consecutive images. After training

(ref. Section 3.2), we examined the ability to learn

garments’ dynamic changes by inputting unseen gar-

ments images into the trained feature extractor to get

their encoded feature maps and input those encoded

feature maps into the trained LSTM and evaluate if

the network (Fig. 1) can predict shapes and weights

classiﬁcations.

3.2 Training Strategy

We split training our architecture (Fig. 1) into two

parts. First, we let the network learn the appearance

or topology of garments by means of the feature ex-

traction and classiﬁcation networks (Sections 3.1 and

3.1). After this, we then train the LSTM network

while freezing the parameters of the feature extrac-

tion and classiﬁcation networks to learn the dynamic

changes of garments.

We have used pre-trained architectures for

AlexNet, Resnet 18 and VGG 16 but ﬁne-tuned its

classiﬁer component. For depth images, we ﬁne-

tuned the input channel size of the ﬁrst convolutional

layer from 3 to 1 (for AlexNet, Resnet 18 and VGG

16). The loss function adopted is Cross-Entropy be-

tween the predicted shape label and the target shape

label. After training the feature extraction networks,

we use these networks to extract features of consec-

utive images and concatenate features for the LSTM.

The LSTM learning task is to predict the next feature

description from the input image sequence, and this

predicted feature description is passed to the trained

classiﬁer to obtain a predicted shape or weight label.

Continuous Perception for Classifying Shapes and Weights of Garments for Robotic Vision Applications

351

The loss function for training the LSTM consists of

the mean square error between the target feature vec-

tor and the predicted feature vector generated by the

LSTM, and the Cross-Entropy between the predicted

shape label and the target shape label. The loss func-

tion is:

total

= L

MSE

+ 1000 × L

Cross−Entropy

(1)

We have used a ’sum’ mean squared error during

training, but we have reported our results using the av-

erage value of the mean squared error of each point in

the feature space. We must note that we multiply the

cross-entropy loss by 1000 to balance the inﬂuence of

the mean squared error and cross-entropy losses.

4 EXPERIMENTS

For a piece of garment, shape is not an indicator of

the garment’s physical properties but the garment’s

weight as it is linked to the material’s properties such

as stiffness, damping, to name a few. However, ob-

taining ground truth for stiffness, damping, etc. re-

quires the use of specialised equipment and the goal

of this paper is to learn these physical properties im-

plicitly. That is, we propose to use the garment’s

weight as a performance measure to validate our ap-

proach using unseen samples of garments.

To test our hypothesis, we have adopted a leave-

one-out cross-validation approach. That is, in our

dataset, there are ﬁve shapes of garments: pants,

shirts, sweaters, towels and t-shirts; and for each type,

there are four garments (e.g. shirt-1, shirt-2, shirt-3

and shirt-4). Three of the four garments (shirt-1, shirt-

2 and shirt-3) are used to train the neural network, and

the other (shirt-4) is used to test the neural work (un-

seen samples). We must note that each garment has

different appearance such as different colour, dimen-

sions, weights and volumes. For weight classiﬁcation,

we divided our garments into three categories: light

(the garments weighed less than 180g), medium (the

garments weighed between 180g and 300g) and heavy

(the garments weighted more than 300g).

We have used a Thinkpad Carbon 6th Generation

(CPU: Intel i7-8550U) equipped with an Nvidia GTX

970, running Ubuntu 18.04. We used SGD as the opti-

miser for training the feature extraction and classiﬁca-

tion networks, with a learning rate of 1 × 10

−3

and a

momentum of 0.9 for 35 epochs. We then used Adam

for training the LSTM with a learning rate of 1 × 10

−4

and a step learning scheduler with a step size of 15

and decay rate of 0.1 for 35 epochs. The reason for

adopting different optimisers is that Adam provides a

better training result than SGD for training the LSTM,

while SGD observes faster training for the feature ex-

traction and classiﬁers. To test our hypothesis, we ﬁrst

experiment on which image representation (RGB or

depth images) is the best to capture intrinsic dynamic

properties of garments. We also examined three dif-

ferent feature extraction networks to ﬁnd the best per-

forming network for classifying shapes and weights

of garments (Section 4.1). Finally, we evaluate the

performance of our network on a continuous percep-

tion task (Section 4.2).

4.1 Feature Extraction Ablation

We have tested using three different deep convolu-

tional feature extraction architectures: AlexNet, VGG

16 and ResNet 18. We compared the performance of

shape and weight classiﬁcation of unseen garments

with RGB and depth images. These feature extractors

have been coupled with a classiﬁer without an LSTM;

effectively producing single frame predictions similar

to (Sun et al., 2017).

From Table 1, it can be seen that ResNet 18 and

VGG 16 overﬁtted the training dataset. As a conse-

quence, their classiﬁcation performance is below or

close to a random prediction, i.e. we have 5 and 3

classes for shape and weight. AlexNet, however, ob-

serves a classiﬁcation performance above chance for

depth images. By comparing classiﬁcation perfor-

mances between RGB and depth images in Table 1,

we observe that depth images (47.6%) outperformed

the accuracy of a network trained on RGB images

(7.4%) while using AlexNet. The reason is that a

depth image is a map that reﬂects the distances be-

tween each pixel and the camera, which can capture

the topology of the garment. The latter is similar

to the ﬁndings in (Sun et al., 2017; Mart

ınez et al.,

2019).

We observe a similar performance while classi-

fying garments’ weights. AlexNet has a classiﬁca-

tion performance of 48.3% while using depth im-

ages. We must note that the weights of garments that

are labelled as ’medium’ are mistakenly classiﬁed as

’heavy’ or ’light’. Therefore compared to the predic-

tions on shape, predicting weights is more difﬁcult

for our neural network on a single shot perception

paradigm. From these experiments, we, therefore,

choose AlexNet as the feature extraction network for

the remainder of the following experiments.

4.2 Continuous Perception

To test our continuous perception hypothesis (Sec-

tion 3), we have chosen AlexNet and a window se-

quence size of 3 to predict the shape and weight of

VISAPP 2022 - 17th International Conference on Computer Vision Theory and Applications

352

Table 1: Classiﬁcation accuracy (in percentages) of unseen garment shapes.

Feature Extractor P SH SW TW TS Average

AlexNet(depth) 57.0 13.0 71.0 47.0 50.0 47.6

AlexNet(RGB) 18.0 13.0 0.0 0.0 0.0 6.2

VGG16(depth) 25.0 18.0 35.0 20.0 25.0 24.6

VGG16(RGB) 9.0 14.0 20.0 7.0 11.0 12.2

ResNet18(depth) 6.0 10.0 51.0 69.0 5.0 28.2

ResNet18(RGB) 16.0 1.0 2.0 81.0 14.0 22.8

Table 2: Classiﬁcation accuracy of unseen garment weights.

Feature Extractor Light Medium Heavy Average

AlexNet (depth) 72.0 18.0 55.0 48.3

AlexNet (RGB) 82.0 14.0 7.0 34.3

VGG16 (depth) 40.0 48.0 31.0 39.7

VGG16 (RGB) 38.0 3.0 100.0 47

ResNet18 (depth) 51.0 6.0 47.0 34.7

ResNet18 (RGB) 41.0 5.0 10.0 18.7

unseen video sequences from our dataset, i.e. video

sequences that have not been used for training. For

this, we accumulate prediction results over the video

sequence and compute the Moving Average (MA)

over the evaluated sequence. That is, MA serves

as the decision-making mechanism that determines

the shape and weight classes after observing a gar-

ment deform over time rather than the previous three

frames as in previous sections.

This experiment consists of passing 3 consecutive

frames to the network to output a shape and weight

class probability for each output in the networks. We

then compute their MA values for each output before

sliding into the next three consecutive frames, e.g.

slide from frame t − 2, t − 1, t to frame t − 1, t, t +1.

After we slide across the video sequence and accu-

mulate MA values, we calculated an average of the

MA values for each class. We chose the class that ob-

serves the maximum MA value as a prediction of the

target category. Our unseen test set contains 50 video

sequences. Hence, we got 50 shape and weight pre-

dictions and used to calculate the confusion matrices

in Fig. 2 and Fig. 3.

From Fig. 2(left) and Fig. 3(left), it can been seen

that an average prediction accuracy of 48% for shapes

and an average prediction of 60% for weights have

been obtained for all unseen video sequences. We can

observe in Fig. 2(left) that the shirt has been wrongly

classiﬁed as a pant in all its video sequences, but the

sweater is labelled correctly in most of its sequences.

Half of the towels have been wrongly recognised as

a t-shirt. Also for weight, the medium-weighted gar-

ments are wrongly classiﬁed in all their sequences,

where most of them have been categorised as heavy

garments, but all heavy garments are correctly classi-

ﬁed. Fig. 2 (right) shows an example of the MA over

a video sequence of a shirt. It can be seen that the net-

work changes its prediction between being a t-shirt

or a pant while the correct class is a shirt. The rea-

son for this is that the shirts, t-shirts and pants in our

dataset are made of cotton. Therefore, these garments

have similar physical properties, but different shapes

and our neural network is not capable of differentiat-

ing between these unseen garments, which suggests

that further manipulations are required to improve the

classiﬁcation prediction. Fig. 3 (right) has suggested

that the network holds a prediction as ’heavy’ over a

medium-weight garment. This is because heavy gar-

ments are sweaters and differ from the rest of the

garments in terms of its materials. Therefore, our

network can classify heavy garments but has a low-

performance accuracy for shirts and pants.

As opposed to shapes, weights are a more implicit

physical property which are more difﬁcult to be gen-

eralised. Nevertheless, the overall performance of the

network (48% for shapes and 60% for weights) sug-

gests that our continuous perception hypothesis holds

for garments with shapes such as pants, sweaters,

towels, and t-shirts and with weights such as light and

heavy, suggesting that further interactions with gar-

ments such as in (Willimon et al., 2011; Sun et al.,

2016) are required to improve the overall classiﬁ-

cation performance. We must note that the over-

all shape classiﬁcation performance while validating

our network is approximately 90%; suggesting that

the network can successfully predict known garment’s

shapes based on its dynamic properties.

Continuous Perception for Classifying Shapes and Weights of Garments for Robotic Vision Applications

353

Figure 2: Continuous shape prediction (Left: Moving Aver-

age Confusion Matrix; Right: Moving Average over a video

sequence).

Figure 3: Continuous weight prediction (Left: Moving Av-

erage Confusion Matrix; Right: Moving Average over a

video sequence).

5 CONCLUSIONS

From the ablation studies we have conducted, depth

images have a better performance over RGB images

because depth captures the garment topology prop-

erties of garments. That is, our network was able

to learn dynamic changes of the garments and make

predictions on unseen garments since depth images

have a prediction accuracy of 48% and 60% while

classifying shapes and weights, accordingly. We also

show that continuous perception improves classiﬁca-

tion accuracy. That is, weight classiﬁcation, which is

an indicator of garment physical properties, observes

an increase in accuracy from 48.3% to 60% under a

continous perception paradigm. This means that our

network can learn physical properties from continu-

ous perception. However, we observed an increase

of around 1% (from 47.6% to 48%) while continu-

ously classifying garment’s shape. The marginal im-

provement while continuously classifying shape in-

dicates that further manipulations, such as ﬂattening

(Sun et al., 2015) and unfolding (Doumanoglou et al.,

2016) are required to bring a unknown garment to a

state that can be recognised by a robot. That is, the

ability to predict dynamic information of a piece of

an unknown garment (or other deformable objects) fa-

cilitates robots’ efﬁciency to manipulate it by ensur-

ing how the garment will deform (Jim

enez and Tor-

ras, 2020; Ganapathi et al., 2020). Therefore, an un-

derstanding of the dynamics of garments and other

deformable objects can allow robots to accomplish

grasping and manipulation tasks with higher dexter-

ity

From the results, we can also observe that there

exist incorrect classiﬁcations of unseen shirts be-

cause of their similarity in their materials. There-

fore, we propose to experiment on how to improve

prediction accuracy on garments with similar mate-

rials and structures by allowing a robot to interact

with garments as proposed in (Sun et al., 2016). We

also envisage that it can be possible to learn the dy-

namic physical properties (stiffness) of real garments

from training a ’physical-similarity network’ (Phys-

Net) (Runia et al., 2020) on simulated garment mod-

els.

REFERENCES

Bhat, K. S., Twigg, C. D., Hodgins, J. K., Khosla, P. K.,

Popovi

c, Z., and Seitz, S. M. (2003). Estimating cloth

simulation parameters from video. In Proceedings of

the 2003 ACM SIGGRAPH/Eurographics symposium

on Computer animation, pages 37–51. Eurographics

Association.

Bohg, J., Hausman, K., Sankaran, B., Brock, O., Kragic,

D., Schaal, S., and Sukhatme, G. S. (2017). Interac-

tive perception: Leveraging action in perception and

perception in action. IEEE Transactions on Robotics,

33(6):1273–1291.

Davis, A., Bouman, K. L., Chen, J. G., Rubinstein, M., Du-

rand, F., and Freeman, W. T. (2015). Visual vibrome-

try: Estimating material properties from small motion

in video. In Proceedings of the ieee conference on

computer vision and pattern recognition, pages 5335–

5343.

Doumanoglou, A., Stria, J., Peleka, G., Mariolis, I., Petrik,

V., Kargakos, A., Wagner, L., Hlav

c, V., Kim, T.-

K., and Malassiotis, S. (2016). Folding clothes au-

tonomously: A complete pipeline. IEEE Transactions

on Robotics, 32(6):1461–1478.

Ganapathi, A., Sundaresan, P., Thananjeyan, B., Balakr-

ishna, A., Seita, D., Grannen, J., Hwang, M., Hoque,

R., Gonzalez, J. E., Jamali, N., Yamane, K., Iba, S.,

and Goldberg, K. (2020). Learning to smooth and fold

real fabric using dense object descriptors trained on

synthetic color images.

He, K., Zhang, X., Ren, S., and Sun, J. (2016). Deep resid-

ual learning for image recognition. In Proceedings of

the IEEE conference on computer vision and pattern

recognition, pages 770–778.

Jim

enez, P. and Torras, C. (2020). Perception of cloth in

assistive robotic manipulation tasks. Natural Comput-

ing, pages 1–23.

Krizhevsky, A., Sutskever, I., and Hinton, G. E. (2012). Im-

agenet classiﬁcation with deep convolutional neural

VISAPP 2022 - 17th International Conference on Computer Vision Theory and Applications

354

networks. In Advances in neural information process-

ing systems, pages 1097–1105.

Li, Y., Lin, T., Yi, K., Bear, D., Yamins, D. L. K., Wu, J.,

Tenenbaum, J. B., and Torralba, A. (2020). Visual

grounding of learned physical models.

Li, Y., Wu, J., Tedrake, R., Tenenbaum, J. B., and Torralba,

A. (2018). Learning particle dynamics for manipulat-

ing rigid bodies, deformable objects, and ﬂuids. arXiv

preprint arXiv:1810.01566.

Mariolis, I., Peleka, G., Kargakos, A., and Malassiotis, S.

(2015). Pose and category recognition of highly de-

formable objects using deep learning. In 2015 Inter-

national Conference on Advanced Robotics (ICAR),

pages 655–662. IEEE.

Mart

ınez, L., del Solar, J. R., Sun, L., Siebert, J. P., and

Aragon-Camarasa, G. (2019). Continuous perception

for deformable objects understanding. Robotics and

Autonomous Systems, 118:220 – 230.

Runia, T. F., Gavrilyuk, K., Snoek, C. G., and Smeulders,

A. W. (2020). Cloth in the wind: A case study of phys-

ical measurement through simulation. arXiv preprint

arXiv:2003.05065.

Sengupta, A., Lagneau, R., Krupa, A., Marchand, E.,

and Marchal, M. (2020). Simultaneous tracking

and elasticity parameter estimation of deformable ob-

jects. In IEEE Int. Conf. on Robotics and Automation,

ICRA’20.

Simonyan, K. and Zisserman, A. (2014). Very deep con-

volutional networks for large-scale image recognition.

arXiv preprint arXiv:1409.1556.

Sun, L., Aragon-Camarasa, G., Rogers, S., and Siebert,

J. P. (2015). Accurate garment surface analysis using

an active stereo robot head with application to dual-

arm ﬂattening. In 2015 IEEE international conference

on robotics and automation (ICRA), pages 185–192.

IEEE.

Sun, L., Aragon-Camarasa, G., Rogers, S., Stolkin, R., and

Siebert, J. P. (2017). Single-shot clothing category

recognition in free-conﬁgurations with application to

autonomous clothes sorting.

Sun, L., Rogers, S., Aragon-Camarasa, G., and Siebert,

J. P. (2016). Recognising the clothing categories from

free-conﬁguration using gaussian-process-based inter-

active perception. In 2016 IEEE International Con-

ference on Robotics and Automation (ICRA), pages

2464–2470.

Tanaka, D., Tsuda, S., and Yamazaki, K. (2019). A learn-

ing method of dual-arm manipulation for cloth folding

using physics simulator. In 2019 IEEE International

Conference on Mechatronics and Automation (ICMA),

pages 756–762. IEEE.

Willimon, B., Birchﬁeld, S., and Walker, I. (2011). Clas-

siﬁcation of clothing using interactive perception. In

2011 IEEE International Conference on Robotics and

Automation, pages 1862–1868.

Yang, S., Liang, J., and Lin, M. C. (2017). Learning-based

cloth material recovery from video. In Proceedings of

the IEEE International Conference on Computer Vi-

sion, pages 4383–4393.

Continuous Perception for Classifying Shapes and Weights of Garments for Robotic Vision Applications

355
