Visual-only Voice Activity Detection using Human Motion in Conference

Video

Keisuke Yamazaki

, Satoshi Tamura

, Yuuto Gotoh

and Masaki Nose

Graduate School of Natural Science and Technology, Gifu University, Gifu, Japan

Faculty of Engineering, Gifu University, Gifu, Japan

Ricoh Company, Ltd., Kanagawa, Japan

Keywords:

Voice Activity Detection, Human Motion, Speaker Diarization, Dynamic Image, Multi-modal Transfer

Module, Conference Video Processing.

Abstract:

In this paper, we propose a visual-only Voice Activity Detection (VAD) method using human movements.

Although audio VAD is commonly used in many applications, it has a problem it is not robust in noisy en-

vironments. In such the cases, multi-modal VAD using speech and mouth information is effective. However,

due to the current pandemic situation, people wear masks causing we cannot observe mouths. On the other

hand, utilizing a video capturing the entire of a speaker is useful for visual VAD, because gestures and mo-

tions may contribute to identify speech segments. In our scheme, we ﬁrstly obtain dynamic images which

represent motion of a person. Secondly, we fuse dynamic and original images using Multi-Modal Transfer

Module (MMTM). To evaluate the effectiveness of our scheme, we conducted experiments using conference

videos. The results show that the proposed model has better than the baseline. Furthermore, through model

visualization we conﬁrmed that the proposed model focused much more on speakers.

1 INTRODUCTION

We have many meetings for discussion and decision

making. Minutes are then often taken, which are use-

ful to conﬁrm the contents of meetings later. It is

still common to take minutes manually, however, it

costs signiﬁcantly. Therefore, in recent years, a lot

of research works have been done to automate the

process of taking minutes. In order to take minutes

automatically, it is necessary to develop technology

for speaker diarization, which recognizes ”who spoke

when,” and speech recognition and lip reading, which

recognize ”what was said.” In this study, we focus on

Voice Activity Detection (VAD) to recognize ”when

a person spoke,” that is one of the speaker diarization

elements. Although VAD has been investigated for

decades, there is a problem that the VAD accuracy is

often degraded by the existence of background noise

or cross talks. In order to further improve the accu-

racy, multi-modal VAD using face movies in addition

to speech data is considered to be an effective method;

Visual VAD (VVAD) utilizes mouth movements to

detect speech segments, and multi-modal VAD incor-

porates audio and visual information in an early- or a

late-fusion manner.

The spread of COVID-19 threat has drastically

changed the situation. Most meetings are held online,

and attendees usually wear masks. This causes new

issues for speaker diarization. Audio data are com-

pressed and distorted so that they could be transmitted

on the internet, resulting a mismatch between the data

and a VAD model. Wearing masks affects acoustic

characteristics, and more crucially, mouths are hidden

making conventional VVAD difﬁcult. To overcome

the last problem, we have investigated another per-

spective. Here we focus on video movies capturing

the entire of a speaker, and utilizing the whole move-

ments of the speaker. This is based on the discov-

ery that individuals unintentionally synchronize their

nonverbal and linguistic behavior during social inter-

actions (N.Latif et al., 2014). We consider that if we

could obtain features effective for VAD from body

movements and gestures, VVAD could be still pos-

sible even when a speaker’s mouth is not visible.

In this paper, we try to develop our VVAD based

on the above discussion. As a preliminary step, we

perform visual-only VAD using videos in which a

mask is artiﬁcially worn to a speaker, and verify the

effectiveness. To the best of my knowledge, this pa-

per is the ﬁrst attempt to perform VVAD on a speaker

570

Yamazaki, K., Tamura, S., Gotoh, Y. and Nose, M.

Visual-only Voice Activity Detection using Human Motion in Conference Video.

DOI: 10.5220/0010829200003122

In Proceedings of the 11th International Conference on Pattern Recognition Applications and Methods (ICPRAM 2022), pages 570-577

ISBN: 978-989-758-549-4; ISSN: 2184-4313

Figure 1: Visualization examples in our preliminary experi-

ments. Which area a VVAD model focused on is illustrated.

wearing a mask. We ﬁrstly build a VAD model using a

simple 3D Convolutional Neural Network (3DCNN).

Next, we conduct visualization to ﬁnd the areas of in-

terest in the prediction results, to examine the inter-

pretability of the model. Examples of the visualiza-

tion results are shown in Figure 1. Based on the pre-

liminary results, we propose a novel VVAD frame-

work using two modalities: video data and dynamic

images. Employing dynamic images is expected to

focus much more on human gestures.

The rest of this paper is organized as follows. At

ﬁrst, we describe related works in Section 2. Next,

Section 3 introduces our method including techniques

used in this work. Experiments, results and discussion

are described in Section 4. Finally, conclusion and

future work are presented in Section 5.

2 RELATED WORKS

2.1 Visual-only VAD

Recently, VVAD has been studied actively. There are

two main types of VVAD methods: using facial infor-

mation such as lip movements and head movements,

and using human appearance like gestures and body

movements.

In terms of using facial information, (A.Aubrey

et al., 2007) proposed two VVAD methods. The

ﬁrst one is applying Active Appearance Model to

lip regions to represent lip shape and texture as a

vector, and then modeling the features by hidden

Markov model. Another one is applying a spatio-

temporal ﬁlter which models human retina behaviors

and calculates the change to classify voice activity.

In (B.Joosten et al., 2015), the authors proposed a

VVAD method based on spatio-temporal gabor ﬁlters.

The authors applied the method to a mouth, a head or

the entire video frame, and found that the mouth re-

gions gave the best result. One of deep-learning mod-

els, Long Short-Term Memory (LSTM), was trained

using face images detected by CNN, and speech and

non-speech intervals were estimated by audio VAD in

(K.Stefanov et al., 2017). The LSTM model was able

to predict speech activities using video frame only,

and gave a good result on average.

The study of VVAD using human appearance is

more relevant to this paper. (B.G.Gebre et al., 2014b)

proposed a VVAD method using Motion History Im-

age (MHI). MHI is a method of representing mo-

tion in a video consisting of multiple frames into a

single image. The method showed the potential of

VVAD using human motion information. (M.Cristani

et al., 2011) introduced a method obtaining optical

ﬂows from a video, and encoded its energy and “com-

plexity” using an entropy-like measure. Their exper-

iment showed the usefulness of using gestures for

VAD. Note that the dataset used in the paper was

top-view. In order to address the VVAD task with

cues from whole body motion, some methods (optical

ﬂow, RGB-dynamic image, and combination of these)

for representing human movements were compared in

(M.Shahid et al., 2019a). They showed that dynamic

images gave better results on average for the dataset

they used. Subsequently, (M.Shahid et al., 2019b)

proposed a method combining RGB-dynamic images

and unsupervised domain adaptation technique, and

improved results in same dataset used in (M.Shahid

et al., 2019a). In (M.Shahid et al., 2021), the authors

extended their work and proposed a method apply-

ing the segmentation task to VAD. They generated

class activation maps using features extracted from

RGB-dynamic images, and created labels for each

speech/non-speech/background region. Using the la-

bels, they performed supervised learning to segment

RGB-dynamic images into three classes.

2.2 Multi-modal VAD

Some researches of VAD using audio and visual in-

formation were reported. (K.Hoover et al., 2017) in-

troduced a system that associates faces with voices in

a video by fusing information from the audio and vi-

sual signals. They connected speech and face by clus-

tering speech segments and face images detected in

the video, and selecting the face clusters that co-occur

most often with the speech clusters. (B.G.Gebre et al.,

2014a) proposed a speaker diarization method using

speech and human motion (gestures) based on the as-

sumption that people who are speaking are often per-

forming gestures. They created a speaker model from

speech samples corresponding to the gestures.

Visual-only Voice Activity Detection using Human Motion in Conference Video

571

Figure 3: An overview of MMTM.

3 METHODOLOGY

In this paper, we propose a method to fuse features

of two modalities, dynamic images and video data,

in the middle layer in order to make the model focus

on human motion much more. In this section, we at

ﬁrst introduce dynamic images (H.Bilen et al., 2016),

followed by Multi-Modal Transfer Module (MMTM)

(H.R.V.Joze et al., 2020) which fuses features of mul-

tiple modalities. After that, we describe details of our

scheme.

3.1 Dynamic Image

There are several ways to represent the information of

human movement. Optical Flow is a typical method

and is often used to represent motion information.

In other cases, Motion History Image (HMI) is used

in (B.G.Gebre et al., 2014b). Recently, a new rep-

resentation method, dynamic image was proposed in

(H.Bilen et al., 2016).

A dynamic image is an image that combines mo-

tion information of a video composed of multiple

frames into a single image. Figure 2 shows an ex-

ample of dynamic images. In dynamic images, mo-

tion in the video is emphasized, and the information

in the non-moving parts is removed. Furthermore,

dynamic image has the potential to ﬁne-tune existing

CNN models because it converts motion information

into a single image. Experiments in (M.Shahid et al.,

2019a) show that dynamic image performs better on

average than the other methods.

The generation of dynamic images is based on the

concept of rank pooling, which can be obtained via

the parameters of a ranking function that encodes the

temporal evolution of video frames. However, rank

pooling requires optimization of the ranking function.

In this paper, we use dynamic images obtained by

Figure 2: A dynamic image example.

approximate rank pooling, which is a more efﬁcient

method among rank pooling schemes. These algo-

rithms are described in detail in (H.Bilen et al., 2016).

3.2 Multi-modal Transfer Module

(MMTM)

An MMTM (H.R.V.Joze et al., 2020) is a method that,

accepting multiple modalities as input, fuses features

of each modality in the middle layers of a neural net-

work model. Since the MMTM can have various lay-

ers and be implemented with minimal changes in the

network structure, it can be used in many ﬁelds such

as gesture recognition, speech enhancement, action

recognition, and so on.

An overview of MMTM is shown in Figure 3. An

MMTM consists of a squeeze step which summarizes

a feature map in a channel, and an excitation step

which weights each channel. Let us describe A

A and

B in Figure 3 as feature maps extracted from each

modality. The number of channels in A

A and B

B are rep-

resented as C

and C

, respectively. For squeezing,

a pooling method such as Global Average Pooling

(GAP) (M.Lin et al., 2014) can be used. The squeezed

values of A

A and B

B are denoted as S

and S

, respec-

tively. Next, in the excitation step,Then, the squeezed

features are combined and adapt two full connection

layers. Assuming that the fully connected feature map

is Z and the number of dimensions of Z is denoted by

ICPRAM 2022 - 11th International Conference on Pattern Recognition Applications and Methods

572

Figure 4: Details of our proposed model.

. Let the output feature maps for each modality

are represented as E

and E

respectively. Finally,

the sigmoid function(σ) is applied to the output of the

full connection layer to convert the values in each di-

mension from 0 to 1. The value of each dimension

can be regarded as the importance for each channel of

the feature map. Features in the dimension of which

value is close to 1 are retained, and the ones close to 0

are removed. Multiplying the importance by the orig-

inal feature map adjusts the value for each channel of

the feature maps. Assuming adjusted feature maps as

′

and B

′

respectively. Further details can be found

in (H.R.V.Joze et al., 2020). In this way, MMTM can

adjust features extracted from one modality using in-

formation from the other modalities.

3.3 Our Proposed Model

In (M.Shahid et al., 2019b), ﬁne tuning of ResNet50

(K.He et al., 2016) with dynamic images and VVAD

were performed. However, the performance was in-

sufﬁcient for the dataset used in this study, which

will be introduced later: about 65% for data without

masks and about 60% for data with masks. There-

fore, we propose another technique to fuse the video

data stream and dynamic image stream much more

efﬁciently.

Our proposed model is shown in Figure 4. In the

ﬁgure, we denote a convolutional layer as ’Conv’ and

a batch normalization as ’BN’. In each of the video

data and dynamic image streams, a set of three con-

volutional layers followed by a max pooling layer is

repeated four times, resulting 12 convolutional lay-

ers. All convolutional layers have the same kernel size

= (3× 3× 3) and stride=1. In addition, zero padding

is also performed. Features of the whole video are ﬁ-

nally extracted from the video data stream, while from

the dynamic image stream features focusing only on

body movements in the video are extracted. After the

last convolutional layers of the third and fourth layer

sets respectively, feature maps before pooling layers

are given to an MMTM block, and the output weights

are multiplied by the feature map. Note that MMTM

blocks are inserted based on the paper (H.R.V.Joze

et al., 2020). We then perform GAP on the feature

map of the video data stream by adapting MMTM, in

order to use dynamic images as supplemental infor-

mation. Finally, classiﬁcation is performed to iden-

tify speech and non-speech, through full connection.

Figure 5 shows the details of the MMTM block.

4 EXPERIMENTS

In this paper, we performed VVAD using a baseline

3DCNN model and our proposed model. We also vi-

sualize the areas of interest in each model.

4.1 Dataset

4.1.1 AMI Corpus

In this experiment, we used the AMI Corpus

(J.Carletta et al., 2005), a multi-modal conference

dataset. The AMI Corpus is a dataset consisting of

synchronized audio and video data of each partici-

pant. The corpus also has videos of the entire con-

ference room, projection mapping, whiteboard, and

other information. In this paper, we carried out exper-

iments using videos of each participant. Examples of

Visual-only Voice Activity Detection using Human Motion in Conference Video

573

Figure 5: Details of MMTM block (note that here the number of ﬁlters in the feature map is 16).

Figure 6: Examples of AMI Corpus videos.

participant videos are shown in Figure 6. The video

size is 352×288, and the frame rate is 25 fps.

In the AMI Corpus, there are several scenario

meetings which were prepared for the purpose of

dataset creation, as well as natural non-scenario meet-

ings. In the scenario conference, there were many

scenes where each participant stood in front of the

projection mapping, and people were often missing

from the video. In the non-scenario meetings, partic-

ipants were less likely to leave their seats because the

meetings were generally interactive, and we can ob-

serve much more conversations among participants.

Only the non-scenario conferences were used in this

work.

4.1.2 Mask-wearing Data

As mentioned in Section 1, for VVAD, it is needed to

investigate the inﬂuence that attendees in a conference

wear masks. However, as long as we know there is no

dataset in which we can observe mask-wearing peo-

ple. Therefore, we created simulation data in which

a speaker’s mouth was artiﬁcially covered in a mask-

like shape. Dlib (D.E.King, 2009) was ﬁrstly applied

to obtain face landmarks if a speaker’s face was found

in an image. Using the obtained landmarks, we then

generated a white-ﬁlled polygon to hide the mouth

by OpenCV (G.Bradski, 2000). We ﬁnally created a

video of a person wearing a mask by repeatedly ap-

plying this process to all frames in the video.

Figure 7 depicts examples of mask-wearing data.

Figure 7: Examples of mask-wearing data.

Figure 8: A baseline model structure.

4.1.3 Preprocessing

Because in a video a speaker generally looked small

compared to the video size, we adjusted the size of

the person in all the videos to be approximately the

same by cropping the videos. According to speech

activities, we labeled each frame in a video: 0 for

non-speech or 1 for speech. The input data for a

video stream was a set of 25 consecutive frames. We

employed video data only when the same label was

found and face detection was succeeded among 25

consecutive frames. To keep the continuity of the

ICPRAM 2022 - 11th International Conference on Pattern Recognition Applications and Methods

574

Table 1: Data speciﬁcation.

Data # data # attendees

Train 42,880 20

Validation 5,600 4

Test 29,928 17

Table 2: A confusion matrix.

Prediction

non-speech speech

Label

non-speech TP FN

speech FP TN

data, the frame shift length of adjacent data was set

to 20 frames. Regarding dynamic images, one im-

age was created for every 25 frames. Both data were

resized into 160×160, grayscaled, and normalized.

Since there was a large difference in the number of

preprocessed data between the two classes, the data of

the larger class was randomly deleted so that the num-

bers of non-speech and speech data per video would

be the same.

4.2 Experimental Setup

Using the preprocessed data, we trained a baseline

model and our proposed model to test their accuracy.

Details of the baseline model are shown in Figure 8.

The proposed model is shown in Figure 4, and the

squeeze method for MMTM is GAP.

We can see several meeting rooms in the AMI cor-

pus. In this study, we used meeting videos recorded

in two rooms among them. In order to conduct open

experiments, the training and evaluation data were

divided so that their meeting rooms were different.

Similarly, the participants of the meeting were differ-

ent between the training and evaluation data.

Details of the number of data are shownin Table 1.

In addition, to verify the effect of wearing masks, the

same experiment was conducted for videos without a

mask. The optimization method for both the baseline

model and the proposed model was Adam, and the

learning rate was set to 0.001.

4.3 Metrics

4.3.1 Accuracy

We evaluated the baseline and our method by classiﬁ-

cation accuracy:

Accuracy =

TP+ TN

TP+ FP+ TN+ FN

(1)

Figure 9: An overview of the Saliency tubes.

Table 3: VVAD classiﬁcation accuracy (%).

Model w/o mask w/ mask

Baseline 84.78 74.98

Proposed 86.07 75.14

Table 4: A confusion matrix of the baseline with masks.

Prediction

non-speech speech

Label

non-speech 11,576 3,388

speech 3,940 11,024

Table 5: A confusion matrix of our model with masks.

Prediction

non-speech speech

Label

non-speech 10,932 4,032

speech 3,124 11,840

True Positive (TP), False Positive (FP), True Negative

(TN), and False Negative (FN) in Equation 1 are de-

ﬁned in Table 2. We conducted the same experiments

three times, and the average accuracy was computed

as the result.

4.3.2 Visualization

As a visualization method, we used the Saliency tubes

(A.Stergiou et al., 2019) method. Saliency tubes cre-

ates a heat map by multiplying the weights of the out-

put layer by each ﬁlter of the feature map output from

the last convolutional layer. We can ﬁnally visualize

the areas of the input data that contribute to class pre-

diction. An overview of the Saliency tubes is shown

in Figure 9.

4.4 Results

The VVAD results of the baseline model and our pro-

posed model are shown in Table 5. Table 4 and Ta-

ble 5 show confusion matrices of the baseline model

and our proposed model respectively, when they were

trained and evaluated on the mask-wearing data.

Visual-only Voice Activity Detection using Human Motion in Conference Video

575

First, according to Table 5, it is observed that the

accuracy of the data without masks is roughly 10%

higher than that with masks. This means that mouth

information includes crucial cues for identiﬁcation of

voice activity. On the other hand, the accuracy with

masks is still acceptable, indicating the effectiveness

of using human gestures for VVAD. In both cases,

visual-only VAD has enough performance which can

compensate audio VAD degradation. Therefore, as

mentioned already, a multi-modal VAD combining

speech and lip animation seems to be effective.

Next, from the comparison of the baseline and

proposed models, our model achieved slightly higher

performance. We conducted the statistical test, ﬁnd-

ing that there was a signiﬁcant difference between the

baseline and our proposed model in the data with-

out masks (p < 0.01). According to Table 4 and Ta-

ble 5, we can see that in the baseline model some-

times misclassiﬁcation from speech to non-speech oc-

curred, while our proposed model had much more

errors that non-speech segments were recognized as

speech. This result suggests that employing dynamic

images as supplementary information could make the

model more sensitive to motion, and robust against

the existence of masks. We checked the misrecog-

nized data, and found that in those mislabelled seg-

ments human movements were often observed due

to posture changes. VAD is usually performed also

as a preprocessing of speech recognition, errors from

speech to non-speech are crucial; once a segment is

categorized into non-speech, the segment is no longer

used for speech recognition and utterances in the seg-

ment are missing. From this standpoint, our model

seems better than the baseline, thanks to dynamic im-

ages.

We also carried out visualization by Saliency

tubes, to discuss how those models worked to the

mask-wearing data. Figure 10 and Figure 11 illustrate

the visualization results of the baseline model and the

proposed model, respectively. Figure 10 indicates that

the baseline model still focused on the background

information as well as attendee’s movements. In con-

trast, from Figure 11, it is conﬁrmed that our proposed

model correctly focused on attendee’s face, head and

body parts. These results suggest that adopting dy-

namic images has two functions: to reduce the effect

of background information and to increase the impor-

tance of information about speaker’s movements.

5 CONCLUSION

In this paper, we proposed visual-only VAD using hu-

man movements, as a preliminary step to multi-modal

Figure 10: Visualization results of the baseline model.

Figure 11: Visualization results of our proposed model.

VAD using audio and visual information. Assuming

the current pandemic situation, we focused on confer-

ence videos with participants virtually wearing masks

to cover their mouths. In our proposed method, we

employed not only raw video images but also dy-

namic images, so that our VAD model could focus

much more on attendees by providing motion infor-

mation as supplementary information. We chose the

MMTM architecture that efﬁciently fuses two modal-

ities: features from the motion information and orig-

inal images. We conducted evaluation experiments

also using the 3DCNN-based baseline model. As a

result, the accuracy of our proposed model could be

improved compared to the baseline, and our model

could also work in the mask-wearing environments.

According to visualization results, it is also conﬁrmed

that our model could focus much more on humans and

their movements for VAD.

As our future work, it is necessary to perform

multi-modal VAD using audio and video information.

In noisy environments, when a mouth is not visible,

the accuracy is expected to be improved by using

both audio and the entire video. The effectiveness of

multi-modal VAD needs to be conﬁrmed by compar-

ing audio-only VAD. We will also try to improve the

performance of VVAD by combining state-of-the-art

VVAD methods with our proposed approach. In this

paper, we generated and used simulated artiﬁcial data

in which participants wore masks, because there is no

corpus having participants wearing real masks. One

possible future attempt is to train and test our model

with speakers who actually wear masks.

ICPRAM 2022 - 11th International Conference on Pattern Recognition Applications and Methods

576

REFERENCES

A.Aubrey, B.Rivet, Y.Hicks, L.Girin, J.Chambers, and

C.Jutten (2007). Two novel visual voice activity de-

tectors based on appearance models and retinal ﬁlter-

ing. In Proc. 2007 15th European Signal Processing

Conference (EUSIPCO), pages 2409–2413.

A.Stergiou, G.Kapidis, G.Kalliatakis, C.Chrysoulas,

R.Veltkamp, and R.Poppe (2019). Saliency tubes:

Visual explanations for spatio-temporal convolutions.

In Proc. 2019 IEEE International Conference on

Image Processing (ICIP), pages 1830–1834.

B.G.Gebre, P.Wittenburg, S.Drude, M.Huijbregts, and

T.Heskes (2014a). Speaker diarization using gesture

and speech. In Proc. INTERSPEECH 2014, pages

582–586.

B.G.Gebre, P.Wittenburg, T.Heskes, and S.Drude (2014b).

Motion history images for online speaker/signer di-

arization. In Proc. 2014 IEEE International Con-

ference on Acoustics, Speech and Signal Processing

(ICASSP), pages 1537–1541.

B.Joosten, E.Postma, and E.Krahmer (2015). Voice activity

detection based on facial movement. In Journal on

Multimodal User Interfaces volume 9, pages 183–193.

D.E.King (2009). Dlib-ml: A machine learning toolkit.

In Journal of Machine Learning Research (JMLR)

vol.10, page 1755–1758.

G.Bradski (2000). The opencv library. In Dr.Dobb’s Jour-

nal of Software Tools.

H.Bilen, B.Fernando, E.Gavves, and A.Vedaldi (2016). Dy-

namic image networks for action recognition. In 2016

IEEE Conference on Computer Vision and Pattern

Recognition (CVPR), pages 3034–3042.

H.R.V.Joze, A.Shaban, M.L.Iuzzolino, and K.Koishida

(2020). Mmtm: Multimodal transfer module for cnn

fusion. Proc. 2020 IEEE/CVF Conference on Com-

puter Vision and Pattern Recognition (CVPR), pages

13286–13296.

J.Carletta, S.Ashby, S.Bourban, M.Flynn, M.Guillemot,

T.Hain, J.Kadlec, V.Karaiskos, W.Kraaij,

M.Kronenthal, G.Lathoud, M.Lincoln, A.L.Masson,

I.Mccowan, W.Post, D.Reidsma, and P.Wellner

(2005). The ami meeting corpus: A pre-

announcement. In Proc. Machine Learning for

Multimodal Interaction (MLMI), pages 28–39.

K.He, X.Zhang, S.Ren, and J.Sun (2016). Deep residual

learning for image recognition. In Proc. 2016 IEEE

Conference on Computer Vision and Pattern Recogni-

tion (CVPR), pages 770–778.

K.Hoover, S.Chaudhuri, C.Pantofaru, M.Slaney, and

I.Sturdy (2017). Putting a face to the voice: Fusing

audio and visual signals across a video to determine

speakers. In arXiv:1706.00079.

K.Stefanov, J.Beskow, and G.Salvi (2017). Vision-based

active speaker detection in multiparty interactions.

In Proc. Grounding Language Understanding (GLU),

pages 47–51.

M.Cristani, A.Pesarin, A.Vinciarelli, M.Crocco, and

V.Murino (2011). Look at who’s talking: Voice activ-

ity detection by automated gesture analysis. In Proc.

AmI Workshops 2011, pages 72–80.

M.Lin, Q.Chen, and S.Yan (2014). Network in network.

In Proc. International Conference for Learning Rep-

resentations (ICLR).

M.Shahid, C.Beyan, and V.Murino (2019a). Comparisons

of visual activity primitives for voice activity detec-

tion. In Proc. Image Analysis and Processing – ICIAP

2019, pages 48–59.

M.Shahid, C.Beyan, and V.Murino (2019b). Voice activity

detection by upper body motion analysis and unsuper-

vised domain adaptation. In Proc. 2019 IEEE/CVF

International Conference on Computer Vision Work-

shop (ICCVW), pages 1260–1269.

M.Shahid, C.Beyan, and V.Murino (2021). S-vvad: Visual

voice activity detection by motion segmentation. In

Proc. 2021 IEEE Winter Conference on Applications

of Computer Vision (WACV), pages 2331–2340.

N.Latif, A.V.Barbosa, E.Vatiokiotis-Bateson,

M.S.Castelhano, and K.G.Munhall (2014). Move-

ment coordination during conversation. PLOS ONE,

pages 1–10.

Visual-only Voice Activity Detection using Human Motion in Conference Video

577
