A Framework for Generating Playstyles of Game AI with Clustering of

Play Logs

Yu Iwasaki

and Koji Hasebe

Master’s Program in Computer Science, Degree Programs in Systems and Information Engineering,

Graduate School of Science and Technology, University of Tsukuba, Tsukuba, Japan

Faculty of Engineering, Information and Systems, University of Tsukuba, Tsukuba, Japan

Keywords:

Game AI, Playstyle, Clustering.

Abstract:

Many attempts have been made to implement agents for playing games with particular playstyles. Most

of these were aimed at generating agents with predetermined playstyles. To this end, they set the reward

function to increase the reward as the agent acquires their intended playstyles. However, it is not easy to

generate unexpected playstyles through this approach. In this study, we propose a framework to generate

multiple playstyles without predeﬁning them. The proposed framework ﬁrst arranges a set of reward functions

regarding the target game and repeats to select a function and make an agent learn with it. Each learned agent

is made to play the game, and those whose scores are higher than a predetermined threshold are selected.

Finally, each cluster obtained from clustering the play logs (i.e., metrics on the behavior in the game) of the

selected agents is considered a playstyle. As a result, it is possible to generate playstyles that play the game

well using this procedure. We also applied the proposed framework to a roguelike game, MiniDungeons, and

observed that multiple playstyles were generated.

1 INTRODUCTION

With the rapid development of game AI technologies,

agents (computer programs that play games) that sur-

pass human professionals, such as AlphaZero (Silver

et al., 2017), have appeared for perfect information

games. More recently, there have been various studies

to go beyond just playing the game well, such as the

agents to play imperfect information games (Brown

and Sandholm, 2019) and research to imitate human

play by agents (Ortega et al., 2013).

Several attempts have also been made to im-

plement agents for playing games with particular

playstyles (Tychsen and Canossa, 2008; Holmgård

et al., 2014; Holmgård et al., 2016; Holmgård et al.,

2019; Ishii et al., 2018; Tampuu et al., 2017; Fan

et al., 2019). Here, the playstyle means a set of char-

acteristic behavior of a player (Tychsen and Canossa,

2008). For example, in the poker, some styles use

bluffs and prefer stable wins. Most previous studies

aimed at generating agents with speciﬁc and prede-

termined playstyles. To this end, they commonly in-

troduced a reward function (a function for an agent

to learn playing games) in advance to emerge the in-

tended playstyle. However, it is not easy to generate

unexpected playstyles using this approach.

In this study, we propose a framework to gener-

ate multiple playstyles (including unexpected ones)

for playing games well without predeﬁning the aimed

styles and the corresponding reward functions. The

proposed framework ﬁrst arranges a set of reward

functions regarding the target game and repeats to

select a function and make an agent learn with it.

As a result, various agents learned with different re-

ward functions are generated. These learned agents

are made to play the game and selected those whose

scores (evaluated by the predetermined utility func-

tion for the game) are higher than a predetermined

threshold. Finally, the play logs (the metrics record-

ing the behavior in a game) of the selected agents

are clustered, and the resulting clusters are regarded

as the playstyles. Through the above procedure, it is

possible to generate multiple characteristic styles for

playing the game well.

To evaluate the performance of the proposed

framework, we conducted an experiment to generate

playstyles for the roguelike game called MiniDun-

geons (Holmgård et al., 2014). In the experiments,

we use a genetic algorithm called NeuroEvolution

of Augmenting Topologies (NEAT) (Stanley and Mi-

Iwasaki, Y. and Hasebe, K.

A Framework for Generating Playstyles of Game AI with Clustering of Play Logs.

DOI: 10.5220/0010869500003116

In Proceedings of the 14th International Conference on Agents and Artiﬁcial Intelligence (ICAART 2022) - Volume 3, pages 605-612

ISBN: 978-989-758-547-0; ISSN: 2184-433X

605

ikkulainen, 2002) for agent learning. We created 96

functions from the set of reward functions using a grid

search method. The utility function was deﬁned to

give a high score when the agent safely reached the

exit in three evaluation stages. Under the above set-

tings, the experimental results show that 41 agents

trained on 41 reward functions, respectively, could

obtain scores above the threshold. As a result, we ob-

tained four playstyles.

There are various possible applications of the pro-

posed framework. When conducting test play in game

development using agents, it is useful to improve the

game and remove bugs by testing in various styles and

agents with a predetermined one. Additionally, the

proposed framework is useful for analyzing the char-

acteristics of games.

The remainder of the paper is organized as fol-

lows. Section 2 presents related work. Section 3

presents the formal description of our target problem.

Section 4 describes the proposed framework. Section

5 presents the experimental results of the proposed

framework. Finally, Section 6 presents the conclusion

and future studies.

2 RELATED WORK

Tychsen et al. (Tychsen and Canossa, 2008) is one

of the earliest studies on playstyle in games. They

deﬁned the notion of playstyle as a set of character-

istic behavior of a player and analyzed the behavior

of players in the game called Hitman: Blood Money

by measuring various metrics of play logs, such as the

player’s position in the game ﬁeld. Additionally, they

reported that these metrics could range from high to

low abstraction. They claimed that these are useful

for analysis with proper preprocessing.

Holmgård et al. (Holmgård et al., 2014; Holmgård

et al., 2016) presented a model of the evolution of

player’s decision-making and created ﬁve agents with

different playstyles through learning. They generated

agents speciﬁed by linear networks and used an evo-

lutionary strategy to optimize agents. Here, they de-

ﬁned reward functions to emerge the predetermined

playstyles in advance. For example, the reward func-

tion for the playstyle called Monster Killer was de-

ﬁned as the more monsters the agent kills, the bigger

the reward.

Ishii et al. (Ishii et al., 2018) generated agents with

two playstyles, called close-range and long-range at-

tacks, on the ﬁghting game platform FightingICE.

Their idea was to use Monte Carlo tree search and

measure the distance to the opponent and the number

of actions suitable for the aimed playstyle when eval-

uating the agent’s reward.

Tampuu et al. (Tampuu et al., 2017) generated the

playstyles of cooperation and hostility on the hockey

game called Pong of Atari 2600. These playstyles

were implemented by deﬁning two distinct reward

functions based on deep Q-network (Mnih et al.,

2013). The cooperation and hostility playstyles were

generated by taking negative and positive rewards, re-

spectively.

Fan et al. (Fan et al., 2019) developed an agent

to entertain novice players of the game, Go using

heuristics that selects different moves for different

strategies. The heuristics were originally developed

by (Ikeda and Viennot, 2013) based on the Monte

Carlo tree search and applied it to the agent playing

Go called Leela, which was based on AlphaGo Zero.

Here, the strategies taken by the heuristics were de-

veloped by deﬁning different rewards for the results

of game play.

In the above studies, agents with speciﬁc styles

were developed in common by predeﬁning aimed

playstyles and reward functions adjusted to the styles.

As applications of these studies, there are attempts to

automatically validate level design (Holmgård et al.,

2014) and attract human players (Fan et al., 2019).

However, it is not easy to generate playstyles that

are unexpected in advance using the approach in

the previous studies. On the other hand, the pro-

posed method has the advantage of generating multi-

ple playstyles to identify the potential playstyles with-

out deﬁning the playstyles in advance.

There have been many attempts at modeling cog-

nitive, affective, and behavioral responses of players,

predicting human experience and characteristics from

gameplay inputs(Yannakakis et al., 2013). Drachen

et al. (Drachen et al., 2009) collected play logs from

over 1,000 players of the game called Tomb Raider:

Underworld, and classiﬁed them into multiple player

types. In (Drachen et al., 2009), six distinct features

were picked out from the collected play logs and clas-

siﬁed them with clustering and self-organizing maps.

As a result, they clariﬁed that there were four dis-

tinct types of players. This approach must collect a

lot of data from human players for analyzing. In ad-

dition, game designers cannot have collected and an-

alyzed data when they want to change the game me-

chanics through trial and error during game develop-

ment, i.e. before release. Therefore, this study trains

agents with many reward weights, generating agents

with more behavioral patterns, instead of collecting

human players’ data.

ICAART 2022 - 14th International Conference on Agents and Artiﬁcial Intelligence

606

3 PROBLEM DESCRIPTION

In this section, we give a formal deﬁnition of

playstyles and the problem description of playstyle

generation addressed in this paper.

First, we deﬁne games as the complete infor-

mation extensive-form games in game theory (cf.

(Osborne and Rubinstein, 1994; Leyton-Brown and

Shoham, 2008)). An extensive-form game is a model

where one or more players make consecutive deci-

sions according to their policy and each player ob-

tains a reward according to the result. However, for

the sake of simplicity, we only consider games with a

single player where there is no probabilistic choice of

action.

Deﬁnition 1 (Game). A game is a tree deﬁned as a

tuple (A, H, Z, χ, σ, u), where

• A is the set of actions;

• H is the set of non-terminal nodes of game tree;

• Z is the set of terminal nodes of game tree, disjoint

from H;

• χ : H → 2

is the action function, which assigns

to each choice node a set of possible actions;

• σ : H ×A → H ∪Z is the successor function, which

maps a non-terminal node and an action to a new

node;

• u : Z → R is the utility function (where R denotes

the set of real numbers).

An agent conducts consecutive decision-making

on a game, and as a result, acquires some utility on

a terminal node. The utility function u is a function

determining the utility according to the result of game

play. A game is designed so that maximization of the

utility leads to the achievement of the game objective.

For example, in Super Mario Bros., the utility is the

score displayed in the upper right corner of a screen,

and the more objectives a player achieves in the game,

such as “getting to the goal faster” or “getting more

coins,” the higher the utility it gains.

Next, we introduce the reward function. This

function is used by agents to learn the game in our

framework described in the next section. Here, the

reason for providing the reward function separately

from the utility function is that it is difﬁcult to train

the agents directly by the utility function.

Deﬁnition 2 (Reward Function). A reward func-

tion f

: D

× ··· × D

→ R for game play is de-

ﬁned as f

, . . . , d

) =

∑

i=1

× d

, where w de-

notes the vector of weights to parameters and w =

, . . . , w

) ∈ W (= W

× ··· × W

). Also, let D

⊂

R, W

⊂ R.

Here, each parameter d

of a reward function is a

numerical value representing a certain feature of the

agent’s behavior in the game. For example, in the case

of Super Mario Bros., the number of coins acquired

and the number of jumps may be parameter values.

The reward for play is deﬁned as the sum of each pa-

rameter d

multiplied by a predeﬁned weight w

Next, we introduce the model that constitutes an

agent. A model has parameters to infer the correct

labels and optimizes them by learning datasets. That

is, it takes non-terminal nodes as inputs and outputs

the next action to be taken that maximizes the reward

function. Originally, the model outputs values of all

possible actions, but for the sake of simplicity, we as-

sume that it takes an action with the largest value and

omit the detailed descriptions.

Deﬁnition 3 (Model). The model that constitutes an

agent is deﬁned as the function m : H → A.

For example, an instance of the Deep Q-Network

or NEAT correspondents to a model m. The set of

models is denoted by M.

Next, we deﬁne the learned model. This repre-

sents the model learned by a reward function.

Deﬁnition 4 (Learned Model). A model m trained by

a reward function is denoted as the learned model m

∗

H → A. The set of learned models is denoted as M

∗

Here, if g : H ×A → D is a function that returns a vec-

tor of measurements where an agent takes an action

on a non-terminal node, then an action a on a non-

terminal node h satisﬁes a = arg max

∈χ(h)

(g(h, a

)).

For a given reward function f

and a learned

model m

∗

, we use z[ f

, m

∗

] to denote the terminal

node reached by an agent repeating to take actions so

as to maximize its reward determined by f

and m

∗

at each node. Here, note that the utility is deﬁned as

a part of the game, while the reward is a criterion for

the agent to select the optimal action in the learning.

Next, we deﬁne the feasible solution, which is a

pair ( f

, m

∗

) that leads to a utility exceeding a prede-

ﬁned threshold.

Deﬁnition 5 (Feasible Solution). Let θ be a real num-

ber and called a threshold. For a given reward func-

tion f

and a learned model m

∗

, if u(z[ f

, m

∗

]) ≥ θ,

then the tuple of ( f

, m

∗

) is called a feasible solution.

The set of feasible solutions (for a threshold θ) is de-

noted by E.

Thus, a feasible solution can be regarded as an

agent which plays the game well.

Next, we deﬁne the play log. Intuitively, this is a

real vector representation of a record of game play by

an agent.

A Framework for Generating Playstyles of Game AI with Clustering of Play Logs

607

Deﬁnition 6 (Play Log). A real vector recording of

the occurrence of various events in game play by an

agent based on a feasible solution ( f

, m

∗

) is called

a play log. We deﬁne the function pl : F

× M

∗

→ Y

that returns the play log for a given feasible solution,

where Y = Y

× ··· ×Y

for each Y

⊂ R.

Next, we deﬁne the playstyle. Intuitively, the

playstyle is a set of characteristic behaviors of an

agent.

Deﬁnition 7 (Playstyle). For a given set E (= ∪

i=1

)

of feasible solutions, a playstyle on granularity k is a

set E

(for i = 1, . . . , k) if satisﬁes the following con-

ditions.

• Condition 1:

∩ E

0 (∀i, j ≤ k with i 6= j).

• Condition 2:

∑

( f

∗

)∈E

pl( f

, m

∗

)

−

∑

( f

∗

)∈E

pl( f

, m

∗

)k ≥ δ

(∀i, j ≤ k).

• Condition 3:

∀( f

, m

∗

) ∈ E

, ∀( f

, m

∗

) ∈ E

(kpl( f

, m

∗

) − pl( f

, m

∗

)k ≤ δ

) (∀i ≤ k).

Here, δ

∈ R is the threshold on the distances between

playstyles and δ

∈ R is the threshold on the distances

between individuals in the playstyle.

Intuitively, Condition 1 means that each subset E

of the feasible solutions is a partition of set E. Condi-

tion 2 means that the average distance of play logs of

any two subsets E

and E

must be more than or equal

to δ

. Condition 3 means that the distance between

any two play logs generated by feasible solutions in

must be less than or equal to δ

Finally, we describe the problem of playstyle gen-

eration addressed in this study.

Deﬁnition 8 (Playstyle Generation Problem).

Playstyle generation problem is a problem to ﬁnd a

class {E

. . . , E

} of playstyles for a given game G

and a granurality k.

4 FRAMEWORK FOR

PLAYSTYLE GENERATION

4.1 Procedure to Generate Playstyles

The procedure to generate playstyles using this frame-

work is as follows. (See also Figure 1 for the graphi-

cal presentation.)

For a given game G, the framework ﬁrst provides

a set F

of various types of reward functions for the

Figure 1: Procedure of the playsytle generation by the

framework.

agent to learn to play this game. It also determines the

types of behavior of interest for the agent playing the

game generated through this framework, and which

features are recorded as play logs. That is, the func-

tion pl is deﬁned. Furthermore, some parameters and

variables, such as the threshold θ and k for clustering,

are determined.

Next, the proposed framework makes agents learn

with reward functions in F

and selects only those sat-

isfying u(z[ f

, m

∗

]) ≥ θ. Speciﬁcally, a reward func-

tion f

∈ F

is selected and generate a model m by

learning with this function. Then, the learned agent

is made to play the game. Play log whose utility ex-

ceeds the threshold θ is saved; otherwise, the agent

is discarded. By repeating the above procedure, a set

of logs that play the game well is obtained. Here, to

efﬁciently obtain a model that plays the game well, it

is necessary to select a reward function from F

that

is likely to generate such a model.

Finally, the collected play logs are classiﬁed into

k clusters using some clustering technique; each is re-

garded as a playstyle playing game well.

4.2 Selection of Reward Functions

When selecting a function from a set of reward func-

tions, it is necessary to efﬁciently and evenly select

ones that are likely to generate agents that play well.

As such a method, grid search is a brute force search

for combination of input values. Since an advantage

of the grid search is simple and easy to implement,

our experiments adopt this method. Other methods

include particle swarm optimization and Bayesian op-

timization. These methods are convenient for efﬁ-

ciently ﬁnding a plurality of semi-optimal solutions.

ICAART 2022 - 14th International Conference on Agents and Artiﬁcial Intelligence

608

4.3 Generating Learning Models and

Play Logs

Since the play logs identify the playstyle, the elements

of the play log recorded as a vector are the numerical

values of the events considered necessary for identify-

ing the playstyle in the game. However, each reward

function describes how the agent ought to behave in

the game.

In our framework, the model used for agent train-

ing is independent of any speciﬁc method if it out-

puts the action that maximizes the value of a given

reward function for the input state. Examples of such

learning models include genetic algorithms (Srinivas

and Patnaik, 1994) and deep reinforcement learning

(Mnih et al., 2013).

5 EXPERIMENTS

5.1 Setting Game and Model

In this study, we conducted experiments with a rogue-

like game to evaluate the effectiveness of the proposed

framework. We used MiniDungeons (Holmgård et al.,

2014; Holmgård et al., 2016), a model developed by

Holmgård with Java, in this experiment. Here, we

reimplemented this game with Python to run in the

OpenAI Gym environment. We set multiple stages

and parameters and domains of reward functions.

The agent in this game aims to move from the

starting point to the goal without dying. This agent

can repeatedly move one square up, down, left, and

right. Each stage is a two-dimentional grid includ-

ing some special types of cells indicating the starting

point, blocks, treasures, monsters, potions, and exit.

When the agent arrives at each treasure, monster po-

tion, and exit, it receives a predetermined reward. Fur-

thermore, a negative reward is obtained as a penalty

for the passage of time for each movement.

In this experiment, we use NeuroEvolution of

Augmenting Topologies (NEATs) as the learning

model of agents. A reward function is initially set for

each NEAT. Then, the individual, which is identical

to its model, receives a state from the environment.

Then, the agent evaluates the reward of the state or

action by its reward function. Finally, it outputs an

action selected by the network to the environment.

These operations are repeated until the agent reaches

the goal, the physical strength less than or equal to 0,

or the speciﬁed number of turns has passed. After the

play, the total rewards obtained during this play are set

to the ﬁtness of the agent, and the agent’s play log is

Table 1: Parameters of reward functions and weights.

Parameter Weight

Movement (-2, -1, 0)

Reaching the exit (-100, 100)

Acquisition of a tresure (-40, 40)

Acquisition of a potion (-30, 30)

Defeating a monster (-50, 50)

Death (-100, 100)

recorded. Agents optimized for the reward functions

are generated so that individuals with high ﬁtness sur-

vive by natural selection.

The input layer of the individual is set as eight

neurons and receives information from the environ-

ment about the shortest distance to each object and

the remaining health. Here, there are two possible

distances: the distance when approaching the object

safely avoiding monsters, and the distance without

avoiding them. The action corresponding to the out-

put neuron with the maximum value is selected at

each decision point, and the agent moves one square

toward the selected object.

5.2 Setting Framework

The utility function of MiniDungeons was set as “it

returns 1 if the agent reaches the exit without dy-

ing within the time limit at all stages, and 0 other-

wise.” The threshold of the feasible solution was set

as “reaching the exit without dying within the time

limit at all stages (i.e., the value 1).”

Here, the reward functions have six parameters.

Table 1 presents the types of values fed into parame-

ters and weights. We set the reward functions so that

the absolute value of the exit and death were equal,

and the absolute values were in the order of mon-

ster, treasure, and potion. The values of reward func-

tions were searched by grid search and direct prod-

uct of weights on Table 1. Thus, the number of re-

ward functions searched was 3 × 2

= 96. For exam-

ple, if the weights of the reward functions parameters

are (−2, 100, 40, −30, −50, −100), and the measured

values for each event are (20, 1, 2, 0, 3, 0), then the re-

ward is 10, the value of the inner product. The play

log expressed in vector form is used for clustering

when generating playstyles. This play log contains

the number of visits to each cell.

Figure 2 shows examples of the training and eval-

uation stages used in the experiments. Three training

stages were used for training individuals of NEAT.

The individual’s utility with the highest ﬁtness was

examined to exceed the threshold in three evaluation

stages. It was judged that the agent played the game

A Framework for Generating Playstyles of Game AI with Clustering of Play Logs

609

!"# !$#

Figure 2: Examples of training stage (a) and evaluation

stage (b).

Table 2: Parameter settings.

Paramerter Value

Initial Health 30

Health required to defeat a monster 10

Health recovered by a potion 10

Maximum number of movements 200

Number of individuals of population 75

Number of populations 50

well if it reached the exit without dying in all evalua-

tion stages. Separating used stages makes it possible

to select reward functions that more generally satisfy

the rule of the game. These stages were randomly

generated according to a predetermined appearance

ratio of objects.

Table 2 presents the parameters of MiniDungeons

and NEAT. Each population of NEAT consists of 50

individuals and 75 populations were trained. Thus,

360, 000 individuals were trained and 96 candidates

were generated, and only those with utilities exceeded

the threshold were used to create playstyles.

5.3 Results for the Framework

Under the above settings, the experimental results

show that 48 out of 96 individuals optimized on 96

reward functions satisﬁed the condition of the evalu-

ation stages. The 48 feasible solutions were classi-

ﬁed into 11 clusters with x-means (Pelleg and Moore,

2000). Here, the play logs of three evaluation stages

were used as the criterion for classiﬁcation. The x-

means automatically estimates the number of clusters;

however, the number of estimated clusters varies de-

pending on random numbers. Thus, x-means were

repeated 1000 times, and 11, the number of clusters

that appeared most frequently, was adopted.

7 out of 11 clusters were excluded because their

sizes were less than 4, being difﬁcult to analyze

playstyles. Table 3 shows the detail of four clusters

whose sizes are greater than or equal to 5. Each clus-

ter 5, 7, 9, and 10 have a size greater than or equal to

Table 3: Generated clusters.

ID Size Name

5 11 Runner

7 11 Consumer

9 10 Treasure Collector

10 5 Coward

Figure 3: Comparison of behavioral characteristics between

cluster (by measuring play logs).

5 and accounts for 75% of the total.

Cluster 5 (named Runner) was negatively re-

warded by treasures on all reward functions and was

negatively rewarded by either monster, treasure, or

both. Thus, it gave priority to the exit and avoids other

objects as much as possible. Cluster 7 (Consumer)

was positively rewarded with curiosity by treasures,

potions, and monsters on all reward functions. Clus-

ter 9 (Treasure Collector) was positively rewarded by

treasures on all reward functions. Cluster 10 (Cow-

ard) was positively rewarded by potions and treasures;

however, it was negatively rewarded by monsters.

We analyzed the events measured by agents on

three evaluation stages for each cluster to investigate

the characteristics of these clusters. Figure 3 shows

the radar chart of the event logs. The events measured

were the number of monsters killed and the number

of potions and treasures obtained. Figure 3 shows the

plot of the average of the measured logs for all reward

functions in each cluster.

The shape of the cluster 5 (Runner) is smaller than

the other clusters. The reason is that agents disliked

other objects and immediately headed for the exit. It

is considered that agents acquired some potions and

treasures along the way to reach the exit in the short-

est path. Cluster 7 (Consumer) has the largest shape

and is close to an equilateral triangle. Agents of this

cluster killed monsters instead of other clusters and

ICAART 2022 - 14th International Conference on Agents and Artiﬁcial Intelligence

610

Table 4: Variance of logs per cluster for play logs.

Group ID Move Monster Potion Treasure

PlayLog

5 91.7 0.6 45.8 0.3

7 775.3 0 0 0

9 411.4 0.81 30.0 1.6

10 299.3 0.6 0 0.2

RewardWeights

4 8425.4 0 202.6 250

5 20087.2 248.5 467.8 241.3

6 6303.8 0.41 229.8 183.4

9 7557.6 1.3 134.0 260.8

10 3442.1 0 27.2 50.1

acquired potions and treasures at the same rate. In

cluster 9 (Treasure Collector), the percentage of the

number of treasures acquired is large. Only the num-

ber of monsters killed is small in cluster 10 (Coward).

This tendency is also seen in Treasure Collector; how-

ever, there is the difference that agents take more po-

tions to heal and put their safety ﬁrst.

The generated playstyles have different priori-

ties for objects; thus, behaving differently on stages.

Therefore, the reward functions are considered to

change the personality and preferences of agents.

Thus, it is considered that the framework could gener-

ate playstyles without predeﬁning playstyles and re-

ward functions by searching these reward functions

and clustering on only the feasible solutions.

5.4 Comparison with Clustering for

Reward Functions

As an auxiliary evaluation, we also conﬁrmed

whether a similar playstyle could be obtained by clus-

tering the vectors of weights for the parameters of the

reward functions, instead of clustering play logs.

In the experiment, 48 reward functions whose util-

ities exceed the threshold were classiﬁed by the x-

means based on the weights for the parameters. They

were classiﬁed into 11 clusters, ﬁve of which have

sizes greater than or equal 6. This result indicates that

the individuals in the same cluster behaved similarly

due to the similarity of the reward functions. How-

ever, compared to clustering play logs, the individu-

als in the same cluster often behaved differently. As

an illustration of this result, Figure 4 shows the mea-

surement of logs when clustering on reward functions.

Clusters 4, 6, and 9, on average, avoided monsters,

and Clusters 5 and 10, on average, were interested in

all objects. The reason is that individuals with differ-

ent behavior were mixed in the same cluster, averag-

ing behavior. Table 4 summarizes the variance of logs

per cluster for play logs and reward functions. In the

Figure 4: Comparison of behavioral characteristics between

cluster (by measuring reward functions).

cluster generated by values of reward functions, each

individual behaves differently, increasing variances.

These results suggest that when generating playstyles,

it is better to convert reward functions into play logs

by playing games and then classify play logs with

clustering. The reason is that playstyles are identi-

ﬁed based on information of events in games that can

be observed by humans and machines.

6 CONCLUSIONS AND FUTURE

WORK

In this study, we proposed a framework for generating

multiple playstyles for playing games well without

predeﬁning the aimed styles and the corresponding

reward functions. The basic idea was to classify the

play logs of agents who learned the game using dif-

ferent reward functions and who could play the game

well. The proposed framework makes agents train

by reward functions and select those whose scores

exceed the threshold. Then, play logs of the se-

A Framework for Generating Playstyles of Game AI with Clustering of Play Logs

611

lected agents are classiﬁed with clustering, generat-

ing playstyles. We applied our proposed framework

to the roguelike game and demonstrated that multiple

playstyles were generated.

In future studies, we will verify the effectiveness

of the proposed framework by adopting it on more

complex games, such as Super Mario Bros., consist-

ing of many possible actions and states. We are also

interested in using a genetic algorithm called Qual-

ity Diversity (Pugh et al., 2016) in our framework to

make more effective and expressive the playstyle gen-

eration, especially MAP-Elites (Mouret and Clune,

2015).

REFERENCES

Brown, N. and Sandholm, T. (2019). Superhuman ai for

multiplayer poker. Science, 365(6456):885–890.

Drachen, A., Canossa, A., and Yannakakis, G. N. (2009).

Player modeling using self-organization in tomb

raider: Underworld. In 2009 IEEE symposium on

computational intelligence and games, pages 1–8.

IEEE.

Fan, T., Shi, Y., Li, W., and Ikeda, K. (2019). Posi-

tion control and production of various strategies for

deep learning go programs. International Conference

on Technologies and Applications of Artiﬁcial Intelli-

gence, pages 1–6.

Holmgård, C., Green, M. C., Liapis, A., and Togelius, J.

(2019). Automated playtesting with procedural per-

sonas through mcts with evolved heuristics. Transac-

tions on Games, 11:352–362.

Holmgård, C., Liapis, A., Togelius, J., and Yannakakis,

G. N. (2014). Evolving personas for player decision

modeling. In Conference on Computational Intelli-

gence and Games, pages 1–8.

Holmgård, C., Liapis, A., Togelius, J., and Yannakakis,

G. N. (2016). Evolving models of player decision

making: Personas versus clones. Entertainment Com-

puting, 16:95–104.

Ikeda, K. and Viennot, S. (2013). Production of various

strategies and position control for monte-carlo go —

entertaining human players. Conference on Computa-

tional Inteligence in Games, pages 1–8.

Ishii, R., Ito, S., Ishihara, M., Harada, T., and Thawonmas,

R. (2018). Monte-carlo tree search implementation of

ﬁghting game ais having personas. In Conference on

Computational Intelligence and Games, pages 1–8.

Leyton-Brown, K. and Shoham, Y. (2008). Essentials of

Game Theory: A Concise Multidisciplinary Introduc-

tion. Morgan and Claypool Publishers.

Mnih, V., Kavukcuoglu, K., Silver, D., Graves, A.,

Antonoglou, I., Wierstra, D., and Riedmiller, M.

(2013). Playing atari with deep reinforcement learn-

ing. arXiv:1312.5602.

Mouret, J.-B. and Clune, J. (2015). Illuminating search

spaces by mapping elites. arXiv:1504.04909.

Ortega, J., Shaker, N., Togelius, J., and Yannakakis, G. N.

(2013). Imitating human playing styles in super mario

bros. Entertainment Computing, 4:93–104.

Osborne, M. J. and Rubinstein, A. (1994). A course in game

theory. MIT press.

Pelleg, D. and Moore, A. W. (2000). X-means: Extend-

ing k-means with efﬁcient estimation of the number

of clusters. In Proceedings of the International Con-

ference on Machine Learning, pages 727–734.

Pugh, J. K., Soros, L. B., and Stanley, K. O. (2016). Qual-

ity diversity: A new frontier for evolutionary compu-

tation. Frontiers in Robotics and AI, 3.

Silver, D., Hubert, T., Schrittwieser, J., Antonoglou, I., Lai,

M., Guez, A., Lanctot, M., Sifre, L., Kumaran, D.,

Graepel, T., et al. (2017). Mastering chess and shogi

by self-play with a general reinforcement learning al-

gorithm. arXiv:1712.01815.

Srinivas, M. and Patnaik, L. M. (1994). Genetic algorithms:

A survey. Computer, 27(6):17–26.

Stanley, K. O. and Miikkulainen, R. (2002). Evolving neu-

ral networks through augmenting topologies. Evolu-

tionary Computation, 10:99–127.

Tampuu, A., Matiisen, T., Kodelja, D., Kuzovkin, I., Korjus,

K., Aru, J., Aru, J., and Vicente, R. (2017). Multiagent

cooperation and competition with deep reinforcement

learning. PLoS ONE, 12:1–15.

Tychsen, A. and Canossa, A. (2008). Deﬁning personas in

games using metrics. In Conference on future play,

pages 73–80.

Yannakakis, G. N., Spronck, P., Loiacono, D., and André,

E. (2013). Player modeling. In Artiﬁcial and Compu-

tational Intelligence in Games. Dagstuhl Publishing.

ICAART 2022 - 14th International Conference on Agents and Artiﬁcial Intelligence

612
