SMPG: Secure Multi Party Computation on Graph Databases

Nouf Aljuaid

1,2

, Alexei Lisitsa

and Sven Schewe

Department of Information Technology, Taif University, Saudi Arabia

Department of Computer Science, University of Liverpool, Liverpool, U.K.

{n.aljuaid, lisitsa, sven.schewe} @liverpool.ac.uk

Keywords:

Graph Databases, Secure Multi-party Computations, Multi-party Querying, Federated Databases, Secure Data

Processing.

Abstract:

In this position paper, we outline how secure multi-party querying can be brought to graph databases. Such a

system will allow multiple users to jointly query federated graph databases that consist of several private parts.

We have provided a proof of concept. Our prototype implementation for the SMPG system builds on top of

Conclave (Volgushev et al., 2019), which was originally proposed and implemented for multi-party computa-

tion and querying on relational databases. We describe the templates of queries that are currently supported by

our prototype and discuss current limitations as well as the extensions planned to tap the conceptual beneﬁts.

1 INTRODUCTION

As the relevance of data security does not need much

discussion, it is only natural that many techniques

have been proposed and developed to increase the

security of data, see (Mostafa, 2016) for a survey.

Multi-party computation (MPC) is a particularly in-

triguing example among them; (Cramer et al., 2015)

describe it as cryptographic technique that enables a

group of people to join together to perform compu-

tation without revealing any private data. It differs

from standard cryptographic techniques in that it does

not focus on the encryption of data or databases, but

rather develops protocols that coordinate the analy-

sis of distributed data without joining the data itself.

The liberation from the need to share data provides

a major beneﬁt that is rather unique to MPC: the

opportunity to cooperate and coordinate operations,

where collaboration was impeded by a lack of trust

(Hemenway et al., 2014). Applications where MPC

can solve such trust issues include secure elections

(Alwen et al., 2015), auctions (Aly and Van Vyve,

2016), and secret sharing (Evans et al., 2018). An-

other application of MPC is to secure the query on

different types of databases. MPC techniques are cur-

rently supported by Conclave (Volgushev et al., 2019)

and GOOSE (Ciucanu and Lafourcade, 2020).

Thus far, MPC mainly has been used in to se-

cure relational databases. For example, Conclave uses

MPC for securing the queries on a federated database

that consists of private individual databases held by

multiple parties, where it executes a single query.

This raises the question of whether MPC queries are

restricted to relational databases, or can transcend the

database type. We look in particular at the scope

to apply MPC in graph databases, a type of NoSQL

database. Graph databases have been created to ad-

dress the limitations of relational databases (Salehnia,

2017), and found multiple application that particu-

larly beneﬁt from the graph paradigm, such as In-

stagram, Twitter, and Facebook (Ciucanu and Lafour-

cade, 2020). These applications beneﬁt from explic-

itly deﬁned connections that are the thumbmark of

graph databases, as opposed to relational databases,

where the data is linked implicitly. This guaran-

tees scalability for graph databases where relational

databases face scalability and complexity barriers,

which makes it cheaper to maintain servers for graph

databases (Salehnia, 2017).

While MPC is a useful technique for executing se-

cure queries, its use in graph databases is still in its

infancies. In (Ciucanu and Lafourcade, 2020), the

use of MPC as the backend for supporting queries

on a graph database has been studied. The authors

of (Ciucanu and Lafourcade, 2020) suggest distribut-

ing a single database over several components that are

then handled with the help of MPC, but they did not

address multi-party queries at the user level. In this

paper, we propose the design of a system that com-

bines the advantages of the MPC technique with those

Aljuaid, N., Lisitsa, A. and Schewe, S.

SMPG: Secure Multi Party Computation on Graph Databases.

DOI: 10.5220/0010876200003120

In Proceedings of the 8th International Conference on Information Systems Security and Privacy (ICISSP 2022), pages 463-471

ISBN: 978-989-758-553-1; ISSN: 2184-4356

463

offered by graph databases for securing multi-party

querying over a graph database.

The remainder of this paper is organised as fol-

lows. The following section presents the proposed

system for secure multi party computation on graph

databases (SMPG). Before presenting the implemen-

tation of the prototype in Section 4, we discuss the

functionality of the existing Conclave system (Volgu-

shev et al., 2019) we use in our prototype implemen-

tation in Section 3. A literature review of existing

implementations of MPC and the related work on se-

curing the query on a different type of data model is

provided in Section 5. We then close with drawing

conclusions and discussing future work in the ﬁnal

section.

2 SMPG ARCHITECTURE

This section provides an overview of the proposed

SMPG scheme, introducing its entities and outlining

how it works.

2.1 SMPG Entities

The architecture of our SMPG system is illustrated in

Figure 1. The system contains three entities, and these

entities have different trust levels in the use cases we

are interested in.

• Data Owners make their graph database available

for SMPG to perform a joint multi-party once the

query is agreed and may allow a single user to

perform a query using their data. Full trust by

the other data owners is required as they need to

jointly conduct the query.

• A user may submit a query using the data from

Data Owners to get results for a query without

sharing any data with the system. She does not

gain access to data beyond the answer to the query

and can be considered un-trusted.

• A Proxy Server is responsible for authenticating

the user to access the system. Proxy Servers are

(only) trusted to this end (semi-trusted).

2.2 Two Use Cases for SMPG Systems

The entities are described for the use case of a sin-

gle user and multiple data owners. In this situation,

a single user who does not contribute a database that

partakes in the query wants to compute something that

uses the databases from the data owners. In this case,

the user needs to be authenticated to access the system

and submit her query. After she gets the permission,

Figure 1: SMPG workﬂow.

she can submit her query to the SMPG, who then ex-

ecutes a joint query.

In the joint query, the data owners, named

, p

, . . . , p

, who own different graph databases, ex-

ecute a single query jointly. In more detail, after all

parties agree on a joint query, they submit it to the

system. Inside the system, the ﬁrst step is to re-write

the query to make it amenable to the execution on the

MPC backend. In this stage, the system takes all un-

necessary operations to run outside the MPC backend.

In our proof-of-concept, we use Conclave (Volgushev

et al., 2019) as our backend, which in turn uses Jiff

(Albab et al., 2019) for MPC queries. Conceptually,

they can be exchanged by other solutions (which then,

naturally, need adjusted translations). After receiving

the result of the query, the system will send it to the

single user who initiated the query. In an alternative

scenario, the multiple data owners initiate the joint

query themselves. The translation of the query is then

similar, but there is no need to return the result to an

external user.

2.3 DB Query Language

While the SMPG scheme can be implemented for any

type of graph-based DBs, we have selected the Neo4j

environment as our starting point. Neo4j is a popular

graph database (L

opez and De La Cruz, 2015), whose

graph data model can be represented by a set of nodes,

which represent data, and arrows that represent the

relationship between them (Miller, 2013).

In order to deal with the data in such a graph,

Neo4j uses a query language called Cypher. In

our SMPG system, we intend to use a fragment of

the Cypher query language, extended with feder-

ated query facilities/functionality (Neo4j Fabric) with

MPC protocols. The operational principle of Neo4j

fabric offers a way to issue Cypher queries that target

more than one Neo4j graph database at once.

2.4 Workﬂow Overview

We ﬁrst assume that we have a single user, who does

not contribute an own database that partakes in the

ICISSP 2022 - 8th International Conference on Information Systems Security and Privacy

464

query and wants to query the federated database from

the data owner. Our system will process such a query

in eight stages. Figure 2 shows The workﬂow of the

SMPG system when used by an outside user (not a

data owner).

1. Submit Cypher Query: after the user is authen-

ticated by the system, she can submit her query to

the coordinator of the SMPG system through the

SMPG Coordinator.

2. Query Translation: the Coordinator translates

the query into individual queries to the partak-

ing data owners (participating parties) and sub-

mits these queries to them.

3. Process Query: each participating party pro-

cesses the query it receives. This includes creating

a conﬁguration JSON ﬁle.

4. Query Execution: each participating party then

invokes the MPC Conclave system

to execute the

workﬂow speciﬁed in the conﬁguration JSON ﬁle

on its Neo4j DB.

5. Computation using MPC: in this stage, the in-

formation will be passed to a Jiff server, who pro-

vides answers to the individual queries using an

MPC protocol.

6. Send the Result to Parties: in this stage, the JIFF

server will send back the result for the parties in-

volved in the query.

7. Send the Result to Coordinator: the overall re-

sult of the original query will then be sent to the

coordinator, in our implementation as a CSV ﬁle.

8. Final Result: the SMPG coordinator ﬁnally as-

sembles the result and returns it to the user.

Figure 2: The workﬂow of the SMPG system when used by

an outside user (not a data owner).

In the alternative scenario, where the query is ini-

tiated by the data owners, the last two steps can be

omitted, as the partaking data owners are already in

or any alternative backend to process MPC queries

possession of the result. This leads to a situation

where, while the query is assembled by an SMPG Co-

ordinator, this coordinator never receives an answer to

the query (cf. Figure 3).

Figure 3: The workﬂow of the SMPG system with a joint

query by the involved data owners.

3 CONCLAVE FUNCTIONALITY

In this section, we describe the functionality of the

Conclave system (Volgushev et al., 2019), which uses

MPC with a relational database; we use it as a ba-

sis to demonstrate that the concept extends to support

Neo4j, including a fragment of the Cypher query lan-

guage.

The Conclave system supports table schema deﬁ-

nitions, relational operators (join, aggregate, project,

and ﬁlter) as well as enumeration, arithmetic on

columns and scalars. Inside the system, after the

originally submitted query has been re-written, each

query is represented as a node within a directed

acyclic graph (DAG). As such, each operation on a

data set should be stored in a variable as follows:

<node> = cc.<query>(<arg1>,<arg2>,..., <argn>)

For the aggregate operators, Conclave supports

count operation, sum, and mean. Inside the system,

the query is written using Language Integrated Query

(LINQ) (Bai, 2010). This is a data querying API

that provides general-purpose query capabilities to

the .NET programming languages with a syntax sim-

ilar to SQL. The syntax of the aggregate query using

LINQ will be:

aggregate(input_node, output_name,

group_column_names,aggregated_column_name,

aggregator, output_column_name)

The project operator is used to select a list of

columns from a data set. A query using the project

operator could be:

project(input_node, output_name,

selected_column_names)

SMPG: Secure Multi Party Computation on Graph Databases

465

The Join operator is a function that joins two data

sets over a list of columns. A query using join could

look like this:

join(left_node, right_node, output_name,

left_column_names, right_column_names)

A ﬁlter is a function to ﬁlter data in a column with

a speciﬁed value. A query using ﬁlter will be like:

filter_by(input_node, output_name,

filter_col_name, by_op)

4 PROTOTYPE

IMPLEMENTATION

In this section, we describe the implementation of a

prototype of a fragment of the above SMPG design,

using a Python API. The main objective of this pro-

totype is to prove the effectiveness of a query over

a graph database using MPC. Our prototype can use

multiple graph databases from multiple data owners

and applies MPC to provide a joint query.

Initially, different Neo4j databases are built. Then,

for each party, the user has to edit the conﬁg ﬁle man-

ually to connect to Neo4j. In future implementations,

editing the conﬁg ﬁle will be automatic, relieving the

user from the need to edit it manually. Currently, the

prototype supports a small fragment of the Cypher

query language. In this fragment, we use the UNWIND,

CALL, and USE clauses of Cypher to handle querying

multiple graph databases. UNWIND supports iteration

of queries over a list of databases. CALL is used to

execute a Cypher subquery by each party involved in

the joint query. To handle a particular graph database,

we utilise the ”USE” clause. Only queries that are

instances of the query templates Q1-Q4 discussed be-

low are fully supported, while Q5 is conceptually sup-

ported, but needs an adjustment of the backend used

(or a workaround, like the mapping of character se-

quences into the integers, which is possible in princi-

ple).

4.1 Query Templates

In the SMPG system, the user submits the query us-

ing Cypher query language and this query is used to

derive sub-queries depending on the number of par-

ties that want to ﬁnd the result of this query.The sub-

queries are then run separately for each party. As a

ﬁrst prototype of our system, we built it on top of the

Conclave system. The cypher query from the input is

translated into the LINQ language. In the following

example queries, we explain the path of executing the

query with the implemented prototype.

• Q1: Aggregation Count

In this query, the count for node 1 may depend on

node 2. The corresponding Cypher query template is:

UNWIND example.graphIds() AS graphId

CALL {

USE example.graph(graphId)

MATCH (node1: label1)-[:Relationship]

->(node2:label2)

WITH node2, count(node1) as cnt

RETURN node2, cnt

}

RETURN node2, cnt

Running the query will ﬁrst collect the graph IDs

for all remote graphs, then using UNWIND to get one

record per graph ID. The CALL sub-query will be ex-

ecuted separately for each party. As example to use

this query, suppose that we have three parties, each

equipped with a Neo4j database with the same prop-

erties. We want to execute the following query:

UNWIND example.graphIds() AS graphId

CALL {

USE example.graph(graphId)

MATCH (c:CAR) -[rel:IN]-> (L:LOCATION)

WITH L, count(c) AS cnt

RETURN L.id AS location_id, cnt

}

RETURN location_id, cnt

The return from this query will provide the number

(or: count) of cars for each location for all parties in-

volved in the query. The sub-query inside the CALL

will be executed separately for each party in the list

example iterated over by UNWIND function. The re-

sult of this sub-query will be the number of cars for

the party. The results from the individual parties are

then combined and mapped to the aggregation count

function, which sums up the individual results with-

out exposing the private data of the individual parties.

This sub-query is translated to LINQ as:

agged = aggregate_count(combined,"heatmap",

["location"],"by_location")

In this example query, this will return the overall num-

ber of cars grouped by location.

• Q2: Aggregation Sum

This query will return the sum for any node in the

query. The cypher query is like be:

UNWIND example.graphIds() AS graphId

CALL {

USE example.graph(graphId)

MATCH (node1: label1)-[:Relationship]

->(node2:label2)

RETURN sum(node2) as Sum

}

RETURN Sum

ICISSP 2022 - 8th International Conference on Information Systems Security and Privacy

466

As an example for this query, suppose that we

have two parties that both hold information about

scores of students from different courses. We want

to ﬁnd the sum of these scores for a given student on

both courses. To do that, we can execute this query:

UNWIND example.graphIds() AS graphId

CALL {

USE example.graph(graphId)

MATCH (s:student) -[rel:get]-> (C:course)

RETURN sum(C.score) AS Score

}

RETURN Score

In SMPG, this query will ﬁrst gather the graph IDs

for all parties involved in the query, and execute the

sub-query separately for each party. Then, the indi-

vidual results of these sub-queries are combined, and

their aggregation, as a sum for all individual results,

is calculated without exposing the private data of the

partaking parties. This aggregation is translated to

LINQ as:

agged = aggregate(combined,"agged",

["student_id"],"score","sum","score")

• Q3: Project Data

This query will match and return particular data from

node1 or node2. A cypher query would look like this:

UNWIND example.graphIds() AS graphId

CALL{

USE example.graph(graphId)

MATCH (node1: label1)-[:Relationship]

->(node2:label2)

RETURN node2

}

RETURN node 2

As an example, suppose that we have two parties,

and each one of them has a Neo4j database with the

same properties. We want to ﬁnd the scores for all

students in both databases in some particular course,

without exposing any information about the individ-

ual students. To this end, we can execute this query:

UNWIND example.graphIds() AS graphId

CALL{

USE example.graph(graphId)

MATCH (s:student) -[rel:get]-> (C:course)

With s.id

RETURN c.score AS score

}

RETURN score

This query will return the score for all students for

each database separately. After that, the results from

each user are combined, and the projection returns the

complete row of scores from the combined data, with-

out return anything else. To execute this query, it is

translated to the LINQ language as:

agged = project(combined,"heatmap",

["scores"],"by_scores")

• Q4: Union Two Databases

We consider as an example that we want to ﬁnd the list

of names of professors, whose students have a grade

≥ 9.0 in either database. Such a query could look like

this:

CALL{

USE Graph 1

MATCH (P:Professor)-[:guide]->(S:Student)

WHERE S.grade >= 9.0

RETURN P.name as prof_name, S.name as student

}

CALL{

USE Graph 2

MATCH (P:Professor)-[:guide]->(S:Student)

WHERE S.grade >= 9.0

RETURN P.name as prof_name, S.name as student

}

RETURN prof_name, student

To execute this query using our system, a query

will be translated to a LINQ query as follows:

agged = join(in_one,in_two,"heatmap",

"P.name","s_name","P.name","s_name")

This query will generate a CSV ﬁle, which in-

cludes the information that results from the cypher

query.

• Q5: Match Intersection

This query will calculate the intersection between two

(or more) nodes, here node 1 and node 2. The cypher

query could look like this:

UNWIND example.graphIds() AS graphId

CALL {

USE example.graph(graphId)

MATCH (node1: label1)-[:Relationship]

->(node2:label2)

RETURN node2

}

RETURN node 2

Assume that we have two different Neo4j

databases that each contain a list of people and the

names of their friends. We want to determine whether

or not there are common friends between them. To do

this, we can run the following query:

UNWIND example.graphIds() AS graphId

CALL {

MATCH (n:Person) -[:Friend]-> (m:Person)

RETURN m.name As Name

}

RETURN Name

After running this query for each party involved,

combining the results to determine whether or not

there is a common friend between them will be ob-

tained through an MPC protocol. Due to the limi-

tation of the Conclave system to numerical data—not

SMPG: Secure Multi Party Computation on Graph Databases

467

supporting strings—we will try to extend their system

to overcome this shortfall in future.

• Q6: Correlated Subquery

Assume that we have two different Neo4j databases

(Graph A and Graph B) and we want to query infor-

mation from Graph B depending on particular data

from Graph A, using the following query:

CALL {

USE graphA

MATCH (node1:label1)

RETURN max(label1.property) AS MaxValue

}

CALL {

USE graphB

WITH MaxValue

MATCH (node1:label1)

WHERE label1.property = MaxValue

RETURN node 1

}

RETURN node1

As an example for this type of query, assume that

Graph A contains American movies and Graph B con-

tains European movies. We want to ﬁnd all European

movies released in the same year as the latest released

American movie. To ﬁnd this, we can execute the fol-

lowing query:

CALL {

USE graphA

MATCH (movie:Movie)

RETURN max(movie.released) AS usLatest

}

CALL {

USE graphB

WITH usLatest

MATCH (movie:Movie)

WHERE movie.released = usLatest

RETURN movie

}

RETURN movie

This query would ﬁrst be translated into two sub-

queries, the ﬁrst one using Graph A.

USE graphA

MATCH (movie:Movie)

RETURN max(movie.released) AS usLatest

This query will ﬁnd all movies that were released

in the same year as the latest movie release in the US.

A query would look like this:

USE graphB

WITH usLatest

MATCH (movie:Movie)

WHERE movie.released = usLatest

RETURN movie

This type of query cannot be supported by Con-

clave due to its limitations. In future, we plan to ex-

tend our work to support such queries and, more gen-

erally, federated privacy-preserving queries using a

combination of Neo4j Fabric with a tailor-made MPC

backend.

4.2 Experimental Results

We have run the queries from this section using our

implemented prototype SMPG, using three different

Neo4j databases from three parties. The total amount

of nodes for all the databases is 26 nodes with 13 rela-

tionships between nodes. In more detail, database one

from the ﬁrst party involved in the query has 12 nodes

with 6 relationships, whereas the second database has

8 nodes with 4 relationships. The third database con-

tains 6 nodes with 3 relationships. We have measured

the execution time where all the parties get the results

of the query using the time function. This function is

supported by Python, which returns the query in 66 to

76 seconds for Q1 through Q4.

While this seems much, it is based on translations

to relational databases and to Conclave, which does

not tap the advantages of graph databases that the

concept will—once underpinned with an independent

MPC implementation—provide.

It is, however, quite easy to cut the time needed

even in the current setting. For example, cutting the

sorting that is included by default in Conclave im-

proves the running time by an order of magnitude,

keeping all running times below 8 seconds.

5 RELATED WORK

5.1 Implementations of MPC

While MPC was mostly the object of theoretical re-

search unitl recently, there has lately been a consid-

erable effor to bring MPC to real-life applications

(Evans et al., 2018). MPC implementations are, for

example, used in Jiff (Albab et al., 2019), ObliVM

(Liu et al., 2015), and GraphSC (Nayak et al., 2015).

Jiff (Albab et al., 2019) is a JavaScript library

that implements MPC. It can perform secure compu-

tation on data distributed between several parties. Jiff

utilises a server to store and route encrypted messages

that are sent between the different participating par-

ties. It assumes the honest-but-curious security model

and uses threshold Shamir’s Secret Sharing (Shamir,

1979). It is compatible with various browsers and can

run as a Node.js application. When Jiff is run as a

server, then each parity runs as a client, and after com-

pletion of the computation, the result will show for

all of the parties without exposing their data that has

ﬂown into the computation of the result.

ICISSP 2022 - 8th International Conference on Information Systems Security and Privacy

468

Table 1: MPC for data processing.

Framework

Parties

supported

MPC

Framework

backend

Trust

Party

No.Data

owners

Data Model

Query

language/API

Available

implementation

Development

language

Conclave (Volgushev et al., 2019) >= 2 Secret Sharing Jiff Yes >= 2 Relational DB SQL/LINQ Yes Python

Congregation >= 2 Secret Sharing Jiff No >= 2 Relational DB SQL Yes Python

SMCQL (Bater et al., 2016) 2 Garbled Circuits/ ORAM ObliVM No 2 Relational DB SQL Yes Java

Senate (Poddar et al., 2020) 2 Garbled Circuits N/A No 2 Relational DB SQL No -

SAQE (Bater et al., 2020) 2 Garbled Circuits ObliVM No 2 Relational DB SQL No -

Shrinkwarp (Bater et al., 2018) 2 Garbled Circuits/ ORAM ObliVM No 2 Relational DB SQL No -

Secrecy (Liagouris et al., 2021) 3 Repl.Secret Sharing - No 3 Relational DB SQL No C

SDB (Wong et al., 2014)

N/A Secret Sharing N/A No 1 Relational DB SQL No -

GOOSE (Ciucanu and Lafourcade, 2020)

N/A Secret Sharing N/A No 1 GraphDB SPARQL Yes Python

SMPG >= 2 Secret Sharing Jiff No >= 2 GraphDB Cypher Python

*Both

and

are using MPC as backend over a database; they do not support multi-party user queries

ObliVM (Liu et al., 2015) is a programming

framework for secure computation. It compiles a

Java-like language called ObliVM-lang and executes

a two-party garbled circuit (Evans et al., 2018). The

authors of (Liu et al., 2015) show that it is possible to

easily and accurately perform complicated arithmetic

operations.

The authors of (Nayak et al., 2015) suggest a se-

cure computation framework that supports parallel se-

cure computation. For MPC, they used the ObliVM

(Liu et al., 2015) protocol. To evaluate their design’s

performance, the authors of (Nayak et al., 2015) use

four classic data analysis algorithms: a histogram,

page-rank, and two versions of matrix factorisation.

5.2 MPC for Data Processing

There are attempts to use MPC with databases for data

protection. For example, (Volgushev et al., 2019) pro-

poses Conclave, a query compiler applied to a rela-

tional database. It works by transforming the queries

into a combination of data-parallel, local cleartext

processing, in conjunction with small MPC steps. In

this system, the queries are rewritten to minimise ex-

pensive processing under MPC in order to improve

scalability. They suggested to pass the rewritten query

to Jiff (Albab et al., 2019), which is used as a back-

end MPC system. Furthermore, (Poddar et al., 2020)

present the Senate system that allows multiple par-

ties to run analytical SQL queries together, without

exposing their private data to each other. The ad-

ditional advantage of their system over prior work

is that it provides security against malicious parties,

while older systems adopted a semi-honest model.

Moreover, (Liagouris et al., 2021) present a relational

MPC framework based on replicated secret sharing

called Secrecy. The central idea of this system is to

split data into three shares, s1, s2, and s3, where each

party will take two of the shares and perform a part of

the code to execute the query.

The authors of (Bater et al., 2016) suggest a sys-

tem called SMCQL that translates SQL queries into

secure multi-party computation. The user submits her

query to an honest broker, who is considered a trusted

third party. An honest broker is responsible for trans-

lating the query to a secure cluster and returning the

result to the user. A further study of the SMCQL sys-

tem (Bater et al., 2020) adopts SMCQL and builds a

system called SAQE to protect the SQL query on top

of it. The query in this system is processed in two

parts: a query planning and a query execution part.

The client side performs the query plan and optimi-

sation, while the execution of the query happens on

the server-side amongst the data owners, using MPC.

They jointly execute queries over their databases and

return the result to the client. Likewise, Bater et al.

build on top of SMCQL (Bater et al., 2018). They

use two-party secure computations, which means that

they run their experiments with two data owners.

While they report an improved performance of SM-

CQL, this comes at the cost of leaking some informa-

tion during the process.

On the systems suggested in (He et al., 2015) and

(Ciucanu and Lafourcade, 2020), the authors examine

using MPC for the implementation of querying by a

single party. The SDB system in (He et al., 2015) is a

cloud database system on relational tables. It contains

two parties: Data owner (DO) and Server provider

(SP). Each sensitive data item is split into two shares,

one kept at the DO, referred to as the item key, and an-

other at the SP, which is regarded as ciphertext. This

system uses MPC and secret sharing between the DO

and the SP. After accepting an SQL query from the

user, the SDB proxy in the DO part rewrites the query

that involves sensitive columns to their corresponding

UDFs at SP. It then submits rewritten queries to the SP

and sends the encrypted result back to the SDB proxy

to decrypt before sending it to the user. Likewise,

the GOOSE framework in (Ciucanu and Lafourcade,

2020) is a system to secure the outsourcing of data

in the RDF graph database using MPC secret sharing.

Here, the graph data is submitted by the data owner to

the cloud in a speciﬁc form: it is chopped into three

different parts, and uploaded in an encrypted form to

SMPG: Secure Multi Party Computation on Graph Databases

469

various places in the cloud. All these parts are consid-

ered multi-party, and each one cannot know the whole

graph, or a query, or its result. Moreover, all messages

between them are encrypted using the AES algorithm.

GOOSE has proven to scale via a large-scale experi-

mental study using a standard query evaluation.

While this previous work has addressed the use

of MPC in relational databases and graph databases,

multi-party queries over graph databases are novel.

Table 1 shows a comparison between all the previous

systems and our suggested system, SMPG.

6 CONCLUSIONS

In this position paper, we have proposed SMPG, a

system to secure multi-party computation on graph

databases. The concept of SMPG is to use MPC pro-

tocols to execute queries over graph databases. We

have implemented a prototype over the Conclave sys-

tem to demonstrate the effectiveness of a query over a

graph database using MPC. In future work, we will

extend this concept to allow for a broader applica-

tion. These extensions will include 1) an enhance-

ment of the backend system to support operations

over string data (where the Conclave system we have

used in the proof-of-concept is restricted to numerical

data); 2) an extension of the supported fragment of

Cypher query language; and 3) the development of a

more general system for privacy-preserving federated

queries that combine federated query facilities with

specialised MPC backends.

REFERENCES

Albab, K. D., Issa, R., Lapets, A., Flockhart, P., Qin, L.,

and Globus-Harris, I. (2019). Tutorial: Deploying se-

cure multi-party computation on the web using JIFF.

In 2019 IEEE Cybersecurity Development (SecDev),

pages 3–3. IEEE.

Alwen, J., Ostrovsky, R., Zhou, H., and Zikas, V. (2015).

Incoercible multi-party computation and universally

composable receipt-free voting. In Advances in

Cryptology–CRYPTO 2015: 35th Annual Cryptology

Conference,, volume 9216, pages 763–780. Springer

Berlin Heidelberg.

Aly, A. and Van Vyve, M. (2016). Practically efﬁcient

secure single-commodity multi-market auctions. In

International Conference on Financial Cryptography

and Data Security, pages 110–129. Springer.

Bai, Y. (2010). Introduction to Language-Integrated Query

(LINQ), pages 147–233. Wiley-IEEE Press.

Bater, J., Elliott, G., Eggen, C., Goel, S., Kho, A., and

Rogers, J. (2016). SMCQL: secure querying for fed-

erated databases. arXiv preprint arXiv:1606.06808.

Bater, J., He, X., Ehrich, W., Machanavajjhala, A., and

Rogers, J. (2018). Shrinkwrap: efﬁcient sql query pro-

cessing in differentially private data federations. Pro-

ceedings of the VLDB Endowment, 12(3):307–320.

Bater, J., Park, Y., He, X., Wang, X., and Rogers, J.

(2020). SAQE: practical privacy-preserving approx-

imate query processing for data federations. Proceed-

ings of the VLDB Endowment, 13(12):2691–2705.

Ciucanu, R. and Lafourcade, P. (2020). GOOSE: A se-

cure framework for graph outsourcing and sparql eval-

uation. In 34th Annual IFIP WG 11.3 Conference

on Data and Applications Security and Privacy (DB-

Sec’20). Accept

a para

ıtre.

Cramer, R., Damg

ard, I. B., and Nielsen, J. B. (2015). Se-

cure multiparty computation. Cambridge University

Press.

Evans, D., Kolesnikov, V., and Rosulek, M. (2018). A prag-

matic introduction to secure multi-party computation.

Found. Trends Priv. Secur., 2:70–246.

He, Z., Wong, W. K., Kao, B., Cheung, D., Li, R., Yiu, S.,

and Lo, E. (2015). SDB: A secure query processing

system with data interoperability. Proc. VLDB En-

dow., 8:1876–1879.

Hemenway, B., Welser IV, W., and Baiocchi, D. (2014).

Achieving higher-ﬁdelity conjunction analyses using

cryptography to improve information sharing. Tech-

nical report, Rand project, Air Force. Santa Monica,

CA.

Liagouris, J., Kalavri, V., Faisal, M., and Varia, M. (2021).

Secrecy: Secure collaborative analytics on secret-

shared data. arXiv preprint arXiv:2102.01048.

Liu, C., Wang, X. S., Nayak, K., Huang, Y., and Shi, E.

(2015). ObliVM: A programming framework for se-

cure computation. In 2015 IEEE Symposium on Secu-

rity and Privacy, pages 359–376.

opez, F. M. S. and De La Cruz, E. G. S. (2015). Liter-

ature review about Neo4j graph database as a feasi-

ble alternative for replacing rdbms. Industrial Data,

18(2):135–139.

Miller, J. J. (2013). Graph database applications and con-

cepts with Neo4j. In Proceedings of the Southern

Association for Information Systems Conference, At-

lanta, GA, USA, volume 2324.

Mostafa, A. (2016). Security of database management

systems. pages 1–6. https://www.researchgate.net/

publication/301613094.

Nayak, K., Wang, X. S., Ioannidis, S., Weinsberg, U., Taft,

N., and Shi, E. (2015). Graphsc: Parallel secure com-

putation made easy. In 2015 IEEE Symposium on Se-

curity and Privacy, pages 377–394. IEEE.

Poddar, R., Kalra, S., Yanai, A., Deng, R., Popa, R. A.,

and Hellerstein, J. M. (2020). Senate: A maliciously-

secure mpc platform for collaborative analytics. arXiv

e-prints, pages arXiv–2010.

Salehnia, A. (2017). Comparisons of relational databases

with big data : a teaching approach. pages 1–8. South

Dakota State University, Brookings.

Shamir, A. (1979). How to share a secret. Communications

of the ACM, 22(11):612–613.

ICISSP 2022 - 8th International Conference on Information Systems Security and Privacy

470

Volgushev, N., Schwarzkopf, M., Getchell, B., Varia, M.,

Lapets, A., and Bestavros, A. (2019). Conclave: se-

cure multi-party computation on big data. In Pro-

ceedings of the Fourteenth EuroSys Conference 2019,

pages 1–18.

Wong, W. K., Kao, B., Cheung, D. W. L., Li, R., and

Yiu, S. M. (2014). Secure query processing with

data interoperability in a cloud database environment.

In Proceedings of the 2014 ACM SIGMOD inter-

national conference on Management of data, pages

1395–1406.

SMPG: Secure Multi Party Computation on Graph Databases

471
