Student Engagement from Video using Unsupervised Domain Adaptation

Chinchu Thomas

, Seethamraju Purvaj and Dinesh Babu Jayagopi

Multimodal Perception Lab, International Institute of Information Technology Bangalore (IIIT-B), Karnataka, India

Keywords:

Student Engagement, Unsupervised Domain Adaptation, Discrepancy and Adversarial Methods.

Abstract:

Student engagement is the key to successful learning. Measuring student engagement is of utmost importance

in the current global scenario where learning happens over online platforms. Automatic analysis of student

engagement, in ofﬂine and online social interactions, is largely carried out using supervised machine learning

techniques. Recent advances in deep learning have improved performance, albeit at the cost of collecting a

large volume of labeled data, which can be tedious and expensive. Unsupervised domain adaptation using

the deep learning technique is an emerging and promising direction in machine learning when labeled data is

less or absent. Motivated by this, we pose our research question: ”Can deep unsupervised domain adaptation

techniques be used to infer student engagement in classroom videos with unlabeled data?” In our work, two

such classic techniques i.e. Joint Adaptation Network and adversarial domain adaptation using Wasserstein

distance were explored for this task and posed as a binary classiﬁcation problem along with different base

models such as ResNet and I3D. The best-obtained result using the JAN network has an accuracy of 68% and

f1-score of 0.80 for binary student engagement with RGB-I3D network as the base model. The adversarial

domain adaptation method gave an accuracy of 71% and f1-score of 0.82 with ResNet 50 as the feature

extractor for predicting the engagement of the students in the classroom.

1 INTRODUCTION

Student engagement is essential to successful learn-

ing and refers to the extent to which students are in-

terested, attentive, and curious when they are learning

or being taught. In the current global scenario, where

online education has become inevitable, it is of ut-

most importance to track student or user engagement.

Automatic analysis of student engagement has been

previously done using supervised machine learning

methods (Nezami et al., 2019) (Thomas and Jayagopi,

2017) (Whitehill et al., 2014).

Recent advances in deep learning have improved

performance, but come at an increased cost of col-

lecting large volumes of labeled data for training the

network. At the same time, there is already an am-

ple amount of annotated data available for various

domains and tasks. Unsupervised domain adaptation

(UDA) using deep neural networks is an emerging

and promising trend in machine learning to utilize

the existing labeled data. Domain adaptation aims

to learn a concept from labeled data in a source do-

main that performs well on a different but related tar-

get domain that can be labeled, partially labeled, or

https://orcid.org/0000-0003-4887-2273

unlabeled. Unsupervised domain adaptation speciﬁ-

cally addresses the scenario where the source data is

labeled, and the target data is unlabeled.

In this work, we address the following research

question: Can deep unsupervised domain adaptation

techniques be used to infer student engagement from

classroom videos with unlabeled data? We address

this question by using a deep learning pipeline that

embeds unsupervised domain adaption into it. To at-

tempt this, we experimented with two methods: Joint

Adaptation Network (JAN) (Long et al., 2017) and

an adversarial method, that uses Wasserstein distance

for unsupervised domain adaptation (Drossos et al.,

2019). Along with the UDA, we experimented with

different base models in the deep learning pipeline to

understand the impact of each model on the domain

adaptation methods. Also, we explored the effective-

ness of image-based models and video-based models

for unsupervised domain adaptation by using various

pre-trained models like ResNet 18, ResNet 50, and

RGB-I3D.

The contributions of the paper are as follows: We

propose an unsupervised method for inferring the en-

gagement level of the students in a classroom, unlike

previous works which use supervised learning meth-

118

Thomas, C., Purvaj, S. and Jayagopi, D.

Student Engagement from Video using Unsupervised Domain Adaptation.

DOI: 10.5220/0010979400003209

In Proceedings of the 2nd International Conference on Image Processing and Vision Engineering (IMPROVE 2022), pages 118-125

ISBN: 978-989-758-563-0; ISSN: 2795-4943

ods. Although the joint adaptation network and ad-

versarial adaptation using Wasserstein distance were

originally proposed for images, in this work, we use

it on video data. We experimented with three differ-

ent base models; ResNet 18 pre-trained on ImageNet

data (He et al., 2016), ResNet 50 pre-trained on VG-

GFace2 (Cao et al., 2018) and RGB-I3D pre-trained

on ImageNet and Kinetics dataset (Carreira and Zis-

serman, 2017). Also, we did a comparative study of

supervised and unsupervised learning methods to see

how far the unsupervised domain adaptation can per-

form.

The rest of the paper is organized as follows. Sec-

tion 2 discusses the related works relevant to the au-

tomatic prediction of student engagement and unsu-

pervised domain adaptation. The theoretical details

of the methods that we used for the experiments are

described in Section 3. The experimental details in-

cluding the dataset, implementation details and the

baselines are outlined in Section 4. Section 5 presents

the results and the ﬁndings. Section 6 concludes the

paper.

2 RELATED WORK

In this work, we focus on inferring student engage-

ment using unsupervised domain adaptation. Hence,

this section discusses works related to the task as well

as the modeling approach.

Task: Student Engagement Analysis. Student en-

gagement can be predicted in different ways such as

from a camera, logs from the learning platforms, and

data from wearable sensors. In this work, we focus

on the video data captured from an RGB camera. The

different learning environments can be a classroom

(Thomas and Jayagopi, 2017) (Raca, 2015), online

learning platforms (Gupta et al., 2016) (Grafsgaard

et al., 2013) or intelligent tutoring systems (Whitehill

et al., 2014). In all these settings, the goal is to in-

fer the affective state of engagement using supervised

learning techniques. These works utilized either tra-

ditional machine learning methods or a deep learning

pipeline to infer the engagement level of the students.

Supervised methods used handcrafted features

such as eye gaze, head pose, and facial action unit in-

tensities to capture the engagement state. Raca (Raca,

2015) used features computed from motion detection,

head detection, and estimation of orientation. White-

hill et al. (Whitehill et al., 2014) worked on facial

expressions to predict different levels of engagement

in an interactive learning environment. Thomas and

Jayagopi (Thomas and Jayagopi, 2017) utilized the

head pose, eye gaze, and facial action unit intensities

to infer the state of students.

Several works utilized deep learning models such

as Inception model, C3D, and LRCN networks on

frame level as well as video level to infer the affective

states of engagement, boredom, confusion and frus-

tration on DaiSEE dataset (Gupta et al., 2019) (Gupta

et al., 2016) (Ashwin and Guddeti, 2019). Gupta et

al. Yang et al. (Yang et al., 2018) used a multi-

modal regression model based on the multi-instance

mechanism as well as LSTM to predict the engage-

ment intensity for the engagement in the wild dataset

from the EmotiW challenge. Thomas et al. (Thomas

et al., 2018) used Temporal Convolutional Networks

(TCNs) to predict engagement intensity on engage-

ment in the wild dataset. More recently, a several at-

tempts have been made to predict student engagement

in online learning (Abedi and Khan, 2021b) (Abedi

and Khan, 2021a) (Geng et al., 2019) (Huang et al.,

2019) (Liao et al., 2021) (Wang et al., 2020) (Zhang

et al., 2019).

Modeling: Unsupervised Domain Adaptation.

Deep domain adaptation (DA) has emerged as a

new learning paradigm to address the lack of huge

amounts of labeled data. The conventional meth-

ods learn a shared feature subspace or reuse gen-

eral source examples with shallow representations,

whereas deep domain adaptation methods make use

of deep networks to learn more transferable repre-

sentations by embedding domain adaptation in the

pipeline of deep learning. Wang et al. (Wang

and Deng, 2018) described the different methods

such as discrepancy based, adversarial-based and

reconstruction-based deep DA approaches.

In this work, we use a discrepancy-based DA

method (JAN network described in Section 3.1) which

uses maximum mean discrepancy as the statistic cri-

terion to learn the invariant features. The adversarial

method (adversarial network described in Section 3.2)

is a non-generative model which learns domain invari-

ant representations. These representations are learned

with a feature extractor that learns a discriminative

representation using the labels in the source domain

and maps the target data to the same space through a

domain-confusion loss. There are applications of un-

supervised domain adaptation for vision applications,

NLP tasks, and time-series data. A detailed study on

the theoretical aspects and the applications are done in

(Wang and Deng, 2018) (Wilson and Cook, 2020). In

this work, we focus on the problem of inferring stu-

dent engagement. The models were trained to learn

invariant features that can be transferred from an on-

line learning environment to a classroom setting.

Student Engagement from Video using Unsupervised Domain Adaptation

119

3 UNSUPERVISED DOMAIN

ADAPTATION USING JAN AND

ADVERSARIAL APPROACHES

In this section, we brieﬂy explain unsupervised do-

main adaptation using joint adaptation network (JAN)

as well as adversarial approach.

3.1 Joint Adaptation Network

In unsupervised domain adaptation, we are given a

source domain D

= {(x

, y

)}

i=1

of n

labeled ex-

amples and a target domain D

= {(x

, y

)}

i=1

of n

unlabeled examples. The source and target domains

are sampled from joint distributions P(X

) and,

Q(X

) respectively, where P 6= Q.

3.1.1 Joint Adaptation Network

The underlying idea in Joint Adaptation Network

(JAN) (Long et al., 2017) is to extend deep con-

volutional neural networks (CNNs) with additional

fully connected layers to learn a joint representa-

tion of the data and the label. CNNs are known

to learn generic features in the convolutional layers

and domain-speciﬁc features in the ﬁnal layers. The

convolutional features are transferable across the do-

mains, while the features in the fully connected lay-

ers cannot be transferred safely for domain adaptation

due to cross-domain discrepancy. Additionally, the

shift in the labels lingers in the classiﬁer layers. In

unsupervised domain adaptation, the joint distribution

of the features in the higher layers are matched for

source and target domain using joint maximum mean

discrepancy (JMMD). L denotes the domain-speciﬁc

layers where the activations are not safely transfer-

able. By integrating the JMMD over the domain-

speciﬁc layers L into the CNN error, the joint dis-

tributions are matched end-to-end with network train-

ing,

min

∑

i=1

J( f (x

), y

) + λ

(P, Q) (1)

where J(.) is the cross entropy loss,

(P, Q) is the

JMMD penalty and λ > 0 is a trade-off parameter of

the JMMD penalty.

3.2 Adversarial Domain Adaptation

using Wasserstein Distance

Let D

= hZ

, f

i and D

= hZ

, f

i be the source

and target domains, respectively. Let h be the classi-

ﬁer, z ∼ Z is the input to the labeling process f . The

Figure 1: Joint Adaptation Network.

aim of unsupervised DA is to obtain a classiﬁer h that

yields a low error in the source domain and adapt it

to get a low target classiﬁcation error without using

labels from the target domain during the adaptation

process.

The whole process happens in two stages. The

ﬁrst stage is pre-training, where a feature extractor

is obtained during the optimization of the label

classiﬁcation, and the second stage is the adaptation

process, where a copy M

of M

is further optimized

during the adversarial training.

In this framework, Drossos et al. (Drossos

et al., 2019) employ a deep neural network (DNN)

and the Wasserstein generative adversarial networks

(WGAN) formulation and algorithm (Arjovsky et al.,

2017). DNN consists of a feature extractor M, a label

classiﬁer h, and a domain classiﬁer h

. There are two

steps involved in the formulation.

The ﬁrst step (pre-training) is to optimize M and

h using the labeled data (x

, y

) from source domain

, Y

), where y

is 1-hot encoding of the classes

and the binary cross-entropy as the loss function

(h, f

) in source domain:

labels

(h, M) = −

∑

(x,y)∈(X

)

log(h(M(x))) (2)

and the classiﬁer h

∗

is obtained and the source domain

feature extractor M

∗

, M

= arg min

h,M

labels

(h, M) (3)

denotes the parameters of the feature extractor

and will be used as initial values for the adapted

feature extractor M

In the second step (adaptation), M

is adapted to

the target domain using an adversarial training proce-

dure. In this framework, order-1 Wasserstein distance

is used as the metric to measure the discrepancy be-

tween Z

. The process of the adaptation of M

performed by the iterative minimization of the losses,

∑

x∈X

(x)) −

∑

x∈X

(x)), (4)

∑

x∈X

(x)) + L

labels

∗

, M

). (5)

IMPROVE 2022 - 2nd International Conference on Image Processing and Vision Engineering

120

(a) (b)

Figure 2: Sample frames from (a) DaiSEE dataset and (b)

SEC dataset.

4 EXPERIMENTS

In this section, we discuss the details of the datasets,

baseline models and computational descriptors used

in the experiments.

4.1 Datasets

The details of the source and target datasets are ex-

plained in the following paragraphs.

Source Dataset. The source dataset used for the ex-

periments is the in-the-wild DaiSEE dataset consist-

ing of 9068 videos of 112 users annotated for affec-

tive states of boredom, engagement, confusion, and

frustration (Gupta et al., 2016). The data comprises

videos of users in an e-learning environment. The af-

fective states are annotated for four levels: very-low,

low, high, and very-high from the CrowdFlower plat-

form. The videos are of 10-second duration. All the

videos are annotated for multiple affect since a per-

son may show different effects while in the learning

environment. This work considers only the engage-

ment affective state. The videos in very low and low

levels are combined for the distracted label (label ’0’)

and high and very-high are combined for the engaged

label (label ’1’).

Target Dataset. The target dataset is the X dataset

which consists of 2262 videos of students attending

video presentations projected on the screen in a class-

room. There are 10 unique students in the classroom,

and each student video is trimmed for 10 seconds.

The student affective state of engagement is annotated

by external observers on a binary scale of engaged or

distracted. More details of the dataset can be found in

(Thomas and Jayagopi, 2017). The dataset is highly

imbalanced. For the experiments, the train, valida-

tion, and test set consist of 1064, 456, and 742 sam-

ples respectively. Sample frames from the videos are

shown in Fig. 2.

4.2 Modeling

In this subsection, we describe our baseline models

and the set of computational descriptors for further

modeling.

Baseline: The baselines are created for the target

test set (IIITB-SE) to compare how well the unsuper-

vised domain adaptation model performs compared to

the supervised and unsupervised learning task. The

baseline for the supervised learning is the majority

baseline which is created for the test set. For the su-

pervised method, we considered Logistic Regression

(LR), Support Vector Machine (SVM), and Random

Forest (RF) classiﬁers. For the unsupervised domain

adaptation, the ﬁne-tuned source models before adap-

tation were considered as baselines. We considered

ResNet 18 pre-trained on ImageNet; ResNet 50 pre-

trained on VGGFace2 dataset and RGB-I3D model

pre-trained on ImageNet and Kinetics dataset as base

models in JAN framework and as generators in an ad-

versarial setting.

Computational Descriptors: The models, with su-

pervised learning, used visual features. The vi-

sual features were computed using OpenFace toolbox

(Baltru

saitis et al., 2016) for every frame. We ex-

tracted features related to eye gaze, head pose, and

facial action unit (AUCs) of the speaker in the video.

The mean and standard deviation of the features were

computed to aggregate the statistics to a video level,

which resulted in a 46-dimensional feature vector. We

ran feature selection to choose 39 features that re-

sulted in the highest relevance score. Another set of

visual features that we used for the experiment was

the 512-dimensional feature vector extracted from the

videos. These are computed from the last pooling

layer of the ResNet 18 pre-trained network. The third

set of features used for the experiments were the last

layer 2048-dimensional features from ResNet 50 VG-

GFace2 pre-trained network. Also, we computed fea-

tures from the last layer of the RGB-I3D model pre-

trained on ImageNet. The feature vectors from both

ResNet 18 and ResNet 50 were computed for the

frames, and the mean of all the frames was consid-

ered as the ﬁnal feature vector.

4.3 Implementation Details

4.3.1 JAN Network

The details of the architecture are described in this

section. The base network of the model were pre-

trained ResNet models and I3D model. The exper-

Student Engagement from Video using Unsupervised Domain Adaptation

121

iments were done using ResNet 18, ResNet 50, and

I3D architectures. The ResNet models until the last

pooling layer were used as the base network. The

ResNet 18 base network is followed by a bottleneck

layer and a classiﬁer layer. The bottleneck layer is

a fully-connected layer with 512 × 256 neurons and

the classiﬁer layer is also a fully connected layer with

256 × 2 neurons. The ResNet 50 base network is fol-

lowed by the bottleneck layer with 2048 × 256 neu-

rons and the classiﬁer layer with 256 × 2 neurons.

The RGB-I3D base model is followed by a bottleneck

layer with 2048 × 256 neurons and a classiﬁer layer

with 256 × 2 neurons. The output from the classi-

ﬁer layer is passed through a Softmax layer for the

class probabilities. The bottleneck layer is followed

by ReLu activation and drop out of 0.2. The bottle-

neck layer and the classiﬁer layers were initialized at

random with a normal distribution. We ﬁne-tune all

convolutional and pooling layers and train the classi-

ﬁer layer via backpropagation. Since the classiﬁer is

trained from scratch, we set its learning rate to be 10

times that of the other layers and the initial learning

rate was 0.01. We use mini-batch stochastic gradient

descent (SGD) with a momentum of 0.5 and the learn-

ing rate annealing strategy in RevGrad (Long et al.,

2017). The trade-off parameter of the JMMD term

was 0.5. We used the PyTorch implementation of JAN

for the experiments

. The learning rate is not selected

by a grid search due to high computational cost; it is

adjusted during SGD as in the original implementa-

tion of JAN.

The training process is as follows: The videos are

sampled at 1 frame per second to extract the frames

of the videos. The frames are cropped for getting the

frontal faces using dlib library, removing all unnec-

essary background information. We did this prepro-

cessing with the assumption that student engagement

can be learned from the region above the shoulder.

The video frames are resized to 456 × 256. During

training, a random 224 × 224 pixels spatial crop of a

random frame of the visual data is randomly ﬂipped

in the left/right direction and fed into the model. The

activities of the penultimate layer are spatially pooled.

This output from the base network is passed to the

bottleneck layer. The network is trained for 20000 it-

erations. Over multiple iterations, we assume that the

model is able to learn the temporal dependencies in

the video. The validation is done at every 500 iter-

ations inside the training using the above-mentioned

procedure. The models which resulted in the best val-

idation accuracy are tested. During testing, the en-

tire video data is fed into the network one frame at a

time. The network predicts for every frame in a video,

https://github.com/thuml/Xlearn

and the ﬁnal prediction is the majority label computed

over all the frames. For the RGB-I3D model, the en-

tire video which is sampled at 1 frame per second is

passed to the model directly for training and testing.

4.3.2 Adversarial Network

The architectural details of the generator models in

the adversarial method are explained in this section.

The ﬁrst network that we used as the generator, was

ResNet 18 pre-trained on ImageNet. The second net-

work considered was pre-trained ResNet 50 as M

ResNet 50 is pre-trained on the VGGFace2 dataset,

which is closer to the source and target dataset. The

last one was RGB-I3D pre-trained on ImageNet and

Kinetics dataset. The discriminator has two fully con-

nected layers followed by a ReLU. The classiﬁer layer

consists of three feed-forward layers, each one fol-

lowed by a ReLU and a drop out of 0.25. The feed-

forward layers consists of 512, 256, 2 neurons for

ResNet 18 model; 2048, 256, 2 neurons for ResNet 50

model and 2048, 256, 2 neurons for RGB-I3D model.

The output non-linearity of h is the softmax function.

The experiments were done using the PyTorch

im-

plementation of the adversarial model. For the adap-

tation stage, the RMSProp optimizer is used with a

learning rate of 5× 10

−4

for RGB-I3D and 1× 10

−3

and 5× 10

−4

for the generator and discriminator re-

spectively in ResNet based models.

The training process for the model is as follows:

The videos are sampled at 1 frame per second to ex-

tract the frames of the videos. The frames are cropped

for getting the frontal faces. A random frame is sam-

pled, and the frame is resized to 224 × 224. In the

ﬁrst step, the ResNet 18 model (M

) pre-trained on

ImageNet, and h are trained using the source dataset

in a supervised manner. This resulted in an adapted

feature extractor M

on the source dataset with an ac-

curacy of 0.88. The ResNet 50 model resulted in an

accuracy of 63% while pre-training. The RGB-I3D

model resulted in an accuracy of 67%.In the second

step of the adaptation, M

is initialized with adapted

. The network is trained to fool the domain clas-

siﬁer. The adaptation process is done for 300 epochs

and all the models are tested. The results are reported

for the best model. During testing, the video data are

fed into the model one frame at a time. The testing

is done using the adapted feature extractor and the la-

bel classiﬁer. The network predicts for every frame

in a video, and the ﬁnal prediction is the majority la-

bel computed over all the frames. For I3D, the entire

video is passed for testing the models.

https://github.com/dr-costas/undaw

IMPROVE 2022 - 2nd International Conference on Image Processing and Vision Engineering

122

Table 1: Student engagement classiﬁcation result with supervised learning.

Model Feature Accuracy Precision Recall f1-score

Majority Baseline 0.83 0.83 1.0 0.91

Naive Bayes facial cues 0.16 0.0 0.0 0.0

Logistic Regression facial cues 0.83 0.83 1.0 0.91

SVM facial cues 0.83 0.83 1.0 0.91

Random Forest facial cues 0.75 0.82 0.90 0.86

Naive Bayes ResNet 18 0.72 0.89 0.76 0.82

Logistic Regression ResNet 18 0.84 0.90 0.91 0.90

SVM ResNet 18 0.82 0.91 0.86 0.89

Random Forest ResNet 18 0.86 0.88 0.95 0.92

Naive Bayes ResNet 50 0.78 0.89 0.85 0.87

Logistic Regression ResNet 50 0.83 0.86 0.95 0.90

SVM ResNet 50 0.83 0.88 0.92 0.90

Random Forest ResNet 50 0.85 0.88 0.96 0.91

Naive Bayes RGB-I3D 0.80 0.90 0.86 0.88

Logistic Regression RGB-I3D 0.81 0.90 0.88 0.89

SVM RGB-I3D 0.81 0.90 0.86 0.88

Random Forest RGB-I3D 0.85 0.87 0.96 0.91

Table 2: Student engagement classiﬁcation result with source domain ﬁne-tuning (before adaptation).

Base model Accuracy Precision Recall f1-score

ResNet18 (ImageNet) 0.19 0.79 0.04 0.11

ResNet50 (VGGFace2) 0.21 0.90 0.06 0.11

RGB-I3D (ImageNet) 0.41 0.77 0.40 053

Table 3: Student engagement classiﬁcation result with unsupervised domain adaptation.

UDA method Base model Accuracy Precision Recall f1-score

JAN ResNet18 (ImageNet) 0.61 0.82 0.74 0.78

JAN ResNet50 (VGGFace2) 0.57 0.81 0.63 0.71

JAN RGB-I3D (ImageNet) 0.68 0.81 0.80 0.80

Adversarial ResNet18 (ImageNet) 0.62 0.88 0.62 0.73

Adversarial ResNet 50 (VGGFace2) 0.71 0.84 0.80 0.82

Adversarial RGB-I3D (ImageNet) 0.54 0.83 0.59 0.69

(a) (b)

Figure 3: t-SNE plots for adversarial model with ResNet 50 as the base model (a) before adaptation (b) after adaptation.

Student Engagement from Video using Unsupervised Domain Adaptation

123

5 RESULTS AND DISCUSSION

In this section, we describe the results for the binary

classiﬁcation task of engaged or distracted. The met-

rics used for evaluation are accuracy, precision, re-

call, and f1-score. The results are reported in Table 1.

The majority classiﬁer, which classiﬁes everything to

the majority class, resulted in a test accuracy of 83%

and an f1-score of 0.68 on the SE test data. Super-

vised learning methods such as Logistic Regression

and SVM performed just like a majority classiﬁer.

Naive Bayes was putting everything to the minority

class, which is even worse. Random Forest performed

better on facial cues with 75% accuracy and f1-score

of 0.86. When the features were extracted from the

last layer of ResNet 18 pre-trained on ImageNet, there

is an improvement in the performance, especially for

Naive Bayes and Random Forest classiﬁers. Naive

Bayes performed with an accuracy of 72%, f1-score

of 0.82, and Random Forest with 86% accuracy and

0.92 as f1-score. When the features were extracted

from ResNet 50 pre-trained on VGGFace2, there is a

slight drop in the performance compared to ResNet 18

pre-trained on ImageNet. This can be because of the

huge dimensionality of the feature vector compared to

the number of samples in the training set. This obser-

vation is consistent with the RGB-I3D model as well.

The results from the supervised learning methods re-

veal the difﬁculty with respect to the dataset, and the

low performance also stems from the huge class im-

balance in the SE dataset.

In Table 2, we can see the results of the base mod-

els ﬁne-tuned with the source dataset and then tested

on the target dataset. This is considered as the base-

line for the UDA methods. The results show that only

the RGB-I3D model is able to perform a little better,

with an accuracy of 41% and f1-score of 0.53 on a

similar dataset. These results show the requirement to

adapt the models for a speciﬁc domain of the dataset.

The results for unsupervised domain adaptation

are reported in Table 3. In unsupervised domain

adaptation, we experimented with discrepancy-based

(JAN) and adversarial-based domain adaptation meth-

ods coupled with various pre-trained deep networks.

In both the cases, the results are reported ResNet 18

pre-trained on ImageNet, ResNet 50 pre-trained on

VGGFace2 dataset, and RGB-I3D pre-trained on Im-

ageNet and Kinetics datasets. Among the JAN mod-

els, the one with RGB-I3D pre-trained on ImageNet

and Kinetics datasets as the base network performed

better than other base models, with an accuracy of

68% and f1-score of 0.80. Among the adversarial

method, the base model with ResNet 50 pre-trained

on VGGFace2 performed way better than all other

models, with an accuracy of 71% and f1-score of 0.82.

This model performed signiﬁcantly better than all the

discussed unsupervised models. The t-SNE plot for

the best model reported, ResNet 50 pre-trained with

VGGFace2 in the adversarial setting, is shown in Fig.

3. In the before adaptation plot, Fig. 3a the source and

target domain points are close enough. This shows

how similarity between the source and target domain.

After adaptation, the points in the source and target

domain moved farther apart, but the classiﬁcation re-

sults are better after adaptation. This can be because,

before adaptation, the classiﬁer was not performing

well on the classes, but after adaptation, though the

source and target domain points moved apart, the clas-

siﬁer is able to classify both the classes irrespective of

the class imbalance in the target domain data. Also,

there is a signiﬁcant improvement from the baseline

models. But when compared to the supervised meth-

ods, their numbers are lagging a lot. Though there is

room for improvement for unsupervised models com-

pared to the supervised models, when the labels are

unavailable, this is a promising direction.

6 CONCLUSION

In this work, we addressed an important question,

can unsupervised deep domain adaptation methods be

used to infer binary engagement of students in a class-

room. For this, we used a discrepancy-based method

and an adversarial method with different base mod-

els that work with images and videos for the exper-

iments. The JAN model with RGB-I3D as the base

network resulted in 68% accuracy and an f1-score

of 0.80 performed better among JAN models. Fur-

ther, using the adversarial method using Wasserstein

distance resulted in the best result with 71% accu-

racy and f1-score of 0.82 among all the unsupervised

methods. The experiments show that unsupervised

domain adaptation is a promising direction for infer-

ring student engagement when labels are not avail-

able. Moreover, the experiments showed that we can

safely transfer features from an online setting to a

classroom setting with unsupervised domain adapta-

tion.

ACKNOWLEDGEMENTS

The ﬁrst author would like to thank Visvesvaraya

PhD Scheme, Ministry of Electronics and Informa-

tion Technology (MeitY), Government of India for

supporting the work.

IMPROVE 2022 - 2nd International Conference on Image Processing and Vision Engineering

124

REFERENCES

Abedi, A. and Khan, S. (2021a). Affect-driven engage-

ment measurement from videos. arXiv preprint

arXiv:2106.10882.

Abedi, A. and Khan, S. S. (2021b). Improving state-of-the-

art in detecting student engagement with resnet and

tcn hybrid network. The 18th Conference on Robots

and Vision.

Arjovsky, M., Chintala, S., and Bottou, L. (2017). Wasser-

stein generative adversarial networks. In Proceed-

ings of the 34th International Conference on Ma-

chine Learning - Volume 70, ICML’17, page 214–223.

JMLR.org.

Ashwin, T. and Guddeti, R. M. R. (2019). Automatic de-

tection of students’ affective states in classroom envi-

ronment using hybrid convolutional neural networks.

Education and Information Technologies, pages 1–29.

Baltru

saitis, T., Robinson, P., and Morency, L.-P. (2016).

Openface: an open source facial behavior analysis

toolkit. In Applications of Computer Vision (WACV),

2016 IEEE Winter Conference on, pages 1–10. IEEE.

Cao, Q., Shen, L., Xie, W., Parkhi, O. M., and Zisserman,

A. (2018). Vggface2: A dataset for recognising faces

across pose and age. In 2018 13th IEEE International

Conference on Automatic Face Gesture Recognition

(FG 2018), pages 67–74.

Carreira, J. and Zisserman, A. (2017). Quo vadis, action

recognition? a new model and the kinetics dataset.

In proceedings of the IEEE Conference on Computer

Vision and Pattern Recognition, pages 6299–6308.

Drossos, K., Magron, P., and Virtanen, T. (2019). Unsu-

pervised adversarial domain adaptation based on the

wasserstein distance for acoustic scene classiﬁcation.

arXiv preprint arXiv:1904.10678.

Geng, L., Xu, M., Wei, Z., and Zhou, X. (2019). Learning

deep spatiotemporal feature for engagement recogni-

tion of online courses. In 2019 IEEE Symposium

Series on Computational Intelligence (SSCI), pages

442–447. IEEE.

Grafsgaard, J., Wiggins, J. B., Boyer, K. E., Wiebe, E. N.,

and Lester, J. (2013). Automatically recognizing fa-

cial expression: Predicting engagement and frustra-

tion. In Educational Data Mining 2013.

Gupta, A., D’Cunha, A., Awasthi, K., and Balasubra-

manian, V. (2016). Daisee: Towards user en-

gagement recognition in the wild. arXiv preprint

arXiv:1609.01885.

Gupta, S. K., Ashwin, T., and Guddeti, R. M. R. (2019).

Students’ affective content analysis in smart class-

room environment using deep learning techniques.

Multimedia Tools and Applications, pages 1–28.

He, K., Zhang, X., Ren, S., and Sun, J. (2016). Deep resid-

ual learning for image recognition. In Proceedings of

the IEEE conference on computer vision and pattern

recognition, pages 770–778.

Huang, T., Mei, Y., Zhang, H., Liu, S., and Yang, H. (2019).

Fine-grained engagement recognition in online learn-

ing environment. In 2019 IEEE 9th international

conference on electronics information and emergency

communication (ICEIEC), pages 338–341. IEEE.

Liao, J., Liang, Y., and Pan, J. (2021). Deep facial spa-

tiotemporal network for engagement prediction in on-

line learning. Applied Intelligence, pages 1–13.

Long, M., Zhu, H., Wang, J., and Jordan, M. I. (2017).

Deep transfer learning with joint adaptation networks.

In Proceedings of the 34th International Conference

on Machine Learning-Volume 70, pages 2208–2217.

JMLR. org.

Nezami, O. M., Dras, M., Hamey, L., Richards, D., Wan, S.,

and Paris, C. (2019). Automatic recognition of student

engagement using deep learning and facial expression.

In Joint European Conference on Machine Learning

and Knowledge Discovery in Databases, pages 273–

289. Springer.

Raca, M. (2015). Camera-based estimation of student’s at-

tention in class. Technical report, EPFL.

Thomas, C. and Jayagopi, D. B. (2017). Predicting stu-

dent engagement in classrooms using facial behavioral

cues. In Proceedings of the 1st ACM SIGCHI interna-

tional workshop on multimodal interaction for educa-

tion, pages 33–40.

Thomas, C., Nair, N., and Jayagopi, D. B. (2018). Predict-

ing engagement intensity in the wild using temporal

convolutional network. In Proceedings of the 2018 on

International Conference on Multimodal Interaction,

pages 604–610. ACM.

Wang, M. and Deng, W. (2018). Deep visual domain adap-

tation: A survey. Neurocomputing, 312:135–153.

Wang, Y., Kotha, A., Hong, P.-h., and Qiu, M. (2020). Au-

tomated student engagement monitoring and evalua-

tion during learning in the wild. In 2020 7th IEEE In-

ternational Conference on Cyber Security and Cloud

Computing (CSCloud)/2020 6th IEEE International

Conference on Edge Computing and Scalable Cloud

(EdgeCom), pages 270–275. IEEE.

Whitehill, J., Serpell, Z., Lin, Y.-C., Foster, A., and Movel-

lan, J. R. (2014). The faces of engagement: Auto-

matic recognition of student engagementfrom facial

expressions. IEEE Transactions on Affective Comput-

ing, 5(1):86–98.

Wilson, G. and Cook, D. J. (2020). A survey of unsuper-

vised deep domain adaptation. ACM Transactions on

Intelligent Systems and Technology (TIST), 11(5):1–

46.

Yang, J., Wang, K., Peng, X., and Qiao, Y. (2018). Deep

recurrent multi-instance learning with spatio-temporal

features for engagement intensity prediction. In Pro-

ceedings of the 2018 on International Conference on

Multimodal Interaction, pages 594–598. ACM.

Zhang, H., Xiao, X., Huang, T., Liu, S., Xia, Y., and Li,

J. (2019). An novel end-to-end network for auto-

matic student engagement recognition. In 2019 IEEE

9th International Conference on Electronics Informa-

tion and Emergency Communication (ICEIEC), pages

342–345. IEEE.

Student Engagement from Video using Unsupervised Domain Adaptation

125
