Robust Face Mask Detection with Combined Frontal and Angled Viewed

Faces

Ivan George L. Tarun

, Vidal Wyatt M. Lopez

, Patricia Angela R. Abu

and Ma. Regina Justina E. Estuar

Ateneo Laboratory for Intelligent Visual Environment, Dept. of Information Systems and Computer Science,

Ateneo De Manila University, Katipunan Avenue, Quezon City, Philippines

Ateneo Center for Computing Competency and Research,Ateneo De Manila University,

Katipunan Avenue, Quezon City, Philippines

Keywords:

Face Mask Detection, Object Detection, Deep Learning, Computer Vision.

Abstract:

One such protocol currently enforced by the Philippine government to combat COVID-19 is the mandatory

use of face masks in public places. The problem however is that ensuring people follow this protocol is

difﬁcult to monitor during a pandemic due to other conﬂicting health protocols like social distancing and

workforce reduction. This study therefore explores on the creation of deep learning models that consider both

frontal and side view images of the face for face mask detection. In doing so, improvements to robustness

were found when compared to using models that were previously trained on purely frontal images. This

was accomplished by ﬁrst relabeling a subset of images from the FMLD dataset. These images were then

split into train, validation, and test sets. Four deep learning models (YOLOv5 Small, YOLOv5 Medium,

CenterNet Resnet50 V1 FPN 512x512, CenterNet HourGlass104 512x512) were later trained on the training

set of images. These four models were compared with three models (MobileNetV1, ResNet50, VGG16) that

were trained previously on purely frontal images. Results show that the four models trained on the relabeled

FMLD dataset offer an approximately 20% increase in classiﬁcation accuracy over the three models that were

previously trained on purely frontal images.

1 INTRODUCTION

New infectious diseases continue to emerge to this

day with them contributing to the already long list of

discovered illnesses. With that said, emerging infec-

tions (EIs) are infectious diseases that have just re-

cently appeared, or they have already existed but only

now are they quickly expanding in geographic range

or occurrence (Petersen et al., 2018). There has been a

constant ﬁght to contain EIs throughout history due to

their global burden of being among the leading causes

of death and disability.

Moreover, infectious diseases have continued to

evolve throughout history with different diseases hav-

ing various potential to spread globally (Fauci, 2001).

COVID-19 is one recent disease which is caused by

the zoonotic virus known as the Severe Acute Res-

piratory Syndrome Coronavirus 2 or SARS-CoV-2

(C¸ elik et al., 2020). It is classiﬁed as a highly trans-

missible and pathogenic viral infection. COVID-19

ﬁrst emerged in Wuhan, China at the end of 2019 and

subsequently escalated into a global pandemic. Upon

its ﬁrst emergence, the novel coronavirus managed to

kill more than 1,800 people and infect over 70,000 in-

dividuals in the ﬁrst 50 days of the epidemic in China

(Shereen et al., 2020). With this as context, the Philip-

pines as of the beginning of February 2022, has sur-

passed 3.6 million total infections along with 3.5 mil-

lion recoveries while 54,000 have died (Department

of Health (Philippines), 2022).

One protocol currently enforced by the Philippine

government to combat COVID-19 is the mandatory

use of face masks in public places (Lazaro et al.,

2020). The problem however is that ensuring peo-

ple follow this protocol during a pandemic is difﬁcult

to monitor due to conﬂicting health protocols (social

distancing & workforce reduction). Compliance also

tends to lessen over time due to complacency (Choud-

hary et al., 2021). To help solve this, the Ateneo Lab-

oratory for Intelligent Visual Environment (ALIVE)

created a real-time face mask detection model for

video feeds (Lopez et al., 2021). It checks if a per-

son is wearing a mask or not, and if so, checks if the

mask is medically approved or not. Still, the model is

462

Tarun, I., Lopez, V., Abu, P. and Estuar, M.

Robust Face Mask Detection with Combined Frontal and Angled Viewed Faces.

DOI: 10.5220/0010986000003179

In Proceedings of the 24th International Conference on Enterprise Information Systems (ICEIS 2022) - Volume 1, pages 462-470

ISBN: 978-989-758-569-2; ISSN: 2184-4992

limited by only being trained to detect face masks of

those who look directly into the camera.

Given the limitations of the front-facing face mask

detection model, this study aims to improve on the

robustness of the computer vision models in (Lopez

et al., 2021) by training new models that also consider

angled or side view images of the face.

2 REVIEW OF RELATED

LITERATURE

2.1 COVID-19 Health Protocols

From an international perspective, the World Health

Organization (WHO) published a document titled

“Mask use in the context of COVID-19: interim guid-

ance” (World Health Organization, 2020). To sum-

marize, the WHO recommends the general popula-

tion to wear at least fabric masks in public settings

where physical distancing of at least one meter can-

not be maintained and ventilation is known to be poor.

Meanwhile, only people with an increased risk of se-

vere complications from contracting COVID-19 are

recommended to wear medical masks. These peo-

ple include those who are aged 60 and above along

with those who have underlying comorbidities. As

for those who are suspected or conﬁrmed to have

COVID-19, they should always wear a medical mask

no matter the community setting.

Transitioning to a more localized perspective, the

“Omnibus Guidelines on the Implementation of Com-

munity Quarantine in the Philippines Updated as of

September 23, 2021” dictates comprehensive proto-

cols on how the COVID-19 pandemic should be man-

aged within the Philippines as prepared by the Inter-

Agency Task Force for the Management of Emerging

Infectious Diseases (Inter-Agency Task Force for the

Management of Emerging Infectious Diseases, 2021).

Mask use is also recommended by these guidelines,

medical or non-medical, similar to that of the WHO.

However, there are some key differences particularly

that wearing of masks are mandatory in any setting

(indoor or outdoor) outside one’s own residence.

Overall, these protocols provide deeper context re-

garding the problem of this study which is the moni-

toring of the compliance of the public to COVID-19

health protocols. Also note that the technical details

of these protocols vary per organization and that there

is no universal answer regarding which is the cor-

rect one to follow. Multiple organizations nonetheless

agree that the wearing of face masks is recommended

in combating COVID-19. This therefore solidiﬁes the

reasoning behind this study which is to create a com-

puter vision model that monitors the wearing of face

masks.

2.2 Previous Attempts in Creating a

Computer Vision Model for

Detecting Face Masks

A study created a novel deep learning model for

face mask detection (Loey et al., 2021). ResNet-50

(Residual Neural Network) with transfer learning and

YOLO v2 (You Only Look Once) was used for fea-

ture extraction and detection of face masks respec-

tively in the training, validation, and testing phases.

The YOLO family of detectors were used for reasons

of speed and performance. Mean Intersection over

Union (IoU) was also used in the study to estimate

the best number of anchor boxes and increase model

performance. Data augmentation was also performed

to increase the diversity of their dataset by ﬂipping

images horizontally. The study then compared two

optimizer techniques used in improving detector per-

formance, Stochastic Gradient Descent with Momen-

tum (SGDM) and the Adam optimizer. Their results

show that SGDM was better than Adam in training

time, validation Root Mean Square Error (RMSE),

and validation Loss. However, Adam was better in

Mini-batch RMSE and Loss. Evaluation of the detec-

tor performance resulted in Adam being better than

SGDM with an average precision (AP) of 0.81 while

SGDM had 0.61 in all recall levels. Miss rates were

also lower and better with Adam with it having a

log-average miss rate of 0.4 while SGDM had 0.6.

The proposed detector model was then compared with

other related works wherein it was found that it per-

formed the best even if AP only reached 81%.

Another study implemented a real-time face mask

detection system for embedded systems (Lopez et al.,

2021). This study comes from the aforementioned

ALIVE laboratory which the current paper seeks to

improve upon. The face mask detection system aims

to do three class classiﬁcation namely for wearing

medically approved masks, non-medically approved

masks, and wearing no mask. Medically approved

masks include surgical masks and N95 respirators

while non-medically approved masks consist of body

parts covering the face (e.g., hands), scarfs, and

cloth face masks. A comparative analysis was sub-

sequently conducted between MobileNetV1, VGG16,

and ResNet50 to determine which deep learning

model to use for the face mask detection system. In

doing so, the MAsked FAces (MAFA) dataset (Ge

et al., 2017) was manually reclassiﬁed to ﬁt the three

aforementioned mask wearing types. The three mod-

Robust Face Mask Detection with Combined Frontal and Angled Viewed Faces

463

els were then trained on this subdataset, also incorpo-

rating data augmentation, for 20 epochs each with a

batch size of 32 and a learning rate of 1e-4. Results

show that the MobileNetV1 achieved the highest vali-

dation accuracy of 79% followed by VGG16 (76%)

and then ResNet50 (37%). After this, the models

were ran on a Raspberry Pi 4 Model B (4GB RAM)

embedded system and classiﬁed video captured from

a webcam to see their real-time performance in terms

of frames per second (fps). MobileNetV1 had the

highest fps with 9.6, then ResNet50 (5.13 fps), and

ﬁnally VGG16 (4.62 fps).

2.3 Mask Detection Datasets

The aforementioned MAFA dataset is one potential

dataset that can be used (Ge et al., 2017). It is meant

for masked face detection and consists of 30,811 im-

ages containing 35,806 masked human faces. Each

masked face has six main attributes which are the

locations of the face, eyes, masks, face orientation,

occlusion degree, and mask type. Of interest to the

current study is the face orientation attribute wherein

ﬁve orientations were deﬁned speciﬁcally left, front,

right, left-front, and right-front. Next, the mask type

attribute consists of four categories including Simple

Mask (pure color), Complex Mask (complex textures

or logos), Human Body (face covered by hand, hair,

etc.) and Hybrid Mask (combinations of at least two

mask types, or one mask type with eyes occluded by

glasses).

One criticism of the MAFA dataset is that it is

more suited for occlusion detection rather than mask

detection (Nowrin et al., 2021). To solve this issue

amongst others, a study created the Face Mask Label

Dataset (FMLD) (Batagelj et al., 2021). It is a com-

bination of the MAFA and WIDER FACE datasets

(Yang et al., 2016). FMLD overall has 41,934 im-

ages containing 63,072 faces labeled as either cor-

rectly masked, incorrectly masked, or unmasked. Ad-

ditional annotations are also available like gender,

pose, and ethnicity.

2.4 Deep Learning Models

In order to determine the best deep learning models to

use for the face mask detection, multiple architectures

were benchmarked in this study which is further dis-

cussed in Section 3. Some of the benchmarked mod-

els include the CenterNet architecture (Zhou et al.,

2019) which involves anchorless object detection. It

replaces the traditional Non-Maximum Suppression

(NMS) with a simpler, faster, and more accurate al-

gorithm. This different approach models objects as a

single point which is the center point of the bound-

ing box. Keypoint estimation is then used to ﬁnd

the center points while regression is used for ﬁnd-

ing other object properties such as size, location, and

pose. CenterNet operates on the insight that relevant

box predictions can be determined depending on the

location of their centers instead of their overlap with

the object as in NMS. Less garbage predictions are

therefore made compared to anchor-based detection

along with removing the need for the computationally

heavy NMS.

The rest of the benchmarked models incorporate

the YOLOv5 architecture (Jocher et al., 2021). In

general, YOLO works by dividing an image into a

system of grids where each grid detects objects within

itself. This system results in consuming less compu-

tational resources during operation. The main differ-

ences of YOLOv5 to its predecessors start with its

backbone. YOLOv5 combines Cross Stage Partial

Networks or CSPNet (Wang et al., 2020) with Dark-

net to form CSPDarknet as its backbone to extract

features from an input image. CSPNet solves the du-

plicate gradient problems usually found in large-scale

backbones and therefore leads to fewer parameters

and ﬂoating-point operations per second. These fur-

ther yield faster inference speed and reduced model

size. As for the model neck, YOLOv5 utilizes the

Path Aggregation Network or PANet (Liu et al., 2018)

to generate feature pyramids that aggregate and pass

features to the model head. PANet introduces a new

feature pyramid structure which improves the propa-

gation of low-level features by having an enhanced

bottom-up path. All-in-all, PANet contributes bet-

ter location accuracy for objects. The model head

remains the same between YOLOv5 and YOLOv4

which is responsible for producing class predictions

and bounding boxes. It is capable of multi-scale

detection or handling small, medium, and large ob-

jects (Xu et al., 2021). Other differences present in

YOLOv5 include the use of the Leaky Rectiﬁed Lin-

ear Unit and Sigmoid activation functions to over-

come the vanishing gradient problem. The loss func-

tion has also switched to the Binary Cross-Entropy

with Logits Loss function. These last two differences

help YOLOv5 to learn faster and perform better.

3 METHODOLOGY

This section contains the necessary steps that were

performed for this study namely Dataset Relabeling,

Splitting the Dataset, Model Training, and Model

Comparison. These are further elaborated in their re-

spective subsections.

ICEIS 2022 - 24th International Conference on Enterprise Information Systems

464

3.1 Dataset Relabeling

With the goal of this study to improve the models

in (Lopez et al., 2021), the dataset required needs

to be similar wherein there are classes for Medically

Approved Masks, Non-Medically Approved Masks,

and No Masks. These would be for the frontal view

of the face. Another set of the three classes would

be needed for the side or angled views of the face.

Taking this into consideration, either the MAFA or

FMLD datasets need to be relabeled in order to have

the same set of classes in (Lopez et al., 2021).

Therefore, Dataset Relabeling was done based on

the FMLD dataset. The makesense.ai tool (Skalski,

2019) was used to relabel a subset of images into

six classes namely Front - Medical Mask, Front -

Non Medical Mask, Front - No Mask, Side - Medi-

cal Mask, Side - Non Medical Mask, and Side - No

Mask. Frontal images are deﬁned as faces where all

its parts are in view (both eyes, whole nose, and whole

mouth). Side view images then are deﬁned as either

purely left or purely right images of the face with only

some parts of the face in view (one eye, half nose,

half mouth, one ear). Medical Masks include surgical

masks and N95 respirators while Non Medical Masks

consist of scarfs, cloth face masks, and construction

masks. Sample images can be seen in Figure 1.

Figure 1: Sample images from the relabeled FMLD dataset.

3.2 Splitting the Dataset

Moving forward, the relabeled FMLD dataset was

split into train, validation, and test sets. Eighty per-

cent (80%) of the images were used as the train set,

ten percent (10%) as the validation set, and ten per-

cent (10%) as the test set. Care was taken to ensure

that there was an equal number of images per class

in each respective set. This was done through the

train test split function with the stratify parameter of

the scikit-learn package in Python (Pedregosa et al.,

2011).

3.3 Model Training

After dataset splitting, four deep learning models

were trained on the training set. Two of them are

the YOLOv5 Small and YOLOv5 Medium models

(Jocher et al., 2021). The other two are the Center-

Net Resnet50 V1 FPN 512x512 and CenterNet Hour-

Glass104 512x512 models from the Tensorﬂow 2 Ob-

ject Detection API Model Zoo (Huang et al., 2017).

Transfer learning was done with the four models pre-

trained on the COCO 2017 dataset. Each model also

comes with their own standard set of data augmenta-

tions which were left as is. Next, the four models were

each trained for 300 epochs. The YOLOv5 Small and

Medium models had a batch size of 32 and 16 respec-

tively with both having an input image size of 640

pixels. The CenterNet Resnet50 V1 FPN 512x512

and CenterNet HourGlass104 512x512 models then

had a batch size of 16 and 4 respectively with both

having an input image size of 512x512 pixels.

YOLOv5 models were chosen for their focus on

speed while the two CenterNet models were cho-

sen for their focus on performance. Mean Aver-

age Precision (mAP) at an Intersection over Union

(IoU) of 0.5 to 0.95, or simply mAP@IoU=0.5:0.95

was then recorded during training using the valida-

tion set. The same goes for mAP@IoU=0.5. Total

loss was also recorded for the training and validation

sets. Training was done on a local desktop computer

with an Nvidia GTX 1080 Ti GPU. The best and last

weights of each model were saved afterwards. The

best weights were chosen based on the highest value

of mAP@IoU=0.5:0.95 across the 300 epochs.

3.4 Model Comparison

Following Model Training, the four models were

compared with the three deep learning models (Mo-

bileNetV1, ResNet50, VGG16) from (Lopez et al.,

2021) to see if training with side view images of

the face would improve face mask detection from the

sides. This was done by comparing the accuracy of

the models in classifying the six classes of the re-

labeled FMLD dataset. Classiﬁcation accuracy was

chosen as the comparison metric because the three

models from (Lopez et al., 2021) are classiﬁcation

models while the four models of this study are ob-

ject detection models. Classiﬁcation accuracy would

be a common metric that can be measured for both

types of models. One issue in measuring the classi-

ﬁcation accuracy for the three models from (Lopez

et al., 2021) was that they were only trained to clas-

sify three classes (Medical Mask, Non Medical Mask,

No Mask) while the relabeled FMLD dataset has six

Robust Face Mask Detection with Combined Frontal and Angled Viewed Faces

465

classes as seen in Section 3.1. The eventual solution

was to consider the predictions of the three models as

correct or wrong depending on if they were able to

predict the mask type of a face correctly no matter if

the face had a frontal or side view. So for example, if

the VGG16 model gave a prediction of Medical Mask

and the ground truth label was Side - Medical Mask,

then this was considered as correct.

The validation and test sets were then combined

next in preparation for measuring the classiﬁcation

accuracy of all the seven models. This was done to

increase the number of images per class so that clas-

sifying a single image correctly or wrongly would not

affect the overall classiﬁcation accuracy too much. In-

ference was then done with each of the seven mod-

els on the combined validation and test set wherein

the class with the highest conﬁdence score from the

prediction was chosen as the predicted class for the

particular image. Accuracy per class was calculated

afterwards by dividing the number of correct predic-

tions over the total number of images per class and

then multiplying by 100 to get a percentage value.

Calculating the classiﬁcation accuracies along with

Inferencing was done with Python. The best weights

of the four models of this study were also used for

Inferencing. The PyTorch package (Paszke et al.,

2019) was used for Inferencing the YOLOv5 models

while the Tensorﬂow package (TensorFlow Develop-

ers, 2021) was used for Inferencing the two CenterNet

models.

4 RESULTS AND DISCUSSIONS

4.1 Relabeled FMLD Dataset

The completion of the dataset relabeling step pro-

duced a subdataset of images from the FMLD dataset

that was subsequently used for this study. The rela-

beled FMLD dataset therefore consists of 300 images

in total with 50 images per class. Each image only

contains one face so that the dataset can be easily bal-

anced during splitting. A breakdown of the relabeled

FMLD dataset can be seen in Table 1.

4.2 Dataset Splits

Splitting the relabeled FMLD dataset resulted in three

image sets. The training set thus contains 240 im-

ages or 80% of the total number of images. Equal

distribution of the 240 images leads to 40 images per

class. The validation set then consists of 30 images

or 10% of the total images. This resolves to 5 images

per class. Lastly, the test set also includes 30 images

Table 1: Breakdown of the relabeled FMLD dataset.

Class Number of Samples

Front - Medical Mask 50

Front - Non Medical Mask 50

Front - No Mask 50

Side - Medical Mask 50

Side - Non Medical Mask 50

Side - No Mask 50

Total 300

and also represents 10% of the total images. This too

then gives 5 images per class.

4.3 Model Training

Figure 2 depicts the graphs of the

mAP@IoU=0.5:0.95 and mAP@IoU=0.5 values

for the four models of this study during training.

It can be seen that the two CenterNet models have

higher mAP values than the YOLOv5 models and

they plateau earlier as well while the YOLOv5 mod-

els have a more gradual increase. Table 2 provides

a summary of the mAP values of the four models

wherein the best and last values are displayed along

with the epoch where they occur. The highest value

of mAP@IoU=0.5:0.95 (0.761451) was achieved by

the CenterNet Resnet50 V1 FPN 512x512 model at

Epoch 184. The YOLOv5 models have a lower value

ranging from 0.05 to 0.08 to the CenterNet models.

As for mAP@IoU=0.5, the highest value (0.994499)

was achieved by the CenterNet HourGlass104

512x512 model at Epoch 33. The YOLOv5 models

also have a lower value with a range of 0.01 to 0.02

to the CenterNet models.

Table 2: Summary of Mean Average Precision values.

mAP @ IoU = 0.5:0.95 mAP @ IoU = 0.5

Model Best Last Best Last

YOLOv5 Small

0.701899

Epoch 258

0.641859

Epoch 300

0.980495

Epoch 257

0.921729

Epoch 300

YOLOv5 Medium

0.681231

Epoch 300

0.681231

Epoch 300

0.974667

Epoch 284

0.896467

Epoch 300

CenterNet Resnet50

V1 FPN 512x512

0.761451

Epoch 184

0.725012

Epoch 300

0.99057

Epoch 124

0.97454

Epoch 300

CenterNet HourGlass104

512x512

0.758944

Epoch 112

0.707889

Epoch 300

0.994499

Epoch 33

0.912096

Epoch 300

Bold = Highest Value

The total loss curves of the YOLOv5 and Center-

Net models are shown in Figures 3 and 4 respectively.

It is evident that the CenterNet models were over-

ﬁtting during training as the validation total losses

started to ﬂuctuate at around Epoch 30. These may

also explain why the best values for mAP of the Cen-

terNet models occur at the earlier epochs and not near

the end. The YOLOv5 models on the other hand had

ICEIS 2022 - 24th International Conference on Enterprise Information Systems

466

Figure 2: Mean Average Precision graphs of the four mod-

els of this study while training.

their validation total losses decreasing up to the very

end of the 300 epochs and were not overﬁtting. Thus,

their best mAP values also occur near the tail end of

training.

Figure 3: Total Loss curves of the YOLOv5 Models.

Figure 4: Total Loss curves of the CenterNet Models.

4.4 Model Comparison

The combination of the validation and test sets re-

sulted into a set of 60 images total with 10 images

per class. These 60 images were used for the model

comparison of the seven models. Subsequently, Table

3 depicts a summary of the resulting classiﬁcation ac-

curacies per model and per class that were measured.

Each cell contains the number of correctly predicted

images, with respect to the model and class, out of the

total number of images present in the class along with

the corresponding accuracy.

For ease of readability, the six classes of the rela-

beled FMLD dataset will be abbreviated in the sub-

sequent sections. The abbreviations are namely Front

- Medical Mask (F-MM), Front - Non Medical Mask

(F-NMM), Front - No Mask (F-NoM), Side - Medical

Mask (S-MM), Side - Non Medical Mask (S-NMM),

and Side - No Mask (S-NoM).

Bearing these technicalities in mind, the Mo-

bileNetV1 model seems to be an anomaly as it per-

formed poorly. It managed to predict nine of the

ten images correctly for the F-NMM and S-NMM

classes. However, it failed to predict any of the ten

images for the F-MM and S-MM classes. Further ob-

servation revealed that the reason behind this behavior

was that the MobileNetV1 model was classifying ma-

jority of the images as Non Medical Mask hence the

high accuracy in these classes. In the end, it managed

to predict 21 of the 60 images in the combined vali-

dation and test set correctly which gives it an overall

Robust Face Mask Detection with Combined Frontal and Angled Viewed Faces

467

Table 3: Summary of Classiﬁcation Accuracies.

Model Front - Medical Mask Front - Non Medical Mask Front - No Mask Side - Medical Mask Side - Non Medical Mask Side - No Mask Overall

MobileNetV1

(Lopez et al., 2021)

0/10

Accuracy = 0%

9/10

Accuracy = 90%

1/10

Accuracy = 10%

0/10

Accuracy = 0%

9/10

Accuracy = 90%

2/10

Accuracy = 20%

21/60

Accuracy = 35%

ResNet50

(Lopez et al., 2021)

9/10

Accuracy = 90%

10/10

Accuracy = 100%

6/10

Accuracy = 60%

7/10

Accuracy = 70%

10/10

Accuracy = 100%

4/10

Accuracy = 40%

46/60

Accuracy = 76.67%

VGG16

(Lopez et al., 2021)

10/10

Accuracy = 100%

10/10

Accuracy = 100%

6/10

Accuracy = 60%

4/10

Accuracy = 40%

10/10

Accuracy = 100%

3/10

Accuracy = 30%

43/60

Accuracy = 71.67%

YOLOv5 Small

(This Study)

9/10

Accuracy = 90%

9/10

Accuracy = 90%

10/10

Accuracy = 100%

9/10

Accuracy = 90%

10/10

Accuracy = 100%

8/10

Accuracy = 80%

55/60

Accuracy = 91.67%

YOLOv5 Medium

(This Study)

10/10

Accuracy = 100%

8/10

Accuracy = 80%

10/10

Accuracy = 100%

8/10

Accuracy = 80%

10/10

Accuracy = 100%

10/10

Accuracy = 100%

56/60

Accuracy = 93.33%

CenterNet Resnet50

V1 FPN 512x512

(This Study)

10/10

Accuracy = 100%

10/10

Accuracy = 100%

9/10

Accuracy = 90%

9/10

Accuracy = 90%

10/10

Accuracy = 100%

9/10

Accuracy = 90%

57/60

Accuracy = 95%

CenterNet HourGlass104

512x512

(This Study)

10/10

Accuracy = 100%

10/10

Accuracy = 100%

10/10

Accuracy = 100%

10/10

Accuracy = 100%

9/10

Accuracy = 90%

8/10

Accuracy = 80%

57/60

Accuracy = 95%

Bold = Highest Value in Column

accuracy of 35%.

Moving to the ResNet50 model, it had a generally

acceptable performance. The model managed to pre-

dict all of the images correctly in the F-NMM and S-

NMM classes. However, accuracy decreased with the

F-NoM, S-MM, and S-NoM classes. The ResNet50

model had an accuracy of 76.67% all-in-all by pre-

dicting 46 of the 60 images correctly. It therefore

has the highest accuracy out of the three models from

(Lopez et al., 2021).

The VGG16 model also had an acceptable over-

all performance. It correctly predicted all of the im-

ages in the F-MM, F-NMM, and S-NMM classes.

This has one more perfectly predicted class than that

of the ResNet50 model but the VGG16 model had

lower accuracy in the rest of the classes particularly

in the S-MM and S-NoM classes. For this reason, it

only has an overall accuracy of 71.67% which puts

it second to the ResNet50 model. This therefore

makes the order of the most accurate models com-

ing from (Lopez et al., 2021) (from most to least)

be the ResNet50 model in ﬁrst followed by VGG16

and the MobileNetV1 in last. This is to be expected

as (Agarwal and Mittal, 2019) and (Bianco et al.,

2018) describe that the MobileNetV1 model intends

to be lightweight and have lower accuracy while the

ResNet50 and VGG16 models are deeper or have

more layers and focus more on having high accu-

racy. Furthermore, the ResNet50 model tends to have

higher accuracy than the VGG16 model because the

ResNet50 model has an architecture that is designed

to solve the vanishing or exploding gradient problem.

Proceeding to the YOLOv5 Small model, it can

be said to have higher performance when compared

to the other models. It predicted all of the images

correctly in the F-NoM and S-NMM classes while its

lowest scoring class was eight which is the S-NoM

class. The rest of the classes had nine out of the ten

images predicted correctly. It therefore has an overall

accuracy of 91.67% by predicting 55 of the 60 images

correctly.

As for the YOLOv5 Medium model, it too had

signiﬁcantly high performance compared to the other

models. All of the images in the F-MM, F-NoM, S-

NMM, and S-NoM classes were predicted correctly.

The rest of the classes had eight of the ten images

predicted as correct. Thus, it managed to predict 56

of the 60 images correctly, one more image than the

YOLOv5 Small model, giving it an overall accuracy

of 93.33%.

This leads to the CenterNet Resnet50 V1 FPN

512x512 model which had the highest overall per-

formance. It only managed to perfectly predict three

classes (F-MM, F-NMM, S-NMM) but the rest of the

classes had nine out of the ten images correctly pre-

dicted. Fifty-seven (57) out of the 60 images were

then predicted as correct resulting in an overall accu-

racy of 95%.

Lastly, the CenterNet HourGlass104 512x512

model also ties for the highest performance. The

model predicted four classes perfectly namely the F-

MM, F-NMM, F-NoM, and S-MM classes. Nine

out of the ten images for the S-NMM class were

correctly predicted while the S-NoM class had eight

correct predictions. It too managed to correctly

predict 57 of the 60 images equalling the Center-

Net Resnet50 V1 FPN 512x512 model and there-

fore also giving it an overall accuracy of 95%. The

order now of the most accurate models (from most

to least of all seven models) comes to the Center-

Net Resnet50 V1 FPN 512x512 and CenterNet Hour-

Glass104 512x512 models tied for ﬁrst, followed

by the YOLOv5 Medium model, YOLOv5 Small,

ResNet50, VGG16, and ﬁnally MobileNetV1. Again,

these are expected because the CenterNet models

are focused on performance while the YOLOv5

ICEIS 2022 - 24th International Conference on Enterprise Information Systems

468

models focus more on speed. The CenterNet and

YOLOv5 models should also have higher accuracies

than the ResNet50, VGG16, and MobileNetV1 mod-

els from (Lopez et al., 2021) because the Center-

Net and YOLOv5 models are trained on the relabeled

FMLD dataset while the ResNet50, VGG16, and Mo-

bileNetV1 models are trained on a different dataset

which is the reclassiﬁed MAFA dataset also found in

(Lopez et al., 2021).

In summary, these results support the main ratio-

nale behind this study which was to ﬁnd out if train-

ing deep learning models to also consider side view

images of the face for face mask detection can im-

prove the robustness of the front-facing face mask de-

tection models that were already trained in (Lopez

et al., 2021). It can be observed in Table 3 that

the three models from (Lopez et al., 2021) (Mo-

bileNetV1, ResNet50, VGG16) had lower accuracy

when it comes to detecting face masks from the side

of a face. An exception would be the Side - Non Med-

ical Mask class where high accuracy was surprisingly

observed. Nevertheless, the four models (YOLOv5

Small, YOLOv5 Medium, CenterNet Resnet50 V1

FPN 512x512, CenterNet HourGlass104 512x512) of

this study that were trained to also consider side view

images of the face had indeed gained an improve-

ment in accuracy when detecting face masks from the

side of a face. Comparing the best overall accuracy

from the models in (Lopez et al., 2021) (Resnet50

with 76.67%) with the models of this study (Center-

Net Resnet50 V1 FPN 512x512 and CenterNet Hour-

Glass104 512x512 with 95%), an overall improve-

ment of ≈ 20% in accuracy was noticed.

5 CONCLUSION AND

RECOMMENDATIONS

To conclude, the goal of this study was to improve

upon the robustness of the deep learning models that

were already created in (Lopez et al., 2021) for face

mask detection. These models were intended to aid

in monitoring compliance by checking if a person is

wearing a mask or not, and if so, check if the mask is

medically approved or not. They were limited how-

ever to only being trained in detecting face masks of

those who look directly into the camera. Thus im-

provements were sought after by ﬁnding out if train-

ing new deep learning models to also consider side

view images of the face can indeed improve upon

the robustness of the front-facing face mask detec-

tion of the models from (Lopez et al., 2021). In do-

ing so, dataset relabeling was performed resulting in

the relabeled FMLD dataset with 300 images in to-

tal which are distributed equally across six classes

namely Front - Medical Mask, Front - Non Medical

Mask, Front - No Mask, Side - Medical Mask, Side

- Non Medical Mask, and Side - No Mask. The rela-

beled FMLD dataset was then split into train, valida-

tion, and test image sets. Four deep learning models

were then trained on the training set of images namely

the YOLOv5 Small, YOLOv5 Medium, CenterNet

Resnet50 V1 FPN 512x512, and CenterNet Hour-

Glass104 512x512 models. Afterwards, these four

models were compared with the three models (Mo-

bileNetV1, ResNet50, VGG16) from (Lopez et al.,

2021) by measuring their classiﬁcation accuracies on

the combined validation and test set of the relabeled

FMLD dataset. Results show that the four models of

this study that were trained to also consider side view

images of the face exhibited improvements in accu-

racy when detecting face masks from the side of a

face. An overall increase of ≈ 20% was observed with

the best models of this study against the best models

from (Lopez et al., 2021) in classifying frontal and

side view images. To this end, the goal of this study

was achieved and it can therefore be said that the four

models of this study are more robust than the models

from (Lopez et al., 2021) when it comes to face mask

detection.

As for future improvements to this study, possi-

ble recommendations can include the creation of a

larger dataset containing more images since the re-

labeled FMLD dataset of this study is relatively small

with only 300 images in total for six classes leading

to 50 images per class. Incorporating ethnicity and/or

time of day can also be added to this larger dataset. A

more exhaustive list of deep learning models can be

further benchmarked as well to ﬁnd the best perform-

ing one. Another possible route would be to examine

the effects of the different data augmentations that are

available for use with the four models of this study as

they were mainly left at the default settings. Lastly, at-

tempting to produce a real-world application or setup

by extending the methodology of this study serves as

an additional possible avenue for continuation.

REFERENCES

Agarwal, T. and Mittal, H. (2019). Performance compar-

ison of deep neural networks on image datasets. In

2019 Twelfth International Conference on Contempo-

rary Computing (IC3), pages 1–6.

Batagelj, B., Peer, P.,

Struc, V., and Dobri

sek, S. (2021).

How to correctly detect face-masks for covid-19 from

visual information? Applied Sciences, 11(5).

Bianco, S., Cadene, R., Celona, L., and Napoletano, P.

(2018). Benchmark analysis of representative deep

Robust Face Mask Detection with Combined Frontal and Angled Viewed Faces

469

neural network architectures. IEEE Access, 6:64270–

64277.

Choudhary, O. P., Priyanka, Singh, I., and Rodriguez-

Morales, A. J. (2021). Second wave of COVID-19

in India: Dissection of the causes and lessons learnt.

Travel Medicine and Infectious Disease, 43:102126.

Department of Health (Philippines) (2022). COVID-19

Tracker.

C¸ elik, I., Saatc¸i, E., and Ey

ubo

glu, A. F. (2020). Emerg-

ing and reemerging respiratory viral infections up

to Covid-19. Turkish Journal of Medical Sciences,

50(SI-1):557–562.

Fauci, A. S. (2001). Infectious Diseases: Considerations

for the 21st Century. Clinical Infectious Diseases,

32(5):675–685.

Ge, S., Li, J., Ye, Q., and Luo, Z. (2017). Detecting masked

faces in the wild with lle-cnns. In 2017 IEEE Con-

ference on Computer Vision and Pattern Recognition

(CVPR), pages 426–434.

Huang, J., Rathod, V., Sun, C., Zhu, M., Korattikara, A.,

Fathi, A., Fischer, I., Wojna, Z., Song, Y., Guadar-

rama, S., and Murphy, K. (2017). Speed/accuracy

trade-offs for modern convolutional object detectors.

In 2017 IEEE Conference on Computer Vision and

Pattern Recognition (CVPR), pages 3296–3297.

Inter-Agency Task Force for the Management of Emerging

Infectious Diseases (2021). Omnibus Guidelines on

the Implementation of Community Quarantine in the

Philippines as of September 23, 2021.

Jocher, G., Stoken, A., Chaurasia, A., Borovec, J.,

NanoCode012, TaoXie, Kwon, Y., Michael, K.,

Changyu, L., Fang, J., V, A., Laughing, tkianai,

yxNONG, Skalski, P., Hogan, A., Nadar, J., imyhxy,

Mammana, L., AlexWang1900, Fati, C., Montes, D.,

Hajek, J., Diaconu, L., Minh, M. T., Marc, albinx-

avi, fatih, oleg, and wanghaoyang0106 (2021). ul-

tralytics/yolov5: v6.0 - YOLOv5n ’Nano’ models,

Roboﬂow integration, TensorFlow export, OpenCV

DNN support.

Lazaro, R. E., Tupas, E., Cabrera, R., and Villanueva, R. E.

(2020). Wearing masks now mandatory. Philstar.com.

Liu, S., Qi, L., Qin, H., Shi, J., and Jia, J. (2018). Path ag-

gregation network for instance segmentation. In 2018

IEEE/CVF Conference on Computer Vision and Pat-

tern Recognition, pages 8759–8768.

Loey, M., Manogaran, G., Taha, M. H. N., and Khalifa, N.

E. M. (2021). Fighting against covid-19: A novel deep

learning model based on yolo-v2 with resnet-50 for

medical face mask detection. Sustainable Cities and

Society, 65:102600.

Lopez, V. W. M., Abu, P. A. R., and Estuar, M. R. J. E.

(2021). Real-time face mask detection using deep

learning on embedded systems. In 2021 3rd Interna-

tional Conference on Electrical, Control and Instru-

mentation Engineering (ICECIE), pages 1–7.

Nowrin, A., Afroz, S., Rahman, M. S., Mahmud, I., and

Cho, Y.-Z. (2021). Comprehensive review on face-

mask detection techniques in the context of covid-19.

IEEE Access, 9:106839–106864.

Paszke, A., Gross, S., Massa, F., Lerer, A., Bradbury, J.,

Chanan, G., Killeen, T., Lin, Z., Gimelshein, N.,

Antiga, L., Desmaison, A., Kopf, A., Yang, E., De-

Vito, Z., Raison, M., Tejani, A., Chilamkurthy, S.,

Steiner, B., Fang, L., Bai, J., and Chintala, S. (2019).

Pytorch: An imperative style, high-performance deep

learning library. In Wallach, H., Larochelle, H.,

Beygelzimer, A., d'Alch

e-Buc, F., Fox, E., and Gar-

nett, R., editors, Advances in Neural Information Pro-

cessing Systems 32, pages 8024–8035. Curran Asso-

ciates, Inc.

Pedregosa, F., Varoquaux, G., Gramfort, A., Michel, V.,

Thirion, B., Grisel, O., Blondel, M., Prettenhofer,

P., Weiss, R., Dubourg, V., Vanderplas, J., Passos,

A., Cournapeau, D., Brucher, M., Perrot, M., and

Duchesnay, E. (2011). Scikit-learn: Machine learning

in Python. Journal of Machine Learning Research,

12:2825–2830.

Petersen, E., Petrosillo, N., Koopmans, M., Beeching,

N., Di Caro, A., Gkrania-Klotsas, E., Kantele, A.,

Kohlmann, R., Koopmans, M., Lim, P.-L., Markotic,

A., L

opez-V

elez, R., Poirel, L., Rossen, J., Stien-

stra, Y., and Storgaard, M. (2018). Emerging infec-

tions—an increasingly important topic: review by the

emerging infections task force. Clinical Microbiology

and Infection, 24(4):369–375.

Shereen, M. A., Khan, S., Kazmi, A., Bashir, N., and Sid-

dique, R. (2020). Covid-19 infection: Emergence,

transmission, and characteristics of human coron-

aviruses. Journal of Advanced Research, 24:91–98.

Skalski, P. (2019). Make Sense.

https://github.com/SkalskiP/make-sense/.

TensorFlow Developers (2021). Tensorﬂow. Spe-

ciﬁc TensorFlow versions can be found

in the ”Versions” list on the right side of

this page. See the full list of authors ”htt

ps://github.com/tensorﬂow/tensorﬂow/graphs/contr

ibutors” on GitHub.

Wang, C.-Y., Mark Liao, H.-Y., Wu, Y.-H., Chen, P.-Y.,

Hsieh, J.-W., and Yeh, I.-H. (2020). Cspnet: A new

backbone that can enhance learning capability of cnn.

In 2020 IEEE/CVF Conference on Computer Vision

and Pattern Recognition Workshops (CVPRW), pages

1571–1580.

World Health Organization (2020). Mask use in the context

of COVID-19: interim guidance, 1 December 2020.

Technical documents.

Xu, R., Lin, H., Lu, K., Cao, L., and Liu, Y. (2021). A for-

est ﬁre detection system based on ensemble learning.

Forests, 12:217.

Yang, S., Luo, P., Loy, C. C., and Tang, X. (2016). Wider

face: A face detection benchmark. In 2016 IEEE Con-

ference on Computer Vision and Pattern Recognition

(CVPR), pages 5525–5533.

Zhou, X., Wang, D., and Kr

ahenb

uhl, P. (2019). Objects as

points. In arXiv preprint arXiv:1904.07850.

ICEIS 2022 - 24th International Conference on Enterprise Information Systems

470
