An Iterated Local Search for a Pharmaceutical Storage Location

Assignment Problem with Product-cell Incompatibility and Isolation

Constraints

Nilson F. M. Mendes

, Beatrice Bolsi

and Manuel Iori

Department of Sciences and Methods for Engineering, University of Modena and Reggio Emilia, Reggio Emilia, Italy

Keywords:

Storage Allocation, Healthcare Supply Chain, Iterated Local Search, Warehouse Management.

Abstract:

In healthcare supply chain, centralised warehouses are used to store large amounts of products close to hos-

pitals and pharmacies in order to avoid shortages and reduce storage costs. To reach these objectives, the

warehouses need to have efﬁcient order retrieval and dispatch procedures, as well as a storage allocation pol-

icy able to guarantee the safe keeping of items. Considering this scenario, we present a Storage Location

Assignment Problem with Product-Cell Incompatibility and Isolation Constraints, that models the targets and

restrictions of a storage policy in a pharmaceutical product warehouse. In this problem, we aim to minimise the

total distance travelled by the order pickers to recover all products required in a set of orders. We propose an

Iterated Local Search algorithm to solve the problem, and present numerical experiments based on simulated

data. The results show a relevant improvement with respect to a greedy full turnover procedure commonly

adopted in real life operations.

1 INTRODUCTION

Healthcare services are strongly sensible to equip-

ment or medicine shortages, as they could cause atten-

dance delays and interruptions and consequently put

patient lives at risk. Traditionally, the main approach

to avoid this problem was the use of high inventory

levels and constant item replenishment (Uthayakumar

and Priyan, 2013) (Aldrighetti et al., 2019). How-

ever, this solution has been often considered expen-

sive and hard to be managed, as it requires large dedi-

cated spaces into facilities and workload of healthcare

personnel (Volland et al., 2017).

Nowadays, more efﬁcient approaches have been

adopted, as acquisitions through Group Purchasing

Organisations (GPO) and wholesalers. One of the

most successful approaches is the sharing of cen-

tralised warehouses to store together products to be

distributed to different customers located in the same

geographical area. Centralised warehouses are par-

ticularly useful because they allow healthcare facili-

ties to share a common structure to store a large vol-

ume of products and receive them quickly when they

https://orcid.org/0000-0002-4924-7341

https://orcid.org/0000-0002-6968-8689

https://orcid.org/0000-0003-2097-6572

are needed. This enables a constant material ﬂow,

a reduction in the personnel costs, a reduced storage

space in the customer facility and a lower work bur-

den over healthcare workers.

These advantages are highly dependent on the

warehouse reliability and capability of delivering the

ordered products in the short terms deﬁned by the

customers. This reliability is, in turn, a direct result

of an efﬁcient warehouse internal organisation, which

requires a good storage location policy.

A storage location policy is a general strategy to

assign Stock Keeping Units (SKU) to storage posi-

tions inside a warehouse. It aims at optimising a met-

ric (e.g. total time or distance travelled to store and

retrieve SKUs, congestion, space utilisation, pickers

ergonomic), while considering issues like product re-

allocations efforts, demand oscillation, picking prece-

dence and storage restrictions.

The metric commonly adopted to evaluate the

quality of these policies is the distance travelled by

the pickers to retrieve all products in a list of orders.

This metric is particularly relevant because picking

operations accounts for around 35% of the total ware-

house operational costs (Wang et al., 2020) and the

time/energy spent to reach a product is a waste of re-

sources that must be minimised. In other contexts, the

Mendes, N., Bolsi, B. and Iori, M.

An Iterated Local Search for a Pharmaceutical Storage Location Assignment Problem with Product-cell Incompatibility and Isolation Constraints.

DOI: 10.5220/0011039000003179

In Proceedings of the 24th International Conference on Enterprise Information Systems (ICEIS 2022) - Volume 1, pages 17-26

ISBN: 978-989-758-569-2; ISSN: 2184-4992

evaluation may also consider issues like congestion,

picker ergonomic, product storage conditions and to-

tal space utilisation, that can also lower the warehouse

operation efﬁciency.

In this paper, we describe a problem originated

from a real life operation of a pharmaceutical prod-

uct distributor. It consists in the optimisation of

a dedicated storage allocation policy in a picker-to-

parts warehouse, i.e., a warehouse where each prod-

uct has a ﬁxed/dedicated position and pickers travel

until product location to retrieve order items. Most

speciﬁcally, we deal with a Storage Location Assign-

ment Problem with Product-Cell Incompatibility and

Isolation Constraints (SLAP-PCIIC). In this prob-

lem, some products cannot be assigned to some lo-

cations due to reasons like refrigeration or ventilation

(product-cell incompatibility), and some other prod-

ucts need to be isolated from the unconstrained ones

due to toxicity or contamination concerns (isolation).

Furthermore, the problem considers a ﬂexible ware-

house layout conﬁguration, with shelves not neces-

sarily grouped on blocks or in a unique pavilion.

This study provides as main contribution an Iter-

ated Local Search (ILS) algorithm, that takes a set of

orders and a warehouse layout in input and returns a

list of assignments of products to locations that min-

imises the total distance travelled to fulﬁll the orders.

The remainder of the paper is organised as fol-

lows: in Section 2, a concise literature review is pre-

sented; Section 3 provides a detailed problem descrip-

tion; Section 4 describes the ILS algorithm and the

data processing done before starting the optimisation

algorithm; Section 6 describes the numeric experi-

ments carried out, results are presented and then the

conclusions are drawn in Section 7.

2 LITERATURE REVIEW

The Storage Location Assignment Problem (SLAP) is

a generalisation of the well known Assignment Prob-

lem in which the objective function is a complex func-

tion that usually depends on several factors, like ware-

house layout, picking policy, picker routing policy

and order batching (Dijkstra and Roodbergen, 2017).

It aims at optimising some warehouse metrics like

shipping time, equipment downtime, on time deliv-

ery, delivery accuracy, product damage, storage cost,

labour costs, throughput, turnover and picking pro-

ductivity (Staudt et al., 2015)(Reyes et al., 2019). The

two most common metrics in the literature are picking

travel time and travel distance (Reyes et al., 2019),

which both require to solve special cases of either

the Travelling Salesman Problem (TSP) or the Vehicle

Routing Problem (VRP), according to the presence of

picker capacity constraints or to the simultaneous use

of multiple pickers. Using the picker travel distance

has as advantage an easier evaluation, as it does not

requires to deal with issues like congestion and items

handling/sorting. Additionally, there are no concerns

about picker average speed or searching and handling

delays.

In this context, several methods to optimise or-

der picking routes have been proposed, both inside

SLAP variants studies or in independent researches.

As pointed out in (Dijkstra and Roodbergen, 2017),

routing problems in warehouses can be seen as spe-

cial case of the Steiner Travelling Salesman Prob-

lem, that in some layouts can be solved to optimal-

ity ((Ratliff and Rosenthal, 1983), (Lu et al., 2016)

and (Scholz et al., 2016), (Cambazard and Catusse,

2018)) but in general layouts is mostly solved us-

ing heuristics ((De Santis et al., 2018), (Chen et al.,

2019), (Roodbergen and Koster, 2001), (Theys et al.,

2010)). The exact methods cited, however, are used

to solve problems with already deﬁned warehouse al-

locations (as can be seen also in (Gu et al., 2007) and

(Reyes et al., 2019)) and they are mostly algorithms

based on a graph theoretic algorithm for single-block

warehouses (Lu et al., 2016). A noticeable exception

for a joint storage assignment and routing exact op-

timisation strategy is presented in (Bola

nos Zu

niga

et al., 2020), but the proposed model reaches optimal-

ity only on small instances.

It is important to notice that the routing method

efﬁciency is inﬂuenced by the warehouse layout. In

both SLAP and picker routing problems, the ware-

houses can have a single block or multiple blocks. A

block is deﬁned as a set of parallel shelves with tight

corridors among them (aisles), from where it is pos-

sible to pick products located in the two shelves at

their borders. The connection between these corridors

(and consequently between different pairs of shelves)

is called cross-aisle.

In the same sense, SLAP literature cites frequently

two types of picking policies: picker-to-parts and

parts-to-picker. In a picker-to-parts warehouse, as

those considered in SLAP-PCIIC, the picker receives

an item list and visits each item position and transport

the items to an accumulation/expedition point.

Once the evaluation method is deﬁned and the pa-

rameters above are set, the main decision in SLAP is

the storage policy. Among the most relevant policies,

we can cite: random storage, dedicated storage and

group based storage (Wang et al., 2020)(

Zulj et al.,

2018).

A random storage policy allocates products in

empty positions inside the warehouse using a random

ICEIS 2022 - 24th International Conference on Enterprise Information Systems

criteria (e.g. closest open location), without includ-

ing any further complexity in the decision process.

In opposite way, dedicated storage ranks the prod-

ucts according to some criteria - popularity, turnorver,

Cube per Order Index (COI) - putting the best ranked

products close to the accumulation/expedition loca-

tions. Finally, class based storage separates products

in groups and assigns the most interesting groups to

places close to the accumulation/expedition positions,

without ﬁxing a speciﬁc position for each product in

the set. The SLAP-PCIIC uses a dedicated storage

policy where the metric is the total travelled distance.

Several studies report that random storage policies

lead to a better space utilisation, due to frequent reuse

of storage positions, but raise the travelled distances

to pick the products (Muppani and Adil, 2008b) and

require higher searching times or control over product

locations (Quintanilla et al., 2015). The distance, on

other hand, is successfully reduced in dedicated stor-

age policy, but this policy raises re-allocations costs

(because of demand ﬂuctuations) and space utilisa-

tion, as empty spaces can be reserved to products not

currently available. It is stated that class based poli-

cies (or zoning) is a balance between random and ded-

icated storage strategies, but it requires more strategic

efforts to deﬁne the number of groups and their posi-

tions on the warehouse.

A dedicated storage policy is considered in (Dijk-

stra and Roodbergen, 2017), in which exact distance

evaluations are used to deﬁne the product assignment.

(Guerriero et al., 2013) proposes a non-linear model

and an ILS to address a storage allocation problem in

a multi-level warehouse considering the compatibil-

ity between product classes. (Wang et al., 2020) de-

parts from an S-shape routing policy and multi-level

storage to create a two-phase algorithm to assign the

items to locations, and use a multi-criteria approxima-

tion to evaluate the solutions.

Class based policies are studied in (Rao and Adil,

2013), (Muppani and Adil, 2008b) and (Muppani and

Adil, 2008a). In (Rao and Adil, 2013), class bound-

aries are deﬁned based on the picking travel distance

in a two-block and low-level warehouse where return-

ing routing policy is used. The second uses a Simu-

lated Annealing algorithm to deﬁne classes and assign

locations to them inside a warehouse considering si-

multaneously space and picking costs.

3 PROBLEM DESCRIPTION

The SLAP can be shortly described as follows: given

a set P of products to be stored, a tuple ω =

,...,O

) of (non necessarily distinct) orders, in

which an order O

⊆ P is the subset of products to

be picked up by a picker in a single route, and a set

L of locations in a warehouse, deﬁne an assignment

(i.e., an injective function) g : P → L in which an eval-

uation function z = v(g,ω), to be described next, is

minimised. The warehouse is received in input in the

form of a graph, and the travel distance d

i j

between

any pair of locations i, j ∈ L is computed by invoking

the Dijkstra algorithm.

In the SLAP-PCIIC, the SLAP variant described

here, due to incompatibility and isolation constraints,

g is, on the one hand, relaxed to a possible partial

assignment, but on the other hand it is subjected to

the constraints of the location-product eligibility, i.e.,

each product is assigned to at most a single location

and each location receives at most a single product

while respecting the incompatibility and (strong) iso-

lation constraints. In this framework, v(g,ω) is de-

ﬁned as the sum of minimum travelled distance to

pick all the products in each order (designated by

D(g,ω)), plus the non negative penalties for non de-

sirable or missing allocations, (designated by Φ(g)).

Notice that if all products are allocated, then we have

no contribution in the penalty Φ caused by missing

allocations, meaning that the lack of product assign-

ment to locations is highly deprecated. Following

the company operational rules, it is assumed that the

warehouse uses a picker-to-parts picking policy (the

picker visits the products locations) and orders split-

ting/batching are not allowed, making each order an

individual and independent route. These assumptions

make it possible to decompose the distance D(g,ω) as

the sum of the minimal travelling distances to pick the

products in each order O in the ω tuple, designated

by d(g,O). With these considerations, and indicat-

ing with G the set of relaxed admissible assignments

g : P → L, the SLAP-PCIIC objective function can be

described as:

z = min

g∈G

∑

i=1

d(g,O

) + Φ(g) (1)

It can be noticed that to evaluate each one of the

d(g,O

) it is necessary to solve another optimisation

problem, more speciﬁcally a variant of the TSP that

calls for the minimization of the travelled distance.

Namely, if there is a single accumulation/expedition

point, each product is assigned to (at most) a unique

location and O

= {p

,..., p

} ⊆ O ⊆ P is the re-

quested order deprived of those products lacking of

location, then d(g,O) is the minimum distance to de-

part from the accumulation/expedition point, visit all

the locations (g(p

),...,g(p

)) in the best possible

sequence and then come back. Conversely, in the

SLAP-PCIIC we allow the presence of more than one

An Iterated Local Search for a Pharmaceutical Storage Location Assignment Problem with Product-cell Incompatibility and Isolation

Constraints

accumulation/expedition point, so the picker can de-

part from any of these points and return to another

if this operation reduces the total distance travelled

D(g,ω). The algorithms can be easily adapted to deal

with the case in which the expedition points are, in-

stead, ﬁxed.

Deﬁning an optimal picker routing in the scenario

above is relatively simple if the warehouse is organ-

ised in blocks of identical and parallel shelves. How-

ever, in the SLAP-PCIIC, the shelves can have dif-

ferent sizes, cell quantities, orientations and position-

ing and also be located in different pavilions. To deal

with this setting, a regular distance matrix containing

the distances between each pair of locations is consid-

ered as the input of the distance minimisation method,

disregarding any further information about the ware-

house organisation.

The second part of the objective function, the

penalty value Φ(g), is the sum of two terms: the num-

ber of products not assigned to any location Φ

(g)

and the number of undesired allocations Φ

(g). In

this sense, the possible conﬁgurations of the function

g are limited by a set F of assignment incompatibil-

ities and a set I of isolation constraints. Each as-

signment incompatibility f ∈ F is a hard constraint

(i.e., it must be strictly respected) composed by a tu-

ple of three values (p,n,c) representing a product p,

the nature n of the incompatible location (cell, shelf

or pavilion) and the code c of the incompatible loca-

tion, respectively. For instance, the incompatibility

,“shel f ”, k

) deﬁnes that product p

cannot be al-

located on shelf k

An isolation constraint is based on the product

classiﬁcation. Given a set T of types, representing

the most relevant product characteristic to the storage

(toxic, radioactive, humid, etc...), an isolation con-

straint ι ∈ I is a tuple of three values (t, n, s) speci-

fying that products of type t ∈ T should be allocated

in an isolated n ∈ {“cell”, “shel f ”,“pavilion”} with

an enforcement s ∈ {“weak”,“strong”}. The enforce-

ment s deﬁnes if the isolation is a hard constraint or

can be relaxed with a penalty.

4 ITERATED LOCAL SEARCH

In this section, we describe the ILS algorithm that we

developed to solve the SLAP-PCIIC. The ILS ﬁrst in-

vokes a constructive algorithm to generate an initial

solution, and then attempts improving the solution by

means of three different neighbourhood structures.

The constructive algorithm is divided into two

phases (see Algorithm 1). In the ﬁrst phase (lines

from 6 to 23), it assigns locations to products with-

out isolation constraints (i.e., products that are not

present in any tuple ι ∈ I) or with isolation constraints

containing an enforcement s = “weak”. In the sec-

ond phase (lines from 25 to 40), it assigns locations

to isolated products, according to their types. This

procedure favors the allocation of a greater number of

products (i.e., it helps controlling Φ(g) value), since

the constrained products are fewer and could give rise

to a large number of unusable locations.

Initially, all the products are sorted by descending

order of popularity, i.e., the products more frequently

required are put ﬁrst, and those less frequently af-

ter, where popularity is calculated from the tuple of

orders ω. Similarly, the storage locations are sorted

by distance from the closest accumulation/expedition

point. Then, the most popular product is assigned to

the closest empty location, if this assignment is al-

lowed. When, instead, an assignment is forbidden,

the algorithm tries iteratively the next location, until

an allowed position is found or the loop reaches the

last position. If a product belongs to a strongly iso-

lated type, it is not assigned during this phase.

In the second phase of the constructive algorithm,

all the products belonging to a strongly isolated type

are divided by type (line 25 in Algorithm 1) and,

similarly, the warehouse locations that are isolated

are grouped by level (block, shelf or cell), in line

26. The allocation is done according to the struc-

ture size, starting from the isolated blocks and ﬁnish-

ing with the isolated cells. At each step, the product

types that have the corresponding isolation level are

selected and sorted by decreasing order of frequency.

Then, each type is assigned to the isolated area where

it is possible to maximise the total frequency, with-

out worrying with the internal assignment optimisa-

tion. After each step, the list of available positions

and products is updated. When all the available iso-

lated spaces are occupied or all the products are as-

signed, the algorithm ends.

It is important to notice that it may be impossible

to assign all the products to the locations in the ware-

house due to incompatibility and isolation constraints.

This can happen even when the number of available

locations is higher than the number of products. Fur-

thermore, the constructive algorithm, as a heuristic

method, may be not able to ﬁnd an initial valid assign-

ment even when it exists. In both the cases mentioned,

the solution evaluation procedure penalises the objec-

tive function according to the number of products not

assigned (i.e., the value of Φ

(g)).

A valid solution, however, can still present one of

the side effects of allocating groups of isolated prod-

ucts together in the warehouse. The ﬁrst is assigning

relatively good positions to several products with a

ICEIS 2022 - 24th International Conference on Enterprise Information Systems

Algorithm 1: Greedy algorithm.

1: g ←

0  Start with an empty assignment

2: L∗ ← distanceSort(L)  Locations are ordered by distance

3: A ← L∗  Available locations

4: P ← sortByFrequence(P)

5:  First part of greedy algorithm

6: for each p ∈ P do  For each product in P

7: if isStronglyIsolated(p) then

8: continue

9: end if

10: l ← f irstAvailable(A)

11: while true do

12: if l == null then

13: break

14: end if

15: if isForbidden(l, p) then

16: l ← nextAvailable(A)

17: continue

18: end if

19: g ← g ∪ (p, l)

20: A ← A\{l}

21: break

22: end while

23: end for

24:  Second part of greedy algorithm

25: Λ ← stronglyIsolatedProductsByType(P)

26: Ψ ← availableIsolatedStructures(A)

27: µ ← allocateOnIsolatedBlock(Y, Ψ)

28:  First allocation. Assigns products isolated by block

29: g ← g ∪ µ

30: Ψ ← updateAvailableIsolateStructures(Ψ,µ)

31: Λ ← updatestronglyIsolatedProductsByType(µ,P)

32:  Second allocation. Assigns products isolated by shelf

33: µ ← allocateOnIsolatedShel f (Y,Ψ)

34: g ← g ∪ µ

35: Ψ ← updateAvailableIsolateStructures(Ψ,µ)

36: Λ ← updatestronglyIsolatedProductsByType(µ,P)

37:  Third allocation. Assigns products isolated by cells

38: µ ← allocateOnIsolatedCell(Y,Ψ)

39: g ← g ∪ µ

40: Ψ ← updateAvailableIsolateStructures(Ψ,µ)

low number of requests due to the existence of some

very popular products in the set, that are responsible

of a skewed popularity of that group. The second ef-

fect is approximately the opposite, i.e., very popular

products can be allocated in bad positions due to the

fact that average popularity is low for their set. Both

these problems are similar to those that are reported

in class or zone based storage location problems (Rao

and Adil, 2013) (Muppani and Adil, 2008b).

After the greedy algorithm creates an initial solu-

tion, its objective function value is calculated accord-

ing to the procedure described in Section 4.1. The ILS

heuristic enters then in a loop that explores the solu-

tion space (lines 4 to 25 of Algorithm 2). This loop is

composed by three neighbourhood structures that are

combined as a single local search, and a perturbation

method.

In a loop iteration, each neighbourhood structure

evaluates a small set of neighbours of the current so-

lution (denoted by g) and picks the one with lowest

objective function value (thus using a best improve-

ment criteria). The best solution in the loop, denoted

by g

, is then compared with the best global solu-

tion, g

∗

, and every time g

is better, it is assigned to

∗

and the number of iterations without improvement

(line 22) is reset. Finally, the iteration closes with a

perturbation of g

∗

. The loop stops if the number of

iterations without improvement reaches the value of

the input parameter iterations without improvements

(IWI).

To avoid non signiﬁcant improvements, we as-

sume that an assignment g

is better than an assign-

ment g

if and only if the objective function value of

is at least 0.1% lower than that of g

(i.e., the ratio

of between difference of solution values, v(g

,O) −

v(g

,O), and the old solution value v(g

,O) must be

smaller than δ = −0.001).

Algorithm 2: ILS algorithm.

1: g

∗

← initialS olution(L, P)  Get greedy assignment

2: g ← g

∗

3: nonI mprovingIter ← 0

4: while nonImprovingIterations < IWI do

5: g

← g  Initialize the best solution on loop

6: g

← mostFrequentLocalNeighbourhood(g)

7: if

v(g

,O)−v(g

,O)

v(g

,O)

≥ δ then

8: g

← g

9: end if

10: g

← insideShel f LocalNeighbourhood(g)

11: if

v(g

,O)−v(g

,O)

v(g

,O)

≥ δ then

12: g

← g

13: end if

14: g

← insidePavilionNeighbourhood(g)

15: if

v(g

,O)−v(g

,O)

v(g

,O)

≥ δ then

16: g

← g

17: end if

18:  Update best global solution

19: nonImprovingIter ← nonImprovingIter + 1

20: if

v(g

∗

,O)−v(g

,O)

v(g

∗

,O)

≥ δ then

21: g

∗

← g

22: nonImprovingIter ← 0

23: end if

24: g ← perturbation(g

∗

)

25: end while

All the neighbourhood structures used in the lo-

cal search are simple location swaps between two

products. The ﬁrst neighbourhood (mostFrequent-

LocalNeighbourhood) consists in swapping the as-

signments of two products belonging to the subset

of 20% most required products. The second (in-

sideShelfNeighbourhood) consists of swapping the

assignments of two products assigned to locations

in the same shelf, working as an intensiﬁcation of

the search. The third neighbourhood (insidePavilion-

An Iterated Local Search for a Pharmaceutical Storage Location Assignment Problem with Product-cell Incompatibility and Isolation

Constraints

Neighbourhood) is a wider search, in which pairs of

products assigned to the same pavilion have their lo-

cations swapped.

The neighbourhood structures work following the

same steps: randomly choose two products, check if

the swap between these products is valid, evaluate the

change in objective function and store the best solu-

tion found.

To check the swap validity, three rules are used:

(1) all swaps that assign a product to a forbidden

position are not allowed; (2) no swaps are allowed

between a product belonging to a strongly isolated

type and a product not belonging to a strongly iso-

lated type; (3) no swaps between products of differ-

ent types are allowed. It is important to notice that

validity does not mean feasibility. In fact, while the

two ﬁrst rules were created to avoid infeasible solu-

tions in the search, the third was created to ﬁlter the

moves in order to avoid recalculating the penalties re-

lated to weak isolated types. It can be noticed that the

second and third rules are complementary (the third

makes the second redundant). In the numeric tests we

tested two algorithm versions, one with rules (1) and

(2) (type-free swap policy), and the other with rules

(1) and (3) (same-type swap policy).

To evaluate the solution after a swap, we reevalu-

ate the distances of the routes affected by that swap

and the total of products with weak isolation con-

straints allocated in altered areas. As the number of

swaps performed during the algorithm execution is

huge and the number of orders can easily reach some

thousands, the procedures to evaluate them must have

a strong performance.

After all neighbourhoods have been explored and

the global best solution has possibly been updated,

a perturbation is performed over the best global so-

lution. It consists in

|P|

/20 unconstrained and valid

swaps, chosen randomly and applied in a loop. The

resulting solution is then used as the initial solution in

the next ILS iteration.

4.1 Solution Evaluation

To evaluate the routing distance, we propose a combi-

nation of two ideas: the former is using different TSP

algorithms according to the size of the instance and

the latter is to keep a mapping of routes that passes

from each position to recalculate only picking dis-

tances of routes containing products involved in the

swap. In the latter case, initially the algorithm re-

trieves all the routes affected and controls if a route

passes from both locations where the products are cur-

rently allocated. If the route has both locations on it,

the reevaluation is useless (because the set of loca-

tions to be visited does not change), otherwise it is

evaluated with the new location replacing the old one.

The evaluation is controlled by the parameter

T SP(α, β). In this parameter, the constants α and β

are two integers representing the order size thresh-

olds used to choose each algorithm method for esti-

mating the minimum distance to visit the product lo-

cations in a route. Let |O| be the number of items

in an order O in the tuple ω, if |O| ≤ α an exhaus-

tive search is run (i.e., all the possibilities are tested

and then the distance found is optimal). Otherwise, if

α < |O| ≤ β, a closest neighbour algorithm is used

to initialise the route and a subsequent quick local

search is performed. In this local search, (|O| − 1)

swaps among two consecutive locations are tested in

(|O| − 1) iterations (always departing from the ﬁrst to

the last product) and the current solution is updated

when the swap reduces the smaller distance. Finally,

if |O| > β, just the closest neighbour heuristic is used.

The route evaluation method described above

presents a quadratic complexity, as the exponential

time approach is limited according to the number of

visited points. Although it does not guarantee an op-

timal route, it is better suited to our purpose of using

non block-based warehouse layouts than algorithms

based on the method proposed in (Ratliff and Rosen-

thal, 1983).

In order to explain how the evaluation of penalties

is done by breaking weak isolation constraints, we use

Algorithm 3 below. This pseudo code shows the pro-

cess for shelves, but it is practically identical for cells

and pavilions.

Algorithm 3: Isolation penalty evaluation after a swap.

1: totalPenalty ← 0

2: S ← allShelves(L)

3: T

← WeakIsolationTypes()

4: P

← productsAllocated(g, s) ∀s ∈ S

5: for each s ∈ S do

6: P

← {p | p ∈ P

,type(p) ∈ T

}

7: P

← {p | p ∈ P

,type(p) /∈ T

}

8: T

← {type(p) | p ∈ P

}

9:  Group products with isolation constraints by type

10: H

← {p ∈ P

|type(p) = t} ∀t ∈ T

11: if |P

| = 0 or |distinct(T

)| = 1 then

12: continue

13: end if

14: penalty ← 0

15: x ← max

t∈T

(|H

|)  Type with max cardinality

16: r ← x

17: if |P

| ≥ |P

| then

18: penalty ← W

pen

∗ |P

/|P

19: else

20: penalty ← W

pen

∗ (|P

+ r)/|P

21: end if

22: totalPenalty ← totalPenalty + penalty

23: end for

ICEIS 2022 - 24th International Conference on Enterprise Information Systems

First of all, the algorithm gets all products allo-

cated and groups them by shelves (line 4). For each

shelf, products are grouped by type (line 9) and then

the algorithm counts the number of different product

types assigned to the shelf. If there is only one type

assigned to the shelf or if no assigned product has

an isolation constraint ι ∈ I|n = “shel f ” (see isola-

tion constraint deﬁnition on Section 3), no penalty is

applied (lines 11 to 13). Otherwise, the actual penalty

evaluation is performed (lines 14 to 22).

The penalty strategy is based on the division of the

products assigned to a structure (which can be a shelf,

a cell or a pavilion) into two groups, one with iso-

lation constraints and another without. One of these

groups is deﬁned as the minority (resp. majority) if it

is the group with less (resp. more) assignments in a

structure.

Departing from the minority (majority) deﬁni-

tion, the method tries to push the search through

the predominant conﬁguration by penalising minority

groups. For example, if the shelf is mostly occupied

by products belonging to types without isolation con-

straints, it penalises the products with isolation con-

straints (lines 17 and 18) that are the minority. Sim-

ilarly, it penalises products belonging to types with-

out isolation constraints if they are the minority in the

shelf (lines 19 and 20). Furthermore, to differentiate

among similar assignments, we consider the propor-

tion of products belonging to the minority/majority

over the total number of products, instead of simply

counting the number of products. This decision was

taken due to the fact that only counting the products

was causing no changes in the total penalty after a

swap.

5 INSTANCE SETS

In this section, we describe the instance sets built up

to test the algorithm performances. We created three

warehouse layouts W

and W

with several differ-

ences between them, not only regarding the number

of positions, but also regarding how these positions

are distributed in the area. A short description of the

warehouses is provided in Table 1.

Table 1: Warehouse layout overview.

ID pavilions shelves cells accum/exp points

1 10 200 3

1 10 240 3

2 12 260 3

The experiments were divided into two parts. The

ﬁrst part was aimed at analysing the algorithm per-

formance considering only the travelled distance and

thus its suitability at dealing with directly calculated

distances. The second part tested the performance

when considering the incompatibility and isolation

constraints, in order to check if these constraints were

well handled in the algorithm.

By using the instance set I

, we tested both the in-

sertion of products and the algorithm parameters. We

experimented the insertion of two sets of products in

the warehouses, one with 100 and the other with 200

products. For each product set, we tested scenarios

with |ω| = 500, 1000 and 5000 orders. For each com-

bination of warehouse, number of products and num-

ber of orders, ﬁve realistic instances were created, for

a total of |I

| = 3 · 2 · 3 · 5 = 90 instances. In all these

instances, we used cells with only one position/level,

as showed in Table 1.

Regarding the algorithm parameters, we investi-

gated two values: the maximum number of IWI, used

as stopping criteria, and the TSP thresholds described

in Section 4. Three values of maximum number

of IWI were tested, and three different combination

of the two TSP thresholds. Additionally, we tested

the local search with and without incompatibility of

swaps between products of different types. In this

way, 3 · 3 · 2 = 18 algorithm parameter combinations

were experimented.

To test the algorithm capabilities in managing in-

compatibility and isolation constraints, we used a sub-

set of the initial instances, using 3 variations to each

combination of warehouse, number of products and

number of orders, for a total of 3 · 2 · 3 · 3 = 54 in-

stances. For each of these 54 instances, we tested 5

incompatibility and isolation constraints, leading to a

new instance set I

, with |I

| = 5 · 54 = 270.

In all the instances mentioned above, the number

of products by order was determined following a Pois-

son distribution with average number of events equal

to 6. The products inside each order were deﬁned

following a uniform distribution, but preventing the

same product from being requested twice in the same

order.

6 COMPUTATIONAL

EVALUATION

In this section, we describe the numeric experiments

performed to test the efﬁciency of the proposed ILS

algorithm. In these experiments, we observed the al-

gorithm performance on different instances, the aver-

age run time, the local search capacity of improving

the initial solution, the inﬂuence of the parameters on

the ﬁnal solution, and the solution quality.

An Iterated Local Search for a Pharmaceutical Storage Location Assignment Problem with Product-cell Incompatibility and Isolation

Constraints

The algorithm was implemented in C++17 lan-

guage, with source code being compiled with -O3

ﬂag. The tests were performed on a Dell Precision

Tower 3620 computer with a 3.50GHz Intel Xeon E3-

1245 processor and 32GB of RAM memory, running

the Ubuntu 16.04 LTS operational system. All the ex-

ecutions were performed on a single thread, without

any signiﬁcant concurrent process.

The results obtained for the I

instance set are pre-

sented in Table 2, grouped by the TSP evaluation pa-

rameters. Each line in this table represents the aver-

age over ﬁve instances of the computational results

with a speciﬁc algorithm parameter setting. Column

gives the average initial solution value produced by

the greedy algorithm, column z

best

gives the average

solution value produced by the ILS, column time(s)

reports the average run time of the ILS in seconds,

and column %G shows the average percentage gain

of z

best

with respect to z

We start our analysis from the effect of the TSP

evaluation parameters on the solution value. As the

constructive algorithm is not affected by these param-

eters, it provides always the same initial solution to a

given instance, but with a different objective function

value, due to the difference in the solution evaluation.

As expected, using exact evaluations (and better

heuristics) in more routes leads to a decrease in the

objective function values, but considering the initial

solution value, this variation is inferior to 5% in total

from the most precise to the less precise evaluation,

which suggests that simple heuristics are sufﬁciently

efﬁcient to check the quality of a storage assignment.

This evidence is in accordance with what is stated in

the literature and practised in real scenarios, mainly

by the pickers, that tend to follow the most intuitive

and sub-optimal routes (De Santis et al., 2018) (Elbert

et al., 2017). On the other hand, the improvement

on evaluation precision is unequivocally counterbal-

anced by a signiﬁcant run time increase if the whole

algorithm is considered. The total run time using the

T SP(7, 11) conﬁguration is over the double of the to-

tal run time using the T SP(5, 9) conﬁguration.

An interesting effect of the TSP evaluation pa-

rameter in the solution is the negative correlation be-

tween the evaluation precision and the improvement

obtained by the local search. In other words, if we

increase the number of routes that are evaluated by

an exact method (or better heuristics), we get less im-

provement over the greedy solution. A possible cause

of this result is the higher probability of a travel dis-

tance over-estimation when evaluating good-quality

solutions if the evaluation precision is low. This could

guide the search to a region with low-quality solu-

tions, increasing the convergence time without im-

proving the solution quality.

In the same sense, it is noticeable that an increase

in the number of products and orders in the instances

also reduces the gains over the initial solution. This is

an expected result, as it is harder to balance all picker

route distances if there are more routes to balance and

more points to visit among the different routes.

When comparing the results of scenarios with the

same evaluation parameters but different IWI val-

ues, it is possible to notice that a higher IWI only

slightly improves the average gains over the initial

solution (on average less than 0.7 percentage points

increase for each two more IWI), even with signif-

icantly higher run times. Among the hypotheses to

explain this behaviour, we can cite a bad performance

of the perturbation method to escape from local op-

tima, a too quick convergence of the method to val-

ues close to an average local optimum, the existence

of too many local optima, or the existence of several

regions of the solution space with very similar char-

acteristics causing repetitive searches.

It is interesting to notice that when comparing

“type-free swap” with “same-type swap” results, the

latter on average gets better solutions with a higher

run time. We expect that a more restricted swap could

lead to a quick conversion and thus a worse solu-

tion. As the differences between solutions are rel-

atively small, while between run times are relevant,

we can suppose that the method, when using a more

restricted local search, performs more but smaller im-

provements. This explanation is compatible with con-

cerns about meta-heuristic parameter calibration, in

which a developer tries to balance the size of inten-

siﬁcation and diversiﬁcation steps in order to ﬁnd a

better algorithm performance.

In Table 3, we show the algorithm results for in-

stances with isolation and allocation incompatibility

constraints. In the table, Φ

gives the average value

of the initial penalties, Φ

best

the average value of the

penalties in the best solutions produced by the ILS,

the average percentage gain over the initial ob-

jective function values, and %G

the average percent-

age gain over the initial penalties. In Table 3, the

block Isolation 1 refers to instances containing one

type of weak isolation constraints, the block Isolation

2 refers to instances containing one type of weak iso-

lation and one type of strong isolation constraints. Be-

sides that, both the blocks Isolation 1 and Isolation 2

in the table are subjected to allocation incompatibili-

ties.

We can ﬁrst observe a satisfactory improvement

over the initial solution obtained by the local search,

although smaller than that observed in the previous

results. Nevertheless, in instances without hard iso-

ICEIS 2022 - 24th International Conference on Enterprise Information Systems

Table 2: Computational results on instance set I

. Each line is an average on 90 instances.

Swap policy IWI

T SP(5, 9) T SP(6, 10) T SP(7, 11)

best

time(s) %G z

best

time(s) %G z

best

time(s) %G

Same-type

6 1675434.0 1025435.0 683.0 41.88 1644702.6 1059339.3 788.0 38.27 1604009.9 1149117.5 1519.7 30.85

8 1675434.0 1016371.8 830.8 42.70 1644702.6 1047753.8 991.4 39.19 1604009.9 1137799.8 1709.8 31.47

10 1675434.0 1007464.1 1038.8 43.34 1644702.6 1042574.2 1126.9 39.70 1604009.9 1130933.5 2078.8 32.10

Type-free

6 1675434.0 1035816.2 589.0 41.39 1644702.6 1065611.6 722.7 37.59 1604009.9 1153347.8 1224.9 30.18

8 1675434.0 1030057.3 709.2 41.85 1644702.6 1059577.0 893.1 38.21 1604009.9 1144094.8 1525.9 30.75

10 1675434.0 1024599.0 866.0 42.26 1644702.6 1055123.4 1090.6 38.56 1604009.9 1143325.2 1858.5 31.20

Table 3: Computational results for instances with isolation and incompatibility constraints on instance set I

. Each line is an

average on 3 instances. Parameters used: 8 IWI, T SP(7, 11). Swap policy: type-free.

Id |P| W |ω|

Isolation 1 Isolation 2

best

time(s) z

best

time(s)

100

500 405287.9 51048.9 225120.3 37610.6 44.32 25.38 276.5 632041.1 344081.8 503372.6 317109.3 20.36 7.84 288.2

2 1000 749806.0 49873.4 430050.9 31858.6 42.63 35.43 713.7 1187816.0 621282.7 977614.8 590412.1 17.64 4.96 499.6

3 5000 3558644.9 49217.2 2193491.7 52373.3 38.36 -6.53 2839.9 5659723.9 2795037.9 4846198.5 2786653.8 14.37 0.30 2119.7

500 383964.6 54282.0 240575.6 42760.2 37.33 20.93 261.0 613230.2 353249.2 534527.6 341856.0 12.82 3.15 203.0

5 1000 704103.1 51699.1 469837.4 42271.7 33.28 17.90 680.6 1162098.5 644019.8 1025637.5 619162.5 11.77 3.90 489.7

6 5000 3332955.4 54780.4 2276342.0 52617.7 31.70 2.89 3005.5 5555117.6 2933844.9 4960398.8 2911717.1 10.71 0.76 2388.9

500 371185.3 58468.7 251748.4 36607.4 32.19 36.99 334.2 575261.8 346403.8 518039.3 334616.3 9.94 3.39 402.6

8 1000 673638.7 49932.3 504716.8 38462.8 25.07 21.97 611.3 1096946.6 632364.3 1001514.8 621692.1 8.70 1.73 519.2

9 5000 3221278.3 58714.3 2444756.2 46692.6 24.10 19.00 3519.7 5296059.8 2928326.8 4907968.1 2915739.4 7.32 0.43 2897.5

200

500 438229.7 27666.7 326534.0 26333.3 25.48 4.87 281.8 728354.9 363274.5 576015.8 297922.2 20.98 18.17 278.5

11 1000 854100.0 32666.7 633261.7 24000.0 25.83 26.33 766.9 1223601.2 503051.5 1022193.0 412985.7 16.44 17.91 622.5

12 5000 4208520.8 51535.1 3145456.1 59535.1 25.26 -25.94 2824.4 5413919.5 1718497.8 4499844.1 1673331.1 16.88 2.62 3092.1

500 425402.5 30307.5 306401.6 25061.0 27.97 14.48 254.7 711924.2 362643.5 546403.6 277711.3 23.24 23.43 282.3

14 1000 814109.8 28141.2 622948.2 23876.2 23.47 15.01 760.5 1210574.2 515456.9 993881.1 447135.4 17.88 13.18 678.9

15 5000 4046685.1 32227.3 2971407.6 30121.8 26.57 6.28 3593.7 5265289.3 1724671.7 4412597.4 1637695.8 16.19 5.02 3621.2

500 431234.1 32694.1 356368.3 23407.3 17.36 28.40 441.0 711317.5 360032.5 611663.2 297630.6 13.98 17.25 229.6

17 1000 833826.9 31042.3 689633.4 24334.8 17.29 21.15 775.5 1208464.6 504536.9 1055921.7 426959.7 12.61 15.21 532.4

18 5000 4165773.8 30477.8 3403163.1 31035.4 18.31 -2.27 3409.6 5349024.8 1733807.5 4761622.8 1645191.5 10.98 5.11 3864.5

Totals 1731243.0 42656.8 1257468.8 42760.2 37.33 20.93 1486.4 2523801.4 1100055.3 2180204.3 341856.0 12.82 3.15 1362.0

lation constraints, this metric raises to 19.4% and

15.1% in blocks Isolation 1 and Isolation 2, respec-

tively. These results may suggest that if the construc-

tive algorithm does not handle well isolation con-

straints, then local search has troubles in improving

the solution.

We notice that the local search reduces proportion-

ally less the penalty value than the overall objective

function value, except in instances with 200 products

in warehouse W

(lines 16 to 18 of Table 3), suggest-

ing that the method could be giving more relevance to

travel distance.

The average run time is smaller than one hour for

almost all instance settings, except on instances on

lines 15 and 18 and Isolation 2. It suggests that the

method converges in an acceptable time even in more

realistic and complex mid-size instances.

7 CONCLUSION

In this paper, we study the Storage Location Assign-

ment Problem with Product-Cell Incompatibility and

Isolation Constraints, a generalisation of the classic

Storage Location Problem in which some products

may need to be allocated in reserved positions and

some other products can not be assigned to speciﬁc

locations. This problem lies in the context of a phar-

maceutical logistic operator aiming at more ﬂexibil-

ity in deﬁning warehouse layouts, while improving its

performance.

We propose an ILS method to solve the problem

and we test it on a large set of instances to demon-

strate its suitability in providing good solutions within

an acceptable run time. We could notice that varia-

tions on the stopping criteria cause relevant changes

in the run time, but just slight changes in the solu-

tion quality. On the other hand, the variations in the

parameters related to the TSP solutions (to determine

the pickers’ routes) prove to be very inﬂuential in both

run time and solution quality. Large instances are well

handled by the ILS algorithm, though with higher run

times, with this raise strongly related to the number of

products to be allocated and less to the number of or-

ders considered. Instances with isolation and incom-

patibility constraints present lower improvements in

the local search phase, but still relevant for commer-

cial purposes.

For future researches, we suggest to investigate

more deeply the inﬂuence of initial allocation of

strongly isolated types on the overall performance of

the optimization method. General weighting of the

different terms in the objective function 1 should be

addressed, after an extensive analysis of several fac-

An Iterated Local Search for a Pharmaceutical Storage Location Assignment Problem with Product-cell Incompatibility and Isolation

Constraints

tors, e.g. incidence of the ratio between warehouse

dimensions and the number of orders, or the distribu-

tion of the various types of penalties among products.

This could also lead to the development of interesting

multi-objective optimization algorithms. Investigat-

ing the suitability of the method to more dynamic sit-

uations is also relevant, mainly when different sources

of information are available for the orders.

REFERENCES

Aldrighetti, R., Zennaro, I., Finco, S., and Battini, D.

(2019). Healthcare supply chain simulation with dis-

ruption considerations: a case study from northern

italy. Global Journal of Flexible Systems Manage-

ment, 20(1):81–102.

Bola

nos Zu

niga, J., Saucedo Mart

ınez, J. A., Salais Fierro,

T. E., and Marmolejo Saucedo, J. A. (2020). Opti-

mization of the storage location assignment and the

picker-routing problem by using mathematical pro-

gramming. Applied Sciences, 10(2):534.

Cambazard, H. and Catusse, N. (2018). Fixed-parameter

algorithms for rectilinear steiner tree and rectilinear

traveling salesman problem in the plane. European

Journal of Operational Research, 270(2):419–429.

Chen, F., Xu, G., and Wei, Y. (2019). Heuristic rout-

ing methods in multiple-block warehouses with ultra-

narrow aisles and access restriction. International

Journal of Production Research, 57(1):228–249.

De Santis, R., Montanari, R., Vignali, G., and Bottani, E.

(2018). An adapted ant colony optimization algorithm

for the minimization of the travel distance of pickers

in manual warehouses. European Journal of Opera-

tional Research, 267(1):120–137.

Dijkstra, A. S. and Roodbergen, K. J. (2017). Exact route-

length formulas and a storage location assignment

heuristic for picker-to-parts warehouses. Transporta-

tion Research Part E: Logistics and Transportation

Review, 102:38–59.

Elbert, R. M., Franzke, T., Glock, C. H., and Grosse, E. H.

(2017). The effects of human behavior on the efﬁ-

ciency of routing policies in order picking: The case

of route deviations. Computers & Industrial Engineer-

ing, 111:537–551.

Gu, J., Goetschalckx, M., and McGinnis, L. F. (2007). Re-

search on warehouse operation: A comprehensive re-

view. European Journal of Operational Research,

177(1):1–21.

Guerriero, F., Musmanno, R., Pisacane, O., and Rende, F.

(2013). A mathematical model for the multi-levels

product allocation problem in a warehouse with com-

patibility constraints. Applied Mathematical Mod-

elling, 37(6):4385–4398.

Lu, W., McFarlane, D., Giannikas, V., and Zhang, Q.

(2016). An algorithm for dynamic order-picking in

warehouse operations. European Journal of Opera-

tional Research, 248(1):107–122.

Muppani, V. R. and Adil, G. K. (2008a). A branch and

bound algorithm for class based storage location as-

signment. European Journal of Operational Research,

189(2):492–507.

Muppani, V. R. and Adil, G. K. (2008b). Efﬁcient forma-

tion of storage classes for warehouse storage location

assignment: a simulated annealing approach. Omega,

36(4):609–618.

Quintanilla, S., P

erez,

A., Ballest

ın, F., and Lino, P. (2015).

Heuristic algorithms for a storage location assignment

problem in a chaotic warehouse. Engineering Opti-

mization, 47(10):1405–1422.

Rao, S. S. and Adil, G. K. (2013). Optimal class boundaries,

number of aisles, and pick list size for low-level or-

der picking systems. IIE Transactions, 45(12):1309–

1321.

Ratliff, H. D. and Rosenthal, A. S. (1983). Order-picking

in a rectangular warehouse: a solvable case of the

traveling salesman problem. Operations Research,

31(3):507–521.

Reyes, J., Solano-Charris, E., and Montoya-Torres, J.

(2019). The storage location assignment problem: A

literature review. International Journal of Industrial

Engineering Computations, 10(2):199–224.

Roodbergen, K. J. and Koster, R. (2001). Routing methods

for warehouses with multiple cross aisles. Interna-

tional Journal of Production Research, 39(9):1865–

1883.

Scholz, A., Henn, S., Stuhlmann, M., and W

ascher, G.

(2016). A new mathematical programming formula-

tion for the single-picker routing problem. European

Journal of Operational Research, 253(1):68–84.

Staudt, F. H., Alpan, G., Di Mascolo, M., and Rodriguez, C.

M. T. (2015). Warehouse performance measurement:

a literature review. International Journal of Produc-

tion Research, 53(18):5524–5544.

Theys, C., Br

aysy, O., Dullaert, W., and Raa, B. (2010). Us-

ing a tsp heuristic for routing order pickers in ware-

houses. European Journal of Operational Research,

200(3):755–763.

Uthayakumar, R. and Priyan, S. (2013). Pharmaceuti-

cal supply chain and inventory management strate-

gies: Optimization for a pharmaceutical company and

a hospital. Operations Research for Health Care,

2(3):52–64.

Volland, J., F

ugener, A., Schoenfelder, J., and Brunner, J. O.

(2017). Material logistics in hospitals: A literature

review. Omega, 69:82 – 101.

Wang, M., Zhang, R.-Q., and Fan, K. (2020). Improving

order-picking operation through efﬁcient storage lo-

cation assignment: A new approach. Computers &

Industrial Engineering, 139:106186.

Zulj, I., Glock, C. H., Grosse, E. H., and Schneider, M.

(2018). Picker routing and storage-assignment strate-

gies for precedence-constrained order picking. Com-

puters & Industrial Engineering, 123:338–347.

ICEIS 2022 - 24th International Conference on Enterprise Information Systems
