Harmonizing the OQuaRE Quality Framework

Achim Reiz

and Kurt Sandkuhl

Chair of Information Systems, Rostock University, Albert-Einstein-Str. 22, 18059 Rostock Germany

Keywords: Ontology, Quality, Quality Framework, OQuaRE, Semantic

Abstract: Measuring ontology quality using metrics is far from a trivial task – one has to pick the right metrics for the

right task and then interpret these values in a meaningful way. Without help, these interpretations are often

highly subjective, even for trained knowledge engineers. Quality frameworks can assist and objectify the

evaluation. One of the more prominent frameworks in ontology evaluation is OQuaRE, which builds upon

the SQuaRE standard for software evaluation. Not only provides it tangible metrics for assessing an ontology,

but it also suggests an interpretation for these values in the form of a quality rating and links these metrics to

a broader quality framework.

However, during an implementation effort, the authors identified some drawbacks. In the last years, various

metrics have been proposed that sometimes seem to conflict with each other or are inconclusive in their

descriptions. The resources on the quality framework are distributed over web pages and papers.

The following paper aims first to present the drawbacks the framework currently has. At the next step, we

resolve the current heterogeneities and collect the information of the various sources. We aim to provide a

one-stop information resource on OQuaRE to enable our further research and applications efforts.

1 INTRODUCTION

The selection, building, and integration of ontologies

are far from trivial tasks. The idea of building shared

knowledge bases emphasizes the reusing of already

accepted terminologies. As vast quantities of

ontologies have been developed over time, how does

one find the right ontology with the best quality for

the individual use case? Moreover, how can we help

the developer create high-quality artifacts during the

ontology development process? Automated quality

metrics can assist the knowledge engineer in the

selection and development process. It enables to

grasp differences between two ontologies or two

ontology versions.

There are a lot of different quantifiable attributes

in an ontology that one can use, like attributes that are

concerned with properties of the graph, the amount of

human-centered annotations, the diversity of

relations, and much more. Quality frameworks

provide orchestration and meaning to these otherwise

arbitrary and isolated measurement points. Over the

https://orcid.org/0000-0003-1446-9670

https://orcid.org/0000-0002-7431-8412

past years, some ontology quality frameworks have

been proposed:

Tartir et al. developed OntoQA, proposing

schema, instance, relationship, and class-specific

metrics (Tartir et al., 2005). Gangemi et al. proposed

a large variety of primarily graph-related

measurements (Gangemi et al., 2005), and Yao et al.

(Yao et al., 2005) presented a set of metrics to

measure cohesion. Furthermore, OQuaRE, initially

proposed by Duque-Ramos et al., developed a quality

framework based on the SQuaRE software

methodology (Duque-Ramos et al., 2011).

OQuaRE was first introduced in 2011. Since then,

it has been used by several publications involving,

among others, always Duque-Ramos and Fernandez-

Breis (Duque-Ramos et al., 2011; Duque-Ramos et

al., 2013; Duque-Ramos et al., 2014; Duque-Ramos

et al., 2016; Franco et al., 2020; M. Quesada-Martínez

et al., 2015; Manuel Quesada-Martínez et al., 2017).

OQuaRE is probably the most holistic framework

compared to the proposals by the authors named above.

The proposed metrics are mapped to a rating system,

showing which values ranges are desirable. Further,

the metrics are associated with quality characteristics

148

Reiz, A. and Sandkuhl, K.

Harmonizing the OQuaRE Quality Framework.

DOI: 10.5220/0011077200003179

In Proceedings of the 24th International Conference on Enterprise Information Systems (ICEIS 2022) - Volume 2, pages 148-158

ISBN: 978-989-758-569-2; ISSN: 2184-4992

like reusability or portability. The authors also provide

an online calculation tool (Fernandez-Breis et al.,

2018), online documentation (OQuaRE: A SQuaRE

Based Quality Evaluation Framework for Ontologies),

and a wiki (OQuaRE Wiki, 2016).

Most other frameworks only propose the metrics

without stating how it affects these quality characte/-

ristics. None of the competing proposals provide such

detailed interpretations for the given metrics in the

form of a school-grade-like rating system. Further,

metric implementations in software tools are scarce

(Reiz et al., 2020). Thus, the knowledge engineer who

needs an evaluation often has no means to calculate the

proposed metrics. All these factors contribute to the

relevance of OQuaRE as practical, applicable quality

guidance for ontology engineering.

In an effort to collect and map the various metric

frameworks, their similarities, and differences as part

of a larger research project (Reiz, 2020), we started to

model the proposed quality dimensions to later create

a shared metric interface for the different

frameworks. However, for the OQuaRE-framework,

that proved to be challenging: Over time, an

increasing amount of metrics have been proposed in

various publications. Some of the metrics were

altered over time, and others are vague in their

definition. The full extent of the documentation is

available on, at times contradicting, online resources

(OQuaRE Wiki, 2016; OQuaRE: A SQuaRE Based

Quality Evaluation Framework for Ontologies).

These discovered limitations made the planned

application of the framework difficult.

This paper targets to collect, harmonize, and

precise OQuaRE. We aim to build a solid foundation

for our further use and investigation of the framework.

This research further shall enable other researchers and

knowledge engineers to implement the same version of

the metrics and make future results comparable. At

first, we present the heterogeneous metrics, precise and

harmonize them. In the next step, we collected and

compared the various sources and presented the

framework to the full extent.

2 IDENTIFIED

HETEROGENEITIES

The different papers referencing OQuaRE propose 19

ontology metrics, even though not all are referenced

and used in every paper. For this section, we checked

whether the quality metrics proposed in the papers

(Duque-Ramos et al., 2011; Duque-Ramos et al.,

2013; Duque-Ramos et al., 2014; Duque-Ramos et

al., 2016; M. Quesada-Martínez et al., 2015; Manuel

Quesada-Martínez et al., 2017), in the online

documentation and wiki (OQuaRE Wiki, 2016;

OQuaRE: A SQuaRE Based Quality Evaluation

Framework for Ontologies), and the tool (Fernandez-

Breis et al., 2018) are consistent with each other.

Twelve of the OQuaRE metrics are well defined.

However, six of the metrics were proposed differently

by the newer papers, even though they sometimes

recalled the previous ones as their foundation. One

metric was described homogeneously, but its

definition seems ambiguous.

To homogenize the papers, we selected the

metrics with the most acceptance in the community

measured by citations. This approach emphasizes the

definitions by (Duque-Ramos et al., 2011), cited 67

times (at the time of writing this paper), then (Duque-

Ramos et al., 2013) and its associated documentation

(OQuaRE: A SQuaRE Based Quality Evaluation

Framework for Ontologies) with 34 citations, and

(Duque-Ramos et al., 2014) with 15 citations.

2.1 NOCOnto (Number of Children)

The first metric that seems inconsistent in its

definitions is NOCOnto. It is defined by (Duque-

Ramos et al., 2016; M. Quesada-Martínez et al.,

2015) as the “Mean number of direct subclasses per

class minus the subclasses of thing”. (Duque-Ramos

et al., 2011), as well as the documentation web page

(OQuaRE: A SQuaRE Based Quality Evaluation

Framework for Ontologies) proposes the same metric

but uses the name “relationship” for the direct sub-

class relations: “Mean number of direct subclasses.

It is the number of relationships divided by the

number of classes minus the relationships of Thing”.

However, as this paper consistently uses the word

“relationship” where other papers declare subclasses

(cf. INROnto), we assume they mean the same.

(Duque-Ramos et al., 2013; Duque-Ramos et al.,

2014) use the same metric, not for subclasses but

superclasses. They describe the metric as the

“Average number of the direct superclasses per class

minus the subclasses of Thing” The recent papers

(Franco et al., 2020; Manuel Quesada-Martínez et al.,

2017), the wiki (OQuaRE Wiki, 2016), as well as the

tool calculation (Fernandez-Breis et al., 2018) use the

first published definition, but subtract the leaf classes:

“Number of the direct subclasses divided by the

number of classes minus the number of leaf classes”

We propose to use the metric by (Duque-Ramos

et al., 2011; Duque-Ramos et al., 2016; OQuaRE: A

SQuaRE Based Quality Evaluation Framework for

Ontologies; M. Quesada-Martínez et al., 2015). At

Harmonizing the OQuaRE Quality Framework

149

first, because it represents the most commonly cited

definition. Secondly because the name alone suggests

the use of subclass relationships.

2.2 RFCOnto (Response for a Class)

This metric is defined by (Duque-Ramos et al., 2013;

Duque-Ramos et al., 2014) as “Number of Datatype

Properties and Object Properties that can be directly

accessed from the class”. (Duque-Ramos et al., 2011;

OQuaRE: A SQuaRE Based Quality Evaluation

Framework for Ontologies) not only state object and

data properties but declare that it is the “Number of

properties that can be directly accessed from the

Class”. Even though this definition would include

annotation properties, later versions state annotation

properties explicitly. We, thus, assume that the

intention from the second definition does not differ

from the previous. (Duque-Ramos et al., 2016; M.

Quesada-Martínez et al., 2015) describe RFCOnto as

the “Number of usages of object and data properties

and superclasses divided by the number of classes

minus the subclasses of Thing”.

The recent papers (Franco et al., 2020; Manuel

Quesada-Martínez et al., 2017) dropped the

subtraction of the subclasses of thing, otherwise

stating the same: “Number of usages of object and

data properties and superclasses divided by the

number of classes”. The wiki and the tool both

implemented the latest calculation methodology

(Fernandez-Breis et al., 2018; OQuaRE Wiki, 2016).

For this metric, we chose the widely used

definition (Duque-Ramos et al., 2011; Duque-Ramos

et al., 2013; Duque-Ramos et al., 2014; OQuaRE: A

SQuaRE Based Quality Evaluation Framework for

Ontologies) that includes the subtraction of the

subclasses of the root class.

2.3 RROnto (Relationship Richness)

A first heterogeneity is in the naming: (Duque-Ramos

et al., 2011; OQuaRE: A SQuaRE Based Quality

Evaluation Framework for Ontologies) define

RROnto as Property Richness. (Duque-Ramos et al.,

2013; Duque-Ramos et al., 2014; OQuaRE Wiki,

2016) describe the metric as PROnto, Property

Richness. Afterward, the naming is reverted to the

abbreviation RROnto and the meaning Relationship

Richness. While there exists another metric called

PROnto, it was first introduced metric-wise in 2017

by (Manuel Quesada-Martínez et al., 2017) and is

further utilized by (Franco et al., 2020). The wiki and

the tool (Fernandez-Breis et al., 2018; OQuaRE Wiki,

2016) also describe PROnto but swapped the meaning

of RROnto and PROnto. To untangle the confusion

for the different naming conventions, we use the

newest term RROnto and Relationship Richness for

this metric.

Regarding metric definitions, the first paper and

documentation (Duque-Ramos et al., 2011; OQuaRE:

A SQuaRE Based Quality Evaluation Framework for

Ontologies) describe RROnto as the “Number of

properties defined in the ontology divided by the

number of relationships and properties”. (Duque-

Ramos et al., 2013; Duque-Ramos et al., 2014; Duque-

Ramos et al., 2016; Manuel Quesada-Martínez et al.,

2017) describes the metric differently as “Number of

usages of object and data properties divided by the

number of subclassof relationships and properties”.

The formula presented in the online documentation

(OQuaRE: A SQuaRE Based Quality Evaluation

Framework for Ontologies) specifies that the definition

uses the number of properties per class (object property

assertions), not the object properties defined in the

ontology generally. The terminology of relationship in

the paper (Duque-Ramos et al., 2011) is the same as in

NOCOnto and other metrics and is seen as equivalent

to subclass relationships. Thus, we can assume that the

two definitions describe the same thing.

The newest publication (Franco et al., 2020)

exchanges the subclassof to a superclass relationship

(which is equivalent) and puts it into the dividend:

“Number of usages of object and data properties and

super classes divided by the number of classes”. The

tool does not follow the paper definitions and

calculates it as the number of used properties divided

by the sum of the used properties and the direct

ancestor classes.

Again, we select the most cited metric, defined by

(Duque-Ramos et al., 2011; Duque-Ramos et al.,

2013; Duque-Ramos et al., 2014; Duque-Ramos et

al., 2016; OQuaRE: A SQuaRE Based Quality

Evaluation Framework for Ontologies; M. Quesada-

Martínez et al., 2015; Manuel Quesada-Martínez et

al., 2017).

2.4 PROnto (Properties Richness)

At first, the definitions for PROnto seemed very

diverse. However, as shown for the RROnto metric,

the name PROnto was sometimes assigned for the

metric RROnto. PROnto in its distinctive form was

first introduced by the papers (Franco et al., 2020;

Manuel Quesada-Martínez et al., 2017) as the:

“Number of subclassof relationships divided by the

number of subclassof relationships and properties”.

The wiki and the tool implement this definition but

swapped the names of PROnto and RROnto

ICEIS 2022 - 24th International Conference on Enterprise Information Systems

150

(Fernandez-Breis et al., 2018; OQuaRE Wiki, 2016).

PROnto is, thus, not inconsistent in the definitions but

the naming. We suggest using the PROnto for the

definition named above.

2.5 TMOnto (Tangledness)

The definitions of tangledness are not as widespread

as some of the other metrics. The first paper (Duque-

Ramos et al., 2011) and the documentation

(OQuaRE: A SQuaRE Based Quality Evaluation

Framework for Ontologies) define it as the “Mean

number of parents per class”. The papers (Duque-

Ramos et al., 2016; Franco et al., 2020; M. Quesada-

Martínez et al., 2015; Manuel Quesada-Martínez et

al., 2017) define it as the “Mean number of classes

with more than 1 direct ancestor”. We choose the

older definition, as it is more broadly accepted,

having more than six times the citations compared to

the newer papers.

2.6 WMCOnto (Weighted Method

Count)

The metric stays relatively consistent throughout the

first five papers and the documentation. The paper

published in 2011, 2015, and 2016 (Duque-Ramos et

al., 2011; Duque-Ramos et al., 2016; OQuaRE: A

SQuaRE Based Quality Evaluation Framework for

Ontologies; M. Quesada-Martínez et al., 2015) define

it as “Mean number of properties and relationships

per class”, the ones published in 2013 and 2014

(Duque-Ramos et al., 2013; Duque-Ramos et al.,

2014) declare it as the “mean (2013 paper: average)

number of Datatype Properties, Object Properties

and subclasses per class”. As in NOCOnto and

INROnto, we assume that “relationships” are

equivalent to subclass declarations.

The latest papers, the wiki, and application

(Fernandez-Breis et al., 2018; Franco et al., 2020;

OQuaRE Wiki, 2016; Manuel Quesada-Martínez et

al., 2017) shift heavily in their meaning of WMCOnto

and define it as the “Mean length of the path from

thing to a (!sic) leaf classes. However, we suggest

using the older, often cited version.

2.7 AROnto (Attribute Richness)

The challenge with AROnto is not the heterogeneity

of its definition; it is defined as by (Duque-Ramos et

al., 2011; Duque-Ramos et al., 2014; Duque-Ramos

et al., 2016; Franco et al., 2020; M. Quesada-Martínez

et al., 2015; Manuel Quesada-Martínez et al., 2017)

as the “number of restrictions of the ontology per

classes”, (Duque-Ramos et al., 2013; OQuaRE: A

SQuaRE Based Quality Evaluation Framework for

Ontologies) define it as the “mean number of

attributes per class”, we assume that they both mean

the same thing. However, the meaning of restriction

or attribute in the context of ontologies is not fully

clear if it is not concerned with properties (as the

analysis of properties is already covered in other

metrics). An implementation effort (Tibaut, 2018),

thus, interpreted the metric as the number of property

restrictions (owl:someValuesFrom, owlhasvalue, …)

divided by the number of classes.

(Manuel Quesada-Martínez et al., 2017) give

more insights into the meaning of AROnto and

describes it as “the number of elements that can be

related by properties”. This metric is implemented by

the tool as well (Fernandez-Breis et al., 2018). The

tool takes into account the domain axioms of data and

object properties and counts how many classes

(including subclasses) can be linked with the given

properties. We adopted this calculation method.

3 HARMONIZED OQuaRE

FRAMEWORK

As we have shown in the previous section, the

available OQuaRE papers seem inconsistent in some

of their proposed metrics. An imprecise terminology

further contributes to the fuzziness in the metric

definitions. The following section targets to translate

the proposed metrics to a precise notation, clear

heterogeneities, and build a joint base for future

implementations of the OQuaRE metrics.

At first, we present the homogenized metric

calculation. Subsection two is concerned with the

collected quality characteristics. Subsection three

recapitulates the metric interpretations that are part of

OQuaRE.

3.1 Metric Definitions

The metrics are at the core of the OQuaRE

framework. The following two tables collect the

harmonized metrics. At first, Table 1 introduces the

fundamental ontology attributes that the OQuaRE

metrics build on. Every measurement is connected to

a distinct symbol and comes with an example. Table

2 then presents the harmonized OQuaRE metrics,

using the symbols previously introduced.

The metrics presented below are either

homogeneously described in the OQuaRE

publications or previously discussed in section two.

Harmonizing the OQuaRE Quality Framework

151

Table 1: Ontology Attributes Needed for Calculating the OQuaRE Metrics.

Symbol Meaning

𝑐



The 𝑖



class of the ontology

E.g.: Class “Mother”

𝑎





𝑂



Annotation 𝑖 on ontology 𝑂, does not include 𝑎





𝑐



E.g.: This ontology is about family relations

𝑎



𝑐 Annotation 𝑖 on class 𝑐

E.g.: Mother, Description: A Mother is a female who has at least one child

𝑖𝑛𝑑



𝑐 Individual 𝑖 of a class 𝑐

E.g.: Karen is instanceOf Mother

𝑠𝑢𝑏



𝑐 Subclass 𝑖 of the class 𝑐

E.g.: Mother is subClassOf Parent

𝑑𝑝



𝑐 Data property assertion 𝑖 on class 𝑐.

E.g.: Person subClassOf (Age exactly 1 sxd:integer)

𝑜𝑝



𝑐 Object Property assertion 𝑖 on class 𝑐

E.g.: Daughter isRelativeOf some Mother

𝑑𝑜𝑚



𝐷𝑃 Classes in the domain 𝑖 of data property 𝐷𝑃 (incl all subclasses)

E.g.: Age Domain Person

𝑑𝑜𝑚



𝑂𝑃 Classes in the domain 𝑖 of object property 𝑂𝑃 (incl all subclasses)

E.g.:isRelativeOf Domain Person

𝐷𝑃



Data property 𝑖 declared in ontology

E.g.: Age

𝑂𝑃



Object property 𝑖 declared in ontology

E.g.: isRelativeOf

𝑠𝑢𝑝



𝑐 Superclass 𝑖 of the class 𝑐

Parent superClassOf Mother

𝑟𝑜𝑜𝑡

Root class of ontology

E.g., owl:thing

𝑙𝑒𝑎

𝑓



Leaf class 𝑖, a leaf class does not have a subclass.

E.g.: Mother

𝑝𝑎𝑡ℎ



𝑐



⃑

Path 𝑖 from 𝑟𝑜𝑜𝑡 to 𝑐.

E.g.: root



Parent



Mother

𝑝𝑎𝑡ℎ



𝑐



⃑



Length of a path 𝑖 from 𝑟𝑜𝑜𝑡 to class 𝑐

E.g.: |root



Parent



Mother | = 3

3.2 OQuaRE Quality Characteristics

On top of the OQuaRE metrics, OQuaRE defines the

quality model. It provides desirable ontology features

based on the software evaluation framework

SQuaRE. It comprises high-level quality

characteristics, each having further sub-

characteristics. Parts of the quality characteristics are

described in (Duque-Ramos et al., 2011; Duque-

Ramos et al., 2013; Duque-Ramos et al., 2016; M.

Quesada-Martínez et al., 2015). The data is available

to a full extent on the OQuaRE webpage and wiki

(OQuaRE Wiki, 2016; OQuaRE: A SQuaRE Based

Quality Evaluation Framework for Ontologies). The

first published quality model, extensively described

in (OQuaRE: A SQuaRE Based Quality Evaluation

Framework for Ontologies) and used by (Duque-

Ramos et al., 2011; Duque-Ramos et al., 2013),

comprises 51 sub characteristics. The wiki,

referenced by the rest of the papers, dropped two

characteristics C8-reliability (3 sub characteristics)

and C9-performance efficiency (2 sub

characteristics), and split two up (C2.6, 2.7 & C.2.12,

C2.13), resulting in a total of 48 quality

characteristics.

ICEIS 2022 - 24th International Conference on Enterprise Information Systems

152

Table 2: OQuaRE Metrics.

Metric Formula

ANOnto

Annotation richness

∑

𝑎



𝑐





,



∑

𝑎



𝑂



∑

𝑐



AROnto

Attribute richness

∑

𝑑𝑜𝑚



𝐷𝑃





,



∑

𝑑𝑜𝑚



𝑂𝑃





,

∑

𝑐



CBOnto

Coupling between objects

∑

sup



𝑐







∑

𝑐



 𝑠𝑢𝑏𝑟𝑜𝑜𝑡

CROnto

Class richness

∑

𝑖𝑛𝑑

,

𝑐





∑

𝑐



DITOnto

Depth of subsumption hierarchy

max



𝑝𝑎𝑡ℎ



⃑





𝑐





INROnto

Relationships per class

∑

𝑠𝑢𝑏



𝑐





,

∑

𝑐



NACOnto

Number of ancestor classes

∑

𝑠𝑢𝑝



𝑙𝑒𝑎𝑓





,

∑

𝑙𝑒𝑎𝑓



NOCOnto

Number of children

∑

𝑠𝑢𝑏





𝑐





,

∑

𝑐





∑

𝑠𝑢𝑏



𝑟𝑜𝑜𝑡



NOMOnto

Number of properties

∑

𝑑𝑝





𝑐







∑

𝑜𝑝





𝑐𝑖





,,

∑

𝑐



LCOMOnto

Lack of cohesion in methods

∑

𝑝𝑎𝑡ℎ



⃗

𝑙𝑒𝑎𝑓







∑

𝑙𝑒𝑎𝑓



RFCOnto

Response for a class

∑

𝑑𝑝





𝑐







∑

𝑜𝑝





𝑐𝑖







∑

𝑠𝑢𝑏





𝑐𝑖





,,,

∑

𝑐





∑

𝑠𝑢𝑏



𝑟𝑜𝑜𝑡



RROnto

Relationship richness

∑

𝑑𝑝





𝑐







∑

𝑜𝑝





𝑐𝑖





,,

∑

𝑠𝑢𝑏



𝑐





,



∑

𝑑𝑝





𝑐







∑

𝑜𝑝





𝑐𝑖





,,

TMOnto

Tangledness

∑

𝑠𝑢𝑝

,



𝑐





∑

𝑐



;Σ



𝑠𝑢𝑝





𝑐



1

TMOnto2

Tangledness 2

∑

𝑠𝑢𝑝

,,

𝑠𝑢𝑝



𝑐





∑

𝑠𝑢𝑝

,



𝑐





;Σ



𝑠𝑢𝑝





𝑐



1

WMCOnto

Weighted method count

∑

𝑑𝑝





𝑐







∑

𝑜𝑝





𝑐𝑖







∑

𝑠𝑢𝑏





𝑐𝑖





,,,

∑

𝑐



WMCOnto2

Weighted method count 2

∑

𝑝𝑎𝑡ℎ





⃑

𝑙𝑒𝑎𝑓





,

∑

𝑙𝑒𝑎𝑓



PROnto

Property richness

∑

𝑠𝑢𝑝



𝑐





,

∑

𝑑𝑝





𝑐







∑

𝑜𝑝





𝑐𝑖







∑

𝑠𝑢𝑏





𝑐𝑖





,,,

Ponto

Ancestors per class

∑

𝑠𝑢𝑝



𝑐





,

∑

𝑐



The elements presented below are the union out

of (OQuaRE Wiki, 2016; OQuaRE: A SQuaRE Based

Quality Evaluation Framework for Ontologies) and

the papers (Duque-Ramos et al., 2011; Duque-Ramos

et al., 2013; Duque-Ramos et al., 2016; M. Quesada-

Martínez et al., 2015), resulting in a total of 53 sub

characteristics. The descriptions of the characteristics

presented in the tables below are shortened and

refined. The ordering of the item encapsulates no

further meaning.

The first characteristic, “structural”, evaluates

the connections within an ontology and the attributes

of the graph.

Harmonizing the OQuaRE Quality Framework

153

Table 3: Sub-Characteristics for Characteristic

“Structural”.

# Sub-

Characteristic

Description

C1.1 Formalization The ontology is built on top

of a formal model (e.g.,

OWL, OBO) to support

reasoning

C1.2 Formal Relations

Support

The ontology supports

formal relations beyond

taxono

C1.3 Redundancy All knowledge items are

informative

C1.4 Structural

Accurac

The terms are correct

C1.5 Consistency No set of items are

contradictor

conflictin

C1.6 Tangledness The fewer multi inheritance

relationships are declared,

the

ette

C1.7 Cycles The existence of cycles is

usually bad design and shall

e avoide

C1.8 Cohesion The classes are strongly

relate

C1.9 Domain Coverage The ontology covers the

specified domain (requires

an ex

ert evaluation

)

Functional Adequacy describes the capability to

provide concrete functions. Regarding this

characteristic, the two documentations have minor

differences. In (OQuaRE: A SQuaRE Based Quality

Evaluation Framework for Ontologies), the elements

Clustering and Similarity are fused, as well as

Guidance, and Decision Trees.

Table 4: Sub-Characteristics for Characteristic “Functional

Adequacy”.

# Sub-

Characteristic

Description

C2.1 Reference

Ontology

The ontology can be used

as a reference source

C2.2 Controlled

Vocabulary

Heterogeneity is avoided.

The ontology provides

terminology management

(e.g., through the use of

labels)

C2.3 Schema and

Value

Reconciliation

The ontology provides a

common data model and

integrations to achieve

semantic interoperabilit

C2.4 Consistent

search and

query

The formal model and

structure guides the search

process for data by

providing concepts,

machine-computable

erties, an

axioms

C2.5 Knowledge

Acquisition

The capability of the

ontology to represent the

knowledge acquired in the

form of instances

C2.6 Clustering The annotations of terms

enable clustering

C2.7 Similarity The components can be

compared for (e.g.,

taxonomy, relation,

attribute, or semantic)

similarit

C2.8 Indexing and

Linking

The classes can act as

indexes for fast

information retrieval

C2.9 Result

Representation

The ontologies capability

to analyze complex results

C2.10 Classifying

Instances

Instances can be

recognized as class

members with defined

roperties

C2.11 Text Analysis Structure supports

association detection

between words and

concepts to classify word

types

C2.12 Guidance Capability to guide the

specification of domain

theories through capturing

knowledge and constraints

about a domain

C2.13 Decision Trees Capability to build

decision trees

C2.14 Knowledge

Reuse

The knowledge base can

be used to build other

ontolo

ies

C2.15 Inference The capability to use

reasoners to make implicit

knowled

e ex

licit

C2.16 Precision The ontology provides the

right results with the

neede

accurac

Compatibility describes the ability of at least two

software components to exchange information and/or

to perform their required functions while sharing a

hardware or software environment.

Table 5: Sub-Characteristics for Characteristic

“Compatibility”.

# Sub-

Characteristic

Description

C3.1 Replaceabililty The ontology can replace

another ontology with the

same purpose in the same

environment

C3.2 Interoperability The ontology can

cooperatively combine its

knowledge with other

ontolo

ies

ICEIS 2022 - 24th International Conference on Enterprise Information Systems

154

Transferability describes the degree to which

software can be transferred from one environment to

another.

Table 6: Sub-Characteristics for Characteristic

“Transferability”.

# Sub-

Characteristic

Description

C4.1 Portability The ontology or parts of it

can be transferred between

environments

C4.2 Adaptability The ontology can be adapted

to different specified

environments (e.g.,

languages, expressivity

levels)

Operability is concerned with the effort that is

needed to use the ontology by stated or implied users.

Table 7: Sub-Characteristics for Characteristic

“Operability”.

# Sub-

Characteristic

Description

C5.1 Appropriateness

Reco

nisabilit

The ontology enables the

users to detect faults

C5.2 Learnability The ontology enables users

to learn its applications

C5.3 Ease of Use It is easy for the users to

operate and control the

ontolog

C5.4 Helpfulness The application assists the

users

Maintainability describes the capability of

ontologies to be modified for changing environments,

requirements, or functional specifications.

Table 8: Sub-Characteristics for Characteristic

“Maintainability”.

# Sub-

Characteristic

Description

C6.1 Modularity The ontology is composed

of discrete components.

Changing one has minimal

effect on the others

C6.2 Reusability A part of the ontology can

e use

in othe

ontolo

ies

C6.3 Analyzability The ontology can be

diagnosed regarding

deficiencies, inconsistencies

C6.4 Changeability The ontology can be easily

modifie

C6.5 Modification

Stabilit

Unexpected effects from

modifications are avoide

C6.6 Testability The ontology can be

validate

The characteristic Quality in Use measures how a

product used by specific users meets their needs to

achieve their goals. It is the quality in a particular

context of use. Unlike the other quality criteria, this

characteristic does describe additional sub

characteristics.

Table 9: Sub-Characteristics for Characteristic “Quality in

Use”.

# Sub-

Characteristic

Description

C7.1.1 Usability in Use 

Effectiveness in

Use

A specified user can

achieve their goals

with accuracy and

completeness in their

context of use

C7.1.2 Usability in Use 

Efficiency in Use

The used resources

match the ontologies

effectiveness

C7.1.3 Usability in Use 

Satisfaction in Use

The user are satisfied

in their specified

context of use

C7.1.3.1 Usability in Use 

Likabilit

Cognitive satisfaction

C7.1.3.2 Usability in Use 

Pleasure

Emotional satisfaction

C7.1.3.3 Usability in Use 

Comfort

Physical satisfaction

C7.1.3.4 Usability in Use 

Trust

Not further described

C7.2.1 Flexibility in Use

 Context

Conformit

in Use

Usability in use meets

requirements of the

intende

context of use

C7.2.2 Flexibility in Use

 Context

Extendibilit

in Use

Usability in use in a

context beyond

initiall

intende

The following two quality characteristics are part

of the first version of the quality framework published

in (OQuaRE: A SQuaRE Based Quality Evaluation

Framework for Ontologies). They were later dropped

in the wiki (OQuaRE Wiki, 2016).

Performance Efficiency describes the

relationship between software performance and

resource consumption under stated conditions.

Table 10: Sub-Characteristics for Characteristic

“Performance Efficiency”.

# Sub-

Characteristic

Description

C8.1 Response Time The ontology provides

appropriate response times

throu

ut rates

C8.2 Resource

Utilization

The application uses the

appropriate amount and

types of resources when

using the ontology

Harmonizing the OQuaRE Quality Framework

155

Reliability is concerned with maintaining the

level of performance under the stated conditions.

Table 11: Sub-Characteristics for Characteristic

“Reliability”.

# Sub-

Characteristic

Description

C9.1 Error Detection The ontology enables the

users to detect faults

C9.2 Recoverability The ontology can re-

establish a specified

performance level/data

recover

in case of a failure

C9.3 Availability The software component

(language, tools, ontology)

is operational and available

when neede

4 CONNECTING QUALITY

CHARACTERISTICS AND

METRICS

As already stated earlier, the unique feature of

OQuaRE is the holistic view on quality. Not only

quality metrics are proposed, but also an

interpretation of which values are desirable. Further,

(Duque-Ramos et al., 2013) and the OQuaRE wiki

(OQuaRE Wiki, 2016) state how quality metrics

influence the quality characteristics shown in the

section above. The section on quality influences in the

online documentation (OQuaRE: A SQuaRE Based

Quality Evaluation Framework for Ontologies) is no

longer accessible. The collected information of the

paper and the wiki is presented in Table 12.

By analyzing the results, one can see that some of

the metrics are not described as an influence on

quality characteristics (cf., PROnto, POnto,

NACOnto). All second versions of metrics (thus, end

with a “2” like TMOnto2) are also not marked as

influencing a quality characteristic. However, as they

are concerned with similar aspects like their first

versions, we assume they also influence the same

quality characteristics (e.g., TMOnto2 also influences

C1.6, C2.13).

Furthermore, while some metrics are connected to

just two metrics (TMOnto, CROnto), others have

much more diverse connections, like AROnto,

NOMOnto (associated with eight metrics), RROnto,

and WMCOnto (associated with eight metrics).

Further, OQuaRE describes two influences on

quality characteristics that are not associated with a

metric but are itself a sub-characteristic of the

category Structural: Formality (C1.1) and

Consistency (C1.5).

Table 12: Quality Interpretations for Metrics and their Influences on Quality Characteristics.

Metric Influences Best Worst

5 4 3 2 1

ANOnto C1.3, C2.2, C2.4, C2.5, C2.6, C2.14 >0,8 0,6-0,8 0,6-0,4 0,4-0,2 <0,2

AROnto C2.3, C2.4, C2.7, C2.8, C2.9, C2.12, C2.13, C2.14 >0,8 0,6-0,8 0,6-0,4 0,4-0,2 <0,2

CBOnto C4.2, C5.2, C6.1, C6.2, C6.3, C6.4, 6.5 1-3 3-6 6-8 8-12 >12

CROnto C2.9, C2.15 >0,8 0,6-0,8 0,6-0,4 0,4-0,2 <0,2

DITOnto C3.1, C4.2, C6.2, C6.3, C6.4 1-2 2-4 4-6 6-8 >8

INRonto C2.4, C2.8, C2.12, C2.13, C2.14 >0,8 0,6-0,8 0,6-0,4 0,4-0,2 <0,2

NACOnto 1-2 2-4 4-6 6-8 >8

NOCOnto C3.1, C4.2, C5.2, C6.2, C6.4, C6.5 1-2 2-4 4-6 6-8 >8

NOMOnto C2.5, C2.14, C3.1, C4.2, C5.2, C6.2, C6.3, C6.4 <=2 2-4 4-6 6-8 >8

LCOMOnto C1.8, C2.14, C5.2, C6.3, C6.4, C6.5 <=2 2-4 4-6 6-8 >8

RFCOnto C4.2, C5.2, C6.2, C6.3, C6.4, C6.5 1-3 3-6 6-8 8-12 >12

RROnto C1.2, C2.3, C2.4, C2.5, C2.7, C2.8, C2.15 >0,8 0,6-0,8 0,6-0,4 0,4-0,2 <0,2

TMOnto C1.6, C2.13 1-2 2-4 4-6 6-8 >8

TMOnto2 1-2 2-4 4-6 6-8 >8

WMCOnto C3.1, C4.2, C5.2, C6.1, C6.2, C6.3, C6.4 1-2 2-4 4-6 6-8 >8

WMCOnto2 1-2 2-4 4-6 6-8 >8

PRONTO >0,8 0,6-0,8 0,6-0,4 0,4-0,2 <0,2

PONTO >0,8 0,6-0,8 0,6-0,4 0,4-0,2 <0,2

Formality C2.2, C2.3, C2.4, C2.11, C2.14, C2.15

Consistency C2.2, C2.3, C2.14

ICEIS 2022 - 24th International Conference on Enterprise Information Systems

156

While we argue that there are metrics available

that could be used to measure these two aspects, e.g.,

Richness and Lawfulness by Burton-Jones et al.

(Burton-Jones et al., 2005), or “Meta-Logical

Adequacy” and “Generic Complexity” by Gangemi et

al. (Gangemi et al., 2005), the definition of new

OQuaRE-metrics is beyond the scope of this paper.

Further, it is noted that we did not carry out an

analysis of whether stated connections between

quality characteristics and metrics or the proposed

metric quality ranges are valid, there are merely

collected out of the various resources.

5 CONCLUSION & OUTLOOK

There are many different aspects one can consider

when evaluating ontologies. Ontology quality

frameworks can guide which metrics to use and how

to interpret them. Furthermore, from the proposed

frameworks, OQuaRE probably provides the most

holistic assessment and guidance. However, as shown

in this paper, the various published papers and

resources on OQuaRE sometimes seem to contradict

each other. The heterogeneities make the

implementation of the framework difficult.

The presented paper aims at providing a single

permanent point of reference for future use of the

framework. We homogenized the proposed metrics

and provided a clear, formalized description of the

metrics. The various sources of OQuaRE are

consolidated, making it the first peer-reviewed paper

that shows OQuaRE to its full extent.

Harmonizing the OQuaRE quality framework is

one next step in a broader effort to research the

practical use of ontology quality frameworks using

evolutional data (Reiz, 2020). In the upcoming

months, we are going to build a software tool to

analyze large amounts of ontologies using various

automatic ontology quality frameworks. Here, we

aim to learn what makes a good ontology and how the

proposed frameworks measure the right aspects. We

believe that this research also has the potential to

validate the stated connections between metric and

quality characteristics and metric value

recommendations.

REFERENCES

Burton-Jones, A., Storey, V. C., Sugumaran, V., &

Ahluwalia, P. (2005). A semiotic metrics suite for

assessing the quality of ontologies. Data & Knowledge

Engineering, 55(1), 84–102. https://doi.org/10.1016/

j.datak.2004.11.010

Duque-Ramos, A [Astrid], Boeker, M., Jansen, L., Schulz,

S., Iniesta, M., & Fernández-Breis, J. T [Jesualdo

Tomás] (2014). Evaluating the Good Ontology Design

Guideline (GoodOD) with the ontology quality

requirements and evaluation method and metrics

(OQuaRE). PloS One, 9(8), e104463. https://doi.org/

10.1371/journal.pone.0104463

Duque-Ramos, A [Astrid], Fernández-Breis, J. T [Jesualdo

Tomás], Iniesta, M., Dumontier, M., Egaña Aranguren,

M., Schulz, S., Aussenac-Gilles, N., & Stevens, R

[Robert] (2013). Evaluation of the OQuaRE framework

for ontology quality. Expert Systems with Applications,

40(7), 2696–2703. https://doi.org/10.1016/j.eswa.20

12.11.004

Duque-Ramos, A [Astrid], Fernández-Breis, J. T [J. T.],

Stevens, R [R.], & Aussenac-Gilles, N. (2011).

OQuaRE: A square-based approach for evaluating the

quality of ontologies. Journal of Research and Practice

in Information Technology, 43(2), 159–176.

https://www.scopus.com/inward/record.uri?eid=2-s2.0

-84860428632&partnerID=40&md5=dcb393aa78ee79

eca9bfe365b38ed0f1

Duque-Ramos, A [Astrid], Quesada-Martínez, M [Manuel],

Iniesta-Moreno, M., Fernández-Breis, J. T [Jesualdo

Tomás], & Stevens, R [Robert] (2016). Supporting the

analysis of ontology evolution processes through the

combination of static and dynamic scaling functions in

OQuaRE. Journal of Biomedical Semantics, 7(1), 63.

https://doi.org/10.1186/s13326-016-0091-z

Fernandez-Breis, J. T., Franco, M., Vivo, J. M., Quesada-

Martinez, M., Duque-Ramos, A [A.], & Bernabe-Diaz,

J. A. (2018). OQuaRE Calculation Web Service

[Computer software]. Universidad de Murcia.

http://sele.inf.um.es/ontology-metrics

Franco, M., Vivo, J. M., Quesada-Martínez, M [Manuel],

Duque-Ramos, A [Astrid], & Fernández-Breis, J. T

[Jesualdo Tomás] (2020). Evaluation of ontology

structural metrics based on public repository data.

Briefings in Bioinformatics, 21(2), 473–485.

https://doi.org/10.1093/bib/bbz009

Gangemi, A., Catenacci, C., Ciaramita, M., Lehmann, J.,

Gil, R., Bolici, F., & Strignano Onofrio. (2005).

Ontology evaluation and validation: An integrated

formal model for the quality diagnostic task.

OQuaRE Wiki. (2016, November 8). http://miuras.inf.

um.es/oquarewiki

OQuaRE: A SQuaRE based Quality evaluation framework

for Ontologies. http://miuras.inf.um.es/evaluation/

oquare/

Quesada-Martínez, M [M.], Duque-Ramos, A [A.], &

Fernández-Breis, J. T [J. T.] (2015). Analysis of the

evolution of ontologies using OQuaRE: Application to

EDAM. CEUR Workshop Proceedings, 1515.

https://www.scopus.com/inward/record.uri?eid=2-

s2.0-

84960969476&partnerID=40&md5=47f57e4d8749da

deecee72b922fc853a

Harmonizing the OQuaRE Quality Framework

157

Quesada-Martínez, M [Manuel], Duque-Ramos, A [Astrid],

Iniesta-Moreno, M., & Fernández-Breis, J. T [Jesualdo

Tomás]. (2017). Preliminary Analysis of the OBO

Foundry Ontologies and Their Evolution Using

OQuaRE. In R. Randell, R. Cornet, C. McCowan, N.

Peek, & P. J. Scott (Eds.), Studies in health technology

and informatics: volume 235. Informatics for health:

Connected citizen-led wellness and population health

(pp. 426–430). IOS Press. https://doi.org/10.3233/978-

1-61499-753-5-426

Reiz, A. (2020). An Evolutional Based Data-Driven Quality

Model for Ontologies. In H. Alani & E. Simperl

(Chairs), ISWC-DC, Athens, Greece/online. http://ceur-

ws.org/Vol-2798/paper1.pdf

Reiz, A., Dibowski, H., Sandkuhl, K., & Lantow, B. (2020,

November 2–4). Ontology Metrics as a Service

(OMaaS). In Proceedings of the 12th International

Joint Conference on Knowledge Discovery, Knowledge

Engineering and Knowledge Management (pp. 250–

257). SCITEPRESS - Science and Technology

Publications. https://doi.org/10.5220/0010144002500

257

Tartir, S., Arpinar, I. B., Moore, M., Sheth, A. P., &

Aleman-Meza, B. (2005). OntoQA: Metric-Based

Ontology Quality Analysis. In IEEE Workshop on

Knowledge Acquisition from Distributed, Autonomous,

Semantically Heterogeneous Data and Knowledge

Sources, Houston.

Tibaut, A. (2018, March 29). ontology-evaluation.

https://freesoft.dev/program/124565495

Yao, H., Orme, A. M., & Etzkorn, L. (2005). Cohesion

Metrics for Ontology Design and Application. Journal

of Computer Science, 1(1), 107–113.

https://doi.org/10.3844/jcssp.2005.107.113

ICEIS 2022 - 24th International Conference on Enterprise Information Systems

158
