A Recommendation Module based on Reinforcement Learning to an

Intelligent Tutoring System for Software Maintenance

Rodrigo Elias Francisco

1,2 a

and Fl

avio de Oliveira Silva

1 b

Faculty of Computer, Federal University of Uberl

andia (UFU),

Av. Jo

ao Naves de

Avila, 2121, Block 1A, Room 1A243 - Campus Santa M

onica, Uberl

andia, MG, Brazil

Federal Institute Goiano (IF Goiano) - Campus Morrinhos, Rodovia BR153, KM633 Zona Rural, Morrinhos, GO, Brazil

Keywords:

Intelligent Tutoring System, Software Maintenance, Reinforcement Learning, Q-Learning.

Abstract:

The demand for qualiﬁed professionals to work with Software Maintenance (SM) brings challenges to com-

puter education. These challenges are related to SM’s inherent complexity and the teacher’s signiﬁcant work

in providing adequate support in practical SM activities. In this context, Artiﬁcial Intelligence (AI) based

techniques, such as recommendations, can play a central role in developing Intelligent Tutoring Systems (ITS)

to focus the teaching-learning process. The literature points out a lack of ITS to SM and that most of them

do not use AI-based techniques to recommend content to the students. In this work, we present an Expert

Knowledge Module (EKM) for an ITS specially designed for SM. To model the EKM content, we did a deep

analysis of the ACM curricula regarding SM topics and the syllabus related to SM from all Brazilian public

universities. The content recommendation engine uses the Q-Learning algorithm, a well-known Reinforce-

ment Learning (RL) AI-based technique. Using simulation-based experiments, we could verify the efﬁciency

of the Q-Learning-based recommendation mechanism to propose contents using the ITS’s EKM properly. This

work highlights how AI-based techniques can enhance and improve SM’s teaching-learning process using ITS

and advance this research area.

1 INTRODUCTION

Software maintenance (SM) is responsible for about

60% of all costs (Russell and Vinsel, 2017) during

the software life-cycle (Russell and Vinsel, 2017) due

to high consumption of time and effort (Fern

andez-

aez et al., 2018). Learning SM involves handling

complex tasks related to the SM process, understand-

ing and modifying software artifacts. Therefore, com-

puter education needs to help students become profes-

sionals capable of working with SM (Heckman et al.,

2018).

This educational problem brings motivations to

design educational tools based on AI for the SM

teaching-learning process, such as Intelligent Tutor-

ing Systems (ITS). ITS is a software system to en-

hance, adapt, and automate (Alkhatlan and Kalita,

2018) the teaching-learning process. Although there

is ITS’s with different architectures, the ITS gener-

ally works with representations of the three types of

knowledge: the content, the student, and teaching

https://orcid.org/0000-0003-2866-3431

https://orcid.org/0000-0001-7051-7396

strategies.

The literature about ITS for SM presents some

gaps. Few works on tutor system for SM and fewer

less on ITS to SM. Most of the work in the literature

does not detail content recommendations. None of the

ones present some recommendation mechanism that

uses AI-based techniques.

In this work we present the design of the Expert

Knowledge Module (EKM)Expert Knowledge Module

(EKM) module of a ITS for SM and a content recom-

mendation mechanism based on the Q-Learning al-

gorithm, a well-known Reinforcement Learning (RL)

AI-based technique used in several areas (Shawky and

Badawi, 2018). The main contributions of this work

are:

• An ITS with an EKM can handle different types

of content related to SM;

• The EKM modeling resulted from a comprehen-

sive analysis of the computer science curricu-

lum proposed by scientiﬁc societies, namely the

Brazilian Computer Society (SBC) (Zorzo et al.,

2017), and the Association for Computing Ma-

chinery (ACM) (ACM Computing Curricula Task

322

Francisco, R. and Silva, F.

A Recommendation Module based on Reinforcement Learning to an Intelligent Tutoring System for Software Maintenance.

DOI: 10.5220/0011083900003182

In Proceedings of the 14th International Conference on Computer Supported Education (CSEDU 2022) - Volume 1, pages 322-329

ISBN: 978-989-758-562-3; ISSN: 2184-5026

Force, 2013), and the syllabus related to SM used

by all Brazilian public universities.

• A content recommendation mechanism that uses

the Q-Learning algorithm whats brings AI to en-

hance the results of the ITS, and that showed its

efﬁciency in different usage scenarios.

We organized work as follows: section 2 describes

the related literature and presents some gaps in this

area. She section 3 describes the design of the EMK

module and the content recommendation strategy fo-

cusing on the SM domain using the Q-Learning algo-

rithm. Section 4 describes the simulation process and

discusses its results. Finally, Section 5 presents some

concluding remarks and future work.

2 RELATED WORK

Table 1 details information about the literature related

to Tutor Systems for SM found in the literature. First,

the table presents if the tutor system is an ITS. When it

is an ITS, the table also shows the modules described

in work using the same name proposed by the au-

thor. The table presents the subject of SM that the

research addresses. The table describes if the ITS has

a content recommendation mechanism and the corre-

sponding recommendation technique indicating based

on AI and highlights if the work describes the tutor

module. The subjects related to SM are Software De-

bugging (SD), Software Refactoring (SR), and Soft-

ware Understanding (SU).

We found some AI techniques in the literature.

Case-based reasoning (CBR) is a strategy that in-

volves the base of a case that is frequently updated

and makes it possible to retrieve stored cases to assist

in solving a new case. Natural Language Processing

(NLP) uses AI algorithms and linguistic knowledge

to work with human language in a given language. Q-

Learning is a Reinforcement Learning (RL) algorithm

that works with the metaphor of an agent inserted in

an environment and performs actions to achieve some

goal. The reinforcement obtained in the perception of

the result makes it possible to create a model at run-

time to guide these actions.

A Socratic ITS and its authoring tool (Alshaikh

et al., 2021) were proposed for teaching-learning of

software understanding. This work applied Natural

Language Processing to generate and interpret stu-

dent dialogues about source code artifacts. They also

used dialogues created by experts. The research ap-

proached the innermost loop of ITS, where the tutor

module performs actions that aim to help the student

understand a speciﬁc source code artifact through di-

alogues. The domain module wraps the programs’

source code artifacts and uses the abstract syntax tree.

This work did not propose any recommendation strat-

egy.

The work of (Oberhauser, 2017) presents an ap-

proach for the recommendation, navigation, and 3D

visualization of source code. This work uses a rec-

ommendation service based on a theoretical model

of program understanding and data related to Metho-

dRank metrics for source code, ﬁltering processing,

distance calculations, and points of interest in source

code. Their goal was to understand software from an

exploratory, analytical, and descriptive cognitive pro-

cess perspective. This work did not address any AI

technique and did not describe any module related to

the concept of ITS.

Another work, an ITS for the software debug-

ging domain (Carter and Blank, 2013) that uses the

CBR technique. The authors claim that the debugging

activity performed by the programmer is inherently

case-based. Although this research does not address

recommendations, the work implements the follow-

ing ITS modules: domain, tutor, student, and com-

munication. The domain module comprises syntax,

runtime, and logical errors cases.

The Interactive Tutor System RefacTutor

(Haendler et al., 2019) focus software refactoring.

The work strategy uses software understanding as

support to approach refactoring.

The analysis of the works presented provides es-

sential information for this research. Few of them fo-

cus on Tutor Systems for SM and even less on ITS

for SM. The literature found addresses only three SM

topics. The only work that addressed content recom-

mendation for SM did not present an AI technique.

Furthermore, the papers describe little about how Tu-

tor Systems or ITS for SM modules represent the sys-

tem domain data.

3 DESIGN OF THE ITS FOR SM

USING Q-LEARNING

This work is part of a larger research that aims to de-

sign, develop and deploy an ITS for SM. This ITS has

an architecture which has Tutor, Student, EKM and

User Interface Modules. One goal of this ITS is that

it can adaptively recommend and offer support to the

teaching-learning process of SM. This work focus on

the EKM and the content recommendation function-

ality performed by the Tutor Module.

Our content recommendation mechanism uses RL

based on the Q-Learning algorithm, which reﬁnes its

decision model according to the results of previous

recommendations. The EKM design started from a

A Recommendation Module based on Reinforcement Learning to an Intelligent Tutoring System for Software Maintenance

323

Table 1: Papers on Tutoring Systems for SM.

Reference

ITS (Yes/No/All

Modules? Which

Modules?)

Subject Recommend.

Recommend.

Technique

AI-Based

Technique

Tutor

Mod.

(Carter and Blank, 2013)

Yes / All / Modu-

les: domain, tutor,

student and commun.

SD No No

Case-based

reasoning

Yes

(Haendler et al., 2019) No SR, SU No No No No

(Oberhauser, 2017)

Yes / Part. / Modu-

le: recommender

SU Yes MethodRank No No

(Alshaikh et al., 2021)

Yes / Part. /

Modules: domain,

tutor

SU No No

Natural L.

Processing

Yes

THIS WORK

Yes / Part. / Modu-

les: exp. knowledge,

tutor

SM Yes Q-Learning Q-Learning Yes

Software Debugging (SD) - Software Maintenance (SM) - Software Refactoring (SR) - Software Understanding (SU)

requirement analysis of the SM educational context,

assuming that it would be a component of ITS that

could provide an automated recommendation.

3.1 Expert Knowledge Module (EKM)

The EKM has an abstraction of the content that sup-

ports activities that the ITS provides to students. In

this section, we present the rationale used to model

the EKM, and we show a categorization of the activi-

ties capable of supporting the several topics related to

SM.

To model the EKM, we carried out a survey of

SM topics in the curriculum of all Brazilian Federal

Universities that have courses in the computing area,

such as Computer Science and Software Engineer-

ing, to contribute to the creation of the EKM. We

chose all Brazilian Federal Universities because they

have geographic coverage throughout Brazil, which

allowed for contemplating the diversity of SM cur-

ricula. In addition, to gather the requirements of the

EMK, we added to this survey the Reference Cur-

ricula proposed by the Brazilian Computer Society

(SBC) (Zorzo et al., 2017), and Association for Com-

puting Machinery (ACM) (ACM Computing Curric-

ula Task Force, 2013) concerning SM.

The survey of topics covered in SM was neces-

sary to support the pedagogical and technical deci-

sions around the construction of an ITS.

The pedagogical assumptions consider the possi-

bility of teaching SM so that learning begins with

practical experiences, which gradually contributes to

increasing the conceptual knowledge.

The technical assumptions considered an EKM for

the SM domain that can be reused, expanded, and

aligned with the architectural design of an ITS. The

EKM should contribute to the operationalization of

the SM content by using AI based algorithms. The

content modeling should deﬁne a semantic that eases

in creating and modifying activities in ITS. Finally,

we consider in the design decisions that the content

managed by the EKM and recommended by the Tu-

tor Module should facilitate the process of evaluating

AI algorithms in instantiating them in an ITS suited

to SM.

We organize the topics raised into four categories:

A - Software Understanding, B - SM Practice, C - SM

Testing, and D - Concepts Understanding. This cate-

gorization allowed the planning of the types of activ-

ities addressed by ITS, as shown in Table 2. We used

Bloom’s Revised Taxonomy (Amer, 2006) to estimate

the dimensions of the cognitive process necessary by

students in each type of activity.

Next, we will present each of these categories and

the topics covered in the SM curricula:

• Category A - Software Understanding includes

the following topics: understanding software ar-

tifacts, reuse, legacy systems, and concerns and

concern location. This category reﬂects the

need for the SM student to build mental models

about software representation to make decisions

of change in SM.

• Category B - SM Practice has the following top-

ics: types of software maintenance, refactoring,

covers SM practice, reverse engineering, reengi-

neering, and debugging. This category contributes

to the proposal of practical SM activities involv-

ing source code for speciﬁc systems that may in-

clude these topics.

• Category C - SM Testsing encompasses only test-

ing in the context of SM

• Category D - Concepts Understanding was di-

vided into two subcategories: D1 - SM Process,

D2 - Software Maintainability.

– D1 - SM Process includes the following topics:

CSEDU 2022 - 14th International Conference on Computer Supported Education

324

Table 2: Activities categorized with Bloom’s Taxonomy.

Activity Type Rememb. Underst. Apply Analyze Evaluate Create Nº Dimens.

A1 - Understand the result

of execution (source code)

x x 2

A2 - Order the program

(parson puzzles)

x x x x 4

A3 1 - Reply to abstract

(source code)

x x x x 4

A3 2 - Reply to abstract

(UML models)

x x x x 4

B1 - Defect Fix type SM

x x x x x x 6

B2 - SM of the Environ.

Adaptation type

x x x x x x 6

B3 - SM of Add Funct. type

x x x x x x 6

B4 - Refactoring x x x x 4

C1 - Tests x x x x x 5

D1 - SM Process x x 2

D2 - Maintainability of

Software

x x 2

Figure 1: Expert Knowledge Module Partial Class Diagram.

process, migration, the relationship between

SM types, conﬁguration and change manage-

ment, effort estimation, software repository

mining, evolution laws, SM generical, predic-

tion Analysis, Impact Analysis, Software Evo-

lution, and Integration and Continuous Deliv-

ery.

– D2 - Software Maintainability has the follow-

ing topics: maintenance problems, mainte-

nance cost, maintainability and metrics for soft-

ware maintainability, and (re)documentation.

As a result of the assumptions, design decisions,

the survey of SM topics, and its categorization, pre-

sented in Table 2, we modeled the EKM. Figure 1

presents a partial class diagram of the EKM classes.

Activity types are represented by the class Activ-

ityType and are categorized by ActivityCategory. Di-

dacticMaterial, which represents the activities, is re-

lated to a given ActivityType and has the ﬁelds score

and demandedCapacity to represent the score and the

capacity that the student needs to be able to get it right

the question in the simulation.

Capacity has three dimensions: knowledge di-

mension, social dimension, and intelligence dimen-

sion. This work emphasizes only the dimensions of

knowledge, subdivided into software understanding,

SM practice, tests, and concept understanding. Stu-

dent represents the student, who has a grade (“score”)

and capacity.

3.2 Content Recommendation

An ITS needs a model capable of allowing its Tutor

Module to make appropriate pedagogical decisions.

These decisions include recommending content con-

sidering the student’s learning status concerning the

SM content at a given time. We choose to use the

Q-Learning algorithm, which builds and improves

the model at run-time and does not depend on prior

knowledge of experts to build the model.

The Q-Learning (Shawky and Badawi, 2018) al-

gorithm, used in this proposal to recommend contents,

uses an RL algorithm that models the best actions for

certain states and stores this model in the Q matrix.

The equation, presented in 1 represents the way the

algorithm updates the matrix. At certain moments

random choices occur in a controlled manner.

Q(s, a) = Q(s, a) + α[r + γ ∗ (maxQ(s

, a

)) − Q(s, a)] (1)

The update of the Q matrix occurs whenever the

algorithm performs an action recommendation and

does its execution. Q(s, a) represents the beneﬁt of

doing action a in state s. α and γ are the learning

rate and discount factor parameters. The maxQ(s’, a’)

function returns the score of the best possible action

(a’) in the new state (s’).

A Recommendation Module based on Reinforcement Learning to an Intelligent Tutoring System for Software Maintenance

325

To use Q-Learning it is necessary to model the

states and actions of the environment in question and

to calibrate their parameters. In a simpliﬁed way, this

algorithm represents an agent that performs actions

in the background and receives reinforcement, which

can be positive or negative, on these actions. Upon

receiving the reinforcement, the algorithm updates its

model with the memory of the result of the executed

action. In our Q-Learning conﬁguration, the recom-

mended actions represent a Didactic Material (DM),

and the states represent the scores of the students.

4 SIMULATION AND

DISCUSSION

Using simulation, we evaluated the EKM and the

content recommendation mechanism based on the Q-

Learning algorithm. In this work, the evaluation fo-

cuses only on the knowledge dimension considering

the student Capacity presented in Figure 1. This sec-

tion details the simulation process and presents a dis-

cussion about the results.

4.1 Simulation Process

Figure 2 details the simulation process and presents

the sequence of activities between the following ac-

tors: the teacher, the ITS, and the student coordinated

by the simulator. Initially, the teacher selects a set of

students and a set of DM’s and conﬁgures the learning

session with the appropriate Q-Learning parameters.

The simulator will traverse the student set. During

this process, the simulator ﬁrst veriﬁes if there is a

DM is available. If yes, the ITS uses the Q-Learning

algorithm and the student’s current proﬁle to recom-

mend a DM. The student solve the DM. In the simu-

lation process, the simulator infers success or failure

for the DM. When no more DM is available for the

student, the simulator displays the results.

The simulator infers success or failure by

verifying if the student’s capacity (attribute Stu-

dent.capacity) is sufﬁcient to solve the DM consid-

ering its DM.demandedCapacity. If the student has

enough capacity, the simulator updates the current

student capacity, its score and the list of solved DM’s.

Using the simulator, we create a set of students in

the ITS using a default constructor. The initial param-

eter for the simulator is the size of the set. Initially all

the students capacity attributes (softwareUnderstand-

ing, practiceSM, testSM and understandingConcepts)

are set to zero. The student score of student represents

the number of activities solved correctly and initially

is also zero.

The simulator creates a set of DM to mimic the

DM selection by the teacher. The simulator receives

the size of the DM set and creates activities of every

type (ActivityType) to the given size. The simulator

calculates the required capacity for each activity. The

attribute categoryActivity deﬁnes the activity category

and indicates knowledge dimension attributes associ-

ated with the attribute demandedCapacity. The Al-

gorithm 1 describes the calculation of the demanded

knowledge capacity and the score for a given DM.

Algorithm 1: Calculate Demand Capacity and DM Score.

Let n be the number of DM for a given Activity

Type: DM[i] | i>=1, i<=n;

Let j be the indication of the Activity Category and

Demanded Capacity (knowledge dimension) of

the DM[i];

i=1;

while i<=n do

DM[i].demandedCapacity[j] = i *

(numBloomDimensions / n);

DM[i].score = numBloomDimensions / n;

i++;

end

To conﬁgure the learning sessions, the teacher de-

scribes the average number of times a student tries

to solve a DM and the parameters of the Q-Learning

algorithm: positive reinforcement, negative reinforce-

ment, learning rate, discount factor, and indicator of

the percentage of exploitation.

The recommendation of DM’s follows the se-

quence of generated students. Initially, the simulator

creates a Q matrix. For each student, while the student

has not reached the maximum score or the maximum

number of attempts, the ITS recommends a DM to the

student. The simulator changes the student state and

updates the Q matrix.

4.2 Results and Discussion

To evaluate the content recommendation module ac-

cording to the EKM proposed, we did several simu-

lations using different parameters conﬁgurations for

the Q-Learning algorithm. We used ten (10) different

conﬁgurations with the same simulation scenario.

The simulation scenario consisted of ten (10) stu-

dents and a set with 110 DM’s for each student. We

created ten (10) DM’s for each of the eleven (11)

types of activity presented in Table 2. The goal of

each experiment was to use the recommendation sys-

tem until each student reached the maximum score,

in this case, 110 considering one point to each DM’s

correctly solved.

Table 3 presents the different settings for the Q-

Learning algorithm in each experiment. The Max.

CSEDU 2022 - 14th International Conference on Computer Supported Education

326

Figure 2: Simulation Process.

Table 3: Experiments and Results of Simulation for the Content Recommendation.

Experiment 1 2 3 4 5 6 7 8 9 10

Max. Number of Attempts 330 330 440 660 770 550 550 550 550 550

Exploration Percentage (%) 50 33,3 25 20 20 16,6 16,6 16,66 12,5 12,5

Positive Reinforcement 4 4 4 10 8 9 15 15 13 13

Negative Reinforcement -4 -4 -4 -9 -8 -9 -15 -15 -13 -13

Learning Rate (α) 0,12 0,12 0,12 0,16 0,16 0,4 0,4 0,5 0,5 0,7

Discount Factor (γ) 0,9 0,9 0,9 0,7 0,7 0,8 0,8 0,8 0,8 0,7

Number of Recommendations: 1473 1538 1569 1388 1408 1303 1276 1342 1326 1361

Number of Attempts sets the maximum number of at-

tempts a student makes to solve the complete DM

set. The Exploitation Percentage deﬁnes the pol-

icy of the Q-Learning algorithm to explore the envi-

ronment. Positive reinforcement, negative reinforce-

ment, learning rate, and discount factor are param-

eters used by Q-Learning to update its model upon

receiving reinforcement. The Number of Recommen-

dations indicates the total recommendations that were

necessary for all students to perform all DM’s cor-

rectly. This number is related to the efﬁciency of the

experiment, and the lower is better.

Experiments number 6 and 7 had the best results,

as they needed fewer recommendations to reach the

maximum score. These experiments have very simi-

lar conﬁgurations, and the only difference was the pa-

rameters referring to positive and negative reinforce-

ment. There are indications that a relatively low ex-

ploitation percentage, as in the case of 16.6%, con-

tributes to the efﬁciency of the experiment, which is

related to the idea of privileging the Q-Learning algo-

rithm model instead to work randomly. Experiments

2 and 3 had the worst results. We can observe that

their exploitation percentages are among the highest,

which indicates a more random behavior.

The simulation contributed to evaluating the con-

tent recommendation functionality of the Tutor Com-

ponent with the EKM at design time. Furthermore,

the experiments showed that the EKM could be prop-

erly operationalized by the simulation process and by

the content recommendation functionality of the Tu-

tor Component.

To highlight the beneﬁts of the recommendation

module based on the Q-Learning algorithm, we will

describe a hypothetical scenario with no recommen-

dation using two different types of students. We mod-

eled these students using average data from under-

graduate computer science students (Tomkin et al.,

2018).

The scenario is the same: a set of ten (10) students

and a set with 110 DM’s, ten (10) different DM’s for

each of the eleven (11) types of activity presented in

Table 2. In each cycle, each type of student tries to

solve all the DM’s. We assumed one ability to hit a

DM for each cycle, and between cycles, we assumed

an increment of this ability.

Table 4 presents these values and details the hy-

pothetical scenario considering the types of students.

The Number of Attempts (set size) is the size of the set

of DM’s that the student needs to solve in each cycle.

Increment (Inc.) shows the increase in the correctness

capacity in a speciﬁc cycle for a given type of student.

The Ability to Hit shows the total capacity to solve

each DM correctly after the increment of the capacity.

Number of Hits (No. Hits) is the number of DM’s that

the student solved correctly in the cycle. The table

summarizes the overall performance for each type of

student, presenting the total Number of Attempts for

one and ten students. For both student types, the in-

crement of hit ability occurs in a non-linear way. The

hypothetical Student Type #1 starts with a slight hit

ability of 20% with a gradual increment (0%, 10%,

10%, 10%, 20%, 30%). In contrast, the hypothetical

student of type #2 starts with a correctness capacity

of 50% with different gradual increments (0%, 15%,

15%, 20%) in each cycle.

Figure 3 presents a comparison between the two

types of hypothetical students. The vertical line of the

A Recommendation Module based on Reinforcement Learning to an Intelligent Tutoring System for Software Maintenance

327

Table 4: Hypothetical scenario of DM resolutions.

Student

Type #1

Student

Type #2

Cycle

No. Attempts

(set size)

Inc.

Ability

to Hit

No. Hits

No. Attempts

(set size)

Inc.

Ability

to Hit

No. Hits

1 110 0% 20% 22 110 0% 50% 55

2 88 10% 30% 26,4 55 15% 65% 35,75

3 61,6 10% 40% 24,64 19,25 15% 80% 15,4

4 36,96 10% 50% 18,48 3,85 20% 100% 3,85

5 18,48 20% 70% 12,93 - - - -

6 5,54 30% 100% 5,54 - - - -

No. of Attempts

(1 student)

320,584 188,1

chart displays the cumulative number of DM’s hits,

the maximum of which is 110. The horizontal line

of the chart shows the cycles in which students try

to solve the complete set of DM’s, where the Student

Type #1 uses six cycles, and student type #2 uses four

cycles. Student Type #2 has a higher DM’s resolution

capability than Student Type #1, which allows it to

resolve DM’s faster.

Figure 3: Comparison between the Students Types.

Student of Type #1, which can be considered a

student with lower ability, would need approximately

320 attempts to solve the 110 DM’s, and the total for

ten students of this type would require around 3206

attempts to solve these 110 DM’s. The Student Type

#2, who is considered a student with average ability,

would need 188,1 attempts to solve these 110 DM’s,

and ten students of this type would need 1881 at-

tempts to solve these 110 DM’s.

Content recommendation and the EKM for ITS

for SM presented in this work, according to the simu-

lation’s parameters described in Experiment 7, allow

ten virtual students to solve the 110 DM’s with 1276

recommendations. This information enables us to es-

timate the improvement that the proposal can bring

to the efﬁciency of the SM teaching-learning process

when considering two types of hypothetical students.

The recommendation method and the EKM pro-

posed in this work reduce by approximately 60,2 %

of the number of attempts compared to the Type #1

students, so instead of 3206 attempts, only 1276 ones

are necessary to solve the complete DM set by all stu-

dents. When considering students Type #2, which has

a higher ability from the beginning, we can see a re-

duction of approximately 32,2 %, with 1276 attempts

to solve all the DM set compared to 1881 attempts.

Thus, the results of this work overcome the hypo-

thetical scenario described, whose types of students

designed meet beginner (Student Type #1) and aver-

age (Student Type #2) ability levels.

5 CONCLUSION

The literature on Tutor Systems for SM has gaps

available for investigation. Furthermore, there are few

initiatives to address the concept of ITS for SM. In

the literature, we did not ﬁnd a content recommenda-

tion method for SM applied in the context of an ITS,

which shows that this research contributes to advanc-

ing the state-of-art. Moreover, the only mechanism of

recommending SM-related content found in the liter-

ature does not use any AI-based technique.

We have realized the importance of providing

Computer Science students with learning based on

SM’s practical and conceptual experience and the dif-

ﬁculty of this for teachers. An ITS can be very

promising in solving this problem.

This work contributes to this area and presents

an ITS with an EKM capable of handling different

types of content related to SM. The EKM modeling

resulted from a comprehensive analysis of the com-

puter science curriculum based on scientiﬁc societies,

namely ACM and SBC, and the syllabus related to

SM from all Brazilian public universities. The EKM

brings the capacity representation, which includes the

SM knowledge dimension and the social and intel-

lectual dimensions; the student representation, which

consists of the ability and the score; and the neces-

sary models for the SM content, which are activity

category, activity type, and the DM.

Other researchers can explore the EKM modeling

CSEDU 2022 - 14th International Conference on Computer Supported Education

328

presented to reuse and reﬁne it to build an ITS suitable

to SM that can help the SM teaching-learning process.

Our contribution goes further in this area, and we

introduce a content recommendation method based on

the Q-Learning algorithm whats brings AI to enhance

the results of the ITS.

The experiments showed that the content recom-

mendation, through the Q-Learning algorithm, man-

ages to make recommendations that improve over

time. The experiment that reached the maximum

score performed 1276 DM’s recommendations, and

this indicates the efﬁciency of Q-Learning algorithm.

As there are ten students and 110 DM’s, an ideal situ-

ation where students do not wrong DM’s is composed

of 1100 recommendations, which is very close to the

experiment’s value.

Using two types of hypothetical students, one with

a low learning ability, called Student of Type #1, and

another one with an average learning ability, called

Student of Type #2, we made a comparison with

our recommendation method. The results showed

that our recommendation method improved approx-

imately 60.2 % compared to students with lower abil-

ity and 32.2 % to students with average ability.

We intend to investigate data clustering algorithms

to extend the ITS student’s module for SM in future

work. We will evaluate its inﬂuence on the content

recommendation. Moreover, we will deploy and as-

sess our ITS for SM in the educational context and

corporate SM training using a real-world experimen-

tal scenario.

ACKNOWLEDGEMENTS

This work is inside UFU-CAPES.Print Program. This

study was ﬁnanced in part by the Coordenac¸

ao de

Aperfeic¸oamento de Pessoal de N

ıvel Superior –

Brasil (CAPES) – Finance Code 001. This research

also received the support from PROPP/UFU.

REFERENCES

ACM Computing Curricula Task Force, editor (2013).

Computer Science Curricula 2013: Curriculum

Guidelines for Undergraduate Degree Programs in

Computer Science. ACM, Inc.

Alkhatlan, A. and Kalita, J. (2018). Intelligent tutoring sys-

tems: A comprehensive historical survey with recent

developments. arXiv preprint arXiv:1812.09628.

Alshaikh, Z., Tamang, L., and Rus, V. (2021). Experiments

with Auto-generated Socratic Dialogue for Source

Code Understanding:. In Proceedings of the 13th In-

ternational Conference on Computer Supported Edu-

cation, pages 35–44, Online Streaming, — Select a

Country —. SCITEPRESS - Science and Technology

Publications.

Amer, A. (2006). Reﬂections on bloom’s revised taxon-

omy. Electronic Journal of Research in Educational

Psychology, 4(1):213–230.

Carter, E. and Blank, G. D. (2013). An intelligent tutor-

ing system to teach debugging. In International Con-

ference on Artiﬁcial Intelligence in Education, pages

872–875. Springer.

Fern

andez-S

aez, A. M., Chaudron, M. R., and Genero,

M. (2018). An industrial case study on the use of

uml in software maintenance and its perceived ben-

eﬁts and hurdles. Empirical Software Engineering,

23(6):3281–3345.

Haendler, T., Neumann, G., and Smirnov, F. (2019). Refac-

tutor: an interactive tutoring system for software

refactoring. In International Conference on Computer

Supported Education, pages 236–261. Springer.

Heckman, S., Stolee, K., and Parnin, C. (2018). 10+

years of teaching software engineering with itrust: the

good, the bad, and the ugly. In 2018 IEEE/ACM 40th

International Conference on Software Engineering:

Software Engineering Education and Training (ICSE-

SEET), pages 1–4. IEEE.

Oberhauser, R. (2017). Visitr: 3d visualization for code

visitation trail recommendations. International Jour-

nal on Advances in Software Volume 10, Number 1 &

2, 2017.

Russell, A. and Vinsel, L. (2017). Andrew

Russell and Lee Vinsel. Let’s Get Ex-

cited About Maintenance! Available in

https://www.nytimes.com/2017/07/22/opinion/sunday

/lets-get-excited-about-maintenance.html. Accessed

in November 13, 2020.

Shawky, D. and Badawi, A. (2018). A reinforcement

learning-based adaptive learning system. In Inter-

national Conference on Advanced Machine Learn-

ing Technologies and Applications, pages 221–231.

Springer.

Tomkin, J. H., West, M., and Herman, G. L. (2018). An

Improved Grade Point Average, With Applications to

CS Undergraduate Education Analytics. ACM Trans-

actions on Computing Education, 18(4):17:1–17:16.

Zorzo, A. F., Nunes, D., Steinmacher, I., Leite, J. C.,

Araujo, R., Correia, R. C. M., and Martins, S.

(2017). Referenciais de Formac¸

ao para os Cursos de

Graduac¸

ao em Computac¸

ao 2017.

A Recommendation Module based on Reinforcement Learning to an Intelligent Tutoring System for Software Maintenance

329
