Detection of Urinary Biomarkers for Early Diagnosis of Pancreatic

Cancer by Data Analysis

Chi Le

1,† a

, Yucheng Liu

2,† b

, Fangyi Tian

3,† c

and Yang Xu

4,† d

ZJU-UoE Institute, Zhejiang University, Hangzhou, Zhejiang, China

College of Animal Sciences & Technology, Huazhong Agricultural University, Wuhan, Hubei, China

Basic Medical School, Capital Medical University, Beijing, China

College of Life Sciences, Nanjing Agricultural University, Taizhou, Jiangsu, China

†

These authors contributted equally

Keywords: Pancreatic Cancer, Diagnosis, Urinary Biomarkers.

Abstract: In this sample-structured document, neither the cross-linking of float elements and bibliography nor

metadata/copyright information is available. The sample document is provided in “Draft” mode and to view

it in the final layout format, applying the required template is essential with some standard steps.

According to data released by the American Cancer Society in 2019, the mortality rate caused by pancreatic

cancer ranks fourth among malignant tumors. By 2030, the incidence of Pancreatic ductal adenocarcinoma

(PDAC) will continue to increase and may become the second leading cause of death among all tumor

diseases. If the tumor could be detected and resectted at an early stage, the survival rate of PDAC patients

will be greatly improved. However, symptoms rarely show until the cancer reaches its advanced stage and

most of the available treatments are palliative. Therefore, most patients have reached the advanced stage of

cancer when they are diagnosed and thus having poor prognoses. Therefore, we are interested in the early

detection, prediction and diagnosis of pancreatic cancer, and we will discusse which factors are related to

pancreatic cancer in the following parts.

We collected a total of 590 samples in which 7 attributes, age, CA 19–9 (Carbohydrate antigen199),

creatinine, LYVE1 (Lymphatic Vessel Endothelial Hyaluronic Acid Receptor 1), REG1B (regenerating islet-

derived 1 beta), TFF1 (Recombinant Trefoil Factor 1) and REG1A (Recombinant Human Regenerating Islet-

Derived Protein 1-alpha) were selected as our independent variables. The dependent variable Y is diagnosis

which indicates whether a participant has pancreatic cancer. Logistic regression and lasso regression were

used to construct a model for the prediction of pancreatic cancer. All analyses above were performed using R

software, version 4.1.1.

We finally found that the distributions of Blood plasma levels of CA 19–9 monoclonal antibody, creatine,

LYVE1, REG1B, TFF1 and REG1A are all positive skewed and asymmetrical. In addition, people's illness is

significantly related to age, creatine, LYVE1, REG1B, TFF1 and REG1A. However, the level of CA 19-9

monoclonal antibody in the human body is not so significantly correlated with the corresponding human

disease. After selecting appropriate methods and analyzing a large amount of data, according to the regression

results, etc., we can conclude that the incidence of PDAC disease is significantly related to age and gender.

Based on this, in the follow-up research, it has provided the possibility for early prediction and disease

prevention and control of PDAC based on age and gender, and also provided new ideas for the pharmaceutical,

treatment and daily care of the disease.

https://orcid.org/0000-0003-4414-3073

https://orcid.org/0000-0002-3095-9904

https://orcid.org/0000-0003-0536-6127

https://orcid.org/0000-0001-9482-5887

Le, C., Liu, Y., Tian, F. and Xu, Y.

Detection of Urinary Biomarkers for Early Diagnosis of Pancreatic Cancer by Data Analysis.

DOI: 10.5220/0011228500003438

In Proceedings of the 1st International Conference on Health Big Data and Intelligent Healthcare (ICHIH 2022), pages 56-61

ISBN: 978-989-758-596-8

1 INTRODUCTION

The pancreas is an organ located in the abdomen and

it plays an important role in converting the food we eat

into energy for body's activities. Pancreatic cancer is

one of the most common digestive tract malignancies.

It begins in the tissue of pancreas and is an extremely

deadly type of cancer, which is ranked as fourth

leading cause of cancer-related mortality in western

countries (Zeng et al., 2019). 90% of pancreatic

malignancies are pancreatic ductal adenocarcinoma

(PDAC) (He et al., 2014). Symptoms rarely shows

until the cancer reaches its advanced stage and most of

the available treatments are palliative (Adamska,

Domenichini and Falasca, 2017). With over 80% of

cases diagnosed at advanced stages, PDAC patients

have a median survival of 5-6 months, and the overall

5-year survival rate is less than 10% because patients

are diagnosed too late (Arnold et al., 2019). However,

if we can detect and resect the tumor at an early stage

of PDAC, the survival rate of cancer patients can be

greatly improved.

Therefore, we are interested in the early detection,

prediction, and diagnosis of PDAC, and trying to find

out what factors are related to pancreatic cancer. Also,

the development of non-invasive diagnosis to detect

early PDAC becomes an urgent need. Non-invasive

diagnostic technology can avoid or reduce pancreatic

biopsy to identify PDAC fibrosis early, and can

perform dynamic monitoring, which has important

clinical application value. Nevertheless, there is no

reliable, non-invasive screening test to detect PDAC

accurately and those methods are expensive (Brezgyte

et al., 2021). By contrast, detecting biomarkers for the

diagnosis of PDAC is minimally invasive and

relatively cheap.

Serum CA19-9, the only biomarker in clinical

practice currently, is less specific and sensitive for

screening purposes and is mainly used to monitoring

treatment response (Ballehaninna and Chamberlain,

2012). Previous studies have found that urine, an

alternative biological fluid has many advantages, such

as accumulation of biomarkers at higher concentra-

tions so that the biomarkers are easy to be detected.

Certain urinary metabolites can indicate malignancy

of various organs, possibly reflecting the metabolic

effects of cancer (Dinges, et al., 2019). Creatinine is a

product of muscle metabolism and is primarily cleared

by the kidneys (Delanaye, Cavalier and Pottel, 2017).

Therefore, biostatistical methods such as model

analysis can be used to identify more effective and

stable biomarkers and provide a reference basis for

early-stage PDAC detection and diagnosis, clinical

practice, related treatment and so on.

In the existing literature, a regression model

PancRISK have been developed using three protein

biomarkers to detect pancreatic cancer and classify

PDAC patients. Researchers of this experiment

creatively replaced REG1A with REG1B, showing

the ability of our urinary panel to distinguish control

individuals and patients with benign hepatobiliary

diseases from early stage PDAC patients with

specificity and sensitivity >85%. On the basis of these

studies, our team explored the previous research to

make some bold assumptions and continued to use

PancRISK with other methods to analyze data basing

on the original database to evaluate whether PDAC is

related to age, gender and other factors.

2 METHODS

2.1 Data Source

The data was selected from the Kaggle platform.

Kaggle is an open online platform, mainly for

developers, data scientists and anyone in need to

provide a platform for holding machine learning

competitions, hosting databases, and writing and

sharing code. The data comes from the data set in a

paper published by Silvana Debernardi and

colleagues in the journal PLOS Medicine on

December 10, 2020. The paper and the complete data

set are open access.

590 clinical specimens were obtained from

different centers: Barts Pancreas Tissue Bank,

University College London, University of Liverpool,

Spanish National Cancer Research Center, Cambridge

University Hospital, and University of Belgrade.

590 urine specimens were assayed and there were

three groups: 183 individuals who had no pancreatic

diseases in control group (group 1), 208 patients who

had benign hepotobiliary diseases in benign group

(group 2) and 199 PDAC patients before treatments

(group 3). 50.7% specimens were obtained from

female individuals.

Among these three types of samples, benign

samples included 119 CP cases, 54 gallbladder

diseases, 20 cystic lesions of the pancreas, and 15

cases with abdominal pain and gastrointestinal

symptoms suggestive of pancreatic origin.

In group 3, PDAC patients had 6 stages: 102 I-II

(IA, IB, IIA) and 97 III-IV (IIIB, III, IV)

Besides, there were 67 patients in urine specimens

with common urological tract malignancies: 18

patients with prostate cancers (PC) (median age 69

years, range 52–83), 29 patients with renal cell

carcinoma (RCC) (median age 67 years, range 20–

Detection of Urinary Biomarkers for Early Diagnosis of Pancreatic Cancer by Data Analysis

85), and 20 patients with bladder transitional cell

cancer (TCC) (median age 65 years, range 44–81).

The restriction is that the number of I–IIA PDAC

samples is low (n=27). In addition, the study used

samples collected from control individuals as

replacements for the lack of specimens from

individuals with hereditary predisposition to PDAC.

350 matched plasma specimens for samples (92

control, 108 benign, and 150 PDAC).

Our dataset Urinary biomarkers for pancreatic

cancer was downloaded from Kaggle, which was

uploaded in 2020.

2.2 Variable Measuring

The required urine and plasma samples were

collected from multiple centers after the respective

institutional review board approvals, and the potential

impact of bacterial growth on urine biomarkers was

tested with 20 mg/ml boric acid. Finally, the samples

were maintained at a low temperature of -80°C.

Commercially sourced ELISA kits were used for

assaying the biomarkers: lymphatic vessel

endothelial hyaluronan receptor 1 (LYVE1), trefoil

factor 1 (TFF1), regenerating family member 1 beta

(REG1B) and plasma CA19-9. Each measurement

was run in duplicate, and further repeats were

performed when there was a discrepancy. The

FLUOstar Omega Microplate Reader was used to

determine optical density. The Roche platform

(Cobas 601E [ECLIA] technology) at The Doctors

Laboratory in London was used to measure plasma

CA19-9. Urine creatinine was determined at the

Clinical Biochemistry Laboratory of the University of

Westminster using an ILab Aries analyser from

Instrumentation Laboratory.

All the research staff who performed the

experiments did not know about the sample diagnosis.

All protein concentration data were natural-log-

transformed and mean-centred.

2.3 Data Analysis

The values obtained from open access were analyzed

by exploratory data analysis firstly. At the beginning,

there were 14 original attributes and we finally

selected 7attributes age, CA 19–9, creatinine,

LYVE1, REG1B, TFF1 and REG1A as our

independent variables. The other 7 attributes are

confounders. The dependent variable Y is diagnosis

which indicates whether a participant has pancreatic

cancer. To meet the requirements of logistic

regression, all the category variables were coded by 0

and 1. After that, we chose to use random forest

algorithm to interpolate all the not available data in

the dataset. To explore the relationship between

independent variable and response, boxplots were

chosen to demonstrate the independent variables

visually (Fig 1.). It should be noted that all the

independent variables except the creatinine are

greater in the pancreatic cancer group significantly.

The χ2 test is used to test the correlation between sex

and diagnosis. The t-test is employed for the purpose

of testing the correlation between all independent

variables and dependent variables. To further explore

influence of interactions between the independent

variables, P-value was calculated.

In logistic regression, the logit function of p is used

to modeling the log odds of response variable as a

suitable transformation. In our study, we found that

some variables were highly correlated with others, in

which case their interactions are possible to differently

effect the response compared to single independent

variable. According to the result of correlation

analysis, we kept all the significantly-correlated

interactions of two variables. Lasso analysis were

performed to further select useful variables and

interactions. Next, we performed best subset selection

to identify the best model that contains a given number

of independent variables. We finally selected the

model based on best subset selection and the Akaike

Information Criterion (AIC) value, and then evaluated

the model with confusion matrix.

3 RESULTS

During the process of exploratory data analysis

(EDA), we first chose age, plasma CA 19-9,

creatinine, LYVE1, REG1A, REG1B and TFF1 as

independent variables and diagnosis as our dependent

variables. After viewing characteristics of all

variables (Table 1.), we found that the distributions of

most of them were skewed, which means that they

were asymmetrical. Take plasma CA 19_9 as an

example, the maximum of its blood plasma level is

31000, but more than 88% participants are smaller

than 1,000. The boxplots also verified this point (Fig

1.). In the comparison of plasma CA 19_9, there are

much more outliers in PDAC group than the PDAC-

free group, which indicates it might be a significant

measurement for PDAC. Also, in variables age,

LYVE1, REG1A, REG1B and TFF1, the minimums,

maximums, medians, first quartile, and third quartile

of PDAC patients group seem to be greater.

ICHIH 2022 - International Conference on Health Big Data and Intelligent Healthcare

Table 1: Characteristics of Variables (N=590).

Characteristics

Percent(%)

Sex

Male 301 51.0

Female 289 49.0

Diagnosis

Pancreatic-

cance

-free

391 66.3

Pancreatic

cance

199 33.7

Continuous

variable

Percent(%) Range

Age

>=50 446 75.6

26-89

<50 144 24.4

Plasma CA19_9

>=1000 69 11.7

0-31000.0

<1000 521 88.3

Creatine

>=2 39 0.1

0-4.1

<2 551 99.9

Lymphatic vessel endothelial hyaluronan receptor 1

(LYVE1)

>=10 32 0.1

0-23.9

<10 558 99.9

Regenerating family member 1 beta (REG1B)

>=700 18 0.1

0-1403.9

<700 572 99.9

Trefoil factor 1 (TFF1)

>=1000 95 16.1

0-13344.3

<1000 495 83.9

Regenerating family member 1 alpha (REG1A)

>=1000 97 16.4

0-13200.0

<1000 493 83.6

What’s more, both male and female participants

are nearly 50%. More than three quarters of the

participants are older than 50 years old. For the

diagnosis of pancreatic cancer, about one-third of the

participants are patients.

In the regression part, we decided to select the model

with 5 predictors: Logit (diagnosis) = 0.65 +

0.0077Age + 0.057LYVE1 + 0.00033REG1B +

0.00011REG1A - 0.000074 (creatinine: REG1A).

The colon means the interactions between two

variables. The confusion matrix showed the accuracy

of prediction made by the model (Table 2). According

to the confusion matrix, the accuracy is 0.85 which

represents the proportion of correctly identified

samples. The sensitivity is 0.73 which represents the

proportion of actual positive samples identified

correctly. The precision is 0.82, which represents the

proportion of predict positive samples identified

correctly. The specificity is 0.91, which represents the

proportion of actual negative samples identified

correctly. These four factors indicate that our model

fits well with the practical condition.

Figure 1: The Boxplots of Associations Between Independent Variables X and Dependent Variable Y Diagnosis.

Detection of Urinary Biomarkers for Early Diagnosis of Pancreatic Cancer by Data Analysis

The boxplots were used to demonstrate all the independent

variables X visually and verify the positive skewed trend.

Table 2: Confusion matrix of the model.

Reference

predict 0 1

0 105 17

1 10 45

After fitting the best lambda, we create a

confusion matrix to evaluate the accuracy of our

modeling. Our data are divided into two parts in

which the training part contains 70 percent of the data

and the test part contains 30 percent. The reference

means the true value and the prediction represents the

value that the model predicted.

4 DISCUSSION

Pancreatic cancer is a highly malignant tumor of the

digestive system, and the molecular mechanism of its

occurrence and progression is still uncertain. In this

article, we are interested in the early detection,

prediction and diagnosis of pancreatic cancer. We

have analyzed and discussed again based on the data

of previous researchers, trying to explore which

factors are related to pancreatic cancer, but it still has

certain limitation.

We detect five urinary biomarkers in this study.

Lymphatic vessel endothelial hyaluronan receptor 1

(LYVE1) is a receptor that binds to both soluble and

immobilised hyaluronan. LYVE1 plays an important

role in lymphatic hyaluronan transport and tumor

metastasis. Regenerating family member 1 beta

(REG1B) belongs to a family of glycoproteins and

may promote regeneration of pancreatic islets.

Regenerating family member 1 alpha (REG1A) is a

protein which is highly similar to REG1B (Frappart

and Hofmann, 2020). Trefoil factor 1 (TFF1) is a 6.5

kDa secreted protein that belongs to a family of

gastrointestinal secretory peptides. It is expressed

predominantly in normal gastric mucosa and involved

in the regeneration and repair of urinary tract. TFF1

plays an important role in the development of cancer.

Creatinine is a protein which is a product of muscle

metabolism and is primarily cleared by the kidneys.

There are still many factors that are not included

in the database that can still affect the incidence and

prediction of PDAC to a large extent. Firstly, HER2

may play an important role in the occurrence and

development of pancreatic ductal adenocarcinoma in

elderly patients. The overexpression rate of HER2

may be related to gender, but its mechanism needs

further study (Ballehaninna and Chamberlain, 2012).

Secondly, we still have a lot to learn from in research

methods. In known studies, including drawing

survival curves based on the Kaplan-Meier method,

comparing survival time differences using Log-rank

test, multivariate Cox regression analysis to assess the

risk factors affecting patient survival, etc., can be

used to obtain better results. good result. In future

research, we will continue to work hard to bring better

research and results.

5 CONCLUSION

In our work, it can be concluded that age, LYVE1,

REG1A, REG1B, and the interaction between

creatinine and REG1A are the key predictors for the

diagnosis of pancreatic cancer. Their performances

are successfully validated by confusion matrix.

Furthermore, we plan to search for more clinical

datasets to verify our model and apply our logistic

regression approach to more available datasets of

cardiovascular diseases and other types of cancer.

REFERENCES

Adamska, A., Domenichini, A., & Falasca, M. (2017).

Pancreatic Ductal Adenocarcinoma: Current and

Evolving Therapies. International journal of molecular

sciences, 18(7), 1338.

https://doi.org/10.3390/ijms18071338

Arnold, M., Rutherford, M. J., Bardot, A., Ferlay, J.,

Andersson, T. M., Myklebust, T. Å., Tervonen, H.,

Thursfield, V., Ransom, D., Shack, L., Woods, R. R.,

Turner, D., Leonfellner, S., Ryan, S., Saint-Jacques, N.,

De, P., McClure, C., Ramanakumar, A. V., Stuart-

Panko, H., Engholm, G., … Bray, F. (2019). Progress

in cancer survival, mortality, and incidence in seven

high-income countries 1995-2014 (ICBP

SURVMARK-2): a population-based study. The

Lancet. Oncology, 20(11), 1493–

1505.https://doi.org/10.1016/S1470-2045(19)30456-5

Ballehaninna, U. K., & Chamberlain, R. S. (2012). The

clinical utility of serum CA 19-9 in the diagnosis,

prognosis and management of pancreatic

adenocarcinoma: An evidence based appraisal. Journal

of gastrointestinal oncology, 3(2), 105–119.

https://doi.org/10.3978/j.issn.2078-6891.2011.021

Bray, F., Ferlay, J., Soerjomataram, I., Siegel, R. L., Torre,

L. A., & Jemal, A. (2018). Global cancer statistics

2018: GLOBOCAN estimates of incidence and

mortality worldwide for 36 cancers in 185

countries. CA: a cancer journal for clinicians, 68(6),

394–424. https://doi.org/10.3322/caac.21492

ICHIH 2022 - International Conference on Health Big Data and Intelligent Healthcare

Brezgyte, G., Shah, V., Jach, D., & Crnogorac-Jurcevic, T.

(2021). Non-Invasive Biomarkers for Earlier Detection

of Pancreatic Cancer-A Comprehensive Review.

Cancers, 13(11), 2722.

https://doi.org/10.3390/cancers13112722

Delanaye, P., Cavalier, E., & Pottel, H. (2017). Serum

Creatinine: Not So Simple!. Nephron, 136(4), 302–

308. https://doi.org/10.1159/000469669

Dinges, S.S., Hohm, A., Vandergrift, L.A. et al. Cancer

metabolomic markers in urine: evidence, techniques

and recommendations. Nat Rev Urol 16, 339–362

(2019). https://doi.org/10.1038/s41585-019-0185-3

Frappart, P. O., & Hofmann, T. G. (2020). Pancreatic

Ductal Adenocarcinoma (PDAC) Organoids: The

Shining Light at the End of the Tunnel for Drug

Response Prediction and Personalized

Medicine. Cancers, 12(10),

2750.https://doi.org/10.3390/cancers12102750

He, X. Y., & Yuan, Y. Z. (2014). Advances in pancreatic

cancer research: moving towards early detection. World

journal of gastroenterology, 20(32), 11241–11248.

https://doi.org/10.3748/wjg.v20.i32.11241

Makawita, S., Dimitromanolakis, A., Soosaipillai, A.,

Soleas, I., Chan, A., Gallinger, S., Haun, R. S., Blasutig,

I. M., & Diamandis, E. P. (2013). Validation of four

candidate pancreatic cancer serological biomarkers that

improve the performance of CA19.9. BMC cancer, 13,

404. https://doi.org/10.1186/1471-2407-13-404

Newton, J. L., Allen, A., Westley, B. R., & May, F. E.

(2000). The human trefoil peptide, TFF1, is present in

different molecular forms that are intimately associated

with mucus in normal stomach. Gut, 46(3), 312–320.

https://doi.org/10.1136/gut.46.3.312

Siegel, R. L., Miller, K. D., & Jemal, A. (2018). Cancer

statistics, 2018. CA: a cancer journal for

clinicians, 68(1), 7–

30.https://doi.org/10.3322/caac.21442

Zeng, S., Pöttler, M., Lan, B., Grützmann, R., Pilarsky, C.,

& Yang, H. (2019). Chemoresistance in Pancreatic

Cancer. International journal of molecular

sciences, 20(18), 4504.

https://doi.org/10.3390/ijms20184504

Detection of Urinary Biomarkers for Early Diagnosis of Pancreatic Cancer by Data Analysis
