Threats to Adversarial Training for IDSs and Mitigation

Hassan Chaitou, Thomas Robert, Jean Leneutre and Laurent Pautet

LTCI, T

ecom Paris, Institut Polytechnique de Paris, Paris, France

Keywords:

Adversarial Machine Learning, GAN, Intrusion Detection System, Sensitivity Analysis.

Abstract:

Intrusion Detection Systems (IDS) are essential tools to protect network security from malicious trafﬁc. IDS

have recently made signiﬁcant advancements in their detection capabilities through deep learning algorithms

compared to conventional approaches. However, these algorithms are susceptible to new types of adversarial

evasion attacks. Deep learning-based IDS, in particular, are vulnerable to adversarial attacks based on Genera-

tive Adversarial Networks (GAN). First, this paper identiﬁes the main threats to the robustness of IDS against

adversarial sample attacks that aim at evading IDS detection by focusing on potential weaknesses in the struc-

ture and content of the dataset rather than on its representativeness. In addition, we propose an approach to

improve the performance of adversarial training by driving it to focus on the best evasion candidates samples

in the dataset. We ﬁnd that GAN adversarial attack evasion capabilities are signiﬁcantly reduced when our

method is used to strengthen the IDS.

1 INTRODUCTION

Currently, networks are open to many types of at-

tacks, including denial of service (DoS), probing, and

SQL injection. Intrusion detection systems (IDSs)

are components that monitor either host machines or

network activity to detect attacks and intercept them.

Machine learning (ML)-based IDS has been identi-

ﬁed as a solution to the common problems of expertly

conﬁgured signature-based IDS, including the large

number of rules to manage, limited detection capabil-

ities, and high maintenance costs. However, this work

concentrates on ML classiﬁer-based IDS that use su-

pervised learning. Classiﬁers are parametric func-

tions with a large number of conﬁgurable parame-

ters. This is accomplished during the training process,

which optimizes their detection rates and avoids false

alarms. The classiﬁer takes as inputs collected data

that has been divided into units describing the sys-

tem’s activity (packets, events, connections...). The

predicted class is the classiﬁer’s output; it is either

attack or normal trafﬁc in the simplest case. Such a

setting can be described as a two-side architecture,

with the attacker responsible for performing attacks

and attempting to evade detection and the defender

responsible for training and deploying an IDS that of-

fers the best trade-off between detection rate and false

alarms. Many works discuss the quality of datasets

that may not be sufﬁciently representative (Khraisat

et al., 2019). This question is also raised in more

generic works on training process quality and poten-

tial threats to classiﬁer performances. (Gong et al.,

2019). In this paper, we study the potential weak-

nesses in the construction and content of the dataset

rather than its representativeness. To our knowledge,

the two weaknesses we focus on have received less

attention in the security domain. They impact the re-

sistance to adversarial samples attacks, a well known

approach to evade detection for IDSs based on ma-

chine learning, (Szegedy et al., 2014). Adversarial

sample attacks involve using adversarial sample gen-

eration to learn how to turn IDS-ignorant attacks into

attacks that can evade them while still having a mali-

cious impact. Such transformations are possible using

Generative Adversarial Networks (Goodfellow et al.,

2014) among other generative approaches. Nonethe-

less, evading IDS detection and ensuring the mali-

cious impact is not a trivial task as pointed out in

(Backes et al., 2016) for malware detection.

In this work, we review previous work on well-

understood models (Goodfellow et al., 2015) and

datasets. In our contributions, we identify major

threats to IDS robustness against adversarial sample

attacks designed to evade IDS detection. Next, we

propose and evaluate three approaches to mitigate

these issues.

Section 2 formalizes the main concept about IDSs

based on classiﬁer besides identifying the known

threats that affect an IDS’s performance. Section 3

formally deﬁnes the main consequence of being able

226

Chaitou, H., Robert, T., Leneutre, J. and Pautet, L.

Threats to Adversarial Training for IDSs and Mitigation.

DOI: 10.5220/0011277600003283

In Proceedings of the 19th International Conference on Security and Cryptography (SECRYPT 2022), pages 226-236

ISBN: 978-989-758-590-6; ISSN: 2184-7711

Figure 1: Deployed architecture of classiﬁer based IDS.

to generate adversarial samples that remain attacks

without testing. Furthermore, it introduces the threats

this situation entails and presents mitigation strate-

gies. Sections 4 and 5 present the experimental

assessment of the risks represented by the threat

we identiﬁed and the performance of the mitigation

strategies.

2 DATASET QUALITY AND

ADVERSARIAL TRAINING

This section recalls the main concepts of adversarial

training and ML-based IDS. We study why the train-

ing set used to set up IDSs needs to be cleansed or ex-

tended to improve IDS detection capabilities and ro-

bustness. We highlight that one of the quality criteria

used to remove problematic data needs to be revisited

when creating adversarial datasets.

2.1 Classiﬁers with IDS

Network raw data refer to data provided by network

sensors, as depicted in Figure 1. Sensors repre-

sent observation capabilities of network activity from

routers, ﬁrewalls or host machines. This data is orga-

nized and merged into observation units correspond-

ing to an element of network activity, called a sample.

An IDS incorporating a classiﬁer for attack detection

is fed with samples of data collected by sensors. As

depicted in ﬁgure 1, the sample goes through various

processes before being processed by a classiﬁer that

determines for each sample whether it belongs to an

attack or not.

Deﬁnition 1 (Raw Sample). A raw sample is a tuple

of n values respectively of types T

, ..., T

. The raw

sample type T

is T

= T

× ... × T

The PCAP format is the type of raw sample usu-

ally used: it is sufﬁciently detailed that the activity

can even be replayed from the raw sample. Basically,

raw samples are expected to be detailed enough to be

able to decide whether a sample corresponds to nor-

mal activity or attack. Let L be the set of possible

labels: L = {normal, attack}.

Deﬁnition 2 (Raw Labeled Sample and Dataset). A

raw labeled sample is a couple (x, y) where x ∈ T

and

y ∈ L. A raw labeled dataset is a set of raw labeled

samples.

The raw sample type often relies on non-numeric

types to capture metadata about packets or applica-

tion behaviors. Therefore, the values of raw samples

can be of very diverse types (e.g., binary, categori-

cal, numeric, strings). It is extremely difﬁcult to feed

a classiﬁer with such data without ﬁrst transforming

all these types into scalar normalized values. This

step is called pre-processing. Let call prep the func-

tion that produces IDS scalar inputs from raw samples

R. Therefore, prep function takes elements of T

and

produces a vector of values q in [0, 1], we now use T

such that T

= [0, 1]

Deﬁnition 3 (Preprocessed Samples and Labeled

Dataset). For any raw sample x, prep(x) is a pre-

processed sample, and for any raw labeled dataset D,

prep(D) = {{(prep(x

), y

)|(x

, y

) ∈ D}}, is the cor-

responding preprocessed labeled dataset.

To apply prep to a labeled dataset, one has to ap-

ply it to the raw sample portion of each labeled sam-

ple. In the machine learning community, a dimension

of a sample is called a feature. A labeled sample is

said to be an attack sample if its label is attack, and

a normal sample if it is normal. Each labeled dataset

can be split in two subsets respectively called normal

trafﬁc and attack trafﬁc.

Deﬁnition 4 (Normal and Attack Trafﬁc of D). Given

a labeled dataset D (raw or preprocessed), the normal

trafﬁc of D denoted N(D), and the attack trafﬁc of D

denoted A(D) are deﬁned as follow:

N(D) = {(x

, y

)|(x

, y

) ∈ D, y

= normal}

A(D) = {(x

, y

)|(x

, y

) ∈ D, y

= attack}

A labeled dataset is necessary when training a

classiﬁer, or deﬁning its parameters; such a dataset is

called a training dataset. Datasets may contain prob-

lematic samples, either due to errors in sample col-

lection or due to poor observational or pre-processing

capabilities.

Deﬁnition 5 (Contradictory Samples and Dataset).

Two labelled samples (x

, y

) and (x

, y

) are contra-

dictory samples if and only if (iff) x

= x

and y

6= y

A dataset D is a contradictory dataset iff it contains

contradictory samples.

Threats to Adversarial Training for IDSs and Mitigation

227

A classiﬁer is a parametric model that must be

conﬁgured, and the training process is responsible for

determining the appropriate parameters. The training

of a deep or standard machine learning model con-

sists of feeding samples to it and tuning its parameters

to minimize a loss function (deﬁned to penalize pre-

dicted labels from those of the training set). Hence,

a contradictory dataset impairs this process as it pre-

vents minimizing this loss function properly.

The following subsection shows how a malicious

adversarial sample can evade detection and how it can

be mitigated and improve the dataset used for train-

ing.

2.2 Adversarial Samples and Training

In (Papernot et al., 2017), the authors identify a meta-

attack procedure that can abuse the classiﬁer’s deci-

sion by mutating a pre-processed sample. This muta-

tion aims to slightly modify the activity to change its

result while providing a different classiﬁer label. This

type of meta-attack can be used to perform an evasion

attack: an attack to hide malicious activity.

An adversarial sample or malicious adversarial

sample (MAdv) is obtained by adding a disturbance

on each dimension (which we call a mutation) of an

existing sample so that the predicted label of the sam-

ple before and after the disturbance is added differ-

ently. In the case of evasion attacks, the attacker fo-

cuses on crafting adversarial examples for attack sam-

ples. As stated above, the purpose here is not to gen-

erate legal trafﬁc from the attack trafﬁc but to change

the output of the classiﬁer and retain the malicious

impact.

Deﬁnition 6 (Adversarial sample generator). An ad-

versarial sample generator AG is a function that pro-

duces a MAdv from an input attack sample and a value

assumed to be chosen at random.

The second parameter is intended to ensure that

the attack generator is a deterministic function that

can be used to produce many different MAdv depend-

ing on the random value provided as input.

An AG is said to be correct if from an originate at-

tack sample x it only generates samples that are actu-

ally attacks (and in practice this gives the same kind of

consequences as x). The efﬁciency of an AG against

an IDS is measured as its likelihood of producing an

attack sample that is classiﬁed as a normal sample by

the IDS.

Note that an efﬁcient but incorrect AG is as useless

as a correct but inefﬁcient generator from the point of

view of the evasion attack.

Deep neural network models are known to be vul-

nerable to MAdvs (Goodfellow et al., 2015). Hope-

fully, efﬁcient adversarial defense approaches have

been proposed to prevent these attacks (Qiu et al.,

2019). According to the literature, adversarial train-

ing or its extensions remain the most effective ap-

proaches to improve the robustness of classiﬁers

against MAdvs (Ren et al., 2020).

Adversarial training involves extending a training

dataset D with MAdvs before training an IDS. It re-

lies on an AG that is used by the defender to generate

MAdvs intended to evade detection of IDS trained on

D. The MAdvs generated by AG are then added to D

and the IDS is retrained on the new dataset.

The purpose of using AG is to add samples to the

training without the need to actually execute them.

Their label would be inferred. Otherwise, the cost

of signiﬁcantly expanding the dataset would be pro-

hibitive.

Three aspects affect the quality of the adversar-

ial training, the number of samples added (because it

changes the distribution of D), the choice of attack

samples that are modiﬁed and the quality of the al-

teration. Surprisingly, the choice of attack generator

inputs and how adversarial training is actually imple-

mented remains poorly studied in the security com-

munity.

2.3 Problem Statement

Without dedicated guidelines, an attack generator

would alter all the features of an attack sample. A

purely random alteration of a sample may not pre-

serve the malicious impact of a sample. Yet, suppose

ﬁrst that we know how to generate only MAdvs. The

problem is that, in some cases, it would be possible to

create a sample through adversarial training identical

to a sample labeled as normal in the dataset used to

train an IDS. While this is possible, although it is not

directly a contradictory data set, it still raises prob-

lems and poses threats to the approach or even to the

IDS itself.

Therefore, the issues raised by these observations

are as follows:

• Is there a concept similar to a contradictory train-

ing data set that needs to be taken into account

when applying adversarial training?

• Can the criterion used to deﬁne effective MAdvs

be exploited to boost adversarial training, either

by helping to select better MAdvs or by reducing

the cost of the approach.

In the next section, we identify the notion of the

impactful neighborhood and explain how this can be

a threat to adversarial training in the ﬁrst place, but

also how understanding this concept helps to design

better sampling approaches of the MAdvs.

SECRYPT 2022 - 19th International Conference on Security and Cryptography

228

3 THREAT TO ROBUSTNESS OF

IDS AND MITIGATION

This section presents the core concepts of our ap-

proach and contribution to better handle and under-

stands adversarial training.

3.1 Extending the Contradictory Set

Our work is motivated by the following observation:

the label of an adversarial sample is set to the label

of the sample that has been modiﬁed and can then be

added to a training dataset. Those actions are carried

out without quality checks and raise issues. Usually,

samples are obtained through observations, and thus

the label is the observed impact. Yet, in the case of

MAdvs no real activity is necessary to “obtain” a sam-

ple. From a defender, it helps to extend training sets

at almost no cost, because no real observation is nec-

essary to obtain new samples. Yet, it relies on the

assumption one can ensure an AG can only generates

attack samples. It implies that we know how to apply

perturbations in a neighborhood of each sample that

does not actually change its impact.

Deﬁnition 7 (Impactful neighborhood of an attack

sample). The impact neighborhood of an attack sam-

ple x, denoted INA(x), is the set of all possible muta-

tions applied to x that does not change its actual im-

pact.

By extension INA(A(D)) is the union of the im-

pactful neighborhood of all attack samples of D. By

deﬁnition, a correct AG only produces elements of

INA(A(D)). Because adversarial training essentially

builds training sets from subsets of D and INA(A(D))

The notion of contradictory data set should be ex-

plored for D ∪ INA(A(D)).

Deﬁnition 8 (Extended contradictory dataset). The

extended contradicting set of a dataset D, given INA

is the set of all contradictory samples contained in D∪

INA(A(D)) and is noted EC

INA

(D) (more formally

INA

(D) =

{(x, normal), (x, attack)} with x such

that (x, normal) ∈ D and (x, attack) ⊆ EC

INA

(D)).

The INA index in EC

INA

will be omitted as we

only consider one version of it. EC(D) contains all

contradicting samples originally in D but also all the

contradicting samples that could be obtained through

adversarial training. Figure 2 depicts a simpliﬁed

dataset D with four elements including two attacks,

and x

. Let assume their INA contains only four

elements : themselves plus the results of two pertur-

bations, p

, and p

. In this case, we assume x

+ p

, x

= x

+ p

, x

= x

+ p

are all samples not

Figure 2: MAdvs, BEAC and EC.

included in D, yet x

+ p

is in fact equal to n

. In

this context, EC(D) = {(n1, normal), (n1, attack)} as

, attack) is an adversarial attack sample that could

be generated. Recall that a classiﬁer trained on D, is

very likely to predict label y for sample x if (x, y) ∈ D.

Therefore, an IDS trained on a dataset containing D

has a high likelihood to predict normal as a label for

. From the attacker’s point of view, applying the

attack generator on samples that are transformed into

elements of EC(D) could represent its best chance of

success. These samples will be called Best Evasion

Attack Candidates (BEAC) and are part of D as shown

in Figure 2.

Deﬁnition 9 (Best evasion candidates of a dataset).

The set of Best Evasion Attack Candidates of a

dataset D is deﬁned as BEAC(D) = {w | INA(w) ∩

EC(D) 6=

Figure 2 depicts this situation in which two con-

tradicting samples can be obtained due to adversarial

training, and details the role of D, INA(D), EC(D),

and BEAC(D)

An attack generator can be created by generative

approaches (GANs, autoencoders ...). In this case, the

attack samples of EC(D) thus contain the right sam-

ples for training an attack generator to attack an IDS

trained with D as is. Thus, the knowledge of EC(D)

and BEAC(D) can be the source of various threats to

IDSs performances.

3.2 Adversarial Training Threats

The concept of the extended contradictory dataset

raises several questions on the way MAdvs for IDSs

are generated and handled.

Assume the attacker knows the INA of its attack

samples. An attack generator is either in a white box

Threats to Adversarial Training for IDSs and Mitigation

229

or black box setting. Black box assumption is consid-

ered equivalent to assuming that the attacker knows

a dataset equivalent (same distribution) to the one

used to train the IDS (before any adversarial train-

ing). Thus, both have similar EC(D). We study the

case where the attacker knows BEAC(D), but the de-

fender applies adversarial training without particular

care.

The ﬁrst threats to IDS performances are due to a

defender that does not know how to explore INA(x)

of an attack sample x. This situation must be taken

into account as we have noticed that to our knowledge

only NSL-KDD explicitly provided insights to deﬁne

the notion of impactful neighborhood.

The consequence of this situation is that the at-

tack generator used by the defender does not guar-

antee that generated samples are actual attacks. We

assumed previously to use only correct attack genera-

tors for simplicity. However, in practice, this situation

is not guaranteed for the defender. Recall that adver-

sarial training extends a dataset D with samples for

which the label is set to attack without actually ob-

serving the activity. Therefore, we have two cases,

either the defender sets blindly labels to attack, or it

checks whether MAdvs are actual attacks. The for-

mer case is called the poisoning threat, and the latter

is called the testing cost threat.

Deﬁnition 10 (Poisoning Threat). If adversarial train-

ing is performed for an IDS using an AG for which

it cannot prove that AG(w, z) ∈ INA(w), then this

training procedure is said to poison the IDS training

dataset.

Indeed, there is a chance that the generated sam-

ples correspond to actual normal activities instead of

attacks. If such a normal activity is labeled as an at-

tack, then it is a dataset poisoning situation that threat-

ens the availability of normal activities.

The alternative approach is to test each adversarial

attack sample that would be added for training (sec-

ond case). The activity has to be carried out and ob-

served. This is no longer adversarial training as it

requires real observation. It is a regular dataset ex-

tension for which the defender must pay the cost of

executing each sample and observing it.

Deﬁnition 11 (Testing Cost Threat). Consider that

adversarial training is performed for an IDS using an

attack generator AG for which it cannot be proven that

∀z, AG(w, z) ∈ INA(w), and that the defender tests

the impact of each generated MAdv, then this training

procedure is said to suffer from a testing cost threat.

If someone applies this approach given the usual

size of adversarial training dataset, it can be in-

tractable or too costly. Now suppose the impactful

neighborhood of an attack sample is deﬁned and used

by the defender to avoid previous threats. In this con-

text, if we do not remove normal samples of D that do

belong to EC(D), then we risk adding to D, through

adversarial training, attack samples that are very sim-

ilar or equal in value but with different labels. Even

if samples are not contradictory, adding samples very

similar with distinct labels might signiﬁcantly disrupt

the training process (having a large gradient even with

small changes on input makes training difﬁcult). This

increases the risk of false prediction.

Deﬁnition 12 (Confusing Normal Sample Threat). If

is a training dataset that extends D with adversarial

samples, then D

is said to be subject to confusing nor-

mal sample threat if it contains normal samples that

belong to EC(D).

Indeed, if a dataset with MAdv does contain con-

fusing normal samples, this can increase the likeli-

hood of evasion attack success for attack samples in

BEAC(D) (attack samples that once modiﬁed may be-

long to EC(D)). The last case is related to the sam-

pling strategy of the different attack samples. Indeed,

if a category of attack is more likely to happen, it is

relevant to acquire more samples of it to improve de-

tection capability. Conversely, if an attacker knows

that an evasion attack is more likely to succeed for an

element of BEAC(D), then it is more likely that this

attack will be carried out because of a higher evasion

rate a priori.

Deﬁnition 13 (Best Evasion Attack Threat). The best

evasion attack threat corresponds to the situation

where an attacker focuses on applying evasion attacks

only for elements of BEAC(D) for an IDS trained on

This threat account for attackers that focus on ap-

plying evasion attacks only on attack samples with the

highest likelihood to evade detection. We now pro-

vide the mitigation strategies for these threats.

3.3 Mitigation Strategy

We identiﬁed four threats to an efﬁcient usage of ad-

versarial training related to INA. Note that the ﬁrst

two threats cannot be mitigated; they represent situa-

tions in which adversarial training is either too costly

or risky as it may signiﬁcantly reduce the system’s

availability. In practice, even if there is no formal def-

inition of the impactful neighborhood, the concept is

implicitly deﬁned. So now, let us consider the two

last threats: the confusing sample threat and the best

evasion attack focus threat.

Deﬁnition 14 (Sample Removal). This mitigation

strategy consists in removing normal samples from D

SECRYPT 2022 - 19th International Conference on Security and Cryptography

230

that belong to EC(D).

This approach avoids normal samples for mem-

bers of EC(D). Yet, these samples can still be ob-

tained through adversarial training. In order to reduce

the likelihood of detection miss, we can change their

label in D instead of removing them.

Deﬁnition 15 (Pessimistic Relabelling). Relabel any

normal sample from D ∩ EC(D) as attacks.

We now introduce mitigation for the last threat.

MAdv generation is based on the selection of attack

samples on which an evasion attack generator is ap-

plied. The selection of attack samples on which the

attack generator is applied is called attack sampling.

Attack sampling is almost never discussed on the at-

tack side and is assumed to be uniform. Yet, attackers

that restrict themselves to BEAC(D) elements would

be less likely to do so either because they do not

have enough samples in this area or because the at-

tack generator creates an element of EC(D). Our mit-

igation strategy would be to change the proportion of

BEAC(D) elements when sampling A(D) during ad-

versarial training.

Deﬁnition 16 (Oversampling of BEAC). This strat-

egy consists in increasing the likelihood of generating

MAdvs from elements of BEAC.

It allows training the IDS to be more efﬁcient in

detecting them. A ﬁrst expected effect is to obtain

samples in EC(D) to force predicting the attack for

this set. A second expected effect is that a good detec-

tion on BEAC(D) could be generalized to other sam-

ples. First, the impact of confusing sample and best

evasion attack focus threats need to be assessed on

IDS without mitigation. Secondly, it is also neces-

sary to check that the proposed mitigation approach

actually mitigates them. Next section details the ex-

perimentation campaign conducted to assess all these

aspects on a dataset for which the INA concept is de-

ﬁned.

4 ASSESSMENT METHOD AND

ARCHITECTURE

This section discusses the different assessment objec-

tives and metrics used. The experimental framework

and dataset are then described.

4.1 Metrics and Objectives

First, we need to determine the performance met-

rics for evasion attacks and adversarial training. The

objective is to identify the extent to which the per-

formance of the attack generator correlates with the

content of the Extended Contradictory set and how

the proposed mitigation strategies perform to ad-

dress the identiﬁed threats. We use the usual IDSs

performance metrics derived from confusion matri-

ces (Wang, 2018). Testing an IDS requires a labeled

test dataset without evasion attack, e.g. an Original

Test Dataset OT D. To test the IDS without evasion

attack, we simply submit OT D samples to the IDS. To

test the IDS against evasion attack, an attack genera-

tor is applied to the members of OT D before submit-

ting them to the IDS. We check IDS predicted labels

for the submitted samples to compute the number of

true positives TP, false negatives FN, false positives

FP, and true negatives TN.

The Recall is one of the most used metrics to

determine if an attack would be detected. Let sup-

pose T P and FN are computed for an IDS tested with

OT D, on which F is ﬁrst applied. F is either the iden-

tity function, noted id, or an attack generator. The

recall of this experiment is noted and deﬁned as:

Recall

IDS

(OT D) =

T P

T P + FN

Then, Recall

IDS

is the recall of IDS tested without

evasion attack applied, and Recall

IDS

is the recall of

IDS tested against the attack generator G. We are in-

terested in the extent to which the Recall is affected

by evasion attacks and measure it through the evasion

increase rate (EIR) of a generator G deﬁned as fol-

lows:

EIR

IDS

(OT D) = 1 −

Recall

IDS

(OT D)

Recall

IDS

(OT D)

The last metric used is the evasion reduction rate

(ERR) which compares EIR for the same attack gen-

erator but against different IDSs.

ERR

IDS

,IDS

(OT D) = 1 −

EIR

IDS

(OT D)

EIR

IDS

(OT D)

ERR compares how well IDS

resists to G com-

pared to IDS

. We use ERR only to compare an

IDS trained without adversarial training to the various

IDSs that take advantage of the mitigation strategies.

4.2 Dataset, Dataset Extension

This subsection describes the dataset and how we use

the GAN-based generator.

4.2.1 Dataset

The choice of the dataset was difﬁcult. To our knowl-

edge, the only one to provide a clear deﬁnition of INA

Threats to Adversarial Training for IDSs and Mitigation

231

is NSL-KDD. Still, this dataset is considered outdated

as it does not cover recent attacks. However, many

papers used it and overlooked the threats we identi-

ﬁed. Therefore, we decided to conduct the assess-

ment on NSL-KDD because it provides a clear deﬁ-

nition of the INA, and this dataset is well understood.

This dataset categorizes attacks as Denial of Service

(DoS), User to Root (U2R), Root to Local (R2L), and

Probe. The NSL-KDD training dataset includes 41

features and class identiﬁers for each record. The con-

cept of INA is deﬁned through the notion of function

features: the dimension that should not change (Lee

and Stolfo, 2000). Hence, the INA is obtained by

changing all non-function features of a sample. NSL-

KDD samples’ features are split into four groups: In-

trinsic, Time-based, Content, and Host-based. Not

surprisingly, the functional features are different for

each attack category:

• DoS attacks: Intrinsic and Time-based

• U2R attacks: Intrinsic and Content

• R2L attacks: Intrinsic and Content

• Probe attacks: Intrinsic, Time-based and Host-

based

In order to stick to our models, binary classiﬁers, the

dataset is split in 4 datasets, one per attack type, which

only retain the targeted attack type. We will focus

on normal, DoS, and probe samples as the others are

too few. It should be noted that after searching for

the BEAC set on the training dataset of NSL-KDD

restricted to DoS and Probe attacks, we found that

BEAC(D) contained only DoS samples that represent

3.74% of DoS samples. In this dataset, the samples

contain categorical attributes, such as protocol type

or ﬂags. We applied the usual pre-processing ap-

proaches on these samples to obtain fully scalar at-

tributes.

4.2.2 Generative Adversarial Network (GAN)

We assume that GAN-based generators are black-box

evasion attack generators. GAN-based attacks target

pre-trained IDS models and repeatedly update the pa-

rameters of two components, the Generator and the

Discriminator. The Generator is trained to mutate the

non-functional features of the attack samples to gen-

erate MAdvs. The generator input is made of an attack

sample concatenated with a random vector (it is com-

pliant with the attack generator deﬁnition). The Gen-

erator is trained to evade discriminator detection, but

the discriminator is trained to mimic the IDS. Each

component has its own loss function: Discriminator

is penalized when a sample is classiﬁed differently by

the IDS, and the generator is penalized when generat-

ing samples that do not evade the IDS. Thus, among

the key parameters of the Generator and Discrimi-

nator, there is the number of update iterations called

epochs. We consider GAN trained here either on 100

or 1000 epochs as both are well-spread constants in

security. A Generator of type GAN−N would de-

note a Generator trained in N epochs. We also con-

sider the best Generator ever observed against the IDS

as the optimization process is not guaranteed to be

monotonous. We implement training set extension

and adversarial training as explained in algorithm 1 to

produce MAdvs using GAN−100 type of generators.

Generators are used on both sides: to extend the IDS

training set but also on the attack side to apply evasion

attacks and thus test our approaches. They all suffer

from variability issues. On the attack side, we handle

it by independently repeating the training of 50 gen-

erators to assess a generator type performance against

an IDS. On the defense side, we ensure that the train-

ing continues or is restarted as long as the generator

does obtain an EIR threshold (here 0.99 for DoS at-

tacks). This ensures that the defense, to its knowl-

edge, is using a decent generator.

Algorithm 1: Adversarial training of an IDS.

Input: OD (an original dataset), IDS (an IDS

trained on OD), S (an extension size factor), r (a

rate of sampling of BEAC(OD);

Output: Best Generator best G, re-trained IDS on

extended dataset D

ext

;

1: procedure ADV-TRAIN IDS(OD, IDS, S, r)

2: initialize Gen and Disc, initial generator and

discriminator of a GAN of type GAN−100

3: Train Gen, Disc, using Gen(OD) labeled by

IDS, store each Generator with its evasion

score.

4: Choose the best attack generator Gen, noted

best G;

5: Use best G to generate MAdvs from elements

of A(OD) to create D

ext

so that the added ele-

ments represent S times the size of OD. More-

over, the proportion of added elements created

from elements of BEAC(OD) has to be r.

6: Re-train IDS on D

ext

;

7: end procedure

5 EXPERIMENTS AND RESULTS

Our experimentation consists in testing IDS trained

on different datasets with adversarial training and/or

mitigation strategies. In order to identify those IDSs,

we follow this notation: IDS−X−sr−option where sr

and option are both optional. X represents the dataset

SECRYPT 2022 - 19th International Conference on Security and Cryptography

232

considered for training (detailed later). The parame-

ter sr denotes the sampling rate chosen for BEAC(X)

if applied (not provided if unchanged). The option

parameter indicates whether removing confusing nor-

mal sample, noted wn for without normal, or rela-

belling them as attacks, noted na for normal as attack,

have been applied.

5.1 Threat Level Without Mitigation

We need to determine whether the existence of a non-

empty BEAC set is problematic. As previously stated,

probe and DoS attacks illustrate two distinct situa-

tions. If we compute the BEAC set of NSL-KDD,

it contains no probe attack sample but DoS samples.

Let thus train two IDSs, one for Probe and on for DoS

attacks and see how they behave. We need a training

dataset to detect DoS samples, it contains normal and

DoS samples of NSL-KDD training dataset, noted

DoS

. The second data set contains normal and

Probe samples of NSL-KDD training dataset, noted

We train two batches of 50 GANs, following

the architecture of GAN−100, respectively against

IDS−OD

and IDS−OD

DoS

. We observe that eva-

sion attacks reach an average EIR of above 0.99 for

IDS−OD

DoS

and is 0 for IDS−OD

. It shows two

situations that are consistent with our claim of the

role of BEAC in evasion attack success. Note that

the IDS trained has shown usual performances, e.g.,

as in (Vinayakumar et al., 2019), of ML-based IDSs.

Hence, we have a 0.85 recall (ability to detect attacks)

for IDS−OD

dos

on non adversarial samples. The next

step is to understand how efﬁcient is the adversarial

training for different size factor parameters. Here,

we test an adversarial training for size factors of 1,

2, 5 and 10, leading to extended datasets for AT 1,

AT 2, AT 3, and AT4. Each dataset is used to train

an IDS without any particular mitigation of identiﬁed

threats. These IDS have been tested against strong

Figure 3: The average EIR for ﬁfty GAN−1000 Generators

vs IDS−AT

, IDS−AT

and IDS−AT

attack generators of type GAN−1000 to better under-

stand their performances, and results are presented in

Figure 3. We notice that the risk of the adversarial

evasion attacks drops signiﬁcantly from 100% EIR

on IDS−OD to reach 9% EIR on a very costly IDS

in terms of training, which is IDS−AT

. Adversar-

ial training works well but at the expense of scaling

factors that are 5 or 10 times the size of the original

dataset. Training an IDS on 10 times larger datasets

has a linear effect on the training cost and may not be

accepted. Note that this adversarial training has not

impaired the performance of IDSs when no evasion

attack is applied, as shown in the ﬁrst three lines in

Table 1.

In the following subsections, we perform experi-

ments to evaluate our mitigation strategies described

in 3.3.

5.2 Confusing Samples Mitigation

This subsection evaluates the impact on the perfor-

mance of both regular and robust IDS when the two

mitigation strategies, sample removal, and sample

pessimistic relabeling (section 3.3) are applied.

5.2.1 Effect on Regular IDS Performance

As pointed out, confusing samples can make it harder

for the IDS to resist attack generators. To assess

the confusing sample threat on the regular IDS re-

silience, we train two IDSs. The ﬁrst one is called

(IDS−OD−wn) trained on OD without the normal

samples applying the sample removal mitigation. The

second one is IDS−OD−na trained on OD in which

we relabeled the confusing normal samples as attacks

as proposed in the sample pessimistic relabelling mit-

igation. These IDS are not designed to be resilient

Table 1: Performance metrics of various IDS models.

IDSs Precision Accuracy F1 score Recall

IDS−OD 85.8 86.4 84.4 85.1

IDS−AT

82.4 86.2 84.6 86.9

IDS−AT

88.4 87.6 85.2 82.2

IDS−OD−na 88.1 87.9 85.7 83.4

IDS−AT

− 25 87.6 87.3 84.9 82.5

to evasion attacks. Thus, we use only Generator of

type GAN−100 trained speciﬁcally against IDS−OD

and test them on IDS−OD−wn and IDS−OD−na.

We observe that the attacks still manage to evade

IDS−OD−wn completely.

However, the average ERR for IDS−OD−na is

0.5 in this case. Note that we use weaker generators in

this subsection compared to before. These results are

Threats to Adversarial Training for IDSs and Mitigation

233

encouraging as relabelling is a very cheap adversarial

training. Indeed, the number of confusing samples

is very limited compared to all normal samples (less

than 1%). Yet, normal samples related to EC(OD)

seem very useful for adversarial training.

Let now consider adversarial training with these

mitigation strategies.

5.2.2 Effect on Robust IDS Performance

We investigate the mitigation approaches of confus-

ing samples combined with IDS reinforced with reg-

ular adversarial training. We assess the performance

using IDS−AT

, IDS−AT

−wn e.g. with sample re-

moval mitigation and IDS−AT

−na using the sample

pessimistic relabeling mitigation. This time, we use

50 GAN−1000 generators against each of these IDSs.

Table 2 summarizes the results.

Table 2: ERR mean over the ﬁfty GAN−A

−1000 attacks

on IDS−AT

, IDS−AT

−wn and IDS−AT

−na.

IDS−AT

−wn IDS−AT

−na

ERR mean over 0.39 0.57 0.43

50 experiments

The ERR of the IDS without mitigation but with

adversarial training on AT

remains low at 0.39. How-

ever, the ﬁrst mitigation strategy, sample removal,

performs signiﬁcantly better this time. It increase the

ERR by almost 50% to 0.57. Surprisingly, the rela-

belling strategy did not perform as expected, with a

very small increase in ERR. Without mitigation, there

is a real gap on the ERR of adversarial training of scal-

ing factor 2, i.e. 0.39, and scaling factor 5, i.e. 0.83.

Hence, we observe that simply removing few normal

samples from the training data set reduces this gap by

50%. It provides a mean to reach a given ERR level

with a signiﬁcantly lower scaling factor.

In the next subsections, we examine the effect of

the oversampling strategies on the BEAC set com-

pared to regular adversarial training with uniform

sampling.

5.3 Adversarial Training on BEAC Set

Here, we consider adversarial training datasets built

by controlling the sampling rate of elements from

BEAC.

This last set of experiments aims to compare

the effect of the last proposed mitigation com-

pared to the sample removal and sample relabel-

ing ones. We consider sampling rates of BEAC in

{0.10, 0.20, 0.25, 0.35, 0.50, 0.75}. We deﬁne the sr

parameter value to denote percentages. Hence, IDS−

−25represents an adversarial training on a dataset

with a size factor of 2 and a sampling rate of 0.25.

Again, we test GAN−1000 generators against IDSs

trained with an adversarial training set of size factor

of 2, e.g., IDS−AT

− j family.

Figure 4: Average ERR on 50 GAN−1000 generators

against IDS−AT

− j for various j.

Figure 4 outlines the result of this experiment.

The results reveal that the adversarial evasion at-

tacks are signiﬁcantly less effective in the majority

of these IDSs when compared to IDS−AT

but for

IDS−AT

− 75. However, this situation is expected as

a too high sampling rate prevents the IDS from cor-

rectly detecting evasion attacks applied to attacks in

A(D)−BEAC(D). A sampling rate between 20% and

50% seems to be equivalent. This mitigation yields

similar results to the sample removal approach with

an ERR close to 0.6. Moreover, it seems not too difﬁ-

cult to take advantage of it, as the interval of sampling

rates yielding similar ERR is large. Furthermore, us-

ing oversampling of BEAC mitigation narrows the

margin between the performance of IDS −AT

−25

and IDS−AT

as the difference in ERR is almost di-

vided by two, as one can see in Figure 4.

6 RELATED WORK

(Gong et al., 2019) provide criteria to deﬁne better

sampling strategies for datasets and the use of diversi-

ﬁcation approaches to improve the training of generic

classiﬁers. Yet, they do not consider the speciﬁcity

of IDS as security classiﬁers or even the speciﬁcity of

adversarial samples. With the recent advancements in

machine learning research, adversarial attacks piqued

the interest of researchers in a wide variety of do-

mains. As a result, network security faces critical

challenges from adversarial attacks as a sensitive and

complex ﬁeld. However, a few researches focus on

the sampling strategy of MAdvs in order to establish

a fair balance between IDS training performance and

SECRYPT 2022 - 19th International Conference on Security and Cryptography

234

detection capabilities against adversarial evasion at-

tacks. In (Khamis et al., 2020), they generated MAdvs

using two methods, either by mutating all the dimen-

sions of attack samples or by mutating the 16 ob-

tained principal components using Principal Compo-

nent Analysis (PCA) as a dimensionality reduction

technique. However, in either case, the MAdv gen-

eration was obtained without taking into account the

impactful neighborhood of the attack samples. There-

fore, the preservation of attack behaviors is not as-

sured following the mutation process.

To our knowledge, all techniques that take INA

into account deﬁne attributes that split attack sam-

ples as functional or non-functional. This separa-

tion of features is typically performed manually by

a domain expert such as in NSL-KDD or through

statistical or machine learning methodologies. (Lin

et al., 2018), (Zhao et al., 2021) and (Usama et al.,

2019) proposed to craft MAdvs using GANs. Dur-

ing the mutation process, they considered the impact-

ful neighborhood of attack samples into account as

they preserved the attack behavior by keeping the

functional features of these samples unaltered, using

the same criteria described for NSL-KDD. Whereas

in (Alhajjar et al., 2021), (Chauhan and Shah Hey-

dari, 2020), and (Msika et al., 2019), each of these

works makes use of statistical tools or deep learn-

ing methods such as Shapley Additive Explanations

(SHAP) (Lundberg and Lee, 2017) to deﬁne the im-

pactful neighborhood of the attack samples. However,

those tools deﬁne the attack’s functionality solely

based on the dataset’s statistical properties, not on

the attack samples’ semantics. Although both cate-

gories perform very powerful adversarial evasion at-

tacks, one shortcoming of these works lacks an ex-

amination of the effect of the confusion samples or

BEAC set on the robustness of the IDSs when adver-

sarial training is used.

To our knowledge, no work in the literature fo-

cuses on assessing the dataset after the mutation of

MAdvs . This paper aims to examine the threats

linked to the current generation process used in ad-

versarial training. Furthermore, we propose a new

method to improve the performance of the adversarial

training for IDS by adjusting the sampling strategies

of adversarial samples to account for confused sam-

ples and the BEAC set.

7 CONCLUSIONS

This paper examined the effect of a non-empty con-

tradictory dataset on IDS robustness performance in

the presence of adversarial samples. First, we iden-

tify the main threats that could lead to extending the

contradictory set during adversarial training, includ-

ing the poisoning threat, the threat of confusing nor-

mal samples, and the threat of the best evasion attack

candidates (BEAC). In addition, we proposed three

mitigation strategies to improve the performance of

adversarial training by taking advantage of the im-

pactful neighborhood of attack samples and focusing

adversarial training on the BEAC set.

In future work, we will investigate the effect of

the overall training approach on the IDS performance

by specifying one IDS to detect regular attacks and

another one to detect adversarial evasion attacks (in

particular BEAC samples). In addition, we want to

investigate the applicability of the proposed approach

used with different sampling strategies such as those

in (Picot et al., 2021).

ACKNOWLEDGEMENTS

This research is part of the chair CyberCNI.fr with

support of the FEDER development fund of the Brit-

tany region.

REFERENCES

Alhajjar, E., Maxwell, P., and Bastian, N. (2021). Adver-

sarial machine learning in network intrusion detection

systems. Expert Syst. Appl.

Backes, M., Manoharan, P., Grosse, K., and Papernot, N.

(2016). Adversarial perturbations against deep neural

networks for malware classiﬁcation. CoRR.

Chauhan, R. and Shah Heydari, S. (2020). Polymorphic

adversarial ddos attack on ids using gan. In ISNCC.

Gong, Z., Zhong, P., and Hu, W. (2019). Diversity in ma-

chine learning. IEEE Access.

Goodfellow, I., Pouget-Abadie, J., Mirza, M., Xu, B.,

Warde-Farley, D., Ozair, S., Courville, A., and Ben-

gio, Y. (2014). Generative adversarial nets. In NIPS.

Goodfellow, I. J., Shlens, J., and Szegedy, C. (2015). Ex-

plaining and harnessing adversarial examples.

Khamis, R. A., Shaﬁq, M. O., and Matrawy, A. (2020).

Investigating resistance of deep learning-based ids

against adversaries using min-max optimization. In

ICC.

Khraisat, A., Gondal, I., Vamplew, P., and Kamruzzaman, J.

(2019). Survey of intrusion detection systems: tech-

niques, datasets and challenges. Cybersecur.

Lee, W. and Stolfo, S. J. (2000). A framework for con-

structing features and models for intrusion detection

systems. ACM TISSEC.

Lin, Z., Shi, Y., and Xue, Z. (2018). IDSGAN: Generative

Adversarial Networks for Attack Generation against

Intrusion Detection. arXiv e-prints.

Threats to Adversarial Training for IDSs and Mitigation

235

Lundberg, S. M. and Lee, S.-I. (2017). A uniﬁed approach

to interpreting model predictions. In NeurIPS.

Msika, S., Quintero, A., and Khomh, F. (2019). Sigma :

Strengthening ids with gan and metaheuristics attacks.

Papernot, N., Mcdaniel, P., Goodfellow, I. J., Jha, S., Ce-

lik, Z. B., and Swami, A. (2017). Practical black-box

attacks against machine learning. ACM ASIACCS.

Picot, M., Messina, F., Boudiaf, M., Labeau, F., Ayed, I. B.,

and Piantanida, P. (2021). Adversarial robustness via

ﬁsher-rao regularization. ArXiv.

Qiu, S., Liu, Q., Zhou, S., and Wu, C. (2019). Review

of artiﬁcial intelligence adversarial attack and defense

technologies. Applied Sciences.

Ren, K., Zheng, T., Qin, Z., and Liu, X. (2020). Adversarial

Attacks and Defenses in Deep Learning. Engineering.

Szegedy, C., Zaremba, W., Sutskever, I., Bruna, J., Erhan,

D., Goodfellow, I. J., and Fergus, R. (2014). Intriguing

properties of neural networks. In ICLR.

Usama, M., Asim, M., Latif, S., Qadir, J., and Ala-Al-

Fuqaha (2019). Generative adversarial networks for

launching and thwarting adversarial attacks on net-

work intrusion detection systems. IWCMC.

Vinayakumar, R., Alazab, M., Soman, K. P., Poornachan-

dran, P., Al-Nemrat, A., and Venkatraman, S. (2019).

Deep learning approach for intelligent intrusion detec-

tion system. IEEE Access.

Wang, Z. (2018). Deep learning-based intrusion detection

with adversaries. IEEE Access.

Zhao, S., Li, J., Wang, J., Zhang, Z., Zhu, L., and Zhang, Y.

(2021). attackgan: Adversarial attack against black-

box ids using generative adversarial networks. Proce-

dia Computer Science.

SECRYPT 2022 - 19th International Conference on Security and Cryptography

236
