COAST: A Conﬂict-free Replicated Abstract Syntax Tree

aron Munsters

, Angel Luis Scull Pupo

and Jens Nicolay

Software Languages Lab, Vrije Universiteit Brussel, Pleinlaan 2, Brussels, Belgium

Keywords:

Conﬂict-free Replicated Data Types, Software Evolution, Abstract Syntax Trees, Distributed Collaboration.

Abstract:

Remote real-time collaborative text editing enables collaboration of distributed parties which improves an

agile workﬂow, team member availability and productivity. Collaborative source-code editors are often imple-

mented as a variant of regular collaborative text editing with source code highlighting. Such approaches do not

use the structural program information to accurately merge concurrent changes on the same portions of code

for temporal network partitions. Therefore, these approaches fail to merge concurrent structural changes to

the program such as a concurrent move and edit operation. In this paper we propose an approach in which the

editor replicates not the program text but the program tree that corresponds with the program text. Propagating

source code changes as tree operations enables resolving concurrent tree changes with higher accuracy. We

evaluate our approach by reproducing a use case in which we concurrently change source code on existing

tools and our approach. We show that existing tools break the lexical structure and come up with an incorrect

program while our approach can distinctly apply the changes preserving the program structure.

1 INTRODUCTION

In collaborative real-time editing systems, multiple

replicas of a digital resource can be updated concur-

rently, while the system ensures that all replicas auto-

matically and quickly converge. An important appli-

cation of collaborative real-time editing is program-

ming. Using collaborative programming, program-

mers can work together by simultaneously writing

and editing source code, while observing edits per-

formed by other programmers in real-time and dis-

cussing ideas and issues that emerge from these con-

current activities. Enabling teams to pair program in

geographically distributed settings is known as dis-

tributed pair programming, which has been shown

to lead to software development with comparable

quality and productivity to colocated pair program-

ming (Baheti et al., 2002).

A Conﬂict-Free Replicated Data Type

(CRDT) (Shapiro et al., 2011b) is a data type

that enables the replication and maintenance of a dig-

ital resource in a distributed system without requiring

additional communication to resolve concurrent

changes. CRDTs that are used to support state of

the art real-time text editors both for commercial

https://orcid.org/0000-0001-5593-1273

https://orcid.org/0000-0003-2083-1285

https://orcid.org/0000-0003-4653-5820

and research projects are modelling the shared data

structure as a string (Yu, 2012; Yu, 2014). For

real-time program editing, however, modelling the

data structure as a string limits the extent to which the

merge strategy can reason about merges. We noticed

that modelling the shared program as its syntax tree

would allow the CRDT to perform better in terms of

merging concurrent program changes.

In this work, we propose CoAST, a real-time col-

laborative source-code editing system supported by

an abstract syntax tree (AST) CRDT. By comput-

ing AST changes on local replicas and sharing these

with others accompanied by a logical timestamp,

all replicas can compute an equal view of the AST

by maintaining a chronologically ordered log of all

changes and querying this log to construct the same

AST. By doing so we aim to provide better sup-

port for distributed developers who experience con-

current changes which could break the syntax for de-

velopment on code editors supported by string-based

CRDTs. To the best of our knowledge CoAST is the

ﬁrst system that proposes a real-time collaborative ed-

itor using a CRDT based on the program structure

(i.e., the AST) instead of the program’s text.

The contributions of the paper are the following:

• A novel approach that enables real-time code col-

laboration through modelling the program’s AST

as a CRDT.

Munsters, A., Pupo, A. and Nicolay, J.

COAST: A Conﬂict-free Replicated Abstract Syntax Tree.

DOI: 10.5220/0011278800003266

In Proceedings of the 17th International Conference on Software Technologies (ICSOFT 2022), pages 187-196

ISBN: 978-989-758-588-3; ISSN: 2184-2833

187

• A proof-of-concept implementation of a real-time

collaborative editor for a Lisp-like language based

on our AST CRDT.

The rest of the text is organized as follows. Sec-

tion 2 explains the main challenges in the state-of-the-

art collaborative editing systems and why the use of a

higher level of abstraction for the program represen-

tation may improve the performance of such collabo-

rative systems. Section 3 describes the main char-

acteristics of CoAST. Section 4 describes the de-

sign choices of our AST CRDT and Section 5 ex-

plains how we used the GumTree algorithm to com-

pute language-agnostic AST changes. In Section 6,

we explain the Scala-based implementation of our

AST CRDT. First, we explain the properties and the

interface of the CRDT. Then, we describe the imple-

mentation of the underlying AST data structure. We

discuss and validate our collaborative editor in Sec-

tion 7 for an example concurrent program edit. Fi-

nally, we discuss the ordering of operations and the

merging granularity as the current limitations of our

approach in Section 8.

2 PROBLEM

Over the years, many collaborative editors (Mi-

crosoft, 2022; Atom, 2022; Ghorashi and Jensen,

2016; Nicolaescu et al., 2015; Salinger et al., 2010;

Yu, 2012; Yu, 2014; Ball et al., 2015; Nichols et al.,

1995) for software development have been proposed.

However, while surveying the existing approaches,

we observed that a considerable number of existing

collaborative code editors are string-based. String-

based editors handle the consistency of concurrent

changes of the source code at the level of sequences of

individual characters. Handling concurrent changes at

the textual level of a program source code is problem-

atic when replicas disconnects and reconnect while

concurrent changes are being made.

In our work, we use Lisp’s S-expression syntax

(also used by other Lisp-like languages such as Clo-

sure and Julia) for conciseness and simplicity, but our

ﬁndings are also valid for other syntax families (e.g.,

C syntax). For example, assume a local and a remote

replica of source code that are synchronized (i.e., have

the same program text). The content of two synchro-

nized replicas is depicted in the green area at the top

of Figure 1. Next, imagine that the two replicas are

disconnected, for example because of a network par-

tition, during which two edits happen concurrently.

A local edit changes the string “apple” into “banana”,

while on the remote replica the two expressions in the

body of the begin switch places. In Figure 1, this is

(begin

(eat "apple")

(touch "nose"))

(begin

(eat "banana")

(touch "nose"))

(begin

(touch "nose")

(eat "apple"))

(begin

(touch "nose")

(eat "banana"))

Local Remote

Synchronized

time

Synchronized

Figure 1: A sample Lisp-like program that evolves through

different machines that temporarily break synchronization.

This example shows that reasoning over the code structure

is required to successfully merge the two separate opera-

tions.

depicted in the pink area. Finally, assume that con-

nectivity between the replicas is restored. We believe

the desired outcome would be that both the local and

remote changes are correctly applied at each replica,

preserving both replicas their intent as shown in the

blue Synchronized state of Figure 1.

However, in string-based collaborative code edi-

tors such as Yjs(Nicolaescu et al., 2015), the outcome

is unpredictable and often wrong (unexpected, some-

times with syntax errors), depending on how and pre-

cisely when the two replicas connect again. An ex-

ample result that can be observed after reconnection

for the diverging changes depicted in the pink area in

Figure 1 is shown in Listing 1.

Listing 1: An example solution proposed by existing string-

based CRTS to the merge conﬂict shown in Figure 1, show-

ing how the syntactical structure of the program breaks.

( be g i nba n a n a

( t ouch " no s e " )

( eat " a p ple " ))

In addition to being incorrect with respect to the

two changes, the program in Listing 1 is also no

longer syntactically correct.

In an attempt to avoid unexpected and incorrect

merge results stemming from string-based synchro-

nization of programs, it is possible to synchronize at

higher levels of syntactic abstraction, even taking into

account the semantic properties of programs. It is for

example possible to synchronize at the lexical level

(tokens) or at the level of abstract syntax (typically

a tree). A system could choose to only synchronize

when code is free from certain syntactic or even se-

mantic errors. An example is the work of (Goldman

ICSOFT 2022 - 17th International Conference on Software Technologies

188

et al., 2012), where synchronization occurs when the

code compiles. However, when the level of abstrac-

tion of the source code model is high and the condi-

tions for merging are strict, it may be the case that

in typical development scenarios there may be long

times between replica updates. This may result in

a system that is closer to working with a traditional

version control system, where programmers are sup-

posed to only commit “working code”. Although

working with a version control system is also a form

of collaborative editing, it is a more asynchronous

workﬂow that does not directly support real-time syn-

chronization between source code replicas.

3 APPROACH

In this paper we explore an approach, called COAST,

for collaborative source code editing that enables

near-real-time updates and avoids some of the incon-

sistencies that result from string-based synchroniza-

tion mechanisms. More precisely, our approach fo-

cuses on several aspects:

• Structure and Consistency

Raising the abstraction level from programs as

strings to programs as syntactically structured en-

tities, permits COAST to make changes to the

content of the program while upholding the syn-

tactical integrity ensuring that the program main-

tains a valid structure by performing merges on a

syntactical abstraction level.

• Near Real-time Distributed Design

Through propagating program changes based on

the program AST, COAST is able to make more

informed merging decisions at high speeds while

abstaining from semantical analysis which we as-

sume would in turn be more costly in terms of per-

formance.

• Decentralized Setting

By building on the existing work of CRDTs,

COAST provides a decentralized implementation

of a collaborative editor featuring system scalabil-

ity, availability and performance.

• Determinism

COAST ensures a deterministic merging strategy

of concurrent operations. This means that repli-

cas that apply concurrent operations will reach the

same state, even if the operations arrive in a dif-

ferent order to different replicas.

Real-time collaborative development of text doc-

uments requires multiple replicas to agree on an iden-

tical view of the shared document while dealing with

the problems that are inherent to distributed systems.

One model that enables replicas to agree on the same

view of a distributed data structure is known as a

Conﬂict-Free Replicated Data Type (CRDT) (Shapiro

et al., 2011b).

While the use of string-based CRDTs has been

proven to be an effective strategy for collaborative

text editing for text in general, it ignores structural

information when the text at hand represents program

source code. This omission weakens the consistency

of the collaborative code editor. Although a pro-

gram’s source code is stored on computers as a se-

quence of characters, the programmer and the com-

puter eventually reason about the program structurally

in terms of its Abstract Syntax Tree (AST). The pro-

gram AST is a tree representation of the textual pro-

gram representation that abstracts from details such as

tokens that separate subexpressions from their parent

expression.

Designing the CRDT based on the program AST

makes it more informed about the underlying program

than handling the program as a large string, with-

out the need for semantic reasoning about the pro-

gram. Replicating the program AST allows us to face

the aforementioned weakened consistency from a dif-

ferent perspective. As ASTs manipulation prevents

breaking the syntactical structure of the code, query-

ing a CRDT from a concurrently manipulated AST

facilitates maintaining the syntactical correctness and

shifting the merge conﬂicts from character-based op-

erations to tree-structure changes. Because our ap-

proach relies on a CRDT, there is no need for strong

synchronization, which improves the availability of

the system (Shapiro et al., 2011a).

4 A REPLICATED

CONFLICT-FREE ABSTRACT

SYNTAX TREE

This work proposes a new approach for collabora-

tive code editing through modelling a program’s ab-

stract syntax tree as an operation-based CRDT. Our

approach consists of replicas of the program’s AST

sharing the state of the code. The CRDT operates in

different stages that depart from code changes in one

replica to converge on a changed AST on all other

replicas. First, changes to the source code text trig-

ger an event that veriﬁes syntactical correctness (ie. an

AST can be constructed). Next, for edits resulting in

a valid AST, the changes are computed in the form

of an edit script that describes what tree transforma-

tions transform the former AST into the latter. In the

next stage, these edit scripts are bundled with a logi-

COAST: A Conﬂict-free Replicated Abstract Syntax Tree

189

cal timestamp and replica identiﬁer, which is stored

on a local log and propagated over the network to

other replicas. Next, replicas that receive the incom-

ing edit scripts insert these edits in their local log in

chronological order and roll back local edits that suc-

ceed the incoming operations, after which they replay

all edits to end up with an equal view on the program

AST. Edit operations arriving in concurrent updates

may depend on earlier changes agreed upon by other

replicas. We adopt a permissive strategy to not in-

clude these operations when computing the ﬁnal tree

as they would invalidate the program, yet they remain

in the log. This behaviour prevents adding invalid

nodes to the graph that could otherwise break the pro-

gram. When the state of the local replica is in a valid

AST the outcome is then reﬂected on the code editor.

Figure 2 provides an overview of the beforementioned

stages that take place for a single syntactically correct

code-change to become replayed on other replicas.

The design of the AST CRDT is highly in-

spired by the design of the paper “A highly-available

move operation for replicated trees” by (Kleppmann

et al., 2022). Their work discusses the design of a

tree CRDT, motivating why move operations become

complex for replicated trees. We summarize the dis-

cussion on the difﬁculties:

• Concurrently Moving the Same Node

Say concurrently a move operation takes place for

the same node, resulting in the node green becom-

ing the child of its sibling blue on one replica and

becoming the child of its sibling orange on an-

other replica as Figure 3 presents. Once these op-

erations merge, different operations are possible,

prioritize a single outcome (Figure 3 (a) and (b)),

or duplicate the green node so that both blue and

orange can have an instance of green as their child

(Figure 3 (c)). Another option could be to have

both nodes blue and orange have as their child

node green, however this would break the tree-

like structure (Figure 3 (d)).

• Introducing Cycles

While move operations may uphold the guaran-

tees of the tree remaining as an acyclic structure

on individual replicas, their combination may in-

troduce cycles. Figure 4 shows the distinct out-

comes possible. The ﬁgure illustrates the possible

choices when two sibling nodes are concurrently

made a parent of one another. It allows for either

move operation to remain (Figure 4 (a) and (b)),

a duplicate instance of both nodes to enable both

move operations (Figure 4 (c)) or to introduce a

cycle to enable both operations without duplica-

tion, but this would break the tree requirement

(Figure 4 (d)).

The work of (Kleppmann et al., 2022) proposes to

accompany each operation with a timestamp such that

incoming operations that are out of order, allow the

CRDT to determine the point at which these should

have been applied. It then performs a rollback using

the undo op operation up until the point where the in-

coming operation can be applied after which all latter

operations can be replayed using the redo op oper-

ation. The authors formally validate their approach

by implementing their approach in the Isabelle/HOL

language, which allows proving the correctness of the

implementation.

Building on their approach we subsequently moti-

vate the correctness of our approach, although we do

not include formal correctness.

5 COMPUTING AST CHANGES

Before propagating AST changes over the network,

they need to be determined locally. AST changes can

also be derived from projectional editors, which allow

the user to develop their programs through manipulat-

ing an AST directly rather than having the program-

mer type the program in an open space for charac-

ters. The beneﬁt of projectional editors is that the

programmer can make no syntactic mistakes. The

drawback is the number of different building blocks

needed to construct a program can become complex

for languages with a rich syntax. Another option to

compute AST changes is through a tree differencing

algorithms (Chawathe et al., 1996; Fluri et al., 2007;

Falleri et al., 2014; Huang et al., 2018; Dotzler and

Philippsen, 2016; Frick et al., 2018).

Whereas projectional editors come with the disad-

vantage that they are specialized per language, AST

tree differencing algorithms exist with language ag-

nostic speciﬁcations. This work has adopted the

GumTree algorithm (Falleri et al., 2014), a language-

agnostic algorithm to compute the changes between

two ASTs.

The output of the GumTree algorithm is an edit

script, which is an ordered set of edit operations that

transform the source AST into the destination AST.

An AST edit script is composed of operations of the

following kinds (Chawathe et al., 1996):

• update(n, v) to update the content of node n with

the value v.

• add(t, p, i, l, v) to add node t with label l and value

v to parent p at index i.

• delete(t) to delete node t.

• move(t, p, i) to move node t in tree to be a child of

p at index i.

ICSOFT 2022 - 17th International Conference on Software Technologies

190

(begin

(eat "apple")

(touch nose))

d' e'

f g

c d

Delete f

Move 0

b e

a a'

b c'

c d'

d e'

e b'

g f'

Monaco Editor Headed AST GumTree Algorithm Minimum Edit Script

(begin

((touch nose) "apple"))

Conflict Free Replicated

AST

Conflict Free Replicated

AST

Monaco EditorReplicated Operation

1. Add a b 0

2. Add c b 0

3. Add d b 1

4. Add e a 1

....

m. Set c "eat"

n. Set g "nose"

o. Delete f

p. Move b e 0

Delete f

Move 0

b e

Local changes log

c d

...

change 1

change 2

change n

Before

After

(begin

(eat "apple")

(touch nose))

(begin

((touch nose) "apple"))

Before

After

Compute edit script4

Compute AST mapping

3Construct changed AST2Detect change1

Propagate serialized changes5 Update local log of changes6

Rollback & apply changes

7 Reflect changes8

insert

serialize

Replica

per replica

Figure 2: An overview of the stages that ﬂow through different components working together to make up a distributed

conﬂict-free replicated abstract syntax tree. Changes detected by the javascriptMonaco Editor trigger the construction of a

new HeadedAST, which is then mapped onto the previous HeadedAST through the GumTreeAlgorithm allowing to compute

the changes that took place as a MinimumEditScript. These AST changes are serialized and propagated over the wire as

ReplicatedOperations, as the CRDT is an operation-based CRDT. The incoming operations allow each replica to roll back the

local AST to then reapply all known changes in order. The ﬁnal computed AST is displayed by the javascriptMonaco Editor

which then reﬂects the converging AST to the developer.

A more constrained form of an edit script is a mini-

mum edit script, which is the smallest set of edit op-

erations that is still a valid edit script. In the context

of our CRDT AST, computing a minimum edit script

is desirable since it directly affects the network load.

The GumTree algorithm consists of a top-down

phase and bottom-up phase to compute a set of map-

pings between both ASTs, while it leaves the algo-

rithm to determine an edit script open to the imple-

mentor. The GumTree implementation used in this

work is based on the work of (Chawathe et al., 1996).

6 IMPLEMENTATION

We used Scala to implement COAST, opting for de-

pendencies such that the implementation can compile

to run on the JVM but also to JavaScript such that it

supports our prototype browser-based web IDE. The

implementation for of the CRDT is discussed in Sec-

COAST: A Conﬂict-free Replicated Abstract Syntax Tree

191

Make a

child of

Make a

child of

Desired outcome

Replica 2

Replica 1

Concurrent operations

Figure 3: A case in which concurrent move operations

take place for a node to become the child of either one of

its siblings, including the possible outcomes. The shown

outcomes illustrate there is either an operation-discarding

choice, a duplicating choice or a tree-structure breaking

choice that must be made. Inspired by the illustrations de-

signed by (Kleppmann et al., 2022).

tion 6.1 and the implementation for modeling the AST

is discussed in Section 6.2.

6.1 Implementing the Local CRDT

We deﬁne an interface for operation-based CRDT

classes that deﬁnes three methods:

• update to propagate external changes (operations)

to the local replicas model of CRDT

• query to yield the data structure that is known so

far, modeled by the local replica

• merge for combining incoming operations from

other replicas across the network

The concrete implementation of our AST CRDT

interface that supports COAST yields the AST upon

Make a

child of

Make a

child of

Desired outcome

Replica 2

Replica 1

c d

Concurrent operations

Figure 4: A case in which concurrent move operations take

place for two nodes to become each other’s descendant, in-

cluding the possible outcomes. The shown outcomes illus-

trate there is either an operation-discarding choice, a dupli-

cating choice or a tree-structure breaking choice that must

be made. Inspired by the illustrations designed by (Klepp-

mann et al., 2022).

invoking the query method by applying all received

edit operations in order on an empty AST. Ordering

the edit operations is possible by accompanying each

with a logical timestamp and replica owner identity,

making an arbitrary but deterministic ordering deci-

sion possible when the logical timestamp for two edits

is equal.

The application of edit operations to a program’s

AST is deterministic but permissive, thus when the

application of operations is not possible (such as mov-

ing a node that cannot be found) the operation is ig-

nored. By making both the ordering and the appli-

cation of the edit operations deterministic, we ensure

converging ASTs among all replicas with an equal set

of edit operations.

Upon invocation of the update method, the CRDT

propagates the local edit operations over the network

ICSOFT 2022 - 17th International Conference on Software Technologies

192

by publishing these changes on its local Transmitter,

which in the prototype is implemented using a third-

party peer-to-peer JavaScript networking library us-

ing the WebRTC standard. This Transmitter invokes

the merge method upon receiving remote edit opera-

tions from the network, which expands the local log

of edit operations with the new operations.

6.2 Implementing the Local AST

The AST itself is implemented in a functional code

style by representing the tree as a mapping from node

identities to nodes. This implies that the data struc-

tures are immutable which ensures that the replicated

application of the same edit script results in the same

AST outcome.

An intuitive implementation of the AST would be

to implement the tree structure as a root with pointers

to other nodes (that in their turn point to other nodes),

but opting for this indirection through identities eases

serialization of AST nodes, as pointers are avoided

in a distributed setting where replicas do not share a

memory space.

The prototype implementation limited the types

of nodes to numbers, strings, identiﬁers and expres-

sions. This set of nodes is relatively small but is suf-

ﬁciently large to provide a prototype that covers all

source-code edit operations for a language supporting

primitive values and nodes with descendants, showing

support for arbitrary nested setups.

For the browser-based prototype, whenever the

code is changed the AST is kept formatted in the

browser to ensure all replicas with the same opera-

tions have the same view.

7 DISCUSSION AND

VALIDATION

We leverage the existing work of (Kleppmann et al.,

2022) and (Falleri et al., 2014) to support the correct-

ness of our approach, however, we lay out the high-

level editor properties below.

Preventing Interfering Changes: When multiple

replicas add new code to the main program during

a network partition, the eventually merged program

will contain both additions without interleaving these

changes. This is guaranteed as the newly added

code is logged as an edit script that constructs a sub-

tree (i.e., the AST of the new code) which will con-

tain nodes that uniquely identify the replica that con-

structed this subtree.

Ensuring Syntactical Correctness: The eventual

data structure that is present on each replica is the

merged log of edit operations, which when queried

will result in an identical AST that represents the

merged program. To ensure this program is a syntac-

tically valid program tree, it should (a) be a valid tree

and (b) not break constraints that ensure syntactical

correctness.

Ensuring the program represents a valid tree re-

quires ensuring the created AST does not introduce

cycles, where node a would be the parent of node b

while b is also the parent of node a or that it does not

add a node without a parent. This requirement is not

implemented at the level of the edit script but when

constructing the AST, where these requirements are

asserted and when not met the operation is ignored,

which allows for local resolution of conﬂicts.

Ensuring syntactical correctness requires the guar-

antee that the requirements of each node are met. An

example would be an if -node that requires an expres-

sion as its condition ﬁeld and two more statements,

one for its consequent ﬁeld and another for its alter-

native ﬁeld. Consequent edit statements should not

result in failing to meet these requirements. The re-

sulting edit scripts from COAST update nodes exclu-

sively whenever their label matches which is a prop-

erty that follows from GumTree. In case the labels

are not equal the edit script deletes the old node and

adds the new node, resulting in two nodes that differ

in their identity which avoids interleaving of correct-

ness properties for different types of nodes. Despite

we do not provide a formal proof we believe this strat-

egy prevents constructing a tree which is an invalid

AST after a merging operation is done.

Tests:

The implementation of COAST comes with a test

suite of 54 tests to exercise the problems arising from

the example described in The IntelliJ Test Cover-

age Tool reports 100% Scala code coverage for our

test suite. Although it is limited, this testing suite

paired with the high amount of code coverage aims

to demonstrate the effort in verifying the correctness

of the codebase.

The test suite includes a setup in which we repli-

cate the behaviour of multiple replicas performing

the concurrent changes shown in Figure 1. This test

case simulates a temporal network partition and as-

serts that all permutations of the received operations

result in an equal output program for each replica.

These preliminary results show that our approach for

COAST can preserve the syntactical structure while

including both concurrent changes shown in Figure 1,

which the string-based CRDT could not.

COAST: A Conﬂict-free Replicated Abstract Syntax Tree

193

8 LIMITATIONS

There are a number of limitations in our current im-

plementation that can be further developed in future

work.

Lack of Heuristics to Pick a Winning Operation

for Conﬂicting Operations. The merge strategy of

our approach performs an ordering of concurrent op-

erations deterministically. However, the ordering is

based on the replica’s identity which prevents know-

ing which replica will perform the winning opera-

tions. An improvement to our current ordering of

concurrent operations could be the assignment of de-

veloper roles through the user interface. The system

should order roles such that operations of hierarchi-

cally higher roles are prioritized to win over other op-

erations. Alternatively, the system could prompt the

user with conﬂicting changes asking to agree on a sin-

gle change, which is more in line with the work of

traditional version control systems.

Lack of Merge Granularity. Currently, the merg-

ing of ASTs happens on a per-node basis. Although

this merge strategy is sufﬁciently powerful, additional

merging strategies based on the types of nodes that

are being affected can improve our current prototype.

For example, for string literal nodes, two concurrent

updates on a single string literal will result in an ar-

bitrary choice to dominate based on the replica iden-

tity. It would be more optimal to delegate the concur-

rent changes to the node which could further decide

on a better merge strategy, in this case opting for a

string-based CRDT. An additional example would be

for literal set nodes, two concurrent additions of an

expression value would duplicate the content, while

this does not make sense for set nodes thus it would

be the desired effect to prevent the double addition of

the content.

As addressed in Section 7 the interfering changes

happen for concurrent modiﬁcations to nodes present

on both replicas, local changes to locally created

nodes introduce no conﬂicts.

9 RELATED WORK

In this section, we describe recent and close related

work to CoAST.

Protzenko et al. (Protzenko et al., 2015) proposed

a conﬂict-free merge algorithm for collaborative edit-

ing which has been deployed as a cloud-based inte-

grated development environment (Ball et al., 2015).

Similar to our approach, the algorithm works at the

AST representation of the program. The algorithm at-

taches unique identiﬁers to the AST nodes and tracks

the order of nodes by remembering the siblings of a

particular node. When a merge occurs, both the lo-

cal and remote AST replicas are represented as sets.

Then, the resulting tree is built by re-attaching the par-

ents of the nodes in the set of the local replica and

then, the nodes in the set of the remote replica. Con-

current updates are handled by always accepting the

changes of the local replica.

Their approach models the program as an AST di-

rectly within the editor, allowing to track tree-edit op-

erations with higher precision. This comes at the cost

of specializing the editor to model the AST and ac-

counting for the possible edit operations, while our

approach derives the edits in a separate stage. In ad-

dition to this specialization, their approach stores the

program as text in the cloud while the replicas operate

on ASTs that are modelled as Cloud Types.

The Live Share (Microsoft, 2022) extension of

Microsoft’s IDEs enables real-time collaboration ses-

sions between a host replica and guest replicas. Live

Share’s approach to synchronising replicas is un-

known as its source code is not publicly available.

In contrast to our model, a Live Share collaboration

session requires a host replica to be always online to

maintain the session of guest replicas. Our experi-

ments show that the replication of Figure 1 does not

result in the proposed solution, but breaks the syntac-

tical structure of the program through outputting the

code shown in Listing 1, demonstrating the limited

syntactical reasoning about the program.

Jimbo (Ghorashi and Jensen, 2016) uses an oper-

ational transformation (OP) algorithm to enable real-

time collaborative code development. However, the

authors do not elaborate on the characteristics of the

algorithm or how concurrent updates are handled.

Saros (Salinger et al., 2010) is a collaborative edit-

ing plug-in for Eclipse. Concurrent activities within a

collaboration session are handled by an implementa-

tion of the Jupiter (Nichols et al., 1995) algorithm,

which relies on a central server for the coordination

of such activities.

The Atom’s Teletype (Atom, 2022) plugin im-

plements a string-wise CRDT (Yu, 2012; Yu, 2014)

to enable collaborative source code development. In

contrast to our work, a string-wise CRDT enables up-

date/insert operations at random places of the source

code (i.e., the string). These random updates may en-

able the propagation of syntactically incorrect updates

to the replicas. In contrast, our approach performs its

merges on the syntactical abstraction, thus the merged

outcome prevents syntactical incorrectness by design.

ICSOFT 2022 - 17th International Conference on Software Technologies

194

The Jetbrains’ Meta Programming System (?) al-

lows developers to extend IntelliJ-based editors with

a projectional editor for a domain-speciﬁc language.

Their editors furthermore support collaborative edit-

ing, however, we are unaware of their approach to

synchronising replicas as their source code is not pub-

licly available.

10 CONCLUSION

This paper presented an alternative approach, called

COAST, to implement a real-time collaborative code

editor to overcome the limitations that arise for tradi-

tional editors that treat source code as sequences of

characters. COAST synchronizes code at the level

of the abstract syntax tree (AST) and implements this

AST as a conﬂict-free replicated data type (CRDT).

Our proof-of-concept implementation covers a min-

imal set of nodes, but already demonstrates the ca-

pability of the merging strategy to resolve conﬂicts

for different concurrent operations. The strategy is

mainly based on the inclusion of a logical timestamp

allowing for an ordering of events that allows the data

structure to recompute the AST including newly re-

ceived updates. Even so, certain optimizations are in

order to improve conﬂict resolution, either by the in-

clusion of developer roles or by shifting the merge

granularity.

REFERENCES

Atom (2022). atom/teletype: Share your workspace with

team members and collaborate on code in real time in

atom. https://github.com/atom/teletype. (Accessed on

03/22/2022).

Baheti, P., Gehringer, E., and Stotts, D. (2002). Exploring

the efﬁcacy of distributed pair programming. In Wells,

D. and Williams, L., editors, Extreme Programming

and Agile Methods — XP/Agile Universe 2002, pages

208–220, Berlin, Heidelberg. Springer Berlin Heidel-

berg.

Ball, T., Burckhardt, S., de Halleux, J., Moskal, M.,

Protzenko, J., and Tillmann, N. (2015). Beyond open

source: The touch develop cloud-based integrated de-

velopment environment. In 2015 2nd ACM Interna-

tional Conference on Mobile Software Engineering

and Systems, pages 83–93.

Chawathe, S. S., Rajaraman, A., Garcia-Molina, H.,

and Widom, J. (1996). Change detection in hier-

archically structured information. SIGMOD Rec.,

25(2):493–504.

Dotzler, G. and Philippsen, M. (2016). Move-optimized

source code tree differencing. In 2016 31st

IEEE/ACM International Conference on Automated

Software Engineering (ASE), pages 660–671.

Falleri, J.-R., Morandat, F., Blanc, X., Martinez, M., and

Monperrus, M. (2014). Fine-grained and accurate

source code differencing. In Proceedings of the 29th

ACM/IEEE International Conference on Automated

Software Engineering, ASE ’14, page 313–324, New

York, NY, USA. Association for Computing Machin-

ery.

Fluri, B., Wursch, M., PInzger, M., and Gall, H. (2007).

Change distilling:tree differencing for ﬁne-grained

source code change extraction. IEEE Transactions on

Software Engineering, 33(11):725–743.

Frick, V., Grassauer, T., Beck, F., and Pinzger, M. (2018).

Generating accurate and compact edit scripts using

tree differencing. In 2018 IEEE International Con-

ference on Software Maintenance and Evolution (IC-

SME), pages 264–274.

Ghorashi, S. and Jensen, C. (2016). Jimbo: A collaborative

IDE with live preview. Proceedings - 9th International

Workshop on Cooperative and Human Aspects of Soft-

ware Engineering, CHASE 2016, pages 104–107.

Goldman, M. et al. (2012). Software development with real-

time collaborative editing. PhD thesis, Massachusetts

Institute of Technology.

Huang, K., Chen, B., Peng, X., Zhou, D., Wang, Y., Liu,

Y., and Zhao, W. (2018). Cldiff: Generating concise

linked code differences. In 2018 33rd IEEE/ACM In-

ternational Conference on Automated Software Engi-

neering (ASE), pages 679–690.

Kleppmann, M., Mulligan, D. P., Gomes, V. B. F., and

Beresford, A. R. (2022). A highly-available move op-

eration for replicated trees. IEEE Transactions on Par-

allel and Distributed Systems, 33(7):1711–1724.

Microsoft (2022). Faq - visual studio live share - vi-

sual studio live share — microsoft docs. https://docs.

microsoft.com/en-us/visualstudio/liveshare/faq. (Ac-

cessed on 03/02/2022).

Nichols, D. A., Curtis, P., Dixon, M., and Lamping, J.

(1995). High-latency, low-bandwidth windowing in

the Jupiter collaboration system. UIST (User Interface

Software and Technology): Proceedings of the ACM

Symposium, (October):111–120.

Nicolaescu, P., Jahns, K., Derntl, M., and Klamma, R.

(2015). Yjs: A framework for near real-time p2p

shared editing on arbitrary data types. In Cimiano,

P., Frasincar, F., Houben, G.-J., and Schwabe, D., edi-

tors, Engineering the Web in the Big Data Era, pages

675–678, Cham. Springer International Publishing.

Protzenko, J., Burckhardt, S., Moskal, M., and McClurg, J.

(2015). Implementing real-time collaboration in touch

develop using AST merges. MobileDeLi 2015 - Pro-

ceedings of the 3rd International Workshop on Mobile

Development Lifecycle, pages 25–27.

Salinger, S., Oezbek, C., Beecher, K., and Schenk, J.

(2010). Saros: An eclipse plug-in for distributed party

programming. Proceedings - International Confer-

ence on Software Engineering, pages 48–55.

Shapiro, M., Preguic¸a, N., Baquero, C., and Zawirski, M.

(2011a). A comprehensive study of Convergent and

Commutative Replicated Data Types. Research Re-

port RR-7506, Inria – Centre Paris-Rocquencourt ;

INRIA.

Shapiro, M., Preguic¸a, N., Baquero, C., and Zawirski,

M. (2011b). Conﬂict-free replicated data types. In

COAST: A Conﬂict-free Replicated Abstract Syntax Tree

195

efago, X., Petit, F., and Villain, V., editors, Stabi-

lization, Safety, and Security of Distributed Systems,

pages 386–400, Berlin, Heidelberg. Springer Berlin

Heidelberg.

Yu, W. (2012). A string-wise CRDT for group editing.

GROUP’12 - Proceedings of the ACM 2012 Interna-

tional Conference on Support Group Work, (Figure

1):141–144.

Yu, W. (2014). Supporting string-wise operations and selec-

tive undo for peer-to-peer group editing. Proceedings

of the International ACM SIGGROUP Conference on

Supporting Group Work, pages 226–237.

ICSOFT 2022 - 17th International Conference on Software Technologies

196
