PhishGNN: A Phishing Website Detection Framework using Graph

Neural Networks

Tristan Bilot, Gr

egoire Geis and Badis Hammi

EPITA School of Engineering, France

Keywords:

Phishing Detection, Graph Neural Networks, Deep Learning, Cybersecurity.

Abstract:

Because of the importance of the web in our daily lives, phishing attacks have been causing a signiﬁcant

damage to both individuals and organizations. Indeed, phishing attacks are today among the most widespread

and serious threats to the web and its users. Currently, the main approaches deployed against such attacks are

blacklists. However, the latter represent numerous drawbacks. In this paper, we introduce PhishGNN, a Deep

Learning framework based on Graph Neural Networks, which leverages and uses the hyperlink graph structure

of websites along with different other hand-designed features. The performance results obtained, demonstrate

that PhishGNN outperforms state of the art results with a 99.7% prediction accuracy.

1 INTRODUCTION

In the era of the Internet, malicious URLs are a com-

mon threat to the Web users. Phishing aims at steal-

ing sensitive information by fooling victims with fal-

siﬁed interfaces. In the case of phishing websites,

attackers usually try to impersonate well-known and

widely used services such as social media, banks and

e-commerce websites. Such spoofed websites are

often built from the same code base as the original

site, which could make them difﬁcult to detect at ﬁrst

glance. Thankfully, numerous other indicators can be

used to differentiate benign and phishing websites.

For instance, most phishing URLs tend to be very

long, with multiple sub-domains and special charac-

ters. Domains are often hosted on suspicious hosts

and use Secure Socket Layer (SSL) certiﬁcates de-

livered by non-trusted authorities. Since the begin-

ning of these attacks, numerous systems have been

implemented to try to overcome them. Some of these

implementations use traditional techniques such as

blacklists or URL lexical features’ analysis. Nonethe-

less, blacklists suffer from multiple drawbacks like

the need for human assistance to be updated and the

lack of exhaustiveness. Furthermore, they cannot be

used on unseen and hidden URLs. Other techniques

leverage Machine Learning to train a model to clas-

sify websites based on a number of examples (Sahoo

et al., 2017), (Benavides et al., 2020). However, in

most approaches, the hyperlink structure of websites

is not tackled.

In this paper we introduce PhishGNN, a frame-

work that leverages and uses both hyperlink struc-

tural features along with other features that have been

proven to be successful for phishing classiﬁcation

We also introduce features such as is same domain

which are essential for differentiating two websites

with the same structure. As many phishing web-

sites redirect to legitimate ones, each link pointing

to these websites has a different domain. However,

on the legitimate website, these links are redirecting

to the same domain, so the feature will be distinct in

both cases and the model will learn how to differen-

tiate them. We evaluated our approach through a real

implementation. The performance results obtained

demonstrate the efﬁciency and effectiveness of our

approach in terms of detection accuracy and its capac-

ity to outperform the existing detection approaches.

2 RELATED WORKS

The detection of phishing websites aims to classify

whether websites are phishing or benign. Research in

this area has increased sharply as the number of phish-

ing websites has exploded in recent years. While ad-

vanced techniques have been proposed for this task,

most solutions currently in production are based on

blacklists (Sahoo et al., 2017). However, phishing

https://archive.ics.uci.edu/ml/datasets/Phishing+

Websites

428

Bilot, T., Geis, G. and Hammi, B.

PhishGNN: A Phishing Website Detection Framework using Graph Neural Networks.

DOI: 10.5220/0011328600003283

In Proceedings of the 19th International Conference on Security and Cryptography (SECRYPT 2022), pages 428-435

ISBN: 978-989-758-590-6; ISSN: 2184-7711

websites become more and more complex and there

is an urgent need for reliable and efﬁcient techniques

to detect them on demand, without human interaction.

2.1 Traditional Techniques

The most common technique used for the detection of

phishing websites is the use of blacklists. However,

this technique reveals numerous drawbacks, mainly:

(1) it requires the manual curation of such a black-

list. (2) it requires the storage (space consumption)

or the querying (time and computing resource con-

sumption) of a blacklist. (3) crowdsourced black-

lists like PhishTank are centralized and lack trans-

parency. The resources consumption problem is ad-

dressed by the Google Safe Browsing API, notably

used in Chromium and in Firefox, which provides

both an online service and a small, downloadable

database of truncated hashes

Prakash et al. (2010) also show that it is possible

to build blacklists that, based on their current entries,

can predict new entries with no human involvement.

As lists are inherently ﬂawed, other techniques

have been proposed to detect phishing using human-

deﬁned heuristics, designed after identifying inherent

characteristics of known phishing websites. Indeed,

since obtaining legitimate domains requires compro-

mising their corresponding entity, phishing websites

often use patterns in the URL to appear like legiti-

mate domains while being subtly different. Further-

more, Sonowal and Kuppusamy (2020) suggest that

having symbols such as ”-” and ”@”, or having more

than three dots in the domain name is suspicious, and

considers long URLs suspicious as well because they

make it harder for users to read the signiﬁcant part

of the URL. Sonowal and Kuppusamy (2020) assign

lower legitimacy scores to web pages that have low

accessibility scores and to those whose lexical signa-

ture does not appear within the ﬁrst results of search

engines.

It was often assumed that legitimate websites are

protected by Transport Layer Security protocol (TLS)

and that phishing websites are not. However, this as-

sumption no longer holds true because most recent

phishing websites are also protected by TLS (82%

in 2021

). Despite this, new techniques exist to as-

sess the legitimacy of TLS certiﬁcates (Sakurai et al.,

2020).

Phishing websites can protect themselves against

content-based phishing detection by obfuscating the

https://developers.google.com/safe-browsing/v4/

urls-hashing

https://docs.apwg.org/reports/apwg trends report q2

2021.pdf

content of their pages. In response, researchers have

used image snapshots of suspicious pages to extract

text content using optical character recognition (Dun-

lop et al., 2010), or to look up whether the suspi-

cious page used logos that are typically associated

with other domains (Wang et al., 2011).

Finally, it has been shown that using combinations

of different techniques leads to more accurate results

(Sonowal and Kuppusamy, 2020).

2.2 Machine Learning Techniques

Machine Learning (ML) and Deep Learning (DL)

have known a real boom during the last decade and

have been widely used in the phishing classiﬁcation

task (Sahoo et al., 2017), (Benavides et al., 2020).

When using such techniques, the ﬁrst step is usually

to extract a set of features from the URL. Although

Deep Learning models have the ability to learn fea-

tures by themselves from raw data, it is challenging to

exploit them directly because a website is not only de-

ﬁned by its raw HTML content. Many useful features

can be extracted by hand from the website’s URL

in order to build a more powerful and robust model.

Deep Learning can be used on top of the features to

let the model learn other kinds of representations that

could improve the classiﬁcation accuracy. These fea-

tures can be divided in three classes: lexical, content

and domain features.

Lexical Features: features that could be extracted

from the URL as a string. Some examples are

the URL length, the entropy, the number of spe-

cial characters, the number of sub-domains, and

so on.

Content Features: features related to the HTML

content of the web page. Such features are ob-

tained by fetching the DOM of the pages and then

processing it to extract useful information like the

number of anchors, the presence of a form, the

number of Javascript imports, and so on.

Domain Features: features obtained from the do-

main name extracted from the URL. By request-

ing that domain, it is possible to extract features

from the underlying server such as its location, the

connection speed, ”WHOIS” information, Secure

Socket Layer (SSL) certiﬁcate and so on.

According to Sahoo et al. (2017), content-based and

lexical-based features are mostly used in Machine

Learning techniques, compared to host-based fea-

tures, due to the complexity of extracting these ones.

Most state of the art approaches for phishing clas-

siﬁcation are URL-based. That is, they focus on the

extraction of useful features directly from the raw

PhishGNN: A Phishing Website Detection Framework using Graph Neural Networks

429

URL. Some studies use traditional Machine Learning

with hand-crafted features to make predictions (Jain

and Gupta, 2018), while others prefer using Deep

Learning to let the model learn the features on its own

(Sahoo et al., 2017). Deep Learning methods have the

beneﬁt of avoiding human-assisted feature engineer-

ing and thus do not require the assistance of domain

experts. Thanks to these beneﬁts, numerous recent

studies (Benavides et al., 2020) apply Deep Learning

to URL classiﬁcation. URL-based classiﬁcation is a

key process in the overall phishing classiﬁcation task.

This is due to the numerous lexical features possible

to extract from a raw URL string.

Saxe and Berlin (2017) proposed eXpose, a so-

lution based on a Convolutional Neural Network

(CNN), where convolutions are applied to the raw

URL at character-level. The convolutions are used to

ﬁnd patterns between characters that could lead to in-

teresting hidden features. In the same context, URL-

Net (Le et al., 2018) is a framework where a character-

level CNN is used in combination with a word-level

CNN. It is stated that using word-level features along

with character-level features achieve better results for

the URL classiﬁcation task. Other techniques such as

HTMLPhish (Opara et al., 2020), take proﬁt of CNNs

to learn the semantic dependencies in the textual con-

tent of the raw HTML page. Using this architecture,

they achieve 93% accuracy with no feature engineer-

ing required.

Similar to our solution, Tan et al. (2020) propose

a graph-based detection system where hand-crafted

features are extracted from the hyperlink structure of

the webpage, achieving 97.8% accuracy using a C4.5

classiﬁer. However, this implementation solely de-

pends on human-created features that could be biased.

The authors do not leverage the Deep Learning to let

the model learn by itself the most useful features to

differentiate benign and phishing examples. Further-

more, a dataset of only 1000 samples is used (500 be-

nign, 500 phishing), resulting in a model that could

difﬁcultly generalize on new data.

To the best of our knowledge, the sole applica-

tion of Graph Neural Networks to phishing detec-

tion is based on the HTML structure of the website

(Ouyang and Zhang, 2021). In this approach, a graph

is built from the HTML DOM and a GNN is fed with

this graph. However, this method only relies on the

HTML content, which could be easily stolen from be-

nign websites in order to build perfect website copies.

This method could thus be easily bypassed by cloning

the HTML structure of legitimate websites.

Unlike previous approaches, our solution takes ad-

vantage of the internal links structure of the website,

along with the traditional features that led to success-

ful results as shown in previous papers. By analysing

many phishing websites, we ﬁgured out that most of

them use similar ”href” patterns in <a>, <form> and

chors (URLs starting by #) or outgoing links to ex-

ternal domains (usually pointing to a legitimate web-

site like a bank or a social media). Such patterns

are useful for phishing classiﬁcation because a neu-

ral network can be trained to learn how to distin-

guish websites with different structures. Malicious

websites could hardly bypass this detection system

because most of the outgoing links present on these

websites redirect to external websites from other do-

main names in order to fool victims by persuading

them that the website is legitimate.

3 PROPOSED APPROACH

3.1 Graph Neural Networks

Graph Neural Networks (GNNs) represent a type of

neural networks that takes graph data as input. Unlike

other neural network architectures, GNNs can handle

non-euclidean data with complex relations between

objects. Most GNNs follow the message-passing

framework (MPNN) (Gilmer et al., 2017) and can be

considered as a generalization of convolutional neural

networks (CNN) for graphs. This message-passing

algorithm takes as input a graph G = (V , E) with n

nodes v

∈ V and m edges (v

, v

) ∈ E, where G could

be directed or undirected. Each node and edge can

store a vector of features, respectively named node

and edge features. Generally, all this information is

represented through three matrices:

• A: the graph-structure matrix, of shape n × n in

the case of an adjacency matrix and 2 × n for a

CSR (Compressed Sparse Row) or COO (COOr-

dinates) sparse matrix

• X: the node features matrix of shape n × d

• E: the edge features matrix of shape m × e

where n = |V |, m = |E|, d and e are respectively the

number of features per node and per edge.

The message passing framework consists of four

steps, where steps 1 to 3 are implemented by one

GNN layer and are repeated as many times as there

are layers. Step 4 is a ﬁnal step that should be applied

after passing through every GNN layers.

1. MESSAGE: every node creates a message based on

its node features and sends it to all neighbors.

2. AGGREGATE: nodes aggregate the incoming mes-

sages from every neighbor by using an aggrega-

tion function.

SECRYPT 2022 - 19th International Conference on Security and Cryptography

430

X ∈ R

n×d

−→

ˆx

X ∈ B

−−−→

GNN

a) b)

ˆx

∑

ˆy

∈ R

n×h

y ∈ R

−−−→

linear

Figure 1: PhishGNN architecture comprises two steps: PRE-CLASSIFICATION (a) and MESSAGE-PASSING (b). Example

using a graph with one root URL x

and 4 outgoing links x

2≤i≤5

. The input feature matrix X is processed in these 2 steps to

result in a prediction vector ˆy containing the probability of the 2 classes.

3. UPDATE: the old features of a node are updated

by merging them with new features aggregated,

creating node embeddings.

4. READOUT: combines every node embeddings into

a representation that could be used in downstream

Machine Learning algorithms for prediction.

Every step is generally a function with learnable pa-

rameters, that is, weight matrices and activation func-

tions are used in the computation of both steps. One

GNN layer usually corresponds to the propagation of

features within a 1-hop neighborhood, so stacking n

GNN layers will result in node features propagating

up to n distant nodes. In each of these layers, every

node gathers its neighbors’ features to result in graph

embeddings.

3.2 PhishGNN

We propose PhishGNN, a framework for websites

classiﬁcation (phishing or benign) based on Graph

Neural Networks. This framework can be considered

as an additional layer to GNN architectures. There-

fore, it can be easily plugged-in existing GNN imple-

mentations. We use graphs to leverage the hyperlink

structure of websites. In the context of GNNs, we

consider the task of phishing websites classiﬁcation

as a node classiﬁcation task, where the node to clas-

sify is a given URL and the other nodes represent ev-

ery possible link coming from that URL until a user-

deﬁned depth. From these links, it is possible to build

a graph where nodes represent URLs, and edges are

the links between URLs, extracted either from <a>,

<form> or <iframe> tags. More precisely, the graph

is a rooted graph where the root node is the website to

classify (named root URL). The input dataset (fed to

our classiﬁer) contains a list of root URLs, mapping

to a label: phishing or benign. For each URL in the

dataset provided, a feature vector is extracted, as well

as a vector of all URLs (children URLs) going from

that root URL. Features are also extracted for the chil-

dren URLs. The feature vectors are used to build the

feature matrix X . The children URLs are used to build

the actual graph-structure matrix A.

In our approach, we suggest to train a model in

a semi-supervised mode. The known labels are the

actual root URLs and the unknown labels represent

every child URL (i.e. we do not know if these URLs

are phishing or not). Our contribution highly relies on

the fact that knowing the label of every node around

the root node makes that node much easier to clas-

sify. Given that labels are not known for every child

URL, a classiﬁer could be used to ﬁnd an approxi-

mation for these labels. This classiﬁer is trained on

every supervised example available in the dataset and

is then used for inference on all other unsupervised

examples. Afterwards, using a traditional GNN with

message passing will gather information from classi-

ﬁed nodes to build the embeddings. We use pooling

methods such as add, max or mean on top of the em-

beddings to reduce graph dimension to a single node

embedding. A linear layer is used as a ﬁnal layer to

make a prediction.

As Figure 1 shows, the architecture is divided into

two steps:

(a) PRE-CLASSIFICATION: initially, the graph com-

prises n nodes, where each node x

(1 ≤ i ≤ n) is

a vector of d features extracted from the corre-

sponding i

URL. x

is the root URL node and

every node x

(1 < i ≤ n) represent a link com-

ing from x

. At this ﬁrst step, a binary classi-

ﬁer is used to predict in a semi-supervised mode

whether a node is phishing or benign, for each fea-

ture node x

(1 ≤ i ≤ n). The classiﬁer is a function

g : R

→ B, where B is the Boolean domain. After

this step, the feature matrix X is transformed to a

vector

X containing respectively zeroes and ones

PhishGNN: A Phishing Website Detection Framework using Graph Neural Networks

431

for legitimate and phishing predictions.

(b) MESSAGE-PASSING: the predictions are then

passed through a traditional message passing

GNN with h hidden layers, to propagate the infor-

mation in the graph and learn node embeddings.

This results into a matrix

where each node is

an embedding vector of size h. A pooling method

is used to reduce the dimension of node embed-

dings to a single node of shape 1 × h. Finally, a

dot product is applied between this node and a lin-

ear layer of shape 2 × h, resulting into a vector

containing the probability of belonging into each

class: phishing or benign.

The graph-structure matrix A is stored in memory

using the COO format, which requires only O(|E|)

memory space, i.e. it grows linearly according to

the number of edges. The feature matrix X uses

O(|V |×d) memory as it stores ﬁxed-size feature vec-

tors for each node.

The propagation rule of PhishGNN with a

Graph Convolutional Network (GCN) as MESSAGE-

PASSING step is the same as the original GCN propa-

gation rule:

f (H

(l+1)

, A) = f (H

(l)

, A) (1)

f (H

(l)

, A) = σ(

−1

(l)

) (2)

where A is the adjacency matrix, H

(l)

is the propa-

gation at layer l, σ is the ReLU non-linear activation

function (Rectiﬁed Linear Unit), W

(l)

is a weight ma-

trix at layer l,

A is the adjacency matrix with self loops

such that

A = A + I (I is the identity matrix), and

D is

the diagonal matrix of

However, instead of starting with H

(0)

= X in

the original GCN, PhishGNN applies the PRE-

CLASSIFICATION step to X such that H

(0)

= g(X),

where g is a Random Forest prediction function.

4 PERFORMANCE EVALUATION

4.1 Evaluation Framework

To train the model and later evaluate arbitrary in-

puts, raw features related to a given URL must be ob-

tained. Unlike traditional classiﬁers operating on con-

tent features, PhishGNN must crawl web pages re-

cursively to provide features for the pages referenced.

Several existing crawlers were considered, but ulti-

mately we implement a crawler speciﬁcally designed

for PhishGNN with the following functionalities.

1. ROBUSTNESS: Servo’s HTML and URL parsers

were used, while domain names are parsed us-

ing Mozilla’s Public Sufﬁx List. rustls is used

for establishing safe TLS connections. Pages that

take more than 10 seconds to read, or that are over

1 MiB, or that lead to more than 10 redirects are

dropped.

2. CONCURRENCY: multiple processes can operate

on the same database at the same time, and each

process contains workers which run in parallel

(using OS threads) and concurrently (using asyn-

chronous tasks).

3. DOMAIN-SPECIFICITY: two types of workers are

available; core workers extract lexical and con-

tent features. Domain workers extract domain fea-

tures. Thus, each domain is processed only once,

no matter how many pages are hosted on it.

4. EXTERNAL STORAGE: the processing queue lives

entirely on a database separate from the workers.

This enables distributed workers to be stopped or

resumed at will, and direct interaction with the

database to, for instance, monitor progress.

Crawling websites can be a heavy and time-

consuming task, which is why the crawler stops pro-

cessing URLs after a speciﬁed depth is reached; in

this study, we have set the crawling depth to 1 (that

is, both pages of depth 0 and 1 are crawled for their

features). A total of 25 features per URL are extracted

during crawling. We classify the most important fea-

tures as follows.

1. LEXICAL FEATURES: is ip address,

domain length, domain depth (number of

dots in the domain name), dashes count,

has at symbol.

2. CONTENT FEATURES: is valid html,

has iframe, has form with url. Refer-

ences are added for <a>, <form>, and <iframe>

elements with valid (i.e. statically known and

leading to a valid HTTP or HTTPS URL after

resolution) href, action, and src attributes.

3. DOMAIN FEATURES: is cert valid (i.e. active

and accepted by rustls), cert reliability

(computed using the duration of the certiﬁcate

and whether its issuer is trusted), has whois,

domain age (seconds between the last update

date and the expiry date).

After extraction, features are exported to a ﬁle which

can be read and pre-processed in Python. To better

understand the underlying structure of each website,

we have developed a tool to visualize every graph

from the dataset. In Figure 2, two crawled web pages,

with different structures, are represented as graphs.

SECRYPT 2022 - 19th International Conference on Security and Cryptography

432

Figure 2: Graph representation of two websites after crawl-

ing with depth=1. Graph on the left contains multiple chil-

dren URLs already crawled in previous iterations so their

children are inserted in the graph as nodes of depth 2. Graph

on the right contains children URLs never crawled before.

Node in dark blue is the root URL, nodes in cyan and yellow

are respectively URLs from the same domain and different

domain, while red nodes are URLs returning an error code

(HTTP status not in range 200-299).

Model Mean-Pool Max-Pool Add-Pool Time

GIN 48±1.5 59±2.4 76±0.1 37.2

GAT 79±3.2 59±2.7 82±1.1 45.5

MemPooling 78±3.0 73±4.1 76±3.8 67.5

GCN

91±0.5 93±0.2 92±0.5 32.1

GCN

91±0.3 92±0.1 89±0.7 34.4

GraphSAGE 92±0.4 92±0.5 89±0.7 29.4

ClusterGCN 93±0.3 93±0.6 72±2.8 37.8

Figure 3: Model accuracy in % on test set for 10 epochs, for

every implemented GNN. Each model is declined in three

versions using multiple pooling methods (mean, max, add)

as readout functions.

4.2 Dataset

Finding a reliable public phishing dataset is fairly

challenging because the lifetime of phishing web-

sites is really short (few days or weeks). Hence, we

have built a dataset based on around 30,000 mali-

cious URLs, extracted from public phishing blacklists

such as OpenPhish

or PhishTank

. However, most of

these URLs redirect to 404 error pages as the corre-

Model Mean-Pool Max-Pool Add-Pool Time

PhishGNN

GIN

52.4 53.2 71.2 23

PhishGNN

GAT

88.9 62.1 95.0 90

PhishGNN

MemPooling

75.8 99.2 98.0 23

PhishGNN

GCN

99.7 99.7 99.1 20

PhishGNN

GCN

99.7 99.7 99.2 22

PhishGNN

GraphSAGE

99.6 99.6 99.6 17

PhishGNN

ClusterGCN

99.7 99.7 97.2 24

Figure 4: Accuracy of PhishGNN framework on test set for

1 epoch using a Random Forest setting. PhishGNN

GCN

PhishGNN

GCN

and PhishGNN

ClusterGCN

achieve best re-

sults with 99.7% accuracy.

https://www.openphish.com/

https://phishtank.org/

sponding websites are now out of service. The ﬁrst

ﬁltering operation to apply on the dataset is thus to

check that every website is responding with a success-

ful HTTP code (i.e. in the range 200-299). This step

has reduced the dataset size by 85%. Furthermore,

some of the ﬁltered URLs are labeled incorrectly. In-

deed, totally legitimate websites like wikipedia.org or

baidu.com are sometimes classiﬁed as phishing in-

stead of benign. These incorrect classiﬁcations could

lead to a biased model and therefore to incorrect pre-

dictions. To prevent this, we used the Google Safe

Browsing API in order to ﬁlter the dataset. Using

this service on every URL from the dataset improves

the reliability of each training example and brings a

fairly better data quality but also removes a signiﬁcant

amount of data. This ﬁltering step reduces the size of

the dataset again by around 40% but has proven to be

proﬁtable. Furthermore, only websites containing at

least a <form>, <input> or <textarea> tag are used

for training. Indeed, we assume that phishing web

pages usually request the user’s personal information.

A web page not containing such HTML tags is there-

fore not trying to steal any information.

Benign URLs are extracted from the Alexa top 1 mil-

lion sites dataset

. The same ﬁltering process is ap-

plied, except for the Safe Browsing API ﬁlter. We use

approximately the same number of training examples

in both classes in order to obtain a balanced dataset.

After the ﬁltering steps, the overall dataset con-

tains 4633 high quality URLs: 2300 benign and 2333

phishing. Graph matrices are built from the crawled

URLs of the dataset. These graphs possess the fol-

lowing statistics: 90 average and 31 median nodes,

ranging from 1 to 5185 nodes, 138 average and 45

median edges, ranging from 0 to 5214 edges.

4.3 Numerical Results and Discussion

4.3.1 Evaluation of Existing GNNs

A total of 7 well-known GNNs have been imple-

mented and trained on the crawled dataset. Every

model was implemented

in Python using the Py-

Torch Geometric library. In this section, we de-

scribe the benchmarking performances of the mod-

els based on the raw features, without considering the

PhishGNN implementation. Models performance is

measured using 10-fold cross-validation during train-

ing. Cross-validation allows to test the model on ev-

ery dataset example and thus gives a better indication

of how well the model performs on unseen data. For

https://www.kaggle.com/datasets/cheedcheed/top1m

Experiments done in this paper are available on

GitHub: https://github.com/TristanBilot/phishGNN.

PhishGNN: A Phishing Website Detection Framework using Graph Neural Networks

433

each GNN architecture, the network is trained for 10

epochs using Adam optimizer with a batch size of 32.

Hyperparameters have been tuned using a validation

set during training. The training starts with a learning

rate of 10

−2

and is decreased by 5% every 3 epochs,

most of the time resulting in a better performance

when set to 9025.10

−3

. The loss is computed at

each epoch using cross-entropy. Implemented mod-

els are GIN (Xu et al., 2018), GAT (Veli

ckovi

c et al.,

2017), MemPooling (Ahmadi, 2020), GCN (Kipf and

Welling, 2016), GraphSage (Hamilton et al., 2017)

and ClusterGCN (Chiang et al., 2019). GCN

and

GCN

are respectively implementations of GCN with

2 and 3 GCN layers. Training has been done on a

NVIDIA Tesla K80 GPU using 16, 32 and 64 hid-

den neurons, where the setting with 32 hidden neu-

rons gave the best accuracy on the validation set. The

obtained results are therefore based on models trained

with hidden layers of size 32. Corresponding accu-

racies (mean ± standard deviation) and the average

execution times are listed in Figure 3.

4.3.2 Evaluation of PhishGNN

In this section, we are interested in benchmarking

PhishGNN framework with every GNN architecture

implemented previously. Traditional Machine Learn-

ing techniques are also evaluated in order to ﬁnd the

best classiﬁer to integrate with PhishGNN. As Fig-

ure 5 describes, most traditional Machine Learning

methods achieve equivalent or even better results than

the previous GNNs. Thereby, the Random Forest

(i.e. the classiﬁer with best accuracy) is chosen as

the default classiﬁer used in the PhishGNN architec-

ture. By combining Random Forest predictions as

PRE-CLASSIFICATION step and GCN

as MESSAGE-

PASSING step, we outperform every other result by a

large gap with an accuracy of 99.7%. The accuracy

has been computed according to Equation 3:

Acc =

(3)

where C is the number of correct predictions and N is

the total number of predictions. A detailed analysis

of true and false positives/negatives is demonstrated

in Figure 6.

As Figure 4 shows, we achieve high scores

with every pooling method in only one epoch. As

predictions are already pre-computed in the PRE-

CLASSIFICATION step, there is no need to train the

GNN multiple times, as we want to propagate the in-

formation one time to obtain node embeddings.

To better understand the model predictions, node

embeddings have been extracted directly after the

pooling step and are plotted in Figure 7, using the T-

distributed Stochastic Neighbor Embedding (TSNE)

88 90 92 94

98 100

PhishGNN

Random Forest

kNN

RBF SVM

GCN

Logistic Regression

Decision Tree

Feed Forward Network

Naive Bayes

Linear SVM

99.7

95.8

95.2

93.9

92.9

88.3

87.7

Accuracy (%)

Figure 5: Classiﬁcation accuracies between traditional Ma-

chine Learning methods, GCN and PhishGNN.

Benign Phishing Total

Benign 688 3 691

Phishing 2 802 804

Total 690 805 1495

Figure 6: Confusion matrix for a test set of 1495 examples

(30% of the overall dataset).

dimension reduction technique. Although the tradi-

tional GCN achieves great classiﬁcation results, we

see in embedding space that the model fails to de-

limit many nodes. However, thanks to the the PRE-

CLASSIFICATION step in PhishGNN, node embed-

dings are more grouped and classes can be delimited

by a straight line, which leads to a better classiﬁca-

tions.

5 CONCLUSION AND FUTURE

WORKS

To the best of our knowledge, we introduced the ﬁrst

Graph Neural Network framework applied to web-

site hyperlink structure for the phishing classiﬁcation

task. Our experiments has shown that GNNs directly

applied on the website graph structure is less efﬁcient

than traditional Machine Learning methods applied to

features. However, by leveraging the semi-supervised

structure of the graph, a classiﬁer can be trained on

supervised examples and make predictions on unsu-

pervised ones. The semi-supervised predictions are

Figure 7: Embeddings of two models trained on our dataset.

GCN

without PhishGNN (left) and with PhishGNN

(right). Green: Benign; Red: Phishing.

SECRYPT 2022 - 19th International Conference on Security and Cryptography

434

then taken by a GNN as new input features and af-

ter message-passing, outperforms both traditional and

Machine Learning techniques. The best accuracy has

been achieved using a GCN combined with a Random

Forest classiﬁer. Furthermore, our approach is easily

pluggable with any GNN architectures or other down-

stream classiﬁcation methods. Hence, can be adjusted

and improved in future works.

For future works we will focus on the establish-

ment of a larger dataset, that contains more diverse ex-

amples. This dataset will be used in further research

to improve benchmarking capabilities for phishing

classiﬁcation based on GNNs. We will also focus on

improving the accuracy of our approach via leverag-

ing edge features in the graph.

REFERENCES

Ahmadi, A. H. K. (2020). Memory-based graph networks.

PhD thesis, University of Toronto (Canada).

Benavides, E., Fuertes, W., Sanchez, S., and Sanchez, M.

(2020). Classiﬁcation of phishing attack solutions by

employing deep learning techniques: A systematic lit-

erature review. Developments and advances in defense

and security, pages 51–64.

Chiang, W.-L., Liu, X., Si, S., Li, Y., Bengio, S., and Hsieh,

C.-J. (2019). Cluster-gcn: An efﬁcient algorithm for

training deep and large graph convolutional networks.

In Proceedings of the 25th ACM SIGKDD Interna-

tional Conference on Knowledge Discovery & Data

Mining, pages 257–266.

Dunlop, M., Groat, S., and Shelly, D. (2010). Goldphish:

Using images for content-based phishing analysis. In

2010 Fifth international conference on internet moni-

toring and protection, pages 123–128. IEEE.

Gilmer, J., Schoenholz, S. S., Riley, P. F., Vinyals, O., and

Dahl, G. E. (2017). Neural message passing for quan-

tum chemistry. In International conference on ma-

chine learning, pages 1263–1272. PMLR.

Hamilton, W., Ying, Z., and Leskovec, J. (2017). Inductive

representation learning on large graphs. Advances in

neural information processing systems, 30.

Jain, A. K. and Gupta, B. (2018). Phish-safe: Url features-

based phishing detection system using machine learn-

ing. In Cyber Security, pages 467–474. Springer.

Kipf, T. N. and Welling, M. (2016). Semi-supervised clas-

siﬁcation with graph convolutional networks. arXiv

preprint arXiv:1609.02907.

Le, H., Pham, Q., Sahoo, D., and Hoi, S. C. (2018). Url-

net: Learning a url representation with deep learn-

ing for malicious url detection. arXiv preprint

arXiv:1802.03162.

Opara, C., Wei, B., and Chen, Y. (2020). Htmlphish: en-

abling phishing web page detection by applying deep

learning techniques on html analysis. In 2020 Interna-

tional Joint Conference on Neural Networks (IJCNN),

pages 1–8. IEEE.

Ouyang, L. and Zhang, Y. (2021). Phishing web page de-

tection with html-level graph neural network. In 2021

IEEE 20th International Conference on Trust, Secu-

rity and Privacy in Computing and Communications

(TrustCom), pages 952–958. IEEE.

Prakash, P., Kumar, M., Kompella, R. R., and Gupta, M.

(2010). Phishnet: predictive blacklisting to detect

phishing attacks. In 2010 Proceedings IEEE INFO-

COM, pages 1–5. IEEE.

Sahoo, D., Liu, C., and Hoi, S. C. (2017). Malicious url

detection using machine learning: A survey. arXiv

preprint arXiv:1701.07179.

Sakurai, Y., Watanabe, T., Okuda, T., Akiyama, M., and

Mori, T. (2020). Discovering httpsiﬁed phishing web-

sites using the tls certiﬁcates footprints. In 2020 IEEE

European Symposium on Security and Privacy Work-

shops (EuroS&PW), pages 522–531. IEEE.

Saxe, J. and Berlin, K. (2017). expose: A character-level

convolutional neural network with embeddings for de-

tecting malicious urls, ﬁle paths and registry keys.

arXiv preprint arXiv:1702.08568.

Sonowal, G. and Kuppusamy, K. (2020). Phidma–a phish-

ing detection model with multi-ﬁlter approach. Jour-

nal of King Saud University-Computer and Informa-

tion Sciences, 32(1):99–112.

Tan, C. L., Chiew, K. L., Yong, K. S., Abdullah, J., Se-

bastian, Y., et al. (2020). A graph-theoretic approach

for the detection of phishing webpages. Computers &

Security, 95:101793.

Veli

ckovi

c, P., Cucurull, G., Casanova, A., Romero, A., Lio,

P., and Bengio, Y. (2017). Graph attention networks.

arXiv preprint arXiv:1710.10903.

Wang, G., Liu, H., Becerra, S., Wang, K., Belongie, S. J.,

Shacham, H., and Savage, S. (2011). Verilogo: Proac-

tive phishing detection via logo recognition.

Xu, K., Hu, W., Leskovec, J., and Jegelka, S. (2018). How

powerful are graph neural networks? arXiv preprint

arXiv:1810.00826.

PhishGNN: A Phishing Website Detection Framework using Graph Neural Networks

435
