Self-supervised Learning from Semantically Imprecise Data

Clemens-Alexander Brust

1 a

, Bj

orn Barz

2 b

and Joachim Denzler

1,2 c

DLR Institute of Data Science, Jena, Germany

Friedrich Schiller University Jena, Jena, Germany

Keywords:

Imprecise Data, Self-supervised Learning, Pseudo-labels.

Abstract:

Learning from imprecise labels such as “animal” or “bird”, but making precise predictions like “snow bunting”

at inference time is an important capability for any classiﬁer when expertly labeled training data is scarce.

Contributions by volunteers or results of web crawling lack precision in this manner, but are still valuable.

And crucially, these weakly labeled examples are available in larger quantities for lower cost than high-quality

bespoke training data. CHILLAX, a recently proposed method to tackle this task, leverages a hierarchical

classiﬁer to learn from imprecise labels. However, it has two major limitations. First, it does not learn from

examples labeled as the root of the hierarchy, e.g., “object”. Second, an extrapolation of annotations to precise

labels is only performed at test time, where conﬁdent extrapolations could be already used as training data.

In this work, we extend CHILLAX with a self-supervised scheme using constrained semantic extrapolation to

generate pseudo-labels. This addresses the second concern, which in turn solves the ﬁrst problem, enabling

an even weaker supervision requirement than CHILLAX. We evaluate our approach empirically, showing that

our method allows for a consistent accuracy improvement of 0.84 to 1.19 percent points over CHILLAX and

is suitable as a drop-in replacement without any negative consequences such as longer training times.

1 INTRODUCTION

High-quality training data labeled by domain experts

is an essential ingredient for a successful application

of contemporary deep learning methods. However,

such data is not always available or affordable in suf-

ﬁcient quantities. And while there exist a number

of effective strategies to maximize sample efﬁciency

such as data augmentation, transfer learning, or active

learning, there are also limits to the information that

can be extracted from a small dataset.

If larger quantities of training data are required, a

compromise w.r.t. the quality has to be made, i.e., by

allowing noisy labels. Such data is available at lower

cost and greater quantity, e.g., by employing volun-

teer labelers instead of experts or crawling the web

for training examples.

In this case, lower quality means that the labels are

noisy w.r.t. to two aspects: accuracy and precision. In-

accuracy means that labels are simply incorrect, i.e.,

confused with other classes. Imprecise labels are cor-

rect, but carry less semantic information in terms of

https://orcid.org/0000-0001-5419-1998

https://orcid.org/0000-0003-1019-9538

https://orcid.org/0000-0002-3193-3300

depth in a class hierarchy (see ﬁg. 1), e.g., “animal”

vs. “bird”. In (Brust et al., 2020), this weakly super-

vised task is formally deﬁned as “learning from im-

precise data”. It is deﬁned such that the training data

can contain imprecise labels, but predictions must al-

ways be as precise as possible, i.e., leaf nodes of the

hierarchy. At test time, labels are said to be extrap-

olated (from imprecise to precise) by their method

CHILLAX, which we brieﬂy explain in section 3.1.

While their method can perform the task reliably,

it has two main limitations. The disadvantages come

from the underlying probabilistic hierarchical classi-

ﬁer (Brust and Denzler, 2019). The classiﬁer is mod-

iﬁed to perform the extrapolation at test time and to

accept imprecise labels during training. However, it

cannot learn from examples that are labeled at root

of the hierarchy, e.g., as “object”, even though it is

clearly capable of the necessary extrapolation at test

time. And while it can learn from inner node exam-

ples, it does not take any advantage of training time

extrapolation for such examples either.

Our main contribution in this work is a self-

supervised approach to learning from imprecise data

based on pseudo-labels. To avoid learning mispredic-

tions and feedback loops, we describe several strate-

Brust, C., Barz, B. and Denzler, J.

Self-supervised Learning from Semantically Imprecise Data.

DOI: 10.5220/0010766700003124

In Proceedings of the 17th International Joint Conference on Computer Vision, Imaging and Computer Graphics Theory and Applications (VISIGRAPP 2022) - Volume 5: VISAPP, pages

27-35

ISBN: 978-989-758-555-5; ISSN: 2184-4321

gies constraining the extrapolation from imprecise la-

bels to more precise pseudo-labels. These strategies

are based on prediction conﬁdence scores and on the

structure of the hierarchy. We also propose methods

that are less sensitive to changes in conﬁdence score

distributions over time, which we call adaptive.

The experimental evaluation concerns two areas.

First, we assess the potential and limits of extrapo-

lation techniques by examining a best case scenario

free of feedback loops. We then evaluate the perfor-

mance of our methods against CHILLAX and observe

the effects of a large range of parameters. The results

show consistent improvements of 0.84 to 1.19 percent

points in accuracy. All experiments are performed on

the North American Birds dataset (Van Horn et al.,

2015) for direct comparison to (Brust et al., 2020).

2 RELATED WORK

The task of learning from semantically imprecise la-

bels is proposed in (Brust et al., 2020), where a class

hierarchy is used to formally deﬁne it. It is then tack-

led using a modiﬁed hierarchical classiﬁer (Brust and

Denzler, 2019). However, if an image is labeled at the

root of the hierarchy, this classiﬁer cannot leverage

it. Instead, the image is ignored entirely. This prop-

erty is a result of the closed world assumption, which

most hierarchical classiﬁers make (Silla and Freitas,

1 01). In this work, we resolve this deﬁciency by ex-

tending the method in (Brust et al., 2020) with a self-

supervision scheme.

Labels can be imprecise in other respects, e.g.,

missing labels in multi-label classiﬁcation (Abassi

and Boukhris, 2020), or a set of labels where only

one is expected (Ambroise et al., 2001). An impor-

tant problem of semantically imprecise labels is that

the classes are no longer mutually exclusive. The

associated consequences are discussed in detail in

(McAuley et al., 2013), altough this work does not

consider label extrapolation. Instead, it allows impre-

cise predictions. In (Deng et al., 2012), the authors

explicitly mention the trade-off between accuracy and

precision (speciﬁcity in their terms) and propose an

algorithm that can reduce the precision of predictions

such that a certain accuracy is guaranteed. This task

is the opposite of ours, where the precision of labels is

reduced, but the predictions are as precise as possible.

The term self-supervised learning has different

meanings depending on the speciﬁc ﬁeld. It is com-

monly used in unsupervised tasks such as visual rep-

resentation learning (Kolesnikov et al., 2019). In this

setting, the supervision that makes training a deep

neural network possible comes from solving auxil-

object

animal vehicle tool

cat dog catbus car bus wre nch

Figure 1: A class hierarchy with semantically imprecise

(dashed) and precise (bold) classes.

liary or “pretext” tasks like predicting the previously

applied rotation of an image. Real applications should

beneﬁt from the representations learned on the auxil-

liary tasks because unlabeled images are ubiquitous.

Another common interpretation of self-

supervision is also known as pseudo-labeling,

where conﬁdent predictions of a model are used as

training data (Lee, 2013; Sohn et al., 2020; Wang

et al., 2016). We use this deﬁnition in our work

and focus on interpreting the conﬁdence scores at

each level and node in the class hierarchy correctly

to maximize the reliability of our pseudo-labels.

Auxilliary tasks and pseudo-labeling approaches can

also be combined (Zhai et al., 2019).

3 SELF-SUPERVISED METHOD

In this section, we describe our proposed methods and

their theoretical background. We ﬁrst review the con-

cept of semantically imprecise data and the existing

method to learn from this data. Then, we introduce

our self-supervised approaches.

3.1 Semantically Imprecise Data

Given a class hierarchy, e.g., ﬁg. 1, we can distin-

guish between semantically precise and imprecise la-

bels. Precise labels are leaf nodes in the hierarchy,

while imprecise labels consist of inner nodes and the

root. A useful analogy is the number of digits of a

measurement. Like the depth in a class hierarchy, a

high number does not guarantee an accurate measure-

ment – only a precise one.

The term imprecise data is used as a shorthand to

describe training data that can contain examples with

semantically imprecise labels (Brust et al., 2020).

This relaxation does not apply to the predictions, i.e.,

we still expect them to be as precise as possible. If

the goal is to allow more training data to be used in or-

der to improve an existing application, the predictions

VISAPP 2022 - 17th International Conference on Computer Vision Theory and Applications

should remain unchanged. An extrapolation from im-

precise training data to precise output is taking place.

In (Brust et al., 2020), the CHILLAX method

based on (Brust and Denzler, 2019) is proposed. In-

stead of predicting probabilities for each class given

some input, a deep neural network predicts the prob-

ability of a class s being present (the event Y

), con-

ditioned on both the input image X and the presence

of any parent class (cf. (Brust and Denzler, 2019,

eq. (5))):

P(Y

|X) = P(Y

|X,Y

)

| {z }

DNN output

·P(Y

|X) (1)

This equation is evaluated recursively to obtain

the ﬁnal unconditional probabilities for all “allowed”

classes s, i.e., leaf nodes in the hierarchy. The ﬁnal

prediction is the leaf node with the highest probabil-

ity. Restricting the possible predictions is necessary,

as leaf nodes cannot have a higher probability than

associated inner nodes owing to the multiplication of

more factors that are ≤ 1. Crucially, the recursion

ends at the root where the probability is always one,

encoding the closed-world assumption. Hence, train-

ing examples that are only labeled at the root have no

effect on the classiﬁer in terms of loss and thus no

value.

3.2 Self-supervised Approach

We propose to make use of effectively unlabeled data

at the root of the class hierarchy, and increase the

value of other imprecise examples, by extrapolating

their labels to pseudo-labels during training. The

classiﬁer’s own predictions are used to generate the

pseudo-labels. Results in (Brust et al., 2020) show

that extrapolation at test time is reliable and we ex-

amine this in more detail in section 4.2.

However, not all predictions are correct, and using

incorrect labels for training can be worse than ignor-

ing the respective example altogether (although con-

trolled amounts of incorrect labels can also be beneﬁ-

cal, see (Xie et al., 2016)). But because we work in a

hierarchical setting, there is a middle ground between

ignoring and using predictions as ground truth. In-

stead of leaf nodes, labels can also be extrapolated to

internal nodes where there is less potential for confu-

sion. In the following, we propose several methods to

determine the appropriate level of extrapolation.

3.2.1 Non-adaptive Methods

While we require that predictions are precise, the

same is not true for training data, and crucially, also

not for pseudo-labels. We can potentially extrapo-

late an imprecise label (the source) to a slightly more

precise label (the target), while both are inner nodes

of the hierarchy. Our main selection criteria for ex-

trapolation targets are the unconditional probabilities

P(Y

|X), which we compute for all classes in the hi-

erarchy. Using predictions for all nodes is clearly not

necessary, if the label is sufﬁciently precise, because

that would ignore the label completely. Instead, we

replace all predicted probabilities with 1 or 0 where

appropriate, which also improves the predictions of

related nodes through the recursion. This process en-

sures that the extrapolation target never “disagrees”

with the source. Semantically, the source always sub-

sumes the target.

However, because these unconditional probabili-

ties are always higher for nodes closer to the root, we

cannot simply choose the most conﬁdent prediction.

Instead, we consider the following three approaches

that work by building a list of candidates (initially al-

ways all classes subsumed by the source class), then

excluding some, and ﬁnally sorting the remainder to

make a selection.

(a) Leaf Node Extrapolate any label to the most prob-

able leaf node. Effectively, all predictions are

used as training data without any further consid-

eration. This strategy has the highest potential for

improvement, but also for inaccuracy. There are

also no parameters to tune.

(b) k Steps Down Limit extrapolation to exactly k

steps “down” the hierarchy from the label, i.e.,

in the more precise direction. Leaf nodes that

are less than k steps down are also allowed be-

cause there might not be any possible extrapola-

tions otherwise. The label is selected based on

the highest predicted unconditional probability

. A threshold on the probabilities can be applied

optionally to further exclude unconﬁdent predic-

tions.

a predicted unconditional probability greater than

or equal to a given, ﬁxed threshold, e.g., 0.8. We

sort all candidates by this probability

. After-

wards, a stable sort of the candidate labels by in-

formation content (IC, a measure of semantic pre-

cision) is performed, such that the candidate with

the highest overall IC is ﬁrst. Thus, if two candi-

dates have the same IC, we select the candidate

Note that we add gaussian noise with σ = 0.0001 to the

probabilities before sorting to make it intentionally unsta-

ble. This is necessary because many predicted probabilities

are exactly 0.5 during initial training as a result of intially

zero weights and a sigmoid activation function. If the sort-

ing were stable, the resulting order would be biased by out-

side factors such as memory layout.

Self-supervised Learning from Semantically Imprecise Data

with higher predicted probability. We use the for-

mulation of IC given in (Harispe et al., 2015, 55,

eq. 3.8).

If no candidate remains in either (b) or (c), the

extrapolation source is used as the target. The ap-

proaches (a-c) are stateless and require no informa-

tion other than the extrapolation source, class hierar-

chy, and predicted probablities from the deep neural

network.

3.2.2 Adaptive Methods

A ﬁxed treshold as described in the previous section is

intuitive and easy to implement. However, it has ma-

jor disadvantages. First, it has to be ﬁne-tuned care-

fully. Second, a threshold that is optimal in one train-

ing step may not be optimal for the next because of

the continually increasing conﬁdence during training.

While methods (a) and (b) do not rely on a thresh-

old and thus don’t suffer from these two effects, those

methods are often outperformed by a ﬁxed threshold.

The experiments in section 4.3 show that constrain-

ing possible extrapolations is critical, and that a ﬁxed

structural criterion as in (b) is not always sufﬁcient.

Instead of relying on probabilities directly, we

propose considering the difference in IC of the label

before and after extrapolation, IC gain in short. IC is

a more meaningful measure than hierarchical distance

because it also takes global and local properties, e.g.,

fan-out, of the graph into account. However, we still

want to consider the predicted probabilities as an in-

dicator of conﬁdence in certain classes.

To achieve both goals at the same time, we pro-

pose two adaptive methods. They are adaptive in the

sense that the speciﬁc selection criteria vary based on

the source label:

(d) Adaptive Threshold We maintain a moving aver-

age of the last 64 IC gains

h and strive for a target

IC gain h

∗

. This average is used to calculate a

probability threshold θ for each time step t (repre-

senting weight updates or minibatches) by apply-

ing a simple update rule:

(t)

= θ

(t−1)

h − h

∗

. (2)

The threshold is bounded by [0.55,1.0] and ini-

tially set to the lower bound. We then apply the

sorting algorithm in (c) to perform the actual ex-

trapolation using the current value of θ.

(e) IC Range An interval of allowed IC differences

is deﬁned, e.g., [0.1,0.3], with the target IC gain

in the middle. We use the interval to preselect ex-

trapolation candidates. Depending on the extrapo-

lation source, the IC difference range allows vary-

ing hierarchical distances to the target, as opposed

to the ﬁxed criterion in (b). Thus, we still consider

this approach adaptive even though the parameters

stay constant throughout training. A ﬁnal selec-

tion on the preselected candidates is made using

rious predictions.

Both proposed methods make use of the predicted

probabilities through application of the algorithm in

(c), but rely mainly on its sorting and less on the

threshold. Furthermore, (d) is stateful because the

value of θ needs to be preserved across iterations,

which may be a disadvantage from an implementa-

tion perspective.

4 EXPERIMENTS

This section contains the experimental evaluation of

our methods. We start with a study that determines

an upper limit for any gains from self-supervision by

examining the pseudo-labels generated by our meth-

ods with hierarchical error measures. Then, we test

the efﬁcacy of our approaches in a benchmark set-

ting as well as their sensitivity to parameters. This

detailed evaluation is seperated into non-adaptive and

adaptive approaches as described in section 3.2.1 and

section 3.2.2, respectively.

4.1 Setup

We evaluate the effects of adding our proposed self-

supervised schemes to the CHILLAX method (Brust

et al., 2020). A conventional one-hot softmax classi-

ﬁer is added as a baseline for comparison. Our exper-

imental setup generally matches that of (Brust et al.,

2020), except for adjustments to the learning rate (η)

and the `

regularization coefﬁcient β. We use η =

0.0044,β = 5·10

−5

and η = 0.003, β = 1.58114·10

−5

for CHILLAX and the one-hot baseline, respectively.

We report results on the North American Birds

(NABirds) dataset (Van Horn et al., 2015) for com-

parison to the original CHILLAX method. This

ﬁne-grained classiﬁcation dataset consists of approx.

48500 images of 555 species of birds. Crucially, it

is also equipped with a class hierarchy. The training

portion of the NABirds dataset is modiﬁed in different

ways according to a selection of noise models from

(Brust et al., 2020):

(i) No noise (100% precise labels),

(ii) Relabeling to parent with p = 0.99 (Deng et al.,

2014) (1% precise labels),

(iii) Geometric distribution with q = 0.5 (9.6% precise

labels),

VISAPP 2022 - 17th International Conference on Computer Vision Theory and Applications

(iv) Poisson distribution with λ = 1 (4.8% precise la-

bels),

(v) Poisson distribution with λ = 2 (22.7% precise la-

bels).

These noise models cover a wide range of scenar-

ios from expertly labeled high-quality data (i) to web

crawling (iii) and volunteer labelers (iv,v). We also

include the protocol (ii) which is proposed in (Deng

et al., 2014). The models are distributions over depths

in the class hierarchy, which are realized by replac-

ing the original precise labels with parent classes to

match the distribution. Note that our experiments are

limited to label noise in terms of imprecision. Inaccu-

racy is beyond the scope of this work, but the extent

of CHILLAX’s relative robustness against inaccurate

labels is demonstrated in (Brust et al., 2020).

Source code will be made available publicly upon

formal publication.

4.2 Limits of Self-supervision

Self-supervised learning with pseudo-labels is subject

to a feedback loop when high-conﬁdence predictions

are used as training data. The scores, e.g.,:

(0.02,0.73, 0.11,. .. ),

are extrapolated to a maximally conﬁdent label:

(0.0,1.0, 0.0,. .. ),

in addition to a potential extrapolation from one class

to another. Subsequent predictions of the same image

are likely to be even more conﬁdent, thereby increas-

ing the chance of selecting the same target class for

training again. This feedback loop can lead to overﬁt-

ting, learning of potentially false pseudo-labels, and

overrepresentation of a subset of training data. While

not all methods proposed in this work are subject to

this effect, it is important to investigate the poten-

tial and limits of extrapolated pseudo-labels in a con-

trolled manner such that feedback effects do not inﬂu-

ence the evaluation.

To this end, we train one CHILLAX classiﬁer on a

noisy NABirds training set for each of the noise mod-

els (i)-(v). We then make predictions for the unseen

NABirds validation data, whose labels we also mod-

ify using (i)-(v) and use as extrapolation sources.

Table 1 shows the hierarchical F1 (hF1) score be-

tween the noise-free ground truth and the extrapolated

noisy label from our non-adaptive methods as well as

a “do nothing” baseline. In terms of hF1, all methods

outperform the baseline. This is not surprising in and

of itself. Since no method will select an extrapolation

target that disagrees with the imprecise source, it is

impossible for them to perform worse than the base-

line, at least in terms of hierarchical recall. Still, the

level of outperformance is substantial in all cases and

hierarchical precision could still decrease.

Observing noise model (ii), the theoretically

largest possible improvement over the baseline is

12.51 percent points (pp), if all labels are correctly ex-

trapolated to their precise origin. The actual improve-

ments realized by our approaches range from 3.32 pp

to 7.26 pp over the baseline. In contrast, we observe

the largest overall improvement of 28.08 pp over the

baseline out of a theoretically possible 40.21 pp in set-

ting (iii). This is the noisest model, i.e., the one with

the lowest expected depth in the class hierarchy.

In all cases, the best evaluated approaches can

ﬁll more than half of the performance gap from the

baseline to the precise labels in terms of hF1.

We can also evaluate the extrapolated labels in

terms of classiﬁcation accuracy, but this is only pos-

sible for the “leaf node” approach. The other ap-

proaches produce imprecise labels as output which

can only be compared to the precise validation set in

terms of hierarchical measures. The results are pre-

sented in table 2. We include a variation where even

the noisy label is withheld from the method, such that

all labels must be extrapolated from the root (effec-

tively unsupervised learning). Including the noisy la-

bel produces an improvement in accuracy of up to

13.9 pp and is always beneﬁcial.

Even in the worst case (iv), more than half of

the labels that are extrapolated as far as possible

are correct. This is a strong result considering the

555 classes and only 4.8% precise labels in the train-

ing set.

4.3 Non-adaptive Methods

The study in section 4.2 shows that most cases, except

possibly (ii), have a strong potential for improvement

by using extrapolated predictions as pseudo-labels.

However, a high hierarchical F1 score in one step does

not necessarily generalize to high accuracy when us-

ing self-supervision continuously during training. On

the one hand, the aforementioned feedback loop could

negatively affect training by overﬁtting and unbalanc-

ing the training data. On the other hand, the quality of

extrapolations might improve over time as the model

learns from correct pseudo-labels.

We ﬁrst apply the non-adaptive methods described

in section 3.2.1 to CHILLAX on NABirds. Ground

truth labels are replaced with pseudo-labels at all

times during training. The resulting model is then

evaluated in terms of accuracy on the NABirds val-

idation set. We repeat the experiment six times per

Self-supervised Learning from Semantically Imprecise Data

Table 1: Hierarchical F1 (%) on NABirds validation set. Comparison between ground truth and extrapolated noisy validation

labels after learning noisy training data. (i) is not included as all results are 100%.

Method / Noise (ii) (iii) (iv) (v)

Baseline (No Extrapolation) 87.49 59.79 61.73 78.06

1 Step Down 94.74 73.97 74.81 87.27

2 Steps Down 94.74 79.29 79.03 91.31

3 Steps Down 94.72 80.88 79.29 92.91

Fixed Threshold 0.55 90.99 82.87 81.37 93.66

Fixed Threshold 0.8 90.72 81.19 80.03 92.99

Leaf Node 94.75 81.15 79.12 93.20

Table 2: Accuracy (%) on NABirds validation set. Comparison between ground truth and extrapolated noisy validation labels

after learning noisy training data. (i) is not included as all results are 100%.

Method / Noise (ii) (iii) (iv) (v)

Leaf Node 76.99 58.52 51.03 83.81

Leaf Node From Root 63.09 49.55 43.36 70.99

individual setting and include a CHILLAX baseline

for comparison.

The results are shown in table 3, where we ﬁrst

observe the threshold-based extrapolation method. It

is very sensitive to the conﬁdence threshold and re-

quires substantial ﬁne-tuning. The optimal threshold

strongly depends on the noise model. For example,

the Poisson noise (iv) only has a working range of

thresholds from 0.97 to 0.998 where it matches or out-

performs the baseline, with the optimum at 0.99.

Overall, improvements w.r.t. the baseline range

from 0.84 pp to 1.05 pp.

The “leaf node” and “steps down” methods are

somewhat competitive, speciﬁcally for the geometric

noise model (iii). Going k steps down the hierarchy

is only beneﬁcial when combined with a conﬁdence

threshold. However, this combination suffers from the

aforementioned ﬁne-tuning problem.

Always selecting the most conﬁdent leaf node

leads to a small improvement in all cases and re-

quires no tuning.

4.4 Adaptive Self-supervision

This experiment compares our two proposed adap-

tive methods of limiting the increase in IC from ex-

trapolation source to target (see section 3.2.2 for de-

tails). The ﬁrst proposed adaptive method “adaptive

threshold” changes a conﬁdence threshold dynami-

cally to achieve a given expected IC gain. Our ex-

periment uses expected gains of 0.025,.. ., 0.1, where

our choice of IC is naturally bounded between 0

and 1. The second method “IC range” uses a ﬁxed

range of allowed IC differences. We use the ranges

[0,0.2], [0.1,0.3], .. ., [0.4,0.6] and a minimum conﬁ-

dence of 0.55 to reject spurious predictions. We per-

form six training repetitions for each combination of

method and noise model.

Table 4 compares the results of both methods. Our

adaptive threshold method performs better than the

ﬁxed range approach in the noisier settings (iii)-(v),

even outperforming the ﬁne-tuned non-adaptive ﬁxed

threshold method on setting (v) with in improvement

in accuracy of 1.19 pp.

Furthermore, the parameter of our adaptive

threshold method is much less sensitive to changes

than the ﬁxed threshold as evidenced by the large

effective range.

The ﬁxed IC gain range setup only works well for

noise model (ii), which is the immediate parent rela-

beling scenario from (Deng et al., 2014). This result

is expected, because this noise model leaves only two

possibilities for IC gain. There can either be no gain

at all, or the ﬁxed amount when moving from the sec-

ond to last level in the hierarchy to the last level. As

such, the model ﬁts the assumption of a ﬁxed IC gain

range perfectly. The other noise models lead to partly

catastrophic results when the ﬁxed range effectivly

prohibits any extrapolation. However, if the noise dis-

tribution is known before training, it could be argued

that setting a correct range is more straightforward.

Overall, we observe that a ﬁxed threshold per-

forms best, but only after signiﬁcant ﬁne-tuning. Our

“adaptive threshold” method is less sensitive to

changes in its parameters, and performs slightly

better than the parameter-free “leaf node” ap-

proach, which is why we recommend it as a drop-

in replacement for fully supervised CHILLAX.

VISAPP 2022 - 17th International Conference on Computer Vision Theory and Applications

Table 3: Accuracy (%) on NABirds validation set. Comparison between non-adaptive self-supervised methods on noisy

training data. Baseline (i) result 81.63 ± 0.12.

Method / Noise (ii) (iii) (iv) (v)

CHILLAX Baseline 62.66 ± 0.82 49.04 ± 1.04 43.18 ± 0.20 70.91 ± 0.34

Leaf Node 63.05 ± 1.37 49.36 ± 0.48 43.49 ± 0.20 70.94 ± 0.42

k Steps Down

1 61.78 ± 0.27 33.11 ± 0.87 23.49 ± 0.60 65.44 ± 0.83

1, conf. ≥ 0.8 61.75 ± 0.69 48.09 ± 0.75 40.85 ± 1.26 71.67 ± 0.23

1, conf. ≥ 0.9 63.13 ± 0.70 49.98 ± 0.55 41.54 ± 1.37 71.75 ± 0.26

2 61.31 ± 0.68 14.53 ± 0.82 12.12 ± 0.96 59.58 ± 0.60

2, conf. ≥ 0.8 62.07 ± 0.43 48.31 ± 0.84 37.21 ± 0.72 71.74 ± 0.81

2, conf. ≥ 0.9 62.52 ± 0.68 50.68 ± 0.44 41.78 ± 0.47 71.54 ± 0.33

Threshold

0.55 61.48 ± 0.36 26.56 ± 0.94 22.68 ± 0.29 65.32 ± 0.53

0.8 61.73 ± 0.54 39.80 ± 0.97 31.15 ± 1.65 69.86 ± 1.23

0.85 61.93 ± 0.25 43.35 ± 0.72 34.60 ± 0.73 70.59 ± 0.17

0.9 62.34 ± 0.33 46.74 ± 1.27 38.03 ± 0.78 71.77 ± 0.00

0.95 62.75 ± 0.21 48.66 ± 1.03 42.11 ± 1.48 71.47 ± 0.44

0.97 63.00 ± 0.58 50.09 ± 0.26 43.20 ± 0.57 71.40 ± 0.25

0.99 63.51 ± 0.52 49.37 ± 0.28 44.02 ± 0.12 71.14 ± 0.15

0.992 63.02 ± 0.57 48.88 ± 0.65 43.78 ± 0.33 71.21 ± 0.51

0.994 63.54 ± 0.51 49.23 ± 0.55 43.61 ± 0.94 70.99 ± 0.27

0.996 63.11 ± 0.60 49.37 ± 0.61 43.69 ± 1.00 71.08 ± 0.45

0.998 63.10 ± 0.83 49.16 ± 0.63 43.81 ± 0.25 70.96 ± 0.22

0.999 62.78 ± 0.48 49.56 ± 1.04 42.92 ± 0.68 71.37 ± 0.39

Table 4: Accuracy (%) on NABirds validation set. Comparison between adaptive self-supervised methods on noisy training

data. Baseline (i) result 81.63 ± 0.12. Best adaptive result, Best overall result.

Method / Noise (ii) (iii) (iv) (v)

CHILLAX Baseline 62.66 ± 0.82 49.04 ± 1.04 43.18 ± 0.20 70.91 ± 0.34

Best non-adaptive 63.54 ± 0.51 50.68 ± 0.44 44.02 ± 0.12 71.77 ± 0.00

Adaptive Threshold

0.025 61.80 ± 0.69 49.07 ± 0.93 43.35 ± 0.82 71.58 ± 0.40

0.0375 61.43 ± 0.51 49.75 ± 1.13 43.11 ± 1.49 72.00 ± 0.43

0.05 61.80 ± 0.44 49.52 ± 0.90 42.92 ± 0.42 72.10 ± 0.31

0.0625 61.87 ± 0.91 49.57 ± 1.55 42.30 ± 0.35 71.15 ± 0.92

0.075 62.20 ± 0.76 49.97 ± 0.59 41.71 ± 1.13 71.37 ± 0.40

0.1 61.79 ± 0.30 48.57 ± 0.61 39.72 ± 0.96 70.77 ± 0.34

Fixed Range

[0,0.2] 62.11 ± 0.44 46.42 ± 0.71 40.50 ± 0.50 68.39 ± 0.47

[0.1,0.3] 61.78 ± 0.42 29.77 ± 0.98 26.07 ± 0.67 64.31 ± 1.05

[0.2,0.4] 63.43 ± 0.42 36.00 ± 1.29 30.64 ± 0.86 68.61 ± 0.22

[0.3,0.5] 63.23 ± 0.10 35.00 ± 0.46 31.45 ± 0.60 68.55 ± 0.94

[0.4,0.6] 62.96 ± 0.98 33.24 ± 0.65 27.31 ± 1.41 68.46 ± 0.33

5 CONCLUSION

Learning from imprecise data is proposed in (Brust

et al., 2020) as a way of maximizing training data

utilization. However, their method CHILLAX does

not utilize all training data as it ignores examples la-

beled at the root. This is a consequence of the closed-

world assumption made by the underlying classiﬁer.

To avoid such meaningless labels, we propose to use

CHILLAX’s label extrapolation not just at test time,

Self-supervised Learning from Semantically Imprecise Data

but during training to generate pseudo-labels. This in-

creases the precision of examples labeled not only at

the root, but also at inner nodes of the class hierarchy.

To implement this self-supervised learning

scheme, we describe several possible strategies of

deciding which candidate pseudo-labels are reli-

able enough for training. These strategies employ

heuristic, structural and statistical criteria. Our

experiments show that an increase in accuracy of

around one percent point can be expected by simply

using one of our self-supervised strategies on top of

CHILLAX. This improvement comes without any

requirement of ﬁne-tuning unrelated parameters or

undue computational efforts.

Future Work. In the future, these methods could

also be applied to semi-supervised learning tasks in

general, e.g.,, by assigning a root label to the unla-

beled images as long as a closed-world scenario can

be assumed. Furthermore, the individual heuristics

could be combined into a meta-heuristic. In contrast,

relaxing the closed-world assumption is another im-

portant research direction. Asking a hierarchical clas-

siﬁer for its conﬁdence in the root node is a ﬁrst step

towards open-set models from a semantic perspective,

as long as the predicted conﬁdence has a reasonable

basis. A ﬁxed hierarchy is a further limiting assump-

tion, which could be relaxed, e.g.,, in a lifelong learn-

ing setting.

The research on semantically imprecise data in

general could be expanded to domains beyond nat-

ural images. For example, we expect source code

to have a stronger feature-semantic correspondence,

which is crucial for the hierarchical classiﬁer. In par-

ticular, human-made hierarchies such as the Common

Weakness Enumeration (CWE, (The MITRE Corpo-

ration, 2021)) explicitly consider certain features of

program code to determine categories. And even in

the visual domain, there are efforts to construct more

visual-feature-oriented hierarchies, e.g.,, accompany-

ing WikiChurches (Barz and Denzler, 2021).

ACKNOWLEDGMENTS

The computational experiments were performed on

resources of Friedrich Schiller University Jena sup-

ported in part by DFG grants INST 275/334-1 FUGG

and INST 275/363-1 FUGG.

REFERENCES

Abassi, L. and Boukhris, I. (2020). Imprecise label ag-

gregation approach under the belief function theory.

In Abraham, A., Cherukuri, A. K., Melin, P., and

Gandhi, N., editors, Intelligent Systems Design and

Applications, pages 607–616. Springer International

Publishing.

Ambroise, C., Denœux, T., and Govaert, G. (2001). Learn-

ing from an imprecise teacher: probabilistic and ev-

idential approaches. Applied Stochastic Models and

Data Analysis, page 6.

Barz, B. and Denzler, J. (2021). Wikichurches: A ﬁne-

grained dataset of architectural styles with real-world

challenges. In Neural Information Processing Systems

(NeurIPS).

Brust, C.-A., Barz, B., and Denzler, J. (2020). Making ev-

ery label count: Handling semantic imprecision by in-

tegrating domain knowledge. In International Confer-

ence on Pattern Recognition (ICPR).

Brust, C.-A. and Denzler, J. (2019). Integrating domain

knowledge: using hierarchies to improve deep clas-

siﬁers. In Asian Conference on Pattern Recognition

(ACPR).

Deng, J., Ding, N., Jia, Y., Frome, A., Murphy, K., Bengio,

S., Li, Y., Neven, H., and Adam, H. (2014). Large-

scale object classiﬁcation using label relation graphs.

In European Conference on Computer Vision (ECCV).

Deng, J., Krause, J., Berg, A. C., and Fei-Fei, L. (2012).

Hedging your bets: Optimizing accuracy-speciﬁcity

trade-offs in large scale visual recognition. In Com-

puter Vision and Pattern Recognition (CVPR).

Harispe, S., Ranwez, S., Janaqi, S., and Montmain, J.

(2015). Semantic similarity from natural language and

ontology analysis. Synthesis Lectures on Human Lan-

guage Technologies, 8(1):1–254.

Kolesnikov, A., Zhai, X., and Beyer, L. (2019). Revisiting

self-supervised visual representation learning. In Pro-

ceedings of the IEEE/CVF Conference on Computer

Vision and Pattern Recognition (CVPR).

Lee, D.-H. (2013). Pseudo-label : The simple and efﬁ-

cient semi-supervised learning method for deep neu-

ral networks. In International Conference on Machine

Learning Workshops (ICML-WS), page 6.

McAuley, J. J., Ramisa, A., and Caetano, T. S. (2013). Op-

timization of robust loss functions for weakly-labeled

image taxonomies. International Journal of Computer

Vision (IJCV), 104(3):343–361.

Silla, C. N. and Freitas, A. A. (2011-01). A survey of

hierarchical classiﬁcation across different application

domains. Data Mining and Knowledge Discovery,

22(1):31–72.

Sohn, K., Berthelot, D., Li, C.-L., Zhang, Z., Carlini, N.,

Cubuk, E. D., Kurakin, A., Zhang, H., and Raffel,

C. (2020). FixMatch: Simplifying semi-supervised

learning with consistency and conﬁdence.

The MITRE Corporation (2021). Common Weakness Enu-

meration (CWE).

Van Horn, G., Branson, S., Farrell, R., Haber, S., Barry,

J., Ipeirotis, P., Perona, P., and Belongie, S. (2015).

VISAPP 2022 - 17th International Conference on Computer Vision Theory and Applications

Building a bird recognition app and large scale dataset

with citizen scientists: The ﬁne print in ﬁne-grained

dataset collection. In Proceedings of the IEEE Con-

ference on Computer Vision and Pattern Recognition,

pages 595–604.

Wang, K., Zhang, D., Li, Y., Zhang, R., and Lin, L. (2016).

Cost-effective active learning for deep image classi-

ﬁcation. Circuits and Systems for Video Technology

(CSVT), PP(99):1–1.

Xie, L., Wang, J., Wei, Z., Wang, M., and Tian, Q. (2016).

Disturblabel: Regularizing cnn on the loss layer. In

Computer Vision and Pattern Recognition (CVPR).

Zhai, X., Oliver, A., Kolesnikov, A., and Beyer, L. (2019).

S4l: Self-supervised semi-supervised learning. In

Proceedings of the IEEE/CVF International Confer-

ence on Computer Vision (ICCV).

Self-supervised Learning from Semantically Imprecise Data
