Colour Augmentation for Improved Semi-supervised Semantic

Segmentation

Geoff French

and Michal Mackiewicz

School of Computing Sciences, University of East Anglia, Norwich, U.K.

Keywords:

Deep Learning, Semantic Segmentation, Semi-supervised Learning, Data Augmentation.

Abstract:

Consistency regularization describes a class of approaches that have yielded state-of-the-art results for semi-

supervised classiﬁcation. While semi-supervised semantic segmentation proved to be more challenging, re-

cent work has explored the challenges involved in using consistency regularization for segmentation prob-

lems and has presented solutions. In their self-supervised work Chen et al. found that colour augmenta-

tion prevents a classiﬁcation network from using image colour statistics as a short-cut for self-supervised

learning via instance discrimination. Drawing inspiration from this we ﬁnd that a similar problem im-

pedes semi-supervised semantic segmentation and offer colour augmentation as a solution, improving semi-

supervised semantic segmentation performance on challenging photographic imagery. Implementation at:

https://github.com/Britefury/cutmix-semisup-seg.

1 INTRODUCTION

State-of-the-art computer vision results ob-

tained using deep neural networks over the last

decade (Krizhevsky et al., 2012; He et al., 2016)

rely on the availability of large training sets con-

sisting of images and corresponding annotations.

Semi-supervised learning offers the possibility of

alleviating the annotation bottleneck that arises from

the manual effort involved in annotation by learning

from un-annotated – or unsupervised – samples in

addition to annotated samples.

Semantic segmentation is the task of classifying

each pixel in an image, often with a view to identify-

ing the type of object under it. While efﬁcient anno-

tation tools (Maninis et al., 2018) can help, producing

pixel-wise ground truth annotation is labour intensive,

making the annotation bottleneck a particularly press-

ing issue for segmentation problems.

The term consistency regularization (Oliver et al.,

2018) refers to a class of approaches that have yielded

state-of-the-art results for semi-supervised classiﬁca-

tion (Laine and Aila, 2017; Tarvainen and Valpola,

2017; Xie et al., 2019; Sohn et al., 2020) over the

last few years. (French et al., 2020) ﬁnd that plain

geometric augmentation schemes used in prior semi-

https://orcid.org/0000-0003-2868-2237

https://orcid.org/0000-0002-8777-8880

supervised classiﬁcation approaches frequently fail

when applied to segmenting photographic imagery.

They offer the challenging data distribution of seman-

tic segmentation problems as an explanation and de-

velop a successful approach based on Cutmix (Yun

et al., 2019).

Recent work in self-supervised learning via in-

stance discrimination trains a network for feature ex-

traction without using ground truth labels. As with

consistency regularization the network is encouraged

to yield similar predictions – albeit image embeddings

instead of probability vectors – given stochastically

augmented variants of an unlabelled image. (Chen

et al., 2020a) conducted a rigorous ablation study,

ﬁnding that colour augmentation is essential to good

performance. Without it, the network in effect cheats

by using colour statistics as a short-cut for the image

instance discrimination task used to train the network.

Inspired by this, we ﬁnd that a similar problem can

hinder semi-supervised semantic segmentation. Our

experiments demonstrate the problem by showing that

it is alleviated by the use of colour augmentation.

Other recent approaches – namely Classmix (Ols-

son et al., 2021), DMT (Feng et al., 2021) and

ReCo (Liu et al., 2021) – have signiﬁcantly improved

on the Cutmix based results of (French et al., 2020).

Our work builds on the Cutmix approach, demonstrat-

ing the effectiveness of colour augmentation. It is not

356

French, G. and Mackiewicz, M.

Colour Augmentation for Improved Semi-supervised Semantic Segmentation.

DOI: 10.5220/0010807400003124

In Proceedings of the 17th International Joint Conference on Computer Vision, Imaging and Computer Graphics Theory and Applications (VISIGRAPP 2022) - Volume 4: VISAPP, pages

356-363

ISBN: 978-989-758-555-5; ISSN: 2184-4321

our intent to present results competitive with Class-

mix and DMT, thus we acknowledge that our results

are not state of the art.

2 BACKGROUND

2.1 Semi-supervised Classiﬁcation

The key idea behind consistency regularization based

semi-supervised classiﬁcation is clearly illustrated in

the π-model of (Laine and Aila, 2017), in which a

network is trained by minimizing both supervised

and unsupervised loss terms. The supervised loss

term applies traditional cross-entropy loss to super-

vised samples with ground truth annotations. Unsu-

pervised samples are stochastically augmented twice

and the unsupervised loss term encourages the net-

work to predict consistent labels under augmentation.

The Mean Teacher model of (Tarvainen and

Valpola, 2017) uses two networks; a teacher and a

student. The weights of the teacher are an exponen-

tial moving average (EMA) of those of the student.

The student is trained using gradient descent as nor-

mal. The teacher network is used to generate pseudo-

targets for unsupervised samples that the student is

trained to match under stochastic augmentation.

The UDA approach of (Xie et al., 2019) adopted

RandAugment (Cubuk et al., 2020); a rich image aug-

mentation scheme that chooses 2 or 3 image opera-

tions to apply from a menu of 14. We note an impor-

tant similarity with Mean Teacher; just as the teacher

network is used to predict a pseudo target, UDA pre-

dicts a pseudo-target for an un-augmented image that

is used as a training target for the same iamge with

RandAugment applied.

The FixMatch approach of (Sohn et al., 2020) re-

ﬁnes this approach further. They separate their aug-

mentation scheme into weak – consisting of simple

translations and horizontal ﬂips – and strong that

uses RandAugment. They predict hard pseudo-labels

for weakly augmented unsupervised samples that are

used as training targets for strongly augmented vari-

ants of the same samples.

2.2 Semi-supervised Semantic

Segmentation

(Hung et al., 2018) and (Mittal et al., 2019) adopt

GAN-based adversarial learning, using a discrimina-

tor network that distinguishes real from predicted seg-

mentation maps to guide learning.

(Perone and Cohen-Adad, 2018) and (Li et al.,

2018) are two early applications of consistency regu-

larisation to semantic segmentation. Both come from

the medical imaging community, tackling MRI vol-

ume segmentation and skin lesion segmentation re-

spectively. Both approaches use standard augmenta-

tion to provide perturbation, as in the π-model (Laine

and Aila, 2017) and Mean Teacher (Tarvainen and

Valpola, 2017). (Ji et al., 2019) developed a semi-

supervised over-clustering approach that can be ap-

plied to natural photographic images, where the list

of ground truth classes is highly constrained.

(French et al., 2020) analysed the problem of se-

mantic segmentation, ﬁnding that it has a challenging

data distribution to which the cluster assumption does

not apply. They offer this as an explanation as to why

consistency regularization had not been successfully

applied to semantic segmentation of photographic im-

ages. They present an approach that drives the Mean

Teacher (Tarvainen and Valpola, 2017) algorithm us-

ing an augmentation scheme based on Cutmix (Yun

et al., 2019), achieving state of the art results.

2.3 Self-supervised and Unsupervised

Learning

Approaches based on contrastive learning (Henaff,

2020; He et al., 2020; Chen et al., 2020b; Chen et al.,

2020a) train a residual network (He et al., 2016) us-

ing only unlabelled input images. Afterwards the net-

work backbone (consisting of convolutional layers)

is frozen and a linear classiﬁer is trained in a super-

vised fashion using it’s feature representations as in-

puts and ground truth labels as targets. The result-

ing image classiﬁers – in which only the last linear

layer is trained using ground truth labels – are able

to achieve ImageNet results that are competitive with

those obtained by traditional supervised learning in

which the whole network is trained.

In contrast to prior work (Henaff, 2020) the MoCo

model (He et al., 2020) simpliﬁed contrastive learn-

ing using standard augmentation to generate stochas-

tically augmented variants of unlabelled images. The

network is encouraged to predict embeddings that are

more similar for augmented variants of the same input

image than for different images. The augmentation

scheme used is very similar to the standard scheme

used to train residual networks (He et al., 2016) and

by Mean Teacher (Tarvainen and Valpola, 2017) for

their ImageNet results. (Chen et al., 2020a) con-

ducted a rigorous ablation study of the augmentations

used for contrastive learning, assessing the effective-

ness of each augmentation operation. They found

that colour augmentation is essential for good perfor-

Colour Augmentation for Improved Semi-supervised Semantic Segmentation

357

mance, as without it the network is able cheat by us-

ing image colour statistics as a short-cut to discrimi-

nate between images, rather than having to focus on

image content. Strong colour augmentation masks

this signal, forcing the network to focus on the image

content, extracting features suitable for accurate im-

age classiﬁcation and other downstream tasks. Colour

augmentation is also used in the MoCo model (He

et al., 2020).

We note the similarities between recent con-

trastive learning approaches and Information Invari-

ant Clustering of (Ji et al., 2019), who also encourages

consistency under stochastic augmentation.

The recent work of (Liu et al., 2021) adapt con-

trastive learning – typically used for classiﬁcation –

for semantic segmentation, achieving impressive re-

sults with very few labelled images.

3 APPROACH

We will start by providing a brief overview of semi-

supervised classiﬁcation and the segmentation, fol-

lowed by our choice of approach and a description

of our addition of colour augmentation.

3.1 Semi-supervised Classiﬁcation

During training we minimize a loss term L that com-

bines standard supervised cross entropy loss L

sup

with

an unsupervised consistency loss term L

cons

that en-

courages consistent predictions under augmentation.

cons

is modulated by an unsupervised loss weight

hyper-parameter γ, so:

L = L

sup

+ γL

cons

(1)

In a classiﬁcation scenario L

cons

measures the

squared difference between probability predictions

generated by a neural network f

given stochastically

augmented variants ˆx and ˜x of a sample x:

cons



( ˆx) − f

( ˜x)



(2)

The Mean Teacher approach deﬁnes L

cons

as the

difference between predictions arising from two net-

works; the student f

trained using gradient descent

as normal and a teacher network g

whose weights

are an exponential moving average of those of the

student. After each gradient descent update of the

student, the weights of the teacher are updated: φ =

βφ +(1 −β)θ where β is the EMA momentum hyper-

parameter. L

cons

is therefore:

cons



( ˆx) − g

( ˜x)



(3)

3.2 Semi-supervised Segmentation

Applying standard geometric augmentation –

e.g. afﬁne transformation – in a segmentation

scenario is a little more involved than it is for

classiﬁcation. For classiﬁcation one needs to ensure

only that the augmentation or transformation is class

preserving, e.g. it does not alter the classiﬁcation of

the image.

A geometric transformation t

may alter the shape

and position of elements in an image. Given that the

goal of semantic segmentation is to classify the con-

tent under each pixel in an image x resulting in the

segmentation map y, applying a geometric transfor-

mation t

to the image such that ˆx = t

(x) will result in

a similarly transformed segmentation map ˆy = t

(y).

This equivariance must be observed during train-

ing when computing both supervised an unsupervised

loss terms. For our supervised loss term this means

computing the loss given the networks’ predictions

(x)) given the augmented input image t

(x) and

the augmented ground truth t

(y). Following (Perone

and Cohen-Adad, 2018) this can be adapted for the

unsupervised loss term in a semi-supervised scenario

by applying the geometric transformation t

to the in-

put image prior to passing it to the student network

and to the predicted segmentation from the teacher

network (also illustrated in Figure 1):

cons



(x)) − t

(x))



(4)

3.3 Colour Augmentation for

Segmentation

In their semi-supervised semantic segmentation ap-

proach (French et al., 2020) offer the challenging

data distribution present in semantic segmentation

problems as an explanation as to why consistency

regularization driven by standard augmentation had

yielded few prior successes when applied to photo-

graphic image datasets such as PASCAL VOC (Ev-

eringham et al., 2012). In view of the strong simi-

larity between semi-supervised consistency loss and

the self-supervised loss used in SimCLR (Chen et al.,

2020a) – both encourage consistent predictions under

stochastic augmentation – the ablation study in Sim-

CLR (Chen et al., 2020a) inspires us to offer colour

statistics as an alternative explanation.

The consistency loss term in equation 4 offers the

opportunity for the network to minimize L

cons

using

colour statistics. The application of the transforma-

tion t

in both the student and teacher sides will result

VISAPP 2022 - 17th International Conference on Computer Vision Theory and Applications

358

𝑥

Teacher 𝑔

Student 𝑓

𝐿

#$%&

𝑔

𝑥

Augment 𝑡

𝑡

𝑥

𝑓

𝑡

𝑥

Augment 𝑡

𝑡

𝑔

𝑥

Figure 1: Illustration of Mean Teacher unsupervised consistency loss driven by standard augmentation for semantic seg-

mentation problems. The path for a pixel on the neck of the cat leading from the input image x is traced by yellows to the

consistency loss map L

cons

(illustrated prior to computing the mean of the square), with the location of the pixel in each image

identiﬁed by coloured crosses.

in L

cons

penalising the network for giving inconsistent

class predictions for each individual pixel in the input

image x under geometric augmentation. This is fur-

ther illustrated in Figure 1, in which the yellow arrows

follow a single pixel from the input image x through

both the student and teacher sides of the consistency

loss term. A simple way to minimize L

cons

is to pre-

dict the class of a pixel in the output segmentation

maps using only the corresponding pixel in the input

image, ignoring surrounding context. Thus, we hy-

pothesize that the network effectively learns to cluster

the colour of individual input pixels, rather than using

surrounding context to identify the type of object that

the pixel lies within.

To test our hypothesis we choose a semi-

supervised segmentation approach whose unsuper-

vised component is as similar as possible to the self-

supervised methods that have successfully employed

colour augmentation in prior work. The consistency

loss term used in the Mean Teacher (Tarvainen and

Valpola, 2017) semi-supervised method is very simi-

lar to the self-supervised loss used in the MoCo (He

et al., 2020; Chen et al., 2020b) method; both are

driven by samples that are stochastically augmented

twice and both use two networks, one whose weights

are an EMA of those of the other. We therefore base

our work on the approach and codebase of the semi-

supervised segmentation work of (French et al., 2020)

as it is employs Mean Teacher. It also provides a va-

riety of semi-supervised regularizers: standard aug-

mentation; ICT (Verma et al., 2019); VAT (Miyato

et al., 2017); Cutout and Cutmix that we use to assess

the effectiveness of colour augmentation in combina-

tion with other approaches.

Following (Sohn et al., 2020) we consider colour

augmentation to be a form of strong augmentation,

that is not used when generating pseudo-targets for

unsupervised samples during training. As in (French

et al., 2020) we only apply strong augmentation to the

input images passed to the student network; we do not

apply it to images passed to the teacher.

We acknowledge that (Ji et al., 2019) applied

colour augmentation in an unsupervised semantic

segmentation setting. While their codebase uses a

similar approach as (He et al., 2020) and (Chen et al.,

2020a) they describe it simply as ‘photometric aug-

mentation’ in their paper, giving little hint that it is in

fact key to the success of consistency regularization

based techniques in this problem domain, as we will

show in Section 4.3.

4 EXPERIMENTS

Our experiments follow the same procedure as

(French et al., 2020), using the same network archi-

tectures. We used the same hyper-parameters, with

the exception of the consistency loss weight that we

will discuss in Section 4.3.1.

4.1 Implementation

Our implementation extends that of (French et al.,

2020), allowing colour augmentation to be combined

with standard augmentation, ICT, VAT, Cutout and

Cutmix based regularizers (please see their paper for

full descriptions of their implementation in a seg-

mentation setting). This allows us to assess its ef-

Colour Augmentation for Improved Semi-supervised Semantic Segmentation

359

Table 1: Performance (mIoU) on CITYSCAPES validation set, presented as mean ± std-dev computed from 5 runs. Other

work: the results for ’Adversarial’ (Hung et al., 2018) and ’s4GAN’ (Mittal et al., 2019) are taken from (Mittal et al., 2019).

The results for DMT (Feng et al., 2021) and Classmix (Olsson et al., 2021) are from their respective works. Bold results in

blue colour indicate results from other works that beat our best results. Our best results are in bold. The baseline results use

plain supervised learning using only samples from the labelled subset.

Fraction labelled ∼1/30 1/8 1/4 All

(# labelled) (100) (372) (744) (2975)

Results from other recent work, ImageNet pre-trained DeepLab v2 network

Baseline — 56.2% 60.2% 66.0%

Adversarial — 57.1% 60.5% 66.2%

s4GAN — 59.3% 61.9% 65.8%

DMT 54.80% 63.06% — 68.16%

Classmix 54.07% 61.35% 63.63% —

Results from (French et al., 2020) and our results, ImageNet pre-trained DeepLab v2 network

Baseline 44.41% ± 1.11 55.25% ± 0.66 60.57% ± 1.13 67.53%± 0.35

Cutout 47.21% ± 1.74 57.72% ± 0.83 61.96% ± 0.99 67.47% ± 0.68

+ colour aug. (ours) 48.28% ± 1.98 58.30% ± 0.73 62.59% ± 0.60 67.93% ± 0.36

CutMix 51.20% ± 2.29 60.34% ± 1.24 63.87% ± 0.71 67.68% ± 0.37

+ colour aug. (ours) 51.98% ± 2.77 61.08% ± 0.71 64.61% ± 0.57 68.11% ± 0.55

fect on a variety of regularizers across three datasets;

CITYSCAPES, PASCAL VOC 2012 and the ISIC Skin

Lesion segmentation dataset (Codella et al., 2018).

We apply colour augmentation to unsupervised

images as part of the strong augmentation scheme

used on images sent to the student network (see Sec-

tion 3.3). This is performed prior to any adversarial

(VAT) or mix-based (ICT or CutMix) unsupervised

regularizer. Our colour augmentation scheme con-

sists of randomly adjusting the brightness, contrast,

saturation and hue of an image with 80% probability

(we use ColorJitter from the torchvision (Chin-

tala et al., 2017) package), followed by converting to

grayscale with 20% probability.

4.2 Cityscapes

CITYSCAPES is a photograpic image dataset of urban

scenery captured from the perspective of a car. Its’

training set consists of 2975 images.

Our CITYSCAPES results are presented in Ta-

ble 1 as mean intersection-over-union (mIoU) per-

centages, where higher is better. The addition of

colour augmentation results in a slight improvement

to the CutOut and CutMix results across the board.

4.3 Augmented Pascal VOC 2012

PASCAL VOC (Everingham et al., 2012) is a pho-

tographic image dataset consisting of various indoor

and outdoor scenes. It consists of only 1464 training

images, and thus we follow the lead of (Hung et al.,

2018) and augment it using SEMANTIC BOUND-

ARIES(Hariharan et al., 2011), resulting in 10582

training images.

Our PASCAL VOC 2012 experiments evalu-

ate regularizers based on standard augmentation,

ICT (Verma et al., 2019) and VAT (Miyato et al.,

2017), Cutout and Cutmix as in (French et al., 2020).

Our results are presented in Table 2.

4.3.1 Consistency Loss Weight

We note that the effects of colour augmentation re-

sulted in different optimal values for γ (consistency

loss weight) than were used by (French et al., 2020).

When using standard geometric augmentation they

found that a value of 0.003 was optimal, yielding a

very slight improvement over the supervised baseline.

Increasing γ caused performance to drop below that

of the supervised baseline. We note that at 0.003, the

consistency loss term would have little effect on train-

ing at all. When using colour augmentation, we were

able to use a value of 1 for γ; the same as that used for

the more successful Cutout and CutMix regularizers.

This strongly suggests that without colour augmenta-

tion, a low value must be used for γ to suppress the

effect of the pixel colour clustering short-cut hypoth-

esized in Section 3.3.

We were also able to use a value of 1 – instead of

0.01 – for the ICT (Verma et al., 2019) based regu-

larizer when using colour augmentation. For VAT we

continue to use a weight of 0.1; we attribute this lower

loss weight to the use of KL-divergence in VAT rather

than mean squared error for the consistency loss.

Being able to use a single value for the consistency

loss weight for all regularizers simpliﬁes the use of

our approach in practical applications.

VISAPP 2022 - 17th International Conference on Computer Vision Theory and Applications

360

Table 2: Performance (mIoU) on augmented PASCAL VOC validation set, using same splits as (Mittal et al., 2019). Other

work: the results for ’Adversarial’ (Hung et al., 2018) and ’s4GAN’ (Mittal et al., 2019) are taken from (Mittal et al., 2019).

The results for DMT (Feng et al., 2021) and Classmix (Olsson et al., 2021) are from their respective works. Bold results in

blue colour indicate results from other works that beat our best results. Our best results are in bold. The baseline results use

plain supervised learning using only samples from the labelled subset.

Fraction labelled 1/100 1/50 1/20 1/8 All

(# labelled) (106) (212) (529) (1323) (10582)

Results from other work with ImageNet pretrained DeepLab v2

Baseline – 48.3% 56.8% 62.0% 70.7%

Adversarial – 49.2% 59.1% 64.3% 71.4%

s4GAN+MLMT – 60.4% 62.9% 67.3% 73.2%

DMT 63.04% 67.15% 69.92% 72.70% 74.75%

Classmix 54.18% 66.15% 67.77% 72.00% —

Results from (French et al., 2020) + ours, ImageNet pre-trained DeepLab v2 network

Baseline 33.09% 43.15% 52.05% 60.56% 72.59%

Std. aug. 32.40% 42.81% 53.37% 60.66% 72.24%

+ colour aug. (ours) 46.42% 49.97% 57.17% 65.88% 73.21%

VAT 38.81% 48.55% 58.50% 62.93% 72.18%

+ colour aug. (ours) 40.05% 49.52% 57.60% 63.05% 72.29%

ICT 35.82% 46.28% 53.17% 59.63% 71.50%

+ colour aug. (ours) 49.14% 57.52% 64.06% 66.68% 72.91%

Cutout 48.73% 58.26% 64.37% 66.79% 72.03%

+ colour aug. (ours) 52.43% 60.15% 65.78% 67.71% 73.20%

CutMix 53.79% 64.81% 66.48% 67.60% 72.54%

+ colour aug. (ours) 53.19% 65.19% 67.65% 69.08% 73.29%

(French et al., 2020) + ours, ImageNet pre-trained DeepLab v3+ network

Baseline 37.95% 48.35% 59.19% 66.58% 76.70%

CutMix 59.52% 67.05% 69.57% 72.45% 76.73%

+ colour aug. (ours) 60.02% 66.84% 71.62% 72.96% 77.67%

(French et al., 2020) + ours, ImageNet pre-trained DenseNet-161 based Dense U-net

Baseline 29.22% 39.92% 50.31% 60.65% 72.30%

CutMix 54.19% 63.81% 66.57% 66.78% 72.02%

+ colour aug. (ours) 53.04% 62.67% 63.91% 67.63% 74.16%

(French et al., 2020) + ours, ImageNet pre-trained ResNet-101 based PSPNet

Baseline 36.69% 46.96% 59.02% 66.67% 77.59%

CutMix 67.20% 68.80% 73.33% 74.11% 77.42%

+ colour aug. (ours) 66.83% 72.30% 74.64% 75.40% 78.67%

Table 3: Performance on ISIC 2017 skin lesion segmentation validation set, measured using the Jaccard index (IoU for lesion

class). Presented as mean ± std-dev computed from 5 runs. All baseline and semi-supervised results use 50 supervised

samples. The fully supervised result (’Fully sup.’) uses all 2000.

Baseline Std. aug. VAT ICT Cutout CutMix Fully sup.

(50) (2000)

Results from (Li et al., 2018) with ImageNet pre-trained DenseUNet-161

72.85% 75.31% – – – – 79.60%

Our results: Same ImageNet pre-trained DenseUNet-161

67.64% 71.40% 69.09% 65.45% 68.76% 74.57% 78.61%

± 1.83 ± 2.34 ± 1.38 ± 3.50 ± 4.30 ± 1.03 ± 0.36

+ colour augmentation

73.61% 61.94% 50.93% 73.70% 74.51%

± 2.40 ± 6.72 ± 7.16 ± 2.59 ± 1.95

Colour Augmentation for Improved Semi-supervised Semantic Segmentation

361

4.4 ISIC 2017 Skin Lesion

Segmentation

The ISIC skin lesion segmentation dataset (Codella

et al., 2018) consists of dermoscopy images focused

on lesions set against skin. It has 2000 images in its

training set and is a two-class (skin and lesion) seg-

mentation problem, featuring far less variation than

CITYSCAPES and PASCAL. Our results are presented

in Table 3.

While colour augmentation improved the perfor-

mance of all regularizers on the PASCAL dataset when

using the DeepLab v2 architecture, the results for

ISIC 2017 are less clear cut. It harms the performance

of VAT and ICT, although we note that we increased

the consistency loss weight of ICT to match the value

used for PASCAL. It yields a noticeable improve-

ment when using standard augmentation and Cutout.

Colour augmentation increases the variance of the ac-

curacy when using CutMix, making it slightly less

reliable. We hypothesized the the hue jittering com-

ponent of the colour augmentation may harm perfor-

mance in this benchmark as colour is a useful queue

in lesion segmentation, so we tried disabling it when

using ICT and VAT. This did not however improve

colour augmentation results.

4.5 Comparison with Other Work

While we have demonstrated that colour augmenta-

tion can improve semi-supervised segmentation per-

formance when using a simple consistency regulariza-

tion based approach, we acknowledge that our results

do not match those of the recent Classmix (Olsson

et al., 2021), DMT (Feng et al., 2021) and ReCo (Liu

et al., 2021) approaches that use more recent semi-

supervised regularizers.

We also note that (Liu et al., 2021) focused on sit-

uations in which a very small number of labelled sam-

ples were used. As their work did not feature experi-

ments with a comparable number of labelled samples

to our own, we were unable to directly compare their

results with ours in Tables 1 and 2.

5 DISCUSSION AND

CONCLUSIONS

As observed by (French et al., 2020) prior work

in the ﬁeld of semi-supervised image classiﬁcation

attributed the success of consistency regularization

based approaches to the smoothness assumption (Luo

et al., 2018) or cluster assumption (Chapelle and Zien,

2005; Sajjadi et al., 2016; Shu et al., 2018; Verma

et al., 2019). Their analysis of the data distribution

of semantic segmentation showed that the cluster as-

sumption does not apply. Their successful application

of an adapted CutMix regularizer to semi-supervised

semantic segmentation demonstrated that the cluster

assumption is in fact not a pre-requisite for successful

semi-supervised learning. In view of this, they of-

fered the explanation that the variety of augmentation

used need to provide perturbations to samples that are

sufﬁciently varied in order to constrain the orienta-

tion of the decision boundary in the absence of the

low density regions required by the cluster assump-

tion. CutMix succeeds due to offering more variety

than standard geometric augmentation.

Our results indicate a more nuanced explanation.

The positive results obtained from adding colour aug-

mentation to standard geometric augmentation, com-

bined with being able to use a consistent value of 1 for

the consistency loss weight for all regularizers shows

that it is in fact the pixel colour clustering short-

cut that was hampering the effectiveness of standard

geometric augmentation by itself, rather than a lack

of variation. The fact that CutMix without colour

augmentation comfortably out-performs standard ge-

ometric augmentation with colour augmentation does

however show that CutMix adds useful variety that

enables more effective semi-supervised learning.

The story presented by the ISIC 2017 results is

less positive however. The augmentation used to drive

the consistency loss term in a semi-supervised learn-

ing scenario must be class preserving. Modifying an

unsupervised sample such that its class changes will

cause the consistency loss term to encourage consis-

tent predictions across the decision boundary, harm-

ing the performance of the classiﬁer (see the toy 2D

examples in (French et al., 2020) for a more thor-

ough exploration of this). In light of this, practitioners

should carefully consider whether colour augmenta-

tion could alter the ground truth class of a sample.

We offer this as an explanation of the inconsistent ef-

fect of colour augmentation on the ISIC 2017 dataset

in which the colour of lesions is an important signal.

ACKNOWLEDGEMENTS

This work was funded under the European Union

Horizon 2020 SMARTFISH project, grant agreement

no. 773521. The computation required by this work

was performed on the University of East Anglia HPC

Cluster.

VISAPP 2022 - 17th International Conference on Computer Vision Theory and Applications

362

REFERENCES

Chapelle, O. and Zien, A. (2005). Semi-supervised classiﬁ-

cation by low density separation. In AISTATS 2005.

Chen, T., Kornblith, S., Norouzi, M., and Hinton, G.

(2020a). A simple framework for contrastive learning

of visual representations. In ICML 2020.

Chen, X., Fan, H., Girshick, R., and He, K. (2020b). Im-

proved baselines with momentum contrastive learn-

ing. arXiv preprint arXiv:2003.04297.

Chintala, S. et al. (2017). Pytorch.

Codella, N. C., Gutman, D., Celebi, M. E., Helba, B.,

Marchetti, M. A., Dusza, S. W., Kalloo, A., Liopy-

ris, K., Mishra, N., Kittler, H., et al. (2018). Skin

lesion analysis toward melanoma detection: A chal-

lenge at the 2017 international symposium on biomed-

ical imaging (isbi), hosted by the international skin

imaging collaboration (isic). In ISBI 2018.

Cubuk, E. D., Zoph, B., Shlens, J., and Le, Q. (2020).

Randaugment: Practical automated data augmentation

with a reduced search space. In NeurIPS 2020.

Everingham, M., Van Gool, L., Williams, C. K. I.,

Winn, J., and Zisserman, A. (2012). The

PASCAL Visual Object Classes Challenge

2012 (VOC2012) Results. http://www.pascal-

network.org/challenges/VOC/voc2012/workshop/index.html.

Feng, Z., Zhou, Q., Gu, Q., Tan, X., Cheng, G., Lu, X., Shi,

J., and Ma, L. (2021). Dmt: Dynamic mutual training

for semi-supervised learning. CoRR, abs/2004.08514.

French, G., Laine, S., Aila, T., Mackiewicz, M., and Fin-

layson, G. (2020). Semi-supervised semantic segmen-

tation needs strong, varied perturbations. In BMVC

2020.

Hariharan, B., Arbel

aez, P., Bourdev, L., Maji, S., and Ma-

lik, J. (2011). Semantic contours from inverse detec-

tors. In ICCV 2011.

He, K., Fan, H., Wu, Y., Xie, S., and Girshick, R. (2020).

Momentum contrast for unsupervised visual represen-

tation learning. In CVPR 2020.

He, K., Zhang, X., Ren, S., and Sun, J. (2016). Deep resid-

ual learning for image recognition. In CVPR 2016.

Henaff, O. (2020). Data-efﬁcient image recognition with

contrastive predictive coding. In ICML 2020.

Hung, W.-C., Tsai, Y.-H., Liou, Y.-T., Lin, Y.-Y., and

Yang, M.-H. (2018). Adversarial learning for

semi-supervised semantic segmentation. CoRR,

abs/1802.07934.

Ji, X., Henriques, J. F., and Vedaldi, A. (2019). Invariant

information clustering for unsupervised image classi-

ﬁcation and segmentation. In ICCV 2019.

Krizhevsky, A., Sutskever, I., and Hinton, G. E. (2012). Im-

ageNet Classiﬁcation with Deep Convolutional Neu-

ral Networks. In NIPS 2012.

Laine, S. and Aila, T. (2017). Temporal ensembling for

semi-supervised learning. In ICLR 2017.

Li, X., Yu, L., Chen, H., Fu, C.-W., and Heng, P.-A.

(2018). Semi-supervised skin lesion segmentation via

transformation consistent self-ensembling model. In

BMVC 2018.

Liu, S., Zhi, S., Johns, E., and Davison, A. J. (2021). Boot-

strapping semantic segmentation with regional con-

trast. arXiv preprint arXiv:2104.04465.

Luo, Y., Zhu, J., Li, M., Ren, Y., and Zhang, B.

(2018). Smooth neighbors on teacher graphs for semi-

supervised learning. In CVPR 2018.

Maninis, K.-K., Caelles, S., Pont-Tuset, J., and Van Gool,

L. (2018). Deep extreme cut: From extreme points to

object segmentation. In CVPR 2018.

Mittal, S., Tatarchenko, M., and Brox, T. (2019). Semi-

supervised semantic segmentation with high-and low-

level consistency. PAMI 2019.

Miyato, T., Maeda, S.-i., Koyama, M., and Ishii, S. (2017).

Virtual adversarial training: a regularization method

for supervised and semi-supervised learning. arXiv

preprint arXiv:1704.03976.

Oliver, A., Odena, A., Raffel, C., Cubuk, E. D., and Good-

fellow, I. J. (2018). Realistic evaluation of semi-

supervised learning algorithms. In ICLR 2018.

Olsson, V., Tranheden, W., Pinto, J., and Svensson, L.

(2021). Classmix: Segmentation-based data augmen-

tation for semi-supervised learning. In WCACV 2021.

Perone, C. S. and Cohen-Adad, J. (2018). Deep semi-

supervised segmentation with weight-averaged con-

sistency targets. In Deep Learning in Medical Image

Analysis and Multimodal Learning for Clinical Deci-

sion Support.

Sajjadi, M., Javanmardi, M., and Tasdizen, T. (2016). Mu-

tual exclusivity loss for semi-supervised deep learn-

ing. In ICIP 2016.

Shu, R., Bui, H., Narui, H., and Ermon, S. (2018). A DIRT-t

approach to unsupervised domain adaptation. In ICLR

2018.

Sohn, K., Berthelot, D., Carlini, N., Zhang, Z., Zhang, H.,

Raffel, C. A., Cubuk, E. D., Kurakin, A., and Li, C.-

L. (2020). Fixmatch: Simplifying semi-supervised

learning with consistency and conﬁdence. In NeurIPS

2020.

Tarvainen, A. and Valpola, H. (2017). Mean teachers are

better role models: Weight-averaged consistency tar-

gets improve semi-supervised deep learning results. In

NIPS 2017.

Verma, V., Lamb, A., Kannala, J., Bengio, Y., and Lopez-

Paz, D. (2019). Interpolation consistency training for

semi-supervised learning. CoRR, abs/1903.03825.

Xie, Q., Dai, Z., Hovy, E., Luong, M.-T., and Le, Q. V.

(2019). Unsupervised data augmentation. arXiv

preprint arXiv:1904.12848.

Yun, S., Han, D., Oh, S. J., Chun, S., Choe, J., and Yoo,

Y. (2019). Cutmix: Regularization strategy to train

strong classiﬁers with localizable features. In ICCV

2019.

Colour Augmentation for Improved Semi-supervised Semantic Segmentation

363
