Biomedical Text Mining: Applicability of Machine Learning-based

Natural Language Processing in Medical Database

Naﬁseh Mollaei

, Catia Cepeda

, Joao Rodrigues

and Hugo Gamboa

Department of Physics, Faculdade de Ciencias e Tecnologia da Universidade Nova de Lisboa, Monte de Caparica,

2892-516, Caparica, Portugal

Keywords:

Natural Language Processing, Machine Learning, Medical Text Mining, Biomedical Science, Clinical Notes.

Abstract:

Machine learning has demonstrated superior performance in solving many problems in various ﬁelds of

medicine compared to non-machine learning approaches. The aim of this review is to understand how Machine

Learning-based Natural Language Processing (ML-NLP) has been applied to the clinical notes databases. Op-

timization algorithms are listed as examples to demonstrate the simplicity and effectiveness of their applica-

tions for clinical notes database. We reviewed the literature in clinical applications of ML-NLP, particularly

techniques of deep learning such as mainly in pathology reports of diabetes, schizophrenia, cancer and cardi-

ology, where NLP either on a classical algorithm or with deep learning has been actively adopted. We covered

60 different studies in this domain, focusing on a wide range of medical perspective based algorithms. Ma-

chine learning-based approaches combine the beneﬁts of health systems with the expertise and experience of

human well-being. From this review, it is clear that these techniques can improve the quantiﬁcation of diagno-

sis and prognosis of cases and may create tools to assist patients during diagnosis and treatment. We complete

this work by providing guidelines on the applicability of ML-NLP by describing the most relevant libraries to

extract medical expressions from clinical reports text that can support clinical decision-making.

1 INTRODUCTION

Machine learning (ML) is a branch of Artiﬁcial In-

telligence (AI) that is derived from the study of pat-

tern recognition and computational learning theory. It

produces models that can learn from vast amounts of

data and make predictions based on that data (Provost

and Kohavi, 1998). Since ML models can learn from

data without the use of rules (Rodrigues et al., 2020),

non-ML refers to statistical modeling using mathe-

matical equations to formalize relationships between

variables in data (Gago et al., 2017). Additionally,

Deep Learning (DL) is a type of ML technology that

uses artiﬁcial neural networks to learn representations

(Goodfellow et al., 2016). Considering the signiﬁ-

cant advantages of ML techniques in medical areas

(Ojo and Olanrewaju, 2019; Mollaei et al., 2021),

ML has been increasingly and widely used in a va-

riety of areas in medicine, with increased perspec-

tives of application in the coming decades (Sun et al.,

https://orcid.org/0000-0002-8332-489X

https://orcid.org/0000-0002-2998-976X

https://orcid.org/0000-0001-7320-511X

https://orcid.org/0000-0002-4022-7424

2017; Wang et al., 2017a; Wang et al., 2017b; Fer-

reira et al., 2020). Advanced analytical techniques

to extract informative features from clinical notes

and model underlying relationships that cannot be

modelled with traditional statistical tools could trans-

form biomedical research as they include techniques

such as speech recognition (Mitrofan and Ion, 2017)

and automated cancer detection (Halilaj et al., 2018).

Traditional ML methods were based on one dataset

and one task. Interestingly, the new generation of

ML consists of a) data: self-supervised, graphs, and

multi-model; b)systems: transfer learning, few shot

learning, federated learning, and mixture of experts;

c)techniques: transformers, deep reinforcement learn-

ing, and Generative Adversarial Networks (GANs)

(Thornton et al., 2021).

One of the other interesting ﬁelds of AI which was

introduced in 1950 is Natural Language Processing

(NLP) (Nadkarni et al., 2011). The way we communi-

cate through language has radically changed over the

past few years. With technological development, new

instruments have been used by humans to communi-

cate. Communication between humans and comput-

ers has never been as broad or as global as it is now.

Mollaei, N., Cepeda, C., Rodrigues, J. and Gamboa, H.

Biomedical Text Mining: Applicability of Machine Learning-based Natural Language Processing in Medical Database.

DOI: 10.5220/0010819500003123

In Proceedings of the 15th International Joint Conference on Biomedical Engineering Systems and Technologies (BIOSTEC 2022) - Volume 4: BIOSIGNALS, pages 159-166

ISBN: 978-989-758-552-4; ISSN: 2184-4305

159

How does a computer comprehend the structure, orga-

nization, and even meaning of what is written? In that

regard, NLP is the computational science developed

to be this bridge between natural language and com-

puter language. NLP can be applied to all domains,

from our day-to-day tasks in auto-completion or spam

ﬁltering, to medi-cal text analysis. In general, NLP

techniques include text generation, text classiﬁcation,

text pro-cessing, and text comprehension. Currently,

ML strategies, both supervised (using sample input-

output pairs to learn a function that maps an input to

an output) and unsupervised (algorithms to ﬁnd pat-

terns in data sets with unclassiﬁed or unlabeled data

points), dominate the main strategies for NLP appli-

cations. Not only NLP can use in medical database, it

can then be used in a broad set of applications, such

as machine translation, grammar check, spam ﬁlters,

sentiment analysis, etc. For example; based on unbal-

anced data on Adverse Drug Reactions (ADRs) in real

Electronic Health Records (EHRs) from the Spanish

population, the hybrid approach presented a combina-

tion of rule-based and machine learning-based tech-

niques. In a highly skewed categorization environ-

ment, recall and precision complement the elements

for knowledge-based and inferred models, accord-

ing to both intra-sentence and inter-sentence ADRs

(Casillas et al., 2016). DL has been applied to clini-

cal notes in Spanish and Swedish for medical named

entity recognition (Weegar et al., 2019). Other stud-

ies can evaluate medical texts like (Pardo et al., 2004)

producing rhetorical structures named DiZer of scien-

tiﬁc texts based upon the Rhetorical Structure Theory

(Rino et al., 2004). This work gives insight into the

concept of how text mining helps medical decision-

making. Hence, we listed a variety of biomedi-

cal text applications; 1)Large-scale classiﬁcation of

biomedical documents; 2)Classiﬁcation of biomedi-

cal databases using ML; 3)Collecting relevant docu-

ment databases and their methods; 4)How the delivery

of the retrieved information made concise and user-

understandable by critical libraries? While applica-

tions of ML-NLP procedures include medical notes, a

critical evaluation of studies that use ML-NLP meth-

ods remains difﬁcult. As the biomedical ﬁeld be-

comes data-intense and the use of ML, particularly

DL, continues to increase, good practices for con-

ducting and reporting research at the intersection of

biomedical text and ML are needed to ensure that con-

clusions are valid and reproducible. Researchers can

use the ﬁndings to develop an intuition for assigning

ML-NLP issues more effectively than they can using

traditional statistics. We also aim to investigate more

visible ML efforts and propose standards to increase

the quality and impact of future research in this excit-

ing area. To achieve this goal, we ﬁrst review appli-

cations of ML encountered in the literature. Then, we

outline best practices for reporting the results of ML-

NLP analyses that focus on various diseases, such

as pathology reports, diabetes, schizophrenia, various

cancers, and cardiology. In the discussion that fol-

lowed, we debate some topics to overcome the chal-

lenges faced by biomedical text analysis. And, Sec-

tion 6 highlights opportunities where emerging tech-

niques are likely to have a signiﬁcant impact in up-

coming years.

2 SEARCH OF METHODS

We conducted a search for original research articles

published up to September 7, 2021. For this rea-

son, using the arXiv

, medRxiv

, IEEE Xplore

Scopus

, ACM Digital Library

, PubMed

and

Google scholar database

(2004-) was considered.

This search used the phrase ”natural language pro-

cessing in the medical text domain” to get a sense

of how academics are using NLP to evaluate medical

texts. NLP, ML, Text Mining, Biomedical Science,

Medical Texts or Clinical Notes, and ”not related”

were the ﬁve categories in which the works were clas-

siﬁed. These keywords were taken into account based

on the published papers’ titles and abstracts. The

automatic search (Figure 1) of 103 papers was ﬁ-

nally selected. ML articles were investigated in two

categories: mathematical articles and papers dealing

with the diagnosis and prognosis of diseases affect-

ing health and well-being (Srinivasagopalan et al.,

2019). Overall, authors manually culled 60 papers

from those 62 to ﬁnd 60 that discussed the use of

NLP in medical textual data. To ﬁnd relevant stud-

ies, we employed search phrases from three separate

categories: 1)Identify clinical factors and patterns to

screen for such learning tasks. 2)ML terms, such as

DL (Akl et al., 2019), and neural network (Zhang and

Zhou, 2006) by taking into account their libraries.

3) medical terminology, such as pathology reports

(Brimo et al., 2010; Chang et al., 2019), diabetes (Xu

et al., 2014), schizophrenia (Srinivasagopalan et al.,

2019), various cancers (Fakoor et al., 2013; Sun et al.,

2017), and cardiology (Weissman et al., 2018). At

least one term from each of these three categories ap-

https://arxiv.org/

https://www.medrxiv.org/

https://ieeexplore.ieee.org/Xplore/home.jsp

https://www.scopus.com/

https://dl.acm.org/

https://pubmed.ncbi.nlm.nih.gov/

https://scholar.google.com

BIOSIGNALS 2022 - 15th International Conference on Bio-inspired Systems and Signal Processing

160

Figure 1: Preferred reporting items for reviews ﬂowchart

detailing how selected articles based on identiﬁcation,

screening, eligibility and included.

peared in the title or abstract of 60 considered arti-

cles. We also considered the following: dissertations,

conference proceedings, non-English articles, studies

whose primary outcome was not one of supervised or

unsupervised learning, and studies that utilized ML

followed by traditional inferential statistics. Among

these 60 articles, ten of them are considered the main

ones. Table 1 shows a brief summary of the tools of

these studies with their GitHub. It is worthwhile to

mention that table 2 has these tools, whether solo or

in combination.

3 RESULT

We found only 10 empirical papers that matched our

inclusion criterion. The use of inconsistent report-

ing methods on classiﬁer performance made it im-

practical to compare model performance across stud-

ies. We did not provide commentary on models’ rel-

ative performance or a corresponding meta-analytic

examination of ﬁndings. Table 2 shows the most

important studies which are related to ML-NLP pa-

pers in clinical notes in terms of four questions for-

mulated in this table of ML-NLP: 1)What are the

medical studies addressed in this study?; 2)What are

the most frequently adopted combination methods?;

3)What are the database used?; 4)What are the solo

ML-NLP/ML/NLP methods?

Wang et al. introduced a new multi-task

learning framework using char-level neural models

for BioNER (Biomedical named entity recognition)

(Wang et al., 2019). A Bi-directional Long Short-

Term Memory-Conditional random ﬁeld (BiLSTM-

CRF) model (Habibi et al., 2017; Lample et al., 2016)

is represented with an additional context-dependent

BiLSTM (Liu et al., 2018) layer for modeling charac-

ter sequences. A prominent advantage of this multi-

task model is that it was inputted from different 15

datasets that can effectively share both character- and

word-level representations by reusing parameters in

the corresponding BiLSTM units. DL has provided

a new advanced approach such as deep uniﬁed net-

works (DUNs), a new mesh-like network structure

of DL designed to avoid overﬁtting in comparison

with other neural networks (Rav

ı et al., 2016). Go-

las et al. improved the 30-day readmission risk for

this (magnetic resonance imaging) EMR-based pre-

diction model for heart failure patients on discharge

from hospital admission. By reducing features via

KL divergence, Logistic Regression (LR), Gradient

Boosting (GB), and Maxout networks cannot outper-

form AUC performance (Golas et al., 2018). Weng et

al. (Weng et al., 2017) applied the Integrating Data

for Analysis, Anonymization, and Sharing (iDASH)

data repository and Massachusetts General Hospital

datasets to the clinical NLP system, Clinical Text

and Knowledge Extraction (cTAKES) analysis with

a Uniﬁed Medical Language System (UMLS). These

databases can be found in the ﬁelds of neurology, car-

diology, and endocrinology. Furthermore, the ”nltk”

program was used to normalize the lexicon (word to-

kenization and stemming process) (Agarwal, 2015).

Hybrid bag-of-words (Maraﬁno et al., 2014) with

UMLS concepts are restricted to ﬁve semantic groups,

with ”tf-idf” (Salton and Buckley, 1988) weighting

and linear Support Vector Machine (SVM) algorithm

(Fan et al., 2008) yielded the best performing clas-

siﬁer for medical sub-domain classiﬁcation in the

”iDASH” database. In parallel, ”scikit-learn” pack-

age was selected for the supervised learning algo-

rithms implementation and model evaluation. ”gen-

sim” was used for document embedding. ”Tensor-

Flow” and ”Keras” were adopted for building deep

neural networks and neural word embedding. Con-

volutional Neural Network (CNN) (Xu et al., 2016)

and CRNN (Rakhlin, 2016) pre-trained fastText word

embedding with Adam optimization, (Kingma and

Ba, 2014) performed better than other top-performing

shallow supervised learning algorithms, such as lin-

ear SVM and regularized multinomial logistic regres-

sion, at document classiﬁcation. A gated scaled dot

product is presented based on another neural network

for biomedical question answering tasks by the use of

transfer learning methods (Du et al., 2020). BioBERT

was the hidden representation of each token for ques-

tions and passages. The performance of the model

is pre-trained on the large-scale SQuAD dataset, and

Biomedical Text Mining: Applicability of Machine Learning-based Natural Language Processing in Medical Database

161

Table 1: Summary of the tools of ten main empirical papers.

Tools Description

bioBert W

A language model representing with Google-AI with deep bidirectional representations from unlabeled

medical text by jointly conditioning on both left and right context in all layers

skip-gram W

A method for learning high-quality distributed vector representations that capture a large number of syntactic

and semantic word associations.

fastText W

An algorithm for generating word vectors is provided by Facebook. This model can generate vectors for words

that have not been trained in the steps using character N-grams, which has been able to have better results than

previous models.

TF-IDF W A matrix with weights over word occurrences

Bag of Words W

A method to generate representations of sentences using representations of its component. This information is

stored in a matrix of data with rows and columns for each unique word. In this case, the features extracted are

purely statistical, but can provide a relevant measure of differences between documents.

BioNER W A NLP methods that recognizes speciﬁc names in medical texts

UMLS W Understanding the meaning of the language of biomedicine and health

Apache cTAKES W Extracting clinical information from electronic health record unstructured text

ﬁne-tuning is implemented on the small target data set

of BioASQ. Conversely, a novel unsupervised deep

feature learning method (Miotto et al., 2016) used to

retrieve a general-purpose patient representation from

EHR data that facilitates clinical predictive modeling.

A lexical scanner with a syntactic method in seventy-

eight diseases such as diabetes, schizophrenia, and

various cancers is used by implementing principal

component analysis (PCA), three-layer stacked de-

noising auto-encoders (”Deep-patient”), K-Means,

Gaussian Mixture Model (GMM) Independent Com-

ponent Analysis (ICA) and supervised learning with

Random Forest. Some of the most recent studies

on how DL was used in text by keyword extrac-

tion algorithms is based on Bidirectional Encoder,

CNN, and Long Short-Term Memory (LTSM) (Kim

et al., 2020). In other words, the Bayes classiﬁer and

the two feature-based key phrase extractors named

Wingnus (Nguyen and Luong, 2010). By using NLP

(Zhang et al., 2019) and text mining (Sung et al.,

2020) with association rules, automatically recog-

nize stressor entities and classify psychiatric stres-

sors from clinical text using NLP–based methods.

Other examples of extracting association rules from

medical records are: (Lakshmi and Vadivu, 2017)

by discovering the correlation between diseases, dis-

eases and symptoms, diseases and medicines, Nat-

ural Language Enhanced Association Rules Mining

(NEARM) (Ren et al., 2018) captured the relations

between lamentation text and natural language pat-

terns in the combining of the knowledge base. Re-

garding i2b2 clinical NLP challenge, (Chen et al.,

2015b) identiﬁed heart disease risk factors in clinical

texts over time with a hybrid pipeline system based on

machine learning-based and rule-based approaches.

Chen et al. (Chen et al., 2015a) classiﬁed the in-

jury text narrative with the evaluation of the feasibility

of matrix auto-encoders (Kingma and Welling, 2014)

factorization (NNMF-SVM) achieved the best perfor-

mance for both external cause and major injury factor

classiﬁcation; Decision Tree (DT), Neural Network

(NN), and K-Nearest Neighbors (KNN).

4 DISCUSSION

This review summarized studies that used ML and

NLP to improve the understanding and processing of

biomedical text. The ﬁndings from 60 studies pub-

lished since 2004 were considered in the current re-

view. Based on this body of work, we concluded that

ML-NLP has shown promise in greatly boosting clin-

ical note text mining. Despite a recent growth in the

use of ML-NLP, we ﬁnd that their application in this

ﬁeld of research is still limited. We hope to identify

gaps in the literature and offer strategies to expand

on current ﬁndings so that researchers can fully grasp

ML-NLP’s promise. In recent advances in the size

of data sets, DL is crucial to developing novel algo-

rithms. In (Wang et al., 2020; Jang and Cho, 2019)

took a broad view of NLP techniques, from produc-

ing dependency parses to text-based event prediction.

clinical context is applied by BERT, but also the appli-

cability of GRU (e.g. (Belo et al., 2017) in signal pro-

cessing) can be introduced in biomedical text mining.

There are DL methods used in (Wang et al., 2020)

that can also be used in biomedical text mining, such

as incremental learning, (Sarwar et al., 2019), varia-

tional and GAN, (Mirza et al., 2014), but they were

not considered in the evaluated studies.

Additionally, aside from Adam optimization,

(Kingma and Ba, 2014) deep neural networks (Akl

et al., 2019) can be used to optimize hyperparame-

ters in clinical literature. On the one hand, most of

the studies in Table 2 utilized DL to improve their

algorithms. But, on the other hand, in (Chen et al.,

BIOSIGNALS 2022 - 15th International Conference on Bio-inspired Systems and Signal Processing

162

Table 2: The ML-NLP studies which used clinical notes in Biomedical text mining.

Authors, year Paper Type NLP Approach Text Description Disease Stastiscal Analysis

(Wang et al., 2019) Mathematics

BioNER and word embedding

with skip-gram model

Huge biomedical text in different areas - DL) LSTM

(Golas et al., 2018) Medical bag-of-word, Part-of-speech tagging

Physician notes and discharge

summaries cause of admission,

the patients’ hospital course and

discharge conclusions, and

instructions, Heart failure,

DUN, Logistic Regression,

Gradient Boosting, Maxout network

Heart failure

ML) Logistic

Regression,

Gradient Boosting, Maxout

network/ DL) DUN

(Weng et al., 2017) Medical

cTAKES, UMLS, ”bag-of-words”,

TF-IDF

Specialist-written notes and created;

an automated mapping script;

which allows the

mapping between note authors and

they’re medical specialization using

the PartnersEnterprise data,

warehouse (EDW),

physician database

Neurology, Cardiology,

and Endocrinology

ML) Support Vector Machine

DL) CRNN, CNN, and

LSTM With

Adam optimization

algorithm

(Du et al., 2020)

Biomedical

Question

Answering

Factoid questions on a set of

Wikipedia articles,

where the answer to every question is

a text segment

from the corresponding passage,

With 100,000+ question-answer pairs on

500+ articles from PubMed abstracts

and possible answers

Transfer Learning and

DL) BioBERT

and LSTM

(Miotto et al., 2016) Medical

A lexical scanner with

syntactic method

Diagnoses (ICD-9codes),

medications,

procedures, and lab tests,

free-text clinical notes

78 diseases

Unsupervised deep feature

learning ML)K-Means, Gaussian

mixture model,

PCA, independent component analysis

”ICA” and supervised learning with

Random Forest

(Kim et al., 2020) Medical - Pathology reports Pathology DL) BERT, CNN, LTSM

(Zhang et al., 2019) Medical Bag-of-word, POS tagging, n-grams

Suicidal behaiviors and sychiatric

Stressors text in EHR

Psychiatric Stress

Unsupervisd word

representation features

(Lakshmi and Vadivu, 2017) Medical

Stemming, POS tagging, Parsing, Stop

words removal, synonym ﬁnding, semantic

analysis, Negative scope identiﬁcation

Disease, medicines, symptoms

text in EHR

Many diseases

ML) Apriori, Apriori Tid,

Close, RElim,

Eclat, FP-Growth

(Chen et al., 2015a) Medical TF-IDF and Binery weghing

Injury narrative

text

ML) SVM, KNN, NN,

AdaBoost, DT,

Naive Bayes algorithm,

NNMF

(Chen et al., 2015b) Medical

TF–IDF, n-grams, bag-of-words,

part-of-speech (POS) tags

Heart disease and

diabetes-associated

risk factors risk

factors in clinical texts

Heart disease, diabetes

ML) SSVMs, SVMs,

and CRFs,

2019) concluded that DL is useful for some tasks,

such as classifying medical images, but it is not ap-

propriate for other clinical data challenges. Accord-

ing to our experience across numerous clinical chal-

lenges, conventional, off-the-shelf ML approaches

can be trained faster and have overall higher perfor-

mance. ML and NLP hold great promise for improv-

ing clinical decision-making and accelerating rehabil-

itation programs (Sung et al., 2020), primarily for di-

agnosis and treatment of disease prognosis. To enable

proper use of advanced analytical approaches, open-

source databases, applications, and discussions must

be actively encouraged within the medical commu-

nity. Application in chronic disease (Sheikhalishahi

et al., 2019) was described in review publications as

re-enacting medical decision-making, which can aid

comprehension of how and why a decision is made.

In biology and medicine, (Ching et al., 2018) exam-

ined various biomedical problems in terms of patient

classiﬁcation, fundamental biological processes, and

treatment of patients. Furthermore, Wu et al. (Wu

et al., 2020) investigated the use of DL as a baseline

Biomedical Text Mining: Applicability of Machine Learning-based Natural Language Processing in Medical Database

163

for NLP research, as well as the use of DL-based NLP

in the medical ﬁeld is being conducted.

5 LIMITATION

Authors proposed medical publications introducing

ML-NLP and its applications for other research pur-

poses. The purpose of this article was to supply med-

ical references with an introduction to NLP and an in-

vestigation of current applications of NLP that may be

of interest to investigators. A limitation ubiquitous in

any study of a survey is publication bias. This paper

just took into account published manuscripts, which

may support a biased representation of the scope and

success of the study. Some investigators may submit

source code for software to online platforms such as

GitHub.

6 CONCLUSION & FUTURE

WORK

The main purpose of this work was to present the ad-

vances and novel developments in the area of ML-

NLP, the state of the art being developed, but also

the fundamentals and main strategies that have al-

ways been used until now. For this demonstration,

an exhaustive list of tools (Table 1), coupled with

their applicability, is presented. Hence, the extention

of tease tools that are used for ML-NLP applications

(Table 2) in the biomedical domain. With the help of

these tools, this work shows, explains, and exempli-

ﬁes all the steps to solve most types of problems in

the ML-NLP ﬁeld. Additionally, the investigation of

ML-NLP on topics like pathology reports of diabetes,

schizophrenia, cancer, and cardiology can be useful

to the healthcare area. This work was also a chal-

lenge to search for solutions that could contribute to

the development of new strategies for the analysis of

a symbolic representation of time series.

ACKNOWLEDGEMENTS

This work was partly supported by science and

technology foundation (FCT), under projects OP-

ERATOR (ref. 04/SI/2019) and PREVOCU-

PAI (DSAIPA/AI/0105/2019), and Ph.D. grants

PD/BDE/142816/2018 and PD/BDE/142973/2018.

The authors have no conﬂicts of interest to report.

REFERENCES

Agarwal, V. (2015). Research on data preprocessing and

categorization technique for smartphone review anal-

ysis. International Journal of Computer Applications,

975:8887.

Akl, A., El-Henawy, I., Salah, A., and Li, K. (2019). Op-

timizing deep neural networks hyperparameter posi-

tions and values. Journal of Intelligent & Fuzzy Sys-

tems, 37(5):6665–6681.

Belo, D., Rodrigues, J., Vaz, J. R., Pezarat-Correia, P., and

Gamboa, H. (2017). Biosignals learning and synthesis

using deep neural networks. Biomedical engineering

online, 16(1):1–17.

Brimo, F., Schultz, L., and Epstein, J. I. (2010). The

value of mandatory second opinion pathology review

of prostate needle biopsy interpretation before radical

prostatectomy. The Journal of urology, 184(1):126–

130.

Casillas, A., P

erez, A., Oronoz, M., Gojenola, K., and San-

tiso, S. (2016). Learning to extract adverse drug reac-

tion events from electronic health records in spanish.

Expert Systems with Applications, 61:235–245.

Chang, H. Y., Jung, C. K., Woo, J. I., Lee, S., Cho, J., Kim,

S. W., and Kwak, T.-Y. (2019). Artiﬁcial intelligence

in pathology. Journal of pathology and translational

medicine, 53(1):1.

Chen, D., Liu, S., Kingsbury, P., Sohn, S., Storlie, C. B.,

Habermann, E. B., Naessens, J. M., Larson, D. W.,

and Liu, H. (2019). Deep learning and alternative

learning strategies for retrospective real-world clinical

data. NPJ digital medicine, 2(1):1–5.

Chen, L., Vallmuur, K., and Nayak, R. (2015a). In-

jury narrative text classiﬁcation using factorization

model. BMC medical informatics and decision mak-

ing, 15(1):1–12.

Chen, Q., Li, H., Tang, B., Wang, X., Liu, X., Liu, Z., Liu,

S., Wang, W., Deng, Q., Zhu, S., et al. (2015b). An

automatic system to identify heart disease risk factors

in clinical texts over time. Journal of biomedical in-

formatics, 58:S158–S163.

Ching, T., Himmelstein, D. S., Beaulieu-Jones, B. K.,

Kalinin, A. A., Do, B. T., Way, G. P., Ferrero, E.,

Agapow, P.-M., Zietz, M., Hoffman, M. M., et al.

(2018). Opportunities and obstacles for deep learn-

ing in biology and medicine. Journal of The Royal

Society Interface, 15(141):20170387.

Du, Y., Pei, B., Zhao, X., and Ji, J. (2020). Deep scaled dot-

product attention based domain adaptation model for

biomedical question answering. Methods, 173:69–74.

Fakoor, R., Ladhak, F., Nazi, A., and Huber, M. (2013).

Using deep learning to enhance cancer diagnosis and

classiﬁcation. In Proceedings of the international con-

ference on machine learning, volume 28. ACM, New

York, USA.

Fan, R.-E., Chang, K.-W., Hsieh, C.-J., Wang, X.-R., and

Lin, C.-J. (2008). Liblinear: A library for large lin-

ear classiﬁcation. the Journal of machine Learning

research, 9:1871–1874.

BIOSIGNALS 2022 - 15th International Conference on Bio-inspired Systems and Signal Processing

164

Ferreira, F., Gago, M., Mollaei, N., Bicho, E., Sousa, N.,

Gama, J., and Ferreira, C. (2020). Objective graphi-

cal clustering of spatiotemporal gait pattern in patients

with parkinsonism. In AIP Conference Proceedings,

volume 2293, page 420101. AIP Publishing LLC.

Gago, M., Ferreira, F. R., Mollaei, N., Rodrigues, M.,

Sousa, N., Bicho, E., and Rodrigues, P. (2017). Gait

analysis as a complementary tool in the levodopa dose

decision in vascular parkinson’s disease.

Golas, S. B., Shibahara, T., Agboola, S., Otaki, H., Sato,

J., Nakae, T., Hisamitsu, T., Kojima, G., Felsted, J.,

Kakarmath, S., et al. (2018). A machine learning

model to predict the risk of 30-day readmissions in

patients with heart failure: a retrospective analysis of

electronic medical records data. BMC medical infor-

matics and decision making, 18(1):1–17.

Goodfellow, I., Bengio, Y., and Courville, A. (2016). Deep

learning. MIT press.

Habibi, M., Weber, L., Neves, M., Wiegandt, D. L., and

Leser, U. (2017). Deep learning with word embed-

dings improves biomedical named entity recognition.

Bioinformatics, 33(14):i37–i48.

Halilaj, E., Rajagopal, A., Fiterau, M., Hicks, J. L., Hastie,

T. J., and Delp, S. L. (2018). Machine learning in

human movement biomechanics: Best practices, com-

mon pitfalls, and new opportunities. Journal of biome-

chanics, 81:1–11.

Jang, H.-J. and Cho, K.-O. (2019). Applications of deep

learning for the analysis of medical data. Archives of

pharmacal research, 42(6):492–504.

Kim, Y., Lee, J. H., Choi, S., Lee, J. M., Kim, J.-H., Seok,

J., and Joo, H. J. (2020). Validation of deep learn-

ing natural language processing algorithm for key-

word extraction from pathology reports in electronic

health records. Scientiﬁc Reports, 10(1):1–9.

Kingma, D. P. and Ba, J. (2014). Adam: A

method for stochastic optimization. arXiv preprint

arXiv:1412.6980.

Kingma, D. P. and Welling, M. (2014). Stochastic gradi-

ent vb and the variational auto-encoder. In Second In-

ternational Conference on Learning Representations,

ICLR, volume 19.

Lakshmi, K. S. and Vadivu, G. (2017). Extracting associ-

ation rules from medical health records using multi-

criteria decision analysis. Procedia Computer Sci-

ence, 115:290–295.

Lample, G., Ballesteros, M., Subramanian, S., Kawakami,

K., and Dyer, C. (2016). Neural architectures

for named entity recognition. arXiv preprint

arXiv:1603.01360.

Liu, L., Shang, J., Ren, X., Xu, F., Gui, H., Peng, J.,

and Han, J. (2018). Empower sequence labeling with

task-aware neural language model. In Proceedings of

the AAAI Conference on Artiﬁcial Intelligence, vol-

ume 32.

Maraﬁno, B. J., Davies, J. M., Bardach, N. S., Dean, M. L.,

and Dudley, R. A. (2014). N-gram support vector ma-

chines for scalable procedure and diagnosis classiﬁca-

tion, with applications to clinical free text data from

the intensive care unit. Journal of the American Med-

ical Informatics Association, 21(5):871–875.

Miotto, R., Li, L., Kidd, B. A., and Dudley, J. T. (2016).

Deep patient: an unsupervised representation to pre-

dict the future of patients from the electronic health

records. Scientiﬁc reports, 6(1):1–10.

Mirza, M., Xu, B., Warde-Farley, D., Ozair, S., Courville,

A., Bengio, Y., et al. (2014). Generative adversarial

nets. Proceedings of Advances in Neural Information

Processing Systems.

Mitrofan, M. and Ion, R. (2017). Adapting the ttl roma-

nian pos tagger to the biomedical domain. In Biomed-

icalNLP@ RANLP, pages 8–14.

Mollaei, N., Londral, A. R., Cepeda, C., Azevedo, S., San-

tos, J. P., Coelho, P., Fragata, J., and Gamboa, H.

(2021). Length of stay prediction in acute intensive

care unit in cardiothoracic surgery patients. In 2021

Seventh International conference on Bio Signals, Im-

ages, and Instrumentation (ICBSII), pages 1–5.

Nadkarni, P. M., Ohno-Machado, L., and Chapman, W. W.

(2011). Natural language processing: an introduction.

Journal of the American Medical Informatics Associ-

ation, 18(5):544–551.

Nguyen, T. D. and Luong, M.-T. (2010). Wingnus:

Keyphrase extraction utilizing document logical struc-

ture. In Proceedings of the 5th international workshop

on semantic evaluation, pages 166–169.

Ojo, A. K. and Olanrewaju, A. B. (2019). Knowledge dis-

covery in medical database using machine learning

techniques. International Journal of Computer Ap-

plications, 975:8887.

Pardo, T. A. S., Nunes, M. d. G. V., and Rino, L. H. M.

(2004). Dizer: An automatic discourse analyzer for

brazilian portuguese. In Brazilian Symposium on Ar-

tiﬁcial Intelligence, pages 224–234. Springer.

Provost, F. and Kohavi, R. (1998). Glossary of terms. Jour-

nal of Machine Learning, 30(2-3):271–274.

Rakhlin, A. (2016). Convolutional neural networks for sen-

tence classiﬁcation. GitHub.

Rav

ı, D., Wong, C., Deligianni, F., Berthelot, M., Andreu-

Perez, J., Lo, B., and Yang, G.-Z. (2016). Deep learn-

ing for health informatics. IEEE journal of biomedical

and health informatics, 21(1):4–21.

Ren, S., Li, Z., Wang, H., Li, Y., Shen, K., and Cheng, S.

(2018). Nearm: Natural language enhanced associa-

tion rules mining. In 2018 IEEE International Con-

ference on Data Mining Workshops (ICDMW), pages

438–445. IEEE.

Rino, L. H. M., Pardo, T. A. S., Silla, C. N., Kaestner, C.

A. A., and Pombo, M. (2004). A comparison of auto-

matic summarizers of texts in brazilian portuguese. In

Brazilian Symposium on Artiﬁcial Intelligence, pages

235–244. Springer.

Rodrigues, J., Gamboa, H., Mollaei, N., Os

orio, D.,

Assunc¸

ao, A., Fuj

ao, C., and Carnide, F. (2020). A ge-

netic algorithm to design job rotation schedules with

low risk exposure. In Doctoral Conference on Com-

puting, Electrical and Industrial Systems, pages 395–

402. Springer.

Biomedical Text Mining: Applicability of Machine Learning-based Natural Language Processing in Medical Database

165

Salton, G. and Buckley, C. (1988). Term-weighting ap-

proaches in automatic text retrieval. Information pro-

cessing & management, 24(5):513–523.

Sarwar, S. S., Ankit, A., and Roy, K. (2019). Incremental

learning in deep convolutional neural networks using

partial network sharing. IEEE Access, 8:4615–4628.

Sheikhalishahi, S., Miotto, R., Dudley, J. T., Lavelli, A.,

Rinaldi, F., and Osmani, V. (2019). Natural lan-

guage processing of clinical notes on chronic dis-

eases: systematic review. JMIR medical informatics,

7(2):e12239.

Srinivasagopalan, S., Barry, J., Gurupur, V., and

Thankachan, S. (2019). A deep learning approach

for diagnosing schizophrenic patients. Journal of

Experimental & Theoretical Artiﬁcial Intelligence,

31(6):803–816.

Sun, W., Tseng, T.-L. B., Zhang, J., and Qian, W. (2017).

Enhancing deep convolutional neural network scheme

for breast cancer diagnosis with unlabeled data. Com-

puterized Medical Imaging and Graphics, 57:4–9.

Sung, S.-F., Lin, C.-Y., and Hu, Y.-H. (2020). Emr-

based phenotyping of ischemic stroke using super-

vised machine learning and text mining techniques.

IEEE journal of biomedical and health informatics,

24(10):2922–2931.

Thornton, J. M., Laskowski, R. A., and Borkakoti, N.

(2021). Alphafold heralds a data-driven revolu-

tion in biology and medicine. Nature Medicine,

27(10):1666–1669.

Wang, C., Elazab, A., Wu, J., and Hu, Q. (2017a). Lung

nodule classiﬁcation using deep feature fusion in chest

radiography. Computerized Medical Imaging and

Graphics, 57:10–18.

Wang, X., Yang, W., Weinreb, J., Han, J., Li, Q., Kong,

X., Yan, Y., Ke, Z., Luo, B., Liu, T., et al. (2017b).

Searching for prostate cancer by fully automated mag-

netic resonance imaging classiﬁcation: deep learning

versus non-deep learning. Scientiﬁc reports, 7(1):1–8.

Wang, X., Zhang, Y., Ren, X., Zhang, Y., Zitnik, M.,

Shang, J., Langlotz, C., and Han, J. (2019). Cross-type

biomedical named entity recognition with deep multi-

task learning. Bioinformatics, 35(10):1745–1752.

Wang, X., Zhao, Y., and Pourpanah, F. (2020). Recent ad-

vances in deep learning.

Weegar, R., P

erez, A., Casillas, A., and Oronoz, M. (2019).

Recent advances in swedish and spanish medical en-

tity recognition in clinical texts using deep neural ap-

proaches. BMC medical informatics and decision

making, 19(7):1–14.

Weissman, G. E., Hubbard, R. A., Ungar, L. H., Harhay,

M. O., Greene, C. S., Himes, B. E., and Halpern,

S. D. (2018). Inclusion of unstructured clinical text

improves early prediction of death or prolonged icu

stay. Critical care medicine, 46(7):1125.

Weng, W.-H., Wagholikar, K. B., McCray, A. T., Szolovits,

P., and Chueh, H. C. (2017). Medical subdomain clas-

siﬁcation of clinical notes using a machine learning-

based natural language processing approach. BMC

medical informatics and decision making, 17(1):1–13.

Wu, S., Roberts, K., Datta, S., Du, J., Ji, Z., Si, Y., Soni,

S., Wang, Q., Wei, Q., Xiang, Y., et al. (2020). Deep

learning in clinical natural language processing: a me-

thodical review. Journal of the American Medical In-

formatics Association, 27(3):457–470.

Xu, J., Chen, D., Qiu, X., and Huang, X. (2016).

Cached long short-term memory neural networks

for document-level sentiment classiﬁcation. arXiv

preprint arXiv:1610.04989.

Xu, R., Li, L., and Wang, Q. (2014). driskkb: a large-scale

disease-disease risk relationship knowledge base con-

structed from biomedical text. BMC bioinformatics,

15(1):1–13.

Zhang, M.-L. and Zhou, Z.-H. (2006). Multilabel neu-

ral networks with applications to functional genomics

and text categorization. IEEE transactions on Knowl-

edge and Data Engineering, 18(10):1338–1351.

Zhang, Y., Zhang, O. R., Li, R., Flores, A., Selek, S., Zhang,

X. Y., and Xu, H. (2019). Psychiatric stressor recogni-

tion from clinical notes to reveal association with sui-

cide. Health informatics journal, 25(4):1846–1862.

BIOSIGNALS 2022 - 15th International Conference on Bio-inspired Systems and Signal Processing

166
