Sovereignly Donating Medical Data as a Patient:

A Technical Approach

Florian Lauf

, Hendrik Meyer zum Felde

, Marcel Klötgen

, Robin Brandstädter

and Robin Schönborn

Fraunhofer Institute for Software and Systems Engineering ISST, Dortmund, Germany

Fraunhofer Institute for Applied and Integrated Security AISEC, Garching near Munich, Germany

Fraunhofer Institute for Experimental Software Engineering IESE, Kaiserslautern, Germany

hendrik.meyerzumfelde@aisec.fraunhofer.de, robin.brandstaedter@iese.fraunhofer.de

Keywords: Medical Data Donation, Data Sovereignty, Patient Empowerment, Usage Control, International Data Spaces.

Abstract: Data is the new asset of the 21

century, and many new business models are based on data. However, data is

also needed in the medical research domain, such as in the procedure of applying new machine learning

methods for gaining new medical findings. Furthermore, the hurdle arises that medical data comprises

personal data, and thus, it requires particular care and protection. Hence, patients must consent to the data

donation process for general medical research but without selecting specific research projects. We argue that

patients must gain more influence in the data donation process to cover this lack of data sovereignty.

Therefore, we developed a concept and implementation empowering patients to make sovereign decisions

about donating their medical data to specific medical research projects. Our work comprises concepts of the

Medical Informatics Initiative, International Data Spaces, and MY DATA Control Technologies with new

specific elements combining these components. This approach of patient empowerment enables a new kind

of data sovereignty in the medical research domain.

1 INTRODUCTION

When considering the restriction of data usage and

access by an individual or company, then we enter the

scientific field of data sovereignty. Being sovereign

as an individual means being able to determine which

entities have access to one’s own data and how this

data may be processed. Furthermore, the current

regulation in Europe dictates that individuals must be

informed about storing and processing their personal

data (European Parliament and Council of European

Union, 2016). Additionally, individuals must

explicitly give consent to each specific usage of their

medical data. However, donating medical data for

cutting-edge research is essential. For instance, the

exploration of large amounts of data with machine

learning methods results in some completely new

https://orcid.org/0000-0003-0844-3722

https://orcid.org/0000-0002-5837-8730

https://orcid.org/0000-0003-4109-8641

https://orcid.org/0000-0001-8439-3697

https://orcid.org/0000-0001-7510-622X

research approaches (Specht-Riemenschneider &

Radbruch, 2021), but legal consent represents a

challenge (Ohmann et al., 2017).

The Medical Informatics Initiative provides a first

text-based template for patient consent forms

(Medical Informatics Initiative, 2020) that is based on

broad consent concepts (Bild et al., 2020; Caulfield &

Kaye, 2009; Sheehan, 2011), especially for medical

research, which serves as a step to simplify the

process of donating medical data. Therefore, patients

who want to donate their medical data to the medical

research can consent into these forms. Both medical

researchers and patients obtain clarity on how

personal medical data is permitted to be used for

further research due to the expressed information of

the consent forms. In this paper, we extend the broad

consent model and give patients additional freedom

Lauf, F., Felde, H., Klötgen, M., Brandstädter, R. and Schönborn, R.

Sovereignly Donating Medical Data as a Patient: A Technical Approach.

DOI: 10.5220/0010880800003123

In Proceedings of the 15th International Joint Conference on Biomedical Engineering Systems and Technologies (BIOSTEC 2022) - Volume 5: HEALTHINF, pages 623-630

ISBN: 978-989-758-552-4; ISSN: 2184-4305

 2022 by SCITEPRESS – Science and Technology Publications, Lda. All rights reser ved

623

in decision-making. We present a mechanism that

allows patients to decide individually for which

research projects their medical data will be donated.

Furthermore, to ensure that an individual’s choice

of whether data transfer is permitted or prohibited, we

enforce data use and access policies in a technical

manner using International Data Spaces technology

(IDSA, 2019). Using specific connectors, the related

architecture dictates the conditions of securely

transferring data for use and access. Thus, our

research objective comprises a linking of separated

concepts to design a trustworthy donation system for

medical data and individual data sovereignty. We

contribute to foster the involvement of patients in data

donating processes and propose a technical system to

realize this patient’s empowerment. Consequently,

we define the following research questions (RQ):

RQ1: How can patients be technically empowered to

donate their medical data sovereignly to selected

medical research projects?

RQ2: What are important components for an

adequate implementation of such a concept?

The paper is structured as follows. In Section 2, we

discuss related works that we have included in our

conceptual approach. Data sovereignty of citizens,

work of the Medical Informatics Initiative including

the SMITH Service Platform, and International Data

Spaces technology with embedded usage control are

the pillars of our research. We integrated these

previous works into our approach for donating

medical data. Hence, we describe our concept in

Section 3. Subsequently, the appropriate

implementation is presented in Section 4. Afterward,

in Section 5, we discuss our implemented concept.

Finally, we outline our research in Section 6 and point

out further research to create a comprehensive tool for

patients to donate their own medical data.

2 RELATED WORK

This section describes the works related to our

research into sovereign donation of medical data.

2.1 Data Sovereignty of Citizens

We understand data sovereignty as a subdomain of

digital sovereignty that puts the asset ‘data’ in the

spotlight (Adonis, 2019; Couture & Toupin, 2019;

Otto, 2016). Furthermore, we state that data

sovereignty of citizens is a means to comply with the

informational self-determination required by the

German legislator because the relevant data constitute

personal data (European Parliament and Council of

European Union, 2016; Steinmüller et al., 1972). In

addition, personal data comprises data that is created

by and about an individual (World Economic Forum,

2011). Overall, we interpret the term data sovereignty

as the knowledge and control of who can access an

individuals’ data and where this data is transferred

(Posch, 2017).

However, insights into the data sovereignty of

citizens show the lack of current solutions to share

one’s data in a self-determined way due to the

inadequate abilities of citizens to make sovereign

data-sharing decisions. However, the Digital Life

Journey describes the digitized lives of citizens and

addresses several areas being included in a holistic

approach of citizens’ data sovereignty (Meister &

Otto, 2019). Initial use cases such as the project

DaWID demonstrate how citizens can sovereignly

participate in data ecosystems with their own personal

data (Lauf et al., 2021).

2.2 Medical Informatics Initiative and

SMITH Service Platform

The Medical Informatics Initiative (MII) aims at

optimizing healthcare through providing

interoperable primary care data for clinical and

medical research (Semler et al., 2018), according to

the FAIR data principles (Wilkinson et al., 2016).

Each university hospital in Germany establishes a

Data Integration Center (DIC), thus ensuring

organizational, regulatory, and functional

prerequisites while addressing interoperability and

(re-)usability of data (Winter et al., 2018). During

their treatment, patients can give consent for their

data to be used in future research projects. Afterward,

researchers can find and identify patient-related data

and request data sets in a cross-organizational

workflow, the Data Use and Access (DUA) process,

thus addressing findability and accessibility of data.

The national commitment to a legal broad consent

is a fundamental achievement of the MII (Medical

Informatics Initiative, 2020), allowing for patient-

related data to be processed and used in a determined

and limited research context. Thus, the broad consent

forms the basis and the first level of agreement to

future secondary-purpose data usage given by each

patient. Yet, it does not support transparency and

consenting to specific research projects or a

horizontal or vertical selection of data sets by

patients. Therefore, the DUA process provides a

second level of consent (Klötgen et al., 2021),

realized as a vicarious and project-specific agreement

based on individual regulations of the DICs.

HEALTHINF 2022 - 15th International Conference on Health Informatics

624

The SMITH consortium develops the SMITH

Service Platform (SSP), which provides common use

cases and user interfaces (UI) for all connected DICs,

such as the DUA process. Researchers submit a

project-specific data usage proposal through the SSP,

and the Data Use and Access Committee (UAC) of

each involved DIC decides whether the requested

data may be provided for the specific research project.

In the end, the researcher and each DIC conclude a

project-specific contract, allowing the requested data

sets to be provided by the SSP. The DUA process is

realized as a distributed process with a central process

management (Klötgen et al., 2021), providing tasks

for the necessary process control and integration of

DIC’s subprocesses, components, and actors.

In order to manage consents and digital identities,

pseudonyms, and their relations, the MII consortia

establish Trusted Third Parties (TTP) as essential

building blocks of data processing workflows,

including protection, pseudonymization, and

anonymization of data. Many DICs will integrate the

‘generic Informed Consent Administration Service’

(gICS) as a tool to manage patients’ broad consents

(Rau et al., 2020). In this context, gICS allows

requesting data sets of all consenting patients and it

can be integrated into the real-time data processing

tasks of a DIC. Yet, gICS does not support patients in

constraining specific data donations for selected

medical research projects.

2.3 International Data Spaces

Numerous technologies exist that are capable of

transferring sets of data to a remote consumer. But

when it comes to organizational requirements, such

as privacy regulations, security requirements, and

legal contracting behind the technical process, the

scientific landscape becomes rather scarce on options.

The International Data Spaces (IDS) provide an

ecosystem for sharing data, which aims to cover all

the issues previously mentioned (IDSA, 2019). The

IDS Association (IDSA) provides standardized

policy negotiation and attested state-of-the-art

security guarantees, and it aims to provide usage

control for shared data. The IDS infrastructure has the

goal of letting data providers remain in control and

keep the ownership of their data even after the data

has been released to consuming parties.

The IDS consist of divisions, which focus on

sharing data for a certain domain, such as the Medical

Data Space. This medical-specific data space allows

scientists to share and regulate data being relevant for

https://camel.apache.org/ (last accessed: 2021/10/27)

health studies. Furthermore, participants

communicate via IDS Connectors (IDSA, 2019),

which serve as components for transferring data

among each other. These connectors are typically

attested using Trusted Platform Modules or Trusted

Execution Environments. Most IDS Connectors

contain Apache Camel

, which is an open-source

message routing framework (IDSA, 2019). Apache

Camel has more than 200 different protocol adapters

allowing to transform incoming and outgoing

messages across protocol boundaries. As a security

mechanism, each implementation of an IDS

Connector must regularly pass a certification, which

determines the level of trust and security achieved. In

the context of IDS, three different security levels exist

to handle ordinary communication as well as highly

confidential data flows. The set of minimal trust

levels and security requirements which need to be

guaranteed by an IDS Connector is defined in a so-

called IDS Policy. IDS Connectors must mutually

agree on IDS Policies which contain requirements for

security standards and rules for processing data flows.

Furthermore, IDS Policies result in so-called IDS

Contracts after successful negotiation. This

negotiation is a specific IDS process to deposit IDS

Contracts with IDS Policies on the recipient side

(Hosseinzadeh et al., 2020).

2.4 Usage Control

Usage control is a research field that deals with the

extension of traditional access control to enforce rules

on data even after their release. Eitel et al. gave a

suitable definition for the perspective of this topic:

“[Usage control] is about the specification and

enforcement of restrictions regulating what must

(not) happen to data. Thus, usage control is concerned

with requirements that pertain to data processing

(obligations) rather than data access (provisions).

Usage control is relevant in the context of intellectual

property protection, compliance with regulations, and

digital rights management.” (Eitel et al., 2021)

The idea of usage control was first formalized by

Park and Sandhu with their model of UCON-ABC,

which stands for usage control with definitions for

authorizations, obligations, and conditions (Park &

Sandhu, 2004; Sandhu & Park, 2003). By that time,

classical access control was the prevalent paradigm,

but it was unable to enforce access rights beyond the

first provision of a user’s access rights. For instance,

one of the first implementations of usage control in a

distributed system was proposed by Pretschner

Sovereignly Donating Medical Data as a Patient: A Technical Approach

625

(Pretschner et al., 2006). Afterward, the UCON-ABC

was incrementally improved, implemented numerous

times, and equipped with more expressive policy

languages such as XACML and additional

extensions, as it is the case for a tool like the MY

DATA Control Technology

. IDSA also deals with

usage control, defines standardized rules and a

corresponding policy language for implementing

such usage control mechanisms (Bader et al., 2020;

Eitel et al., 2021; Hosseinzadeh et al., 2020). For

instance, the previously mentioned MY DATA

Control Technology can be used to enforce the rules

in an IDS Connector.

3 CONCEPT

MII’s DUA process incorporates two levels of

agreement to data usage. Acting as the data owner, a

citizen provides a broad consent on the first level of

agreement, thus approving the usage of medical data

for the research in general. This enables researchers

to find patients’ data managed by the specific DIC for

usage within data use projects. Acting as the data

provider, the UAC of a DIC approves a researcher’s

data usage proposal and agrees or disagrees to the

usage of each patient’s data vicariously on the second

level of agreement. Due to the lack of transparency

and influence for citizens regarding specific data use

projects, we added a third level of agreement enabling

citizens to constrain the usage of their data in the

context of specific data use projects and thus,

strengthening patient empowerment and data

sovereignty. These three levels are represented in

Figure 1 and form the starting point of our work.

Our concept comprises components and systems

of the SMITH project such as SSP and DICs on the

one hand, and IDS technology such as IDS

Connectors and embedded usage control on the other

hand. Hence, in our concept, we combine existing

technologies from SMITH and IDS to create a portal

focusing on the participation of patients.

Figure 1: Levels of Agreement.

https://www.dataspaces.fraunhofer.de/de/software/usage-

control/mydata.html (last accessed: 2021/10/19)

Figure 2: Concept Overview.

Figure 2 shows an overview of our concept, and the

demonstrated scenario follows a chronological

sequence with 14 steps, marked in the illustration.

Firstly, patients agree in the MII broad consent to

donate their data for all interested medical research

projects at the doctor’s appointment, as described

before in the first level of agreement, and, in addition,

they gain personal login details for the patient portal

(0). After that, data is available, and researchers use

the SMITH Marketplace to provide a data usage

proposal containing a data query that is needed for the

appropriate research (1). The Data Sharing Services

component, acting as the central repository for data

use projects and connecting component for multiple

DICs, manage all workflow based interactions

between involved actors and provide all tasks

included in the DUA process (2). When a task

addresses a DIC, its Data and Metadata Transfer Unit

(DMT) is notified (3), which retrieves the necessary

information and triggers a local subprocess. Thus, the

UAC is able to manage and provide the individual

evaluation of a data usage proposal (4). When the data

use project is accepted, the Data Sharing Services

provide data provision tasks to the involved DICs in

the same way, and the requested data sets are sent to

the provider app within the IDS Connector instance

(5). Based on the research project conditions, an IDS

Policy is created (6) and negotiated with the

researcher’s IDS Connector (7). After the project

policy is deployed, patients may intervene. The

implemented patient portal shows project information

and corresponding data processing to the patients (8),

HEALTHINF 2022 - 15th International Conference on Health Informatics

626

so the involved patients gain insights into the

requesting projects and can decide to accept or to

reject the requested data transfer, which forms the

third level of agreement (9). The default setting

represents consent to the requesting project by using

the MII broad consent. If a patient rejects the data

transfer for a selected project, no data is sent to the

related researcher’s IDS Connector, and, as a result,

the researcher will not receive data from the declining

patient. Otherwise, after a period the requested data is

filtered using the IDS Policy (10) and subsequently

securely sent (11). Within the IDS Connector of the

researcher, data is also checked using the IDS Policy,

for instance, by checking valid time intervals for

usage and, after that verification, forwarded to the

consumer app (12). Hence, IDS mechanisms support

the enforcement of patient choices but transferred

data cannot be withdrawn by patients. After a defined

period for rejection, patient choices are final due to

the required researchers’ planning dependability.

Finally, the consumer app will display the requested

data to the researcher if the check of the IDS Policy

was valid (13).

Our objective is to improve the ability of patients

to be sovereign in their data donations for medical

research. By using the IDS Connectors, a technology

focusing on fair data sharing and sovereign

participants was chosen to achieve this objective.

Patients can intervene in the transfer of data for

specific research projects. Hence, patients can choose

which projects they want to support with their data.

This approach answers RQ1. A detailed description

of the used components is presented in the following

Section 4, answering to RQ2.

4 IMPLEMENTATION

A main objective of our work regarding usage control

is to empower patients to keep control of their

personal medical data. Another objective is to

consider the time span of requesting research projects

and to impose a time constraint on the visibility of the

data on the researcher’s side as an obligation, which

must be automatically enforced. Thus, data usage

control affects several steps in the process of

transferring data. First, a DIC checks the

authorization for accessing the patient data. This was

already implemented on DICs by UAC and is not part

of our implementation. After that and before sending

the data, the consent or refusal of patients is

Figure 3: Business Process Model of Implementation.

Sovereignly Donating Medical Data as a Patient: A Technical Approach

627

considered in the data sets. Subsequently, IDS

Policies are exchanged between IDS Connectors that

include the duration of the project so that no data will

be displayed after this time span. Figure 3 shows the

process that implements our concept.

For our prototypal implementation, we use

Trusted Connectors as a specialization of IDS

Connectors (Schütte et al., 2018), which are open

source and feature a high trust level. A Trusted

Connector is a runtime environment. Its core

component serves as a gateway for inbound and

outbound network requests and communication

between user apps running on it, for instance,

consumer and provider apps (Schütte et al., 2018).

Furthermore, MY DATA Control Technology is

integrated using Camel Interceptors

. A Camel

Interceptor is an integration pattern of the Apache

Camel framework with the purpose of interrupting the

original flow of messages and applying various

actions to the messages and data. In addition, we have

implemented connector apps on both the provider’s

side and the consumer’s side, whose functionality is

described in the following.

Starting on the provider’s side, see top left of

Figure 3, the provider app fetches the requested data

sets from the DIC’s storage. Those date sets are

expressed in HL7 FHIR

format, where a FHIR

Bundle

acts as a project, and FHIR Conditions

contained in a FHIR Bundle represent the medical

data of specific patients. Subsequently, patients can

view the available projects and their included own

medical data for donation in a UI within the patient

portal. Patients withdraw their consent for specific

projects or retain their consent by broad consent. The

authentication of patients in the patient portal is based

on the patient login details which they received at the

doctor’s appointment before. Furthermore, the IDS

Contracts with policies, which are generated by our

prototype, are ‘negotiated’ with the recipient over the

period of use, matching the requested duration of the

project. Patients have 14 days to withdraw their

consent. The prototype implements this mechanism

with a time-based event. After that, the provider

transforms the originally fetched data sets, filtering

out the medical data of patients who decided to

withdraw their consent. As next step, the provider

transmits the altered data sets —only after successful

IDS Contract negotiation—via the provider’s core

https://camel.apache.org/components/3.11.x/eips/intercep

t.html (last accessed: 2021/10/27)

https://www.hl7.org/fhir/ (last accessed: 2021/10/27)

https://www.hl7.org/fhir/bundle.html (last accessed:

2021/10/28)

component of Trusted Connector to the consumer’s

core component of another Trusted Connector.

The altered data sets are now arriving on the

consumer’s side. Since the data sets possess a unique

identifier as an attribute of the FHIR Bundle, they can

be referenced by the IDS Policies. Before the data is

passed to the consumer app, where the researcher will

be able to view the potentially altered data sets

tabularly in a UI, MY DATA Control Technologies

check the corresponding time-based rules for the

project. The rules are also checked before each

display in the UI, so the data will only be visible

within the consumer app for the duration of the

project and can also no longer be transferred within

the IDS Connector. In addition, the flow of messages

in the connector is defined by so-called Camel

Routes

. On these Camel Routes, the Camel

Interceptor is applied to control the flow of messages.

In summary, our implementation points out that a

close dovetailing between technology and contracts is

required. The IDS provide data exchange

mechanisms that guarantee a high level of policy

enforcement. These components are relevant for a

valid implementation of our concept, which answers

RQ2. Furthermore, our added elements, such as the

patient portal and the integration of three levels of

agreement, are also part of an answer to RQ2.

5 DISCUSSION

Our concept and implementation demonstrate

sovereign data donation in medical research.

Furthermore, our work provides benefits for all

participants in the data donation process. The results

could also be beneficial for future work towards a

European strategy for data spaces, since IDS provides

a potential foundation of Gaia-X (Otto et al., 2021).

Firstly, we show an opportunity for patients to

donate their medical data sovereignly by combining

existing technology with additional elements. This

result answers RQ1, defined in Section 1. Further,

using our patient portal leads to a sovereign patient

empowerment and fosters trust in donating medical

data. Providing patients with choices of specific

research projects for their medical donation

strengthens patients’ trust because of the secure

https://www.hl7.org/fhir/condition.html (last accessed:

2021/10/28)

https://camel.apache.org/manual/routes.html (last

accessed: 2021/10/28)

HEALTHINF 2022 - 15th International Conference on Health Informatics

628

implementation and enforcement of their individual

choices in a technical way by our developed system.

Secondly, our approach is based on data in HL7

FHIR format. Therefore, our work is interoperable

with several other existing medical tools and systems,

using the same international standard. Hence, our

work contributes to a comprehensive data availability

due to the interconnection of numerous data sources,

such as DIC or other medical and clinical data

storages. The implementation is based on components

by MII, SMITH, IDS, and MY DATA Control

Technologies, so we point out an interplay of these

different components. Therefore, by adding specific

new components, our concept implementation

approach responds to RQ2.

Finally, extending IDS technology with aspects

involving citizens moves the rather industrial focus

further to a more general application. So far, IDS have

been used mostly in corporate and scientific contexts.

Since our approach describes a patient embedding,

citizens can participate in data ecosystems from now

on. It must be noted that citizens do not use their own

IDS Connectors, but they can interact with a portal

allowing them to adjust data donation flows. These

settings are transformed into machine-readable

policies that are embedded into the IDS Connectors

of DICs and researchers. This procedure enables

citizens to participate in data donation in particular

and in data sharing processes in general. However,

there are still limitations on data usage for analysis

purposes in external systems. The policy enforcement

no longer exists if data leaves the IDS Connector, but

this does not relieve data consumers of their legal

obligations to comply with the contract. However,

there are two promising approaches enabling

technical enforcement. On the one hand, the

development of special IDS applications with

appropriate analysis functions embedded into the

Connector, and on the other hand, the extension of

existing applications with data usage mechanisms.

6 CONCLUSION AND OUTLOOK

We conceptualized and implemented an initial

approach, empowering patients to make sovereign

data-donating decisions. For this objective, we

combined the MII broad consent concept with

components from the IDS and MY DATA Control

Technologies to create new opportunities for patients

to control the use of their data. Our concept is based

on patients’ broad consent given during medical

treatment. Broad consent allows donating medical

data for medical research, but patients cannot choose

specific research projects. We argue that patients

must become more involved in the data donation

process for medical research. To this end, we

developed a system empowering patients to make

sovereign decisions about donating their medical data

to specific medical research projects. As a result, we

contribute to sovereign medical data donation

considering individual patients. Additionally, with

our system based on industrial technologies such as

IDS and MY DATA Control Technologies, we

contribute to (industrial) data ecosystems considering

not only companies but also individuals’ preferences.

Since we developed an initial prototype, our

research is limited in terms of application in common

practice. Further research should validate our

prototype with patients donating medical data and

researchers requesting medical data. Furthermore,

our approach can further enhance patients’ data

sovereignty, for instance, by enabling patients to

select specific data types for their donation to specific

medical research projects.

REFERENCES

Adonis, A. A. (2019). Critical Engagement on Digital

Sovereignty in International Relations: Actor

Transformation and Global Hierarchy. Global: Jurnal

Politik Internasional, 21(2), 262–282. https://doi.org/

10.7454/global.v21i2.412

Bader, S., Pullmann, J., Mader, C., Tramp, S., Quix, C., Müller,

A. W., Akyürek, H., Böckmann, M., Imbusch, B. T., Lipp,

J., Geisler, S., & Lange, C. (2020). The International Data

Spaces Information Model – An Ontology for Sovereign

Exchange of Digital Content. In J. Z. Pan (Ed.), Lecture

Notes in Computer Science: Vol. 12507. The Semantic Web

- ISWC 2020: 19th International Semantic Web Conference

(Vol. 12507, pp. 176–192). Springer.

https://doi.org/10.1007/978-3-030-62466-8_12

Bild, R., Bialke, M., Buckow, K., Ganslandt, T., Ihrig, K., Jahns,

R., Merzweiler, A., Roschka, S., Schreiweis, B., Stäubert,

S., Zenker, S., & Prasser, F. (2020). Towards a

comprehensive and interoperable representation of consent-

based data usage permissions in the German medical

informatics initiative. BMC Medical Informatics and

Decision Making, 20(1), 103. https://

doi.org/10.1186/s12911-020-01138-6

Caulfield, T., & Kaye, J. (2009). Broad Consent in Biobanking:

Reflections on Seemingly Insurmountable Dilemmas.

Medical Law International, 10(2), 85–100.

https://doi.org/10.1177/096853320901000201

Couture, S., & Toupin, S. (2019). What does the notion of

"sovereignty" mean when referring to the digital? New

Media & Society, 21(10), 2305–2322. https://doi.org/

10.1177/1461444819865984

Eitel, A., Jung, C., Brandstädter, R., Hosseinzadeh, A., Bader,

S., Kühnle, C., Birnstill, P., Brost, G., Gall, M., Bruckner,

Sovereignly Donating Medical Data as a Patient: A Technical Approach

629

F., Weißenberg, N., & Korth, B. (2021). Usage Control in

the International Data Spaces. Dortmund Berlin.

International Data Spaces Association.

European Parliament and Council of European Union. (2016).

Regulation (EU) 2016/679. https://eur-lex.europa.eu/legal-

content/EN/TXT/ ?uri=OJ:L:2016:119:TOC

Hosseinzadeh, A., Eitel, A., & Jung, C. (2020). A Systematic

Approach toward Extracting Technically Enforceable

Policies from Data Usage Control Requirements. In

Proceedings of the 6th International Conference on

Information Systems Security and Privacy (ICISSP 2020)

(pp. 397–405). https://doi.org/

10.5220/0008936003970405

IDSA. (2019). Reference Architecture Model: Version 3.0 |

April 2019. International Data Spaces Association.

https://internationaldataspaces.org/use/reference-

architecture/

Klötgen, M., Fiege, E., & Houta, S. (2021). Concept and

Implementation of Data Usage Proposal Process Based on

International Standards in SMITH. Studies in Health

Technology and Informatics, 278, 171–179. https://

doi.org/10.3233/SHTI210066

Lauf, F., Scheider, S., Meister, S., Radic, M., Herrmann, P.,

Schulze, M., Nemat, A. T., Becker, S. J., Rebbert, M.,

Abate, C., Konrad, R., Bartsch, J., Dehling, T., & Sunyaev,

A. (2021). Data Sovereignty and Data Economy—Two

Repulsive Forces? Position Paper. Dortmund. Fraunhofer

Institute for Software and Systems Engineering ISST.

https://doi.org/ 10.24406/isst-n-634865

Medical Informatics Initiative. (2020). Template text for patient

consent forms. https://www.medizininformatik-

initiative.de/en/template-text-patient-consent-forms

Meister, S., & Otto, B. (2019). Digital Life Journey: Framework

for a self-determined life of citizens in an increasingly

digitized world (basic research paper). Dortmund.

Fraunhofer Institute for Software and Systems Engineering

ISST. https://doi.org/10.24406/ ISST-N-559377

Ohmann, C., Banzi, R., Canham, S., Battaglia, S., Matei, M.,

Ariyo, C., Becnel, L., Bierer, B., Bowers, S., Clivio, L.,

Dias, M., Druml, C., Faure, H., Fenner, M., Galvez, J.,

Ghersi, D., Gluud, C., Groves, T., Houston, P., . . .

Demotes-Mainard, J. (2017). Sharing and reuse of

individual participant data from clinical trials: Principles

and recommendations. BMJ Open, 7(12), e018647.

https://doi.org/10.1136/bmjopen-2017-018647

Otto, B. (2016). Digitale Souveränität: Beitrag des Industrial

Data Space. Munich. Fraunhofer Institute for Software and

Systems Engineering ISST. https://

doi.org/10.13140/RG.2.2.35125.68321

Otto, B., Rubina, A., Eitel, A., Teuscher, A., Schleimer, A. M.,

Lange, C., Stingl, D., Loukipoudis, E., Brost, G., Böge, G.,

Pettenpohl, H., Langkau, J., Gelhaar, J., Mitani, K.,

Hupperz, M., Huber, M., Jahnke, N., Brandstädter, R.,

Wessel, S., & Bader, S. (2021). Gaia-X and IDS. Berlin.

International Data Spaces Association.

https://doi.org/10.5281/zenodo.5675897

Park, J., & Sandhu, R. (2004). The UCON ABC usage control

model. ACM Transactions on Information and System

Security, 7(1), 128–174. https://doi.org/

10.1145/984334.984339

Posch, R. (2017). Digital sovereignty and IT-security for a

prosperous society. In H. Werthner & F. van Harmelen

(Eds.), Informatics in the Future (pp. 77–86). Springer.

https://doi.org/10.1007/978-3-319-55735-9_7

Pretschner, A., Hilty, M., & Basin, D. (2006). Distributed usage

control. Communications of the ACM, 49(9), 39–44.

https://doi.org/10.1145/1151030.1151053

Rau, H., Geidel, L., Bialke, M., Blumentritt, A., Langanke, M.,

Liedtke, W., Pasewald, S., Stahl, D., Bahls, T., Maier, C.,

Prokosch, H.‑U., & Hoffmann, W. (2020). The generic

Informed Consent Service gICS®: Implementation and

benefits of a modular consent software tool to master the

challenge of electronic consent management in research.

Journal of Translational Medicine, 18(1), 287.

https://doi.org/ 10.1186/s12967-020-02457-y

Sandhu, R., & Park, J. (2003). Usage control: A vision for next

generation access control. In International Workshop on

Mathematical Methods, Models, and Architectures for

Computer Network Security. Symposium conducted at the

meeting of Springer.

Schütte, J., Brost, G., & Wessel, S. (2018). Der Trusted

Connector im Industrial Data Space. Garching. Fraunhofer

Institute for Applied and Integrated Security AISEC.

https://www.aisec.fraunhofer.de/

content/dam/aisec/Dokumente/Publikationen/Studien_Tec

hReports/deutsch/IDS-Paper_Datensouveraenitaet.pdf

Semler, S. C., Wissing, F., & Heyder, R. (2018). German

Medical Informatics Initiative. Methods of Information in

Medicine, 57(S 01), e50-e56. https://doi.org/

10.3414/ME18-03-0003

Sheehan, M. (2011). Can Broad Consent be Informed Consent?

Public Health Ethics, 4(3), 226–235. https://

doi.org/10.1093/phe/phr020

Specht-Riemenschneider, L., & Radbruch, A. (2021).

Datennutzung und -schutz in der Medizin: Forschung

braucht Daten. Deutsches Ärzteblatt, 118(27-28), 1359-

1361. https://www.aerzteblatt.de/int/ article.asp?id=220270

Steinmüller, W., Lutterbeck, B., Mallmann, C., Harbot, U.,

Kolb, G., & Schneider, J. (1972). Grundfragen des

Datenschutzes. In Anlage zu BT-Drucks. VI/3826.

Wilkinson, M., Dumontier, M., Aalbersberg, I. J., Appleton, G.,

Axton, M., Baak, A., Blomberg, N., Boiten, J.‑W., Da Silva

Santos, L., Bourne, P., Bouwman, J., Brookes, A., Clark, T.,

Crosas, M., Dillo, I., Dumon, O., Edmunds, S., Evelo, C.,

Finkers, R., . . . Mons, B. (2016). The FAIR Guiding

Principles for scientific data management and stewardship.

Scientific Data.

Winter, A., Stäubert, S., Ammon, D., Aiche, S., Beyan, O.,

Bischoff, V., Daumke, P., Decker, S., Funkat, G., Gewehr,

J. E., Greiff, A. de, Haferkamp, S., Hahn, U., Henkel, A.,

Kirsten, T., Klöss, T., Lippert, J., Löbe, M., Lowitsch, V., .

. . Löffler, M. (2018). Smart Medical Information

Technology for Healthcare (SMITH). Methods of

Information in Medicine, 57(S 01), e92-e105.

https://doi.org/10.3414/ME18-02-0004

World Economic Forum. (2011). Personal Data: The

Emergence of a New Asset Class. Geneva, CH. http://

www3.weforum.org/docs/WEF_ITTC_PersonalDataNew

Asset_Report_2011.pdf

HEALTHINF 2022 - 15th International Conference on Health Informatics

630
