Multimodal Analysis of User-recipes Interactions

Emilija Georgievska

, Martina Stojanoska

, Sanja Mishovska

Tome Eftimov

and Dimitar Trajanov

Faculty of Computer Science and Engineering, Ss. Cyril and Methodius University, Skopje, Republic of North Macedonia

Computer Systems Department, Jožef Stefan Institute, Ljubljana, Slovenia

dimitar.trajanov@finki.ukim.mk

Keywords: Food, Recipes, Interactions, Recommendations.

Abstract: A good diet is essential for good health and nutrition, but also as a way of expressing and feeling good.

Culinary and food recommender systems are becoming increasingly popular at a time when people are facing

fast-paced lifestyles. In this paper, we are analysing interactions between users and recipes in order to make

food recommendations based on their previous behaviour which would result in higher personalization for

every single person. This also raises the question of whether people stick to what they know well or are open

to new suggestions, or do personal recommendations lead to more homogeneity.

1 INTRODUCTION

As technology advances and succeeds to rise above

its peak in plenty of industries, there is still space for

a big breakthrough in the food industry. For sure, it is

great to have a digital menu on your phone with a

single scan of a QR code, but what about food

recommendation systems? A recommendation

system with the possibility of generating good food

suggestions can revolutionize not only the food

industry but also people’s lives.

However, the food domain is not straightforward

or uncomplicated since it revolves around people and

their unique characteristics. To be successful, one

recommendation system needs to deal with numerous

features such as recipes, food ingredients, and their

mutual combination, nutritional values, and cooking

methods.

Following the factors that should be addressed

and the features that should be taken into

consideration, it is vastly complex to build a

recommendation system that does it all. There are

numerous types of food recommendation systems,

each with its features and focusing on different

https://orcid.org/0000-0001-9975-6649

https://orcid.org/0000-0002-7287-436X

https://orcid.org/0000-0002-0880-9205

https://orcid.org/0000-0001-7330-1902

https://orcid.org/0000-0002-3105-6010

problems. For instance, a recommender system that

focuses on the person’s behaviour and the food

industry.

What additionally complicates the development

of recommender systems is the concept of filter

bubbles. The term filter bubble suggests a situation

that means that every user on the Internet exists in its

universe of information where we receive

information based on our behaviour, knowledge, and

activities, neglecting the diversity of information that

we should be receiving (Bruns, 2019). Even in

environments where there are no recommender

systems, a large portion of the users tend to repeat

their eating patterns and habits. The presence of

recommender systems especially ones that are based

on previous user’s behaviour can furthermore lead to

homogenization (Aridor et al., 2020). The question is

while developing recommender systems should we

try to burst the bubble or give the user what he already

knows and likes (Amrollahi, 2019).

The whole idea behind recommender systems and

recommendations themselves lies behind the desire to

help people by assisting them in the decision-making

process and overcoming the load of available

Georgievska, E., Stojanoska, M., Mishovska, S., Eftimov, T. and Trajanov, D.

Multimodal Analysis of User-recipes Interactions.

DOI: 10.5220/0010902800003123

In Proceedings of the 15th International Joint Conference on Biomedical Engineering Systems and Technologies (BIOSTEC 2022) - Volume 5: HEALTHINF, pages 689-696

ISBN: 978-989-758-552-4; ISSN: 2184-4305

689

information (Trattner and Elsweiler, 2017). As in

everyday life, they are also a helping hand in e-

commerce and in classic commerce so the businesses

can bring their products as close as possible to the

needs of their customers (Schafer et al., 1999).

Recommender systems in the food industry are

becoming more relevant over the years and the

demand for them is increasing (Trattner and

Elsweiler, 2017).

In this paper, the focus is put on a single person’s

lifestyle and eating habits. By using multimodal

analysis of the users-recipes interactions the

recommendation models will be able to predict

possible future food choices, and with comparison

between the two, we will be able to tell if the results

acquired are similar or a complete match.

With the ubiquity of the Internet, individuals tend

to share everything in their lives nowadays, and food

recipes are not an exception. Currently, there are

many cooking websites, few clicks away from us on

the Internet, which provide various recipes and food

content (e.g., description, meal photos, cooking

videos, how-to guides), as well as useful functions for

searching and filtering.

The dataset used in this research is data from

Food.com, publicly available on Kaggle (Li, 2019).

Following the data, the main goal is to build a

system that can efficiently predict which recipe can

be of interest to a user by learning about the user’s

past choices and preferences and also adding diversity

to the recommendations This would minimize user’s

efforts to search through enormous databases of

recipes on websites, only to find ones that are not to

their liking.

2 RELATED WORK

Recommender systems have a core function to

recommend items that the user would actually take

into consideration (Ricci et al., 2011), with content

filtered recommendations that consider the user’s past

choices and preferences, or collaboratively filtered

recommendations that consider similar users and their

choices and interests (Shokeen and Rana, 2020).

Some researchers say that to give good food

recommendations, it is necessary to take into

consideration the quantity of the ingredients and also

the specificity of the ingredients in the recipes that the

user browsed or cooked (Ueda et al., 2014). Given

this, the algorithms often find similar recipes based

on overlapping ingredients, either treating each

ingredient equally or by identifying key ingredients.

(Geleijnse et al., 2011) built a version of a

personalized recipe recommendation system that

suggests recipes to users based on past food choices

and nutrition intake.

Though there are several choices, to our

knowledge, we chose a hybrid, multimodal approach,

which connects the previous history of recipe usages

for the user and also the ingredients contained, in

order to result in recommendations that are familiar

to the user, but also recommendations that

incorporate new various ingredients. Therefore, in

this paper, we do our first attempt to investigate how

good the recommendations can be if they are based

on the user's previous experience or as we like to say

food choices and preferences and the ingredients in

those food choices.

But in order to map the whole user’s history into

one piece, a specific approach is needed. If

interactions are mapped to a bipartite user-recipe

interaction graph, a recommendation problem can be

transformed into a link prediction problem (Li and

Chen, 2009). The constructed bipartite graph can

capture important information on the relationship

between the users and case recipes (Li and Chen,

2009). However, a weighted network is much more

informative than an unweighted one, so a lot of

techniques can be applied to determine the link's

weights (Zhou et al., 2007).

Even though low-dimensional node embeddings

in large graphs have been proven as useful in link

prediction problems as this one, a big deal of the

approaches require all of the nodes to be present

during embeddings training (Hamilton et al., 2017).

However, due to the low generalization to unseen

nodes of these approaches, they do not seem fit to

recommend problems. GraphSAGE and his

heterogeneous version HinSAGE, efficiently

generate node embeddings for previously unseen

data, where instead of training individual embeddings

for each node, a function that generates embeddings

by looking into the node’s local neighborhood is

learned (Hamilton et al., 2017).

On the other side of the story, in the last few years,

many meta-path-based algorithms are proposed to

carry out data mining tasks over HINs, including

similarity search, personalized recommendation, and

object clustering. In particular, the concept of meta-

paths, which connect two nodes through a sequence

of relations between node types, is widely used to

exploit rich semantics in HINs. Following the

example of the metapaths and their meaning, in this

particular research the metapath P1: U → R → U, will

mean that two users have cooked the same recipe,

whereas the metapath P2: R → U → R, will mean that

HEALTHINF 2022 - 15th International Conference on Health Informatics

690

a user has cooked two of the recipes. Metapath2Vec

is proven to capture better proximity properties,

semantics between different types of nodes and learn

better than other the algorithms which abandon

different node and edge types (Zhang et al., 2018).

3 DATA-SETS AND FEATURES

The data is crawled from Food.com which is one of

the largest online recipe sharing communities,

covering 18 years of activity (January 2000 to

December 2018).

There are three key parts in the data: recipes,

users, and interactions between them. For every

recipe there is detailed information such as the

ingredients that we need to prepare it, preparation

directions, categories added by users, and also the

nutrition facts of the given recipe. Also, for every user

there is information about the cooking techniques

encountered by the user, recipes interacted with and

rating to the recipes retrospectively.

The raw data consists of more than 180 thousand

recipes and 700 thousand user-recipe interactions

(reviews and ratings).

One very mitigating circumstance is that the data

mainly comes in 2 different formats, where the first

part of the data-sets are more natural with descriptive

textual attributes in natural English language and

other languages, that we use to understand and

analyse the data. The second part of the data-sets are

the same data-sets as the first, but pre-processed,

without missing values, and encoded textual

attributes to numeric attributes. These include

separate pre-processed data-sets for training, testing

and validating. This makes it very easy to use the pre-

processed data-sets directly as an input to algorithms.

All of the data-sets consist of comma-separated

values.

After analysing each one of the data-sets, there are

some interesting facts about the overall data: 231.637

recipes were published by 27.926 users, and most

recipes were published by the user with id: 89831

(3118 recipes). The average steps for making one

recipe are 9 steps, and there is a recipe with 145 steps.

The average ingredients for making a recipe are also

9 ingredients. Recipes that contain more than 25

ingredients are very rare. It is also shown that over the

years, users tend to change their lifestyle and interact

with healthier recipes.

4 METHODS

Using a multimodal approach, the first aspect that is

being considered is the temporal dimension of the

data with the help of the StellarGraph Python library

and the HinSAGE algorithm which is a heterogenous

extension of the GraphSAGE algorithm (CSIRO's

Data61, 2018).

The goal here is to predict if the interactions that

we know really occurred. For that purpose, the data is

divided in two parts using the first half of the data for

training and the second half of the data for testing the

models.

The second aspect focuses on future recipe

recommendations, instead of the ones that already

happened. First of all, we obtain recommendations

with similar ingredients based on text similarity, and

then recommendations based on the graph structure

with MetaPath2Vec (Dong et al., 2017).

4.1 Temporal Interaction Prediction

Since the main goal revolves around personal

recommendations, it is crucial to modify the data in a

way that the information within is captured correctly

and efficiently.

The nature of the data implies that there are two

distinct entities - users and recipes which are mutually

connected by interactions. The interaction can be a

rating or a review of a particular recipe which is

preceded by trying the same recipe. However,

although the users and recipes are connected, it is not

naturally implied that the users are mutually

connected or the recipes are mutually connected.

Because of this structure, a user-recipe network can

be created as a complex network which displays a

natural bipartite structure.

A bipartite graph is a graph whose vertices can be

split in two independent sets, where every edge

connects one vertex from the first set and one vertex

from the second set (Guillaume and Latapy, 2004).

Following the particular data, a bipartite graph

with two types of nodes (users and recipes) and edges

that correspond to user-recipe interaction can be

constructed. Besides that, a proper weighting method

is required so that the original information is captured

and retained (Zhou et al., 2007). All of the links have

the default weight of 1, which suggests that a link is

existent (note that if a link weights 0, it is not present

in the graph). Weighing the links by their existence

contributes more to the link-prediction problem in

graphs than weighing the links (note that a link is an

interaction) by the rating.

Multimodal Analysis of User-recipes Interactions

691

The first step towards constructing some kind of

structure that can be used for predictions was trying

out the NetworkX library X (Hagberg et al., 2008).

NetworkX is a Python software package that is used

to study, create and manipulate large complex

networks that may be represented in the form of

graphs, like this case. Adjacency matrix was created

with users on one side and recipes on the other side,

with a 1 on places where interaction took place, and 0

where it did not. This matrix later was fed into a

NetworkX graph. One drawback was that the matrix

was very sparse, and it required great computational

power for processing. Another drawback was that this

structure was successful only to the point where

predicting algorithms ought to be used. Many state-

of-the-art algorithms require a specific kind of graph

as an input, so they can thoroughly learn about the

graph and the relations it has.

The most suitable structures and state-of-the-art

prediction algorithms for building bipartite graphs

and link prediction problems are part of the

StellarGraph library, which offers an easy way to

discover and learn the patterns in the data and guide

towards good recommendations.

StellarGraph as a class for graph machine learning

offers an easy way for storing graph structure by

providing collection of nodes and collection of edges

which connect a source node to a target node. In order

to achieve and preserve the heterogeneity of the data,

a heterogeneous undirected StellarGraph is defined,

with users as the first and recipes as the second type

of the nodes.

Given a bipartite user-item interaction graph, we

can convert the recommendation problem in a link

prediction problem (Li and Chen, 2009).

Considering that, with the help of HinSAGE,

supervised link prediction is the next step towards

building a recommendation system. HinSAGE

supports representation learning, node

classification/regression and link

prediction/regression as the original GraphSAGE but

for heterogeneous graphs. Link prediction is one of

the most important research topics in the field of

graphs and networks. The primary goal of link

prediction is to discover pairs of nodes which are

likely to form a link in the future. Retrospectively, in

this research paper, given a pair of nodes, the goal is

to identify whether a link would or would not exist in

the future. But how can solving link-prediction

problems be of a service to the construction of

recommendation systems? Given the

recommendations obtained from the next section, the

HinSAGE model could predict the probability of a

link between a particular user and the

recommendation suggested.

The model has the following architecture: two-

layer HinSAGE model that takes labeled (user,

recipe) node pairs that correspond to a particular user-

recipe interaction and output a pair of node

embeddings for the user and recipe nodes. Then these

embeddings are fed into a link regression layer, which

concatenates them and turns them into a link

embedding. The newly constructed link embeddings

are passed through a link regression layer to obtain

the probability of a certain user-recipe node pair

existence. The entire model is trained end-to-end by

minimizing the root mean square error as the loss

function. The model’s ability to predict a certain user-

recipe interaction lies behind the manipulation of the

link’s weights and therefore simplifying the problem

as a binary classification problem.

As said before, all the existent links in the graph

have the default weight of 1. To balance the model,

non-existent links were generated and weight of 0

was given to them (a link between a user and recipe

has weight of 0 only if there was no interaction

between the pair). To treat the problem as a

classification problem, one more thing was done. The

results from the link regression layer were rounded

with a threshold of 0.5. If the result is below 0.5 –

there is no significant evidence that shows that there

is or will be an interaction between a pair of a user

and a recipe. Likewise, if the result is above 0.5 or 0.5

– there is evidence that leads the model to believe that

there is or will be an interaction between a pair of a

user and a recipe.

Following this principle, all of the known

interactions were divided by years, taking the first ten

years for training and the rest for testing (following

the 70:30 rule). Figure 1 shows that interactions are at

their peak in 2008 and thereafter begin to drop, owing

to people sharing less information and interacting

Figure 1: Interactions between users and recipes by years.

HEALTHINF 2022 - 15th International Conference on Health Informatics

692

with previously submitted recipes over time. This was

done to research more about the temporal ability of

graphs and how they change over time.

It is obvious that some people’s preferences and

choices change over time, along with the trend of a

healthier life that has been more present over the past

few years. All of this is visualized in Figure 2, from

which we can see how the consumption of olive oil is

increasing year after year.

Figure 2: Cooking Oil usage through the years.

By testing with the rest 30% of the data (from 2011

to 2018), the model had an accuracy of 0.828. The

accuracy led to a conclusion that the model gives

good results based on a user’s previous behaviour,

given the fact that over time people’s taste can

change. Given the model which can predict if there is

or will be an interaction between a user and a recipe

with an accuracy of nearly 0.828 shown on Figure 3,

the next part of the research is to find the right

algorithm for recipe recommendations. Then using

the model, we can test if the corresponding user

would take the recipe recommendation in

consideration. This can be done by testing if the

model predicts an interaction between the pair of user

and recipe in consideration.

Figure 3: Prediction if a future interaction will happen.

4.2 Future Recipe Recommendation

This aspect is completely different from the first one,

and it focuses on the future recipe recommendations.

It is implemented in 2 parts. The first one is done

using the ingredients as the primary tool for the

recommendations and the second one focusing on the

user’s previous behaviour. The reason behind trying

two different methodologies is to try and analyse the

concept of filter bubbles and how to burst them. The

goal behind every recommendation is to be of a user’s

taste but also try to stray of a straightforward personal

recommendation.

Additionally, it is expected that the following two

approaches give completely different results, so the

idea is to create a new, hybrid approach that would

take into account the habits of the user, but would also

add a new perspective and different

recommendations, thus bursting the filter bubble that

could happen.

4.2.1 Text Similarity Recommendations

The purpose of generating recommendations based

on text similarity leads to recipes that are ingredient-

wise to the ones that the user already interacted with.

The algorithm for generating recipe embeddings that

was taken into consideration was BERT (Devlin et

al., 2018). BERT stands for Bidirectional Encoder

Representations from Transformers. BERT learns

contextual relationships between words in a sentence

or text.

The goal here was to get recommendations based

on the recipe’s name - which almost always includes

the ingredients of the recipe. A sentence-transformer

BERT was chosen to get the embeddings for the

recipes with help of the raw recipes data-set. The raw

recipes data-set does not contain pre-processed data,

therefore all of the attributes for one recipe are textual

and not numeric, which is good for BERT to take

them as text and encode them by its rules. The text

similarity embeddings actually rely on the recipe’s

name, which in this case is highly productive because

of the way the recipes are named (e.g. arriba baked

winter squash Mexican style). As said, the recipe’s

name includes some of the ingredients (mostly the

key ingredients), the cooking technique (e.g. baked)

and other adjectives which additionally describe the

food recipe (e.g. Mexican food).

Large numbers of the recipes included in the data-

set had zero reviews and ratings - never seen recipes,

so they are not taken into consideration while

building the recommendation system based on text

similarity for better accuracy. Also, it is relevant to

mention that some of the recipes had rather strange,

creative (e.g. smells like Sunday chicken fricassee

with meatballs) names that may confuse the text

Multimodal Analysis of User-recipes Interactions

693

similarity model in the process of generating the

embeddings.

The newly generated recipes embeddings by text

similarity are then used for cosine similarity

calculation. In other words, there is a pairwise

comparison or cosine similarity between pairs of

recipes - each recipe compares with the rest of the

recipes. This computation is done on just one part of

the embeddings because of the big computation

power that is needed. Cosine similarity,

mathematically, measures the cosine of the angle

between two vectors in a multi-dimensional space, in

this context two recipes transformed into

embeddings. When plotted on a multi-dimensional

space, where each dimension corresponds to a word

in the recipe, the cosine similarity captures the

orientation (the angle) of the recipes. The cosine

similarity is advantageous because even if the two

similar recipes are far apart by the Euclidean distance

they could still have a smaller angle between them. If

the angle is smaller, the similarity will be higher and

otherwise.

After the cosine similarity is calculated, the

closest or the most similar recipes to a given one can

be found - based on the highest cosine similarity

score.

The recommendations from the text similarity

model, as expected, were not surprising. BERT using

text similarity shows a great focus on the key

ingredients of the recipe. If the recipe of interest was

a dessert for example, all of the recommendations

would also be desserts. Or if a recipe has chicken as

its key ingredient, then all of the recommendations

would also contain chicken, nevertheless if it is a

breakfast or lunch. It can be concluded that text

similarity would be a great deal if the goal is to

generate recommendations only based on an

ingredient of preference, but only to the point where

no other factors are taken into consideration.

4.2.2 Node Embedding Recommendations

The idea of generating recommendations based on the

whole graph is to find recipes that the user might like

based on the whole graph structure.

The algorithm that was chosen for generating

recipe embeddings in the process of creating

recommendations was Metapath2Vec along with

cosine similarity calculations.

As already described, the bipartite graph has a

simple structure, consisting of two types of nodes

(recipes and users) connected with a link that

represents an interaction. There are no connections

between two users or two recipes.

Given this structure, with the help of

Metapath2Vec and Word2Vec node embeddings

were generated. The Metapath2Vec model formalizes

meta-path based random walks to construct the

heterogeneous neighbourhood of a node and then

leverages a heterogeneous skip-gram model to

perform node embedding (Dong et al., 2017). The

Metapath2Vec algorithm includes 2 steps: First, Use

uniform random walks to generate sentences from a

graph. A sentence is a list of node IDs. The set of all

sentences makes a corpus. The random walk is

driven by a metapath that defines the node type order

by which the random walker explores the graph.

The random walks have fixed maximum length

and are controlled by the list of metapath schemas.

Second, the corpus is used to learn embedding vector

for each node in the graph. Each node ID is

considered a unique word/token in a dictionary that

has a size equal to the number of nodes in the graph.

The Word2Vec algorithm is used for calculating the

embedding vectors.

In this case, the metapath which defines the node

type order of the random walk consists of two

schemes which change the order of the nodes. To be

more precise, each metapath schema must start and

end with the same type of node (e.g. start and end with

a recipe or a user). In this particular case, there is a

scheme for a user to a recipe, ending with a user, and

from a recipe to a user, ending with a recipe. Schemes

that included a walk between the same type of nodes

(e.g., from a user to a user) weren’t taken into

consideration because of the graph structure which

states that there are no interactions between the same

type of nodes.

Given the newly constructed node embeddings,

cosine similarity was again used as a measure of

nodes similarity. Given a particular recipe node, the

top 10 similar nodes were considered to be the most

similar ones to that node. So in order to test the

previous hypothesis, explore more about the

difference between the two algorithms and to find the

possible link that connects them both, few

experiments were run.

The results from Metapath2Vec came back rather

different than the ones with the previous algorithm. It

was concluded that the most similar recipes to a

particular recipe, were more diverse and varied within

multiple types of meals (dessert, breakfast, lunch,

dinner), opposite to BERT that sticks to a same type

of meal, and almost same ingredients, making the

recommendation very similar to the past food choices

of the user.

HEALTHINF 2022 - 15th International Conference on Health Informatics

694

5 EXPERIMENTS AND RESULTS

Text similarity recipe recommendations for a lunch

come back as lunches with focus on the ingredients of

the recipe, whereas the results from the

Metapath2Vec vary among different types of meals

such as lunch, dessert, or dinner with no focus on the

ingredients whatsoever.

To test the previous assumptions, a few

experiments were conducted to compare the

recommendations from text similarity and node

embeddings. For this purpose, the following steps are

applied: Choose a random user, choose a recipe that

the user has interacted with, make text similarity

based recommendations for that recipe, make node

embedding recommendations for that recipe and last

check if text similarity recommendations and node

embedding recommendations overlap.

So, 100 random users were taken and for each of

them, a random recipe from the list of their

interactions was chosen. The next step was a

generation of 10 text similar recommendations and 10

node-embedding recommendations. The

recommendations were compared with each other,

and they didn't overlap in any of the cases, which

means that there is a difference between them.

Text similarity focuses on the words while node

embeddings are calculated based on the whole graph

structure, aka the user's previous behaviour.

However, this does not mean that we can overthrow

any of these approaches, but moreover gives an

opportunity to create a new, hybrid one that combines

the previous two. It is expected that by combining an

approach that focuses on a user’s past behaviour and

an approach that focuses on the ingredients, the filter

bubble that personal recommendations can create, can

easily be burst and a new perspective can be shown.

6 CONCLUSIONS

The overall goal of the whole research is to test

various approaches for making recipe

recommendations, and combine them into one hybrid

approach that takes the best of them.

To do so, we analyse user-recipe interactions from

two aspects, through future recipe recommendations

and through temporal interaction predictions.

In the first aspect after analysing the results from

the recipe recommendations, two conclusions were

derived. The recommendations based on node

embeddings are more diverse. For example, if you are

looking for a recommendation for a starter meal, the

recommender will offer a main course or a dessert

rather than a similar starter meal, whereas text

similarity as different approach focuses on the

ingredients and will offer similar starter meals or

meals that have similar ingredients. The text

similarity method would give great recommendations

for people who like to stay consistent with their food

choices and like to repeat the same food pattern and

ingredients. The approach with node embeddings

would give great recommendations for people who

like to try out new things and follow the food trends.

Furthermore, knowing that filter bubbles are not the

most desirable situation, the combination of these two

approaches would prevent their formation (Aridor et

al., 2020).

ACKNOWLEDGEMENTS

This work was supported by the Slovenian Research

Agency (research core funding programmes P2-

0098); the European Union's Horizon 2020 research

and innovation programme under grant agreement

863059 (FNS-Cloud, Food Nutrition Security) and

under grant agreement 101005259 (COMFOCUS).

REFERENCES

Ricci, F., Rokach, L., Shapira, B., Kantor, P. B. (Eds.).

(2011). Recommender Systems Handbook. Springer.

Ueda M, Asanuma S, Miyawaki Y, Nakajima S. (2014).

Recipe recommendation method by considering the

users preference and ingredient quantity of target

recipe. In: Proceedings of the international

multiconference of engineers and computer scientists,

vol 1.

Geleijnse, G., Nachtigall, P., van Kaam, P., Wijgergangs,

L. (2011). A personalized recipe advice system to

promote healthful choices. In: Proceedings of the 16th

International Conference on Intelligent User

Interfaces.

Li X., Chen H. (2009). Recommendation as link prediction:

a graph kernel-based machine learning approach In:

Proceedings of the 9th ACM/IEEE-CS Joint

Conference on Digital Libraries.

Zhou, T., Ren, J., Medo, M., Zhang, Y.-C. (2007). Bipartite

network projection and personal recommendation.

Physical Review E 76:046115.

Hamilton, W., Ying, Z., Leskovec, J. (2017). Inductive

representation learning on large graphs. In: Advances in

Neural Information Processing Systems.

Zhang, D., Yin, J., Zhu, X., Zhang, C. (2018).

MetaGraph2Vec: Complex Semantic Path Augmented

Heterogeneous Network Embedding. In PAKDD.

Springer.

Multimodal Analysis of User-recipes Interactions

695

Trattner, C., Elsweiler, D. (2017). Food recommender

systems: Important contributions, challenges and future

research directions.

Guillaume, J. L., Latapy, M. (2004). Bipartite structure of

all complex networks. In: Information processing

letters.

Devlin, J., Chang, M., Lee, K., Toutanova, K. (2018). Bert:

Pre-training of deep bidirectional transformers for

language understanding.

Hagberg, A. A., Schult, D. A., Swart, P. J. (2008).

Exploring network structure, dynamics, and function

using NetworkX. In: Proceedings of the 7th Python in

Science Conference

CSIRO's Data61 (2018). StellarGraph Machine Learning

Library. GitHub Repository. https://github.com/

stellargraph/stellargraph

Dong, Y., Chawla, N. V., Swami, A. (2017). metapath2vec:

Scalable representation learning for heterogeneous

networks. In: Proceedings of the 23rd ACM SIGKDD

International Conference on Knowledge Discovery and

Data Mining.

Bruns, A. (2019). Filter bubble. Internet Policy Review

[Internet].

Aridor, G., Goncalves, D., Sikdar, S. (2020).

Deconstructing the filter bubble: User decision-making

and recommender systems. In: Fourteenth ACM

Conference on Recommender Systems.

Amrollahi, A. (2019). Burst the Filter Bubble: Towards an

Integrated Tool. In: 30th Australasian Conference on

Information Systems.

Schafer, J.B., Konstan, J. Riedl, J. (1999). Recommender

systems in e-commerce. In: Proceedings of the 1

ACM

conference on Electronic Commerce.

Shokeen, J., Rana, C. (2020). A study on features of social

recommender systems. Artificial Intelligence Review

53(2): 965–988

Shuyang Li. (2019, August) Food.com, Recipes and

Interactions, Version 2. Retrieved March, 2021 from

https://www.kaggle.com/shuyangli94/food-com-

recipes-and-user-interactions

HEALTHINF 2022 - 15th International Conference on Health Informatics

696
