Machine Learning-based Study of Dysphonic Voices for the

Identification and Differentiation of Vocal Cord Paralysis and Vocal

Nodules

Valerio Cesarini

, Carlo Robotti

, Ylenia Piromalli

, Francesco Mozzanica

Antonio Schindler

, Giovanni Saggio

and Giovanni Costantini

Department of Electronic Engineering, University of Rome Tor Vergata, Rome, Italy

Department of Otolaryngology - Head and Neck Surgery, University of Pavia, Pavia, Italy

Department of Clinical Sciences and Community Health, University of Milan, Milan, Italy

Department of Biomedical and Clinical Sciences, L. Sacco Hospital, University of Milan, Milan, Italy

francesco.mozzanica@unimi.it, antonio.schindler@unimi.it, saggio@uniroma2.eu, costantini@uniroma2.eu

Keywords: Machine Learning, Voice Analysis, Dysphonia, CFS, SVM, Biomarkers, MFCC, Energy, Shimmer, Vocal

Cords, Vocal Folds, Nodules, Paralysis.

Abstract: Dysphonia can be caused by multiple different conditions, which are often indistinguishable through

perceptual evaluation, even when undertaken by experienced clinicians. Furthermore, definitive diagnoses are

often not immediate and performed only in clinical settings through laryngoscopy, which is an invasive

procedure. This study took into account Vocal Cord Paralysis (VCP) and Vocal Nodules (VN) given their

perceptual similarity and, with the aid of euphonic control subjects, aimed to build a framework for the

identification and differentiation of the diseases. A dataset of voice recordings comprised of 87 control

subjects, 85 subjects affected by VN, and 120 subjects affected by VCP was carefully built within a controlled

clinical setting. A Machine-Learning framework was built, based on a correlation-based feature selection

bringing relevant biomarkers, followed by a ranker and a Gaussian Support Vector Machine (SVM) classifier.

The results of the classifications were promising, with the comparisons versus healthy subjects bringing

accuracies higher than 98%, while 89.21% was achieved for the differentiation. This suggests that it may be

possible to automatically identify dysphonic voices, differentiating etiologies of dysphonia. The selected

biomarkers further validate the analysis highlighting a trend of poor volume control in dysphonic subjects,

while also refining the existing literature.

1 INTRODUCTION

1.1 A Background on Dysphonia

Dysphonia can be defined as a qualitative and/or

quantitative alteration of voice production, which can

represent the result of several pathological conditions.

Approxilmately 10% of the general population may

experience dysphonia at least once in a lifetime

https://orcid.org/0000-0002-8305-3604

https://orcid.org/0000-0002-2731-9754

https://orcid.org/0000-0003-3780-8129

https://orcid.org/0000-0003-2591-4063

https://orcid.org/0000-0002-8767-5179

https://orcid.org/0000-0002-9034-9921

https://orcid.org/0000-0001-8675-5532

(Martins et al., 2016). Dysphonia can be associated to

different clinical conditions with different levels of

severity. For example, a breathy voice could be

related either to vocal nodules (VN) or to vocal cord

paralysis (VCP), two forms of dysphonia which are

very common among the general population

(Mozzanica et al., 2015). However, while VN

generally represent the result of vocal abuse and

misuse, VCP can be related to more threatening

Cesarini, V., Robotti, C., Piromalli, Y., Mozzanica, F., Schindler, A., Saggio, G. and Costantini, G.

Machine Learning-based Study of Dysphonic Voices for the Identiﬁcation and Differentiation of Vocal Cord Paralysis and Vocal Nodules.

DOI: 10.5220/0010913800003123

In Proceedings of the 15th International Joint Conference on Biomedical Engineering Systems and Technologies (BIOSTEC 2022) - Volume 4: BIOSIGNALS, pages 265-272

ISBN: 978-989-758-552-4; ISSN: 2184-4305

265

conditions such as viral infections or even cancer

(Wang et al., 2020; Todisco et al., 2021). To better

assess the underlying etiologies of dysphonic

patients, diagnostic workups are conducted in clinical

environments following standardized guidelines

including objective and subjective evaluations

(Schindler et al., 2013; Mozzanica et al., 2017;

Robotti et al., 2019; Schindler et al., 2010). However,

such diagnostic procedures are usually carried out

later than the actual development of dysphonia.

Moreover, these exams are generally expensive (as

they require qualified healthcare professionals) and

potentially invasive like a laryngoscopy (Maher et al.,

2019).

1.2 State-of-the-Art for Machine

Learning-based Speech Analysis

In recent years there has been a growing interest in

the development of methods for automatic diagnosis

and screening of dysphonia only using vocal

recordings of patients. This type of diagnosis would

not only allow the detection of the pathology at an

early stage, but would also offer the chance of a

significantly cheaper and safer medical procedure.

A pre-diagnosis based on an automatic, AI-based

analysis of the speech signal has already been proven

to be feasible, predictably more reliably for

pathologies that directly affect the phonatory system,

but not strictly limited to that (Asci et al., 2021; Suppa

et al., 2021).

A review of papers on the topic published in 2019

(Sarika et al., 2019) showed that the most widely used

classification method appears to be that based on

Support Vector Machine (SVM) (Cortes and Vapnik,

1995), which is in line with the fact that it is a very

effective classifier for small datasets like the ones

encountered in the literature.

In a 2016 study (Forero et al, 2016), classification

using SVM provided better results than those based

on ANN and HMM, reaching an accuracy rate of

97.2%. However, the dataset used is rather small, and

all people with dysphonia due to nodules are female.

In a 2018 paper (Dankovičová et al., 2018), a

dataset consisting of 94 samples of objects with

dysphonia and 100 samples of healthy subjects was

used. The samples contained the vowels /a/, /e/, and

/u/, and an initial number of 1560 features (130 for

each vowel pitch), but only the vowel /a/ with

approximately 300 features, using an SVM classifier,

brought the best accuracy levels, the highest one

being 86.2% obtained with only male samples. Even

in the recent years, SVM has still proven itself as a

very accurate alternative to Deep Learning models for

reduced datasets of dysphonic voices (Costantini et

al., 2021).

Other studies report satisfactory results, but rarely

focus on the distinction between diseases in

classifying sick subjects. Our aim is to improve the

classification accuracy for the identification of

dysphonic conditions, starting from the collection of

a clean and homogeneous dataset, which will then be

processed with a problem-specific, fine-tuned

machine learning pipeline. Moreover, we also focus

on the distinction between VCP and VN as different

causes of dysphonia, and on a preliminary study on

pre- and post-treatment VCP and its effects on the

voice.

2 MATERIALS AND METHODS

2.1 Study Population

A total of 292 subjects, all over the age of 18, took

part in the study. Specifically, 120 subjects affected

by Vocal Cord Paralysis (VCP) and 85 subjects

affected by Vocal Nodules (VN) have been recruited

thanks to the collaboration with the Hospital of San

Matteo, Pavia. Of the VCP subjects, all recorded

before any treatment, 65 were female and 55 were

male, while the VN subjects counted 63 females and

20 males. 87 healthy control subjects of normal

weight, with no audible or diagnosed vocal

impairment were recruited from previous studies in

the University of Rome, Tor Vergata. They are

composed of 64 female and 23 male subjects, which

is approximately homogeneous to the distribution of

the sick subjects, especially for VN.

Healthy subjects will be referred to as “H”, pre-

treatment VCP will be “P1”, and VN will be “N”.

2.2 Voice Recording

Voice recordings have been performed in controlled

environment by trained personnel. Specifically,

hospital rooms that were as noise-free as possible

have been chosen, with each subject being alone in

the room with the recording personnel. Each subject

was asked to sit comfortably and vocalize the vowel

/a/ for at least 3 seconds without straining. The choice

of the specific vocal task was due to a compromise

between classification effectiveness (Suppa et al.,

2020), ease of recording for the subjects, and

neutrality of the larynx (Fant, 1960).

The recording hardware consisted in a Sennheiser

e835 dynamic microphone, with a cardioid polar

pattern, connected to a Zoom H4n hi-definition

BIOSIGNALS 2022 - 15th International Conference on Bio-inspired Systems and Signal Processing

266

digital recorder. Output files were mono .wav, with

16 bits of depth and a sampling frequency of 44100

Hz.

Each recording was checked on-site by the

personnel to make sure that no unexpected noises

occurred, with a particular attention to other voices.

Each sample was listened by ear by trained audio

engineers and voice experts.

2.3 Data Pre-processing

Three different binary classifications, also referred to

as comparisons, will be built from the collected

datasets. Two comparisons are focused on the

identification of a certain pathology, namely pre-

treatment VCP versus healthy subjects (referred to as

“P1 vs H”) and VN versus healthy subjects (“N vs

H”). A comparison between the two diseases is also

tackled (“P1 vs N”).

2.3.1 Audio Processing

All the audio files, which ultimately consisted of one

sample per subject in each class, were imported into

the Digital Audio Workstation REAPER (by Cockos)

for pre-processing. There, they endured a manual

segmentation to remove portions of non-spoken

signal at the beginning and at the end of the file.

Afterwards, they were normalized to 0dB peak

volume. Subsequently, a noise reduction algorithm

was applied using the “Spectral Denoise” plugin,

which is part of the iZotope® RX7 audio repair suite

(https://www.izotope.com/en/products/rx/features/sp

ectral-de-noise.html). The noise profile has been

“learnt” by the algorithm by evaluating silence-only

sections, and each file was listened to after the

processing, and verified as more intelligible than

before and without audible artifacts.

After noise reduction, each file was normalized

again and rendered in the same format as the original.

2.3.2 Feature Extraction

The normalized, noise-free audio files were then

transformed into data matrices by a feature extraction

process using OpenSMILE® by AudEERING

(Eyben et al., 2010).

It is a tool that allows for the automatic extraction

of an incredibly high amount of acoustic features,

depending on a “configuration” feature set. The one

chosen for this study is the INTERSPEECH

Computational Paralinguistic Challenge (ComParE)

2016 (Schuller et al., 2016). It extracts many

functionals of features spanning in the Energy and

Frequency domains as well as prosodic features),

Mel-frequency Cepstral Coefficients, or MFCC

(Bogert et al., 1963) and RASTA-PLP coefficients

(Hermansky and Morgan, 1994).

A total of 6373 features were extracted from each

file, and a data matrix (in .arff format) was created for

each comparison. As an example, the .arff file

necessary for the P1 vs H comparison had

120+87=207 rows, one for each subject, and 6374

columns, the last of which being the “class” label.

2.4 Machine Learning

All the learning algorithms have been applied to the

numeric data matrices extracted by OpenSMILE,

using the environment of Weka®, by the University

of Waikato (Eibe et al., 2016). As previously stated,

an automatic feature selection followed by a ranking

and manual selection of the top features precede the

SVM-based classification.

2.4.1 Feature Selection and Ranking

Data matrices first endured an automatic feature

selection procedure, in order to greatly reduce the

number of attributes in accordance with the principles

of the Curse of Dimensionality (Köppen, 2009). A

feature space of a much higher dimensionality than

the amount of labeled data will render such data as

sparse, which will drastically hinder the performances

of any statistical model. Although many “rules of

thumb” have been established, it is a currently

accepted principle to at least have less features than

the amount of data. Moreover, as stated by Zollanvari

et al. (Zollanvari et al., 2020), it is also important to

check for redundancy among the additional features

involved.

Thus, we opted to use an automatic method called

CFS – Correlation-based Feature Selection (Hall,

1999), which is based on a heuristic merit factor

which takes into account both the correlation between

a feature set and the class, and the redundancy among

features.

𝑀



𝑘∗𝑟







𝑘+𝑘

(

𝑘−1

)

∗𝑟





(1)

Where:

k I the number of features in the subset S

𝑟





is the average correlation between each

feature in the subset and the class.

𝑟





is the average cross-correlation between all

the features one with each other.

The optimal subset is selected with the aid of a

search method, which in our case was a Forward

Greedy Stepwise, which represented a good

Machine Learning-based Study of Dysphonic Voices for the Identiﬁcation and Differentiation of Vocal Cord Paralysis and Vocal Nodules

267

compromise between performance and computational

complexity.

Throughout all of our comparisons, the CFS

retained a number of features which was not

predictable, although always smaller than 3% of the

original number. Thus, a manual selection followed

in order to furtherly reduce the features to a number

that was always consistent. The algorithm of choice

was a wrapped Linear SVM Classifier, trained on a

single feature at a time. This way, the features were

ranked and then the top 50 were manually retained.

2.4.2 Classification

Reduced data matrices were used to train a Gaussian

SVM classifier. Support Vector Machines are

statistical classifiers which aim to find the optimal

hyperplane for linear separation of the data. As

already stated, SVM classifiers are often chosen for

audio classification tasks with complex relationships

due to them being well-generalized even with small

datasets (Srivastava and Bhambhu, 2010; Costantini

et al., 2010). They are based on the non-linear

separation obtained by the “kernel trick”, based on

Mercer’s theorem. The corresponding kernel function

for a Gaussian SVM is:

𝐾

(

𝑥,𝑦

)

=𝑒



‖

𝒙

𝟏

𝒙

𝟐

‖



)

For each pair of data points x

and x

The parameter γ represents the inverse weight of

the distance between two points: the higher it is, the

lower the importance of a single training example.

The SVM optimization is solved with the

Lagrangian Dual problem, which can also include a

regularization procedure that leads to a parameter C

(“Complexity”) penalizing classification errors,

according to the formula:

𝐶

𝑤





𝑛

max(0,1−𝑦



𝐻)







(3)

Where 𝐻=𝑤



𝑥−𝑏 represents the common

maximum margin hyperplane function, and with n

being the number of samples, x being the data vector,

𝑦



representing one of the two thresholds of the

binary classification (-1 and 1), w being the normal

vector to the hyperplane and b determining the offset.

A lower C value will result in less strict margins over

the separation plane: the parameter can be tuned to

prevent overfit.

For our specific study, the Gaussian SVM models

for each comparison have been tuned with different

values of γ and C. The classifier were calibrated,

according to Platt’s scaling method (Platt, 1999),

using a multinomial Logistic regressor. Thus,

formerly binary output predictions could be

transformed in a probability distribution over classes,

which also aided in the evaluation of the ROC curve

(Fawcett, 2006).

A 10-fold cross-validation has been employed to

evaluate the accuracy of the classifiers, by averaging

the test performances over each of the ten subsets.

Performance on each training example is evaluated

when the example is placed in the test subset. Figure

1 shows the steps of the whole pipeline.

Figure 1: Flowchart for the machine learning-based voice

analysis: from audio files to classification models.

3 RESULTS

The confusion matrices for each comparison are

presented in the following Table.

Table 1: Confusion matrices.

True Class

Classified as: P1 H

P1 119 1

H1 86

N H

N 83 1

H2 85

P1 N

P1 108 12

N 10 74

Classification accuracy percentages (abbreviated

as ACC) are displayed in Table 2 along with other

useful performance indicators. Specifically,

Sensitivity (Sens) and Specificity (Spec) are reported

along with the False Positive Rate (FPR). Sens and

BIOSIGNALS 2022 - 15th International Conference on Bio-inspired Systems and Signal Processing

268

Spec represent the True Positive Rate and the True

Negative Rate respectively, and can be calculated as

such:

𝑆𝑒𝑛𝑠 =

𝑇𝑃

𝑃𝑜𝑠

)

𝑆𝑝𝑒𝑐 =

𝑇𝑁

𝑁𝑒𝑔

)

𝐹𝑃𝑅 =

𝐹𝑃

𝑁𝑒𝑔

=1−𝑆𝑝𝑒𝑐

)

Where TP are the True Positives, TN the True

Negatives, FP the False Positives (negative subjects

classified as positive), Pos represents all the positive

subjects (TP+False negatives) and Neg all the

negatives (TN+FP). For each of our comparisons, the

first class in the order they appear in Table 1 is

considered as positive. Control subjects are always

negative, and, for the P1 vs N comparison, N are

considered as negative.

ROC curves have also been evaluated for each

classifier and are displayed in Figures 2, 3 and 4. The

area under the curve, or AUC, is reported in Table 2,

as well as the Cut-off point (CO) of each ROC curve.

Note that the AUC is generally considered as a more

general and reliable indicator for the performances of

a classifier, since it is an aggregate measure of

performance across all possible classification

thresholds. “Comp.” in the first column refers to

which comparison is being considered.

Table 2: Classification Performances.

Comp. ACC

Sens Spec FPR AUC CO

P1 vs H

99.03 0.99 0.99 0.01 0.99 1.00

N vs H

98.24 0.99 0.98 0.02 0.98 0.99

P1 vs N

89.21 0.9 0.88 0.12 0.95 0.91

3.1 Acoustic Features

The top ranked features, in the number of 50, are the

data on which the classifiers have been trained. Since

the very features can be fairly complex in terms of

descriptors. Considering that the most important

information is represented by the main trends in the

domains, a summary of the more prevalent acoustic

domains for each comparison is presented in Table 3.

Figure 2: ROC curve for the P1 vs H comparison.

Figure 3: ROC curve for the N vs H comparison.

Figure 4: ROC curve for the P1 vs N comparison.

Additionally, the top 5 features are presented, from

first to last, in the far-right column.

The abbreviation “std. dev” means Standard

Deviation, and “min” means Minimum. Loudness

refers to the Spectral Loudness Summation as a

weighted sum of the auditory spectrum (Anweiler and

Verhey, 2006). MFCC refers to Mel-Frequency

Cepstral Coefficients, which result from a discrete

cosine transform of the logarithmic mel-spectrum,

and identify a “frequency of frequency” useful to

describe pitch. A similar role is held by RASTA,

which refers to a RASTA-style bandpass filtering

applied to the log spectrum domain, and then applied

to a PLP (Perceptual Linear Predictive) processing

which involve the calculation of an all-pole model in

Machine Learning-based Study of Dysphonic Voices for the Identiﬁcation and Differentiation of Vocal Cord Paralysis and Vocal Nodules

269

Table 3: Trends in top ranked features.

Comp. Main

Domains

Top 5 Features

P1 vs H Energy,

Loudness,

MFCC

RMS Energy (delta),

osition of the mean

Loudness (delta), inter-

quartile range 1-2

RMS Energy (delta), 1-

ercentile

Loudness (delta), inter-

uartile ran

e 1-3

RMS Energy (delta),

ran

N vs H Energy,

Spectral

Variance,

Loudness

RMS Energy (delta), Root

quadratic mean

Spectral Slope (delta),

osition of the mean

RMS Energy (delta), 1-

ercentile

Spectral Slope (delta), 99-

ercentile

RMS Energy, range

P1 vs N MFCC,

RASTA,

Energy

2nd MFCC, mean of

risin

slo

RASTA Window 1, 1-

ercentile

RASTA Window 0, 1-

ercentile

RMS Energy (delta),

Relative min ran

RASTA-style Loudness,

ercentile

the transformed domain, followed by the calculation

of MFCC. So, a RASTA-style Loudness as it appears

in the 5

place for the P1 vs N comparison, is based

on a summation over a RASTA-filtered spectrum.

The Spectral Variance is used as an “umbrella term”

for features generally related to variations in the

spectrum. Includes Slope, Kurtosis, Skewness, Flux,

Harmonicity.

As an additional tool for visualizing the relative

value and the discrimination power of the selected

features, a sample radar plot for the first 20 features

is displayed in Figure 5. The reduced number of

features is due to visualization needs. The plots are

made by averaging each feature over all the instances

(subjects) and normalizing it with respect to the

“negative” class, which is always the second

according to the order found in Table 1. Each point in

the plot represents one feature, and two curves are

thus realized, the negative class always resulting in a

unit circle since it’s normalized by itself. Note that the

classifier performances are based on more

information than just the mean of the first 20 features.

Figure 5: Radar plot for the P1 vs H comparison. The darker

unit circle refers to the normalized H class.

4 DISCUSSION

Accuracies higher than 98% have been obtained for

the comparisons of dysphonic subjects versus

healthy-voiced subjects. This is quite promising

because it shows that an automatic distinction can

indeed be performed with the aid of the right features

and machine learning pipeline. On the other hand, the

lower accuracy for the P1 vs N comparison also

appears reasonable, as distinguishing between a

healthy and dysphonic voice is an easier task even in

phoniatric examinations. Specific attention has been

used in the recording environment and audio

segmentation, and specific feature selection

algorithms which we already tested extensively have

been employed in place of standardized subsets which

can be found in the literature (Saggio and Costantini,

2020). Although bias due to heterogeneity in the

subjects’ demographics is indeed possible, the

features were confronted with those typical of other

effects affecting the voice, like ageing or gender (Asci

et al., 2020).

The chosen classifier, namely a Gaussian SVM

with a logistic calibrator, has been selected basing on

the state-of-the-art, on previous experiments and on

the principle that it’s a very effective classifier for

reduced datasets. High AUC values show that the

models are indeed effective on the training set for

many threshold values.

From the observation of the features distribution

between classes, a general trend appears for sick

subjects with respect to non-dysphonic subjects. Both

P1 and N classes show a significantly higher variance

in RMS Energy, which could be consistent with a

“stale” quality of the voice and, especially, with a

BIOSIGNALS 2022 - 15th International Conference on Bio-inspired Systems and Signal Processing

270

certain lack of volume control that sick subjects may

experience. Thus, there is indeed a similarity in the

features that distinguish between VCP and healthy

subjects, and VN and healthy subjects. The latter

comparison appears to rely more on spectral

characteristics.

In fact, the differentiation of the two diseases does

not rely on the Energy domain, but it’s shown as

feasible basing mainly on RASTA-PLP filtering. This

is in line with some of our studies which show how

RASTA is a powerful tool for the identification of

complex characteristics in the voice (Cesarini et al.,

2021).

5 CONCLUSIONS

After building a polished dataset, a traditional

pipeline-based machine learning framework has been

established for the detection of VCP and VN versus

healthy control subjects, and the differentiation

between the two diseases. A feature selection helped

identify acoustic features as specific biomarkers for

each comparison, which were then used for the

training of SVM models. The classification results

show a very high accuracy in distinguishing patients

from healthy subjects, in fact the highest among

similar studies. A lower but still significant accuracy

was obtained for the differentiation between diseases.

This is in line with the complexity of the problem

when faced on a phoniatric point of view, and also

proves that a distinction can be made even when the

effects on the voice aren’t evident by ear. Energy-

level characteristics are used for the distinction of a

dysphonic voice from a healthy one, suggesting a lack

of voice volume control in dysphonic subjects, while

RASTA and Cepstral domains are relevant for the

differentiation of the diseases.

The whole framework would benefit from the

collection of more data, which is foreseeable since the

environment and collaborations are ongoing.

This kind of vocal analysis can be of great help in

the diagnostics of dysphonic diseases, especially

since currently used methods are often slow and

invasive. The automatic voice analysis as well as the

observation of acoustic features can also aid

phoniatric examinations, replacing or supporting

evaluations made by-ear. In this perspective, a more

thorough study of the selected features, possibly

refined by a bigger dataset, will help identifying the

best possible subsets, specific to each disease or

comparison. Moreover, automatic tools can be built

for on-site classification, helping in preliminarily

identifying different dysphonic conditions. Although

automatic voice analysis per se cannot substitute a

medical diagnosis, the possibilities offered by this

technology appear to be very wide and promising.

ACKNOWLEDGEMENTS

This study was supported in part by Voicewise S.r.l.,

and thanks to the precious collaborations of the

Hospital of San Matteo, Pavia, and of the University

of Rome Tor Vergata.

REFERENCES

Anweiler, A., Jesko L.V. (2006). Spectral loudness

summation for short and long signals as a function of

level. In: Journal of Voice, The Journal of the

Acoustical Society of America 119, 2919-2928 (2006)

Asci , F., Costantini, G., Saggio, G., Suppa, A. (2021).

Fostering Voice Objective Analysis in Patients with

Movement Disorders. In: Movement Disorders, vol. 36,

ISSN: 0885-3185

Asci, F., Costantini, G., Di Leo, P., Zampogna, A.,

Ruoppolo, G., Berardelli, A., Saggio, G., & Suppa, A.

(2020). Machine-Learning Analysis of Voice Samples

Recorded through Smartphones: The Combined Effect

of Ageing and Gender. In: Sensors (Basel,

Switzerland), 20(18), 5022.

Bogert, B.P., Healy, M.J.R., Tukey J.W. (1963). The

Quefrency Alanysis [sic] of Time Series for Echoes:

Cepstrum, Pseudo Autocovariance, Cross-Cepstrum

and Saphe Cracking, Proceedings of the Symposium on

Time Series Analysis (M. Rosenblatt, Ed) Chapter 15,

209-243. New York: Wiley.

Cesarini, V., Casiddu, N., Porfirione, C., Massazza, G.,

Saggio, G., Costantini, G. (2021). A Machine Learning-

Based Voice Analysis for the Detection of Dysphagia

Biomarkers, In: 2021 IEEE MetroInd4.0&IoT, 2021.

Cortes, C.; Vapnik, V.N. (1995). "Support-vector

networks" (PDF). In: Machine Learning.

Costantini, G., Casali, D., Todisco, M. (2010), “An SVM

based classification method for EEG signals”,

Proceedings of the 14th WSEAS international

conference on Circuits, 107–109.

Costantini, G., Di Leo, P., Asci, F., Zarezadeh, Z., Marsili,

L., Errico, V., Suppa, A., Saggio, G. (2021). Machine

learning based voice analysis in spasmodic dysphonia:

An investigation of most relevant features from specific

vocal tasks. In: BIOSIGNALS 2021. Vienna, Austria,

2021

Dankovičová, Z.; Sovák, D.; Drotár, P.; Vokorokos, L.

(2018). Machine Learning Approach to Dysphonia

Detection. Appl. Sci. 2018, 8, 1927.

Eibe, F., Hall, M. and Witten, I. (2016). The WEKA

Workbench. Online Appendix for Data Mining:

Practical Machine Learning Tools and Techniques,

Morgan Kaufmann, Fourth Edition, 2016.

Machine Learning-based Study of Dysphonic Voices for the Identiﬁcation and Differentiation of Vocal Cord Paralysis and Vocal Nodules

271

Eyben, F., Wöllmer, M., Björn Schuller, M. (2010).

openSMILE - The Munich Versatile and Fast Open-

Source Audio Feature Extractor, Proc. ACM

Multimedia (MM), ACM, Florence, Italy, ISBN 978-1-

60558-933-6, pp. 1459-1462, 25.-29.10.2010.

Fant, G. (1960). Acoustic Theory of Speech Production.

The Hague: Mouton.

Fawcett, Tom (2006). An Introduction to ROC Analysis In:

Pattern Recognition Letters. 27 (8): 861–874.

Forero M, L. A., Kohler, M., Vellasco, M. M., & Cataldo,

E. (2016). Analysis and Classification of Voice

Pathologies Using Glottal Signal Parameters. Journal

of voice: official journal of the Voice Foundation,

30(5), 549–556.

Hall, Mark A. (1999). Correlation-based Feature Selection

for Machine Learning. University of Waikato,

Department of Computer Science, Hamilton, NZ.

Hermansky, Hynek & Morgan, Nathaniel. (1994). RASTA

processing of speech. In: IEEE Transactions on Speech

and Audio Processing.

Köppen, Mario. (2009). The Curse of Dimensionality.

10.1007/978-0-387-39940-9_133.

Maher, D. I., Goare, S., Forrest, E., Grodski, S., Serpell, J.

W., & Lee, J. C. (2019). Routine Preoperative

Laryngoscopy for Thyroid Surgery Is Not Necessary

Without Risk Factors. Thyroid: official journal of the

American Thyroid Association, 29(11), 1646–1652.

Martins RH, do Amaral HA, Tavares EL, Martins MG,

Gonçalves TM, Dias NH. Voice Disorders: Etiology

and Diagnosis. J Voice. 2016

Moore, R., Lopes, J. (1999). Paper templates. In:

TEMPLATE’06, 1st International Conference on

Template Production. SCITEPRESS.

Mozzanica F, Ginocchio D, Barillari R, et al. (2016).

Prevalence and Voice Characteristics of Laryngeal

Pathology in an Italian Voice Therapy-seeking

Population. Journal of Voice. 2016 Nov;30(6):774.e13-

774.e21.

Platt, John (1999). "Probabilistic outputs for support vector

machines and comparisons to regularized likelihood

methods". In: Advances in Large Margin Classifiers. 10

(3): 61–74.

Saggio G, Costantini G (2020). Worldwide Healthy Adult

Voice Baseline Parameters: A Comprehensive Review.

Journal of Voice, ISSN: 0892- 1997

Sarika, H., Surendra, S., Smitha, R., Thejaswi, D.. (2019).

A Survey on Machine Learning Approaches for

Automatic Detection of Voice Disorders, In: Journal of

voice: official journal of the Voice Foundation.

Schindler, A., Mozzanica, F., Maruzzi, P., Atac, M., De

Cristofaro, V., & Ottaviani, F. (2013).

Multidimensional assessment of vocal changes in

benign vocal fold lesions after voice therapy. Auris,

nasus, larynx, 40(3), 291–297.

Schindler, A., Ottaviani, F., Mozzanica, F., Bachmann, C.,

Favero, E., Schettino, I., & Ruoppolo, G. (2010). Cross-

cultural adaptation and validation of the Voice

Handicap Index into Italian. Journal of voice: official

journal of the Voice Foundation, 24(6), 708–714.

Schuller, B., Steidl, S., Batliner, A.,Hirschberg, J.,

Burgoon, J., Baird, A.,Elkins, A.,Zhang, Y., Coutinho,

E., Evanini, K. (2016). The INTERSPEECH 2016

Computational Paralinguistics Challenge: Deception,

Sincerity and Native Language. 2001-2005. In:

INTERSPEECH, 10.21437/Interspeech.2016-129.

Smith, J. (1998). The book, The publishing company.

London, 2

edition.

Srivastava, Durgesh & Bhambhu, Lekha. (2010). Data

classification using support vector machine. In: Journal

of Theoretical and Applied Information Technology.

12. 1-7.

Suppa, A., Asci ,F., Saggio ,G., Di Leo, P., Zarezadeh, Z.,

Ferrazzano, G., Ruoppolo, G., Berardelli, A.,

Costantini, G. (2021). Voice Analysis with Machine

Learning: One Step Closer to an Objective Diagnosis of

Essential Tremor. In: Movement Disorders.

Suppa, A., Asci, F., Saggio, G., Marsili, L., Casali, D.,

Zarezadeh, Z., Ruoppolo, G., Berardelli, A., Costantini,

G. (2020). Voice analysis in adductor spasmodic

dysphonia: Objective diagnosis and response to

botulinum toxin. In: Parkinsonism and Related

Disorders, ISSN: 1353-8020

Todisco, M., Alfonsi, E., Arceri, S., et al. (2021). Isolated

bulbar palsy after SARS-CoV-2 infection. Lancet

Neurology 2021 Mar;20(3):169-170.

Wang, H.W., Lu, C.C., Chao, P.Z., Lee , F.P. (2020).

Causes of Vocal Fold Paralysis. Ear Nose Throat J.

2020 Oct 22:145561320965212. doi: 10.1177/

0145561320965212. Epub ahead of print.

Zollanvari, A., James, A.P. & Sameni, R. (2020). A

Theoretical Analysis of the Peaking Phenomenon in

Classification. J Classif 37, 421–434.

BIOSIGNALS 2022 - 15th International Conference on Bio-inspired Systems and Signal Processing

272
