Classiﬁcation and Direction Detection of Ambient Sounds on Microsoft

HoloLens to Support Hearing-impaired People

Beauclair Dongmo Ngnintedem

1 a

, Eric Mense

1 b

, Johannes R

uckert

1 c

and Christoph M. Friedrich

1,2 d

Department of Computer Science, University of Applied Sciences and Arts Dortmund (FHDO), Dortmund, Germany

Institute for Medical Informatics, Biometry and Epidemiology (IMIBE), University Hospital Essen, Essen, Germany

(beauclair.dongmongnintedem001, eric.mense001)@stud.fh-dortmund.de

(christoph.friedrich, johannes.rueckert)@fh-dortmund.de

Keywords:

Sensor Substitution, Hearing Loss, Ambient Sound Classiﬁcation, Sound Source Localization, Mixed Reality.

Abstract:

Hearing-impaired people are exposed to greater dangers in everyday life, due to the fact that they are not able

to perceive danger and warning signals. This paper addresses this problem by developing an application, that

could help by classifying and detecting the direction of ambient sounds using Microsoft HoloLens 2 devices.

The developed application implements a client-server architecture. The server-side REST-API supports not

only the classiﬁcation of sounds from audio ﬁles via deep-learning methods, but also allows the results of the

sound source localization to be saved and read. The sound source localization is performed by a Maix Bit mi-

crocontroller with a 6-channel microphone array. For the user integration and interaction with the application,

a 3D scene has been designed using Unity and the Mixed Reality Toolkit (MRTK). The implemented applica-

tion showcases how classiﬁcation and direction detection of ambient sounds could be done on the Microsoft

HoloLens to support hearing-impaired people.

1 INTRODUCTION

According to World Health Organization (WHO),

approximately 446 million

people suffer from dis-

abling hearing loss (Berra et al., 2020). To help

those people, the solution includes the development of

new supporting wearable technologies. The following

paper describes the development of an application,

which can be used for ambient sound source local-

ization and classiﬁcation on the Microsoft HoloLens

2 to support hearing-impaired people. Therefore, this

paper presents the development process of such an ap-

plication. The resulting application is a proof of con-

cept Mixed Reality (MR) application running on Uni-

versal Windows Plattforms (UWPs) such as Microsoft

HoloLens 2. The aim of the application is twofold: on

the one hand, the application records, saves, and clas-

siﬁes sounds from the surrounding environment and

presents the results on the 3D scene. On the other

https://orcid.org/0000-0002-8291-7124

https://orcid.org/0000-0003-2748-7958

https://orcid.org/0000-0002-5038-5899

https://orcid.org/0000-0001-7906-0038

https://www.who.int/health-topics/hearing-loss,

accessed 2021-11-26

hand, the results of the sound source direction de-

tection, which is performed with a microphone array,

are permanently queried and displayed on the scene.

Sound classiﬁcation is performed on a server using a

neural network. In Section 2 the fundamentals, in-

cluding a short overview of sensor substitution, Con-

volutional Neural Network (CNN) and some related

works will be described. After that, the design and

implementation of the UWP application will be de-

scribed in more detail in Section 3. The results of

an evaluation will be presented and discussed in Sec-

tion 4. Section 5 concludes the paper and gives some

insights about future works.

2 FUNDAMENTALS AND

RELATED WORKS

2.1 Sensor Substitution

Human beings have various senses at birth. These in-

clude seeing, hearing, touch, tasting, and smelling.

The organs responsible for these senses are the eye,

the ear, the skin, the tongue, and the nose. These

Ngnintedem, B., Mense, E., Rückert, J. and Friedrich, C.

Classiﬁcation and Direction Detection of Ambient Sounds on Microsoft HoloLens to Support Hearing-impaired People.

DOI: 10.5220/0010973500003123

In Proceedings of the 15th International Joint Conference on Biomedical Engineering Systems and Technologies (BIOSTEC 2022) - Volume 5: HEALTHINF, pages 857-863

ISBN: 978-989-758-552-4; ISSN: 2184-4305

857

organs function as sensors, enabling people to per-

ceive their immediate environment using only these

senses. A failure or disease of a sensory organ can

occur not only at birth, but also during the growing

process. This can lead to considerable problems in ev-

eryday life, leading to neurodegenerative diseases and

depression (Bach-y Rita and Kercel, 2003). Thanks

to scientiﬁc and technological progress, it is nowa-

days possible to compensate or treat a damaged or

diseased sensory organ by using sensor substitution

(Bach-y Rita and Kercel, 2003).

A failure of an organ does not affect the whole sense,

but only the part which is responsible for the transmis-

sion of the signal to the brain, as it is commonly the

case by the retina in the eye, or the Cochlea in the ear

(Bach-y Rita and Kercel, 2003). Besides, by sensor

substitution there is a possibility to replace a failed

sensor (sense) with another one, for example see-

ing by hearing, seeing by feeling and hearing (Deroy

and Auvrey, 2012), hearing by seeing and reading or

hearing by feeling or touching (Cie

sla et al., 2019).

To sum up, sensor substitution is about coupling an ar-

tiﬁcial receptor with the brain via a Human Machine

Interface in order to restore a lost sense. Here, in the

damaged organ, the signal perceived by the receptor

is transmitted directly to the brain, where impressions

are created. This is possible due to brain plasticity.

The term brain plasticity refers here to the ability of

the central nervous system to adapt itself when needed

by changing its structural organization and function.

This includes neurochemical, synaptic, receptor, and

neuronal structural changes (Bach-y Rita and Kercel,

2003).

2.2 Hearing Enhancement with

Augmented Reality

According to (Mehra et al., 2020), people with hear-

ing loss may carry more cognitive load to deal with

complex acoustic environments. They have to spend

more effort in order to fully understand speech in

these situations. The treatment of Hearing Loss (HL)

is commonly undertaken with hearing aids. This

can be described as a multichannel wide dynamic

range compression, which enhances the perception

of soft sounds while keeping louder sounds within

a comfortable range. However, hearing aids present

some considerable limitations. Firstly, sufﬁciently

increasing the intelligibility of speech in noisy en-

vironments may be challenging. Secondly, the cur-

rent hearing technologies seem not to always match

the user’s needs in complex everyday situations. The

most advanced devices provide only modest addi-

tional beneﬁts, even with additional features. Cur-

rent ear-centered, multi-microphone hearing aid solu-

tions have limited spacing between microphones, and

current state-of-the-art beamforming and machine-

learning technologies do not allow for the required

source separation and sound enhancement. This ear-

centric form factor also puts tight constraints on the

computation and memory resources available due to

limited battery capacity and power budget.

Due to the above-mentioned limitations, the authors

stated that there is a real need for new technologies

that would help hearing-impaired people by giving

them additional support in problematic listening sit-

uations. So, the authors suggest that an Augmented

Reality (AR) platform, which is described as an inter-

dependent hardware, software, and algorithmic sys-

tem consisting of a collection of constituent technolo-

gies, would give such additional support. According

to the authors, an AR platform can be a single de-

vice or a collection of interlinked wearable devices

working together, which could serve as a frontend to

current and future hearing solutions.

To help solve some problems of listening situ-

ations like the cocktail-party problem for example,

the authors introduced and described one potential

conﬁguration of an AR platform named AR hearing-

enhancing device, which combines AR glasses, cloud,

hearing aids, and input device.

Another way to support people with hearing loss

in problematic listening situations would be to give

real-time speech-to-text captioning displayed in the

AR glasses display system. This has been success-

fully demonstrated by (Slaney et al., 2020) with a mo-

bile accessibility app designed for the deaf and people

with hearing loss, where speech and sound are tran-

scribed to text and displayed on the screen.

To sum up, the authors stated that a combination of

multimodal egocentric sensing, a Machine Learning

(ML) backbone, and a socially acceptable form factor

point toward a future where an AR platform could be-

come the ideal choice to help overcome challenges in

compensating for hearing loss.

2.3 Support of Hearing-Impaired

People with Mixed Reality

To our knowledge, the present work is the ﬁrst to deal

with classiﬁcation and detection of direction of ambi-

ent sounds on Microsoft HoloLens to support hearing-

impaired people. However, two projects are related to

the sensor substitution, with the focus on ML, using

image classiﬁcation and object detection on the Mi-

crosoft HoloLens. In the ﬁrst one, a system for object

detection on the HoloLens to assist the blind has been

developed (Eckert et al., 2018). The approach here

WHC 2022 - Special Session on Wearable HealthCare

858

was similar to that of the present work. By this sys-

tem, using a speech command such as Scan or simply

the HoloLens Clicker enables the user to take a pic-

ture of all objects present in the ﬁeld of view and out-

put the results of object recognition as sound.

The second project deals with the direct use of Deep

Learning models on the Microsoft HoloLens 2

. In

that work, a MR application has also been imple-

mented, which allows the classiﬁcation of captured

images directly on the Microsoft HoloLens 2 using its

embedded chip. To perform classiﬁcation of the im-

age, a CNN model trained based on EfﬁcientNetB0

has been used.

2.4 Ambient Sound Classiﬁcation

Convolutional Neural Networks (Krizhevsky et al.,

2012) refer to a particular type of neural network that

has become widely used in computer vision for im-

age classiﬁcation or detection tasks. The success of

CNNs in image recognition and classiﬁcation has led

to their adoption for audio data classiﬁcation (Piczak,

2015).

Like classical neural networks, a CNN consists of in-

puts, hidden layers, and output layers. In CNNs, a

different number of convolutional layers come after

the input layer, depending on the network architec-

ture. For example, after the image matrix is passed

to the input layer it undergoes a sequence of opera-

tions named convolutions followed by dimension re-

duction (sub sampling), and the class or category of

the image is conveyed through a multilayer percep-

tron to the output layer. Any number of ﬁlters with

different ﬁlter masks can be used in the convolutional

layers. The ﬁlters extract features from the images

that are learned by the network throughout the train-

ing process. In the Sound Event Detection (SED)

ﬁeld, CNNs are used speciﬁcally for the classiﬁca-

tion of so-called Mel scaled spectrograms generated

from single audio ﬁles. There are also works ap-

plying advanced architectures from the Natural Lan-

guage Processing (NLP) ﬁeld, such as Bidirectional

Encoder Representations from Transformer (BERT)

(Devlin et al., 2019) for the same task. Increas-

ingly, attention-based mechanisms are added on top

of CNNs to form CNN-attention hybrids, which help

sound classiﬁcation because they better capture the

global context (Kong et al., 2020). These models

were also used in the DCASE 2021 challenge on de-

tection and classiﬁcation of sound events (Nguyen

et al., 2021b). (Gong et al., 2021) went further by

introducing Audio Spectrogram Transformer (AST),

https://github.com/doughtmw/

HoloLens2-Machine-Learning, accessed 2021-11-26

a convolution-free, purely attention-based model in-

spired by the success of such models in vision tasks,

which provides state-of-the-art performance on some

popular audio classiﬁcation datasets.

3 DESIGN AND

IMPLEMENTATION

In Figure 1 the architecture of the overall system is

shown. At the center of the system is the Microsoft

HoloLens 2 on which the implemented MR applica-

tion will be deployed. The user interacts with the ap-

plication through speech commands and by clicking

on conﬁgured buttons. The implemented MR applica-

tion accesses an implemented REST interface on the

server-side, that classiﬁes sounds recorded using the

embedded microphone on the Microsoft HoloLens 2

device. The reason for outsourcing the classiﬁcation

on a server is that the preprocessing of the recorded

clips currently cannot be done locally on the client.

Sound source localization is performed by the micro-

controller Maix Bit. The results from this will be

written to the ESP32 Thing via the Universal Asyn-

chron Receiver Transmitter (UART) interface and ﬁ-

nally sent by Bluetooth to a connected device. Di-

rect communication between the ESP32 Thing and

Microsoft HoloLens proved to be complex. Instead,

the data is read using the Android application from

(Mense, 2020) and sent to the server using the Repre-

sentational State Transfer (REST)-API.

3.1 Training of a Classiﬁcation Model

Ambient Sound classiﬁcation is the ﬁrst task the de-

veloped application should perform. To solve this

task, a classiﬁcation model is needed. For training, we

used the Environment Sound Classiﬁcation Dataset

(ESC-50) dataset (Piczak, 2015), which is a collec-

tion of 2000 audio clips grouped in 50 categories of

everyday sounds. Each clip was recorded with a sam-

ple rate of 44.1kHz in mono. The dataset provides

5 splits for comparable cross-validation. First, we

trained a CNN similar to the one in (Kumar et al.,

2018) from scratch, which only achieved a mean ac-

curacy of 71%, so we instead decided to focus on

state-of-the-art models for audio classiﬁcations. At

the time of writing, the best performing model on the

ESC-50 dataset is Audio Spectrogram Transformer

(AST)

(Gong et al., 2021). AST is a convolution-

free, purely attention-based model which reaches an

https://github.com/YuanGongND/ast, accessed

2021-11-25

Classiﬁcation and Direction Detection of Ambient Sounds on Microsoft HoloLens to Support Hearing-impaired People

859

Figure 1: Diagram of the technical architecture of the implemented application.

accuracy of 88.7% (ImageNet pre-training) and

95.6% (ImageNet and AudioSet pre-training) on

ESC-50. 5-fold cross-validation training was per-

formed for 25 epochs based on the splits provided

by the dataset, and based on a model pre-trained on

both ImageNet and AudioSet (Gemmeke et al., 2017),

making use of cross-modality transfer learning from

images to audio data. Table 1 summarizes the overall

achieved accuracies by the trained model from scratch

ESC50Net and the AST-architecture.

Table 1: Achieved accuracy (%) by ESC50Net and the AST-

architecture using cross-validation.

Fold ESC50Net AST

top1 acc. (%) top1 acc. (%)

1 71 94.75

2 67 98.25

3 71 95.00

4 77 96.25

5 69 95.00

Mean 71 95.80

3.2 Server-side Ambient Sound

Classiﬁcation

The ambient sound classiﬁcation is performed by a

Flask

(Grinberg, 2018) (version 1.1.2) application

https://palletsprojects.com/p/ﬂask/ accessed

2021-11-26

that was developed and hosted on the server. This is

due to the fact that the supporting libraries for audio

conversion have been missing on the HoloLens. The

Flask application provides a REST Interface, which

supports the client-server communication through

Application Programming Interface (API) endpoints.

For this application, four endpoints are needed:

1. POST /api/classiﬁer: Send audio ﬁles to the

server. The result contains the top 3 predicted

classes, including probabilities as JSON data.

2. POST /api/direction: Send sound localization

results from the Android App to the server.

3. GET /api/direction: Get the latest sound local-

ization results from the server as JSON data.

4. GET /api/amplitude: Get the maximum ampli-

tude value from the localization results as JSON

data.

In order to perform inference of received audio ﬁles

on the server, the best trained model is loaded into the

developed Flask application.

3.3 Detection of Direction of Sound

Detecting the direction of sound is made difﬁcult by

factors like reﬂection, polyphony, interference, and

non-stationary sound sources (Nguyen et al., 2021a).

Modern datasets used for sound event localization and

detection, like the one used in DCASE 2021 Task 3

(Politis et al., 2021), use either ﬁrst-order Ambisonics

WHC 2022 - Special Session on Wearable HealthCare

860

or microphone arrays for the recordings. To approach

this, we decided to go with a microphone array (see

Figure 2) with integrated direction detection.

Figure 2: Portability of the hardware used for sound direc-

tion detection.

The sound source localization is performed on a

Maix Bit

microcontroller with a microphone array.

The module includes 7 microphones of which 6 are

arranged in a circle around a central one. The micro-

phone module communicates with the Inter-IC-Sound

(I2S) protocol

. To provide a Bluetooth interface for

the localization data, a Sparkfun ESP32 Thing

is at-

tached to the Maix Bit via UART. The ESP32 Thing

forwards the UART data to a Bluetooth interface.

The above-mentioned hardware together with an An-

droid application for sound classiﬁcation and direc-

tion determination has been developed in (Mense,

2020). An image of the solution is displayed in Fig-

ure 2. This application was integrated as a proxy in

the developed version of the MR application, as the

data from the sound source localization could not be

read directly from the hardware using the MR appli-

cation. Figure 3 shows the results of the application

in a test.

3.4 User Interaction

To help the user in the interaction with the applica-

tion, a 3D scene was designed using the game en-

gine Unity and the MRTK

. The MRTK provides a

https://dl.sipeed.com/shareURL/MAIX/HDK/

Sipeed-Maix-Bit/Speciﬁcations, accessed 2021-11-25

https://wiki.sipeed.com/soft/maixpy/en/develop kit

board/maix bit.html, accessed 2021-11-25

https://github.com/sparkfun/ESP32

Thing, accessed

2021-11-25

https://docs.microsoft.com/en-us/windows/

mixed-reality/develop/unity/mrtk-getting-started, accessed

2021-11-26

Figure 3: Presentation of the result from direction determi-

nation. The direction of the sound is displayed as coming

from west-north direction in the middle.

set of components and features that accelerate cross-

platform development of MR applications

In this work, the version 2019.4.8f1 of Unity is used

in addition to the MRTK

(version 2.7.0).

The designed user interface is displayed in Fig-

ure 4. The most conﬁdent class of the top 3 predicted

classes is displayed with its probability and inference

time at the top. In the center, the direction of the loud-

est ambient sound is shown by a 3-dimensional arrow.

The buttons for starting and stopping the application

can also be triggered by voice commands.

While the application is running, an audio clip is

recorded and sent to the server every ﬁve seconds to

determine the class of the sound.

4 EVALUATION AND

DISCUSSION

In order to evaluate the performance of the imple-

mented application, several experiments were per-

formed. The experimental setup consisted of:

1. A Bluetooth speaker PPA401BT-B,

2. A smartphone Samsung Galaxy S20 FE,

3. A laptop Acer Aspire E5-573G,

4. The hardware device containing the Sparkfun

ESP32 Thing and Maix Bit, and

5. The module Maix R6+1 Microphone Array.

https://docs.microsoft.com/en-us/windows/

mixed-reality/mrtk-unity/, accessed 2021-11-26

https://docs.microsoft.com/en-us/windows/

mixed-reality/mrtk-unity/release-notes/

mrtk-27-release-notes?view=mrtkunity-2021-05, accessed

2021-11-26

Classiﬁcation and Direction Detection of Ambient Sounds on Microsoft HoloLens to Support Hearing-impaired People

861

Figure 4: Screenshot of the application running on the Microsoft HoloLens 2.

The speaker used as the sound source was placed

around the microphone array for the direction detec-

tion. Audio recording was done using the embedded

microphone on the devices.

For the experiments, a sound clip containing a mix

of several sound classes was played using the speaker,

which was placed in a distance d ≤ 1.5 meter left,

right, above and behind the microphone array or Mi-

crosoft HoloLens 2. Direction detection and sound

classiﬁcation were then performed both using the An-

droid application and the MR application. Classiﬁca-

tion and direction detection was performed 10 times

over the course of 50 seconds, the results for the direc-

tion detection are summarized in Table 2. During this

experiment, 40 inferences have been conducted on a

NVIDIA Titan Xp GPU with a mean preprocessing

and inference time of 308 ms.

Table 2: Direction detection results. Mean detection from

10 classiﬁcations for each direction.

Direction Result Expected Deviation

Right 82.5° 90° 7.5°

Front 346.5° 0° 13.5°

Left 279° 270° 9°

Behind 174° 180° 6°

Mean 9°

Similar to (Eckert et al., 2018) the voice command

recognition for the two conﬁgured commands “start

recording” and “stop recording” has been evaluated.

The results are shown in Table 3.

Table 3: Voice command recognition using the HoloLens.

Not

Command Recognized recognized Sum

start rec. 11 20 31

stop rec. 13 2 15

The direction detection works good in a lab sce-

nario, with a mean deviation of 9°. During exper-

iments in the wild, some problems of microphone-

arrays could be noticed. For example sound reﬂec-

tions on walls could deviate the direction detection.

Inference times are reasonable for a proof-of-concept

but overall, the latency of the classiﬁcation could be

improved if the preprocessing and inference could be

done on the HoloLens.

For the sound classiﬁcation, on the other hand, we

did not manage to reproduce the AST performance

on the development dataset. Possible reasons include

the microphone characteristics as well as the fact that

the sound was played using a speaker. To improve

the microphone performance, several microphones or

a 3D microphone (e.g., Ambisonics) could be used in

future works.

5 CONCLUSIONS

This paper described the implementation of a proof

of concept MR application providing classiﬁcation

and direction detection of ambient sounds on the Mi-

crosoft HoloLens 2 to support hearing-impaired peo-

WHC 2022 - Special Session on Wearable HealthCare

862

ple. While the results of the experiments leave room

for improvement, especially in terms of the sound

classiﬁcation, we are conﬁdent that future work can

build on this and improve the performance, for exam-

ple by using Ambisonics microphones.

REFERENCES

Bach-y Rita, P. and Kercel, W. S. (2003). Sensory sub-

stitution and the human-machine interface. Trends in

cognitive sciences, 7(12):541–546.

Berra, S., Pernencar, C., and Almeida, F. (2020). Silent

augmented narratives: Inclusive communication with

augmented reality for deaf and hard of hearing. Media

& Jornalismo, 20(36):171–189.

Cie

sla, K., Wolak, T., Lorens, A., Heimler, B., Skar

nski,

H., and Amedi, A. (2019). Immediate improvement

of speech-in-noise perception through multisensory

stimulation via an auditory to tactile sensory sub-

stitution. Restorative neurology and neuroscience,

37(2):155–166.

Deroy, O. and Auvrey, M. (2012). Reading the World

through the Skin and Ears: A New Perspective on Sen-

sory Substitution. Frontiers in Psychology, 3:457.

Devlin, J., Chang, M.-W., Lee, K., and Toutanova, K.

(2019). BERT: Pre-training of deep bidirectional

transformers for language understanding. In Proceed-

ings of the 2019 Conference of the North American

Chapter of the Association for Computational Lin-

guistics: Human Language Technologies (NAACL),

Volume 1 (Long and Short Papers), pages 4171–4186,

Minneapolis, Minnesota. Association for Computa-

tional Linguistics.

Eckert, M., Blex, M., and Friedrich, C. M. (2018). Ob-

ject Detection Featuring 3D Audio Localization for

Microsoft HoloLens - A Deep Learning based Sen-

sor Substitution Approach for the Blind. In Proceed-

ings of the 11th International Joint Conference on

Biomedical Engineering Systems and Technologies,

pages 555–561. SCITEPRESS - Science and Technol-

ogy Publications.

Gemmeke, J. F., Ellis, D. P. W., Freedman, D., Jansen,

A., Lawrence, W., Moore, R. C., Plakal, M., and Rit-

ter, M. (2017). Audio Set: An ontology and human-

labeled dataset for audio events. In Proceedings of the

IEEE International Conference on Acoustics, Speech

and Signal Processing (ICASSP 2017), pages 776–

780.

Gong, Y., Chung, Y.-A., and Glass, J. (2021). AST: Audio

Spectrogram Transformer. In Proc. Interspeech 2021,

pages 571–575.

Grinberg, M. (2018). Flask Web Development. O’Reilly

Media, Inc, 2nd edition.

Kong, Q., Cao, Y., Iqbal, T., Wang, Y., Wang, W., and

Plumbley, M. D. (2020). Panns: Large-scale pre-

trained audio neural networks for audio pattern recog-

nition. IEEE/ACM Transactions on Audio, Speech,

and Language Processing, 28:2880–2894.

Krizhevsky, A., Sutskever, I., and Hinton, G. E. (2012).

Imagenet classiﬁcation with deep convolutional neu-

ral networks. In Proceedings of the 25th Interna-

tional Conference on Neural Information Processing

Systems - Volume 1, NIPS’12, page 1097–1105, Red

Hook, NY, USA. Curran Associates Inc.

Kumar, A., Khadkevich, M., and F

ugen, C. (2018). Knowl-

edge transfer from weakly labeled audio using convo-

lutional neural network for sound events and scenes.

In Proceedings of the IEEE International Conference

on Acoustics, Speech and Signal Processing (ICASSP

2018), pages 326–330. IEEE.

Mehra, R., Brimijoin, O., Robinson, P., and Lunner, T.

(2020). Potential of augmented reality platforms to

improve individual hearing aids and to support more

ecologically valid research. Ear and hearing, 41

Suppl 1:140S–146S.

Mense, E. (2020). Sound classiﬁcation and direction deter-

mination with an Android App. Bachelor thesis, De-

partment of Computer Science, University of Applied

Sciences and Arts Dortmund, Germany.

Nguyen, T. N. T., Watcharasupat, K. N., Lee, Z. J., Nguyen,

N. K., Jones, D. L., and Gan, W. S. (2021a). What

makes sound event localization and detection difﬁ-

cult? insights from error analysis. In Proceed-

ings of the Detection and Classiﬁcation of Acous-

tic Scenes and Events 2021 Workshop (DCASE2021),

pages 120–124, Barcelona, Spain.

Nguyen, T. N. T., Watcharasupat, K. N., Nguyen, N. K.,

Jones, D. L., and Gan, W. (2021b). DCASE 2021

task 3: Spectrotemporally-aligned features for poly-

phonic sound event localization and detection. ArXiv,

abs/2106.15190.

Piczak, K. J. (2015). ESC: Dataset for environmental sound

classiﬁcation. In Zhou, X., Smeaton, A. F., Tian, Q.,

Bulterman, D. C., Shen, H. T., Mayer-Patel, K., and

Yan, S., editors, Proceedings of the 23rd ACM inter-

national conference on Multimedia - MM ’15, pages

1015–1018, New York, New York, USA. ACM Press.

Politis, A., Adavanne, S., Krause, D., Deleforge, A., Sri-

vastava, P., and Virtanen, T. (2021). A Dataset of

Dynamic Reverberant Sound Scenes with Directional

Interferers for Sound Event Localization and Detec-

tion. In Proceedings of the 6th Detection and Classiﬁ-

cation of Acoustic Scenes and Events 2021 Workshop

(DCASE2021), pages 125–129, Barcelona, Spain.

Slaney, M., Lyon, R. F., Garcia, R., Kemler, B., Gnegy, C.,

Wilson, K., Kanevsky, D., Savla, S., and Cerf, V. G.

(2020). Auditory measures for the next billion users.

Ear and hearing, 41 Suppl 1:131S–139S.

Classiﬁcation and Direction Detection of Ambient Sounds on Microsoft HoloLens to Support Hearing-impaired People

863
