TerrorMine: Automatically Identifying the Group behind

a Terrorist Attack

Alan Falzon and Joel Azzopardi

Department of Artiﬁcial Intelligence, Faculty of ICT, University of Malta, Msida, Malta

Keywords:

Terrorism, Data-mining, GTD, Machine Learning, Prediction, Clustering, Forecasting.

Abstract:

Terrorism is a problem that provokes fear and causes death internationally. The Global Terrorism Database

(GTD) contains a large number of terrorist attack records which can be used for data mining to help counter

or mitigate future terror attacks. TerrorMine employs AI techniques to identify perpetrators responsible for

terrorist attacks. Moreover, the effect of clustering beforehand is investigated, while also attempting to identify

new (unknown) terrorist organisations, and predicting future activity of terror groups. Several experiments are

performed. The Random Forest model obtains the highest Weighted F1-score when identifying responsible

perpetrators. Furthermore, upon clustering the data using Hierarchical Density-Based Spatial Clustering of

Applications with Noise (HDBScan) before classiﬁcation, training time is reduced by more than 50%. Various

techniques are used for the unsupervised identiﬁcation of whether a terrorist attack was carried out by an

unknown terrorist group. Nearest Neighbours gives the highest Macro F1-score when cross-validated. When

forecasting the future impact of the different terrorist groups, Prophet achieved an F1-score higher than that of

Autoregressive Integrated Moving Average (ARIMA).

1 INTRODUCTION

Terrorism refers to violent threats and acts aiming

to spread fear among targets, and impose ideas onto

a particular population (Jackson, 2018). It affects

tourism and in turn the national general economy. For

this reason, terrorism is one of the toughest challenges

faced worldwide (Tolan and Soliman, 2015).

One of the most notable attacks of all time is the

September 11 attack, more commonly known as ‘9/11

attacks’, committed by the Al Qaeda group in the

US in 2001. It caused almost 3000 deaths, spread-

ing tremendous terror

. While the average frequency

of terrorist attacks has slowly declined over time, the

impact of terrorist activity has increased mostly due to

mass media which reports terrorist activity and their

widespread condescending behaviour in a dramatised

fashion (Pfeiffer, 2012).

Data driven approaches can help counter-

terrorism efforts whereby data about past terrorist

attacks and related intelligence can be mined for

knowledge that can help prevent future attacks. The

https://abcnews.go.com/US/

20th-anniversary-911-nears-questions-anger-death-linger/

story?id=79606569 [Last Accessed: April 5th, 2022]

Global Terrorism Database (GTD)

is an excellent

source of such data and can be used to help train

models that automatically identify perpetrators

behind an attack or predict future terrorist activities.

Perpetrator identiﬁcation is one of the initial

counter-terrorism steps which lead to the prevention

of future attacks (Talreja et al., 2017). Tradition-

ally, the organisation responsible for a terrorist act

either claims responsibility or is discovered through

intelligence gathering activities such as email track-

ing, phone tracing or social network analysis (Talreja

et al., 2017). Such methods are cumbersome, require

specialised skill and dedicated hardware, and poten-

tially infringe on privacy rights. This reveals the need

for AI approaches to help in counter-terrorism work.

This paper aims to mine the GTD in order to dis-

cover knowledge that can help in counter-terrorism.

Other than perpetrator identiﬁcation, this work aims

to potentially ﬁll certain gaps such as the detection of

a newly formed terrorist group. The ability to tackle

such a problem would ultimately be useful to raise

warnings about threats by terrorist organisations.

The overall aim of this work is to contribute to the

efforts of counter-terrorism using a data-driven ap-

https://www.start.umd.edu/gtd/ [Last Accessed: June,

2022]

Falzon, A. and Azzopardi, J.

TerrorMine: Automatically Identifying the Group behind a Terrorist Attack.

DOI: 10.5220/0011540300003335

In Proceedings of the 14th International Joint Conference on Knowledge Discovery, Knowledge Engineering and Knowledge Management (IC3K 2022) - Volume 1: KDIR, pages 221-228

ISBN: 978-989-758-614-9; ISSN: 2184-3228

221

proach. The aim was achieved through the following

objectives:

• Automatically identifying the terrorist organisa-

tion responsible for a terrorist attack

• Investigating the effect of clustering on the terror-

ist group identiﬁcation

• Automatically discovering new terrorist groups

responsible for recent attacks

• Predicting the future activity of terrorist groups

2 LITERATURE REVIEW

This section consists of an overview of the various

research carried out in relation to the objectives spec-

iﬁed in Section 1. Section 2.1 provides an overview of

the Global Terrorism Database (GTD) while Sections

2.2, 2.3, 2.4 and 2.5 provide a review of literature re-

lated to each of the four objectives, respectively.

2.1 The Global Terrorism Database

(GTD)

The GTD, maintained by the National Consortium of

the START, is an open-source database that, at the

time of writing, contains data describing over 200,000

terrorist attacks that happened from 1970 until 2019.

For each terrorist incident, there are up to 120 vari-

ables including the date, location, information about

the target and weapons used, the number of casual-

ties, and the responsible group if identiﬁed (National

Consortium for the Study of Terrorism and Responses

to Terrorism (START), 2019).

Data from the GTD needs to be prepared by se-

lecting the subset of features considered to be im-

portant, handling missing data, scaling and encoding

data (Pag

an, 2010), (Laite et al., 2019). Feature se-

lection involves reducing the number of attributes to

be used by classiﬁcation models, as done by Pan us-

ing Extremely Randomised Trees (Pan, 2021). Var-

ious techniques are explored when it comes to han-

dling missing data, including Listwise Deletion and

Mode, Mean, Median, KNN and Multivariate Impu-

tation (Pag

an, 2010).

2.2 Objective 1: Automatically

Identifying the Perpetrator

This section provides a review of the literature related

to the automated identiﬁcation of the terrorist organ-

isation responsible for an attack. It tackles the vari-

ous encountered missing data techniques, feature se-

lection methods and classiﬁcation models.

Missing Data

The most frequently used technique to handle missing

GTD data is Listwise Deletion (Tolan and Soliman,

2015), (Pag

an, 2010), (Khorshid et al., 2015b), (Laite

et al., 2019). (Tolan and Soliman, 2015) compare

the performance of the Listwise Deletion technique

to that of Mode Imputation, arriving to the conclu-

sion that the former method performs better overall.

(Pag

an, 2010) compares Listwise Deletion to Mean

Imputation, Median Imputation and KNN Imputation

and reports that the best results were obtained using

the latter method.

Feature Selection

In order to perform classiﬁcation of the data found

in GTD, the features to be fed to the classiﬁcation

pipeline are most frequently hand-picked manually

(Pag

an, 2010), (Laite et al., 2019), (Khorshid et al.,

2015b). (Pan, 2021), (Peng, 2018) and (Talreja et al.,

2017) use automated approaches involving Extremely

Randomised Trees, a feature correlation matrix and

Factor Analysis of Mixed Data, respectively.

Classiﬁcation

The most frequent ML classiﬁers used on terrorist at-

tack data from GTD encountered in the performed

research include Decision Tree, Logistic Regression,

KNN, Naive Bayes and SVM. (Talreja et al., 2017),

(Mohammed and Karabatak, 2018), (Tolan and Soli-

man, 2015) and (Khorshid et al., 2015a) all imple-

ment and compare both the Decision Tree and SVM

classiﬁers. (Talreja et al., 2017) report that upon eval-

uating their different implemented models trained on

GTD data ranging from 1990 until 2014 and tested on

attacks that happened during 2015 where the location

is India, SVM resulted in the highest accuracy. (Peng,

2018) and (Diab, 2019) also implement the Decision

Tree and SVM ML models, respectively.

(Peng, 2018), (Tolan and Soliman, 2015) and

(Khorshid et al., 2015a) perform classiﬁcation using

KNN and Naive Bayes, with the former classiﬁca-

tion technique also being utilised by (Pag

an, 2010)

and (Mohammed and Karabatak, 2018). (Tolan and

Soliman, 2015) report that the KNN classiﬁer resulted

in the highest accuracy score. (Diab, 2019) applies

the Logistic Regression, SVM and Perceptron clas-

siﬁers for classiﬁcation and they use them to com-

pare the performance of Gradient Descent (GD) and

Stochastic Gradient Descent (SGD) on the classiﬁca-

tion of terrorist attacks with respect to the type of at-

tack based on textual data. They report that the best

KDIR 2022 - 14th International Conference on Knowledge Discovery and Information Retrieval

222

result was obtained when using the Perceptron classi-

ﬁer.

2.3 Objective 2: Exploring the Effect of

Clustering

As observed in the undertaken research, clustering is

used in various ways to improve the classiﬁcation pro-

cess. These include: the removal of outliers detected

through clustering, as done by (Meng et al., 2017); ﬁt-

ting a classiﬁer on each cluster during the classiﬁca-

tion phase, as performed by (Mathivanan et al., 2018);

and performing clustering to generate the cluster ID

of each record as an additional feature to be fed to

the classiﬁer, as implemented by (Alapati and Sindhu,

2016).

(Meng et al., 2017) use clustering as an unsuper-

vised approach to detect outliers in GDT data. The

ﬁrst approach is to consider all instances of a cluster

which is smaller than a speciﬁc threshold as outliers.

The second approach is to consider those instances

whose distance to their respective centroid is above a

threshold as outliers. The latter approach resulted in

a better classiﬁcation performance.

Focusing on the e-commerce domain, (Math-

ivanan et al., 2018) compare K-Means and Hierar-

chical clustering as means to improve classiﬁcation.

They report that while classiﬁcation performance was

not improved, the classiﬁcation process takes much

less time when preceded by Hierarchical clustering.

(Alapati and Sindhu, 2016) investigate the same two

clustering methods where the cluster ID resulting

from the pre-process is input to the ANN classiﬁer as

an additional ﬁeld. As opposed to the experiments

performed by (Mathivanan et al., 2018), their re-

sulting classiﬁcation accuracy is improved when pre-

ceded by clustering, with the highest increase result-

ing from hierarchical clustering before classiﬁcation

through ANN (Alapati and Sindhu, 2016).

2.4 Objective 3: Automatically

Discovering New Perpetrators

Novelty detection is commonly treated as an outlier

detection problem where outliers are considered to

be only present in new data (Pedregosa et al., 2011).

To date, we have not encountered systems that apply

these techiques to the terrorism domain.

The most frequently encountered novelty and out-

lier detection techniques include One-Class Support

Vector Machine (OCSVM), which is implemented by

(Spinosa and Carvalho, 2005); Autoencoder, which is

used by (Curia, 2020); Generative Adversarial Net-

work (GAN), as utilised by (Zenati et al., 2018) and

(Carrara et al., 2021); and Local Outlier Factor (LOF)

– used by (Alsawadi and Bilal, 2021).

(Spinosa and Carvalho, 2005) use OCSVM to per-

form novelty detection on medical data, where a data

point which falls outside the space enclosed by the hy-

perplane is considered to belong to an unseen class.

(Curia, 2020) performs outlier detection on terrorist

attacks from GTD as a means to predict whether an at-

tack is successful or not using a hybrid approach con-

sisting of an Autoencoder model and K-Modes clus-

tering. Autoencoder is a speciﬁc type of ANN which

encodes an input instance and decodes it back to its

original form. If the loss between the two instances is

greater than a threshold speciﬁed for each cluster of

data resulting from K-Modes clustering, then the in-

stance is considered an outlier, thus a successful ter-

rorist attack (Curia, 2020).

(Zenati et al., 2018) and (Carrara et al., 2021)

combine an Autoencoder with a GAN to perform

anomaly detection. GANs are specialised types of

ANNs made up of a Generator and a Discriminator.

The Generator is responsible of generating fake data,

while the Discriminator is responsible of determining

whether data is real or generated when fed both types

of data. When the GAN is used as an outlier detector,

the Generator component is an Autoencoder whose

input instance is considered an outlier if the Discrim-

inator tags the output as having been generated.

LOF is an unsupervised technique applicable to

outlier and novelty detection. (Alsawadi and Bilal,

2021) utilise LOF for safer navigation of autonomous

vehicles by enabling it to detect new potentially dan-

gerous situations during autonomous driving. The

LOF method considers any data points as outliers if

they are located in low-density areas in relation to

their neighbours (Alsawadi and Bilal, 2021).

2.5 Objective 4: Predicting the Future

Activity of Terrorist Groups

When it comes to the forecasting of future terrorist

activity, the most frequently encountered technique is

the ARIMA forecasting model, which is used by both

(Sahin, 2018) and (Li et al., 2017). While not specif-

ically used in the counter-terrorism ﬁeld, Prophet,

open sourced by Facebook in 2017, has also been

gaining traction when it comes to forecasting (Taylor

and Letham, 2017). Prophet is essentially an additive

regression model which relies on the growth, season-

ality, effect of any speciﬁed holidays and any custom

white noise error.

(Sahin, 2018) proposes a system used to fore-

cast the frequency of terrorist attacks taking place in

different countries for a given month, utilising data

TerrorMine: Automatically Identifying the Group behind a Terrorist Attack

223

from the GTD. They compare the performance of the

ARIMA and the Dynamic Regression models. The

ARIMA method solely uses a linear combination of

past terrorist attacks. On the other hand, the Dynamic

Regression Model not only depends on past values

of the variable being predicted, but also on other

factors, such as the Gross Domestic Product (GDP)

(Sahin, 2018). The Dynamic Regression model did

perform better than ARIMA in certain cases, how-

ever the ARIMA model performed better overall. (Li

et al., 2017) also make use of the ARIMA model

based on GTD data to predict future terrorist activity

occurring in different countries, aiming to predict the

conditional probability of bombing tactics in different

countries. (Li et al., 2017).

(Battineni et al., 2020) use Prophet to perform 60-

day forecasting of the total number of COVID-19 in-

fections in the USA, Brazil, India and Russia, using

a logistic growth model. On the other hand, (Jha and

Pande, 2021) compare the ARIMA and Prophet mod-

els by forecasting Supermarket sales data, ultimately

concluding that Prophet performs better, resulting in

a better ﬁt, more accurate predictions and a smaller

error rate.

3 METHODOLOGY

The methodology of TerrorMine consists of the con-

duction of various experiments to identify the terror-

ists behind an attack, explore the effect of cluster-

ing on the identiﬁcation, detect the emergence of new

groups and forecast terrorist group activity. The ex-

periments, performed in line with the objectives, are

respectively described in Sections 3.1, 3.2, 3.3 and

3.4.

3.1 Objective 1: Automatically

Identifying the Perpetrator

For the automated identiﬁcation of the responsible

terrorist groups, the initial step is to select the most

salient features. This is done through extremely ran-

domised trees using the ExtraTreesClassiﬁer model

provided by SKLearn

. During the ﬁtting of the clas-

siﬁer, the feature importance is computed for each

of the tables based on the impurity score for the

splitting of data based on the features. After ﬁt-

ting, these impurity scores for all the input features

are extracted from the trained model. All features

with an impurity score higher than average are then

https://scikit-learn.org/ [Last Accessed: May 13th,

2022]

selected. The selected features are iyear, imonth,

country, region, provstate, city, latitude, longitude,

targsubtype1, corp1, target1, natlty1 and weapsub-

type1.

The classiﬁers implemented for this objective are

Decision Tree, Random Forest, KNN, Logistic Re-

gression, SVM (also trained using SGD) and Feed-

forward Neural Network (FNN), which are some of

the best encountered performing classiﬁcation tech-

niques in this domain. For the Decision Tree and Ran-

dom Forest classiﬁers, the categorical features are or-

dinal encoded and the continuous features are left as

is, since high non-standardised values do not impact

tree-based classiﬁcations. On the other hand, for the

remaining classiﬁcation techniques, categorical fea-

tures are one-hot encoded and continuous features are

standardised. All classiﬁers, excluding ANNs, are

ﬁne-tuned through a grid search using a wide variety

of parameters.

After selecting the optimal classiﬁcation model,

two additional experiments are carried out in attempt

to enhance the performance of the model which in-

clude handling of missing data and the use of textual

features. For the former, Listwise Deletion, Mode Im-

putation and Multivariate Imputation are performed

before classiﬁcation. For the inclusion of textual data

we compute the structured TF-IDF features of the at-

tack summary ﬁeld in GTD. Such improvements are

implemented based on their positive impact in the ex-

periments encountered in the reviewed literature.

3.2 Objective 2: Exploring the Effect of

Clustering

Two different approaches are taken to explore the

effect of clustering on classiﬁcation. The ﬁrst ap-

proach is to use the assigned cluster label as an ad-

ditional feature to the classiﬁcation pipeline. The sec-

ond approach is to cluster the data and then ﬁt a sepa-

rate classiﬁcation model on each cluster. The second

approach involves performing hyper-parameter tun-

ing on each model so that each model is optimised

to classify instances belonging to its respective clus-

ter. Clustering experiments are carried out using K-

Means, K-Modes and HDBScan.

K-Means operates using Euclidean distance, thus

continuous features are standardised and categorical

features are one-hot encoded. Since K-Means does

not perform well with high dimensional data, possi-

bly resulting in meaningless clusters, the four textual

features that mostly contribute to data sparsity are ex-

cluded, namely: provstate, city, corp1, target1. The

K-Means and HDBScan techniques both operate on

the same feature subset. K is set to 6 for K-Means,

KDIR 2022 - 14th International Conference on Knowledge Discovery and Information Retrieval

224

determined through the Elbow method using Distor-

tion score. HDBScan, on the other hand, automati-

cally infers the number of clusters due to its density-

based mechanism. K-Modes is set up to only operate

on the categorical feature subset since it is a technique

used for clustering categorical attributes. A K of 11

is determined by considering the least cost, which is

the sum of dissimilarities between all of the resulting

clusters.

3.3 Objective 3: Automatically

Discovering New Perpetrators

The problem of detecting new perpetrators is treated

as an outlier detection problem where outliers are

only assumed to be present in unseen data. The ex-

periments for this objective use unsupervised Nearest

Neighbours, LOF, OCSVM, Autoencoder and GAN

for outlier detection, which were found to be some of

the most effective techniques in the related work. The

same feature subset described in Section 3.1 is con-

sidered, except for the Autoencoder and GAN, which

exclude the highly dimensional attributes that cause

the DNN model training to exceed the available hard-

ware’s capacity. The Nearest Neighbours, LOF and

OCSVM models are ﬁne-tuned using Grid Search.

For the implementation of Nearest Neighbours,

the model is ﬁtted on the training data and for any new

unseen instance, its Euclidean distance to the closest

K neighbours is calculated. If the mean distance is

greater than a speciﬁed threshold determined through

Grid Search, then the instance is considered an out-

lier. When using Autoencoder, the decoded output of

an instance is compared to the input using Mean Ab-

solute Error (MAE). If the loss is larger than the stan-

dard deviation of the list of (MAE) values of the train-

ing data subtracted by their mean, then the instance

is considered an outlier, as done by (Rajan, 2021).

When it comes to the GAN technique, the Genera-

tor is replaced by an Autoencoder and once the Dis-

criminator is trained, the network is fed the unseen

data. Any instances which the Discriminator labels as

”fake” are considered to be outliers, thus assumed to

be attacks performed by unseen terrorist groups.

3.4 Objective 4: Predicting the Future

Activity of Terrorists Groups

The impact of each terrorist group for a speciﬁc year

and month is predicted using ARIMA and Prophet,

where, according to the review literature, the former

technique has been shown to perform well in this ﬁeld

and the latter has been proven to even surpass ARIMA

in other ﬁelds. The impact is predicted by forecasting

the number of civilian fatalities (nkill - nkillter), the

number of those wounded (nwound - nwoundte) and

then summing them up, as performed by (Singer and

Golan, 2019). The impact is then categorised through

quantile-based discretisation. As an additional exper-

iment, the attack frequency is also forecast.

In order to ﬁnd the optimal ARIMA model for

each required measure for each terrorist group, the

auto arima behaviour of the arima class developed by

(Smith et al., 2017) is used; a tool intended to dis-

cover the optimal parameters of this forecasting tech-

nique. This enables the discovery of the optimal value

for the order of the ﬁrst-differencing, auto-regressive

and moving-average models. It then proceeds to ﬁne-

tune the values of the order of the auto-regressive and

moving-average components of the seasonal model,

and seasonal differencing. When evaluating how

well a set of parameters results in forecasting, Mean

Squared Error (MSE) is used. Similarly, the optimal

Prophet model is estimated in terms of growth, upper-

bound and seasonality pattern. For Prophet, in order

to evaluate the performance of each set of parameters,

the Root Mean Square Error (RMSE) is used.

4 RESULTS & DISCUSSION

This section presents the achieved results for each ob-

jective. For the ﬁrst three objectives, data was or-

dered by date and eventid and split into 80% train-

ing and 20% testing sets. The training set is used to

ﬁne-tune and select the optimal model through time-

independent cross-validation. The test set is used

to test the selected model on unseen time-dependent

data. For the fourth objective, data ranging from Jan-

uary 2010 until May 2016 is used as training data and

data from June 2016 until December 2017 for valida-

tion data in order to ﬁne-tune the forecasting models.

The models are then tested on the unseen data which

ranges from January 2018 until December 2019.

4.1 Objective 1: Automatically

Identifying the Perpetrator

This section includes the results for perpetrator iden-

tiﬁcation involving the Decision Tree, KNN, Logistic

Regression, SVM and FNN classiﬁers, in addition to

missing data handling techniques and the use of un-

structured textual data. Table 1 shows that, based on

the Weighted F1-score of 0.818, the optimal model

for the automated identiﬁcation of the perpetrator is

the Random Forest model operating on both struc-

tured data and unstructured textual data from the sum-

mary ﬁeld of terrorist attack records. Furthermore, it

TerrorMine: Automatically Identifying the Group behind a Terrorist Attack

225

also shows that handling missing data using Listwise

Deletion, Mode Imputation and Multivariate Imputa-

tion does not improve the results.

The scores decreased when tested on the unseen

test data, resulting in an F1-score of 0.800. This is

expected since the model is ﬁne-tuned on the training

data. The decrease is slight however, which implies

that the model is not over-ﬁt on the training data. The

table also shows that our model performs substan-

tially better than a weighted random (naive) model.

The model is also trained on GTD data ranging from

1990 until 2014 and tested on data for 2015 and 2016,

to compare it with the classiﬁcation results obtained

by (Peng, 2018). The table shows that our model per-

formed better, achieving an accuracy of 0.693.

Table 1: Table showing the perpetrator identiﬁcation Ac-

curacy and Weighted Precision, Recall and F1-score for

the different models: Decision Tree (DT), KNN, Logistic

Regression (LR), SVM, SVM using SGD (SVM-S), FNN,

Random Forest (RF), Random Forest in addition to Listwise

Deletion (RF-LD), Mode Imputation (RF-MI) and Mul-

tivariate Imputation (RF-MVI), Random Forest operating

only on text features (RF-T) and Random Forest operating

on both structured and text features (RF-ST).

Accuracy Precision Recall F1

Cross Validation Data (2015 - 2018)

DT 0.718 0.795 0.718 0.737

KNN 0.797 0.771 0.797 0.777

LR 0.827 0.810 0.827 0.811

SVM 0.801 0.814 0.801 0.797

SVM-S 0.829 0.807 0.829 0.808

FNN 0.620 0.718 0.620 0.625

RF 0.830 0.811 0.830 0.813

RF-LD 0.808 0.791 0.808 0.788

RF-MI 0.829 0.813 0.829 0.812

RF-MVI 0.829 0.811 0.829 0.812

RF-T 0.696 0.651 0.696 0.663

RF-ST 0.828 0.828 0.828 0.818

Test Data (2018 - 2019)

Random 0.075 0.101 0.075 0.082

RF-ST 0.817 0.817 0.817 0.800

Test Data (2015 - 2016)

Random 0.072 - - -

RF-ST 0.693 - - -

Peng

(2018)

0.583 - - -

4.2 Objective 2: Exploring the Effect of

Clustering

This section includes the clustering performance re-

sults for the K-Means, K-Modes and HDBScan tech-

niques. Table 2 shows that the hybrid approach in-

volving the ﬁne-tuning and ﬁtting of a Random For-

est model on each cluster produced by the HDBScan

technique, resulted in the best Weighted F1-score of

0.830 during cross-validation, surpassing the stan-

dard Random Forest model. When tested on unseen

data however, the standard Random Forest model pro-

duced a slightly higher F1-score. The most proba-

ble reason for this is the fact that cross-validation was

done on data which is clustered beforehand, offering

an unfair advantage. The time taken to evaluate the

hybrid pipeline using cross-validation takes less than

half the time to train the standard one, which is highly

advantageous.

Table 2: Table providing the Accuracy and Weighted Preci-

sion, Recall and F1-score for classiﬁcation when preceded

by the different clustering techniques. The entries for K-

Means, K-Modes and HDBScan refer to the traditional clas-

siﬁcation model which also utilises the cluster label as an

additional feature. K-Means*, K-Modes* and HDBScan*

refer to the hybrid approach where a separate classiﬁcation

model is ﬁt on each of the clusters.

Clustering Acc. Prec. Rec. F1

Cross Validation Data (2015 - 2018)

None 0.828 0.828 0.828 0.818

K-Means 0.824 0.827 0.824 0.814

K-Modes 0.829 0.828 0.829 0.819

HDBScan 0.822 0.827 0.822 0.814

K-Means* 0.849 0.823 0.849 0.821

K-Modes* 0.841 0.819 0.841 0.822

HDBScan* 0.848 0.826 0.848 0.830

Test Data (2018 - 2019)

None 0.828 0.828 0.828 0.818

HDBScan 0.804 0.793 0.804 0.783

4.3 Objective 3: Automatically

Discovering New Perpetrators

This section includes the new perpetrator detection

results for the LOF, OCSVM, Nearest Neighbours,

Autoencoder and GAN techniques. Table 3 shows

that the unsupervised Nearest Neighbours model re-

sulted in the highest Macro F1-score during cross-

validation when it comes to detecting new terrorist

groups. This model is then tested on the unseen test

set and compared to a constant model which classiﬁes

all attacks as not having been carried out by unseen

groups. While the obtained result is not outstanding,

our model performs better than this constant, imply-

ing that it manages to detect some of the attacks as

having been carried out by new groups.

KDIR 2022 - 14th International Conference on Knowledge Discovery and Information Retrieval

226

Table 3: Table showing the novel class detection Accu-

racy and Macro Precision, Recall and F1-score for the LOF,

OCSVM, Nearest Neighbours (NN), Autoencoder (AE) and

GAN results.

Accuracy Precision Recall F1

Cross Validation Data (2015 - 2018)

LOF 0.941 0.516 0.517 0.516

OCSVM 0.951 0.568 0.564 0.564

NN 0.930 0.571 0.605 0.579

AE 0.759 0.500 0.380 0.428

GAN 0.782 0.500 0.391 0.400

Test Data (2018 - 2019)

Constant 0.976 0.488 0.500 0.494

NN 0.911 0.537 0.616 0.547

4.4 Objective 4: Predicting the Future

Activity of Terrorists Groups

This section includes the new terrorist group forecast-

ing results for the ARIMA and Prophet techniques.

When predicting the future impact of the twenty most

impacting terrorist groups, Table 4 shows that the

Prophet model has the edge, resulting in slightly bet-

ter Accuracy and Weighted Recall and F1-score.

Table 4: Table showing the Accuracy and Weighted Preci-

sion, Recall and F1-score for the Impact classiﬁcation car-

ried out using both Prophet and ARIMA.

Accuracy Precision Recall F1

ARIMA 0.535 0.668 0.535 0.581

Prophet 0.602 0.653 0.602 0.620

5 CONCLUSION AND FUTURE

WORK

TerrorMine is a system which builds upon existing

research focusing on counter-terrorism using data-

driven methods. The ﬁrst objective was to identify

the groups responsible for terrorist attacks. The per-

formed experiments show that the Random Forest

seems to be the optimal classiﬁer for this objective.

While classiﬁcation is not improved when handling

missing data using specialised techniques, it seems to

slightly improve when including textual data from the

summary of attacks. The second objective involved

exploring the effect of clustering on the perpetrator

identiﬁcation. Clustering the data before classiﬁca-

tion seems to have a negative impact on the result

metrics when tested on unseen data, however model

training and ﬁne-tuning is made faster. The third ob-

jective involved the detection of attacks which were

carried out by new groups. The results produced

for this objective are not outstanding, however the

Nearest Neighbours technique shows potential. The

fourth objective was to forecast the terrorist activity of

the different groups, with the performance of Prophet

surpassing that of ARIMA in terms of weighted F1-

score.

This work contributes to current research by com-

paring an extensive range of ML techniques on global

and more recent GTD data to automatically identify

terrorist groups. We also compare the sole utilisation

of structured data, text data and ultimately a combi-

nation of both for classiﬁcation. Additionally, we ex-

plore the niche of possibly detecting whether terrorist

attacks were carried out by an unobserved group, by

employing diverse techniques. To our knowledge, this

has never been tackled before in this domain. Fur-

thermore, we provide terrorist activity forecasts us-

ing Prophet, a tool which was not encountered in this

ﬁeld.

5.1 Future Work

A possible future improvement is to use the Gower

distance instead of Euclidean where plausible since it

considers both categorical and continuous data. The

challenge with this approach is that the computation

of a Gower matrix is computationally expensive. Fur-

thermore, when it comes to clustering data to im-

prove classiﬁcation, the K parameter could alterna-

tively be determined by varying it according to the

classiﬁcation results. Additionally, the clustering pro-

cess could be used for outlier detection and removal,

which could improve the results of all the objectives.

Oversampling records related to minority terrorist or-

ganisations could also improve the results of the ﬁrst

two objectives. Another improvement is to use the

terrorist organisation identiﬁcation pipeline produced

for the ﬁrst objective to identify the terrorist organisa-

tions which are actually unknown, resulting in a more

complete dataset which could improve the results of

the remaining objectives. Furthermore, the terrorist

groups which are determined to be inactive during the

period of the unseen test data through the fourth ob-

jective could also be eliminated from the training data

used for the identiﬁcation of terrorist groups in the

ﬁrst objective.

REFERENCES

Alapati, Y. K. and Sindhu, K. (2016). Combining clustering

with classiﬁcation: a technique to improve classiﬁca-

tion accuracy. Lung Cancer, 32(57):3.

Alsawadi, H. and Bilal, M. (2021). Measuring novelty in

autonomous vehicles motion using local outlier factor

algorithm. arXiv preprint arXiv:2104.11970.

TerrorMine: Automatically Identifying the Group behind a Terrorist Attack

227

Battineni, G., Chintalapudi, N., and Amenta, F. (2020).

Forecasting of covid-19 epidemic size in four high

hitting nations (usa, brazil, india and russia) by fb-

prophet machine learning model. Applied Computing

and Informatics.

Carrara, F., Amato, G., Brombin, L., Falchi, F., and Gen-

naro, C. (2021). Combining gans and autoencoders

for efﬁcient anomaly detection. In 2020 25th Inter-

national Conference on Pattern Recognition (ICPR),

pages 3939–3946. IEEE.

Curia, F. (2020). Unsupervised hybrid algorithm to detect

anomalies for predicting terrorists attacks. Interna-

tional Journal of Computer Applications, 975:8887.

Diab, S. (2019). Optimizing stochastic gradient de-

scent in text classiﬁcation based on ﬁne-tuning hyper-

parameters approach. a case study on automatic clas-

siﬁcation of global terrorist attacks. arXiv preprint

arXiv:1902.06542.

Jackson, R. (2018). Writing the war on terrorism: Lan-

guage, politics and counter-terrorism. Manchester

University Press.

Jha, B. K. and Pande, S. (2021). Time series forecasting

model for supermarket sales using fb-prophet. In 2021

5th International Conference on Computing Method-

ologies and Communication (ICCMC), pages 547–

554. IEEE.

Khorshid, M., Abou-El-Enien, T., and Soliman, G.

(2015a). A comparison among support vector ma-

chine and other machine learning classiﬁcation algo-

rithms. IPASJ International Journal of Computer Sci-

ence (IIJCS).

Khorshid, M. M., Abou-El-Enien, T. H., and Soliman,

G. M. (2015b). Hybrid classiﬁcation algorithms for

terrorism prediction in middle east and north africa.

International Journal of Emerging Trends & Technol-

ogy in Computer Science, 4(3):23–29.

Laite, R., Lozano, M., and Sankaranarayanan, K. (2019).

Terrorist group classiﬁcation of historic terrorist at-

tacks from the global terrorism database. In 2019 14th

International Conference on Computer Science & Ed-

ucation (ICCSE), pages 237–242. IEEE.

Li, S., Zhuang, J., and Shen, S. (2017). Dynamic forecast-

ing conditional probability of bombing attacks based

on time-series and intervention analysis. Risk analy-

sis, 37(7):1287–1297.

Mathivanan, N. M. N., Ghani, N. A. M., and Janor, R. M.

(2018). Improving classiﬁcation accuracy using clus-

tering technique. Bulletin of Electrical Engineering

and Informatics, 7(3):465–470.

Meng, X., Mo, H., Zhao, S., and Li, J. (2017). Application

of anomaly detection for detecting anomalous records

of terroris attacks. In 2017 IEEE 2nd International

Conference on Cloud Computing and Big Data Anal-

ysis (ICCCBDA), pages 70–75. IEEE.

Mohammed, D. Y. and Karabatak, M. (2018). Terrorist at-

tacks in turkey: An evaluate of terrorist acts that oc-

curred in 2016. In 2018 6th International Symposium

on Digital Forensic and Security (ISDFS), pages 1–3.

IEEE.

National Consortium for the Study of Terrorism and Re-

sponses to Terrorism (START) (2019). Global terror-

ism database. https://www.start.umd.edu/gtd.

Pag

an, J. V. (2010). Improving the classiﬁcation of terrorist

attacks a study on data pre-processing for mining the

global terrorism database. In 2010 2nd International

Conference on Software Technology and Engineering,

volume 1, pages V1–104. IEEE.

Pan, X. (2021). Quantitative analysis and prediction of

global terrorist attacks based on machine learning.

Scientiﬁc Programming, 2021.

Pedregosa, F., Varoquaux, G., Gramfort, A., Michel, V.,

Thirion, B., Grisel, O., Blondel, M., Prettenhofer,

P., Weiss, R., Dubourg, V., Vanderplas, J., Passos,

A., Cournapeau, D., Brucher, M., Perrot, M., and

Duchesnay, E. (2011). Scikit-learn: Machine learning

in Python. Journal of Machine Learning Research,

12:2825–2830.

Peng, A. (2018). An integrated machine learning approach

to studying terrorism. In Undergraduate Thesis. Yale

University.

Pfeiffer, C. P. (2012). Causalities and casualties: Media

attention and terrorism, 1970–2010. Working Paper

127/2012, Helmut Schmidt University, Hamburg.

Rajan, S. (2021). Anomaly detection using autoen-

coders: A walk-through in python. https://tinyurl.

com/2p92wm4p. Analytics Vidhja. Accessed June

2022.

Sahin, Y. (2018). Forecasting the Monthly Occurrence of

Terrorist Incidents Based on the GPI indicators and

the GDP. PhD thesis, Tilburg University.

Singer, G. and Golan, M. (2019). Identiﬁcation of sub-

groups of terror attacks with shared characteristics for

the purpose of preventing mass-casualty attacks: A

data-mining approach. Crime Science, 8(1):1–11.

Smith, T. G. et al. (2017). pmdarima: Arima estimators for

Python. http://www.alkaline-ml.com/pmdarima. Ac-

cessed June 2022.

Spinosa, E. J. and Carvalho, A. (2005). Support vector

machines for novel class detection in bioinformatics.

Genet Mol Res, 4(3):608–15.

Talreja, D., Nagaraj, J., Varsha, N., and Mahesh, K. (2017).

Terrorism analytics: Learning to predict the perpe-

trator. In 2017 International Conference on Ad-

vances in Computing, Communications and Informat-

ics (ICACCI), pages 1723–1726. IEEE.

Taylor, S. J. and Letham, B. (2017). Prophet: Forecast-

ing at scale. https://research.facebook.com/blog/2017/

02/prophet-forecasting-at-scale/. Meta Research. Ac-

cessed June 2022.

Tolan, G. M. and Soliman, O. S. (2015). An experi-

mental study of classiﬁcation algorithms for terror-

ism prediction. International Journal of Knowledge

Engineering-IACSIT, 1(2):107–112.

Zenati, H., Foo, C. S., Lecouat, B., Manek, G., and Chan-

drasekhar, V. R. (2018). Efﬁcient gan-based anomaly

detection. arXiv preprint arXiv:1802.06222.

KDIR 2022 - 14th International Conference on Knowledge Discovery and Information Retrieval

228
