Situational Question Answering using Memory Nets

Joerg Deigmoeller

, Pavel Smirnov

, Viktor Losing

, Chao Wang

, Johane Takeuchi

and Julian Eggert

Honda Research Institute Europe, Carl-Legien-Straße 30, 63073 Offenbach am Main, Germany

Honda Research Institute Japan, 8-1 Honcho, Wako, Saitama 351-0114, Japan

Keywords:

Situational Question Answering, Knowledge Representation and Reasoning, Natural Language

Understanding.

Abstract:

Embodied Question Answering (EQA) is a rather novel research direction, which bridges the gap between

intelligence of commonsense reasoning systems and reasoning over actionable capabilities of mobile robotic

platforms. Mobile robotic platforms are usually located in random physical environments, which have to be

dynamically explored and taken into account to deliver correct response to users’ requests. Users’ requests

are mostly related to foreseeable physical objects, their properties and positional relations to other objects in

a scene. The challenge here is to create an intelligent system which successfully maps the query expressed in

natural language to a set of reasoning stems and physical actions, required to deliver the user a correct answer.

In this paper we present an approach called Situational Question Answering (SQA), which enforces the em-

bodied agent to reason about all available context-relevant information. The approach relies on reasoning over

an explicit knowledge graph complemented by inference mechanisms with transparent, human-understandable

explanations. In particular, we combine a set of facts with basic knowledge about the world, a situational mem-

ory, commonsense understanding, and reasoning capabilities, which go beyond dedicated object knowledge.

On top, we propose a Semantics Abstraction Layer (SAL) that acts as intermediate level between knowledge

and natural language. The SAL is designed in a way that reasoning functions can be executed hierarchically

to provide complex queries resolution. To demonstrate the ﬂexibility of the SAL we deﬁne a set of questions

that require a basic understanding of time, space, and actions including related objects and locations. As an

outlook, a roadmap on how to extend the question set for incrementally growing systems is presented.

1 INTRODUCTION

The motivation of our work is to enable an Intelli-

gent Agent (IA) to interact with its environment in

a purposeful way as well as to pursue and reach its

own goals by utilizing its own resources. As this is a

quite abstract and high goal, we approach the problem

from top down and focus on the continuous reﬁne-

ment of agent’s knowledge base via incorporation of

new facts extracted either from commonsense knowl-

edge graphs or from an agent’s perception of the en-

vironment. For speeding up the development, we use

a virtual environment, which ﬁrst has to be explored

in order to let an agent to reason about it. This idea

is similar to Embodied Question Answering (EQA,

(Das et al., 2017)), which gets greater attention in re-

cent years. Here, an environment related question is

raised to an agent and the task is to explore the sur-

rounding until it ﬁnds the required information (usu-

ally using visual recognition) to answer the question.

The main difference to our work is that the reasoning

in not embedded into an end-to-end deep neural net-

work, but in a knowledge engine that combines world

knowledge with environment information into a sin-

gle graph representation. This gives use the advan-

tages to explicitly deﬁne general reasoning processes

as well as to allow for a transparent explanation of

internal reasoning steps. Another difference is, that

we leave the recognition task out of scope for this pa-

per and focus on the reasoning in a certain situation,

given the perception delivered by a simulator frame-

work. In this paper we put focus on the agent’s knowl-

edge engine system, which provides two main func-

tions: continuously store and retrieve complex struc-

tured and unstructured information about the environ-

ment and infer additional context relevant knowledge

in situations. Our previous work (Eggert et al., 2019;

Eggert et al., 2020) introduces the idea of Memory

Deigmoeller, J., Smirnov, P., Losing, V., Wang, C., Takeuchi, J. and Eggert, J.

Situational Question Answering using Memory Nets.

DOI: 10.5220/0011549200003335

In Proceedings of the 14th International Joint Conference on Knowledge Discovery, Knowledge Engineering and Knowledge Management (IC3K 2022) - Volume 2: KEOD, pages 169-176

ISBN: 978-989-758-614-9; ISSN: 2184-3228

 2022 by SCITEPRESS – Science and Technology Publications, Lda. All rights reser ved

169

Net (MemNet), which provides a conceptual basis for

a knowledge engine that facilitates an agent to act in

a physical environment.

As a means to share knowledge with a user and

measure the reasoning performance, we attached a

natural language understanding to the knowledge en-

gine. Given an environment setting in the simulator

and a dedicated set of questions and answers, we can

enforce the agent to utilize and show its reasoning ca-

pabilities. Our focus is that the agent makes sense

out of a situation it is in by using its gained contex-

tual knowledge and making this process transparent.

We call this approach Situational Question Answer-

ing (SQA).

We are convinced, that real situational reason-

ing requires a detailed understanding of the seman-

tic meaning, which goes beyond usual language un-

derstanding. It requires a tight interaction between

language and semantic concepts embedded in a large

network. In the same way, observations need to be

part of that network, to utilize the full inference capa-

bilities. To allow an agent to act in an environment,

observed objects must be semantically separated into

objects that are manipulated and objects that are used

for manipulation (tool), as well as the changes an ob-

ject undergoes through an action. Such a context def-

inition is known from linguistics as verb semantics

(Baker et al., 1998), where each participant plays a

different role in an action. The most important roles

for our setting are the agent itself, the patient (object)

and the instrument (tool) that contribute to an action.

The novelty we present in this paper, especially in

relation to EQA, constitutes of two parts. First, the de-

tailed distinction between different action participants

(object, tool, subject, location) and their tight linkage

to the language understanding. In our work, we call

such context deﬁnitions action patterns which pro-

vide the key structure for situational reasoning. Sec-

ond, the embedding of observations and action pat-

terns into a large semantic network, combined with

commonsense information. We show both novelties

on the task of situational question answering.

In the reminder of this paper, we present our work

in the area of EQA and focus on knowledge represen-

tations that require situational aspects for the embod-

ied agent. In chapter 3, we explain the overall system

and how each component contributes to the overall in-

formation gain in a situation. Finally we evaluate the

system on a set question-answer pairs in chapter 4 and

conclude the paper with an outlook in chapter 5.

2 RELATED WORK

In recent years, the domain of Embodied Question

Answering (EQA) has rapidly grown in combination

simulators for home environment for executing high

level tasks (Puig et al., 2018; Kolve et al., 2019). The

focus of EQA (Das et al., 2017; Duan et al., 2022; Yu

et al., 2019) - sometimes also called Interactive Ques-

tion Answering (IQA) (Gordon et al., 2018) - is on ex-

ploring virtual environments by an agent and to ﬁnally

answer questions raised to the system. This direction

has set a new trend and provided great opportunities

for researchers interested in language grounding in

robotics (Tangiuchi et al., ) and question answering

(Pandya and Bhatt, 2019) by using simulated envi-

ronments. Even though the relation to SQA might be

obvious, the questions differ signiﬁcantly in the sci-

entiﬁc direction, which enforces more consideration

of robotics and commonsense knowledge. The focus

in SQA is less on dedicated object information, but

rather on the embedding of objects in all day situa-

tions. Therefore, instead of reasoning on physical fea-

tures, we target for a contextual embedding of objects

in all day situations to broaden the scope of language

interaction.

The work that comes closest to our idea is de-

scribed in (Tan et al., 2021). They include common-

sense information into the EQA process by loosely

coupling semi-structured data from ConceptNet with

their scene graph. As they operate on graphs and not

on deep neural network (as all EQA approaches do),

they call their approach K-EQA (Knowledge-based

Embodied Question Answering). The performance is

estimated by comparing the question answering task

with and without visual recognition (scripted scene

information). The questions are generated automat-

ically from selected link types in ConceptNet, con-

nected with the simulator information to ﬁnally gener-

ate answers for training and testing. The step towards

using commonsense information in the question an-

swering is a remarkable contribution to the domain.

Nevertheless, the reasoning is performed on triplet

information like (‘Sports equipment’, ‘ReceivesAc-

tion’, ‘purchased at a sporting goods store’), which is

questionable that such text snippets provide any ma-

chine interpretable meaning. As already described

in the introduction, our approach further splits such

snippets like ‘purchased at a sporting goods store’ into

detailed information as ’purchased’ is the action and

’sporting goods store’ is the location where the ac-

tion takes place. Making these types explicit allows

for a real semantic understanding and embedding into

the agent’s context. We describe this approach in

section 3.3. Additionally, we combine commonsense

KEOD 2022 - 14th International Conference on Knowledge Engineering and Ontology Development

170

and scene graph information into a single knowledge

graph. This provides a strong connection between se-

mantic types and observations, as well as the storing

and correcting of context information in situations.

The detailed description of actions and their con-

tributors is also known from knowledge representa-

tions in robotics (Paulius and Sun, 2018; Thosar et al.,

2018). The goal is usually to execute a manipulation

task and to infer missing information that is required

for the successful execution (Beetz et al., 2018). Even

if a language interaction would be really helpful for

this domain, it has not been established so far, espe-

cially not for resolving situations on a high level, in-

cluding ambiguities coming from language. We dis-

tinguish ourselves from this domain as we operate on

a higher level in direct language interaction by devel-

oping further the idea of embodied question answer-

ing and situation understanding at the same time.

We think that SQA provides a novel direction to

bring the domains of question answering, common-

sense knowledge and robotics closer together to ﬁ-

nally enable a natural interaction with agents, either

in simulation or in real.

3 SYSTEM OVERVIEW

In this section, we describe the overall system and go

into depth of each component in the sub-sections. The

core of the system is the knowledge engine that acts as

connecting component (see ﬁgure 1) that is synchro-

nized with the simulated environment. Other com-

ponents either allow to access the knowledge engine

via natural language (Semantic Parsing), inspect the

reasoning steps (Explainable AI) or insert externally

gathered knowledge (Knowledge Insertion). The in-

teraction between all, ﬁnally enables the task of SQA

using natural language and reasoning in speciﬁc situ-

ations.

3.1 Knowledge Engine

The knowledge engine consists of three main parts

(see ﬁgure 1 at bottom left), the knowledge graph, the

reasoning layer, and the Semantics Abstraction Layer

(SAL). Those layers are important to allow for mod-

ular access of the knowledge representation and rea-

soning. The SAL is the highest layer and describes as

orthogonal as possible access functions to scale well

by applying nested executions. This ﬁnally leads to

the idea of Inductive Functional Programming which

allows for various learning applications on top (Dia-

conu, 2020).

Figure 1: Overall system sketch with the knowledge engine

as core component. The simulated environment and the

semantic parsing allows for situational question answering

using externally gathered knowledge. The XAI facilitates

tracing of the reasoning steps in the knowledge engine.

3.1.1 Knowledge Graph

First we start with the lowest layer, the knowledge

graph. The representation is created according to

MemNet and covers four main columns of object,

subject, action and state hierarchies, as described in

(Eggert et al., 2020). The four columns are motivated

by verb semantics (Baker et al., 1998), which derive

from linguistics. In verb semantics, words acquire a

semantic role in the context of a verb, or here an ac-

tion. That means, each participant from one of the

four hierarchies in MemNet can jump into a role that

is dedicated to a speciﬁc action. For example, a knife

is no longer a simple object, but rather a tool if it con-

tributes to the action cut. In the same way, an agent

can become an actor or recipient in an action bring,

depending on the context. Such roles are reﬂected in

MemNet as action patterns using inheritance or even

multiple inheritance if required. For further reading,

we refer to our earlier papers (Eggert et al., 2019; Eg-

gert et al., 2020). The action patterns can be inserted

manually, in interaction or through accessing exter-

nal knowledge sources (cf. chapter 3.3). They pro-

vide the basis for situational reasoning, for example

if we are interested in objects that are usually related

to the action cutting, what objects are used for cutting

Situational Question Answering using Memory Nets

171

or which agent applied which tool for a certain ac-

tion. According to VerbNet (Schuler, 2005), the par-

ticipants in actions are arranged in a whole taxonomy,

starting with time, place, undergoer and actor on high-

est level. For our work we focus on actor, location

(place) and object/tool (undergoer), as it already cov-

ers the most obvious interactions. As initial hierarchy,

we reuse the WordNet (Fellbaum, 1998) inheritance

hierarchy and import it into MemNet. For simplicity,

we assign all nouns to the object column and all verbs

to the action column at ﬁrst.

As will be explained later in chapter 3.4, phys-

ical instances in the simulator are inserted into the

knowledge graph as specializations of known object

concepts or subject in case of the agent. For each in-

stance, we manually identiﬁed the correct concept in

the graph and enriched the specialization with geo-

metric information, either position or shape.

3.1.2 Reasoning Layer

The reasoning layer provides basic methods to iden-

tify concepts in the graph from different entry points.

Each concept is embedded into related concepts, ei-

ther in a hierarchy (semantically related) or through

an action pattern (context related). This is a straight

forward inference by following paths in the graph.

Spatial reasoning is based on simple geometric inter-

pretations based on 2D shapes and points.

3.1.3 Semantics Abstraction Layer

The SAL provides an access to the knowledge engine

on a semantics level. This means, no deeper under-

standing of reasoning details is required when oper-

ating on this level. In a nutshell, the whole API is

based on getting or setting objects, locations, actions,

states, tools or combinations of those as action pat-

terns. All arguments can be either forwarded as ut-

terance, i.e. text or a unique ID of the concept node

in the graph. Further distinction is made between ab-

stract concepts and instances that are attached with

positions and shapes. Instances are provided with a

short term memory (STM) label for easy identiﬁca-

tion in the graph. We focus on the most important

API calls for situational question answering, which

are the STM retrieving functions. A list of functions

is presented below with further explanation:

get action patterns(object, location, action, state, tool)

get stm objects(object, location, action, state, tool)

get stm locations(object, location, action, state, tool)

get stm actions(object, location, action, state, tool)

get stm subjects(object,location,action, state, tool)

get stm states(object, location, action, state, tool)

get stm tools(object, location, action, state, tool)

get count(object, location, action, state, tool)

The API can be read as following. For each se-

mantic type there is a getting function, while again the

arguments are the semantic types, where none, one

or multiple can be speciﬁed. By specifying a certain

type, the internal reasoning will also explore its spe-

cializations, i.e. its child concepts until they ﬁnally hit

a matching instance within the hierarchy. That means,

we could alternatively identify a banana by calling

get stm objects (object=”fruit”, state=”yellow”).

The only exception are spatial key words as state

argument, which are currently limited to in or on. For

example, identifying all objects on a table, we could

ask for

get stm objects (state=”on”, location=”table”).

In the same way, if contextual information has

been extracted from external knowledge sources,

tools could be identiﬁed that are used for the action

cut by

get stm tools (action=”cut”).

As return value, the functions always return the

corresponding concept IDs, which again can be for-

warded to any function, so that we can create a tree

of calls. This gives us a quite large ﬂexibility, with

a comparably low number of functions. When we

talk about the translation from natural language to se-

mantic calls in chapter 3.2, such a ﬂexibility and con-

ceptual interplay between grammar and semantics be-

comes very important to be able to check the validity

of natural language.

3.2 Semantic Parsing

The semantic parsing translates incoming natural lan-

guage requests into SAL calls. As a ﬁrst step, the

incoming sentence is analyzed by the syntactic parser

spaCy (Honnibal and Montani, 2017), which returns

the grammatical structure of the text as a graph. The

advantage is that in addition to usual intent and slot

recognition known from natural language understand-

ing in chat-bot systems (Jiao, 2020), we additionally

get the relation between words from the dependency

parsing. By this, we can identify sub-clauses and can

group them into semantic closed sub-contexts. As an

example, if we look at ”where is something to drink”,

we can identify the pattern ”where is [object]” on a

high level. We use this pattern to map this to the func-

tion get

stm locations. Further, on a next level, the

[object] is further speciﬁed by the sub-clause ”some-

thing to drink”. The extracted structure by the syntac-

tic parser gives us all information we need to map this

KEOD 2022 - 14th International Conference on Knowledge Engineering and Ontology Development

172

sub-clause to the function get stm objects, where the

arguments are ”something” for the object and ”drink”

for the action.

Pursuing this idea, we applied a set of rules to map

words (tagged as parts-of-speech) and the dependency

tree to a sequence of SAL calls. The advantage here

is that this is a generic mapping, because it relies on

the syntactic tree and the SAL calls are generated au-

tomatically from the sentence structure.

3.3 Knowledge Insertion

In the reasoning process, we also aim to answer

common-sense questions such as ”What tool can I

use to cut an orange ?” or ”What tool can I cut using

the knife?”. To enable such reasoning we extracted

common-sense knowledge from ConceptNet (Speer

et al., 2017) and inserted it into our graph. In particu-

lar, we extracted action patterns as tool-action-object

triplets, e.g., knife-cut-orange, from the phrases of

the used for relation. We use the syntactic parsing

of spaCy (Honnibal and Montani, 2017) to extract

the action and object from the phrases. The tool is

given by the entity to which the used for relation is

assigned. More details about the extraction and an

analysis of its accuracy can be found in (Losing et al.,

2021). Altogether, we extracted 5887 action patterns.

As the extracted information is on text level,

we perform Word Sense Disambiguation (WSD)

(Bevilacqua et al., 2021) to obtain a mapping from

words to the synsets in our graph. In this regard, we

apply the state-of-the-art method CONSEC (Barba

et al., 2021), which phrases the WSD task as a

text extraction problem. The method is based on

the pre-trained Transformer model DEBERTA (He

et al., 2021), which was ﬁne-tuned using the anno-

tated SEMCOR data (Miller et al., 1994).

3.4 Virtual Simulation

Capabilities of embodied question-answering have to

be demonstrated in a certain context in the way that

asked questions relate to objects located in a certain

environment. 3D-simulators like Virtual Home (Puig

et al., 2018) or AI2-THOR (Kolve et al., 2019) of-

fer a variety of ﬂat-looking scenes, where a virtual

agent can be placed and manipulated via high-level

execution commands. Virtual Home has been cho-

sen because of it’s abstraction level, capability to add

multiple agents to the scene and return a subset of the

scene graph observed by a certain camera (mocking

the visual recognition part).

3.4.1 Interaction with Knowledge Engine

In order to facilitate a synchronization between vir-

tual simulator and the knowledge engine, an interme-

diate simulator-managing component is required. The

purpose of the component is to conﬁgure a desired

scene using the simulator’s API and initialize objects

as short-term instances in the knowledge graph. This

means that the relevance of inserted objects is re-

stricted by the current situation only. By combining

instances of the short-term memory with long-term

commonsense knowledge, the agent is able to rea-

son on the current environment. If the environment

gets changed (because of agent’s or human’s manip-

ulations) the simulator-managing component updates

corresponding short-term instances in the knowledge

engine, so that their latest state is taken into account

during the next reasoning operations.

3.5 XAI

Visualization of the knowledge graph, known as both

the human- and machine-readable format by its na-

ture, is widely used for increasing the explainability

of machine learning models (Tiddi and Schlobach,

2022). Therefore, a user-friendly Explainable Arti-

ﬁcial intelligence (XAI) interface is demanded by ex-

perts for getting more insight into how our system

works in real-time (Spinner et al., 2019; Arrieta et al.,

2020; Tjoa and Guan, 2020). In our system, a web-

based graphical user interface (GUI), which combines

different modes and a dialogue box is designed and

implemented. There are three targets of the XAI in-

terface: 1) send commands to the system and receive

feedback from the agent, 2) visualize the reasoning

process of the agent to resolve the request for a user

and 3) supervise the current status and execution of

the agent.

We introduce the the whole procedure of the in-

teraction with our XAI interface by the following ex-

amples (Figure 2): Firstly, the user can type a natural-

language command into the dialog box. For exam-

ple, when a user asks ”how many breads are in the

kitchen?” (Figure 2 A), the front-end GUI will send

the raw language input to the Semantic Parsing and

translates it into the calls of the Semantics Abstrac-

tion Layer (see 3.1.3). After getting the results from

the knowledge graph, the output data is sent to the

front-end interface to visualize the whole process of

calling a sequence of functions. Then, as shown in

Figure 2 B, the natural language ”how many breads

are in the kitchen?” is translated into the pattern of

”counting objects” on a higher level, which matches

the function ’get count’ (Figure 2 b.5). This func-

Situational Question Answering using Memory Nets

173

tion requires the parameter of the related instances to

”count”. On a lower level, the system calls the func-

tion ’get stm objects in’ (Figure 2 b.2), with the ar-

guments ’bread’ as object and ’kitchen’ as location.

The outputs are the instances of the concept ”bread”,

which are displayed as pink circles (b.4). After the

instances are put as the parameter ”object” (Figure

2 b.2) and calling the function ’get count’, the ﬁ-

nal result is returned (Figure 2 b.7) and answered in

the dialog box (Figure 2 b.8). At last, the user can

switch to the camera mode (Figure 2 D), which dis-

plays the video stream from the virtual home simu-

lator, by pressing the tab button (Figure 2 c.1) to ob-

serve what is the status of the agent in real-time. As

shown in Figure 2 C, when asked ”bring the book to

the kitchen”, the agent applies the action in the sim-

ulation. This allows for a real and transparent user

experience of the system beyond the SQA task de-

scribed in this paper.

4 EVALUATION

To evaluate our system, we used a set of question

types, known from state-of-the-art (Tan et al., 2021;

Das et al., 2017; Duan et al., 2022; Yu et al., 2019).

In comparison to the existing work, we added the se-

mantic types tool, location and action stored as action

patterns in the knowledge engine which are fed by ex-

tracted commonsense. This allows us to increase the

variations in phrasing questions and at the same time,

enforcing the system to show its capabilities related

to situational understanding.

To focus on the variations of questions, we stick

to a single environment, instead of using multiple en-

vironments, as related work does. Another reason for

this is that we don’t need a training phase, because we

answer questions using zero shot learning by relying

on extracted commonsense information (cf. chapter

3.3) or predeﬁned standard operations as discussed in

chapter 3.1. The environment is a modiﬁed setup de-

livered by Virtual Home (Puig et al., 2018) and lim-

ited to 2 rooms.

As already discussed in chapter 2, our work is

coming closest to the approach (Tan et al., 2021). Un-

fortunately, it is hard to judge the impact of common-

sense information, which we think is a key factor in

free interaction with the user. It seems that the com-

monsense information requested in (Tan et al., 2021)

is prompted using the same phrasing as it is available

in ConceptNet. This ﬁnally does not require much

reasoning and is rather a pattern matching without se-

mantic interpretation.

We created a set of questions for locating, count-

ing and enumerating objects, as well as asking for

their existence in the environment. The types of ques-

tions are listed in table 1. Each question type can

again refer to either an action pattern or directly re-

fer to an instance. We estimated the accuracy of

a question by comparing the answers delivered by

the system against the ground truth answers from the

scene. As it can happen that multiple answers exist,

we need to compare every possible ground truth an-

swer against every system answer and vice versa.

To give a better insight, we ﬁrst evaluated each

question type individually (see columns 1 and 3 in ta-

ble 2). Then we tested the inﬂuence of extracted com-

monsense information on the whole set (see columns

2 and 3 in table 2, all questions). The main mes-

sage of table 2 is that the performance increases from

77% to 91% on the complete questions set, if we add

commonsense information to the knowledge engine

(columns 2 and 3). This shows the importance of ac-

tion pattern information for situational reasoning.

The instance questions (column 1) refer directly to

instances in the environment, without any context in-

formation extracted from commonsense, which is the

usual way in Embodied Question Answering. That

means, this set measures the basic reasoning capabil-

ities without the need to query action patterns. This

also shows the drop of performance (from 94% to

77%) once we add questions that require context in-

formation by applying the complete set.

5 CONCLUSION

We proposed Situational Question Answering (SQA),

which is a new direction based on Embodied Question

Answering with the addition of situational reasoning.

The main intention is to enforce an agent to show its

abilities to reason on all day situations and infer con-

textually related items in its environment.

The novelty of this paper can be divided into two

parts. First, the introduction of action patterns for

question answering and the tight linkage to language

understanding. Second, the embedding of observa-

tions and action patterns that are fed by commonsense

information into a single semantic network.

We showed the need to distinct between semantic

types from the view of an agent to allow for realis-

tic decision making in situations. We investigated the

inﬂuence of extracted commonsense information on

questions that require such contextual semantic un-

derstanding. This was reﬂected by an improvement

from 94% to 77% on a large questions set using com-

monsense information.

As an outlook, we plan to extend the extracted

KEOD 2022 - 14th International Conference on Knowledge Engineering and Ontology Development

174

Figure 2: The XAI interface. (A) the dialogue box, which enables the end-user to type in natural-language commands and the

agent will provide answers. (B) Graph Mode, which visualizes the internal computation process of the system. (C) Camera

Mode, which displays the video stream from the virtual home simulator.

Table 1: Templates for different question types ranging from locating, counting and enumerating to asking for the existence of

an object in the simulated environment. Overall, we had 53 objects (such as apple, milk, pillow, remote control, microwave,

etc.) represented by additional 78 upper-class lemmas (such as food, drinks, furniture, etc.). Additionally, we had 12 locations

(e.g. sofa, fridge or dining table), 38 actions (such as drink, sit, cut, eat) and 28 tools related to speciﬁc actions (e.g. fork,

knife, plate or microwave). Column 3 of the table reﬂects the different kinds of knowledge used in the templates. The ﬁnal

column is the semantic type that is returned by the question.

Question Types Question Templates

Required

Knowledge

Return

Types

Locating

”Where is [object]?”

”Where is something to [action]?”

instances

action patterns

location

Counting

”How many [object] are on/in [location]?” instances number

Enumerating

”What is in/on [location]?”

”What tool can I use to [action] an [object]?”

”What object can I [action] with a [tool]?”

instances

action patterns

object

tool

object

Existence

”Is there [object] on/in the [location]?”

”Is there something to [action] on/in the [location]?”

instances

action patterns

bool

Table 2: Accuracy for the different question types from table 1 using no extracted commonsense information about object-

action-tool relations (column 1 and 2) and using commonsense information in column 3. Columns 1 and 2 shows the difference

between the question sets referring to instances directly and questions that require action pattern information. The number in

brackets are the number of questions. The overall count was 321 questions for the complete set.

without commonsense with commonsense

instance questions all questions all questions

Locating 0.86 (48) 0.76 (51) 0.80 (51)

Counting 0.92 (96) 0.92 (96) 0.92 (96)

Enumerating 0.97 (11) 0.71 (44) 0.90 (44)

Existence 1.0 (96) 0.73 (130) 1.0 (130)

Overall 0.94 (291) 0.77 (321) 0.91 (321)

commonsense information to also tackle questions re-

ferring to usual object properties, like taste or consis-

tency. The goal is to step by step improve the situ-

ational interpretation capabilities of an agent by in-

creasing the detailed semantic understanding.

It is also obvious that some situations might be

ambiguous, so that the agent should have the chance

to request more information from the user using di-

alog. Therefore, we also want to extend the set by

ambiguous questions to enforce the agent to raise a

query to the user to ﬁnally resolve a situation.

Situational Question Answering using Memory Nets

175

REFERENCES

Arrieta, A., Diaz-Rordiguez, N., Ser, J. D., Bennetot, A.,

Tabik, S., Barbado, A., Garcia, S., Gil-L

opez, S.,

Molina, D., and Benjamins, R. (2020). Explainable

artiﬁcial intelligence (xai): Concepts, taxonomies, op-

portunities and challenges toward responsible ai. In

Information Fusion.

Baker, C., Fillmore, C., and Lowe, J. (1998). The berkeley

framenet project. In In Proceedings of the Coling-Acl.

Barba, E., Procopio, L., and Navigli, R. (2021). Consec:

Word sense disambiguation as continuous sense com-

prehension. In Conference on Empirical Methods in

Natural Language Processing.

Beetz, M., Bessler, D., Haidu, A., Pomarlan, M.,

Bozcuoglu, A. K., and Bartels, G. (2018). Know rob

2.0 — a 2nd generation knowledge processing frame-

work for cognition-enabled robotic agents. In Inter-

national Conference on Robotics and Automation.

Bevilacqua, M., Pasini, T., Raganato, A., and Navigli, R.

(2021). Recent trends in word sense disambiguation:

A survey. In International Joint Conference on Artiﬁ-

cial Intelligence.

Das, A., Datta, S., Gkioxari, G., S. Lee, D. P., and Ba-

tra, D. (2017). Embodied question answering. https://

arxiv.org/abs/1711.11543. Accessed:2022-07-11.

Diaconu, A. (2020). Learning functional programs

with function invention and reuse. https://

arxiv.org/abs/2011.08881. Accessed: 2022-07-11.

Duan, J., Yu, S., Tan, H. L., Zhu, H., and Tan, C. (2022). A

survey of embodied ai: From simulators to research

tasks. https://arxiv.org/abs/2103.04918. Accessed:

2022-07-11.

Eggert, J., Deigmoeller, J., Fischer, L., and Richter, A.

(2019). Memory nets: Knowledge representation for

intelligent agent operations in real world. In 11th

International Conference on Knowledge Engineering

and Ontology Development. SCITEPRESS.

Eggert, J., Deigmoeller, J., Fischer, L., and Richter, A.

(2020). Action representation for intelligent agents

using memory nets. In Communications in Computer

and Information Science. SPRINGER.

Fellbaum, C. (1998). WordNet: An Electronic Lexical

Database. Bradford Books.

Gordon, D., Kembhavi, A., Rastegari, M., Redmon,

J., Fox, D., and Farhadi, A.(2018). Iqa: Vi-

sual question answering in interactive environments.

https://arxiv.org/abs/1712.03316. Accessed: 2022-07-

11.

He, P., Liu, X., Gao, J., and Chen, W. (2021). Deberta:

Decoding-enhanced bert with disentangled attention.

In Conference on Learning Representations.

Honnibal, M. and Montani, I. (2017). spaCy 2: Natural lan-

guage understanding with Bloom embeddings, con-

volutional neural networks and incremental parsing.

https://sentometrics-research.com/publication/72.

Accessed: 2022-07-11.

Jiao, A. (2020). An intelligent chatbot system based on en-

tity extraction using rasa nlu and neural network. In J.

Phys.: Conf. Ser.

Kolve, E., Mottaghi, R., Han, W., VanderBilt, E., Weihs,

L., Herrasti, A., Gordon, D., Zhu, Y., Gupta,

A., and Farhadi, A. (2019). Ai2-thor: An in-

teractive 3d environment for visual ai. https://

arxiv.org/abs/1712.05474.Accessed: 2022-07-11.

Losing, V., Fischer, L., and Deigmoeller, J. (2021). Extrac-

tion of common-sense relations from procedural task

instructions using BERT. In Proceedings of the 11th

Global Wordnet Conference.

Miller, G. A., Chodorow, M., Landes, S., Leacock, C., and

Thomas, R. G. (1994). Using a semantic concordance

for sense identiﬁcation. In Human Language Technol-

ogy: Proceedings of a Workshop held at Plainsboro.

Pandya, H. A. and Bhatt, B. S. (2019). Question answer-

ing survey: Directions, challenges, datasets, evalua-

tion matrices. https://arxiv.org/abs/2112.03572. Ac-

cessed: 2022-07-11.

Paulius, D. and Sun, Y. (2018). A survey of knowledge rep-

resentation in service robotics. In Robotics and Au-

tonomous Systems.

Puig, X., Ra, K., Boben, M., Li, J., Wang, T., Fidler, S.,

and Torralba, A. (2018). VirtualHome: Simulating

household activities via programs. In Conference on

Computer Vision and Pattern Recognition.

Schuler, K. K. (2005). VerbNet: A Broad-Coverage, Com-

prehensive Verb Lexicon. University of Pennsylvania.

Speer, R., Chin, J., and Havasi, C. (2017). Conceptnet 5.5:

An open multilingual graph of general knowledge. In

Proceedings of AAAI-31.

Spinner, T., Schlegel, U., Sch

afer, H., and El-Assady, M.

(2019). explainer: A visual analytics framework for

interactive and explainable machine learning. In IEEE

Transactions On Visualization And Computer Graph-

ics.

Tan, S., Ge, M., Guo, D., Liu, H., and Sun, F.

(2021). Knowledge-based embodied question an-

swering. https://arxiv.org/abs/2109.07872. Accessed:

2022-07-11.

Tangiuchi, T., Mochihashi, D., Nagai, T., Uchida, S., Inoue,

N., Kobayashi, I., Nakamura, T., Hagiwara, Y., Iwa-

hashi, N., and Inamura, T. Survey on frontiers of lan-

guage and robotics. https://arxiv.org/abs/2112.03572.

Accessed: 2022-07-11.

Thosar, M., Zug, S., Skaria, A. M., and Jain, A. (2018).

A review of knowledge bases for service robots in

household environments. In 6th International Work-

shop on Artiﬁcial Intelligence and Cognition.

Tiddi, I. and Schlobach, S. (2022). Knowledge graphs as

tools for explainable machine learning: A survey. In

Artiﬁcial Intelligence.

Tjoa, E. and Guan, C. (2020). A survey on explainable arti-

ﬁcial intelligence (xai): Toward medical xai. In IEEE

Transactions On Neural Networks And Learning Sys-

tems.

Yu, L., Chen, X., Gkioxari, G., Bansal, M., Berg, T. L., and

Batra, D. (2019). Multi-target embodied question an-

swering. https://arxiv.org/abs/1904.04686. Accessed:

2022-07-11.

KEOD 2022 - 14th International Conference on Knowledge Engineering and Ontology Development

176
