Detecting Java Programming Language Smell Code with a Long

Parameter List

Fajar Ratnawati and Jaroji

Politeknik Negeri Bengkalis, Bengkalis, Riau, Indonesia

Keywords: Smell Code, Java, Long Parameter List.

Abstract: This research resulted in the evaluation of the smell code (wrong program code) in the Java programming

language. The main objective to be achieved in this study is to detect the smell code (wrong program code)

so that the quality level of the code can be seen. The smell code that will be detected in this study is a long

parameter list. To support the research process, the evaluation phase of a Java-based application case study

was taken from the PMD static code analyzer as a code inspection sample for smell code detection and

software metric calculations. The results obtained are code detection based on smell code rulesets, namely

warning errors that have been determined with a number of parameters greater than four.

1 INTRODUCTION

The complexity of software systems is currently

increasing at such a rapid pace that software

companies must constantly update the source code

that has been created (D. Di Nucci et al, 2018). These

ongoing changes frequently take place under duress

and in a short period of time. As a result, developers

abandon sound programming practices and

principles. They want to provide the best product

possible but are unable to do so because they are

working in the shortest amount of time possible (F.

Shull et al, 2013). In other words, the source code's

quality is not optimal or good because of an error or

problem in the source code.

Java is a popular programming language because

the range of applications that can be made using this

language is very wide, from computers to

smartphones (Mardison, 2017). The Java

programming language is known as OOP-Object

Oriented Programming. Java was first developed by

Sun Microsystems, which was started by James

Gosling and released in 1995. Currently, Sun

Microsystems has been acquired by Oracle

Corporation. Java is Write Once, Run Anywhere (a

program that is written once and can run on multiple

platforms). Just like programming in general, the Java

programming language can work using a database.

Almost all of the Study Programs in the Informatics

Engineering Department use the Java programming

language for the practicum learning process. Hundreds

of Java program codes, the result of student

assignments, are still manually checked. Sometimes,

only checked by the output generated from the code

without regard to the quality of the program.

Smell code is a term used to indicate that there

may be a problem in a program's code. (Slinger and

Stevan, 2005). A smell in code indicates that

something is wrong, or that it should not be in the

code. Smell code is a problem caused by a design flaw

in a piece of software. This poor design can lower the

quality of the compiled software. Smell code must be

reduced by detecting its presence in program code

and repairing it as needed. Humans can detect smell

codes manually, or a system can do it automatically.

However, manual detection will take a long time,

especially if hundreds of program codes are to be

detected. As a result, we require a code smell detector

device that can be used automatically to detect

hundreds of program codes in a relatively short period

of time.

The long parameter list is one of the methods in

the smell code. There is no specific rule on how many

parameters to use in one method. Usually, more than

three or four is considered too many. Long parameters

that are easy to recognize include:

1. It is hard to use a method call or to get the

parameters in the correct order.

2. It is hard to read and interpret what a method call

does.

3. A method call has boolean parameters.

228

Ratnawati, F. and Jaroji, .

Detecting Java Programming Language Smell Code with a Long Parameter List.

DOI: 10.5220/0011755100003575

In Proceedings of the 5th International Conference on Applied Science and Technology on Engineering Science (iCAST-ES 2022), pages 228-231

ISBN: 978-989-758-619-4; ISSN: 2975-8246

4. A method call has null parameters as optional

parameters.

Long parameter lists can occur due to trying to do too

many things in a method or trying to minimize

dependencies between objects.

To realize the ideas outlined in the background

above, there are problems that will be researched and

found the right solution model. These problems are as

follows:

1. How to design in building a system for detecting

smell code.

2. How to implement a smell code detection system

using long parameter list.

3. How to detect error code or bad code (smell code)

in the Java programming language.

This study focuses on detecting smell codes with the

type of bad smell long parameter list for the Java

programming language.

2 LITERATURE REVIEW

There have been several studies related to the topic of

discussion so far, which later became development

material. Sujadi's research seeks to identify smell

codes and anti-patterns in case studies of E-

Commerce applications that manage goods and

customer master data, as well as sales and payment

transactions (Sujadi, 2019).

Putro and Liem's research aims to detect code

smells that can be used for all programming

languages, particularly to evaluate the outcomes of

practical work on programming lectures, using data

in xml format and a by-rules approach (Putro and

Liem, 2010). The research of Firdaus et al aims to

detect a refused bequest type of smell code during the

design stage (Firdaus et al., 2018).

J. Kreimer's research uses Decision Trees as an

approach to classifying and building a knowledge

base. The training and detection phases are carried out

independently. The knowledge base model is built in

the training phase. The model represents the result of

accumulated knowledge that was previously learned

based on input from users. The study also uses

software metrics as a feature to identify bad smells.

Some examples of bad smells that are targeted to be

detected in this research are long method and big

class. (Kreimer, 2005).

3 PROPOSED FRAMEWORK

SMELL CODE

The proposed smell code framework consists of four

stages, namely collecting java projects, creating data

sets, creating java code detection rules, and smell

code detection systems. The smell code framework

can be seen in the following figure.

Figure 1: Proposed Framework Smell Code.

Collecting java projects as data sources, this

project was obtained from Qualitas Corpus which is a

collection of heterogeneous or unique software

systems used in empirical studies related to Java code

artifacts. In this study, two projects were used as data

sources, namely freemind and jasml.

Next, create a dataset from the downloaded java

project (freemind & jasml) using the WekaNose

tools, there are several stages in making this dataset.

a. Extraction of metrics or calculate each metric in

the java project, which will be used as a feature in

machine learning.

b. Determine the rules that will categorize the

dataset into normal (false), and smell (true).

c. Manually labelling true/false on the generated

dataset.

d. Build a detection rule model

The results are used as rules on the smell code

detection system. For more details can be seen in the

following image.

Figure 2: System Flow Built.

The picture above describes the workflow of the

system created, namely:

1. The user opens the web page of the smell code app

detector.

Detecting Java Programming Language Smell Code with a Long Parameter List

229

2. The user enters a line of Java code and presses the

analyze button.

3. The line of code will be sent to the server.

4. The server will analyze the line of code based on

the pre-defined rules.

5. If a smell code is found in the code, a warning

message will be sent along with the smell code

details to the user's browser.

6. Done

4 DESIGN RESULT

The result achieved in this research is a smell code

detection system for the Java programming language.

This system is web-based and has a user-friendly

interface.

Figure 3: Initial View.

The picture above is the initial appearance of the

smell code system. There is a window to enter the

Java code and an analyze button to check whether

there is a smell code or not. After the Java code is

entered, the next step is to press the analyze button.

Figure 4: Java Code Example.

The figure depicts an example of the program

code that is entered, which contains a long parameter

list in the constractor method. As a result, the system

able to detect the smell code. Figure 4 indicates the

result of detecting the smell code.

Figure 5: The Resulting Output.

There were seven smell codes detected in the Java

code, including members serialize problem, long

parameter list, and variable unused. User can fix their

java code and try to check it again using this system.

If the Java code detects a long parameter list, then

the things you can do are as follows:

1. If the parameter can be obtained from another

object, replace the parameter with a method call.

The object can be a field in the class or passed as

a parameter.

2. If the parameters belong to a single object,

preserve the whole object.

3. If the parameters come from different objects,

introduce a parameter object.

4. If there is a boolean parameter, consider replacing

the parameter with explicit methods.

The benefit of long-side parameter list detection

is that it improves code readability and reduces

duplication. A long parameter list is sometimes

needed for some programmers for some reason. So,

smell code detection also does not guarantee that all

Java code will be free from problems.

5 CONCLUSIONS

This system makes it easier for users to check the

smell code of Java code so that it can assist in building

applications in the Java programming language.

Using a long parameter list can reduce the number of

parameters in a method and avoid duplicates.

REFERENCES

D. Di Nucci, F. Palomba, D. A. Tamburri, A. Serebrenik

and A. De Lucia, "Detecting code smells using machine

learning techniques: Are we there yet?," 2018 IEEE

25th International Conference on Software Analysis,

Evolution and Reengineering (SANER), 2018, pp. 612-

621, doi: 10.1109/SANER.2018.8330266.

iCAST-ES 2022 - International Conference on Applied Science and Technology on Engineering Science

230

F. Shull, D. Falessi, C. Seaman, M. Diep, and L. Layman,

Perspectives on the Future of Software Engineering.

Springer, 2013, ch. Technical Debt: Showing the Way

for Better Transfer of Empirical Results, pp. 179–190.

Firdaus, M.F., Priyambadha, B., Pradana, F. (2018).

Pembangunan Sistem Untuk Pendeteksian Code Smells

Refused Bequest. Jurnal Pengembangan Teknologi

Informasi dan Ilmu Komputer. Vol. 2, No. 12

J. Kreimer, “Adaptive Detection of Design Flaws,”

Electronic Notes in Theoretical Computer Science, pp.

117-146, 2005.

M. Fowler, K. Beck, J. Brant, W. Opdyke dan d. Roberts,

Refactoring: Improving the Design of Existing Code,

Boston: Addison-Wesley Longman Publishing Co.,

Inc, 1999.

Mardison, 2017. Perancangan Sistem Penunjang Keputusan

Untuk Mengoptimalkan Pemberian Kredit Pada Bank

Bpr Kubang Dengan Bahasa Pemrograman Java Dan

Didukung Dengan Database Mysql. Jurnal Processor.

Jilid 7. Terbitan 1

Putro, H.P., Liem, I., (2010). Deteksi Code Smell Pada

Kode Program Dalam Representasi Ast Dengan

Pendekatan By Rules. Seminar Nasional Aplikasi

Teknologi Informasi 2010 (SNATI 2010). Yogyakarta

Slinger, Stevan, 2005. Code Smell Detection in Eclipse.

Delft University of Technology, Delft, Belanda.

Sujadi, S.F. (2019). Evaluasi Deteksi Smell Codedan Anti

Patternpada Aplikasi Berbasis Java. Jurnal Teknik

Informatika dan Sistem Informasi. Volume 5 Nomor3.

Detecting Java Programming Language Smell Code with a Long Parameter List

231
