Single Sign On (SSO) System with Application of Central

Authentication Service (CAS) at Manado State Polytechnic

Marike Kondoj

, Tineke Saroinsong

and Anritsu Polii

Informatics Engineering, Manado State Polytechnic, Indonesia

Mechanical Engineering, Manado State Polytechnic, Indonesia

Keywords: Application, SSO, Polimdo, Integrated.

Abstract: Integrated information systems are an essential requirement in the digital era. However, the number of

currently available/running applications at the Manado State Polytechnic (Polimdo) with different accounts

makes it difficult for users to access or remember their accounts. Based on this condition, it is necessary to

have a solution for implementing a Single Sign On a system that allows users to have one application for

several applications. The purpose of this research is to integrate all applications currently running at Polimdo

to provide effective and efficient conditions for the utilization of each application. The expected result is a

system developed according to user needs so that the utilization of the application can be effective.

1 INTRODUCTION

In the current era of technological development, the

world of information is increasingly dynamic.

Because it is supported by technology and the use of

the internet, which is increasing rapidly and

increasing, according to Emarketer (2013), internet

users (www) will increase from 26.3% in 2012 to

30.7% in 2016 for the Asia-Pacific region. In

Indonesia, internet users reached 63 million users in

2012. It is estimated that an increase of 30% in 2013

was 82 million users, according to the Association of

Indonesian Internet Service Providers (APJII).

The Internet is one form of the development of

information and communication technology (ICT).

ICT has a significant role in the world of education.

In the Ministry of National Education's ICT blueprint,

there are at least seven functions of ICT in education:

learning resources, learning aids, learning facilities,

competency standards, administrative systems,

decision support, and infrastructure. Utilization of the

internet network in previous research by Saroinsong

et al. Design and Implementation of Integrated

Software Research and Community Service at

Manado State Polytechnic (Saroinsong, 2017).

Utilization of the internet network at the Manado

State Polytechnic already has an internet network to

support education and creativity in quality, quality

teaching and learning processes, as well as facilitate

communication and exchange of information in an

academic environment. Many applications require

authentication in the Manado State Polytechnic's

existing infrastructure. Among them are e-learning

learning media, campus mail, and educational

information systems. However, existing web

applications are still not entirely appropriately

integrated. This influences the number of different

State Polytechnic because users must log in to each

application.

In previous studies, a single sign-on (SSO)

method based on the Lightweight Directory Access

Protocol (LDAP) has been researched by Dian

Novera from Bina Darma University. The research

resulted in one username and one password that can

make it easier for users because they don't need to use

many accounts and memorize many passwords.

However, LDAP-based SSO has limitations where

users still have to log in to each application. With that,

the author will test the integration of all applications

into a web portal for further development with the

CAS (Central Authentication Service)-based SSO

method in the Manado State Polytechnic

environment.

In a study by Binu et al., a Single Sign On (SSO)

is an authentication mechanism that allows users to

the same session. SAML is generally used as a Single

Sign-On protocol. The study proposes a Secure

698

Kondoj, M., Saroinsong, T. and Polii, A.

Single Sign On (SSO) System with Application of Central Authentication Service (CAS) at Manado State Polytechnic.

DOI: 10.5220/0011863100003575

In Proceedings of the 5th International Conference on Applied Science and Technology on Engineering Science (iCAST-ES 2022), pages 698-702

ISBN: 978-989-758-619-4; ISSN: 2975-8246

Dynamic-ID-based scheme using a smart card or

crypto card that does not require a verification table

and implements the Single Sign On feature using the

SAML protocol, thus enabling users to enjoy all MSE

features along with SSO.

Furthermore, the research pane, Jian Hu et al.,

stated that frequent verification is an obstacle faced in

constructing campus networks. To overcome these

problems, they integrated the application of the B/S

architecture with the Single sign-on (SSO) system. As

a result, a unified personnel database has been created

using an LDAP server and created dynamic groups to

manage the database.

Single Sign On (SSO) is a system where users

only need one username and password to access and

use services on all existing applications. Central

Authentication Service (CAS) based on the CAS

Protocol is one part of the SSO product. CAS is used

to deal with communication problems between

different applications. With the Site on CAS on SSO

on all existing applications at the Manado State

Polytechnic, who can form application integration in

the form of a web portal. Users only need to log in

once to be able to use all the applications in the web

portal. Users also do not need to memorize many

accounts, just one account. Thus the organization and

integration of user data can be facilitated so that the

security of user data is more guaranteed because the

place used for storing user data becomes systematic

and centralized.

Therefore, one of the solutions to the problems

obtained for the centralized user authentication

system to access all applications at the Manado State

Polytechnic is expected to be implemented by

conducting SSO Technology Analysis with the

application of CAS at the Manado State Polytechnic,

where this research can help users more efficiently

and safely in accessing all existing applications.

From the explanation of the background above,

what can find problems can be discussed and studied

together? The authors formulate the problem in this

study, namely the use of Single Sign On System

Technology Analysis (SSO) with the Central

Authentication Service (CAS) application to access

web applications. Centrally in the system within the

Manado State Polytechnic.

2 PROPOSED METHOD

2.1 Action Research

Action research aims to develop the most efficient

work methods so that what can reduce production

costs and the productivity of institutions can be

increased. Action Research, or Action Research,

according to Davison, Martinsons, and Kock, is

action research that describes, interprets and explains

a social situation or, at the same time, makes changes

or interventions with the aim of improvement or

participation. The stages of research that are part of

this Action Research are:

1. Diagnosing: Identifying existing problems in

previous research becomes the basis for groups

or organizations so that further changes occur.

2. Action Planning: Understanding the main

problem, then developing an appropriate action

plan to solve the existing problem.

3. Action Taking: This action plan is expected to

solve the problem at the implementation stage.

4. Evaluating: The implementation results are

evaluated after the implementation period is

deemed sufficient.

Specifying Learning: This stage is the final part

that has been passed after the criteria in the learning

principle so that the research can end by reviewing

the stages.

2.2 Data Collection

In the data collection method, the authors obtain data

and information in the following ways:

1. Observation: Researchers directly reviewed the

Manado State Polytechnic for the UPT-IT,

which is the centre of the campus information

system.

2. Interview: At this stage, questions are submitted

to UPT-IT Manado State Polytechnic to get

accurate and direct information and data from

sources who know about the research conducted

by the author.

3. Literature: In this literature study, data is

obtained by searching and obtaining materials

on the internet, libraries and journals and books

that are by the object to be studied by the author.

2.3 Design System

The design of the Single Sign On (SSO) system in this

study is described by using a flowchart, as shown in

Figure 1. Starting with login access to the system, it

will then be checked if the user is registered or not. If

not, it is necessary to input the application username

and password and proceed to the SSO registration and

Single Sign On (SSO) System with Application of Central Authentication Service (CAS) at Manado State Polytechnic

699

synchronization process. If registered, you will input

data as an SSO username and password. The next step

is authentication, and access authorization will then

be followed by a display to the system.

Figure 1: Flowchart System Single Sign On (SSO).

Furthermore, the depiction of the use case in the

Single Sign On (SSO) System is shown in Figure 2.

Figure 2: Usecase Single Sign On (SSO).

Figure 2 illustrates a user who can log into several

information systems. All authentication and identity

authorizations are stored on one server.

Figure 3 shows the context diagram of the Single

Sign On (SSO) System. First, the user needs to

in the user database. Furthermore, the user can

perform the login process and who will authenticate

the data first.

Figure 3: Single Sign On (SSO) Context Diagram.

The server specifications used in this study are presented

in table 2.

Table 1: Server Specifications.

No Name Specifications

1 Monitor 14 Inch FHD IPS Anti Glare

2 Processor AMD Ryzen 3 3200U

(2.6GHz up to 3.5GHz)

3 Graphics Radeon Vega 3 Graphics

4 Memory 8GB DDR4

5 Storage 512GB SSD

3 RESULT

The study's results of testing Single Sign On (SSO)

First, they test the organizational information system

using Google email as Single Sign On authentication.

Figure 4 shows the login display of the system.

Figure 4: Managerial System Login Display.

If the option to log in with Google is selected, a

display will appear, as shown in Figure 5.

iCAST-ES 2022 - International Conference on Applied Science and Technology on Engineering Science

700

Figure 5: Google Login Page.

If the email is not connected to any account, a

message will appear that there is no account

connected to the email, and then you must activate

Single Sign On in the settings menu.

Figure 6: Email not connected to SSO.

Emails linked to more than one message will appear

stating that more than one account is linked to that

email, so it is necessary to log in and change the email

in one of the accounts. As shown in figure 7.

Figure 7: Email connected to more than one account.

If you have more than one account connected to the

email that has been used, you must use another email,

as shown in Figure 8.

Figure 8: Multiple accounts are linked by email.

If you change your email to an email that has never

been used, a description will appear, as shown in

Figure 9.

Figure 9: Change the mail with an email that has never been

used.

The results of this study are also presented in the form

of a test table, as shown in table 2.

Table 2: System Testing.

Testing Scenario Test Method Expected Results Test Result Conclusion

SSO login with the condition

that you have added Google

email data to the

organizational information

system and there is no

duplicate email on other

accounts.

Press the "Signed in with

Google" button, then log in

using the google account that

has been registered in the

organizational information

system.

Displays the page according to

the access rights and with the

appropriate account session

Correct Normal

SSO login with the email

condition added is not

registered in the organizational

information system.

Press the "Signed in with

Google" button, then log in

using a google account that

never registered in the

organizational information

system.

If no account is connected to

your email, please log in and

activate Single Sign On in the

Settings menu.

Correct Normal

SSO login with email

conditions registered in 2

different accounts but have the

same email

Press the "Signed in with

Google" button, then log in

using a google account that

never registered in the

organizational information

system.

If you have more than one

account linked to this email,

please log in and change your

email in one of the accounts!

Correct Normal

After successfully logging in,

change the email with the

email that has been registered

in another account

information system, then open

the settings menu and change

email with an email that

another account has used.

Please use another email if you

have more than one account

linked to this email. Correct Normal

After successfully logging in,

change the email to an email

that has not been registered in

another account

information system, open the

settings menu and change

email with an email not used

by another account.

Successfully updated profile,

thank you!

Correct Normal

Single Sign On (SSO) System with Application of Central Authentication Service (CAS) at Manado State Polytechnic

701

SSO makes it possible for users to perform logins that

can be accepted by several separate applications.

With the SSO method, admins can manage users

centrally.s

4 CONCLUSION

The results of research on creating a Single Sign On

(SSO) system based on the Central Authentication

Service (CAS) at the Manado State Polytechnic can

be divided into several parts.

1. The implementation of Single Sign helps portal

users On because it can make it easier for users.

Users do not need to use multiple accounts, only

by using one account that the system has

authenticated.

2. Single Sign On also helps organise users

because the Lightweight Data Access Protocol

(LDAP) is used as a single data user.

ACKNOWLEGMENT

Thank you to the Manado State Polytechnic for facilitating

this research activity and all those who have helped so that

we can complete this research correctly.

REFERENCES

Asosiasi Penyelenggara Jasa Internet Indonesia (APJII).

http://www.apjii.or.id/v2/index.php/read/page/halama

n-data/9/statistik.html. Diakses 29 Juli 2022.

Central Authentication Service (CAS). www.jasig.org/cas.

Diakses 29 Juli 2022

Cartealy, Imam. (2013). Linux Networking. Jakarta:

Jasakom.

Dian, Novera. (2013). Single Sign On (SSO) dengan

Menggunakan Lightweight Directory Access Protocol.

Palembang, Universitas Bina Darma.

Emarketer. (2013). “Asia-Pasific: Digital Ad Spending

Share WorldWide, by Region, 2010- 2016”.

https://www.emarketer.com/Cover age/Asia-Pacific.aspx.

Diakses 28 Juli 2022.

Jian Hu, Qizhi Sun and Hongping Chen, "Application of

Single sign-on (SSO) in Digital Campus," 2010 3rd

IEEE International Conference on Broadband Network

and Multimedia Technology (IC-BNMT), 2010, pp.

725-727, doi: 10.1109/ICBNMT.2010.5705185.

Kasahara, Y., Shimayoshi, T., Ito, E. and Fujimura, N.,

2018, September. The Past, Current, and Future of Our

Email Services in Kyushu University. In Proceedings of

the 2018 ACM SIGUCCS Annual Conference (pp. 103-

106).

Radha, V. and Reddy, D.H., 2012. A survey on single sign-

on techniques. Procedia Technology, 4, pp.134-139.

Rudy, dan Riechie, Odi Gunadi. (2009). Integrasi Aplikasi

Menggunakan Single Sign On Berbasiskan Lightwight

Directory Access Protocol (LDAP) dalam Portal

binus@ccess (BEE-PORTAL). Jakarta, Universitas

Bina Nusantara.

S. Binu, M. Misbahuddin and P. Raj, "A Single Sign on

based secure remote user authentication scheme for

Multi-Server Environments," International Conference

on Computing and Communication Technologies,

2014, pp. 1-6, doi: 10.1109/ICCCT2.2014.7066715.

Saputro, Muhammad Yanuar Ali. (2012). Jurnal

Implementasi Sistem Single Sign On/Single Sign Out

Berbasis Central Authentication Service Protocol pada

Jaringan Berbasis Lightweight Directory Access

Protocol. Universitas Diponegoro.

T. Saroinsong, M. A. S. Kondoj, G. Kandiyoh, and G.

Pontoh, “Design and Implementation of Integrated

Software Research and Community Service at State

Polytechnic of Manado,” J. Phys. Conf. Ser., vol. 953,

p. 012037, Jan. 2018, doi: 10.1088/1742-

6596/953/1/012037.

Xin, L., Liang, L. and Yong, D., 2010, October. Email

information integration with sso in portal service based

on ajax. In 2010 International Conference on Computer

Application and System Modeling (ICCASM 2010)

(Vol. 12, pp. V12-544). IEEE.

iCAST-ES 2022 - International Conference on Applied Science and Technology on Engineering Science

702
