How Does Cognitive Fatigue and Mental Workload Influence Alarm

Detection in Flight Simulator? Classification of Electrophysiological

Signatures with Explainable IA

Massé Eva, Bartheye Olivier and Fabre Ludovic

Centre de Recherche de l’École de l’Air (CREA), Ecole de l’Air et de l’Espace, F-13661, Salon-de-Provence, France

Keywords: Single-Trial Classification, pBCI, Inattentional Deafness, Brain Activity, ERP (Event Related Potentials),

Explainable AI.

Abstract: Relevant sounds such as alarms are sometimes involuntarily ignored, a phenomenon called inattentional

deafness. This phenomenon occurs under specific conditions including high workload (i.e., multi-tasking)

and/or cognitive fatigue. In the context of aviation, such an error can have drastic consequences on flight

safety. The present study used an Oddball paradigm in which participants had to detect rare sounds in an

ecological context of simulated flight. Cognitive fatigue and cognitive load were manipulated to trigger

inattentional deafness, and brain activity was recorded via EEG. Our results showed that alarm omission and

alarm detection can be classified based on a time-frequency analysis of brain activity. We reached a maximum

accuracy of 76.4% when the algorithm was trained on all participants and a maximum of 90.5%, on one

participant, when the algorithm was trained individually. This method can benefit from explainable artificial

intelligence to develop efficient and understandable passive Brain-Computer Interfaces, to improve flight

safety by detecting such attentional failures in real-time and giving appropriate feedback to pilots, according

to our ambitious goal: providing them reliable and rich human/machine interactions.

1 INTRODUCTION

Increased operational capabilities of aircraft had

considerably modified the pilots’ missions. These

changes concern an increase in the time spent

onboard and the complexity of technologies or

operations, particularly in the military domain. These

long periods of intense and sustained cognitive

activities induce cognitive fatigue that is one of the

major risks of incidents/accidents in aviation (e.g.,

Dönmez & Uslu, 2018; Marcus & Rosekind, 2017).

Cognitive fatigue has been shown to occur when

the costs of cognitive effort to perform the activity are

higher than the expected benefits (e.g., Boksem &

Tops, 2008; Kurzban et al., 2013). In this case, after

performing an effortful task, disengagement from the

current task or unwillingness to sustain the effort on

a second task is likely (Inzlicht et al., 2014; Müller &

Apps, 2019). Previous studies found that cognitive

fatigue can impair cognitive performance, leading to

impaired ability to suppress irrelevant information

(selective attention found by Faber et al., 2012), alter

the automatic motor response (online action control

found by Salomone et al., 2021), and more generally

disrupt attentional processes (Boksem et al., 2005).

The influence of cognitive fatigue on

electrophysiological activities has been also reported

as, for example, an increase of the spectral power of

δ, θ, and α frequency bands but a decrease of the

spectral power of β band, as well as a decreased

amplitude of ERP components such as P300, N100

and N200b (e.g., Boksem et al., 2005; Barwick et al.,

2012; Borghini et al., 2012; Zhao et al., 2012;

Wascher et al., 2014 ; Sabeti et al., 2017; Schmidt et

al., 2009). However, these findings are not always

replicated, and some authors do not report any

impairment of performance with cognitive fatigue

(e.g., Ackerman & Kanfer, 2009; Boksem et al.,

2005; Lorist et al., 2005; Möckel et al., 2015; Trejo et

al., 2007). Unknown is whether the decreased

performance or electrophysiological changes

associated with cognitive fatigue are caused by a

progressive deterioration of the cognitive resources or

by an inadequate recruitment of unaltered cognitive

processes, and this is the issue we address here.

Moreover, we aimed at developing a passive brain-

Eva, M., Olivier, B. and Ludovic, F.

How Does Cognitive Fatigue and Mental Workload Inﬂuence Alarm Detection in Flight Simulator? Classiﬁcation of Electrophysiological Signatures with Explainable IA.

DOI: 10.5220/0011958100003622

In Proceedings of the 1st International Conference on Cognitive Aircraft Systems (ICCAS 2022), pages 47-51

ISBN: 978-989-758-657-6

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

computer interfaces (pBCI) based on explainable

classification and explainable machine learning to

infer the influence of cognitive fatigue on

inattentional deafness in the context of flying. To

achieve these ends and following previous studies

(Dehais et al., 2019, 2018), we asked participants to

perform an alarm-detection task during repeated

landing sessions on flight simulator. To accentuate

the presence of cognitive fatigue, we also

manipulated the mental workload. Most originally,

we tested whether a real flight glider-instruction prior

the experiment influence performance in the alarm

detection task on flight simulator. We hypothesized

that (a) cognitive fatigue impairs alarm detection as a

function of the mental workload (b) cognitive fatigue

modulates electrophysiological activities and (c)

these modulations can be used as a predictor of a loss

in pilot’s efficiency.

2 METHODS

Twenty-four pilot-students were recruited for the

experiment (mean age: 22.6 years old, SD = 2.0;

flight experience: 75.6 hours, SD = 79.6 hours,

including 44.7 hours of glider experience, SD = 58.9

hours). Half of the participants had normal daily

activities without any training flight during the whole

day of the experiment (NFBE group), and the other

half had an instruction flight just before the

experiment (IFBE group).

In a first time, participants were asked to evaluate

their level of subjective fatigue (with Visual

Analogous Scales of fatigue and sleepiness, VASf,

and VASs), sleepiness (Karolinska’s Sleepiness

Scale), and alertness (Samn-Perelli scale). Then, they

performed a Stroop task and an arithmetic task to

assess their cognitive control.

In a second time, participants had to perform 6

identical and successive landings in a flight simulator

(on a glider) while performing an alarm detection task

(i.e., auditory Oddball). In this task, they had to detect

rare sounds (i.e., target) and press a key on the

joystick as fast and accurate as possible. In average,

100 sounds were played during a landing, among

which 75 were standard sounds (i.e., to be ignored)

and 25 had to be responded to. The landing was

composed of 2 phases: a low cognitive load phase

(i.e., corresponding to the downwind leg of the

approach: they had to pilot the glider and perform the

Oddball task) and a high cognitive load phase (i.e.,

composed of the base leg, the final and the landing:

they had to pilot the glider, perform the Oddball task,

and perform a backward counting task). Brain activity

was recorded by a Bionic-EEG (32 passive

electrodes).

After the experimental task, they had to perform

again the cognitive tests and the subjective

evaluations.

3 MAIN FINDINGS

3.1 Alarm Detection Task

Performance was analyzed with mixed-design

ANOVAs, 2 (Group: NFBE, IFBE) x 2 (Time on

Task: beginning—the first three landings, end—the

last three landings) x 2 (Cognitive Load: low, high)

with group as the only between-participants factor.

In the low cognitive load condition, participants

were faster and more accurate to detect alarms than in

the high cognitive load condition. A lack of

attentional resources is thus associated with higher

rates of inattentional deafness. Surprisingly, we found

better alarm detection in the IFBE group than in the

NFBE group. One possible explanation to this finding

is that participants of the IFBE group were more

trained to detect alarms due to the prior instruction

flight, compared to NFBE group participants. No

difference of alarm detection rate was observed

throughout successive landings.

3.2 Electrophysiological Signatures

Data were analyzed with mixed-design ANOVAs, 2

(Group: NFBE, IFBE) x 3 (Electrode: Fz, Cz, Pz) x 2

(Sound: target, standard) x 2 (Cognitive Load: low,

high) x 2 (Time on Task: beginning, end) with group

as the only between-participants factor.

3.2.1 ERP Analyses

We found that the amplitude of the P300 component

was higher with target sounds (i.e., rare alarms) than

with standard sounds (i.e., frequent sounds to ignore)

only in the low cognitive load condition. Moreover,

for target sounds, we found an increase of the P300

amplitude under high cognitive load condition

compared to the low cognitive load condition.

No effect of cognitive fatigue was observed on the

amplitude of the P300 component. Possibly, our task

was not sufficiently difficult to increase cognitive

fatigue and to observe modifications on ERPs.

ICCAS 2022 - International Conference on Cognitive Aircraft Systems

3.2.2 Frequency Analysis

Results showed that the spectral power of δ band

tended to vary as a function of the temporal window.

The spectral power was larger at the beginning

compared to the end of the task. The effect of

cognitive load was observed on the β spectral power

for the NFBE group. β spectral power was larger for

high cognitive load condition than for low cognitive

load condition. These results are correlated with

slower latencies in alarm detection observed under

high cognitive load conditions.

3.3 Subjective Scales and Cognitive

Tests

No differences were observed between the beginning

and the end of the experimental session for the Visual

Analogous Scale of Fatigue, the Samn-Perelli scale

and the Karolinska scale.

Performance in the Stroop task was analyzed with

mixed-design ANOVAs, 2 (Group: IFBE, NFBE) x 2

(Session: pre, post) x 2 (Congruency: congruent,

incongruent), with group as the only between-

participants factor. We found a significant

congruency effect (i.e., better performance on

congruent trials compared to incongruent trials). Most

interestingly, the NFBE group performed better than

the IFBE group (i.e., 96.3% vs. 94.6%). The

interference score increased after the experimental

task only in the IFBE group. These results suggest a

decrease of cognitive control for participants of the

IFBE group compared to the NFBE group.

Performing the same activity before and during the

experiment could lead participants to be less accurate

particularly when they had to inhibit automatic

responses. The control of automatic response and

more generally the cognitive control seems to depend

on the nature of the preceding task.

To summarize, we cannot conclude that cognitive

fatigue is responsible for the observed modulations of

electrophysiological activities. However, it is

possible that the manipulation of cognitive load

during sustained activity influences brain activity, as

suggested by the modulation of the δ and β frequency

bands. These manipulations could have resulted in a

significant modulation of the subjective cognitive

fatigue in other conditions (i.e., longer runs, more

complex weather conditions, more landings...). In the

low cognitive load condition, participants benefit

from more attentional resources to process target

sounds than in in the high cognitive load condition.

These differences do not exist for standard sounds

that must be ignored. In other words, cognitive

fatigue could seem to impair performance as a

function of attentional resources available. The

frequency analysis can also be explained in term of

decrease in attentional resources, but the differences

between the beginning and the end of experiment

could also reflect a lack of motivation at the end of

the experiment.

3.4 Single Trial Classification of Alarm

Detection or Omission and

Decision-Making Tress

To compare electrophysiological signals between

alarm detections and alarm omissions, we focused our

analyses on the high cognitive load condition. Data

were analyzed with 2 (Group: IFBE, NFBE) x 2

(Time on Task: beginning, end) x 3 (Electrode: Fz,

Cz, Pz) x 2 (Response: hit, miss) ANOVAs with

group as the only between-participants factor. 80% of

trials were used to train classifiers and 20% were used

to test them.

The spectral power of the δ frequency band and

the α frequency band was larger for hit trials

compared to miss trials. The differences between hit

and miss trials were significant only at the beginning

of the session. Moreover, the spectral power of the

mid-β frequency band in the NFBE group was larger

for hits than for missed alarms at the beginning of the

session. We then classified trials with respect to alarm

omission or detection and we reached a maximum

averaged performance of 76.4% (range: 57.7% —

90.5%) in participant-specific single-trial

classification from the spectral power of δ and α

frequency bands with Support Vector Machines

classifier. Frequency features, and more specifically

δ and α bands, implemented in a support vector

classifier formed an efficient tool to assess auditory

alarm misperception in simulated flight conditions.

4 CONCLUSIONS

A way to improve the experimentation domain

consists of putting the classification work above in a

virtuous cognitive loop; to do so, we need explainable

classification methods to be able to interpret the

knowledge acquired. Such an understandable

information, which can be either numerical,

symbolic, or logical, constitutes the support of rich

human/machine interactions and justifies the

interpretability criterion providing a good level of

confidence at the operational level. For instance, the

Classification and Regression Trees (CART)

How Does Cognitive Fatigue and Mental Workload Inﬂuence Alarm Detection in Flight Simulator? Classiﬁcation of Electrophysiological

Signatures with Explainable IA

algorithm delivers logical rules as the criteria

separating alarm omission and detection from values

on the four centered electrodes Cz, Pz, Oz and Fz.

Starting from a normalized form of these rules which

is easily explainable as a Boolean expression, we can

generate the appropriate code in a static context or in

dynamic context. In a static context, once EEG values

are available, one can predict attention failure

regardless to the software involved as the

implementation context (Python, Java, Matlab, …); in

a dynamic context, this is more interesting: since one

can define an active role for electrodes taken as agents

with a dedicated level of knowledge. That way, one

can reengineer completely these rules according to

electrodes as both actuators and sensors. That way,

one can improve the experimentation domain by of

putting the classification work in the loop thanks to a

multi-agent model. Active electrodes become virtual

agents (sensors and actuators) connected together

thanks to logical connectors as firing rules. including

other actuators (red light alarm, sounds, …). Domain-

specific scenarios and doctrines can be defined.

thanks to explainable classification. From that

situation awareness, one can expect connect more

powerful automatic decision mechanisms. In effect,

abnormal behavior detection is the first step of the

sense-making process relayed by decision-making.

For instance, the purpose is to trigger a sequence of

actions to be engaged, whether these actions are

automatic or not. As a use-case, one can mention the

situation in a cockpit characterized by a loss of

attention of the pilot and his/her inability to continue

his/her current mission. That is, the operator did not

consciously detect the alarm although his brain

processed the signal. It is therefore necessary to

inform the operator that he has omitted the alarm (by

feedback) and to adapt the work environment with the

explainable AI to help him in his task so that he comes

back in the loop.

REFERENCES

Ackerman, P. L., & Kanfer, R. (2009). Test length and

cognitive fatigue: An empirical examination of effects

on performance and test-taker reactions. Journal of

Experimental Psychology: Applied, 15(2), 163-181.

Barwick, F., Arnett, P., & Slobounov, S. (2012). EEG

correlates of fatigue during administration of a

neuropsychological test battery. Clinical

Neurophysiology, 123(2), 278-284.

Boksem, M. A. S., Meijman, T. F., & Lorist, M. M. (2005).

Effects of mental fatigue on attention: An ERP study.

Cognitive Brain Research, 25(1), 107-116.

Boksem, M. A. S., & Tops, M. (2008). Mental fatigue:

Costs and benefits. Brain Research Reviews, 59(1),

125-139.

Borghini, G., Vecchiato, G., Toppi, J., Astolfi, L.,

Maglione, A., Isabella, R., Caltagirone, C., Kong, W.,

Wei, D., Zhou, Z., Polidori, L., Vitiello, S., & Babiloni,

F. (2012). Assessment of mental fatigue during car

driving by using high resolution EEG activity and

neurophysiologic indices. 2012 Annual International

Conference of the IEEE Engineering in Medicine and

Biology Society, 6442-6445.

Dehais, F., Duprès, A., Blum, S., Drougard, N., Scannella,

S., Roy, R., & Lotte, F. (2019). Monitoring Pilot’s

Mental Workload Using ERPs and Spectral Power with

a Six-Dry-Electrode EEG System in Real Flight

Conditions. Sensors, 19(6), 1324.

Dehais, F., Dupres, A., Di Flumeri, G., Verdiere, K.,

Borghini, G., Babiloni, F., & Roy, R. (2018).

Monitoring Pilot’s Cognitive Fatigue with Engagement

Features in Simulated and Actual Flight Conditions

Using an Hybrid fNIRS-EEG Passive BCI. 2018 IEEE

International Conference on Systems, Man, and

Cybernetics (SMC), 544-549.

Dönmez, K., & Uslu, S. (2018). The Relationship Between

Flight Operations and Organizations in Aircraft

Accidents; The Application of the Human Factor

Analysis and Classification System. Anadolu

University Journal of Science and Technology A -

Applied Sciences and Engineering, 1-1.

Faber, L. G., Maurits, N. M., & Lorist, M. M. (2012).

Mental Fatigue Affects Visual Selective Attention.

PLoS ONE, 7(10), e48073.

Inzlicht, M., Schmeichel, B. J., & Macrae, C. N. (2014).

Why self-control seems (but may not be) limited.

Trends in Cognitive Sciences, 18(3), 127-133.

Kurzban, R., Duckworth, A., Kable, J. W., & Myers, J.

(2013). An opportunity cost model of subjective effort

and task performance. Behavioral and Brain Sciences,

36(6), 661-679.

Lee, K. A., Hicks, G., & Nino-Murcia, G. (1991). Validity

and reliability of a scale to assess fatigue. Psychiatry

Research, 36(3), 291-298.

Lorist, M. M., Boksem, M. A. S., & Ridderinkhof, K. R.

(2005). Impaired cognitive control and reduced

cingulate activity during mental fatigue. Cognitive

Brain Research, 24(2), 199-205.

Marcus, J. H., & Rosekind, M. R. (2017). Fatigue in

transportation : NTSB investigations and safety

recommendations. Injury Prevention, 23(4), 232-238.

Möckel, T., Beste, C., & Wascher, E. (2015). The Effects

of Time on Task in Response Selection—An ERP

Study of Mental Fatigue. Scientific Reports, 5(1),

10113.

Müller, T., & Apps, M. A. J. (2019). Motivational fatigue :

A neurocognitive framework for the impact of effortful

exertion on subsequent motivation. Neuropsychologia,

123, 141-151.

Sabeti, M., Boostani, R., & Rastgar, K. (2017). How mental

fatigue affects the neural sources of P300 component?

Journal of Integrative Neuroscience, 17, 1-19.

ICCAS 2022 - International Conference on Cognitive Aircraft Systems

Salomone, M., Burle, B., Fabre, L., & Berberian, B. (2021).

An Electromyographic Analysis of the Effects of

Cognitive Fatigue on Online and Anticipatory Action

Control. Frontiers in Human Neuroscience, 14,

615046.

Schmidt, E. A., Schrauf, M., Simon, M., Fritzsche, M.,

Buchner, A., & Kincses, W. E. (2009). Drivers’

misjudgement of vigilance state during prolonged

monotonous daytime driving. Accident Analysis &

Prevention, 41(5), 1087-1093.

Trejo, L. J., Knuth, K., Prado, R., Rosipal, R., Kubitz, K.,

Kochavi, R., Matthews, B., & Zhang, Y. (2007). EEG-

Based Estimation of Mental Fatigue : Convergent

Evidence for a Three-State Model. In D. D. Schmorrow

& L. M. Reeves (Éds.), Foundations of Augmented

Cognition (Vol. 4565, p. 201-211). Springer Berlin

Heidelberg.

Wascher, E., Rasch, B., Sänger, J., Hoffmann, S.,

Schneider, D., Rinkenauer, G., Heuer, H., & Gutberlet,

I. (2014). Frontal theta activity reflects distinct aspects

of mental fatigue. Biological Psychology, 96, 57-65.

Zhao, C., Zhao, M., Liu, J., & Zheng, C. (2012).

Electroencephalogram and electrocardiograph

assessment of mental fatigue in a driving simulator.

Accident Analysis & Prevention, 45, 83-90.

How Does Cognitive Fatigue and Mental Workload Inﬂuence Alarm Detection in Flight Simulator? Classiﬁcation of Electrophysiological

Signatures with Explainable IA
