Update on Our Ongoing Evaluation of Our Workload Monitoring

System During a Simulated Event

Thomas de Groot, Manon L. Tolhuisen, Rafal Hrynkiewicz, Tije Oortwijn and Johan de Heer

Thales - Human Behavior Analytics Lab, Zuidelijke Havenweg 40, 7554 RR Hengelo, The Netherlands

Keywords: Human Behaviour Analytics, Human Cognitive State Monitoring.

Abstract: In complex task environments, especially during crisis management scenarios, optimal performance is

essential. Workload levels are associated with levels of performance. We aim to develop a human cognitive

monitoring tool that aids in reaching optimal performance levels by providing insight into the experienced

workload of one or multiple operators. Here, we give an update on our ongoing evaluation findings regarding

our human workload monitoring tool that was tested in operational security operations centers in the context

of the IMPETUS project.

1 INTRODUCTION

This paper addresses our workload assessment tool

that was evaluated in a series of simulated crisis

management scenarios in two smart cities. The

human workload monitoring system (WMS) was

developed to monitor the workload of human

operators in real time during crisis management

operations and provide feedback when workload

levels are suboptimal. Operators were working in a

Security Operations Centre (SOC) and the workload

assessment tool sent out alerts when observed levels

of workload were different than expected. This work

was done on a European project named IMPETUS

(Gorman et al., 2023). We report an update on our

evaluation findings.

2 WORKLOAD ASSESSMENT

TOOL

Our tool focuses on the monitoring of human

workload and team collaboration since both

constructs directly impact human performance. The

inverted U-shape relation between the human state

and performance suggests a tipping point indicating

that at an appropriate level of state maximum

performance can be expected. Note that this relation

has been associated with complex task environments

such as command and control settings. In addition,

there is no absolute value attached to the human state

level, and the definition of what is the appropriate

state is likely to vary across operators. But the general

notion is clear, too low, or too high workload levels

reduce the level of performance (Yerkes, 1908).

During a crisis management scenario, SOC

operators are interacting with their equipment and

with each other, while performing their specific tasks.

Mostly, operators must process information coming

from multiple input channels, both visual and

auditory, and subsequently act by communicating

with the system or their team members.

The number and complexity of the tasks will

affect the experienced workload and alter both the

operator’s behavior and biosignals. From these two,

biosignals are a more suitable information source for

workload assessment since the alteration of the

biosignals in response to workload is involuntary,

while behavior can intentionally be altered

(Giannakakis, 2022). We measure biosignals

continuously, in real time, and as unobtrusively as

possible.

The end goal of the monitoring tool is to provide

timely feedback and assure that operators can perform

their tasks without being overloaded or overstressed

which might impede their work and introduce

unwanted reduced effectiveness of the operators.

Feedback provided by the WMS is based on a rule

system that is configurable. For example, the rule

could be to generate an alert when workload levels

exceed a certain threshold for a longer period, say 3

minutes. Assessments are shown as feedback in a

configurable amount of detail, on individual and

de Groot, T., Tolhuisen, M., Hrynkiewicz, R., Oortwijn, T. and de Heer, J.

Update on Our Ongoing Evaluation of Our Workload Monitoring System During a Simulated Event.

DOI: 10.5220/0011962100003622

In Proceedings of the 1st International Conference on Cognitive Aircraft Systems (ICCAS 2022), pages 73-76

ISBN: 978-989-758-657-6

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

aggregated (team) levels, to person or persons of

choosing, in the form of a (digital) dashboard. This

feedback can also be used in the context of a Human

Machine Teaming application to close the loop (Fig.

1) and adapt the human-machine interface to the

operators being assessed to balance the cognitive load

and drive mission effectiveness.

Figure 1: Schematic representation of the assessment flow:

team members are sensed, neuro-physiological

measurements are analyzed, workload and team

collaboration are assessed, and feedback is available for

interventions such as load balancing.

3 EVALUATING THE HUMAN

WORKLOAD MONITORING

SYSTEM IN AN

OPERATIONAL

ENVIRONMENT

We tested the WMS in the IMPETUS project. The

goal of IMPETUS is to provide city authorities with

new means to address security issues in public spaces.

Using data gathered from multiple sources, the

project aims to facilitate the detection of threats and

help human operators to deal with threats by making

better-informed decisions. IMPETUS will detect

potential threats by using AI techniques to search

social media and the deep/dark web for unusual and

suspicious activities and to analyze available smart

city data complying with ethical, legal, and societal

issues (ELSI). Threats will be classified and assessed

to determine an appropriate response using an

approach that employs the power of AI to support

situational awareness, human judgment, problem-

solving, sense-making, and decision-making. The

project builds on tested technologies but enhances

and combines them in a coherent and user-centered

solution that goes beyond the state-of-the-art in key

areas such as detection, simulation & analysis, and

intervention. For IMPETUS we configured our

workload assessment tool to the requirements of the

project Part of the research in the IMPETUS project

is to evaluate all tools in an operational environment

provided by two partner cities Oslo (Norway) and

Padova (Italy).

3.1 Method

We tested our WMS (Fig 2) in various SOCs in the

cities of Oslo and Padova. We monitored the

workload of SOC operators interacting in a series of

simulated events. The SOC operators were wearing a

Muse S, which captures both PhotoPlethysmo-Gram

(PPG) and ElectroEncephaloGram (EEG) signals.

We collected data from a single PPG sensor that was

located on the skin. The PPG sensor records the

capillary blood flow that can be translated to the local

pulse. Four EEG electrodes located at the scalp

recorded the electrical activity of the brain, i.e., EEG

signals. From these signals, we computed features,

including multiple heart rate variability features and

the EEG spectral band power of the Theta, Alpha,

Beta, and Gamma frequency bands.

Before the simulated events, we collected data

from the operator while performing a calibration task.

These data were used to train personalized models for

the mental, emotional, and physical workload. The

calibration task included a controlled environment in

which the operator had to perform multiple tasks with

varying difficulty to simulate the range in the

cognitive load that the operators may experience in a

SOC. Data management, privacy, and ethical

concerns were part of the tool design process.

Figure 2: Human workload monitoring tool.

The initial evaluation sessions were performed in

November and December 2021 in the SOC in Oslo

town hall and the Cyber SOC and Municipality

CCTV SOC in the City of Padova, respectively. As

reported earlier (De Groot, 2022), during these

sessions we evaluated the usability and

interpretability of the HMT in collaboration with

multiple SOC operators in a single-operator and

multiple-operator setting. Subsequent evaluation

ICCAS 2022 - International Conference on Cognitive Aircraft Systems

sessions were organized in August and September

2022. During these sessions, the usability of the

WMS was further evaluated in a scripted scenario that

simulated a realistic event. Additionally, we

evaluated the experienced and hypothesized impact

of the WMS on real-life operations, now and in the

future.

From the first event, in Oslo, we learned that the

collection of the calibration data for the models the

day before the actual evaluation was suboptimal since

the operators were distracted by the organization of

the actual event. Therefore, for the second event in

Padova, we collected the calibration data a few weeks

upfront. During the evaluation, the operators used

several other IMPETUS tools during several

roleplays just outside the city hall. In Oslo, a single

operator participated in the simulated event. The Oslo

city hall was closed to the public, but the SOC was

still operational. At the Cyber SOC in Padova, the

operator was able to fully focus on the evaluation

scenario. In parallel, the workload assessment tool

captured the operators’ neuro-physiological data

using the Muse S, which was processed in real time

resulting in a workload classification (low, medium,

high) for each workload dimension (physical,

emotional, mental). If the workload classifications

remained high for over three minutes an alert was

generated and visualized in the dashboard.

The test included an explanation of the workload

assessment tool dashboard. The alerts were presented

on the IMPETUS dashboard which was accessible by

the supervisor of the SOC. The supervisor also had

access to the WMS dashboard.

The assessment tool enabled the supervisor to act

when a team member was mentally and physically

under or overloaded and/or stressed. Both operators

and their supervisors were included in the

debriefing/interview afterward. During the debrief we

asked the operators and supervisors about their

experience with the tool, specifically focusing on:

• the time needed for the calibration and training

of the tool,

• the impact of the tool on their normal

activities,

• the impact of wearing the sensors,

• the influence of the HMT on the experienced

workload, and potential cyber security issues.

3.2 Results and Discussion

From the evaluation, we have learned that:

• The calibration task, including the setup, takes

around 2 to 3 hours. The design choice is

based on personalized workload models given

the variability in perceived workload between

subjects. However, the enrolment procedure

could be optimized with an online learning

procedure where we start off with a generic

workload model that is periodically or

continuously adapted over time.

• The collection of calibration data is preferably

collected at a moment when the operator is not

distracted by other activities. This points to a

potential bias or skewness in the dataset used

for model training that may impact our

workload prediction. However, it is

challenging to design a calibration task that

results in a calibration dataset with evenly

distributed workload labels since the

experienced complexity of the calibration task

varies between subjects.

• The dashboard of the workload assessment

tool is considered informative, and easy to use

by both supervisor and operator.  Alerts and

feedback are preferably shown to the

supervisors instead of the operators because

the operators experienced increased workload

due to the visibility of the HMT results. The

operators and supervisors saw the potential of

monitoring the workload levels during daily

life. However, further exploration is needed to

determine the actions required after an alert is

generated. These issues reflect the operational

embedding of human state assessment tools in

general. An objective standardized human

assessment tool is not part of current

procedures and mitigating strategies relating

to human error.

• During the simulated scenario, like the

previous evaluation, the MUSE S headband

was considered comfortable, unobtrusive, and

easy to wear. Also, here the design choice is

characterized by the trade-off between a

number of channels to measure EEG and

therefore potentially an increase in model

accuracy versus usability requirements related

to unobtrusive measurements.

4 CONCLUSIONS

We reported an update on our findings from the

evaluation of our WMS during a simulated event that

was organized in the context of the IMPETUS

project. The WMS was intuitive, and the sensors were

not impacting their daily activities. Future work

should focus on validating the models and exploring

Update on Our Ongoing Evaluation of Our Workload Monitoring System During a Simulated Event

strategies for situations where operators deviate from

workload levels that affect their level of performance

during crisis management situations.

ACKNOWLEDGEMENTS

This study is part of IMPETUS a research and

innovation project on the Intelligent Management of

Processes, Ethics, and Technology for Urban Safety.

This project receives funding from the European

Union's Horizon 2020 research and innovation

programme under grant agreement No. 883286. All

authors contributed equally to the paper and are listed

in alphabetical order. The writers of this paper are

also the makers of the WL assessment tool used in the

study.

REFERENCES

Gorman (2023) IMPETUS https://www.impetus-project.eu

Yerkes, R.M., Dodson, J.D. (1908) The relation of strength

of stimulus to rapidity of habit-formation. Journal of

Comparative Neurology and Psychology. 18 (5): 459–

482. doi:10.1002/cne.920180503.

Giannakakis, Grigoriadis, Giannakakie et al. (2022) Review

on psychological stress detection using biosignals

IEEE Transactions on Affective Computing, 13 (1):

440-460, doi: 10.1109/TAFFC.2019.2927337

De Groot, T., Heer, J., Hrynkiewicz, R., Tolhuisen, M.,

Oortwijn, T. (2022). Evaluation of Real-time

Assessment of Human Operator Workload during a

Simulated Crisis Situation, Using EEG and PPG. In:

Hasan Ayaz (eds) Neuroergonomics and Cognitive

Engineering. AHFE International Conference. AHFE

Open Access, vol 42. AHFE International, USA. doi:

10.54941/ahfe1001818

ICCAS 2022 - International Conference on Cognitive Aircraft Systems
